Owner's Manual

LG CineBeam

DLP Projector

Please read the safety information carefully before using this product.

Green : the buttons and the text to be displayed on the projector screen.

PH450UGV

P/NO : SAC37034678 (1806-REV02)

www.lg.com

NOTE

LICENSES

Supported licenses may differ by model. For more information about licenses, visit

ENGLISH

www.lg.com.

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

This DivX Certied® device has passed

rigorous testing to ensure it plays DivX® video.

To play purchased DivX movies, rst register

your device at vod.divx.com. Find your registration code in the DivX VOD section of your device setup menu.

DivX Certied® to play DivX® video up to HD

1080p, including premium content. DivX®, DivX Certied® and associated logos are trademarks of DivX, LLC and are used under license. Covered by DivX Patents 7,295,673; 7,515,710; RE45,052; and others available at [www.divx.com/patents]

The terms HDMI and HDMI High-Denition

Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

• Image shown may differ from your projector.

• Your projector’s OSD (On Screen Display) may differ slightly from that

shown in this manual.

SAFETY PRECAUTIONS

Please take note of the safety instructions to prevent any potential accident or misuse of the projector.

• Safety precautions are given in two forms, i.e., WARNING and CAUTION as

detailed below.

WARNING Failure to follow the instructions may cause serious injury and

even death.

CAUTION Failure to follow the instructions may cause personal injury or

product damage.

• Read the owner's manual carefully and keep it on hand.

WARNING/CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightning ash with

arrowhead symbol, within

an equilateral triangle, is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be

of sufcient magnitude to

constitute a risk of electric shock to persons.

The exclamation point

within an equilateral

triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the device.

WARNING/CAUTION

- TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions.

Indoor Installation

WARNING

• Do not use the projector outside

and do not expose the product to any humidity or water.

- Since the product is not waterproof, this may result in a

re or electric shock.

• Do not place the projector in direct

sunlight or near heat sources such as radiators, fires, stoves, etc.

- This may result in re.

• Do not place flammable materials

such as aerosols near the projector.

- This may result in re.

ENGLISH

• Do not allow children to cling to or

ENGLISH

• Do not install the product in a

• Do not place the product close to

• Do not install the product onto

• Do not place the projector where it

climb up to the projector.

- This may cause the projector to fall, causing injury or death.

place with no ventilation (e.g., on a bookshelf or in a closet) or on a carpet or cushion.

- This may result in re due to the increase in internal temperature.

sources of steam, oil or oil mist, such as humidifiers and kitchen counters.

- Failure to do so may result in

re, electric shock, or corrosion.

a wall or ceiling that is close to sources of oil or oil mist.

- The product may be damaged and fall, resulting in serious injury.

might be exposed to dust.

- This may result in re.

• Do not use the projector in a damp

place such as a bathroom where it is likely to get wet.

- This may result in re or electric shock.

• Do not allow a tablecloth or curtain

to block the air vent.

- This may result in re due to the increase in the internal temperature.

• Ensure good ventilation around the

projector. The distance between the projector and the wall should be at least 30 cm.

- This will prevent re due to the increase in the internal temperature.

CAUTION

• When placing the projector on a

table or shelf, be careful not to put it near the edge.

- The projector could fall due to balance problems, which may cause personal injury or damage to the product. Make sure to use the projector cabinet or stand

that ts the projector.

• When moving the projector, make

sure to switch it off and remove the power plug and cords.

- The power cord may be

damaged, resulting in re or

electric shock.

• Do not place the projector on an

unstable or vibrating surface such as a wobbly shelf or a slope.

- It may fall and cause injury.

• Be careful not to tip the projector

over when connecting external devices to the projector.

- This may cause personal injury or damage to the projector.

Power

WARNING

• DISCONNECTING THE DEVICE

FROM THE MAIN POWER

- The Power plug is the disconnecting device. In case of an emergency, the Power Plug must remain readily accessible.

• The grounding wire should be

connected. (Except for devices which are not grounded.)

- Ensure that you connect the grounding cable to avoid electric shock. If it is not possible to ground the

unit, have a qualied electrician

install a separate circuit breaker. Do not try to ground the projector by connecting it to telephone wires, lightning rods, or gas pipes.

• The power plug should be inserted

fully into the power outlet.

- An unstable connection may

cause a re.

• Do not place heavy objects on the

power cord.

- This may result in re or electric shock.

ENGLISH

• Never touch the power plug with

• Do not plug too many devices into

ENGLISH

• Keep the AC adapter, power plug,

• If there is any smoke or a burning

• To turn off the main power, remove

wet hands.

- This may result in electric shock.

one multi-power outlet.

- This may result in re due to the power outlet overheating.

and the used power outlet clean from dust or foreign materials building up.

- This may result in re.

smell from the projector or AC adapter, stop using the product immediately. Disconnect the power cord from the power outlet, and then contact the customer service center.

- This may result in re.

the power plug, which should be positioned so it is easy to access for operation.

CAUTION

• Always grab the plug to remove the

AC adapter or power cord.

- Otherwise, this may result in a

re or may damage the product.

• Refrain from constantly bending the

power cord of the AC adapter.

- If the power cord is bent excessively for a long period of time, the cord may break

inside. This may result in a re or

electric shock.

• Ensure the power cord and plug are

not damaged, modified, severely bent, twisted, pulled, sandwiched or hot. Do not use the product if the power outlet is loose.

- This may result in re or electric shock.

• Keep the power cord away from

heating devices.

- The wire's sheath may melt,

which may result in re or

electric shock.

• Place the projector where people

will not trip over or step on the power cord to protect the power cord and plug from any damage.

- This may result in re or electric shock.

• Do not turn the projector on or

off by plugging in the power plug or unplugging it from the power outlet. (Do not use the power plug as a switch.)

- This may result in electric shock or damage to the product.

• Do not insert a conductor into the

other side of the wall outlet while the power plug is inserted into the wall outlet. In addition, do not touch the power plug immediately after it is disconnected from the wall outlet.

- This may result in electric shock.

• Only use the official power cord

provided by LG Electronics. Do not use other power cords.

- This may result in re or electric shock.

• If any water or foreign materials

have gone into the AC adapter, power cord, or the interior of the projector, turn off the projector by pressing the power button. Remove all the cables, and then contact the customer service center.

- This may result in re or electric shock.

• The surface of the AC adapter is

hot. Keep the AC adapter out of the reach of children and avoid touching it during use.

• Never disassemble the power

supply devices (AC adapter/power cord, etc.).

- This may damage the power

cord and result in a re or

electric shock.

• Connect the AC adapter and the

power cord firmly.

- Not doing so may result in a

product failure or re.

• Do not place heavy objects or put

pressure on the power cord and AC adapter and avoid damage.

- This may result in a re or may damage the product.

• Always use the AC adapter provided

or any AC adapters approved and certified by LG Electronics.

- Any other AC adapter connected may result in the

screen ickering.

ENGLISH

When in Use

ENGLISH

• Do not place anything containing

• In the event that there is a heavy

• Do not insert pieces of metal such

• Make sure that a child does not

WARNING

liquid on top of the projector such as a vase, flower pot, cup, cosmetics, medicine, or ornaments, candles, etc.

- This may result in re or electric shock, or cause injury due to falling.

impact or the cabinet is damaged, switch it off, unplug it from the power outlet and contact an authorized service center.

- This may result in electric shock.

as coins, hairpins, or metal debris, nor flammable materials such as paper or matches into the projector.

- This is to prevent electric shock

or re.

swallow the batteries when you replace the old remote control batteries with new ones. Keep batteries out of reach of children.

- If a child swallows a battery, consult a doctor immediately.

• Never open any cover on the

projector.

- There is a high risk of electric shock.

• Do not look directly into the lens

when the projector is in use.

- The bright light may damage your eyes.

• When the lamp is on or has just

been turned off, avoid touching the air vent or lamp, because these will be very hot.

• If there is a gas leak in the room

with the projector, do not touch the projector or power outlet. Open the windows for ventilation.

- Sparks may cause re or burns.

• Unplug the power cord from the

outlet during a lightning storm.

- This will prevent shock or damage to the projector.

• Do not use the projector near

electronic devices that generate a strong magnetic field.

• Keep the plastic film used for

packaging the projector out of the reach of children.

- If not handled safely, it can cause suffocation.

• Do not keep your hand on the

projector for a long time when it is running.

• When you play a game by

connecting a game console to a projector, it is recommended that you maintain a distance of more than four times the diagonal length of the screen.

- Make sure that the connecting cable is long enough. Otherwise, the product may fall causing personal injury or damage to the product.

• Do not place the projector or its

remote control with battery in an extremely high temperature environment.

- This may result in re.

• Do not use 3D glasses if you do not

watch 3D.

CAUTION

• Do not place heavy objects on the

projector.

- It may fall down and cause personal injury.

• Be careful not to allow any impact

to the lens during transport.

• Do not touch the lens of the

projector.

- The lens may be damaged.

• Do not use any sharp tools on

the projector such as a knife or hammer, because this may damage the casing.

• In the event that no image appears

on the screen or no sound is heard, stop using the projector. Switch off the projector, unplug it from the power outlet and contact our service center.

- This may result in re or electric shock.

• Do not drop anything onto the

projector or allow anything to bang into the projector.

- This may cause damage to the projector or personal injury.

ENGLISH

• It is recommended that you

ENGLISH

• Do not block the light beam emitted

• Do not start the projector with the

• Do not use high voltage electrical

maintain a distance of more than 5 to 7 times the diagonal length of the screen.

- If you watch the screen at a close distance for a long time, your eye sight may become worse.

from the projector using a book or other object.

