LG Xenon GR500 User Manual

LIMITED WARRANTY STATEMENT

1. WHAT THIS WARRANTY COVERS :

LG offers you a limited warranty that the enclosed

subscriber unit and its enclosed accessories will be free from defects in material and workmanship, according to the following terms and conditions:

1. The limited warranty for the product extends for

TWELVE (12) MONTHS beginning on the date of purchase of the product with valid proof of purchase, or absent valid proof of purchase, FIFTEEN (15) MONTHS from date of manufacture as determined by the unit’s manufacture date code.

2. The limited warranty extends only to the original

purchaser of the product and is not assignable or transferable to any subsequent purchaser/end user.

3. This warranty is good only to the original purchaser

of the product during the warranty period as long as it is in the U.S, including Alaska, Hawaii, U.S. Territories and Canada.

4. The external housing and cosmetic parts shall

be free of defects at the time of shipment and, therefore, shall not be covered under these limited warranty terms.

5. Upon request from LG, the consumer must provide

information to reasonably prove the date of purchase.

6. The customer shall bear the cost of shipping the

product to the Customer Service Department of LG. LG shall bear the cost of shipping the product back to the consumer after the completion of service under this limited warranty.

2. WHAT THIS WARRANTY DOES NOT COVER :

1. Defects or damages resulting from use of the

product in other than its normal and customary manner.

2. Defects or damages from abnormal use, abnormal

conditions, improper storage, exposure to moisture or dampness, unauthorized modifications, unauthorized connections, unauthorized repair, misuse, neglect, abuse, accident, alteration, improper installation, or other acts which are not the fault of LG, including damage caused by shipping, blown fuses, spills of food or liquid.

3. Breakage or damage to antennas unless caused

directly by defects in material or workmanship.

4. That the Customer Service Department at LG was

not notified by consumer of the alleged defect or malfunction of the product during the applicable limited warranty period.

5. Products which have had the serial number

removed or made illegible.

6. This limited warranty is in lieu of all other

warranties, express or implied either in fact or by operations of law, statutory or otherwise, including, but not limited to any implied warranty of marketability or fitness for a particular use.

7. Damage resulting from use of non-LG approved

accessories.

8. All plastic surfaces and all other externally exposed

parts that are scratched or damaged due to normal customer use.

9. Products operated outside published maximum

ratings.

10. Products used or obtained in a rental program.

11. Consumables (such as fuses).

3. WHAT LG WILL DO:

LG will, at its sole option, either repair, replace or

refund the purchase price of any unit that does not conform to this limited warranty. LG may choose at its option to use functionally equivalent reconditioned, refurbished or new units or parts or any units. In addition, LG will not re-install or back-up any data, applications or software that you have added to your phone. It is therefore recommended that you back-up any such data or information prior to sending the unit to LG to avoid the permanent loss of such information.

4. STATE LAW RIGHTS :

No other express warranty is applicable to

this product. THE DURATION OF ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY, IS LIMITED TO THE DURATION OF THE EXPRESS WARRANTY HEREIN. LG INFOCOMM INC. SHALL NOT BE LIABLE FOR THE LOSS OF THE USE OF THE PRODUCT, INCONVENIENCE, LOSS OR ANY OTHER DAMAGES, DIRECT OR CONSEQUENTIAL, ARISING OUT OF THE USE OF, OR INABILITY TO USE, THIS PRODUCT OR FOR ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY APPLICABLE TO THIS PRODUCT.

Some states do not allow the exclusive of

limitation of incidental or consequential damages or limitations on how long an implied warranty lasts; so these limitations or exclusions may not apply to you. This warranty gives you specific legal rights and you may also have other rights which vary from state to state.

5. HOW TO GET WARRANTY SERVICE :

To obtain warranty service, please call or fax to

the following telephone numbers from anywhere in the continental United States:

Tel. 1-800-793-8896 or Fax. 1-800-448-4026 Or visit www.lgeservice.com.

Correspondence may also be mailed to:

LG Electronics MobileComm U.S.A., Inc. 201 James Record Road Huntsville, AL 35824 DO NOT RETURN YOUR PRODUCT TO THE ABOVE

ADDRESS. Please call or write for the location of the LG authorized service center nearest you and for the procedures for obtaining warranty claims.

GR500

User Guide

Table of Contents

Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Phone Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Slide Open View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . 9

Installing the SIM Card and Battery . . . . . . . . . . . . . 9

Installing a Memory Card . . . . . . . . . . . . . . . . . . . . . 11

Start Up Guide . . . . . . . . . . . . . . . . . . . . . . . . 14

General Functions . . . . . . . . . . . . . . . . . . . . . 15

Making a Call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . . 16

Setting Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Qwerty Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Address Book . . . . . . . . . . . . . . . . . . . . . . . . . 23

Contact List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

New Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Caller Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Speed Dial List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Contacts Management . . . . . . . . . . . . . . . . . . . . . . . . 25

Service Dial Numbers . . . . . . . . . . . . . . . . . . . . . . . . 25

My Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

In-Call Menu . . . . . . . . . . . . . . . . . . . . . . . . . 26

During a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Making a Second Call . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Swapping Between Two Calls . . . . . . . . . . . . . . . . . . . . 26

Answering an Incoming Call . . . . . . . . . . . . . . . . . . . . . 26

Rejecting an Incoming Call . . . . . . . . . . . . . . . . . . . . . . . 26

Muting the Microphone . . . . . . . . . . . . . . . . . . . . . . . . . 26

Using the Speakerphone . . . . . . . . . . . . . . . . . . . . . . . . 27

Video Share Calling . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Making a Video Share Call. . . . . . . . . . . . . . . . . . . . . . . 27

Answering a Video Share Call . . . . . . . . . . . . . . . . . . . . 30

Making a Video Share Call from the Video Recording

Mode or Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Conference Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Making a Second Call . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Setting Up a Conference Call . . . . . . . . . . . . . . . . . . . . . 32

Activate the Conference Call on Hold . . . . . . . . . . . . . . 32

Adding Calls to the Conference Call . . . . . . . . . . . . . . . 33

Private Call in a Conference Call . . . . . . . . . . . . . . . . . . 33

Ending a Conference Call . . . . . . . . . . . . . . . . . . . . . . . . 33

Your Standby Screen . . . . . . . . . . . . . . . . . . 34

Touch Screen Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

The Quick Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Widget Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Hello UI! Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Annunciator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Menu Tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

AT&T GPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

New Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Inbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

IM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Mobile Email . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Drafts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Outbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Message Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Message Alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Signature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Text Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Multimedia Message . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Voicemail Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Service Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

YELLOWPAGES.COM . . . . . . . . . . . . . . . . . . 56

MEdia Net . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

MEdia Net . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

MEdia Mall . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Shop Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Shop Games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Shop Graphics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Shop Multimedia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Shop Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Shop Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

MEdia Net . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Applications . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Shop Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

MobiTV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Mobile Banking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

My-Cast Weather . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

AT&T Music . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Music Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Additional Music Services . . . . . . . . . . . . . . . . . . . 67

Multimedia . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

CV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

My Stuff . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Voice Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Voice Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Notepad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

World Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Stopwatch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Tip Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Unit Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Alarm Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Camera & Recordings . . . . . . . . . . . . . . . . . . . . . . . . 78

Take Photo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Record Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Camera Album . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Record Voice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Web Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

RSS Reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Bookmarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Saved Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Recent Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

More . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Other Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Shop Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Ringtone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Message Tone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Alert Tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Keypad Tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Power On/Off Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Date & Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Languages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Auto Screen Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Set Flight Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Reset Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Shop Graphics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Wallpapers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Fonts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Backlight Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Themes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Touch Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Send My Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Auto Redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Recent Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Answer Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Minute Minder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Call Reject . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Send DTMF Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

TTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Time & Cost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Bluetooth

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

More . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Application Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Video Share . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Voice Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Software Update . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Phone Information. . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Q&A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . 103

For Your Safety . . . . . . . . . . . . . . . . . . . . . . . 104

Safety Guidelines . . . . . . . . . . . . . . . . . . . . 108

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

Your Phone

Phone Components

1. EARPIECE: Lets you hear the caller and

automated prompts.

2. MAIN LCD: Displays phone status icons,

menu items, web items, web information, pictures and more in full color. You can choose menu on touch pad by touching the icon slightly.

3. SEND KEY: Press this key in standby

mode to quickly access the most recent all, missed, dialed and received calls.

4. End/Power key: Ends or rejects a call.

Turns the phone on/off. Press once to return

to the standby screen.

5. Multi tasking key

6. Micro SD memory card socket

7. Hold key

8. Capture button

9. Side keys

• When the screen is idle: Volume of

key tone.

• During a call: Volume of the earpiece.

• When playing background music:

Controls volume continuously.

Rear View

Your Phone

Battery cover

Flash

External camera lens

Battery

SIM card socket

Micro SD memory card socket

Your Phone

Slide Open View

Text Msg

Mobile Email

Contact list

Caps

Change between Upper Case and Lower Case.

Press Fn key to input symbols and numbers on Qwerty key pad.

Del

Delete digits or letters.

Press to input @

Press to input .com

Press to move to the next

Right

row.

Up Down

Space

Press to create a space between words.

Sym

Press Sym to input various symbols.

Left

Getting Started

Installing the SIM Card and Battery

1. Remove the battery cover

Press the release button at the bottom of the phone and slide the cover. The battery cover should slide and lift off easily.

2. Remove the battery

Hold the top edge of the battery and, using the battery cover, lift it from the battery compartment.

• Using battery cover

Warning

• We do recommend not to user your fingernail to remove the battery not to be hurt.

• Do not remove the battery when the phone is switched on, as this may damage the phone.

Getting Started

3. Install the SIM card

Slide the SIM card into the SIM card holder. Make sure that the gold contact area on the card is facing downward. To remove the SIM card, pull it gently in the opposite direction.

4. Install the battery

Insert the top of the battery first into the top edge of the battery compartment. Ensure that the battery contacts align with the terminals on the phone. Press the bottom of the battery down until it clips into place.

Getting Started

5. Charging your phone

Slide back the cover of the charger socket on the side of your LG Xenon. Insert the charger connector to the phone (‘B’ side of the connector has to be facing up when connecting to the phone) and then plug into the wall socket. Your LG Xenon will need to be charged until a message reading “Battery full. Please unplug charger to save energy” appears on the screen.

Important!

You should insert the battery before charging.

Warning

Use of unauthorized accessories could damage your phone and void your warranty.

To use the travel charger provided with your phone:

Installing a Memory Card

You can expand the memory available on your phone by using a microSD memory card. The LG Xenon will support up to a 16 GB microSD memory card.

Tip

A memory card is an optional accessory.

1. Lift the memory card cover and insert a

microSD card with the gold contact area facing downwards. Close the memory card cover so that it clicks shut.

