Owner's Manual
LG MiniBeam
DLP Projector
Please read the safety information carefully before using this product.
PF50KA
P/NO : SAC37034696 (1712-REV00)
Copyright © 2018 LG Electronics Inc. All Rights Reserved.
www.lg.com
Page 2
2
LICENSES
Supported licenses may differ by model. For more information about licenses, visit
www.lg.com.
ENGLISH
The terms HDMI and HDMI High-Denition
Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI
Licensing Administrator, Inc. in the United
States and other countries.
Manufactured under license from Dolby Laboratories. Dolby, Dolby Vision,
Dolby Audio, Dolby Atmos, and the double-D symbol are trademarks of Dolby
Laboratories.
For DTS patents, see http://patents.dts.com. Manufactured under license from
DTS Licensing Limited. DTS, the Symbol, & DTS and the Symbol together, DTS
2.0 Channel, DTS 2.0+Digital Out, DTS-HD, and DTS Virtual:X are registered
trademarks or trademarks of DTS, Inc. in the United States and/or other countries.
© DTS, Inc. All Rights Reserved.
USB Type-CTM and USB-CTM are trademarks of USB Implementers Forum.
• Images shown in this manual may differ from your projector.
• Your projector’s OSD (On Screen Display) may differ slightly from that
shown in this manual.
Page 3
SAFETY PRECAUTIONS
Please take note of the safety instructions to prevent any potential accident or
misuse of the projector.
• Safety precautions are given in two forms, i.e., WARNING and CAUTION as
detailed below.
WARNING Failure to follow the instructions may cause serious injury and
even death.
CAUTION Failure to follow the instructions may cause personal injury or
product damage.
• Read the owner’s manual carefully and keep it on hand.
3
ENGLISH
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning ash with
arrowhead symbol, within an
equilateral triangle, is intended
to alert the user to the presence of
uninsulated dangerous voltage within
the product’s enclosure that may be of
sufcient magnitude to constitute a risk
of electric shock to persons.
The exclamation point within
an equilateral triangle is
intended to alert the user to
the presence of important operating
and maintenance (servicing) instructions
in the literature accompanying the
device.
WARNING/CAUTION
- TO REDUCE THE RISK OF FIRE
AND ELECTRIC SHOCK, DO NOT
EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Indoor Installation
WARNING
• Do not use the projector outside
and do not expose the product to
any humidity or water.
- Since the product is not
waterproof, this may result in a
re or electric shock.
• Do not place the projector in direct
sunlight or near heat sources such
as radiators, fires, stoves, etc.
- This may result in re.
• Do not place flammable materials
such as aerosols near the projector.
- This may result in re.
Page 4
4
• Do not allow children to cling to or
climb up to the projector.
- This may cause the projector to
fall, causing injury or death.
• Do not install the product in a
ENGLISH
place with no ventilation (e.g., on
a bookshelf or in a closet) or on a
carpet or cushion.
- This may result in re due to the
increase in internal temperature.
• Do not place the product close to
sources of steam, oil or oil mist,
such as humidifiers and kitchen
counters.
- Failure to do so may result in
re, electric shock, or corrosion.
• Do not install the product onto
a wall or ceiling that is close to
sources of oil or oil mist.
- The product may be damaged
and fall, resulting in serious
injury.
• Do not place the projector where it
might be exposed to dust.
- This may result in re.
• Do not use the projector in a damp
place such as a bathroom where it
is likely to get wet.
- This may result in re or electric
shock.
• Do not allow a tablecloth or curtain
to block the air vent.
- This may result in re due to
the increase in the internal
temperature.
• Ensure good ventilation around the
projector. The distance between the
projector and the wall should be at
least 30 cm (11.8 inches).
- This will prevent re due to
the increase in the internal
temperature.
Page 5
5
CAUTION
• When placing the projector on a
table or shelf, be careful not to put
it near the edge.
- The projector could fall due to
balance problems, which may
cause personal injury or damage
to the product. Make sure to use
the projector cabinet or stand
that ts the projector.
• When moving the projector, make
sure to switch it off and remove the
power plug and cords.
- The power cord may be
damaged, resulting in re or
electric shock.
• Do not place the projector on an
unstable or vibrating surface such
as a wobbly shelf or a slope.
- It may fall and cause injury.
• Be careful not to tip the projector
over when connecting external
devices to the projector.
- This may cause personal injury
or damage to the projector.
Power
WARNING
• DISCONNECTING THE DEVICE
FROM THE MAIN POWER
- The Power plug is the
disconnecting device. In case of
an emergency, the Power Plug
must remain readily accessible.
• The grounding wire should be
connected. (Except for devices
which are not grounded.)
- Ensure that you connect the
grounding cable to avoid electric
shock. If it is not possible to
ground the unit, have a qualied
electrician install a separate
circuit breaker.
Do not try to ground the
projector by connecting it to
telephone wires, lightning rods
or gas pipes.
• The power plug should be inserted
fully into the power outlet.
- An unstable connection may
cause a re.
• Do not place heavy objects on the
power cord.
- This may result in re or electric
shock.
• Never touch the power plug with
wet hands.
- This may result in electric shock.
ENGLISH
Page 6
6
• Do not plug too many devices into
one multi-power outlet.
- This may result in re due to the
power outlet overheating.
• Keep the AC adapter, power plug,
ENGLISH
and the used power outlet clean
from dust or foreign materials
building up.
- This may result in re.
• If there is any smoke or a burning
smell from the projector or AC
adapter, stop using the product
immediately. Disconnect the power
cord from the power outlet, and
then contact the customer service
center.
- This may result in re.
• To turn off the main power, remove
the power plug, which should be
positioned so it is easy to access for
operation.
CAUTION
• Always grab the plug to remove the
AC adapter or power cord.
- Otherwise, this may result in a
re or may damage the product.
• Refrain from constantly bending the
power cord of the AC adapter.
- If the power cord is bent
excessively for a long period
of time, the cord may break
inside. This may result in a re or
electric shock.
• Ensure the power cord and plug are
not damaged, modified, severely
bent, twisted, pulled, sandwiched or
hot. Do not use the product if the
power outlet is loose.
- This may result in re or electric
shock.
• Keep the power cord away from
heating devices.
- The wire’s sheath may melt,
which may result in re or
electric shock.
• Place the projector where people
will not trip over or step on the
power cord to protect the power
cord and plug from any damage.
- This may result in re or electric
shock.
Page 7
7
• Do not turn the projector on or
off by plugging in the power plug
or unplugging it from the power
outlet. (Do not use the power plug
as a switch.)
- This may result in electric shock
or damage to the product.
• Do not insert a conductor into the
other side of the wall outlet while
the power plug is inserted into the
wall outlet. In addition, do not touch
the power plug immediately after
it is disconnected from the wall
outlet.
- This may result in electric shock.
• Only use the official power cord
provided by LG Electronics. Do not
use other power cords.
- This may result in re or electric
shock.
• If any water or foreign materials
have gone into the AC adapter,
power cord, or the interior of the
projector, turn off the projector by
pressing the power button. Remove
all the cables, and then contact the
customer service center.
- This may result in re or electric
shock.
• The surface of the AC adapter is
hot. Keep the AC adapter out of the
reach of children and avoid touching
it during use.
• Never disassemble the power
supply devices (AC adapter/power
cord, etc.).
- This may damage the power
cord and result in a re or
electric shock.
• Connect the AC adapter and the
power cord firmly.
- Not doing so may result in a
product failure or re.