- Lengthy exposure to the projector beam may result in

re. In addition, the lens may

be overheated and damaged by

the reected heat. Disable the

AV function to stop projection temporarily or turn off the power.

volume turned up high.

- High volume may damage hearing.

equipment near the projector, (e.g., a bug zapper). This may result in product malfunction.

Cleaning

WARNING

• Do not spray the projector with

water when cleaning. Make sure water does not flow into the projector.

- This may result in re or electric shock.

• When there is smoke or a strange

smell coming out from the projector or a foreign object falls into the projector, please switch it off and unplug it from the power outlet and contact our service center.

- Otherwise, this may result in re or electric shock.

• Use air spray, a soft cloth, or a

cotton swab moistened with a lens cleaning chemical or alcohol to remove dust or stains on the front projection lens.

CAUTION

• Contact your seller or our service

center once a year to clean the internal parts of the projector.

- If you do not clean the projector for a long period of time, dust will accumulate, which may

result in re or damage to the

projector.

• When cleaning plastic parts such

as the projector case, unplug the power first and wipe with a soft cloth. Do not spray with water or wipe with a wet cloth. Never use glass cleaner, automobile or industrial polish, abrasives, wax, benzene, or alcohol as these can damage the projector.

- This can result in re, electric shock or cause damage to the product (deformation and corrosion).

• Do not wipe the optical system

(lens, mirror) right after the product has been turned off or while the product is being operated. When cleaning each part of the product, remove the power cord and wipe gently with a soft cloth. Do not spray with water or wipe with a wet cloth. Do not use detergents, automobile or industrial polish, abrasive substances, wax, benzene, alcohol, water, etc. on the product's main unit or optical system (lens, mirror) as this may damage the product.

- This can result in re, electric shock or cause damage to the product (deformation and corrosion).

• Remove the plug from the outlet

before cleaning the product.

- Otherwise, this may result in electric shock.

ENGLISH

Others

ENGLISH

• Some users may experience

• When you go out, place the

• Do not use the projector near high-

WARNING

a seizure or other abnormal symptoms when they are exposed to a flashing light or particular patterns from a video game.

projector out of reach of animals, and remove the power plug from the wall outlet.

- Using a damaged power cord

may result in short circuit or re.

precision electronic devices or those that transmit weak radio signal.

- This may affect the operation of the product, causing an accident.

• Only a qualified technician can

disassemble or modify the projector. For diagnosis, adjustment, or repair, contact your seller or our service center.

- This may result in re or electric shock.

• Proper ventilation required, do not

block airflow around unit. Doing so can cause injury and internal overheating.

• Do not touch the lens; doing so can

result in burns or damage to lens. Lens and unit may be HOT during and immediately after use. Use caution when handling unit, allowing for proper cool down.

• Only use a grounded electrical

outlet. (Except for devices which are not grounded.)

• Do not insert anything into or cover

up the exhaust vents.

- This may result in re or electric shock.

• Follow all maintenance guidelines

for optimal use; service only at an authorized service center.

• Keep the batteries and remote out

of reach of children.

- This will prevent personal injury or damage to the product.

CAUTION

• Do not use or store the projector

outdoors for long periods of time.

• Do not mix new batteries with old

ones.

- Burst or leaking batteries may result in damage or injury.

• Be sure to unplug if the projector is

not to be used for a long period.

- Accumulated dust may result

in re or electric shock due to

overheating, ignition, or poor insulation.

• Only use the specified type of

battery.

- Burst or leaking batteries may result in damage or injury.

• Make sure you use the same type

of battery when replacing.

- In the case of a battery contact failure, the battery may drain quickly or the remote control may not work properly.

ENGLISH

• Dispose of used batteries properly.

ENGLISH

• Do not throw or disassemble the

• Store batteries away from metallic

• Do not store the batteries near any

- This may result in explosion

or re. The correct method of

disposal may vary depending on your country or region. Dispose of the battery pack as instructed.

battery.

- This may result in re or explosion due to damage to the battery.

objects, such as keys and paper clips.

- Excess current may cause a rapid increase in temperature,

resulting in re or burns.

heat source, such as a heater.

- This may result in re or damage to the product.

• Do not store batteries at

temperatures higher than 60 °C or in high humidity.

- This may result in explosion

or re.

• Make sure that the battery is

installed correctly.

- This may prevent explosion or

re.

• Incorrect battery replacement may

cause fire.

• Batteries: Store the accessories

(battery, etc.) in a safe location out of the reach of children.

Risk Group 2

CAUTION Possibly hazardous

optical radiation emitted from this product. Do not stare at operating lamp. May be harmful to the eye.

This label is attached to the bottom of

the product and language may differ.

CONTENTS

LICENSES 2

SAFETY PRECAUTIONS 3

PREPARATION 17

Accessories 17

Optional Extras 18

Parts and Components 19

- Main Unit 19

- Side 20

- Back 21

Using the Joystick Button 22

- Basic Functions 22

- Adjusting the Menu 23

Projector Status Indicators 23

Installation 24

- Installation Precautions 24

- Projection Distance per Screen Size 25

- Kensington Security System 27

REMOTE CONTROL 28

USING THE PROJECTOR 31

Watching Projector 31

- Turning on the Projector 31

- Focus of the Screen Image 32

- Watching With the Projector 32

Additional Options 33

- Adjusting Aspect Ratio 33

- Using the Keystone Function 34

- Changing Input Device 35

- Blank Function 37

Using the Quick Menu 38

ENTERTAINMENT 39

Using SCREEN SHARE 39

Setting Up Bluetooth on the Projector 40

- Searching for Bluetooth Devices and Connecting 41

- Connecting, Disconnecting, or Deleting Bluetooth Devices in the List of registered devices 43

- Adjusting AV Sync. Adjust 44

ENGLISH

MY MEDIA 45

Before Using 45

ENGLISH

To Use My Media 47

3D FUNCTION 69

While Watching 3D 69

Requirements for Watching 3D Images 72

To view 3D images 73

CUSTOMIZING SETTINGS 75

SETTINGS 75

PICTURE Settings 76

AUDIO Settings 82

TIME Settings 84

WIRELESS Settings 85

OPTION 1 Settings 87

OPTION 2 Settings 88

- Connecting a USB Device 45

- Removing a USB Device 45

- Watching the Videos 51

- Viewing the Photos 57

- Listening to Music 61

- Viewing Files 65

- Using the DLP-LINK (DLP- Ready) Type Glasses 73

- Supported 3D Mode 74

CONNECTING DEVICES 90

Connecting to HD Receiver, DVD Player, or External Devices 91

- HDMI Connection 91

Connecting a PC 91

- HDMI Connection 91

Connecting a Laptop 92

- HDMI Connection 92

Connecting to Headphones 93

Using the Mirroring Function of a Mobile Phone 94

- MHL/Slimport Connection 94

MAINTENANCE 95

Cleaning 95

- Cleaning the Lens 95

- Cleaning the Projector Case 95

SPECIFICATIONS 96

SYMBOLS 99

PREPARATION

The pictures may differ slightly from the actual product.

Accessories

Accessories included with the projector are show below. Accessories are subject to change without prior notice. New accessories may be added or old ones removed.

Remote Control,

Two AAA Batteries

Power cord

• When connecting an HDMI or USB cable, or

connecting a USB flash drive to the HDMI or USB port, use a product that has a width of 18 mm or less and a height of 10 mm or less. If the USB cable or USB flash drive does not fit the USB ports of the projector, use an extension cable that supports USB 2.0.

• Use a certified cable with the HDMI logo attached.

• If you do not use a certified HDMI cable, the screen may not display or a

connection error may occur. (Recommended HDMI cable types)

- High-Speed HDMI®/™ Cable

- High-Speed HDMI®/™ Cable with Ethernet

Owner's Manual AC-DC Adaptor

ENGLISH

Optional Extras

To purchase optional accessories, visit an electronics store or online shopping site or contact the retail store where you purchased the product. Optional accessories

ENGLISH

are subject to change without prior notice.

Projection Screen HDMI Cable

MHL or Slimport cable

3D glasses

(DLP-LINK or DLP

Ready Type)

Parts and Components

This projector is manufactured using high-precision technology. You may, however, see tiny black dots and/or bright colored dots (red, blue, or green) that continuously appear on the projector screen. This is a normal result of the manufacturing process and does not indicate a malfunction.

Main Unit

Joystick button

Lens

Vent

Focus ring

ENGLISH

Speaker

1) Due to the high temperature of vent area, do not get close to the vent area.

2) Do not touch the lens when using the projector. The lens may be damaged. (Keep lens away from sharp objects.)

Side

ENGLISH

1 2 3

Description

(USB Port)

Port

(Headphone Port)

Back

ENGLISH

Description

DC IN Port

NOTE

Using the Joystick Button

You can operate the projector by pressing the button or moving the joystick left, right, up, or down.

ENGLISH

Basic Functions

Power On When the projector is turned off, place

your nger on the joystick button, press it

once, and release it.

Power Off When the projector is turned on, place

your nger on the joystick button, press

it once for a few seconds, and release it. (However, if the menu button is on the screen, pressing and holding the joystick button will let you exit the menu.)

Volume Control

Place your nger over the joystick button

and move it left or right. You can adjust the volume level.

Up/Down/ Left/Right

• Move the joystick button up, down, left, or right. Be careful not to press

the joystick button. If you press the button while moving the joystick, the volume control may not work, and the cursor may not move.

If you move the joystick up, down, left, or right, you can move the cursor to select the menu items.

Adjusting the Menu

When the projector is turned on, press the joystick button one time. You can adjust the menu items ( , , , ) moving the joystick button left, right, up, or down. Move to the desired menu item, and then press the joystick button once to select it.