Getting Started

Note

If your memory card has existing content it will automatically be filed in the correct folder. For example, videos will be accessible from the My Videos folder. If your memory card has protected content (i.e. content such as songs or graphics with Digital Rights Management copywriting loaded from another device), it will not work. You will need to reformat the memory card prior to using it with this device.

On-Screen Icons

The table below describes various display indicators or icons that appear on the phone's display screen.

Getting Started

ICON/

INDICATOR

Multitasking

Network signal strength (number of bars will vary)

No network signal

Battery empty

New text message

New email

An alarm is set

Normal profile in use

Silent profile in use

DESCRIPTION

ICON/

INDICATOR

EDGE available

Bluetooth® is active

The browser is active

Vibrate mode

Speakerphone

Call in Progress

Voicemail

Battery Full

Battery Charging

Airplane Mode

DESCRIPTION

Start Up Guide

After you install SIM card and battery, and turn on the LG Xenon, you will see Start Up Guide on the screen.

Touch Start and it will show you an easy guide to follow. Touch to see animation description. Touch Next to move on to the next screen. You will see:

]

Unlock Your Phone

]

Open Menu & Select Item

]

Scroll Page, Navigate between

]

Navigate between Items

]

Rotate Screen Orientation

]

Open Keypad and Enter Text

]

Change the standby screen

]

Add Shortcuts on the standby screen

]

How to Add Contacts on the standby screen

General Functions

Making a Call

1. Make sure your phone is powered on.

2. Touch

] Press and hold the key to erase the

3. Press the [SEND] key to call the

4. When finished, press the

Making a Call with the Send Key

1. Press the [SEND] key, and the most

2. Select the desired number.

3. Press the

and touch a phone number on the touch pad. Or slide open the qwerty pad and enter a phone number including the area code. To edit a number on the display screen, simply press the one digit at a time.

entire number.

number. Or touch on touch pad.

recent missed, dialed and received phone numbers will be displayed.

[SEND] key or touch

key to erase

[END] key.

Making International Calls

1. Press and hold the key and the

international access character ‘+’ will appear. On touch pad, touch and hold

2. Enter the country code, area code and the

phone number.

3. Touch

Ending a Call

When you have finished a call, press the

[END] key.

Making a Call from the Contacts

You can store frequently called names and phone numbers in the SIM card as well as in the phone memory known as the Contacts.

You can dial a number by simply selecting a name in the contacts and pressing the [SEND] key.

General Functions

Answering a Call

When you receive a call, the phone rings and the phone icon appears on the screen. If the caller can be identified, the caller’s phone number (or name if stored in your Address Book) is displayed.

1. Press the

If Any Key has been set as the Answer Mode, any key press will answer a call except for the [END] key, ,

2. End the call by pressing the [END]

key.

Note

You can answer a call while using the Address Book or other menu features.

[SEND] or touch Accept.

and .

Adjusting the Volume

During a call, if you want to adjust the earpiece volume, use the side volume keys of the phone.

In idle mode, you can adjust the ring volume using the side volume keys.

Setting Proﬁ les

Press either of the side volume keys. You can set your Ringtone to Vibrate All, Alarm Only or Silent All.

General Functions

You can adjust the touchtone sound and vibration volume.

Vibration Mode (Quick)

Vibration Mode can be activated by touching and holding . You can set Vibration Mode by pressing and holding down side volume key as well.

General Functions

The phone will display ‘Vibrating Mode On’. If you would like to turn Vibration mode Off, touch and hold again.

Signal Strength

If you are inside a building, being near a window may give you better reception. You can see the strength of your signal by the signal indicator on your phone’s display screen.

Entering Text

You can enter alphanumeric characters by using the phone’s touch pad. For example, storing names in the Address Book, writing a message or scheduling events in the calendar all require text to be entered.

The following text input modes are available on the phone.

Changing the Text Input Mode

Change the text input mode by touching .

Using the Symbol Mode

The Symbol Mode enables you to enter various symbols or special characters. To enter a symbol, touch . Select the desired symbol.

ABC Mode

This mode allows you to enter letters by touching the key labeled with the required letter once, twice, three or four times until the letter is displayed.

General Functions

123 Mode (Numbers Mode)

Type numbers using one keytouch per number. To change to 123 mode in a text entry field, touch .

Using the T9 Mode

The T9 predictive text input mode allows you to enter words easily with a minimum number of key presses. As you touch each key, the phone begins to display the characters that it thinks you are typing based on a built-in dictionary. As new letters are added, the word changes to reflect the most likely candidate from the dictionary.

1. When you are in the T9 predictive text

input mode, and touch It will be the word ‘Be’. Touch one key per letter.

] The word changes as letters are typed

- Ignore what is displayed on the screen until the word is typed completely.

] If the desired word is missing from the

word choice list, add it by using the ABC mode.

and .

2. Enter the whole word before editing or

deleting any letters.

3. Complete each word with a space by

touching

To delete letters, touch down word.

Note

Pressing the [END] key will save your unsaved message in the Drafts folder.

. Touch and hold

to continuously erase the whole

Using the ABC Mode

Use the keypad keys to enter your text.

1. Touch the key labeled with the required

letter:

]

Once for the first letter

] Twice for the second letter

]

And so on

2. To insert a space, touch . To delete

letters, touch . Touch and hold down

to continuously erase the whole word.

General Functions

n Note

Refer to the table below for more information on the characters available using the keys.

Touch to input a Upper Case letter. To change text entry mode from Lower Case to Upper Case, touch

twice and the key will turn to orange color. works as Caps Lock key of Qwerty keypad.

Characters in the Order Display

Key

Upper Case Lower Case

1 . , ' @ ? ! - : / 1 . , ' @ ? ! - : / 1

2 A B C 2 a b c 2

3 D E F 3 d e f 3

4 G H I 4 g h i 4

5 J K L 5 j k l 5

6 M N O 6 m n o 6

7 P Q R S 7 p q r s 7

8 T U V 8 t u v 8

9 W X Y Z 9 w x y z 9

Space Key,

0 (Long press)

Space Key,

0 (Long press)

Using the 123 (Numbers) Mode

The 123 Mode enables you to enter numbers in a text message (a telephone number, for example) more quickly. Touch the keys corresponding to the required digits before manually switching back to the appropriate text entry mode.

T9 dictionary

The T9 dictionary is a feature that allows the user to add any unique or personal words to the T9 standard language database. The T9 dictionary function can be selected from the Text Entry Settings by using Options . Within the T9 dictionary function, the user can add, modify, delete or reset personal words.

Note

You can select a different T9 language from the Options menu. The default setting on the phone is the T9 disabled mode.

General Functions

Qwerty Keypad

Text input mode using the Qwerty Keypad

When you are required to enter text, for example when writing a message, the keypad will default to ABC mode. If you are entering a number, for example when making a call, the keypad number keys will default to numbers. In ABC mode you can enter numbers by first pressing and then the number you require.

Note

Some fields may allow only one text input mode (e.g. telephone number in Address Book fields).

To input a symbol in the text entry field, press the key and select a symbol from touch screen, then select OK. Or for simple symbol, just press and press the symbol. To return ABC mode, press again.

Scroll using the navigation keys to show more symbol options.

Complete each word with a space by pressing

. To delete a character, press key.

General Functions

Using the Korean Mode

Allows you to type in Korean when you set the language to Korean.

When you use Touch Keypad

Allows you easily input the letters. To input touch and touch . To input , touch

and touch .

When you use Qwerty Keypad

Open the slide and you can see the Korean key guide on the monitor. To input numbers, touch

Touch once, and you can see the Korean key guide as below. To return its normal input mode, touch again.

Address Book

From standby screen, touch and touch

. You will see following Address Book’s

submenus.

Contact List

This menu allows you to save and manage contact address information. The Contact List's functions allow you to add a new address or search saved contact addresses by name. To search a contact address, touch and input the contact person’s name. If you input ‘At’, it will show all contacts including ‘At’ in its name. From the standby screen, you can directly search for a contact by touching

and .

New Contact

This menu allows you to add a new contact address. You can enter contact address information including name, phone numbers, email addresses, group information pictures, ringtone and memo.

]

From the standby screen, Touch and

touch . Select New Contact.

]

Touch to set a Picture ID for a contact

by using a saved picture from Pictures or taking a New picture of the contact person. Choose from No picture, Pictures or Take New Picture. After you take a new picture of the contact person, touch to save. To delete the picture, touch and take a new picture.

Address Book

]

Enter the First name, last name or both.

Enter up to five different numbers. Touch

and you can set that number as Speed

Dial.

]

Enter email address and set the Group type

for the contact.

]

Set the ringtone for the contact or leave it

as default ringtone.

]

Add memo if necessary.

]

Choose whether to save the contact to

Phone or SIM Card.

]

Touch to save the contact.

Caller Groups

This menu allows you to manage group information. By default, there are 4 groups: Colleague, Family, Friends and School. Or you can put a contact in No Group. You can also configure a ring tone for a group so that the group ring tone sounds when a call from a specific contact address within that group is received and there is no ring tone configured for the specific contact address.

Speed Dial List

You can assign a frequently-called contact to a speed dial list. You can select a number from 2 to 9 as a speed dial. You can configure speed dial numbers for any of the 8 numbers for a specific contact address.

]

Your Voicemail are already set to speed

dial 1. This is default and can not be changed. Touch any other number to assign it a speed dial contact and touch

]

Your address book will open. Touch twice

the contact you’d like to assign to that number.

]

To call a speed dial number, touch from

the standby screen then touch and hold the assigned number until the call initiate automatically.

Contacts Management

This menu allows you to copy all of the information from your SIM card, e.g. name, handset number, etc. to your handset. If a name is duplicated during the copying operation, the information is also duplicated.

You can copy the entry from the SIM card to the phone memory. You can copy the entry from the handset memory to the SIM card (not all the data will be copied).

You can delete all entries in the SIM card the Handset. Press the to standby mode.

[END] key to return

Address Book

Service Dial Numbers

You can view the list of Service Dialing Numbers (SDN) assigned by your network provider. Such numbers could include the emergency services, directory assistance and voice mail numbers.

1. Select the Service dial number option.

2. The names of the available services will

be shown.

3. Touch a service number. Press the

[SEND] key.

My Numbers

This displays your phone numbers stored in the SIM card. You can edit its name and number by touching or you can choose and delete the information.

In-Call Menu

Your phone provides a number of control functions that you can use during a call. To access these functions during a call, touch

During a Call

The menu displayed on the handset screen during a call is different from the default main menu displayed when in the idle screen, and these options are described below.

Making a Second Call

You can select a number you wish to dial from the Address Book, to make a second call. Touch Contact on the screen. Then, you can press SEND key to make a second call.