• Do not place heavy objects or put
pressure on the power cord and AC
adapter and avoid damage.
- This may result in a re or may
damage the product.
• Always use the AC adapter provided
or any AC adapters approved and
certified by LG Electronics.
- Any other AC adapter
connected may result in the
screen ickering.
ENGLISH
Page 8
8
When in Use
WARNING
• Do not place anything containing
ENGLISH
liquid on top of the projector
such as a vase, flower pot, cup,
cosmetics, medicine, or ornaments,
candles, etc.
- This may result in re or electric
shock, or cause injury due to
falling.
• In the event that there is a heavy
impact or the cabinet is damaged,
switch it off, unplug it from the
power outlet and contact an
authorized service center.
- This may result in electric shock.
• Do not insert pieces of metal such
as coins, hairpins or metal debris,
nor flammable materials such as
paper or matches into the projector.
- This is to prevent electric shock
or re.
• Make sure that a child does not
swallow the batteries when you
replace the old batteries in the
remote control with new ones. Keep
batteries out of reach of children.
- If a child swallows a battery,
consult a doctor immediately.
• Never open any cover on the
projector.
- There is a high risk of electric
shock.
• Do not look directly into the lens
when the projector is in use.
- The bright light may damage
your eyes.
• When the lamp is on or has just
been turned off, avoid touching the
air vent or lamp, because these will
be very hot.
• If there is a gas leak in the room
with the projector, do not touch the
projector or power outlet. Open the
windows for ventilation.
- Sparks may cause re or burns.
• Unplug the power cord from the
outlet during a lightning storm.
- This will prevent shock or
damage to the projector.
• Do not use the projector near
electronic devices that generate a
strong magnetic field.
• Keep the plastic film used for
packaging the projector out of the
reach of children.
- If not handled safely, it can
cause suffocation.
Page 9
9
• Do not keep your hand on the
projector for a long time when it is
running.
• When you play a game by
connecting a game console to a
projector, it is recommended that
you maintain a distance of more
than four times the diagonal length
of the screen.
- Make sure that the connecting
cable is long enough. Otherwise,
the product may fall causing
personal injury or damage to the
product.
• Do not place the projector or its
remote control with batteries in
an extremely high temperature
environment.
- This may result in re.
CAUTION
• Do not place heavy objects on the
projector.
- It may fall down and cause
personal injury.
• Be careful not to allow any impact
to the lens during transport.
• Do not touch the lens of the
projector.
- The lens may be damaged.
• Do not use any sharp tools on
the projector such as a knife or
hammer, because this may damage
the casing.
• In the event that no image appears
on the screen or no sound is heard,
stop using the projector. Switch
off the projector, unplug it from
the power outlet and contact our
service center.
- This may result in re or electric
shock.
• Do not drop anything onto the
projector or allow anything to bang
into the projector.
- This may cause damage to the
projector or personal injury.
• It is recommended that you
maintain a distance of more than
5 to 7 times the diagonal length of
the screen.
- If you watch the screen at a
close distance for a long time,
your eye sight may become
worse.
ENGLISH
Page 10
10
• Do not block the light beam emitted
from the projector using a book or
other object.
- Lengthy exposure to the
ENGLISH
projector beam may result in
re. In addition, the lens may
be overheated and damaged by
the reected heat. Disable the
AV function to stop projection
temporarily or turn off the
power.
• Do not start the projector with the
volume turned up high.
- High volume may damage
hearing.
• Do not use high voltage electrical
equipment near the projector, (e.g.,
a bug zapper). This may result in
product malfunction.
Cleaning
WARNING
• Do not spray the projector with
water when cleaning. Make sure
water does not flow into the
projector.
- This may result in re or electric
shock.
• When there is smoke or a strange
smell coming out from the projector
or a foreign object falls into the
projector, please switch it off and
unplug it from the power outlet and
contact our service center.
- Otherwise, this may result in re
or electric shock.
Page 11
11
CAUTION
• Contact your seller or our service
center once a year to clean the
internal parts of the projector.
- If you do not clean the projector
for a long period of time, dust
will accumulate, which may
result in re or damage to the
projector.
• When cleaning plastic parts such
as the projector case, unplug the
power first and wipe with a soft
cloth. Do not spray with water
or wipe with a wet cloth. Never
use glass cleaner, automobile or
industrial polish, abrasives, wax,
benzene, or alcohol as these can
damage the projector.
- This can result in re, electric
shock or cause damage to
the product (deformation and
corrosion).
• Do not wipe the optical system
(lens, mirror) right after the product
has been turned off or while the
product is being operated. When
cleaning each part of the product,
remove the power cord and wipe
gently with a soft cloth. Do not
spray with water or wipe with a
wet cloth. Do not use detergents,
automobile or industrial polish,
abrasive substances, wax, benzene,
alcohol, water, etc. on the product’s
main unit or optical system (lens,
mirror) as this may damage the
product.
- This can result in re, electric
shock or cause damage to
the product (deformation and
corrosion).
• Remove the plug from the outlet
before cleaning the product.
- Otherwise, this may result in
electric shock.
ENGLISH
Page 12
12
Battery Use
CAUTION
• Do not charge the battery using any
ENGLISH
equipment other than that supplied
with the product. This may damage
the battery or cause a fire.
• Always use a battery that is
approved and certified by LG
Electronics, Inc. Failure to do so may
result in an explosion or fire.
• If the battery is leaking or giving
off an odor, discontinue its use
immediately and contact LG
Electronics Customer Support
Center.
• The battery contains lithium-ion,
so please handle with care. Failure
to do so may result in an explosion
or fire.
Others
WARNING
• When you go out, place the
projector out of reach of animals,
and remove the power plug from
the wall outlet.
- Using a damaged power cord
may result in short circuit or re.
• Do not use the projector near high-
precision electronic devices or those
that transmit weak radio signal.
- This may affect the operation of
the product, causing an accident.
• Only a qualified technician can
disassemble or modify the
projector. For diagnosis, adjustment,
or repair, contact your seller or our
service center.
- This may result in re or electric
shock.
• Proper ventilation required, do not
block airflow around unit. Doing
so can cause injury and internal
overheating.
Page 13
13
• Do not touch the lens; doing so can
result in burns or damage to lens.
Lens and unit may be HOT during
and immediately after use. Use
caution when handling unit, allowing
for proper cool down.
• Only use a grounded electrical
outlet. (Except for devices which
are not grounded.)
• Do not insert anything into or cover
up the exhaust vents.
- This may result in re or electric
shock.
• Follow all maintenance guidelines
for optimal use; service only at an
authorized service center.
• Keep the batteries and remote out
of reach of children.
- This will prevent personal injury
or damage to the product.
CAUTION
• Do not use or store the projector
outdoors for long periods of time.
• Do not mix new batteries with old
ones.
- Burst or leaking batteries may
result in damage or injury.
• Be sure to unplug if the projector is
not to be used for a long period.
- Accumulated dust may result
in re or electric shock due to
overheating, ignition, or poor
insulation.
• Only use the specified type of
battery.
- Burst or leaking batteries may
result in damage or injury.
• Make sure you use the same type
of battery when replacing.
- In the case of a battery contact
failure, the battery may drain
quickly or the remote control
may not work properly.
• Dispose of used batteries properly.
- This may result in explosion
or re. The correct method of
disposal may vary depending
on your country or region.
Dispose of the battery pack as
instructed.
ENGLISH
Page 14
14
• Do not throw or disassemble the
battery.
