SIMPLE MANUAL
Sound Bar
Please read this manual carefully before operating your set
and retain it for future reference.
To view the instructions of advanced features,
visit http://www.lg.com and then download Owner's Manual.
Some of the content in this manual may differ from your unit.
FRANÇAISDEUTSCH
NEDERLANDS
ESPAÑOLITALIANO
ΕΛΛΗΝΙΚΑ
SRPSKIHRVATSKILATVIEŠUROMÂNĂPOLSKI
БЪЛГАРСКИ
PORTUGUÊS
МАКЕДОНСКИ
MAGYAR
BOSANSKI
SVENSKA
DANSK NORSK
SUOMI
MODEL
SK1
www.lg.com
Copyright © 2018 LG Electronics Inc. All Rights Reserved.
SK1.AEUSLLK_SIM_ENG_MFL70443680.indd 1 2018-05-14 9:22:17
Front Panel
State LED
A
yWhite (Staying on): Optical function is selected.
yWhite (Blinking twice and staying on): LG Sound
Sync (Optical) function is selected.
yGreen (Staying on): Portable function is selected.
yRed (Staying on): Standby mode without network
connection.
Bluetooth LED
B
yBlue (Blinking): Waiting for Bluetooth connection.
yBlue (Staying on): Paired with Bluetooth device.
This unit operates only with the remote
control.
Rear Panel
USB (Service only) ····· S/W download connector.
PORT. IN (Portable) Connect to a portable device.
OPT. IN (Optical) ····· Connect to an optical device.
SK1.AEUSLLK_SIM_ENG_MFL70443680.indd 2 2018-05-14 9:22:18
TV Connection
a Connect the sound bar to the TV using
an optical cable.
b Set up [External Speaker (Optical)] on
your TV setting menu.
TV
Additional Device Connection
a Connect to the external device as follows.
(Set-top Box,
Player etc.)
TV
b Set the input source by pressing OPTICAL on
the remote control.
Remote control
STANDARD/BASS BLAST : Selects the sound effect.
DRC ON/OFF :
Replacement of battery
Makes comfortable sound at Dolby Digital.
SK1.AEUSLLK_SIM_ENG_MFL70443680.indd 3 2018-05-14 9:22:19
Additional Information
Specication
Power requirements
Power
consumption
Dimensions
(W x H x D)
Amplier
(Total RMS
Output power)
Design and specications are subject to change without
notice.
How to disconnect the wireless network
connection or the wireless device
Press and hold (Mute) on the remote control for
about 2 seconds and turn off the unit.
Declaration of Conformity
Refer to the main label.
Refer to the main label.
Networked standby : 0.5 W
(If all network ports are
activated.)
Approx.
650.0 mm x 79.0 mm x
94.0 mm With foot
40 W RMS
Wall mounting (Optional)
You can mount the main unit on a wall by using holes on
the rear of the unit. For details, download the online owner’s
manual. http://www.lg.com
a b
dc
BUY :
Hereby, LG Electronics declares that the radio equipment type Sound
Bar is in compliance with Directive 2014/53/EU. The full text of the
EU declaration of conformity is available at the following internet
address:
http://www.lg.com/global/support/cedoc/cedoc#
For consideration of the user, this device should be installed and
operated with a minimum distance of 20 cm between the device
and the body.
Frequency range Output power (Max.)
2402 to 2480 MHz 10 dBm