Swapping Between Two Calls

By using one of three methods, you can switch between two calls.

1. Press [SEND] key.

and select “Swap Calls.”

2. Touch

Answering an Incoming Call

To answer an incoming call when the handset is ringing, simply press the [SEND] key. The handset is also able to warn you of an incoming call while you are already on a call. A tone sounds in the earpiece, and the display will show that a second call is waiting. This feature, known as Call Waiting, is only available if your network supports it.

If Call Waiting is turned on, you can put the first call on hold and answer the second call by pressing the

[SEND] key.

Rejecting an Incoming Call

You can reject an incoming call without answering by simply pressing the [END] key.

Muting the Microphone

You can mute the microphone during a call by touching . The handset can be unmuted by touching . When the handset is muted, the caller cannot hear you, but you can still hear the caller.

In-Call Menu

Using the Speakerphone

You can use the integrated Speakerphone during a call by touching . The loudspeaker is automatically deactivated when you end the call.

Warning

Due to increased volume levels, do not place the phone near your ear while the speakerphone is enabled.

Video Share Calling

Making a Video Share Call

You can make or answer a Video Share call with other 3G video phones. In order to start a Video Share call, both sides must have a 3G Video Share capable phone and both must be in a 3G coverage area.

Note

Before you start a Video Share Call you must check the following:

• Phone must be in an AT&T 3G service area.

To initiate Video Share follow these steps:

1. Make a phone call by dialing a number, or

selecting a number from Address book. Or directly make a video share call from the Recent Call or Contact List by selecting

> [Video Share Call] and selecting Video Type (Live or Recorded). In this case skip steps 2-3.

2. A few seconds after the connection is

established, a "Video Share Ready" prompt will appear on the screen once the other party is ready to use the Video Share service. If Audio alert in Video Share setting (See Application Setting) is set to

, audio alert will sound along with

prompt.

3. To Share Video with an other party, touch

Video icon or press the Camera key and select Video Type (Live or Recorded).

In-Call Menu

Note

The Speakerphone will be automatically activated when a Video Share session begins, unless a hands-free device (Bluetooth headset) is connected.

• Live: Share a real-time video stream with the

other party.

• Recorded: Share a pre-recorded video

clip with the other party. (Note that H.263 & Mpeg4 video formats in 176x144 size is supported)

or stereo

4. If the other party accepts the Video Share

invitation, the Video Share session will begin. (After accepting, it may take several seconds before the actual Video Share starts.)

During a Video Share call, you can do the following by touching the icons below:

]

/ : You can turn on/off the

Speakerphone.

]

/ : You can mute/unmute

the microphone.

]

: You can stop a Video Share Call

and proceed to a Voice Call.

You can choose from the following:

]

Brightness: You can adjust the brightness

of the screen by selecting Brightness.

]

Zoom: You can zoom in/out the video by

selecting Zoom.

]

Audio to Bluetooth®/Audio to Phone:

When Audio to Bluetooth® is selected, you can have a conversation using Bluetooth®. When Audio to Phone is selected, you can have a conversation using either speakerphone or headset.

]

Record Video Share/Stop Recording:

You can start recording the live video by selecting ‘Record Video Share’. Once you are recording the video, you can stop recording by selecting ‘Stop Recording’.

]

End Call: You can end the phone call by

selecting ‘End Call’. (Note: Video Share will stop as well)

]

Hold Call: You can hold the phone call by

selecting ‘Hold Call’. (Note: Video Share will stop when you select ‘Hold Call’)

In-Call Menu

During the Video Share session, turn the speakerphone on/off using the ‘Spk. off’ / ‘Spk. on’ key.

Note

Recorded video clip will be saved in [My stuff] - [More].

5.1. Stop a Video Share call and proceed to a

voice call by

1. Touching [Stop] Icon

2. Selecting > [Stop Video share]

5.2. End a voice call along with the Video

Share call by

1. Pressing [End] Key

2. Selecting > [End Call]

Note

1. A Video Share Call will be terminated in the

following cases:

• When trying to make a conference call/ second call during a Video Share Call.

• When the voice call is placed on hold.

• When the voice call is disconnected.

• When moving out of an AT&T 3G service area.

• When the network connection is poor.

2. A Video Share Call will be unavailable in

the following cases (“Video Share Ready” message will not appear).

• When trying to make a conference call/ second call during a Video Share Call.

• When the voice call is placed on hold.

• When moving out of an AT&T 3G service area.

In-Call Menu

Answering a Video Share Call

1. Touch [Accept] when prompt asking “The

other party wants to share Video Share with you” appears, to start the Video Share Call. Touch [Decline] to decline the Video Share call. (Note that after accepting the call, it may take several seconds before the Video Share session starts.)

During Video Share call, you can do as following by touching icons below:

]

/ : You can turn on/off the

Speakerphone.

]

/ : You can mute/unmute

the microphone.

]

: You can stop Video Share Call

and proceed to Voice Call.

You can choose from the following:

]

Landscape mode: When Landscape mode

is selected you can watch shared video in landscape mode.

]

Audio to Bluetooth®/Audio to Phone:

When Audio to Bluetooth

is selected, you can have a conversation using Bluetooth®. When Audio to Phone is selected, you can have a conversation using either speakerphone or headset.

Note

The speakerphone will be automatically turned on when a Video Share Call begins, and automatically reverts back to the previous mode when a Video Share Call ends.

In-Call Menu

Making a Video Share Call from the Video Recording Mode or Video

When you are Recording Video, you can easily make a Video Share Call to a person in your Contact List.

1. Start Video Share call as follows:

]

In Record Video Mode, Touch .

] In Video Gallery, touch and choose

Video Share Call.

Note

This menu item is active only in 3G coverage areas and on Video Share capable devices.

Note

If the other party is not ready for Video Share, the call will proceed to an ordinary voice call.

Saving your Video Share

The sender can record video during the Video Share session by

1. Selecting [Option] > [Record Video Share]

during a live Video Share call.

2. Setting Auto Record to ‘ON’

(See Application Settings).

Sender can save the recorded video by

1. Selecting [Option] > [Stop Recording] during

a live Video Share call.

2. Ending Video Share call.

Recorded video will be saved in [My Stuff] > [Videos] folder in the phone.

In-Call Menu

Conference Calls

The conference service provides you with the ability to have a simultaneous conversation with more than one caller. The conference call feature can be used only if your network service provider supports this feature.

A conference call can only be set up when you have one call active and one call on hold, meaning both calls must have been answered. Once a conference call is set up, calls may be added, disconnected or separated (that is, removed from the conference call but still connected to you) by the person who set up the conference call. These options are all available from the In-Call menu.

The maximum number of callers in a conference call is five. Once started, you are in control of the conference call, and only you can add calls to the conference call.

Making a Second Call

You can make a second call while currently on a call simply by entering the second number and pressing the [SEND] key. When the second call is connected, the first call is automatically placed on hold. You can swap between calls by pressing the [SEND] key.

Setting Up a Conference Call

To set up a conference call, place one call on hold, then conference in the second active call by touching and select the Join Calls sub menu option from the Conference Call menu.

Activate the Conference Call on Hold

To activate a conference call on hold, press the [SEND] key.

Adding Calls to the Conference Call

To add a call to an existing conference call, touch and then select the Join Calls sub menu from the Conference Call option.

Private Call in a Conference Call

To have a private call with one caller from a conference call, touch and select Private Call from the Conference Call option. When the numbers of the callers are displayed, select the one you wish to speak in private with. Only the person who initiates the Conference Call can initiate a Private Call.

Ending a Conference Call

The currently active conference call can be disconnected by pressing the [END] key.

In-Call Menu

Your Standby Screen

Whenever your LG Xenon is not in use it will return to your standby screen. From here you can access all menu options, make a quick call and view the status of your phone - as well as many other things.

Touch Screen Tips

The standby screen is also a great place to get accustomed to the touch screen.

To select an item, touch the icon accurately. Your LG Xenon will vibrate slightly when it recognises you’ve touched an option.

To scroll through lists, touch the last item visible and slide your finger up the screen. The list will move up so more items are visible.

]

There’s no need to press hard, the

touchscreen is sensitive enough to pick up on a light yet firm touch.

]

Use the tip of your finger to touch the

option you require. Be careful not to touch any other keys.

]

When the screen light is off, press and

hold the on the right hand side to restore the standby screen.

]

Don’t cover the phone with a case or cover

as the touch screen will not work with any material covering it.

Quick keys

Your Standby Screen

The Quick Keys

The quick keys on your standby screen provide easy, one-touch access to your most used functions.

Touch to bring up the touch dialling pad to make a call. Input the number as you would using a normal key pad and touch or press the hard key.

Touch to access the Messaging options menu. From here you can create a new SMS.

Touch to open your contacts. To search for the number you want to call. Enter the name of the contact using the touchpad. You can also create new contacts and edit existing ones.

Touch to open the full Top menu which is separated into four submenus. Touch the vertical tabs to view further options.

Your Standby Screen

Widget Mode

]

Click to open the Widget mode.

]

When the standby screen is Widget mode,

you can drag and click what you need right away. Touch

]

You can play songs, add memos, check the

calendar, play slide show, set an alarm or add events directly from the standby screen using Widget mode.

]

Click to close the Widget mode.

to open Widget mode.

Widget

Hello UI! Mode

Allows you to easily contact your friends and family by displaying your favorite contacts on the standby screen.

]

First, touch from the standby screen.

Touch and hold .

]

Select and choose the contact. You

can choose up to 6 contacts for one page.

]

If you slightly shake or move the phone, the

contacts will float in the screen. If you want to delete a contact from the Favorite mode, touch .

]

Touch to align the contacts on the

screen.

Your Standby Screen

]

Touch and the contact will have a

slight shadow around it. If you slightly shake or move the phone, the contacts will float in the screen. Touch again and the contacts will be fixed and not be moved by the phone’s status.

Your Standby Screen

]

Touch and you can now select a

Favorite contact from standby screen. Touch

to call, touch to send a message and touch to check the message you received from that person.

]

If you want to edit the Favorite contacts,

touch and hold the contact or the margin space of the screen. It will turn to the Edit screen.

Shortcuts Mode

Add your favorite menu on standby screen.

]

Touch and hold the menu or the margin

space of the screen. It will turn to the Edit Screen.

Touch to add other menu, touch

to delete the menu from Shortcuts, touch

to finish.

Annunciator

With LG Xenon’s Annunciator, you can quickly connect to the Music Player, Bluetooth service and more.

Touch the top side of the standby screen.

]

You can use Music Player to edit a playlist

or turn on Bluetooth.

]

You can set your profile by touching .

You can set your profile to Normal, Ring and Vibration, Ring after Vibration or Silent and Vibration.

Your Standby Screen

]

To send a Text message, touch .