- This may result in re or
explosion due to damage to the
ENGLISH
battery.
• Store batteries away from metallic
objects, such as keys and paper
clips.
- Excess current may cause a
rapid increase in temperature,
resulting in re or burns.
• Do not store the batteries near any
heat source, such as a heater.
- This may result in re or damage
to the product.
• Do not store batteries at
temperatures higher than 60 °C or
in high humidity.
- This may result in explosion
or re.
• Make sure that the battery is
installed correctly.
- This prevent explosion or re.
• Incorrect battery replacement may
cause fire.
• Batteries: Store the accessories
(battery, etc.) in a safe location out
of the reach of children.
Risk Group 2
CAUTION Possibly hazardous optical radiation
emitted from this product. Do not stare at
operating lamp. May be harmful to the eye.
ANTENNA
WARNING
• If you are using an outdoor antenna,
please install it away from electrical
wires to make sure it does not
touch any nearby wires even when
it falls down due to heavy wind.
- Failure to do so may cause
electric shock or physical injury.
CAUTION
• To prevent any water flowing into
the product, install a drip loop in
the outdoor antenna wire where it
comes indoors.
- Raindrops owing into the
product may cause re or
electric shock.
This label is attached to the bottom of
the product and language may differ.
Page 15
15
Outdoor Antenna Grounding
• If an outdoor antenna is installed,
follow the precautions below. An
outdoor antenna system should
not be located in the vicinity of
overhead power lines or other
electric light or power circuits, or
where it can come in contact with
such power lines or circuits as death
or serious injury can occur. Be sure
the antenna system is grounded to
provide some protection against
voltage surges and built-up static
charges. Section 810 of the
National Electrical Code (NEC) in
the U.S.A. provides information with
respect to proper grounding of the
mast and supporting structure,
grounding of the lead-in wire to
an antenna discharge unit, size of
grounding conductors, location of
antenna discharge unit, connection
to grounding electrodes and
requirements for the grounding
electrode.
Antenna grounding according to
the National Electrical Code, ANSI/
NFPA 70
For USA
NOTE TO CABLE/TV INSTALLER
This reminder is provided to call the
CATV system installer’s attention
to Article 820 - 40 of the National
Electric Code (U.S.A.). The code
provides guidelines for proper
grounding and, in particular, species
that the cable ground shall be
connected to the grounding system of
the building, as close to the point of
the cable entry as practical.
ENGLISH
Ground Clamp
Electric Service
Equipment
Ground Clamp
NEC: National Electrical Code
Antenna Lead in Wire
Antenna Discharge Unit (NEC
Section 810-20)
Grounding Conductor (NEC
Section 810-21)
Power Service Grounding
Electrode System (NEC Art
250, Part H)
Page 16
16
CONTENTS
LICENSES 2
ENGLISH
SAFETY PRECAUTIONS 3
PREPARATION 17
Accessories 17
Optional Extras 18
Parts and Components 19
- Main Unit 19
- Back 20
Using the Buttons 22
- Basic functions 22
- Adjusting the menu 23
Projector Status Indicators 23
Installation 24
- Installation Precautions 24
- Projection Distance per Screen
Size 25
- How to Install the Projector On
a Tripod 26
- Kensington Security System 27
REMOTE CONTROL 28
USING THE PROJECTOR 31
Using The Battery 31
Battery using time information 33
Connecting the Antenna or Cable
34
- Focus of the Screen Image 35
- Watching With the Projector 36
CONNECTING DEVICES 37
HDMI Connection 38
- Connecting to HD Receiver, DVD,
or External Devices 38
- Connecting a PC 39
- Connecting a Laptop 40
Connecting with a USB-C Cable 41
- Computer/Laptop and Phone
Connections 41
Connecting Headphones 42
- Connecting Headphones 42
Connecting a smart device
(smartphone, tablet, etc.) 43
- Slimport supported devices 43
- Apple Lightning Digital AV
adapter supported devices 43
- Apple 30-pin Digital AV adapter
supported devices 43
MAINTENANCE 44
Cleaning 44
- Cleaning the Lens 44
- Cleaning the Projector Case 44
SPECIFICATIONS 45
SYMBOLS 50
Page 17
PREPARATION
The pictures may differ slightly from the actual product.
17
Accessories
Accessories included with the projector are show below.
Accessories are subject to change without prior notice.
New accessories may be added or old ones removed.
Remote Control,
Two AAA Batteries
AC-DC Adaptor Power cord
• When connecting an HDMI or USB cable, or
connecting a USB flash drive to the HDMI or
USB port, use a product that has a width of
18 mm (0.7 inches)
10 mm (0.3 inches) or less. If the USB cable
or USB flash drive does not fit the USB ports
of the projector, use an extension cable that
supports USB 2.0.
• Use a certified cable with the HDMI logo attached.
• If you do not use a certified HDMI cable, the screen may not display or a
connection error may occur. (Recommended HDMI cable types)
- High-Speed HDMI®/™ Cable
- High-Speed HDMI®/™ Cable with Ethernet
or less and a height of
Owner's Manual
ENGLISH
Page 18
18
Optional Extras
To purchase optional accessories, visit an electronics store or online shopping site
or contact the retail store where you purchased the product. Optional accessories
are subject to change without prior notice.
ENGLISH
Projection Screen Tripod HDMI Cable
USB-C Cable RF Cable
1) Some functions of the Magic Remote may not work.
Magic Remote Control
(AN-MR650A)
1)
Page 19
Parts and Components
This projector is manufactured using high-precision technology. You may,
however, see tiny black dots and/or bright colored dots (red, blue, or green)
that continuously appear on the projector screen. This is a normal result of the
manufacturing process and does not indicate a malfunction.
Main Unit
Buttons
Outlet Vent
1)
Speaker
Lens
2)
Speaker
Inlet Vent
Bottom of the Projector
Focus Ring
19
ENGLISH
Adjustable leg
3)
1) Due to the high temperature of vent area, do not get close to the vent area.
2) Do not touch the lens when using the projector. The lens may be damaged.
(Keep lens away from sharp objects.)
3) Turn the adjustable leg left or right to adjust the angle.
Page 20
20
Back
ENGLISH
1
4
5
2
7
8
10
3
No. Description
1
2
3
4
5
Port
Port
(USB 2.0 port)
IR Receiver
/ Switch
- : Turns the projector on and the projector goes into Standby
mode.
- : Turns the projector off completely.
Place the switch to when you move the projector or when you
intend not to use the projector for long periods of time.
6
9
Page 21
No. Description
6
7
(Headphone Port)
8
9
10
(USB-C port)
Battery Charge Indicator
- Red: Charging
- Green: Charging complete
Port
Port
21
ENGLISH
Page 22
22
Using the Buttons
You can operate the projector by pressing the button.
Basic functions
ENGLISH
Power On Press the power button once while the
projector is off.
Power Off
(Press and
Hold)
,
,
Volume Control Adjust the volume by pressing the left/
Channels
Control
Press and hold the Power button
for more than 3 seconds while the
projector is on.
right button.
Change the channel by pressing the up/
down button.
Page 23
Adjusting the menu
Press the power button once while the projector is on.
Press the top, bottom, left, and right buttons to move to a menu item (
, ). After moving to the desired menu item, press the Power button once to
select it.
Turns the power off.
Changes the input source.
Clears on-screen displays and returns to projector viewing.
Displays the Settings menu.