Turns the power off.

Changes the input source.

Clears on-screen displays and returns to projector viewing.

Projector off

Input List

ENGLISH

Settings

Projector Status Indicators

LED Power Indicator

Power standby state

Red

The projector is operating with the power on.

Off

Displays the Settings menu.

Installation

Installation Precautions

ENGLISH

• Place the projector in a well-

ventilated environment.

- To prevent internal overheating, install the projector in a wellventilated place. Do not place anything near the projector that may block its air vents. If the air vents are blocked, the internal temperature of the projector will increase.

- Do not place the projector on a carpet or rug. If the projector's inlet vent is on the bottom, be careful not to block the vent and always use the projector on a solid, level surface.

- Be sure to prevent foreign objects such as paper debris from entering the projector.

- Leave an adequate open area (30 cm or more) around the projector.

• Do not place the projector in a hot,

cool, or humid environment.

• Do not place the projector in a place

where it will easily attract dust.

- This may result in re.

• Never open any cover on the

projector. There is a high risk of electric shock.

• The projector is manufactured using

high-precision technology. You may, however, see tiny black dots and/ or bright colored dots (red, blue or green) that continuously appear on the projector screen. This is a normal result of the manufacturing process and does not indicate a malfunction.

• The remote control may not work

in an environment where a lamp equipped with electronic ballasts or a three-wavelength fluorescent lamp is installed. Replace the lamp with an international standard lamp for the remote control to work normally.

Projection Distance per Screen Size

1 Place the projector on a sturdy, level surface, together with the PC or audio/

video source.

2 Place the projector an appropriate distance away from the screen. The distance

between the projector and the screen determines the actual size of the image.

3 Position the projector so that the lens is at a right angle to the screen. If the

projector is not at a right angle, the projected image will look distorted. To correct the distortion, use the keystone function. (See page 34.)

4 Connect the power cord of the projector and the connected device to the wall

outlet.

Ratio of upward projection: 120 %

Screen

ENGLISH

CAUTION

ENGLISH

The projection distance may vary depending on the installation conditions.

Screen Size [mm] (16:9

Aspect Ratio)

1016 886 x 498 274 74 69 161

1143 996 x 560 306 106 81 173

1270 1107 x 623 338 138 94 186

1397 1218 x 685 370 170 106 198

1524 1328 x 747 402 202 119 211

1651 1439 x 809 434 234 131 223

1778 1550 x 872 466 266 144 236

1905 1660 x 934 498 298 156 248

2032 1771 x 996 531 330 169 260

• If the projected image looks distorted or bent, check to see if the screen is

installed properly.

Horizontal Size (X) x

Vertical Size (Y) [mm]A [mm]

[mm]

[mm]D [mm]

Kensington Security System

• This projector has a Kensington Security Standard connector as an anti-theft

mechanism. Connect a Kensington Security System cable as shown below.

• For more information on installation and use of the Kensington Security System,

refer to the user’s guide provided with the Kensington Security System.

• The Kensington Security System is an optional accessory.

• What is Kensington?

Kensington is a company that provides safety systems for laptops and other electronic devices. Website: http://www.kensington.com

ENGLISH

①

②

REMOTE CONTROL

Open the battery cover on the back of the remote

ENGLISH

control and insert the batteries which are specied in

the battery room with poles pointing in the correct direction. Use new batteries and do not mix regular or rechargeable batteries. (1.5 V AAA)

CAUTION

• Do not mix new batteries with old ones.

(POWER)

Turns the projector on or off.

Changes the input source.

Accesses USB mode.

Adjusts the volume level.

Mutes the sound of the projector.

Displays a blank screen.

Changes the aspect ratio of the screen per pressing of the button.

Moves to the previous/next page.

Displays or closes the Settings menu.

Adjusts the Keystone function.

Enters the quick menu.

Up/Down/Left/Right buttons

Sets the function or moves the cursor.

Shows the current mode and saves changes to the settings.

Exits the menu.

Freezes the moving image. (Available in any mode other than USB mode.)

(BACK)

Returns to the previous screen.

Playback control buttons

Controls playback of MY MEDIA.

Shows 3D images.

Switches left and right in 3D mode.

Color buttons

Sets detailed settings or gesture for each menu.

ENGLISH

NOTE

ENGLISH

• When using the remote control, the optimal operation

range is 6 meters or less (left/right) and within a 30 degree arc of the remote control IR receiver.

• For seamless operation, do not block the IR receiver.

• When you carry the remote control in the portable

bag, make sure that the buttons on the remote control are not pressed by the projector, cables, documents, or any other accessories in the bag. Otherwise, it may significantly reduce the battery life.

30° 30°

USING THE PROJECTOR

Watching Projector

Turning on the Projector

The menu screen display in this owner's manual is an example to help users understand how to operate the product and may look different from the actual screen.

1 Connect the power cord correctly. 2 After waiting for a moment, press the (POWER) button on the remote

control or the joystick button.

3 In the Language Selection screen, select a language. 4 In the Mode Setting screen, select the setting mode you want.

Mode Setting

Selecting the environment.

Choose the setting mode you want.

Select [Standard] to use this Projector at home. To use this Projector at store, select [Store Demo].

Standard

Demo Mode

* Store Demo is used when displaying the product in-store. The picture mode is

automatically reset after a certain period of time. You can select Standard to use the product at home.

Store Demo

Off

Conrm

5 Select an input signal by using the button on the remote control.

ENGLISH

Focus of the Screen Image

When an image appears on the screen, check if it is in focus and ts the screen

properly.

ENGLISH

• To bring images into focus, move the Focus Ring slowly up or down,

Watching With the Projector

1 When in standby mode, press the (POWER) button to turn the projector

2 Press the button and select the input signal you want. 3 Control the projector using the following buttons while watching projector.

Focus Ring

concentrating on the upper central part of the screen. Optimal focus is reached when the left and right sides of the screen appear balanced.

on.

Button Description

Adjusts the volume level.

Mutes all sounds.

Accesses the quick menu.

Resizes an image.

Adjusts Keystone.

4 To turn the projector off, press the (POWER) button.

Additional Options

NOTE

Adjusting Aspect Ratio

Resize an image to view at its optimal size by pressing while you are using the projector.

• Available picture size may differ depending on the input signal.

• You can also use the

Menu Description

16:9 Resizes images to the 16:9 ratio.

Displays video images in the original size without removing

Just Scan

Set By Program

4:3 Resizes images to the previous standard 4:3.

Zoom

Cinema Zoom 1

parts of the edge of the image.

• If you select Just Scan, you may see image noise at the edge

or edges of the screen.

Displays images in the same aspect ratio as the original image.

Resizes the image to t the screen width. The top and bottom

parts of the image may be cut off.

• Press the or button to zoom in or out of the image.

• Press the or button to move the image.

Formats an image to the cinemascope ratio, 2.35:1. It ranges from 1 to 16.

• Press the or button to zoom in or out of the image.

• Press the or button to move the image.

• If you enlarge or reduce an image, the image may be

distorted.

or button.

ENGLISH

Using the Keystone Function

To prevent the screen image from becoming trapezoidal, Keystone adjusts the top and bottom width of the image if the projector is not set up at a right angle to the

ENGLISH

screen. Because the Keystone function may cause inferior screen image quality, use this function only when it is not possible to set up the projector at an optimal angle.

• Keystone 0

- +

◀

▶

1 Press the button to adjust the picture.

• Keystone values differ depending on the PJT Mode of OPTION 2.

2 Press the button when done.

Changing Input Device

To select an external input

Selects external input. The illustration of the menu may differ from the actual screen on the product.

• Press the button on the remote control to display the input

selection screen.

- Connected inputs are displayed rst. However, SCREEN SHARE input is always activated.

• Select an input signal using the remote control's button to connect

the projector to the desired input. You can use the or button to switch between all the input modes.

Input List

SCREEN SHARE USB HDMI

ꔂ Move ꔉ OK

ExitInput Label

ENGLISH

Displays which devices are connected to which input ports.

ENGLISH

1 Press the button on the remote control to display the input

2 Press the Red button. 3 Use the or button to select one of the input labels.

Selecting an Input Label

Input Label

HDMI

selection screen.

Blank Function

Using the Blank Function

This function may be effective when you need to draw attention during a meeting or training.

1 Press the button, and the screen is covered by the background color.

You can change the background color by referring to

Selecting a Blank Image

2 Press any button to clear the blank function. To cover the screen temporarily,

press the button on the remote control. Do not block the lens with any object while the projector is running. It may become overheated and

deformed or even cause a re.

Selecting a Blank Image

1 Press the button. 2 Press the , , , or buttons to select OPTION 2 and press the

button.

3 Press the , buttons to select Blank Image and press the button. 4 Press the or button to move to the setting or option you want and

press the button.

ENGLISH

Using the Quick Menu

You can easily customize your frequently used menus.

1 Press the button.

ENGLISH

2 Press the or button to select a menu and press button.

3 Press the or button to scroll through the following menus.

Menu Description

Aspect Ratio Resizes the picture.

PJT Mode

Picture Mode Changes the picture mode.

Sound Mode Sets the sound mode.

Sleep Timer Sets the projector to be turned off at the specied time.

Clear Voice II Makes the voice from the projector crisp and clear.

Energy Saving

USB Device

Turns the projected image upside down or ips it

horizontally.

Reduces power consumption by adjusting peak screen brightness.

Allows you to remove a connected USB device in a safe manner. (The menu is displayed only when the USB device is connected.)