To send a Mobile Email, touch . To check Voicemail, touch .

]

To use IM, choose from .

If you want to set an Alarm, touch . To view the Calendar and add new events, touch .

Menu Tree

Touch in the standby screen to open a Top menu. From here you can access further menus: Phone, Multimedia, My stuff and Settings

Phone

Dialing Address Book Recent Calls Messaging Mobile Email IM AT&T GPS YELLOWPAGES.COM

My stuff

Audio Pictures Video Tools Calendar Alarm Clock Calculator More

Multimedia

MEdia Net MEdia Mall AT&T Music CV Applications Games Camera Web Pages

Settings

Call Date & Time Sound Display Tou ch Phone Bluetooth More

AT&T GPS

The AT&T Navigator application on your device uses GPS position determination technology and access to your carrier’s data network to provide you with driving directions and a host of other services, including:

]

GPS navigation that gives you turn-by-turn

directions to any destination address in the continental United States. If you miss a turn or get off-track, AT&T Navigator will calculate a new route for you. You can enter a destination address by using AT&T Navigator’s automatic voice recognition system or by typing on the device’s keypad.

]

Audio and visual traffic alerts while driving

or viewing maps, as well as traffic rerouting capabilities to minimize delays on your trip.

]

A Search feature that allows you to find

businesses or points of interest near your current location, an airport, a waypoint, or any other entered address. You can read ratings and reviews for businesses and easily call the business that you have found to check on the availability of an item or to make a reservation. You can navigate to the business location now or save the address for later use.

]

Maps of the area around your current

location, around a marked waypoint, or around an address that you had previously entered. You can pan the map (adjust left, right, up, or down) and zoom in or out. You can also mark a point under the cursor as a waypoint.

]

A compass-like indicator presenting your

direction of travel, location, and speed.

]

The ability to personalize your application

preferences by selecting U.S. customary or metric distance units, the language for audible guidance, and so on.

You can also use many of AT&T Navigator’s features on the TeleNav website, such as getting driving directions (Route Planning) and using the Search function to find businesses, churches, schools, and government offices. You can also use the TeleNav website to add an address to your My Favorites list, manage your My Favorites and Recent Places lists, and shop at the TeleNav Store.

AT&T GPS

Note

For best GPS performance

• In order to improve GPS antenna sensitivity, do not cover the GPS antenna area of the device.

• Your GPS antenna sensitivity might be weakened if you are in a high rising building, underground, or location surrounded by metal or concrete.

• Use near the window indoors for better GPS antenna sensitivity.

• For battery durability, please use vehicle power adapter in your car.

• It could take 2~3 minutes to get your GPS position depending on the condition of the environment or network.

Messaging

This menu includes functions related to SMS (Short Message Service), MMS (Multimedia Message Service), voice mail as well as the network's service messages.

New Message

In the standby screen, select . Touch Create Mess age.

Note

If you select a graphic or an audio file while writing a multimedia message, the file loading time will take about 5 seconds. You will not be able to activate any key during the file loading time. When the file loading is complete, you will be able to write a multimedia message.

Editing a message

The following options are available when Editing a Message.

]

Symbol: You can insert symbols ranging

from sentence notes to emoticons. Touching the twice, and you can select the symbols you want. You can use and

to find a icon.

]

Picture: Touch and choose Picture.

You can select a graphic image. You can preview the selected picture by choosing Icon View.

]

Audio: You can insert various ringtones.

]

Video: You can insert a video clip.

]

Take New Picture: You can insert a new

image taken from the camera by pressing

[Capture]. The following camera options

are available when you press [Settings].

Messaging

Preview tab

• View Mode: Choose between Full Image

and Full Screen.

• Image Size: The resolution of the

image can be captured in 1600*1200 / 1280*960 / 640*480 / 320*240.

• Brightness: Adjust brightness by

adjusting the slider.

• Color Effects: Includes options of Color/

Mono/Sepia/Negative/Blue.

• White Balance: Set the White Balance

as Auto/Daylight/Cloudy/Illuminate/ Indoors.

• Night Mode: This is useful to take a

photo in a dark place.

• Timer: The Timer can be set to

Off/3 Seconds/5 Seconds/10 Seconds.

• Image Quality: Set the image quality as

Super Fine/Fine/Normal.

• Continuous Shot: This is great for

taking photos of moving objects or at sporting events. Allows you to set 3 shots, 6 shots or 9 shots continuously. This option is only available when you set image size as 320*240.

Others tab

• Save to: Phone Memory or Memory

Card. If you do not insert a memory card, it will save to Phone.

• Shutter Tones: Can be set to Tone 1 /

Tone 2 / Tone 3 / Off.

• Reset Settings: Allows you to set to

default settings.

]

Record Audio: You can record a new audio

clip by touching .

• Quality: Set the audio quality to

Fine, Normal or Economy.

• Select Storage Defaults: You can

assign the default storage to Phone Memory or Memory Card.

Record Mode: MMS mode record

• time is about 6 minutes and the General mode provides a longer recording time.

]

Record New Video: You can record a

new video.

]

Template

- Text: You can easily insert frequently used

sentences in the text message.

- Multimedia: Preset multimedia templates

are available.

- Signature: Input your own created

signature. For further details, see page 53.

]

More: Allows you to insert Subject, vCard,

vCalendar, vNote, vTask or Contact.

Note

vCard, vCalendar, vNote, vTask and Contact are created by Address Book, Calendar, Notepad and Tasks respectively. Go to the menu paths sections for more detailed information.

Messaging

Using Options

Touch

to use options below.

• Text Entry Settings: Text Entry Language

allows you to set the text entry language to English, Français, Español or Korean. You can set to use Show Word Candidate List. Also, Next Word Prediction is available when it is set to On. Use T9 Dictionary to add words or delete/reset/ modify words.

• Delivery Options

- Delivery Receipt: If this is set to On in

this menu, you can check whether your message was sent successfully.

- Reply via Same Message Center: You

can set On or Off.

• Save to Drafts: Saves the selected

message to Drafts.

• Writing Font Size: Sets the Writing Font

size from Small, Medium and Large.

• Cancel Message: Allows you to exit the

text input mode without saving your input message.

Messaging

Sending a Message

After completing a message using the Insert/ Options, select Send To to send a message.

• Enter the recipient(s). From

, you can

choose an option item below.

- Enter Number: You can input the

recipient(s) number using Touch keypad or Qwerty keypad.

- Enter Email: You can enter Email address

instead of phone number.

- Caller Groups: Shows Contacts in Group.

- Recent Messages: Choose a contact

from recent messages.

- Recent Calls: Choose a contact from

recent calls.

- Delivery Options: Options of Delivery Receipt, Reply via Same Message Center, Add Cc, and Add Bcc.

- Edit Message: Go back to the message

editing mode.

- Save to Draft: Saves the selected message to Drafts.

- Cancel Message: You can cancel the message.

Tip

Text messages can be copied from the SIM card to the phone and vice versa.

Message folders

You’ll recognise the folder structure used on your Xenon, which is fairly self-explanatory.

]

Inbox: All the messsages you receive are

placed into your Inbox. From here you can view, delete and more, see Managing Your messages below for details. You can enter this menu through Message box.

]

Drafts: If you don’t have time to finish

writing a message, you can save what you’ve done so far here.

]

Outbox: This is a temporary storage folder

while messages are being sent.

Note

If you see the message “No space for USIM messages”, then you should delete some messages from your Inbox. If you see the message “No space for messages”, then you can delete either messages or saved files to create space.

Messaging

Inbox

You will be alerted when you receive a message. They will be stored in the Inbox. In the Inbox, you can identify each message by icons. To reach the Inbox, from the standby screen, Touch

The following [Options] when you select a message and touch.

]

Add to Address Book: You can save the

sender's phone number in the Contact List.

]

Select Slide: If the multimedia message

has more than one slide, you can select and move to the desired slide.

]

Extract Data: You can make a voice call or

send message. You can save the number As New contact or Updating Existing.

]

Copy to SIM/Move to SIM: You can copy

or move the message SIM depending on where the text message is stored.

]

Message Details: You can view

information about received messages; message Type, Subject, Sender's address, and message Time.

and touch Inbox.

The following Options are available in Inbox folder.

]

Delete: You can pick a message and

delete it.

]

Sort by: You can sort all messages by

Name, Title, Date and Read/Unread.

]

Delete All Read Messages: You can

delete all read messages.

The Instant Messaging feature can only be used with the support of the network operator or communities such as AIM, Windows Live and Y! Messenger. For Instant Messaging users, a valid User ID and Password will be required in order to login and exchange messages as well as checking the online status.

Messaging

To access the IM feature

1. Touch

2. You can see available IM clients. The menu

and touch .

items below might not appear as not all IM communities support the various options. In addition, the menu strings may appear differently. This depends on the selected IM communities. The keywords such as User ID, Login and Contact will be used as general terms in IM menus according to the currently selected communities such as AIM, Windows Live and Yahoo! Messenger.

Offline Menu

This allows users to login by filling in the User ID and Password.

Note

Once the User ID and Password are saved, you will not be required to type them in again during the Login process. This feature is optional.

Saved Conversations

This is where a user can view saved conversations.

Settings

]

Set Sound: Allows you to turn alerts

On/Off for a Contact when they have

activity on their session.

]

Network: You may check your Network

Profiles or Server Address information.

IM Information

This displays the Instant Messaging Client Information such as Client Name and Version Number.

Online Menu / 1-to-1 conversation

After a successful Login, a list of contacts with Screen Names will appear on the screen.

Messaging

When cursor is located on a Conversation

]

End Conversation: This closes the

selected conversation. If an unknown contact was selected, that contact is deleted.

]

Block/Unblock Contact: This allows you

to block/unblock the selected Conversations Contact.

]

Contact Info: This allows you to view the

User ID and Status Text information.

When cursor is located on a Contact List

]

Refresh Contact List: This refreshes the

current information on the contacts within the list.

When cursor is located on a Contact

]

Delete Contact: This deletes the selected

Contact.

]

Move Contact: Allows you to move a

Contact to another Contact List.

Messaging

]

Block/Unblock Contact: This allows you

to block/unblock a conversation with the selected Contact.

]

Contact Info: This allows you to view

information. It provides User ID, Status Text.

Menu options available in the Conversation screen

]

Insert: You can insert a Symbol, Template

and emoticons in the conversation screen. This feature is accessed by pressing the left soft key.

]

Back to Contacts: This brings the screen

back to the contacts.

]

My Communities: Displays the list of

Email providers.

]

Block/Unblock Contact: This allows you

to block/unblock a conversation with the selected Contact.

]

Add to Contact List: Allows you to add

the person you are currently having a conversation with to a Contact List.

]

Save Conversation: Stores the currently

active conversation.