Projector Status Indicators
LED Power Indicator
23
, ,
ENGLISH
Red
Off
LED Power Indicator
Power standby state
The projector is operating with the power on. /
When the projector’s power switch is switched .
Page 24
24
Installation
Installation Precautions
ENGLISH
• Place the projector in a well-
ventilated environment.
- To prevent internal overheating,
install the projector in a wellventilated place. Do not place
anything near the projector.
That may block its air vents. If
the air vents are blocked, the
internal temperature of the
projector will increase.
- Do not place the projector on a
carpet or rug. If the projector’s
inlet vent is on the bottom, be
careful not to block the vent and
always use the projector on a
solid, level surface.
- Be sure to prevent foreign
objects such as paper debris
from entering the projector.
- Leave an adequate open area
(30 cm [11.8 inches] or more)
around the projector.
• Do not place the projector in a hot,
cool, or humid environment.
• Do not place the projector in a place
where it will easily attract dust.
- This may result in re.
• Never open any cover on the
projector. There is a high risk of
electric shock.
• The projector is manufactured using
high-precision technology. You may,
however, see tiny black dots and/
or bright colored dots (red, blue or
green) that continuously appear
on the projector screen. This is a
normal result of the manufacturing
process and does not indicate a
malfunction.
• The remote control may not work
in an environment where a lamp
equipped with electronic ballasts
or a three-wavelength fluorescent
lamp is installed. Replace the lamp
with an international standard lamp
for the remote control to work
normally.
Page 25
25
Y/2 Y/2
Projection Distance per Screen Size
1 Place the projector on a sturdy, level surface, together with the PC or audio/
video source.
2 Place the projector an appropriate distance away from the screen. The distance
between the projector and the screen determines the actual size of the image.
3 Position the projector so that the lens is at a right angle to the screen. If the
projector is not at a right angle, the projected image will look distorted. To
correct the distortion, use the Keystone function.
4 Connect the power cord of the projector and the connected device to the wall
outlet.
Ratio of upward projection: 100 %
Screen Height (X)
X/2 X/2
Screen
Screen Width (Y)
Screen
ENGLISH
Projection Distance (D)
16:9 Aspect Ratio
Screen Size Screen Width (Y) Screen Height (X)
(inches) (mm) (inches) (mm) (inches) (mm) (inches) (mm)
25 635 21.7 553 12.2 311 31.1 791
30 762 26.1 664 14.7 374 37.4 951
40 1016 34.8 886 19.6 498 49.8 1266
50 1270 43.5 1107 24.5 623 62.3 1583
60 1524 52.2 1328 29.4 747 74.8 1900
70 1778 61.0 1550 34.3 872 87.2 2216
80 2032 69.7 1771 39.2 996 99.7 2533
90 2286 78.4 1992 44.1 1121 112.1 2849
100 2540 87.1 2214 49.0 1245 125.0 3177
• The figures in the above table may differ depending on the installation
environment.
Projection Distance (D)
Projection
Distance (D)
Page 26
26
How to Install the Projector On a Tripod
• You can install the projector using a camera tripod.
As shown below, you can mount the projector instead of a camera on the tripod.
• When stabilizing the tripod, we recommend using a locking bolt of standard size
ENGLISH
4.5 mm (0.1 inches) or less. The maximum size allowed for the locking bolt is
5.5 mm (0.2 inches).
(If it is longer than the maximum allowed size, it may damage the projector.)
Bottom side of the
projector
Bolt used to
attach the
projector
+
The projector is
connected to this part.
• If you are using a tripod, be careful not to apply external force to the tripod.
Doing so may damage the projector.
• Do not place the tripod on an unstable surface.
• Be sure to use a tripod with a maximum load capacity of 3 kg (6.6 lbs) or
more.
• To use the projector safely, position the tripod legs so that they are as wide
and stable as possible and be sure to securely attach the projector to the
tripod.
Tripod
Page 27
27
Kensington Security System
• This projector has a Kensington Security Standard connector as an anti-theft
mechanism. Connect a Kensington Security System cable as shown below.
• For more information on installation and use of the Kensington Security System,
refer to the user’s guide provided with the Kensington Security System.
• The Kensington Security System is an optional accessory.
• What is Kensington?
Kensington is a company that provides safety systems for laptops and other
electronic devices. Website: http://www.kensington.com
ENGLISH
Page 28
28
REMOTE CONTROL
Open the battery cover on the back of the
remote control and insert the batteries which
ENGLISH
are specied in the battery room with
poles pointing in the correct direction. The
new and same type of batteries (1.5 V AAA)
must be used.
• Do not mix new batteries with old ones.
(POWER) Turns the Projector on or off.
(INPUT) Changes the input source.
Activates or deactivates the subtitles.
Shows channels guide.
(SEARCH) Search for content such as channels, movies
and other videos, or perform a web search by entering your
search terms in the search box.
Use the external input and switch to watching the TV
screen.
Number buttons Enters numbers.
(Dash) Inserts a dash between numbers such as 2-1
and 2-2.
Accesses the saved channel list.
Displays the channel you were watching previously.
* You can access the application or Live TV
channel by using the number buttons as registered.
Adjusts the volume level.
Shows favorite channels.
Shows information on the current program.
(MUTE) Mutes all sounds.
- Pressing and holding the (MUTE) button displays
the Accessibility menu.
Changes the TV channel.
Moves to the previous/next page.
Page 29
Shows the previous history.
Accesses the Home menu.
- Pressing and holding the button displays the
previous history.
Enables SAP (Secondary Audio Program) Feature.
(Q. Settings) Accesses the Quick Settings.
Up/Down/Left/Right buttons Sets the function or moves
the cursor.
Shows the current mode and saves changes to the
settings.
By zooming in on the selected area, you can view it
in full screen.
Returns to the previous screen.
Clears all on-screen displays and returns to Projector
viewing.
Changes the aspect ratio of the screen per pressing
of the button.
Changes the picture mode.
, , , , Control buttons for media contents
* Provides content related to the program you are
currently watching.
Coloured buttons
These access special functions in some menus.
(
: Red, : Green, : Yellow, : Blue)
29
ENGLISH
* : To use the button, press and hold for more than 3 seconds.
Page 30
30
ENGLISH
• When using the remote control, the optimal
operation range is 6 meters (19.6 feet) or
less (left/right) and within a 30 degree arc of
the remote control IR receiver.
• If a cable is connected to the back port, the
optimal operating range is 3 meters (9.8
feet) or less (left/right) and within a 30
degree arc of the remote control IR receiver.
• For seamless operation, do not block the IR
receiver.
• When you carry the remote control in the
portable bag, make sure that the buttons on the remote control are not
pressed by the projector, cables, documents or any other accessories in the
bag. Otherwise, it may significantly reduce the battery life.
Page 31
USING THE PROJECTOR
31
Using The Battery
• It is displayed when the battery is low (Energy Saving will be changed Maximum
mode and will be disabled).
• If the screen shows a low battery message, be sure to charge the battery.
It is displayed when the battery is low during the USB-C connection.
•
When displayed, USB-C connection will be released.
• Charge the battery when this message is displayed.
ENGLISH
Page 32
32
ENGLISH
• It is displayed when the battery is running out.
• As your battery is running out, the projector will turn off immediately.
• If the battery runs out, the projector can only be turned on after it has been
connected to a power supply.
•
If power is supplied via USB-C, the product can only be turned on again
after the battery has been charged for at least 2 minutes.