ENTERTAINMENT

CAUTION

Using SCREEN SHARE

1 Set the external input of the projector to SCREEN SHARE. 2 Enable related SCREEN SHARE function on the device you wish to connect. 3 Connect the projector from the search list on the device you wish to connect.

(When you connect the projector to your laptop, input the PIN code shown on your display. The request for a PIN will be shown only at the initial connection.)

4 If the desired device accepts the request, SCREEN SHARE will be started.

• Windows 7 / 8 / 8.1 / 10 are compatible with SCREEN SHARE. However,

other versions of Windows, and some other operating systems, may not be compatible with SCREEN SHARE.

• Ice Cream Sandwich, Jellybean, Kitkat, Lollipop, and Marshmallow versions of

LG’s Android devices are guaranteed to be compatible.

• When connecting via SCREEN SHARE, place the device close to the

projector.

• The response rate and image quality may vary depending upon the user’s

environment.

• For more information on the device you want to connect to, refer to its

owner’s manual.

• Certain Windows 8.1 laptops may have difficulty in reconnecting when

initializing the device information during a wireless connection. In this case, it is recommended that you remove the registered device and reconnect.

ENGLISH

NOTE

Setting Up Bluetooth on the Projector

This option is used to output sound from the projector through Bluetooth audio devices.

ENGLISH

• Press the button on the remote control, and then set Bluetooth to

On in the WIRELESS menu.

• The devices that can be connected are as follows: LG BTS1, LG HBS-700, LG

HBS-730, LG HBS-800 (Models available for purchase may vary by region.)

• Products from other manufacturers may not be compatible.

• You can use the remote control to adjust the volume of the connected

device.

• When connecting devices wirelessly, if the device connection fails, check

that the device is connected to a power supply and also check that the Bluetooth audio device is operating properly.

• If Bluetooth is turned on, the projector will automatically connect to the

last connected Bluetooth device when the projector powers on. (Be sure to check that the last connected Bluetooth device is powered on as well.)

• This projector does not support the LG TV Sound Sync feature. To use

products that support the LG TV Sound Sync feature, use the general Bluetooth mode instead of the LG TV mode.

• The Bluetooth function is to connect the product to Bluetooth speakers

or Bluetooth headset. You cannot connect the product to a mobile phone through the Bluetooth function.

Searching for Bluetooth Devices and Connecting

Go to • WIRELESS • Search Device to search for nearby Bluetooth audio devices and then connect any detected devices to the projector. (If the device name is longer than 20 characters, no more than 20 will be displayed.)

1 Set the Bluetooth device to pairing mode and then select Search Device.

• Select Stop searching to view the devices detected so far.

• If the device has not been detected, check that the device is powered on and

in pairing mode.

• The time it takes to search for devices may vary according to the signal

strength and the number of devices.

ENGLISH

WIRELESS

• SCREEN SHARE : [PJTR][LG]PH450UGV[0000]

• Group

• Channel

• Bluetooth : On

• Search Device

• List of registered devices

• AV Sync. Adjust

ꔂ Move ꔉ OK

2 When the search is complete, you can select a Bluetooth device and connect

ENGLISH

to it.

• You can stop the connection process immediately by selecting Stop

searching.

• The time it takes to connect to a device may vary according to the signal

strength and the number of devices.

Search Device

List Please wait.

Stop searching Close

Searching...

Search Device

List

HBS-700

Press OK(ꔉ) to connect the device.

Re-search Close

Search complete

3 When a Bluetooth device is connected, you will hear sound from the projector

through the connected device.

• The connected Bluetooth device will be added automatically to the List of

registered devices. Once registered, Bluetooth devices can be connected

simply by selecting them from the List of registered devices without having to search for them.

• Connected devices can only be disconnected from • WIRELESS

• List of registered devices.

Connecting, Disconnecting, or Deleting Bluetooth Devices in the List of registered devices

In • WIRELESS • List of registered devices, Bluetooth devices are shown in the order that they were connected, and the same devices can be reconnected simply by selecting them without having to search for them again.

List of registered devices

List

HBS-700

Delete

Press OK(ꔉ) to connect the device.

Delete All Close

Connecting

Select a Bluetooth device from the List of registered devices to connect to it.

• The registered Bluetooth device will attempt to connect automatically

depending on the characteristics of the device. (Refer to the manual for the Bluetooth device.)

• You can stop the connection process immediately by selecting Stop.

• The time it takes to connect to a device may vary according to the signal

strength and the number of devices.

ENGLISH

Disconnecting

Select Disconnect to disconnect the device.

• You can only disconnect a device from the List of registered devices.

Select Delete Marked or Delete All to delete any registered devices.

• Delete Marked: Press the red button in List of registered devices to delete

ENGLISH

• Delete All: Select Delete All in List of registered devices to delete all of the

Adjusting AV Sync. Adjust

When a Bluetooth device is connected, go to • WIRELESS • AV

Sync. Adjust to adjust the synchronization between the video and the Bluetooth

headset sound.

Deleting

the selected device.

registered devices.

• AV Sync. Adjust 10

◀ ▶

• This feature is only available when a Bluetooth device is connected.

• Audio sync may vary by manufacturer.

• When playing video from a connected USB drive, AV Sync. Adjust can also be

adjusted using the Set Audio. menu.

MY MEDIA

NOTE

Before Using

Connecting a USB Device

Connect a USB device (external HDD, USB memory) to the USB port of projector to

enjoy the content les stored in the USB

device with your projector. You cannot write or delete data in the USB device.

Connect a USB ash drive as shown below.

USB ash

Drive

Removing a USB Device

1 Click the button. 2 Use the or button to move to USB Device and press the button. 3 Select a USB to remove. Wait for conrmation that the USB device has

stopped before removing the USB.

• If detached early, an error may occur on the projector or the USB storage

device.

• Once a USB device has been selected for removal, it can no longer be read.

Remove the USB storage device and then re-connect it.

ENGLISH

• If the USB storage device has a built-in auto recognition program or uses its own

ENGLISH

• Some USB storage devices may not work or may work incorrectly.

• If you use a USB extension cable, the USB device may not be recognized or may

• Use only USB storage devices formatted with the Windows FAT32 or NTFS file

• For external USB HDDs, it is recommended that you use devices with a rated

• It is recommended to use a Hard Disk Drive with its own power supply. (If the

• It is recommended that you use USB flash drives of 32 GB or less and USB

• If a USB HDD with power-saving function does not work properly, turn the

• Data in USB storage device can be damaged so be sure to back up important

Tips for using a USB device

driver, it may not work.

not work properly.

system.

voltage of less than 5 V and a rated current of less than 500 mA.

power being supplied is not sufficient, the USB storage device may not be detected correctly). Note, a USB Hub is not supported.

HDDs of 2 TB or less.

power off and on. For more information, refer to the user manual of the USB HDD.

files to other devices. Data maintenance is the user's responsibility and the manufacturer is not responsible for data loss.

To Use My Media

1 Press the button on the remote control. 2 Select MY MEDIA.

Select desired le from the list. Watch the chosen le.

Sets play related settings by checking option during disk playback.

My Media supporting file

• Maximum data transmission rate: 20 Mbps (Mega bit per second)

• External supported subtitle formats: *.smi, *.srt, *.sub (MicroDVD, SubViewer

1.0/2.0), *.ass, *.ssa, *.txt (TMPlayer), *.psb (PowerDivX)

• Internal supported subtitle formats: SRT/ASS/SSA (Supports internal subtitles

generated from DivX6)

ENGLISH

Video Supported Codec

Maximum: 1920 x 1080 @ 30p (only Motion JPEG 640 x 480 @ 30p)

ENGLISH

Extension Codec

.asf

.wmv

.divx

.avi

.mp4 .m4v .mov

.mkv

.ts

.trp

.tp

.mts

.m2ts

.vob

.mpg

.mpeg

Video

Audio WMA Standard, WMA 9 Professional

Video

Audio

Video H.264/AVC, MPEG-4 Part 2

Audio AAC

Video H.264/AVC

Audio HE-AAC, Dolby Digital

Video H.264/AVC, MPEG-2, VC-1

Audio

Video MPEG-1, MPEG-2

Audio Dolby Digital, MPEG-1 Layer I, II, DVD-LPCM

Video MPEG-1

Audio MPEG-1 Layer I, II

VC-1 Advanced Prole, VC-1 Simple and Main Proles

DivX3.11, DivX4, DivX5, DivX6, XVID, H.264/AVC

MPEG-1 Layer I, II, MPEG-1 Layer III (MP3), Dolby Digital

MPEG-1 Layer I, II, MPEG-1 Layer III (MP3), Dolby Digital, Dolby Digital Plus, AAC

Audio File

File type Item Info

MP3

AC3

MPEG

AAC,

HEAAC

CDDA

LPCM

Bit rate 32 kbps to 320 kbps

Sampling rate 32 kHz to 48 kHz

Bit rate 32 kbps to 640 kbps

Sampling rate 32 kHz, 44.1 kHz, 48 kHz

Bit rate 32 kbps to 448 kbps

Sampling rate 32 kHz to 48 kHz

Bit rate 24 kbps to 3844 kbps

Sampling rate 8 kHz to 96 kHz

Bit rate 1.44 kbps

Sampling rate 44.1 kHz

Bit rate 1.41 Mbps to 9.6 Mbps

Multi-channel : 44.1 kHz, 88.2 kHz /

Sampling rate

Stereo : 176.4 kHz, 192 kHz

48 kHz, 96 kHz

ENGLISH

Available photo file

File type Item Info

2D (jpeg,

jpg, jpe), 3D (jps)

3D (mpo)

Support File type

Picture Size

Support File type

Picture Size

SOF0: Baseline, SOF1: Extend Sequential, SOF2: Progressive

Minimum: 64 x 64 Maximum: Normal Type: 15360 (W) x 8640 (H)

Progressive Type: 1920 (W) x 1440 (H)

MPO

4:3 size : 3648 x 2736, 2592 x 1944,

2048 x 1536

3:2 size : 3648 x 2432

BMP

PNG

* BMP and PNG format les may be slower to display than JPEG.