]

End Conversation: This ends the active

conversation and clears the conversation buffer.

]

Settings:

- Display Name

- My Status: Allows you to set your status

to Available, Busy or Invisible.

- Offline Contacts

- Set Sound: Allows you to turn on/off

an alert for the Contact when they have activity on their session.

- Auto Sign In

]

Text Entry Mode: Sets the text input mode

such as abc, Abc, ABC, T9 abc, T9 Abc, T9 ABC and 123.

]

Text Entry Mode Settings: This selects

the T9 predictive mode Language. This feature also allows you to turn T9 mode on or off, and to access the T9 Dictionary, Text Entry Language.

]

Minimize: Minimizes the IM window and

returns to standby mode.

]

Sign Out: This begins the logout process.

Note

• In the conversation window, you can use the up/down select for scrolling through the conversation.

• The maximum number of characters supported by a message is 800 characters, for receiving, and 127 characters for sending.

• The current information might not update in real time so the "Refresh List"/"Refresh Contact" option can be used for the most up to date status.

Mobile Email

Mobile Email allows you to access your Yahoo! Mail, AOL Mail, AIM Mail, Windows Live Hotmail, AT&T Yahoo!, BellSouth Mail and Other providers accounts on your phone. So, now you can quickly and easily check your email while you are away from your computer.

Messaging

To Set Up Mobile Email

]

Open Mobile Email: From the standby

screen, Touch Menu, and touch Mobile Email.

]

Select an Email Provider: Touch and hold

the email provider you wish to use.

]

1. Highlight the ID entry field, touch and

then type in your existing email ID.

2. Touch the Password field, highlight on

the select, and enter your password.

Quick Tip: Your password is case

sensitive. Press the

button on the keypad to change to lower case or upper case.

3. To save your password scroll down to

Remember Me and press down on the select to check the box.

4. Select Sign In.

Messaging

]

Opening an Email: Just scroll down and

highlight the email subject line you want to open and touch on the select. When the email is open, select Options to reply, forward or delete.

]

Deleting an Email: Scroll down to the

email you want to delete, Touch, then Delete.

For additional details, visit www.att.com/email.

Drafts

You can view the messages saved as drafts. To see the Drafts, in the standby screen, Touch and touch . Touch Drafts.

Outbox

Outbox is a temporary storage place for messages waiting to be sent. When you press the [SEND] key, you can make a call to the number of the recipient number of the selected message.

If the message is not sent from the Outbox, you will receive a sound alert along with a Message Sending Failure notice on the screen. Another attempt will be made to send the failed message and after two unsuccessful attempts, the message will no longer be sent automatically. In order to send the message that has failed, you must touch

After the maximum number of Send attempts has been reached, the Send function has failed. If you were trying to send a text message, open the message and check that the Sending options are correct.

Outbox list will display messages in sending failed, sending or waiting, sent order. Touch

]

Delete: Deletes a message you choose.

]

Sort by: Sorts by name, title and date.

]

Delete All: Delete all messages.

to resend the message.

to use options aviable from Outbox list.

Messaging

Those options are available when you choose a message in Outbox.

]

Edit: Allows you to edit the selected

message.

]

Select slide: If the multimedia message

has more than one slide, you can select and move to the desired slide.

]

View Attachment: View attachment of

the message.

]

Message Details: Allows you to view the

information on the message.

Voicemail

This menu provides you with a quick way of accessing your voice mailbox (if provided by your network).

This may already be available; to check the voicemail, touch and hold the key.

Note

Please check with your network service provider for details of their service in order to configure the handset accordingly.

Message Settings

To set the message, Touch . Touch Message Settings.

Message Alert

You can set the Sounds and Alert Type here.

Save to: Choose between Phone and SIM Card to save message.

Signature

This feature allows you to create your Text signature. You can use symbols, templates and contacts as part of the signature.

Text Message

]

Text Template

There are 6 predefined messages in the

list. You can view and edit the template messages or create new messages. The following [Options] are available.

- Send: Allows you to send the selected

template via Message.

- Delete: Allows you to delete the selected

template message.

Messaging

- Edit: Allows you to edit the selected

template message.

- Delete All: Deletes all messages in the

folder.

]

Message Center Number: If you want

to send a text message, you can get the address of the SMS center by using this menu.

]

E-mail Gateway: You can send the text

message to an Email Address via this gateway.

]

Message Subject: You can enter the SMS

Subject when this menu is ON. You can switch between to by dragging it from left to right.

]

Message Types: Convert your text into

Voice, Fax, X.400 or Email.

]

Validity Period: This network service

allows you to decide how long your SMS messages will be stored at the message center.

]

Delivery Receipt: Allows you to ask

a delivery confirmation mail for a SMS Message.

]

Reply via Same Message Center: Allows

you to reply via the same message center where you received a message from.

]

Insert Signature: Insert signature you

created.

Multimedia Message

]

Multimedia Templates: The preset

multimedia templates are available.

]

Priority: You can choose to set the priority

of the message.

]

Message Subject: You can enter the

MMS Subject when this option is . You can switch between to by dragging it from left to right.

]

Validity Period: This network service

allows you to decide how long your multimedia messages will be stored at the message center.

]

Send Delivery Receipt: Allows you to

send a delivery confirmation mail for a Multimedia Message.

]

Send Read Receipt: Allows you to send

a message read confirmation mail for a Multimedia Message.

]

Download Options

- Download Without Ask: Allows

Multimedia Messages to be downloaded automatically.

- Ask Always: You can download a

multimedia message manually.

- Discard: Used when the user rejects

download of the Multimedia Message.

]

Message Center: The details for the

Multimedia gateway are pre-loaded onto your handset and should not be changed.

Voicemail Number

This menu allows you to set the voicemail center number if this feature is supported by AT&T. Please check with AT&T for details of their service in order to configure the handset correctly.

Messaging

Service Message

You can set the Service option to determine whether or not you will receive service messages.

YELLOWPAGES.COM

Unleash the power of YELLOWPAGES.COM local search on your mobile phone.

Find a business, get maps and directions, and save your favorites: our mobile app gives you what you need, whenever and wherever you need it.

]

Search for local businesses.

]

View ratings and call businesses.

]

Save businesses for future access.

]

Get maps and view step-by-step directions.

* For more information, refer to the

www.yellowpage.com

MEdia Net

This connects to the homepage, which is defined in the activated account. The default account connects to AT&T’s homepage.

This menu shows how to access the Internet by launching the WAP browser.

MEdia Net is one of the services provided by AT&T and it gives you access to all the cool things you can do with your wireless phone.

Note

Check the availability of WAP services, pricing and tariffs with your network operator and/or the service provider whose service you wish to use. Service providers will also give you instructions on how to use their services.

Please contact your service provider to open an Internet account.

To launch the browser in standby mode, Touch

and choose . Touch .

Once connected, the homepage is displayed. The content depends on the service provider.

To exit the browser at any time, press the

key.

Menus for the Browser

You can surf the Internet using either the phone keys or the WAP Browser menu.

Using the WAP Browser Menu

Online menu

Once you are connected to the Internet, the following menu options are available:

]

Back: Moves to the previous page.

]

Forward: Moves to the next page.

]

Refresh: Loads the current page again.

]

Home: Moves to the initial homepage.

]

EnterURL: Connects to the specific URL

after editing.

]

Bookmarks: You can add or save the

current page to Bookmark or view the list saved under Bookmark.

]

Search Text: You can search the text what

you want to find.

]

Recent Pages: You can manage the list of

the Internet pages you visited.

]

Settings: Allows you to set options such as

Full Screen View, Cache, Cookie and other Browser Settings.

MEdia Mall

Shop Tones

This menu option connects to AT&T’s ringtone download site.

Note

Additional charges may incur when downloading ringtones. Contact AT&T for additional information.

Shop Games

This menu option connects to AT&T’s game download site. This allows users to download the various games by connecting to the Internet.

Note

Additional charges may incur when downloading games. Contact AT&T for additional information

Shop Graphics

This menu option connects to AT&T’s graphics download site.

Note

Additional charges may incur when downloading graphics. Contact AT&T for additional information.

Shop Multimedia

This allows you to connect to AT&T’s multimedia download site.

Note

Additional charges may incur when downloading multimedia contents. Contact AT&T for additional information.

MEdia Mall

Shop Applications

This menu option connects to AT&T’s application download site. This allows users to download the various applications by connecting to the Internet.

Note

Additional charges may incur when downloading applications. Contact AT&T for additional information.

Shop Video

This menu option connects to AT&T’s video download site.

Note

Additional charges may incur when downloading applications. Contact AT&T for additional information.

MEdia Net

This connects to the homepage, which is defined in the activated account. The default account connects to AT&T’s homepage.

Applications

This menu displays the list of Java programs downloaded using WAP. All previously downloaded programs can be selected, deleted or viewed in detail within the Application menu.

Shop Applications

This menu option connects to AT&T’s application download site. This allows users to download the various applications by connecting to the Internet.

MobiTV

This applications enables you watch Mobile TV.

Mobile Banking

You can check your bank account, transfer money or etc things via this applications.

My-Cast Weather

Allows you to search quickly weather forecast.

AT&T Music

Music Player

]

All Songs: You can view all the songs in

your music library.

]

Playlists: You can make your own playlists

by choosing songs from the All songs menu list.

]

Artists: Shows the list of artists of all the

songs in your music library, and shows all the songs by a chosen artist.

]

Albums: Shows the list of albums of all the

songs in your music library, and shows all the songs on a chosen album.

]

Genres: Shows the list of genres of all the

songs in your music library, and shows all songs of a specific genre.

]

Shuffle songs: You can view all the songs

in your music library with shuffle.

Tip!

It supports formats such as MP3, AAC, AAC+, WMA, MP4 (audio only) or 3GP (audio only).

Note

Copyrights of music files may be protected by copyright and intellectual property laws. Please ensure that you adhere to the applicable Terms of Use of materials laws prior to downloading or copying files.

Playing Music

To listen to music that you have transferred to your phone, follow these quick easy steps:

1. Touch

2. Touch .

3. Select Music Player to view your options.

and touch .

You can select from All Songs, Playlists, Artists, Albums, Genres and Shuffle songs to select your Music. Now Playing is only available when music is playing.

AT&T Music

]

Touch to pause a selected song.

While playing, touch to adjust the volume. Touch and to skip to the next song or previous song.

]

Touch to Minimize the music player

and access other phone functions while music is playing.

Note

Files under 300kb are stored as ringtone files.

Adding Music To Your Handset

Music files can be added to your handset by using one or more of the following methods:

]

Download music and ringtones over the

AT&T network directly to your device via the Shop Music link in the AT&T Music Folder or the Shop Tones link in the AT&T MEdia Mall folder

]

From your existing digital media collection

on your PC via Windows Media® Player and/or Windows Explorer.