Page 33
33
Battery using time information
Status Time and Display
Charging About 3 hours (When in standby and charging)
Up to 2.5 hours
Usage Hours
Battery Level
Indicator
• Check the battery level in the upper right corner of the screen by pressing the
button on the remote control.
• If you do not intend to use the projector for a long time, leave the battery
charged at 40 % to 50 % ( ).
• The battery is automatically recharged when the projector is connected to a
power supply.
• Charge the battery fully when you first use the projector.
• The battery standard usage time given in the manual is based on measurements
taken by LG; the actual time may vary depending upon usage.
• Battery usage time may vary depending on broadcast type, operating
temperature, period of use, and user preferences.
• As the battery is consumable, its lifetime gradually decreases. When the
battery’s life is reduced by half, replace it with a new battery from an LG
Electronics Customer Support Center.
(Available battery using time up to 2.5 hours when Energy
Saving mode set to Max.)
Step 1 Step 2 Step 3 Step 4 Step 5 Full
ENGLISH
Page 34
34
Connecting the Antenna or Cable
To watch TV using an indoor/outdoor
antenna, connect a wall terminal and the
antenna port of the projector using an RF
ENGLISH
cable (75Ω).
You can watch terrestrial or cable
(analog, digital) TV. (The RF cable is sold
separately.)
• Make sure not to bend the copper wire of the
RF cable (75 Ω). Turn the input jack to the right
to fasten it.
• Ensure you use a standard coaxial cable (75
Ω, sold separately) when connecting to the
projector input.
• For better image quality in locations where signal
strength is low, purchase and install a signal
amplifier (booster).
• A signal splitter is required if you want to use two or more projectors
through one antenna.
• If you have any problems when installing the antenna, please consult a
suitable retailer or the store where you purchased the antenna.
Copper wire
Page 35
Focus of the Screen Image
When an image appears on the screen, check if it is in focus and ts the screen
properly.
Focus Ring
• Picture Focus Test
To focus the image, use the Focus Test function to slowly adjust the focus ring
to the left or right while viewing the mark on the screen. Optimal focus is
reached when the left and right sides of the screen appear balanced. Make sure
the product does not move when adjusting the focus.
35
ENGLISH
Page 36
36
Watching With the Projector
1 Connect the power cord correctly.
2 Place the / switch on the rear port area to and press the
ENGLISH
(POWER) button on the projector or on the remote control. (If the switch is
placed to , the projector will not turn on.)
3 In the Language Selection screen, select a language.
4 In the Home/Store Mode screen, select the setting mode you want.
(Store Mode is used when displaying the product in-store. The picture mode is
automatically reset after a certain period of time. You can select Home Mode
to use the product at home.)
5 Select the (INPUT) All Inputs and select the input signal you want.
6 Control the projector using the following buttons while watching projector.
Button Description
Changes the TV channel.
Adjusts the volume level.
(MUTE)
Mutes the sound from the projector.
7 To turn the projector off, press the (POWER) button.
Page 37
CONNECTING DEVICES
You can connect various external devices to the projector.
37
ENGLISH
Computer/Notebook
Digital Device
Headphone
DVD USB
Games Console
HDMI - Page 38, 39, 40
USB-C - Page 41
Headphone - Page 42
Smart device - Page 43
USB-C
Mobile Phone
Page 38
38
HDMI Connection
Connect an HD receiver, DVD, or
external devices to the projector and
select an appropriate input mode.
ENGLISH
You can connect with any HDMI input
port.
•
(INPUT) All Inputs
HDMI1/HDMI2
Connecting to HD Receiver, DVD, or External Devices
With an HDMI cable, you can enjoy
high quality picture and sound.
Using a HDMI cable, connect the
port of the projector to the
HDMI output port of the device to
connect. Both video and audio are
output at the same time.
ARC (Audio Return Channel)
• External audio devices that
support SIMPLINK and ARC
must be connected using
port.
• When connected with a high-
speed HDMI
audio devices that support ARC
output or SPDIF work with the
SIMPLINK function without the
need for an additional optical
audio cable.
®
cable, external
Optional Extras
Page 39
Connecting a PC
The projector supports Plug and Play.
Your PC will automatically detect
the projector and requires no driver
installation.
Using an HDMI cable, connect the
port of the projector to the
HDMI output port of your PC. Both
video and audio are output at the
same time.
Optional Extras
39
ENGLISH
Page 40
40
Connecting a Laptop
You can connect the projector to a
laptop to use various functions.
ENGLISH
Using an HDMI cable, connect the
port of the projector to the
HDMI output port of your laptop. Both
video and audio are output at the
same time.
Optional Extras
Examples of switching output
settings when connecting a laptop
The table below shows examples
of switching the output. For more
information, refer to the External
Output, Connecting to an External
Monitor, or similar sections of the
owner’s manual of your computer.
Brand Switching Output
NEC [Fn]+[F3]
Panasonic [Fn]+[F3]
Toshiba [Fn]+[F5]
IBM [Fn]+[F7]
Sony [Fn]+[F7]
Fujitsu
LG [Fn]+[F7]
Samsung [Fn]+[F4]
Macintosh
[Fn]+[F10]
Adjust the control
panel to enable
mirroring after
start-up.
Page 41
Connecting with a USB-C Cable
Computer/Laptop and Phone Connections
• (INPUT) All Inputs
USB-C
Use a USB-C cable to connect to
the projector’s USB-C port and the
USB-C output port on your PC/laptop
or phone. To nd out whether your
device is USB-C-certied, please
contact your device manufacturer.
Both video and audio are output at
the same time.
Optional Extras
• PD (Power Delivery) and DP
Alternate Mode are supported.
- A USB-C gender changer
may be necessary depending
on the cable used if using
PD (Power Delivery).
• The function may not
operate properly depending
on the connected device’s
specifications, USB-C cable
status, or surroundings.
• PD functions may charge/
discharge the projector or
not operate depending on the
specifications of the connected
devices.
• The charging feature may
function differently with some
devices (MacBook Pros, etc.)
when connected.
• Check the resolution of the
connected devices before
using the DP Alternate Mode
function.
41
ENGLISH
PC/laptop/phone
Page 42
42
Connecting Headphones
Connecting Headphones
You can listen to the audio through a
ENGLISH
headphone.
Not provided
Page 43
43
Connecting a smart device (smartphone, tablet, etc.)
• (INPUT) All Inputs HDMI1/HDMI2
• The picture may look different from the actual product.
Connect a smart device to the projector using a cable
of the projector to HDMI. The smart device screen will then be displayed through
the projector. You can connect with any HDMI input port.
For model-specic instructions regarding use of the wired connection, please check
with the smart device manufacturer.
Supported smart devices may change depending on the circumstances of each
manufacturer.
1) Examples of how to connect a cable to different smart devices (cable purchased
separately).
Slimport supported devices
HDMI cable
Projector HDMI port
Projector USB port
Apple Lightning Digital AV adapter supported devices
HDMI cable
1)
and set the external input
Slimport adapter
Lightning Digital AV
adapter
Charging port of a
smart device
Charging
cable of
a smart
device
Charger
ENGLISH
Projector HDMI port
Charging port of a
smart device
Apple 30-pin Digital AV adapter supported devices
HDMI cable
Projector HDMI port
Apple 30-pin
Digital AV
adapter
Charging port of
a smart device
Page 44
44
MAINTENANCE
Clean your Projector to keep it in optimal condition.
ENGLISH
Cleaning
Cleaning the Lens
• If there is any dust or staining on the lens surface, you must clean the lens.