Picture Size

Support File type

Picture Size

Minimum: 64 x 64 Maximum: 9600 (W) x 6400 (H)

Interlace, Non-Interlace

Minimum: 64 x 64 Maximum: Interlace: 1200 (W) x 800 (H)

Non-Interlace: 9600 (W) x 6400 (H)

Watching the Videos

In the Movie List, you can watch movies stored on the connected USB device. Controls playback and sets options while viewing videos.

Tips for Playing Video Files

• Some subtitles created by users may not work properly.

• The video and subtitle files should be placed in the same folder. For subtitles to

display correctly, the video and subtitle files must have the same name.

• We do not support any stream that contains GMC (Global Motion

Compensation) or Qpel (Quarterpel Motion Estimation).

• Only H.264/AVC profile level 4.1 and lower is supported.

• Video files that exceed 50 GB (gigabyte) are not supported for playback. The file

size limit is dependent on the encoding environment.

• DTS audio codec is not supported.

ENGLISH

Page 1/1

Play a video le stored from a connected device.

1 Connect a USB storage device.

ENGLISH

2 Press the button. 3 Use the , or button to select Movie List and press the button. 4 Use the , , , or button to select the le you want and press the

Browsing Movie List

button.

Movie List

USB STORAGE DEVICE

Butterfly_... 01:34:33

Drive1 Drive5Drive3 Drive4

Drive2

Page Change

PAGE

Page 1/1

Go to root folder

Go to upper folder

6 7 8

No. Description

Thumbnails

Abnormal le

File not supported

File List

Moves to the upper level folder.

Current page/Total no. of folder pages

Current page/Total no. of le pages

Exit

No. Description

Moves to the top level folder.

Moves to the upper level folder.

Exit Movie List.

5 Control playback by using the following buttons.

Option

Q.MENU

Item Description

Shows the current playing position. Use or buttons to move forward or backward.

Stops playing and returns to Movie List.

Returns to normal playback.

Pauses the media player. If no button is pressed on the remote control for 10 minutes after pausing, the playback is restarted.

Displays in slow motion.

Whenever this button is pressed, the playback speed is changed.: x2, x4, x8, x16, x32

Reduces power consumption by adjusting peak screen brightness.

Switches to the 3D screen.

Option A pop-up window will appear.

Hide

Hides the playback bar. Press the button to make it appear.

Exit Returns to the Movie List screen.

ENGLISH

나가기

Hide

Exit

1 Press the button. 2 Use the or button to move to a desired option and press the

ENGLISH

3 Use the , , , or button to set up each item.

Set Video Play.

Options for Movie List

button.

Item Description

Selects the size of a playback screen.

Picture Size

Audio Language

Subtitle Language

Repeat

• Full: Files are played in full screen mode according to the

aspect ratio of video.

• Original: Displays the video in the original size.

Allows you to select the language you want for the le with multiple audio tracks. This option is not available if the le has

only one audio track. The subtitle can be turned on or off.

• Language: One of any of the available languages can be

selected.

• Code Page: A character set used for a subtitle can be

selected. By default, the subtitle is displayed in a language configured in OPTION 1 • Language.

- Sync: If a subtitle is not synchronized with its video, you can adjust its speed at 0.5 seconds unit.

- Position: Moves the location of a subtitle.

- Size: Changes the subtitle font size.

Turns the repeat function On or Off.

When it is set to off, the next le can be played sequentially if the le name is similar.

Set Video.

You can change video settings.

Set Audio.

You can change audio settings.

BLUETOOTH

You can change Bluetooth settings.

Projector on page 40.)

(Refer to PICTURE Settings on page 76.)

(Refer to AUDIO Settings on page 82.)

(Refer to Setting Up Bluetooth on the

Set 3D Video

NOTE

You can set 3D video or 2D video.

3D setting

You can set 3D settings.

Registering the DivX code

Checks DivX Reg. Code for replaying DivX protected videos. Register at http://vod. divx.com. Use Reg. Code to rent or purchase movies at www.divx.com/vod.

(Refer to OPTION 1 Settings on page 87.)

1 In the Settings menu, move to OPTION 1 and press DivX(R) VOD. 2 Press the or button to move to Registration and press the

button.

3 Check the DivX Registration code.

Registration

Deregistration

You must register your device to

play DivX(R) protected videos.

Registration code: XXXXXXXXXX

ENGLISH

• Rented/purchased DivX files cannot be played if the DivX Registration Code

of a different device is used. Use only the DivX Registration Code granted to this specific device.

• Converted files not conforming to the DivX Codec Standard may not play or

may produce abnormal sound.

NOTE

Use the DivX deregistration code to deactivate the DivX DRM function.

1 In the Settings menu, move to OPTION 1 and press DivX(R) VOD.

ENGLISH

2 Use the or button to go to Deregistration and press the

To deregister the DivX code

button.

Registration

Deregistration

Your device is already registered.

Are you sure you wish to deregister?

Yes

Deregistration code : ********

Deregister at http://vod.divx.com

Continue with registration?

Yes

3 Select Yes.

• What is DRM [Digital Rights Management]?

DRM technologies and services protect the interests and rights of copyright holders by preventing illegal use of digital content. Files can be played after the license is verified through an online method, etc.

Viewing the Photos

You can view photos stored on a connected device.

Supported Photo Files

PHOTO (*.JPEG) Baseline: 64-pixel (width) x 64-pixel (height) - 15360-pixel (width) x 8640-pixel (height) Progressive: 64-pixel (width) x 64-pixel (height) - 1920-pixel (width) x 1440-pixel (height)

• Non-supported files are displayed in the form of an icon.

• An error message is displayed for corrupted files or file formats that cannot be

played.

• Corrupted files may not be displayed properly.

• It may take some time to view high-resolution images in full screen.

ENGLISH

1 Connect a USB storage device. 2 Press the button.

ENGLISH

3 Use the or buttons to select Photo List and press the button. 4 Use the , , , or button to select the le you want and press the

Browsing Photo List

button.

Photo List

USB STORAGE DEVICE

Butterfly_... 06/09/2014

Drive1 Drive5Drive3 Drive4

Drive2

Page 1/1

Page Change

PAGE

Page 1/1

Go to root folder

Go to upper folder

6 7 8

No. Description

Thumbnails

Abnormal le

File not supported

File List

Moves to the upper level folder.

Current page/Total no. of folder pages

Current page/Total no. of le pages

Moves to the top level folder.

Moves to the upper level folder.

Exits Photo List.

Exit

5 Control playback by using the following buttons.

01_a.jpg 2008/12/10 1920 x 1080 479 KB [1/4]

ENGLISH

Slideshow

BGM

Q.MENU

Item Description

Selects the previous or next photo.

Slideshow

BGM

All photos are displayed during slide show.

• Set Slide Speed in the Option • Set Photo View. menu.

You can listen to music while viewing photos in full size.

• Set the BGM in the Option • Set Photo View. menu.

Rotates photos.

• Rotates a photo 90°, 180°, 270°, 360° clockwise.

• Photos cannot be rotated if their width is greater than the

height of the max. supported resolution.

Views the photo in full mode or original mode. Press the blue button to enlarge the image.

Reduces power consumption by adjusting peak screen brightness.

Switches to the 3D screen.

Option A pop-up window will appear.

Hides the menu on the full size screen.

Hide

• To see the menu, press the button on the remote

control.

Exit Exit from full screen photo view.

Hide Exit

Option

1 Press the button. 2 Use the or button to move to a desired option and press the

ENGLISH

3 Use the , , , or button to set up each item.

Set Photo View.

Set Video.

You can change video settings.

Set Audio.

You can change audio settings.

BLUETOOTH

You can change Bluetooth settings.

Projector on page 40.)

Set 3D Video

You can set 3D image or 2D image.

3D setting

You can set 3D settings.

Options for Photo List

button.

Item Description

Slide speed

BGM

Selects a slideshow speed.

Selects a music folder for the background music.

• You cannot change the music folder while the background

music is playing.

• For background music, only the folder from the same device

can be selected.

- Repeat: Selects repeat play.

- Random: Selects random play.

(Refer to PICTURE Settings on page 76.)

(Refer to AUDIO Settings on page 82.)

(Refer to Setting Up Bluetooth on the

(Refer to OPTION 1 Settings on page 87.)

Listening to Music

Page 1/1

You can play audio les stored on the connected device.

Supported Music Files

*.MP3 Bit rate range 32 Kbps to 320 Kbps

• Sampling rate MPEG1 Layer3: 32 kHz, 44.1 kHz, 48 kHz

• Sampling rate MPEG2 Layer3: 16 kHz, 22.05 kHz, 24 kHz

Browsing Music List

1 Connect a USB storage device. 2 Press the button. 3 Use the or button to select Music List and press the button. 4 Use the , , , or button to select the le you want and press the

button.

Page Change

PAGE

Page 1/1

Exit

Music List

USB STORAGE DEVICE

Butterfly_... 03:25

Go to root folder

Drive1 Drive5Drive3 Drive4

Drive2

Go to upper folder

6 7 8

ENGLISH

No. Description

Thumbnails

ENGLISH

Abnormal le

File not supported

File List

Moves to the upper level folder.

Current page/Total no. of folder pages

Current page/Total no. of le pages

Moves to the top level folder.

Moves to the upper level folder.