]

From your PC using other music subscription

services, such as Napster or eMusic.

AT&T Music

Purchasing and downloading Music directly to your Device

1. Touch and touch .

2. Touch

3. Select Shop Music.

4. Navigate the Shop Music page to

download today’s hottest music, ringtones and other personalized content directly to your phone.

Note

Some sites are data intensive (i.e. previews via streaming) so the user should be enrolled in an unlimited data plan before using these services to avoid per-use data charges.

Note

Additional charges may apply when downloading music, ringtones etc.

Transferring Music using your PC

Before You Get Started

To transfer music from your PC to your device, you will need the following:

]

Windows Media® Player 10 (or above) or

other digital music management software such as Napster or eMusic

]

Music on your PC in one of these formats:

MP3, .AAC, AAC+ or WMA

]

A MicroSD card*

(supports up to 8GB cards)

]

USB data cable*

* MicroSD card and USB data cable sold

separately; go to att.com/wireless for details.

Note

This device is not compatible with iTunes and/or iTunes files.

AT&T Music

Transferring Music from the Digital Music Service (such as Napster or eMusic)

1. Using your computer, open your preferred

PC music management client.

2. Download the selected song to your library.

3. Make sure the microSD card is inserted

properly into the handset.

4. Use the USB adapter cable to connect the

handset to the PC. When you try to connect handset on your PC, the handset displays “Connecting as Music Sync...”.

5. Once the USB connection has been

established, the handset displays “Connected as Music Sync Mode. Do not disconnect during transfer.“ and the computer screen then shows the LG Xenon device. If the detection does not occur, skip to Changing USB Connection Settings section on page 66.

6. Follow the instruction in the program to

transfer music to your handset.

Note

If you have a USB hub, connect the handset directly to your computer rather than through the hub.

Transferring Music using Windows Media Player

1. Open Windows Media® Player on your

computer (version 10.0 or higher).

2. Use the USB adapter cable to connect the

handset to the PC. When you try to connect handset on your PC, the handset displays “Connecting as Music Sync...”.

3. Once the USB connection has been

established, the handset displays “Connected as Music Sync Mode. Do not disconnect during transfer.“ and the computer screen then shows the LG Xenon device.

Note

If the target computer does not detect the newly connected handset or provide an MTP Player dialog window on the PC screen, skip to Changing USB Connection Settings section on page 66.

AT&T Music

4. From within the Windows Media®

Player application, click on the Sync tab. Previously downloaded songs are then listed on the left side of the application.

5. Choose the destination location for the

media files. The LG Xenon Music Sync Player appears in a drop-down list on the right side of the screen.

Note

If there is no items present in the playlist, click the Edit Playlist button and begin adding the music files from among the various media categories.

6. Click on the checkmark boxes (to the left of

the song entry) to select the song you want to synchronize to your handset.

7. Click the Start Sync button to download the

selected songs to your handset. A “synchronization in progress” message appears on the application. Do not unplug the handset during this process. Once complete, the progress bar will be disappeared.

8. It is now safe to unplug the USB connector

from the handset.

Drag and Drop Music Using LG Xenon As A Mass Storage Device

1. Make sure the microSD card is inserted

properly into the headset.

2. Connect the device to a PC using a

LG Xenon USB data cable.

3. A bubble may appear on the PC, “Found

New Hardware LG USB Modem”.

4. Access My Computer on the PC.

5. The phone’s memory card will be listed

under “Devices with Removable Storage” in the same location as an optical drive.

Note

The PC will automatically assign a drive letter.

7. File explore in a new window for desired

music files.

8. Drag and drop the desired music content

from the PC window to the “Storage Card” window.

AT&T Music

9. Disconnect the device from the cable.

10. Access the Music Player on the phone.

Note

If the target computer does not detect the newly connected handset as Mass Storage, skip to Changing USB Connection Settings section below.

Changing USB Connection Settings

1. Touch and touch .

2. Touch More.

3. Select Connection.

4. Touch USB Connection Mode.

5. Touch Music Sync (if using Windows

Player or other Digital Music

Media Services) or Mass Storage (if you are going to drag or drop files).

6. Reconnect the device to a PC.

Deleting Music Files

The following are the three options available to delete Music from your Phone:

1. Delete a file using Mass Storage, but not

using Music sync function.

2. Delete a file by directly inserting the

microSD external memory onto the PC.

3. Delete a file using delete function on the

phone.

Note

Be aware that all of the existing data will be erased on microSD card if you use the below process.

1. Use the Master Clear > memory card

function in the Settings menu.

2. Format external memory using Mass Storage.

Additional Music Services

There may be other AT&T music applications preloaded or available for your phone that allow you to:

]

Identify the name, artist and album to a

song from a song sample.

]

Listen to the latest Hip Hop, R&B, Rock,

Jazz, or Country streaming commercial-free radio channels, anywhere you go.

]

View the latest music videos.

]

View music news and information.

]

Cut custom-made ringtones from the

favorite parts of your favorite songs, etc.

Note

Some sites are data intensive (i.e. previews via streaming) so the user should be enrolled in an unlimited data plan before using these services to avoid per-use data charges.

Note

Additional charges may apply for downloading content or use of these services.

AT&T Music

Multimedia

CV brings you quick, on-demand access to news, sports, weather and entertainment video clips. Catch up on TV’s hottest shows, funniest comedians, biggest headlines and latest sports scores. You can even personalize your homepage for quick access to your favorites. In addition, the CV service automatically streams localized weather information to your personalized “News & Weather” page each and every day.

Games

Note

The JAR file is a compressed format of the Java program and the JAD file is a description file that includes all detailed information. From the network, prior to download, you can view all detailed file descriptions from the JAD file.

Warning

Only J2ME (Java 2 Micro Edition) based programs will run in a phone environment.

J2SE (Java 2 Standard Edition) based programs will only run in a PC environment.

]

Shop Games: This menu option connects

to AT&T’s game download site.

You can see the default and downloaded games in the list.

My Stuff

Audio

]

Shop Tones: This menu option connects to

AT&T’s ringtone download site.

]

Answer Tones: This menu option shows

the list of the sites which is related with AT&T’s answer tone.

]

Voice Recorder: You can record your own

audio by touching .

]

You can view the audio files in the list.


This allows you to view pictures when browsing.

]

Shop Graphics: Connects to AT&T’s

graphic download site.

]

Take Photo: It takes you to move to the

camera mode.

]

Make Animated GIF: You can make an

animation file with the selected images in the list.

]

Camera Album: You can open your camera

album.

]

You can view the graphic files in the list.

My Stuff

Video

]

Shop Videos: You can download videos.

]

Record Video: You can record your own

video.

]

You can view the video files in the list.

Note

DRM sometimes restricts some functions, such as send and edit.

Tools

Voice Recorder

Use your voice recorder to record voice memos or other sounds.

]

Touch and touch . Touch Voice

Recorder.

]

Settings

Record Mode: MMS mode record

• time is about 6 minutes and General mode provides longer recording time.

•

Quality: Set the audio's quality to

Fine, Normal or Economy.

• Select Storage Defaults: You can assign the default storage to Phone Memory or Memory Card.

]

Touch to start recording. Touch

to pause recording. To continue recording, touch again. To stop recording, touch . The recording will be saved automatically.

My Stuff

]

To start a new recording, touch .

To play the recording, touch . To send the recording by Message or Bluetooth, touch . To delete the recording, touch

and confirm Yes.

My Stuff

Voice Command

Voice command is the function whereby your phone’s voice recognition engine identifies the voice of the user and carries out the requested commands. When the user operates the voice command function, there are five possible commands, call <name or number>, Listen to voicemail, missed calls, messages and time and date. Also, to Activate the Voice Command function while in standby mode:

1. Call <Name or Number>: This function

is activated only when the user says the command "Call" followed by the name stored in the Address Book or specified phone number. The voice engine inside the handset recognizes the user's utterance and displays name lists or phone numbers from the phone's Address Book. However, interfering noise might cause a problem displaying candidates. Additionally, the user has the option to superimpose a number type at the end, such as "mobile", "home" or "office".

2. Listen Voicemail: this command is

activated when the user says the words "Listen Voicemail". The user will then be automatically connected to your voicemail.

3. Missed Calls: this command is activated

when the user says the words "Missed Calls". The mobile phone presents missed call lists.

• commands available to user

- yes: make the phone call

- no: moves to the next missed call list

- cancel: go back to the main voice

command menu

- exit: terminate voice command

4. Messages: this command is activated

when the user says the word "Messages". Mobile phone displays details of unread SMS or MMS messages.

My Stuff

• commands available to user

- yes: make the phone call

- no: moves to the next unread message

- cancel: go back to the main voice

command menu

- exit: terminate voice command

5. Time & Date: this command is activated

when the user says the words "time and date". The phone displays the current local time and date.

• mode

- speed: voice command is abbreviated

- normal: voice command is played

normally

• best match

- 1 match: the most likely match will be

displayed, finding a number from the Address Book

- 4 matches: the four most likely matched

names will be displayed, finding a name from the Address Book

• Sensitivity

- High: Operation and performance of

the voice recognition engine is rarely affected by the user's voice command and surrounding sound.

- Medium: Operation of voice recognition

engine is normally affected by user's voice command and surrounding sound.

- Low: Operation of voice recognition

engine is strongly affected by user's voice command and surrounding sound.

• Speakerphone mode

- automatic on: When this option is

selected, sound is loud enough so you can hear the output when the phone is away from the ear, at a distance.

- off: When this option is selected, sound

is quieter, and cannot be heard when the phone is away from the ear, at a distance.

My Stuff

Notepad

You can create up to a maximum of 30 memos.

1. Touch

2. Input the memo and touch

and choose . Touch and

choose Notepad.

to save.

World Clock

The World clock function provides time information for major cities worldwide.

and select New City.

1. Touch

2. Touch the default city name and it will

show alphabetically ordered cities name.

3. To make it easier, touch

show the Globe. Touch twice the continent and choose city you want to know the time.

and It will

My Stuff

4. You will see its date and time of that city

on the bottom side of the screen. Touch and touch .

Tas k s

This feature allows you to save and manage a task.

1. Touch

2. Input Due Date, Note and Priority for the

new Task.

3. Touch

The following [Options] are available in the Task list.

]

New Task: Allows you to create a new

task.

]

Delete: Deletes the selected task.

]

Selective Delete: Allows you to delete

tasks for All Completed/All Past Tasks selectively.

]

Send Task Via: Enables the selected task

to be sent via Text Message/Multimedia Message/Bluetooth®.

]

View Calendar: The calendar window

will display, from there you will be able to create New Tasks.

to save the Task item.