• To remove dust or stains on the lens, use a compressed air duster, cotton swab,
or soft cloth to gently wipe the lens.
• Do not wipe the lens while the product is in use or immediately after it has been
turned off.
• When cleaning the lens, do not use a cleanser, automobile or industrial shiner,
abrasive, wax, benzene, alcohol, water, etc., as this may damage the product.
Cleaning the Projector Case
• To clean the projector case, first unplug the power cord.
• To remove dust or stains, use only a dry, lint-free, nonabrasive cloth to polish
the lens.
• Do not use alcohol, benzene, thinners, or other chemicals, which may damage
the case.
Page 45
SPECIFICATIONS
MODEL PF50KA (PF50KA-NA)
Resolution (Pixel) 1920 (Horizontal) × 1080 (Vertical)
Aspect ratio 16:9 (Horizontal:Vertical)
Projection distance
(Screen size)
Ratio of upward
projection
Working range of
the remote control
Power consumption 65 W
AC-DC Adaptor
Audio Output 1 W + 1 W
Television System ATSC / NTSC-M / 64 & 256 QAM
Program Coverage
External Antenna
Impedance
Height
Width 170.0 mm (6.6 inches)
Depth
Weight 910 g (2.0 lbs)
USB Device
791 mm ~ 3177 mm (31.1 inches ~ 125.0 inches)
(635 mm ~ 2540 mm [25 inches ~ 100 inches])
100 %
6 m (19.6 feet) (Max.)
Manufacturer: APD
Model: DA-65G19
19 V 3.42 A
(Adaptor Input 100-240 V @ 50/60 Hz)
VHF 02 to 13, UHF 14 to 69, CATV 01 to 135,
DTV 02 to 69, CADTV 01 to 135
75 Ω
49 mm (1.9 inches) (without foot),
52.3 mm (2.0 inches) (with foot)
170.0 mm (6.6 inches) (without lens),
178.0 mm (7.0 inches) (with lens)
USB 2.0
Standard-A
USB Type-C
Output: 5 V, 0.5 A (Max.)
Output: 5 V, 1 A (Max.)
Input: 5 V/2 A, 9 V/2 A, 15 V/2 A,
20 V/2 A (Max.)
45
1)
ENGLISH
1) Full HD resolution with 2.1 million discrete pixels projected by XPR (Expanded
Pixel Resolution) video processing.
Page 46
46
MODEL PF50KA (PF50KA-NA)
Temperature
Operation 0 °C to 40 °C (32 °F to 104 °F)
ENGLISH
Environment
Condition
• Use only power supplies listed in the user instructions.
Contents in this manual may be changed without prior notice due to upgrade of
•
product functions.
Storage -20 °C to 60 °C (-4 °F to 140 °F)
Relative Humidity
Operation 0 % to 80 %
Storage 0 % to 85 %
Page 47
HDMI (DTV) / USB-C (DTV) Supported Mode
Resolution
640 x 480p
720 x 480p
1280 x 720p
1920 x 1080i
1920 x 1080p
Horizontal Frequency
(kHz)
31.46 59.94
31.50 60.00
31.47 59.94
31.50 60.00
44.96 59.94
45.00 60.00
33.72 59.94
33.75 60.00
26.97 23.97
27.00 24.00
33.71 29.97
33.75 30.00
67.43 59.94
67.50 60.00
47
Vertical Frequency
(Hz)
ENGLISH
Page 48
48
HDMI (PC) / USB-C (PC) Supported mode
Resolution
ENGLISH
640 x 350 31.46 70.09
720 x 400 31.46 70.08
640 x 480 31.46 59.94
800 x 600 37.87 60.31
1024 x 768 48.36 60.00
1152 x 864 54.34 60.05
1280 x 1024 63.98 60.02
1360 x 768 47.71 60.01
1920 x 1080 67.5 60.00
• If an invalid signal is input into the projector, it will not be displayed properly on
the screen or a message such as No Signal or Invalid Format will be displayed.
• The projector supports the DDC1/2B type as the Plug and Play function (Auto-
recognition of PC monitor).
• 1920 x 1080 is recommended as the best picture quality in the PC mode.
Horizontal Frequency
(kHz)
Vertical Frequency
(Hz)
Page 49
49
Open Source Software Notice Information
To obtain the source code under GPL, LGPL, MPL, and other open source licenses,
that is contained in this product, please visit http://opensource.lge.com.
In addition to the source code, all referred license terms, warranty disclaimers and
copyright notices are available for download.
LG Electronics will also provide open source code to you on CD-ROM for a charge
covering the cost of performing such distribution (such as the cost of media,
shipping, and handling) upon email request to opensource@lge.com.
This offer is valid for a period of three years after our last shipment of this product.
This offer is valid to anyone in receipt of this information.
ENGLISH
Page 50
50
SYMBOLS
ENGLISH
Refers to alternating current (AC).
Refers to direct current (DC).
Refers to class II equipment.
Refers to stand-by.
Refers to “ON” (power).
Refers to dangerous voltage.
Page 51
Page 52
ABOUT LG
webOS 3.5
PROJECTOR
Image shown may differ from your projector.
Your projector’s OSD (On Screen Display) may differ slightly from that shown in this
manual.
Green: The buttons and the text to be displayed on the projector screen.
Copyright © 2018 LG Electronics Inc. All Rights Reserved.
Page 53
2
CONTENTS
ABOUT LG webOS PROJECTOR
ENGLISH
4
Home Tutorial 4
- Using the Home feature of the
LG WebOS Projector 4
Prepare Live TV 8
- Watching TV broadcasting 8
Network Setting 9
- Network Setting 9
HOW TO OPERATE
PROJECTOR 11
Using the Screen Remote 11
Setting Universal Control 13
SIMPLINK (HDMI-CEC) 14
- Using SIMPLINK 14
Using the LG TV Plus App 16
Magic Mobile Connection 18
- Using Magic Mobile Connection
18
Using a Keyboard and Mouse 19
- Using a USB Wired/Wireless
Mouse 19
- Using a USB Wired/Wireless
Keyboard 19
Using a Gamepad 20
ENJOY LIVE TV 21
Live Menu 21
- Using Live Menu 21
My Channels 23
- Using My Channels 23
Guide 24
- Viewing Guide 24
Checking Program Info 26
- Viewing Program Information 26
Using MAGIC LINK 28
Using Advanced Broadcast
Settings 29
HOW TO USE VARIETY OF
CONTENTS 30
LG Content Store 30
Creating Wish List 31
- Using My Content 31
Account Creating 32
- Creating LG Account 32
Account Management 33
- Managing your LG Account 33
Search Content 34
- Search 34
- Searching for Content 34
Use App & Contents 35
- Installing Apps 35
Watching VOD Content 36
Page 54
3
PLAY OTHER DEVICE FILES 37
Photo & Video 37
- Viewing Photos and Videos 37
- Photo Player 38
- Video Player 40
- Supported Video Files 42
- Cautions for Video Playback 44
Music 45
- Playing Music 45
- Using the Music Player 46
File Viewer 49
- Viewing Files 49
- Browsing File Viewer 50
Connecting USB 52
- Tips for Using a USB storage
device 53
Share Smart Phone 54
- Content Share with Smartphone
54
View Smart Phone 56
- To see the Mobile Device's
screen on the projector 56
Share PC 57
- What Is Content Share? 57
View PC 60
- To see the PC screen on the
projector 60
BENEFITS OF SMART
PROJECTOR 61
Zooming in the Projector Display 61
Zoom Recording 63
- Running Zoom Recording 63
Using My Starter 65
Enjoying Internet 67
- Using the Web Browser 67
Notifications 70
- Using Notifications 70
TOUR LIST OF SETTINGS 71
Quick Settings 71
- To use Setting function quickly
71
Picture Settings 72
Sound Settings 80
Channels Settings 87
Network 91
General 93
Safety Settings 101
Accessibility 104
To Update Software 106
TROUBLESHOOTING 107
Abnormal Operation 107
Screen Problems 108
Sound Problems 110
PC Connection Problems 112
Photo & Video Movie Playback
Problems 113
Network Connection Problems 115
LG Account Problems 117
Contents Problems 118
Internet Browser Problems 118
ENGLISH
Page 55
4
ABOUT LG webOS PROJECTOR
Home Tutorial
ENGLISH
Using the Home feature of the LG WebOS Projector
You can open the Home screen by pressing the button on your remote
control. You can combine frequently used apps on a single screen and use
whichever you want at any time.