Exits Music List.

5 Control playback by using the following buttons.

Music List

USB STORAGE DEVICE

Butterfly_... 03:25

Drive1

Page 1/1

Page Change

PAGE

Page 1/1

ENGLISH

002. - B02.mp3

Q.MENU

Option Hide

Item Description

Changes the playing position.

Stops playing.

Returns to normal playback.

Pauses the media player.

Plays the previous/next le.

Reduces power consumption by adjusting peak screen brightness.

Option Sets up the options of Music List.

Hide

Hides the playback bar.

• Press the button to make the playback bar appear.

Exit Returns to the Music List screen.

Exit

1 Press the button. 2 Use the or button to move to a desired option and press the

ENGLISH

3 Use the , , , or button to set up each item.

Set Audio Play.

Set Audio.

You can change audio settings.

BLUETOOTH

You can change Bluetooth settings.

Projector on page 40.)

Options for Music List

button.

Item Description

Repeat

Random

Selects repeat play.

Selects random play.

(Refer to AUDIO Settings on page 82.)

(Refer to Setting Up Bluetooth on the

Viewing Files

You can see document les stored on a connected device.

Supported File Formats

XLS, XLSX, DOC, DOCX, PPT, PPTX, TXT, PDF, HWP

Microsoft Ofce: 97/2000/2002/2003/2007 Version

Adobe PDF: 1.0/1.1/1.2/1.3/1.4 Version Hangul: 97/2000/2002/2005/2007 Version

• File Viewer realigns a document, so it may look different from what is displayed

on a PC.

• For documents that include images, the resolution may look lower during the

realigning process.

• If the document is large or has many pages, it may take longer to load.

• Unsupported fonts may be replaced by other fonts.

• The file viewer may not open for Office documents that contain many high

resolution images. In that case, reduce the image file size, save it on a USB storage device and run the file viewer again or connect your PC to the projector and open the file on your PC.

ENGLISH

DOC

1 Connect a USB storage device. 2 Press the button.

ENGLISH

3 Use the or button to select File List and press the button. 4 Use the , , , or button to select the le you want and press the

Browsing File List

button.

File List

USB STORAGE DEVICE

Butterfly_... 06/09/2014

Drive1 Drive5Drive3 Drive4

Drive2

Page 1/1

Page Change

PAGE

Page 1/1

Go to root folder

Go to upper folder

Exit

5 6 7

No. Description

File List

Moves to the upper level folder.

Current page/Total no. of folder pages

Current page/Total no. of le pages

Moves to the top level folder.

Moves to the upper level folder.

Exits File List.

5 Control playback by using the following buttons.

• Click Go Page, then the pop-up window for selecting the number of page

appears. Input the page to move to the page you want.

• Press the

Press the button and then use the Up/Down/Left/Right buttons to move to Go Page or Zoom.

button to zoom in or zoom out.

ENGLISH

Go Page Zoom Option Hide Exit

Q.MENU

ꔦ

Item Description

Moves to the page you want.

Go Page

Use the Up/Down/Left/Right buttons to select a page and press the button.

Zoom

Option

Hide

Exit

Enlarges or reduces the document.

Sets up the options of File Viewer.

Hides the menu.

• Press the button to make it appear.

Returns to the File Viewer screen.

1 Press the button. 2 Use the , , , or button to set up each item.

ENGLISH

Set FileViewer Option

File Viewer settings are default, so close the currently opened document to apply changes to the new document, if any.

Options for File List

Item Description

On Loads and displays pages one by one. The initial

loading time is short but a content-heavy page may

Single Page Loading

Image Quality

Docu ment Align

be displayed slowly.

Off Loads all pages of a le to memory before it starts to

display them. The initial loading time is long but you can navigate pages quickly after loading is complete.

If a le is too large, it may fail to load all the pages.

You can set the quality of the image included in the document. The following three options are available for the image quality: High, Medium, Low. Higher the image quality, lower the display time.

Selects initial document align method.

3D FUNCTION

3D technology uses different video frames for each eye to add depth to the video.

While Watching 3D

WARNING

• If you view 3D video or images too closely for a long period of time, you may

experience eyestrain.

• If you watch the projector or game screen for a long time with 3D glasses on,

you may experience dizziness or eye fatigue.

• People with chronic diseases (epilepsy, cardiovascular disease, blood pressure-

related diseases, etc.), pregnant women, and people with serious motion sickness should avoid watching 3D video.

• People with stereo blindness, or with stereopsis problems, should also avoid

watching 3D video content. It may cause double vision or visual discomfort.

• People with strabismus, amblyopia, or astigmatism may have difficulty perceiving

video depth and may be fatigued easily due to double vision or other ailments. It is recommended to rest more frequently than other viewers.

• Because 3D can be perceived as real, some viewers may be surprised or

overexcited.

• Do not watch 3D images near fragile objects or any objects that can be knocked

over easily.

• Take care not to injure yourself as you may subconsciously try to move away

from the life-like 3D images.

ENGLISH

• Warning about photosensitivity seizures

ENGLISH

• You can reduce the risk of photosensitive seizures by taking the following

• Extra special care is required for children watching a 3D video.

• Prevent children of 5 years or younger from watching a 3D video. It may impair

• Children 10 years old or younger are still developing their eyesight and may

• Since the distance between the eyes is narrower for children than in adults,

• Children under 19 years old or younger may respond with sensitivity to the light

- Some users may experience a seizure or other abnormal symptoms when

they are exposed to a ashing light or particular patterns from a video game.

If anyone in your family has a history of epilepsy or has ever experienced any kind of seizure, please consult your doctor before viewing 3D images. If you experience one of the following symptoms while watching a 3D video, stop watching the 3D video immediately and take a rest.

- Dizziness, switched eyesight, twitching of the eye or facial muscles, involuntary movements, cramp, loss of consciousness, confusion, loss of sense of direction, or nausea. If the symptom does not disappear, please consult your doctor.

preventive measures.

- Take a rest of 5 to 15 mins. for every 1 hour of viewing.

- If vision varies between each eye, correct the variation before beginning to watch a 3D video.

- Ensure that the 3D video is directly in front of you, at eye level.

- You should stop watching if you experience a headache, fatigue, or dizziness.

- Do not view 3D images for a long period of time when you are tired or ill.

CAUTION

When Watching 3D Video

the development of their eyes.

have an excessive tendency to touch or jump at the screen. Adult guidance and supervision is recommended.

children tend to notice a greater difference in the images seen by each eye. Therefore, even while watching the same 3D video, children may have a greater depth perception than adults.

stimuli of 3D content. Excessive viewing when fatigued is not recommended.

• Elderly viewers may have a reduced depth perception than younger viewers.

Avoid watching video nearer than the recommended distance.

• Watch 3D images within the optimum viewing angle and distance.

• If you are outside the viewing angle or distance, you may not be able to see 3D

images. You cannot view 3D images when you are lying down.

• You may see left and right images overlapped during projector initialization after

it is powered on. It may take some time for optimization.

• It may take some time for the 3D image to look normal after you turn your eyes

away from the screen and look back at the 3D image.

• It may flicker slightly while watching 3D images under a 3 wavelength lamp

fluorescent light (50 Hz to 60 Hz) or near windows. If so, it is recommended to block the sun light with a curtain and to dim the lights.

• The 3D glasses must be DLP-LINK (DLP Ready) type.

• You may not be able to watch 3D properly if there is an obstacle between the

projector and 3D glasses.

• Install the 3D projector as far as possible from other devices.

• If a future 3D broadcasting format that is not supported by this projector

becomes the standard, an additional device such as a set-top box may be required.

Please check the following when using 3D glasses.

• Do not use 3D glasses as ordinary glasses, sunglasses, or protective goggles.

- If you do so, this may cause injury.

• Do not store 3D glasses in very hot or very cold conditions. If you do, this may

cause them to become distorted. Do not use distorted glasses.

• Do not drop 3D glasses or allow them to come into contact with other objects.

- This may cause product malfunction.

• The lenses of 3D glasses are easily scratched. Use a soft clean cloth when

cleaning them.

• Foreign particles on the cloth may cause scratches.

• Do not scratch the surface of the 3D glasses' lenses with sharp objects or wipe

them with chemicals. If the lenses get scratched, images may not look normal when viewing 3D.

ENGLISH

NOTE

Requirements for Watching 3D Images

ENGLISH

* Watching 3D videos should be done in dark room environments only.

* Optimum viewing angle: Top/Bottom/Left/Right 9°

Recommended viewing distance: 3 m to 5 m (with Adaptor)

1 m to 2 m (without Adaptor)

Recommended screen size: 101 cm

• The pairing with the DLP-LINK glasses is affected by the intensity of light

reflected from the screen. Therefore, the pairing with DLP-LINK glasses may not work properly if the light reflected from the screen is not bright enough, such as when the surrounding area is bright, the screen is big, or the maximum energy saving mode is enabled.

• Some menus may not work while playing a 3D video.

• You can only watch a 3D video properly when the 3D video format option

has been selected on the projector.

Using the DLP-LINK (DLP-Ready) Type Glasses

1 While watching 3D images from the projector, press buttons on the glasses. 2 When you press the button, the glasses icker while synchronizing with the 3D

images. (The ickering is a unique operation method of DLP-LINK type glasses.

It may be different depending on the glasses type.)

3 If the glasses icker or problems occur while watching 3D, rst turn the lights

off to make the room darker. Contact your projector seller for queries about the glasses.

To view 3D images

3D imaging is a technology that utilizes the slight difference in left/right eyes to make the images on the projector appear just like real-life 3-dimensional space.