My Stuff

Stopwatch

This menu allows you to record the elapsed time of an event. The duration of an individual lap time (up to 20 times) and the total time can also be displayed.

]

New Time

1. To start timing, touch .

The running time is displayed as HH.MM.SS.hh (hours, minutes, seconds, hundredths of a second).

2. During the timing, you can record an

individual lap time by touching [Lap]. Up to 20 lap times can be recorded.

3. You can stop or restart timing by

touching Stop or Start.

4. To reset the stop watch, touch [Reset].

]

Saved Times: You can see the saved

recorded times.

Tip Calculator

This feature allows you to quickly and easily calculate the tip amount based on the total bill as well as the split of the total bill based on the number of people.

Unit Converter

This function converts any measurement into a unit you want.

There are 6 types of units that can be converted: Area, Length, Weight, Temperature, Volume and Velocity.

Note

You can input a decimal by pressing the [Star] key.

My Stuff

Alarm Clock

The alarm function allows you to set up multiple separate alarms. You can also set the time, repetition interval and alarm sound. Select your desired alarm setting to configure from the alarm list. If there is no alarm setting,

]

Time: Select the desired set time mode

using the select. Input your desired alarm time by specifying the hour and minutes. If the time is in the 12 hour format, you have to select either or by touching it.

]

Repeat: Select the desired repeat mode

using the select.

]

Alarm Tone: Select the alarm sound to use

for the alarm using the Center key.

]

Memo: Input alarm name.

]

Snooze Interval: You can set the snooze

interval at 5 Minutes, 15 Minutes, 30 Minutes, 45 Minutes or I Hour. Now, Touch to save your new Alarm.

Calendar

When you enter this menu, a calendar will be displayed. The red square cursor is used to locate a particular day. The bottom bar on the calendar indicates schedule(s) for that day. This function helps to remind you of the schedule. The phone will sound an alarm tone if it has been set for a specific schedule item.

The chart below shows the keys that can be used to navigate the Calendar:

The following [Options] are available when a Calendar event is selected from the Calendar menu.

]

Add new: Allows you to add a new

schedule on the date you select.

]

Search: Allows you to search the saved

schedule(s).

]

Delete: Allows you to delete the selected

schedule.

]

Set Holiday: Allows you to set your

personal holiday for the selected date.

My Stuff

]

View All: Allows you to view all saved

schedules.

]

Week View: Allows you to change

Calendar view mode from Monthly View to Week View.

]

Go to Date: Allows you to jump to a

specific date.

]

Selective Delete: Allows you to delete

Old Schedules or All Schedules selectively.

]

Select Multiple: Allows you to select

multiple schedules.

]

Settings: Allows you set Default View and

Weekly Begin day.

Calculator

The calculator function allows you to add, subtract, multiply and divide. You can input numbers using the number keys, and input operators using the touch key pad.

Use the key to delete numbers.

Camera & Recordings

Take Photo

Using the camera module built into your phone, you can take pictures of people or events while on the move. Additionally, you can send photos to other people in a picture message.

Use the select to the [Album] icon to access the Album menu.

]

Album: You can see saved image files.

]

Video: Go to the video application, also

enabling you to record a video clip.

]

Capture: You can capture the image.

]

Flash: You can set the flash mode.

The right soft key [Setting] will bring up the following options.

Getting to know the viewfinder

My Stuff

Back: Touch here to return to the standby

screen.

Camera mode: Camera mode is selected.

Size

Flash status

Album

Capture: Take the picture

Flash

Settings: Touch this icon to open the

settings menu. See Using the advanced settings on page 80 for details.

Video camera mode: Convert from camera to video camera mode.

My Stuff

Note

The shortcut options disappear after a few seconds automatically. Simply touch the centre of the viewfinder once. To recall the options touch the screen again.

Preview tab

]

View Mode: Choose between Full Image

and Full Screen.

]

Image Size: The resolution of the image

can be captured in 1600*1200 / 1280*960 / 640*480 / 320*240.

]

Brightness: Adjust brightness by adjusting

slider.

]

Color Effects: Includes options of Color/

Mono/Sepia/Negative/Blue.

]

White Balance: Set the White Balance as

Auto/Daylight/Cloudy/Illuminate/Indoors.

]

Timer: Set the Timer can be set to

Off/3 Seconds/5 Seconds/10 Seconds.

]

Night Mode: This is useful to take a photo

at dark place.

]

Continuous Shot: This is great for taking

photos of moving objects or at sporting events. Allows you to set 3 shots, 6 shots or 9 shots continuously.

Others tab

]

Video Share: You can make a Video Share

Call. For more details, refer to Video Share Calling (page 27).

]

Save to: Choose save a photo to Phone or

Memory Card.

]

Shutter Tones: Can be set to Tone 1/

Tone 2/Tone 3/Off.

]

Reset Settings: Allows you to set to the

default settings.

Note

In Take Photo mode, you can adjust the zoom scale by moving the slider. The maximum zoom scale depends on the resolution as follows.

Resolution Zoom scale

1600*1200 Level 1

1280*960 Level 1

640*480 Level 1 ~ Level 10

320*240 Level 1 ~ Level 10

My Stuff

Record Video

You can record a video clip in this menu by pressing the Camera key or Center key. Before starting to record, Touch [Settings] to set the following values.

]

Album: You can see saved video files.

]

Photo: Go to the photo application, also

enabling you to create an image file.

]

Record: You can record the video.

]

Flash: You can set the flash mode.

]

Video Share: You can make a Video Share

Call. For more details, refer to Video Share

Calling (page 27).

My Stuff

Getting to know the viewfinder

Back: Touch here to return to the standby

screen.

Video mode: Video mode is selected.

Size

Flash status

Album

Recording start

Flash: See Using the flash on page 81.

Settings: Touch this icon to open the

settings menu.

Zoom: Touch zoom out. Alternatively you can use the side volume keys.

Video Share

Camera mode: Change from video

camera to camera mode.

to zoom in or to

My Stuff

Preview Tab

]

Video Size: Sets the size of video to

320*240 or 176*144. The selected size appears on the capture screen.

]

Brightness: Adjust brightness by adjusting

slider.

]

Color Effects: Includes options of Color/

Mono/Sepia/Negative/Blue.

]

White Balance: Set the White Balance as

Auto/Daylight/Cloudy/Illuminate/Indoors.

]

Night Mode: This is useful to take a photo

at dark place.

]

Video Quality: Determines the quality

of a video clip. Includes options for Super Fine/Fine/Normal.

]

Duration: Set the duration from General/

Video Share/MMS Mode.

Others Tab

]

Save to: Choose save a video clip to Phone

or Memory Card.

]

Voice: Mute or unmute the voice.

]

Recording Tones: Set Recording Tones

On or Off.

]

Reset Settings: Allows you to set to the

default settings.

Note

In Video Record mode, you can adjust the zoom scale by moving the slider. The maximum zoom scale depends on the resolution as follows.

Resolution Zoom scale

320*240 Level 1 ~ Level 10

176*144 Level 1 ~ Level 10

My Stuff

Camera Album

You can view the images that are captured from Camera mode, using the options

One by One View/Sort by/Send/Use As/ Print via Bluetooth/Delete/Slide Show/ Edit/Display Date/File Information.

Record Voice

You can record an audio clip in this menu. The recorded audio file is saved automatically in the Audio & Ringtones menu.

Touching options.

]

Touch [Gallery], which take you to Camera album directly.

will bring up the following

Record Mode: Sets the recording mode to

either MMS or General.

Quality: Determines the quality of an

audio clip.

Set Storage Defaults: You can set the

default storage of the recorded audio to the Handset Memory or the Memory Card.

Web Pages

RSS Reader

With this program, you can open and view files created in the format with RSS. The following [Options] are available.

]

Update: You can update one RSS feed if

you can access the network.

]

Update all: You can update RSS feeds with

just one click.

]

New RSS Feed: You can add an RSS feed

manually.

]

Move: Move a RSS feed to another folder

which you added manually.

]

Delete: Allows you to erase the selected

RSS feed.

]

Send URL: Allows the RSS information to

be sent via SMS to another person.

]

New Folder: Add a new folder manually.

]

Update schedule: You can change the

schedule for updating RSS feeds.

]

Delete All: Delete all RSS feed.

My Stuff

Bookmarks

This function allows you to store and edit frequently accessed sites. The following [Options] are available.

]

New Bookmark: Add a new bookmark

manually.

]

Send URL: Allows the bookmark

information to be sent via SMS to another person.

]

List View: You can view the preset

bookmarks list.

]

Select Multiple: Allows you to select

multiple bookmarks for moving or deleting.

Note

Pre-installed bookmarks cannot be deleted or edited by users. In order to change the text input mode for symbol input, please refer to the General Functions section.

Saved Pages

This saves the page on display as an offline file. A maximum of 20 pages can be saved.

Recent Pages

You can manage the list of the Internet pages you visited.

Other Files

When you receive files of an undefined format (such as .vcs, .vcf, etc.) via email, the files are saved in this folder.

The following [Options] are available.

]

Send: Send the selected file via Bluetooth®

or MMS.

]

Send via: Send the selected file via

Bluetooth® or MMS.

]

Delete: Allows you to delete the selected

file.

]

Move To: You can move the selected file.

]

Copy To: You can copy the selected file.

My Stuff

]

Rename: You can edit the name of the

selected file.

]

Delete All: You can delete all files and

folders.

]

New Folder: Allows you to make a new

folder.

]

Sort by: You can sort the folders by name,

date and type.

]

Used Space: You can view internal and

external memory status.

Memory Card

This function shows the status of the external microSD card memory.

Settings

Sound

There are 5 sound modes: General, Vibrate All, Alarm Only, Silent All and Ear Mic. All modes can be changed from the Volume menu under Ringtone. In addition, touching and holding the mode switches between Normal mode and Vibrating mode. Ear Mic is available when respective instruments are attached.

Shop Tones

Connects to AT&T Ringtone Shops.

Volume

This menu controls Ringtone & Alerts, Multimedia, Call and Keypad volume.

Ringtone

]

Sounds: Shows and plays ring tones.

These can be downloaded ring tones from Ringtone shops.

]

Alert Type: Supports 3 ring alert types.

Ring, Ring & Vibrate and Ring after Vibration.

[Star] key on idle screen

]

Increasing Ringtone: Allows you to select

an Increasing Ringtone type which is played when you receive an incoming call. You can elect to turn this and .

Message Tone

]

Sounds: Shows and plays message tones.

These can be downloaded ring tones from Ringtone shops.

]

Alert Type: Supports 6 message alert

types: Ring Once, Ring Every 2 Min., Ring Every 15 Min., Ring & Vibrate, Vibrate and Silent.