3
1
2
4 5
Description
You can use your projector’s other features while listening to
music.
• This feature is available on certain models only.
1
2
3
You can switch to another input or change your settings.
You can easily change the settings of your projector.
Select for advanced setup.
Displays the remaining battery life.
• This feature is available on certain models only.
Add content you like to use, easily and quickly. (This feature is not
supported in some countries. When you select the feature, you will be
directed to the LG Content Store.)
6
Page 56
Description
By adding channels you like, you can check channel information and
4
watch your desired channel easily and quickly.
This is a list of recently used apps. To access the list of recently used
apps, select this item and then press and hold the Wheel (OK) or
5
OK button. You can view all the apps you used recently in the list.
You can run, move, and delete all the apps installed on your projector.
6
Using Recent List
To access the list of recently used apps, press and hold the
remote control, or press and hold a recently used item on the Home screen. You
can run or exit all the apps you’ve used recently.
•
The On Screen Display (OSD) of the projector may differ depending on
the model.
button on your
1
5
ENGLISH
1
Description
Exit the app.
Page 57
6
Managing Apps
You can view a list of all apps installed on your projector, change their positions, or
delete them.
• Some apps cannot be edited.
ENGLISH
1 Select the app you want to edit, and press and hold the Wheel (OK) or
OK button on the Remote Control. This will activate the app edit mode.
2 To move the app to your desired position, go to the position and press the
Wheel (OK) or OK button. To delete an app, select the above the app.
• You can move and delete as many apps as you wish before exiting the edit
mode.
• You can also move apps with the
buttons on your remote control.
3 When you have completed the edit, click DONE to exit the app edit mode.
Page 58
7
Stopping the current function
•
The On Screen Display (OSD) of the projector may differ depending on
the model.
1 Press the button on the remote control.
2 Select the application name at the top left corner of the screen by the Remote
Control to display the Close icon.
3 Select the Close icon displayed next to the application name to quit the
function in use.
ENGLISH
Page 59
8
Prepare Live TV
Watching TV broadcasting
ENGLISH
1 Connect the broadcast antenna/cable to the projector. You may also connect
a piece of equipment that can receive broadcasting such as a set-top box
instead of the antenna/cable. Press the button on the remote control. To
see the details, select Set-Top Box from the device list that is displayed when
operating the Device Connector.
2 Start the (Q. Settings) Channels Channel Tuning Auto
Tuning. Finds and adds only channels being broadcast.
Page 60
Network Setting
Network Setting
If you congure settings for the network, you can use various services such as
online contents and applications.
Setting a Wired Network
1 Connect the LAN port of the projector and the router using a LAN cable. The
router should be connected to the Internet beforehand.
2 Press the (Q. Settings) button on the remote control and select
Network Wired Connection (Ethernet). This will start the wired network
connection.
• If the router supports DHCP, the projector is automatically connected to the
network when you connect the projector to the network with a LAN cable.
Setting a Wireless Network
1 Turn on the power of the router connected to the Internet.
2 Press the (Q. Settings) button on the remote control and select
Network Wi-Fi Connection. This will start the Wireless network
connection.
3 When the network search is complete, the list of networks available for
connection is shown.
4 Select a network to connect. If your Wireless Router is password protected,
enter the password congured for the router.
9
ENGLISH
Page 61
10
Network Setting Warnings
• Use standard LAN cable (connect to Cat7 or higher with RJ45 connector, 10
Base-T, or 100 Base TX LAN port).
• Resetting the modem may fix some network connection problems. Turn the
ENGLISH
power OFF, disconnect and reconnect it, and then turn the power on to solve
the problem.
• LG Electronics is not responsible for any network connection problems or any
faults, malfunctions, or errors caused by network connection.
• The network connection may not work properly because of network settings or
the Internet service provider.
• DSL service must use a DSL modem; and cable service must use a cable modem.
Since only a limited number of network connections may be available, projector
network setting may not be used depending on the contract with Internet
service provider. (If the contract does not allow more than one device per line,
only the already-connected PC may be used.)
• A wireless network can experience interference from other devices that use
the 2.4 GHz frequency (wireless phone, Bluetooth device, or microwave oven).
Although interference can also happen when using the 5 GHz frequency, it is
less likely to occur.
• The wireless environment can make wireless network service run slowly.
• Failure to turn off all local home networks may cause excessive traffic on some
devices.
• The access point device must support wireless connections and wireless
connection feature must be enabled on the device to have AP (access point)
connection. Contact the service provider for availability of wireless connections
on the access point.
• Check SSID and security settings of the AP. Refer to the appropriate
documentation for SSID and security settings of the AP.
• Invalid settings of network devices (wired/wireless line sharer, hub) can cause
the projector to operate slowly or not operate properly. Install the devices
correctly according to the appropriate manual and network.
• The connection method may differ depending on the AP manufacturer.
Page 62
HOW TO OPERATE PROJECTOR
11
Using the Screen Remote
You can control external devices connected to your projector by using the Screen
Remote displayed on your projector screen.
• This feature is available on certain models only.
1 Press the button on the Magic Remote.
2 Using the Magic Remote, select your desired button on the Screen Remote
displayed on your projector screen.
6
1
3
2
4 5
ENGLISH
Page 63
12
Description
Congure Set Up Universal Control for external devices connected to
your projector.
ENGLISH
When you select a device, the Screen Remote turns into the remote
1
control for the device.
If a sound bar is connected, the Screen Remote can be used as a
remote control for the sound bar.
The buttons suitable for the selected device appear.
2
You can capture your projector screen.
• This feature is available on certain models only.
3
• You can view/delete screen-captured images in the Photo & Video
app.
You will see more remote control buttons.
4
You can start the Device Connector app. You can set the universal
5
remote control.
You can change the position of the screen remote control.
6
• This feature can only be used with the Magic Remote.
• You can purchase the Magic Remote separately if it is not provided.
• The types of buttons appearing on the Screen Remote vary, depending on the
region and the type of connected device.
• Some features and services may not be provided depending on models or
regions.
Page 64
13
Setting Universal Control
You can control devices such as Set-Top Box, Blu-ray Player, or Home Theater
using by Magic Remote or Slim Remote.
• This feature is available on certain models only.
1 Check that the device you want to set is connected to your projector.
2 Press the button on the remote control and select at the top right.
(Press the button on the remote control.)
3 Select All Inputs and go to Input Hub.
4 Select the input mode that the device is connected to in Input Hub.
5 If you press Set Up Universal Control, you can set up the Universal Control.
Follow the instructions on the screen to nish the setup.