1 Play supported 3D video titles. 2 Press the button to activate 3D. 3 Turn on the 3D glasses and put them on. 4 While viewing 3D images, press the button on the remote control to end

3D image viewing.

5 Press the button to switch the playing direction of an image. Select a

screen with better 3D display quality.

- If you press the button during viewing, it returns to 2D.

* Depending on the input signal, the available 3D type may differ.

ENGLISH

Supported 3D Mode

ENGLISH

Signal Resolution

720p

1080i

HDMI

1080p

USB 1080p

1280 x

720

1920 x

1080

1920 x

1080

1920 x

1080

Horizontal Frequency

(kHz)

89.9 / 9059.94 /

75 50 Frame Packing

45 60

37.5 50

33.7 60

28.125 50

53.95 / 5423.98 /

67.5 60

27 24

33.7 30

56.25 50

33.75 30

Vertical

Frequency

(Hz)

Supported 3D

Frame Packing

Side by side (half), Top and Bottom

Frame Packing

Side by side (half), Top and Bottom, Single Frame Sequential

Side by side (half), Top and Bottom

Side by side (half), Top and Bottom, Single Frame Sequential

Side by side, Top and Bottom, MPO, JPS (Photo)

Formats

CUSTOMIZING SETTINGS

SETTINGS

1 Press the button. 2 Use the , , , or button to select the desired item and press the

button.

3 Use the , , , or button to set up the desired item and press the

button.

4 Press the button when completed.

Menu Description

PICTURE Adjusts the image quality for optimal viewing.

AUDIO Adjusts the sound quality and volume level.

TIME Sets time-related settings.

WIRELESS Wireless-related features.

OPTION 1 Customizes the general settings.

OPTION 2 Customizes the settings related the projector.

INPUT Selects the desired input source.

MY MEDIA Accesses photo, music, movie, and document les.

ENGLISH

PICTURE Settings

1 Press the button. 2 Use the , , , or

ENGLISH

3 Use the , , , or

4 Press the button when

The available picture settings are described as follows.

buttons to select PICTURE and press the button.

button to set up the desired item and press the button.

- To return to the previous

menu, press the button.

completed.

Menu Description

Reduces power consumption by adjusting peak screen brightness.

Energy Saving

Minimum/ Medium/

Applies the pre-set Energy Saving mode.

Maximum


• Energy Saving : Minimum

• Picture Mode : Standard

• Contrast 100

• Brightness 50

• Sharpness 20

• Color 55

• Tint 0

Mode

ꔂ Move ꔉ OK

Menu Description

Selects the picture mode optimized for the viewing environment or the program. You can also customize advanced options for each mode.

Mode

Maximizes the visual effect of video.

Vivid

Standard

Cinema Optimizes the image for a movie.

Picture Mode

Contrast

Brightness Adjusts the overall screen brightness.

Sharpness

Color Adjusts the intensity of all colors.

Tint Adjusts the balance between red and green levels.

Sport

Game

Expert1 / Expert2

Adjusts the difference between bright and dark regions of the screen.

Adjusts the sharpness of the borders between bright and dark. Horizontal and Vertical Sharpness are available only in

Expert1/Expert2.

Heightens contrast, brightness, and sharpness to display vivid images.

Displays images in standard levels of contrast, brightness, and sharpness.

Optimizes the image for sports by emphasizing primary colors and dynamic actions.

Optimizes the image for playing games on fast-moving screens.

Menu for adjusting picture quality that allows experts and amateurs to enjoy the best projector viewing.

- Expert mode is for picture tuning

professionals to control and ne-tune using a specic image. For normal images,

the effects may not be dramatic.

ENGLISH

Menu Description

Advanced Control

Picture Option Sets optional settings.

Picture Reset

Aspect Ratio Resizes the picture.

Advanced Control

Menu Description

Dynamic Contrast

Dynamic Color Adjusts colors for more natural-looking colors.

Color Gamut

Skin Color

Sky Color Sky color is set separately.

Grass Color

Gamma

Customizes the advanced settings.

Resets values customized by the user. Each picture mode is reset. Select the picture mode you wish to reset.

Adjusts contrast and color to the optimal level according to the screen’s brightness.

Selects the range of colors that can be expressed.

• Standard: Displays the original colors of an input signal

regardless of the display features.

• Wide: Makes use of the display's rich colors.

Skin color spectrum can be separately set to implement the

skin color as dened by the user.

Natural color spectrum (meadows, hills, etc.) can be separately set.

Sets the gradation curve according to the output of the picture signal in relation to the input signal.

* Depending on input signal or other picture settings, the range of detailed items

for adjustment may differ.

Expert Control

Menu Description

Dynamic Contrast

Color Gamut

Edge Enhancer

Color Filter

Color Temperature

Adjusts contrast and color to the optimal level according to the screen’s brightness.

Selects the range of colors that can be expressed.

• Standard: Displays the original colors of an input signal

regardless of the display features.

• Wide: Makes use of the display's rich colors.

Shows clearer and distinctive yet natural edges of the video.

Filters a specic color spectrum in RGB colors to ne-tune

color saturation and hue accurately.

In Expert mode, you can customize the options of each mode.

Gamma: Select 1.9, 2.2,or 2.4.

a. Method: 2 Points

- Pattern: Inner, Outer

- Points: Low, High

- Red/Green/Blue: The adjustment range for each color is from -50 to +50.

- Apply to all inputs: The values of the Color

Temperature is applied to all the input modes.

b. Method: 20 Point IRE

- Pattern: Inner, Outer

- IRE (Institute of Radio Engineers) is the unit indicating the size of a video signal and can be set to 5,10,15, ... 100. You can ne-tune for each setting as shown below.

- Luminance: The adjustment range is 50 to 500.

- Red/Green/Blue: The adjustment range is -50 to +50.

- Apply to all inputs: The values of the Color

Temperature is applied to all the input modes.

ENGLISH

* Depending on input signal or other picture settings, the range of detailed items

Menu Description

Adjusts Red/Green/Blue/Cyan/Magenta/Yellow colors. Allows an expert to adjust the tint using a test pattern. Six colors (Red/Green/Blue/Cyan/Magenta/Yellow) can

Color Management System

for adjustment may differ.

be selectively adjusted without affecting other colors. You may not see colors change on a normal picture even after adjustment.

- Saturation Red/Green/Blue/Cyan/Magenta/Yellow,

Tint Red/Green/Blue/Cyan/Magenta/Yellow, Luminance Red/Green/Blue/Cyan/Magenta/Yellow:

The adjustment range is -30 to +30 each.

Picture Option

Menu Description

Noise Reduction Reduces screen noise in the video.

MPEG Noise Reduction

Black Level

Real Cinema

Color Temperature

Eliminates noise generated while creating digital picture signals.

Adjusts the brightness or darkness of the screen to suit the black level of the picture input using the degree of darkness (black level) of the screen.

Optimizes the screen for movie viewing.

Adjusts the overall color of the screen to suit your preference. Select Warm, Natural, Cool, or Medium.

ENGLISH

AUDIO Settings

1 Press the button. 2 Use the , , , or

ENGLISH

3 Use the , , , or

4 Press the button when

The available audio settings are described as follows.

button to select AUDIO and press the button.

button to set up the desired item and press the button.

- To return to the previous menu, press the button.

completed.

Menu Description

Sets the sound mode.

Sound Mode

Standard Suitable for all types of video. News/Music/

Cinema/Sport/ Game

Sets audio optimized for a specic genre.

AUDIO

• Sound Mode : Standard

• Sound Effect

• Auto Volume : Off

Mode

ꔂ Move ꔉ OK

Menu Description

The user can select various sound effects.

Mode

Clear Voice II

Virtual Surround

Sound Effect

Equalizer

Balance

Reset

Auto Volume Automatically adjusts the volume level.

Makes the voice from the projector crisp and clear.

LG’s proprietary audio processing technology allows 5 channel-like surround sound from two speakers.

• When Clear Voice II is set to on,

Virtual Surround cannot be selected.

Adjusts the volume to a level of your choice using the Equalizer.

• Audio-band (100 Hz/ 300 Hz/ 1 kHz/

3 kHz/ 10 kHz) can be adjusted from

-10 to 10.

• Reset: Resets voice options that the

user has changed.

Adjusts the balance of the left and right speakers.

Initialize the applied effect under the

Sound Effect menu.

ENGLISH

TIME Settings

1 Press the button. 2 Use the , , , or

ENGLISH

3 Use the , , , or

4 Press the button when

The available time settings are described as follows.

button to select TIME and press the button.

button to set up the desired item and press the button.

- To return to the previous menu, press the button.

completed.

Menu Description

Sleep Timer

Auto Off

Automatic Standby

Turns off the projector after a preset number of minutes. To cancel the Sleep Timer, select Off.

If there is no input signal or button press, the projector automatically turns off after the preset time has elapsed.

Turns off the projector automatically after a set period of time if there is no button input on the projector.

TIME

• Sleep Timer : Off

• Auto Off : 60 min.

• Automatic Standby : 4 hours

ꔂ Move ꔉ OK

WIRELESS Settings

1 Press the button.

WIRELESS

2 Use the , , , or

button to select WIRELESS and press the button.

• SCREEN SHARE : [PJTR][LG]

3 Use the , , , or

button to set up the desired item and press the button.

- To return to the previous menu, press the button.

• Bluetooth : Off

4 Press the button when

completed.

The available wireless settings are described as follows.

Menu Description

The SCREEN SHARE displays the screen of the connected device.

• You can check the SCREEN SHARE's ID.

Mode

This is the group setting for each device supporting the SCREEN SHARE feature.

Group

SCREEN SHARE

Channel

When the wireless connection is weak or unstable, adjust the group setting to correct the problem.