Note

Full length music tracks cannot be set as either ringtones or message tones.

Alert Tone

]

Sounds: Allows you to select a set of alert

tones. Supports 2 alert tone types, Alert Tone 1 and Alert Tone 2.

]

Alert Type: You can elect to turn Alert

Tones to Ring or Silent.

Settings

Keypad Tone

This menu option allows you to select a tone that the phone sounds when a key is pressed. You can select an option between Beep and

Voice.

Power On/Off Tones

You can elect to turn Power On/Off Tones to

Ring or Silent.

Date & Time

]

Set Date: This allows you to enter the day,

month and year. You can change the date format via the Date Format menu option. ddd, MMM DD (day, month date) MM/DD/YYYY (month/date/year) DD/MM/YYYY (date/month/year) YYYY/MM/DD (year/month/date)

]

Set Time: This allows you to enter the

current time. You can choose the time format via the Time Format menu option, which are 12 Hours and 24 Hours. Also you can set Daylight Saving Time for 1 Hour or 2 Hours.

]

Auto Update: Select to set the phone

to automatically update the time and date according to the current local time zone.

Phone

Languages

You can change the language for the display text on your phone. This change will also affect the Language Input mode.

Auto Screen Lock

This allows you to set the amount of time before your screen lock automatically.

Settings

If you set When Slide Down , the screen will be locked automatically when you slide down the phone.

Set Flight Mode

This allows you to use only the phone's features that do not require the use of the wireless network when you are in an airplane or in places where the wireless network is prohibited. If you set the flight mode , you will be informed like below. After you confirm it by touching the Flight mode icon will be displayed on the screen instead of the network signal icon.

]

: You cannot make (or receive) any

calls, including emergency calls or use other features that require network coverage.

]

: You can deactivate the flight mode

and restart your handset to access the network.

Security

Various codes and passwords are used to protect the features and settings of your phone.

Reset Settings

This function allows you to restore factory settings. To do this, you need the security code.

]

Master Reset: Restores the settings (e.g.:

Audio, Display, Language, Date & Time, Bluetooth® Settings) stored in the handset memory to default values.

]

Master Clear: Deletes downloaded/user

created contents (e.g.: images, videos) from Handset content and the External Memory card.

Settings

• Phone

- Deletes all downloaded/user created Images, Videos & Sounds from the Handset Memory.

- Restores Deletes Personal Information stored in the handset memory (e.g.: address book, messages, tasks, alarm, Calendar schedules) to default values.

- Restores the settings stored in the handset memory to the default values.

• Memory Card: Deletes all contents from

the External Memory Card.

Display

Shop Graphics

Connects to AT&T’s graphic download site.

Wallpapers

From this menu you can select to have a picture for a background or a Solid Color.

Fonts

You can configure the font size and color of the numbers which appear in the standby screen when you make a call.

Brightness

You can set the brightness of the display screen and the keypad. The default setting is on Automatic - this phone comes equipped with a light sensor that automatically adjusts the brightness depending on your surrounding environment.

Backlight Timer

Use this to set the duration of the backlight and keypad.

Settings

Themes

You can change the whole look of display. Touch the screen and drag it from right to left and touch to change display theme from Black to White or vice versa.

Touch Keypad

You can set the Touch light style and Touchscreen Feedback types such as Vibration, Sound, Vibration & Sound and Silent. Also you can choose Vibration type and adjust its intensity. When you set Sound as Touchscreen Feedback type, you can choose sound type and adjust its volume.

Call

Call Forwarding

When this network service is activated, you can direct your incoming calls to another number, for example, to your voice mailbox number. For details, contact AT&T. Select one of the divert options, for example, select If Busy to divert voice calls when your number is busy or when you reject an incoming call.

The following options are available:

]

All Voice Calls: Diverts voice calls

unconditionally.

]

If Busy: Diverts voice calls when the phone

is in use.

Settings

]

If No Answer: Diverts voice calls which

you do not answer.

]

If Out of Reach: Diverts voice calls

when the phone is switched off or out of coverage.

Send My Number

This network service allows you to set your phone number to be displayed On or hidden Off from the person you are calling. You can select Set by Network if you prefer to have different settings for different service providers.

Auto Redial

Select On, your phone redials the number you're trying to call up to 10 times after you hear a quick, busy signal. Press [END] to stop the call attempts.

This feature attempts to redial numbers that are engaged due to the wireless network. It does not redial numbers to an engaged party.

Note

There will be no alert indicating the call has been connected. You must stay on the line to hear when the call is connected.

Recent Calls

This shows recent calls categorized to All/ Missed/Dialed/Received by tab.

Answer Mode

This allows you to determine how to answer the phone.

]

Any Key: You can answer an incoming call

by touching the [SEND] or any key except the [END] key.

]

Send Key Only: You can only answer

an incoming call by pressing the [SEND] key.

Minute Minder

This option allows you to specify whether the phone will beep every minute during a call to keep you informed of the length of the call.

Call Waiting

The network will notify you of a new incoming call while you have a call in progress. Select Activate to request the network to activate call waiting, Deactivate to request the network to deactivate call waiting or View Status, to check if the function is active or not.

Call Reject

This menu allows you to enable or disable call reject for all numbers or a specific number.

]

Call Reject On/Off: This feature

allows you to choose whether to reject the incoming calls unconditionally by disconnecting. When the Reject All Calls option is set, all incoming calls are routed directly to Voicemail. Reject on List allows you to enable Call Reject for the numbers saved on your Call Reject List.

Settings

]

Call Reject List: Configures conditional

call reject mode. After touching

reject list by selecting [Contact List] or [New Number]. When you add a number to the Call Reject list, you can add the number by entering it directly or by searching for the number in the Contact List.

, you can add to the call

Send DTMF Tones

Select from / .

TTY

Select from TTY Full/TTY Talk/TTY Hear/TTY Off.

Time & Cost

You can check Call Duration and Data Counter.

Settings

Bluetooth

Your phone has built-in Bluetooth® wireless technology, which makes it possible for you to connect your phone wirelessly to other Bluetooth® devices such as a hands-free device, PC, PDA, a remote screen or other phones. The devices registered in your phone can only be connected one at a time. (To make a connection to the same type of device or change Bluetooth

preferences, disconnect

the existing device first.)

You can have a conversation via a cordless

hands-free phone or browse the

Bluetooth Internet, wirelessly connected, via a mobile phone.

You can also exchange, for example, business cards, calendar items and pictures.

MobiTV, XMRadio or Music Playing is supported through a Bluetooth® headset.

Hands-free profile

This icon appears when the hands-free profile is used between the hands-free device. This allows you to call using a

connection.

Bluetooth

A2DP profile

This icon appears when the A2DP profile is used between the stereo headset device and the phone. This allows you to listen to an audio clip. A2DP is the Advanced Audio Distribution Profile, which provides support for streaming either mono or stereo audio using

Bluetooth

Hands-free + A2DP profile

This icon appears when both profiles of the hands-free and the A2DP are used between the compatible device and the phone. This allows you to call and listen to an audio clip using a Bluetooth® connection.

When using each device, see the manual that comes with the device.

Settings

Note

We recommend that your phone and the

device you are communicating with

Bluetooth should be no more than 10 meters apart. The connection may be improved if there are no solid objects between your phone and the other

device.

Bluetooth

]

Bluetooth®: This menu sets the Bluetooth®

or .

]

My Visibility

- Selecting the option exposes your

phone to other Bluetooth® devices.

- Selecting

shows your phone to

already-paired devices only.

]

Search New Device: This function allows

you to search for and add new devices.

]

My Devices: This function allows you to

view the list of all devices that are paired with your phone.

1. Touch

to search for the device that can be connected, and which is also within range.

2. If you want to stop searching, touch

3. All of the devices found are displayed.

Settings

Touch the desired device and enter the password. If you would like to search again, touch .

]

My Bluetooth® Info: This menu allows you

to configure the profile for Bluetooth®.

- My Device Name: Allows you to change

the handset's name, this can be seen by other Bluetooth

- Supported Services: Shows you all

services that the handset supports.

- Primary Storage: Select from Handset

and Memory Card to save data you received using Bluetooth.

devices.

Connection

USB Connection Mode

You can transfer files from a compatible PC to the memory in your phone using the Mass Storage. When you connect the phone to a PC using the USB cable, this will be displayed as a removable disk through Windows Explorer.

The USB Connection Mode determines how your Phone will communicate with other USB devices when they are connected with a USB cable.

Internet Profiles

This menu shows the Internet Profiles. You can add, delete and edit Internet Profiles by using the Options Menu. However, you cannot delete or edit default configurations provided by AT&T.

Access Points

This menu shows the Access Points. You can register, delete and edit by using the Options Menu. However, you cannot delete or edit default configurations provided by AT&T.

Settings

Memory

Used Space

This function shows the status of the user memory of the handset.

Memory Card: If your phone has a multimedia memory card in the card slot, you can save images, sounds and videos on the memory card. You can check the current status of the external memory card in the Memory status menu.

Phone Reserved: This function shows the status of the reserved memory for the user (Text Message, Contact List, Calendar, Tasks, Memo).

SIM Card: This function shows the status of the SIM Card user memory.

Set Storage Defaults

You can set Storage default for each case. When you need to save files from Camera, Internet Download, Bluetooth and Voice Recorder, set Phone Memory or Memory card. You can set each case separately or choose All and set the Storage Default all the same.

Application Settings

This Menu allows you to adjust the settings to the following features on the phone:

Video Share

]

Audio Alert: Enable/Disable audio alert

when Video Share is available.

]

Auto Record: Enable/Disable automatic

recording of live Video Share.

Messaging

To set the message settings from standby screen, touch . Touch Message Settings. For more information regarding Message settings, please refer page 53.

Message Alert

You can set the Sounds and Alert Type here.

Save to Choose between Phone and SIM Card to save message.

Signature

This feature allows you to create your Text signature. You can use symbols, templates and contacts as part of the signature.

Settings

Browser

Accounts

This includes the network information used to connect the browser to the Internet. Select the desired account by tapping the screen. This will activate the account that will be used for future connections. MEdia Net is the predefined account that is set as default.

]

Activate: Select the account among the

list of accounts, so it can be used for future connections.

]

View: Allows you to see the specific

account information.

The following options will be available when you touch

]

Edit: Allows you to change the account

information.

]

Delete: Allows you to delete the account.

]

New: Allows you to create a maximum of

20 new accounts.

Note

You cannot edit and delete pre-installed accounts. In order to create a new account, please fill in the network information.

1. Account Name: Name associated with

new account.

2. Homepage: Homepage URL.

3. Internet Profile: You can choose one from

the Internet profiles.

Note you can choose a Internet profile by selecting the list option on the center key.

LG Xenon GR500 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