You can change the channel used for wireless connections.

• Search Channels: Select channel

searching methods.

- Auto: The projector searches for available channels and automatically selects the least used channel.

- Manual: You can select a channel manually.

• Channel: This is shown when Search

Channels is set to Manual. It allows you

to specify a channel number to use.

ꔂ Move ꔉ OK

PH450UGV

[0000]

• Group

• Channel

• Search Device

• List of registered devices

• AV Sync. Adjust

ENGLISH

Menu Description

Sound is output through the Bluetooth headset. First, set Bluetooth to On.

Bluetooth

Search Device

List of registered devices

AV Sync. Adjust

Search for the device to connect to.

Connected devices are saved in the List

of registered devices. The saved list of

registered devices can be displayed. When the video and the sound are not

synchronized correctly, you can manually adjust the synchronization.

Item

OPTION 1 Settings

1 Press the button.

OPTION 1

2 Use the , , , or

button to select OPTION 1 and press the button.

3 Use the , , , or

button to set up the desired item and press the button.

- To return to the previous menu, press the button.

• Language

• 3D Mode

• DivX(R) VOD

• Initial Setting

• Mode Setting : Standard

4 Press the button when

completed.

The available option 1 settings are described as follows.

Menu Description

Language Selects a desired Menu Language.

Adjusts various aspects of 3D imaging.

3D Mode

DivX(R) VOD Sets DivX related settings.

Initial Setting

Mode Setting

3D Picture Correction

Resets all the projector settings to the factory default. Do not turn off the power during initialization.

Selects Standard or Store Demo. When in use in home, please select Standard.

Store Demo mode is for store display.

Mode

Switches left/right images of 3D video.

ꔂ Move ꔉ OK

ENGLISH

OPTION 2 Settings

1 Press the button. 2 Use the , , , or

ENGLISH

3 Use the , , , or

4 Press the button when

The settings for option 2 are described as follows.

button to select OPTION 2 and press the button.

button to set up the desired item and press the button.

- To return to the previous menu, press the button.

completed.

Menu Description

To prevent the screen image from becoming trapezoidal,

Keystone

Keystone adjusts the top and bottom width of the image if the projector is not set at a right angle to the screen.

Auto Keystone provides a rectangular screen image by

automatically adjusting the Keystone number when there is a trapezoidal screen image caused by tilting of the projector.

Auto Keystone

On Automatically adjusts the Keystone number.

Off Manually adjusts the Keystone number.

This function turns the projected image upside down or

ips horizontal.

• Select Rear when projecting from the back of the

PJT Mode

transparent screen purchased separately.

• Select Front Ceiling when installing the product on the

ceiling.

• When the PJT Mode is Rear Ceiling/Front Ceiling, the

left/right of the speaker changes automatically.

OPTION 2

• Keystone 0

• Auto Keystone : Off

• PJT Mode : Front

• High Altitude : Off

• Blank Image : Blue

• Auto Power : Off

• Self Diagnosis

Item

ꔂ Move ꔉ OK

- +

Menu Description

If the projector is used at an altitude higher than 1200 meters, turn this on.

High Altitude

Blank Image Selects a background for blank image.

Auto Power

Self Diagnosis

Otherwise, the projector may overheat or its protection function may be activated. If this happens, turn the projector off and then on again after waiting for several minutes.

Makes the projector turn on automatically when the adaptor plug is inserted.

Item

Off

Troubleshoots functional problems that can arise while using the product.

When the AC/DC plug is connected to the projector, it turns on automatically.

When the AC/DC plug is connected to the projector, it goes into standby mode.

ENGLISH

CONNECTING DEVICES

You can connect various external devices to the projector.

ENGLISH

Computer/Notebook

Digital Device

Headphones

Mobile Phone (MHL/Slimport) - Page 94

DVD

HDMI - Page 91 USB Device - Page 45 Headphone - Page 93

USB

Game Console

Mobile Phone

Connecting to HD Receiver, DVD Player, or External Devices

Connect an HD receiver, DVD player, or External Devices to the projector and select an appropriate input mode.

HDMI Connection

With an HDMI cable, you can enjoy high quality picture and sound. Using a HDMI cable, connect the

port of the projector to the HDMI output port of the device to connect. Both video and audio are output at the same time. Press the button on the remote control to select HDMI.

Optional Extras

Connecting a PC

The projector supports Plug and Play. Your PC will automatically detect the projector and requires no driver installation.

HDMI Connection

Using an HDMI cable, connect the

port of the projector to the HDMI output port of your PC. Both video and audio are output at the same time. Press the button on the remote control to select HDMI.

Optional Extras

ENGLISH

Connecting a Laptop

You can connect the projector to a laptop to use various functions.

ENGLISH

HDMI Connection

Using an HDMI cable, connect the

HDMI output port of your laptop. Both video and audio are output at the same time. Press the button on the remote control to select HDMI.

port of the projector to the

Optional Extras

The table below shows examples of switching the output. For more information, refer to the External

Output, Connecting to an External Monitor, or similar sections of the

owner's manual of your computer.

Brand Switching Output

NEC Fn + F3

Panasonic Fn + F3

Toshiba Fn + F5

IBM Fn + F7

Sony Fn + F7

Fujitsu Fn + F10

LG Fn + F7

Samsung Fn + F4

Macintosh Adjust the control

panel to enable mirroring after start-up.

Connecting to Headphones

You can listen to the audio through a headphone.

Not provided

ENGLISH

NOTE

Using the Mirroring Function of a Mobile Phone

MHL/Slimport Connection

ENGLISH

You must use a HDMI adapter to connect your cell phone to the projector and to output images and sound from your cell phone to the projector. The compatible HDMI adapters are different, depending upon your cell phone type. Therefore, purchase an appropriate MHL or Slimport adapter.

(To nd out whether your device is MHL/Slimport-certied, please contact your

device manufacturer.)

Optional Extras

• When you connect a mobile phone to the port, you can see the

mobile phone screen through a projector.

- This only applies to mobile phones that support MHL/Slimport.

- You can use the remote control for some applications.

• Disconnect the MHL/Slimport cable from the projector when:

- The MHL/Slimport function is disabled.

- Your mobile device is fully charged in standby mode.

MAINTENANCE

Clean your projector to keep it in optimal condition.

Cleaning

Cleaning the Lens

If there is any dust or staining on the lens surface, you must clean the lens. Use an air spray or a cleaning cloth to clean the lens. To remove dust or stains, use an air spray or apply a small amount of cleaning agent onto a swab or soft cloth to lightly rub the lens.

Please be aware that liquid may ow into the lens if the product is sprayed directly

onto the lens.

Cleaning the Projector Case

To clean the projector case, rst unplug the power cord.

To remove dust or stains, use only a dry, lint-free, nonabrasive cloth to polish the lens. Do not use alcohol, benzene, thinners, or other chemicals, which may damage the case.

ENGLISH

SPECIFICATIONS

ENGLISH

• Use only power supplies listed in the user instructions.

• Contents in this manual may be changed without prior notice due to upgrade of

MODEL PH450UGV (PH450UGV-GL)

Resolution (Pixel) 1280 (Horizontal) × 720 (Vertical) Aspect ratio 16:9 (Horizontal:Vertical)

Panel size 7.93 mm

Projection distance (Screen Size)

Ratio of upward projection

Working range of the remote control

Power consumption 55 W

AC-DC Adaptor

Audio Output 1 W + 1 W

Height 80.5 mm (without foot), 85 mm (with foot)

Width 132 mm

Depth 200 mm

Weight 1.0 kg

USB Device 5 V, 0.5 A (Max.)

Environment Condition

product functions.

274 mm to 531 mm (1016 mm to 2032 mm)

120 %

6 m

Manufacturer: Lite-On Model: PA-1650-43

19.0 V 2.53 A (Adaptor Input 100-240 V @ 50/60 Hz)

Temperature

Operation 0 °C to 40 °C Storage -20 °C to 60 °C

Relative Humidity

Operation 0 % to 80 %

Storage 0 % to 85 %

Manufacturer: APD Model: DA-48F19

Supported HDMI(PC) Mode

Resolution

640 x 350 31.468 70.09

720 x 400 31.469 70.08

640 x 480 31.469 59.94

800 x 600 37.879 60.31

1024 x 768 48.363 60.00

1152 x 864 54.348 60.053

1280 x 720 45.00 60.00

1280 x 1024 63.981 60.020

1440 x 900 55.935 59.888

1400 x 1050 65.317 59.979

1600 x 900 60 60

1680 x 1050 65.29 59.954

1920 x 1080 67.5 60

• If an invalid signal is input into the projector, it will not be displayed properly on

the screen or a message such as No Signal or Invalid Format will be displayed.

• The projector supports the DDC1/2B type as the Plug and Play function (Auto-

recognition of PC monitor).

• In PC mode, 1280 x 720 is recommended for the best picture quality.

Horizontal Frequency

(kHz)

Vertical Frequency

(Hz)

ENGLISH

• To provide the best picture quality, a 720p resolution is recommended.

To obtain the source code under GPL, LGPL, MPL, and other open source licenses, that is contained in this product, please visit http://opensource.lge.com. In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com. This offer is valid for three (3) years from the date on which you purchased the product.

Supported HDMI/DTV Mode

Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz)

31.47

480p

576p 31.25 50

720p

1080i

1080p

Open source software notice information

31.47

31.50

45.00

44.96

37.5

33.75

33.72

28.125

67.500

67.432

27.000

26.97

33.75

33.71

56.25

59.94 60

60.00

59.94 50

60.00

59.94 50

59.939

24.000

23.976

30.000

29.97 50