• If you want to change or cancel Universal Control Settings, go to
Inputs and select Edit Universal Control.
• You can also set the Universal Control in
• You can use this only with the Magic Remote or Slim Remote. (The provided
remote control differ depending upon model.)
• You can purchase the Magic Remote separately if it is not provided.
• This feature is available in certain countries only.
• When changing the settings, check that the device to be changed is turned on.
• You can set one device per type.
• If you connect to a network before setting the Universal Control, the latest
update for the supported manufacturer list becomes available.
• Some buttons may not work depending upon the model of the external device.
• Place the device near the projector for seamless operation.
• If there is an obstacle in front of the device, it may not be able to receive the
signal properly. If the device is in a drawer, open the drawer.
Device Connector.
All
ENGLISH
Page 65
14
SIMPLINK (HDMI-CEC)
Using SIMPLINK
You can conveniently control and use various multimedia devices connected
ENGLISH
through HDMI with the projector’s remote control.
1 Connect the SIMPLINK HDMI Output port to the projector’s HDMI IN port with
an HDMI cable.
2 Press the (Q. Settings) button on the remote control and select
General SIMPLINK (HDMI-CEC).
3 Set SIMPLINK (HDMI-CEC) to On.
4 Congure the Auto Power Sync settings to On or Off. (If Auto Power Sync
is set to On, turning on a SIMPLINK-linked device will turn the projector on.
When you turn off the projector, the device will also be turned off.)
5 Turn on the connected device. When the projector automatically connects to
the device, the input will switch. If the device is not automatically connected to
the projector, click the (INPUT) button.
• This feature works only with devices with the
SIMPLINK logo on the external device. There may be a problem using the device
if the device does not meet the required specifications.
• A high-speed HDMI
is required to use SIMPLINK. Pin 13 of the high-speed HDMI® cable is used for
data transfer between devices.
• If you want to output sound to the external audio equipment connected through
the HDMI cable, set SIMPLINK (HDMI-CEC) to On.
®
cable with CEC (Consumer Electronics Control) function
logo. Check for the
Page 66
Supported SIMPLINK Functions
• Instant Play
When you start a multimedia device, you can immediately watch content from
the device on the projector without having to control anything.
• Controlling devices with the projector remote control
Enables the user to control multimedia devices with the projector remote
control to watch content.
- The pointer function of the Magic Remote can be limited.
• Main Power Off
If Auto Power Sync is set to On in the SIMPLINK (HDMI-CEC) settings and
the projector is turned off, the devices connected to your projector via SIMPLINK
will also be turned off. Likewise, your projector will be turned off if you turn off a
device connected to your projector via SIMPLINK.
- This feature is only available in certain devices.
• Main Power On
If Auto Power Sync is set to On in the SIMPLINK (HDMI-CEC) settings,
turning on a SIMPLINK-linked device will turn the projector on.
- If SIMPLINK (HDMI-CEC) is set to Off, Auto Power Sync can not be set
to On.
15
ENGLISH
Page 67
16
Using the LG TV Plus App
You can control the functions of your projector by using the app installed on your
smart device.
• You can watch TV shows, movies, and recommended content. Also, you can
ENGLISH
make a wishlist. (This feature is available in certain countries only.)
• You can search for any content you want. (This feature is available in certain
countries only.)
• The text input function is supported, so you can enter text easily. (Text cannot
be entered on some screens.)
Select the app’s touch pad to control the projector in the same way as you do
•
with the Magic Remote pointer or a mouse pointer.
1 Download LG TV Plus app from the Apple App Store or the Google Play Store,
depending on the OS of each smart device.
2 Press the (Q. Settings) button on the remote control and select
Network.
3 Set LG Connect Apps to On.
4 Connect the projector and your smart device on the same Wi-Fi network.
5 Launch the LG TV Plus app on your smart device.
6 Tap the Start button to scan for projectors that can be connected to your
smart device.
7 Select the projector you want from the list of search results. A PIN code
appears on the projector screen.
8 Enter the PIN code in the LG TV Plus app to pair your smart device with the
projector.
9 You can tap the buttons on your smart device’s screen to control the projector.
Page 68
17
1 2 3
Description
You can use various apps installed on your projector.
1
You can control the TV channels, volume, etc. remotely.
2
Functions the same as the Magic Remote pointer or a mouse
3
pointer.
•
Some controls may be limited in external input mode.
• The app’s screen and functionality are subject to change without prior notice.
• The functions require a network connection.
• Available features may differ depending on your country and OS.
ENGLISH
Page 69
18
Magic Mobile Connection
Using Magic Mobile Connection
Magic Mobile Connection lets you share and enjoy the content stored on people’s
ENGLISH
smart devices through your projector.
• It is recommended that your Android smart devices run Lollipop or later versions
of Android.
Connecting a Smart Device with Magic Mobile Connection
Set up a connection following the guide below:
1 Install the LG TV Plus app on the smart device.
2 Connect both your projector and the smart device to the same network.
3 Run the LG TV Plus app and set up a connection to your projector following
the instructions shown on the screen.
4 Press the button, and a list of connected smart devices will appear on the
right side of the screen.
5 Select your desired smart device.
• Android smart devices will automatically attempt to reconnect when they enter
the network zone after the initial connection has been established.
Sharing Content with Magic Mobile Connection
You can share and enjoy the content stored on your smart device through your TV.
1 Run the LG TV Plus app installed on your smart device.
2 Set up your desired content on your projector.
• Some features may not be available depending on whether or not you have
logged in as a member in the LG TV Plus app.
• Supported features may vary depending on the country.
• Supported features may vary depending on the version of your smart device’s
operating system.
Page 70
19
Using a Keyboard and Mouse
Using a USB Wired/Wireless Mouse
Connect your mouse to the USB port. Use the mouse to move the pointer on the
projector screen and select the menu you want.
• The right button and the special buttons on the mouse do not work.
• When using a wireless USB mouse/keyboard, the experience may be affected by
the distance and wireless condition.
Using a USB Wired/Wireless Keyboard
Connect your keyboard to the USB port. You can enter text with the connected
keyboard device.
• It is not possible to enter text on some screens.
• It is recommended that you use a product that has been tested for compatibility
with LG projectors.
- LOGITECH K360, LOGITECH K400, LOGITECH K750, LG Electronics MKS-
1200
• You can change the input language by pressing the language switch key or the
right Alt key. It can also be changed by pressing the Ctrl key and the Space key
at same time.
• Wireless USB keyboard use may be affected by the usage range and the wireless
environment.
• To enter text in the text field, use the on-screen keyboard on your projector
screen or a USB keyboard.
ENGLISH
Page 71
20
Using a Gamepad
Connect your gamepad to the USB port on the projector if the game requires a
gamepad.
• It is recommended that you use a gamepad that has been tested for
ENGLISH
compatibility with LG projectors.
- LOGITECH F310, LOGITECH F510, LOGITECH F710, LOGITECH Rumblepad
2, LOGITECH Cordless Rumblepad 2, LOGITECH Dual Action Gamepad,
MICROSOFT Xbox 360 Controller (cable), SONY Playstation(R)3 Controller
Page 72
ENJOY LIVE TV
21
Live Menu
Using Live Menu
You can use the relevant features with ease when watching TV broadcasts.
1 Run Live TV by pressing .
2 Press button (on the right) on the remote control or move the
Magic Remote pointer to the right side of the projector screen.
1
2
Description
View a list of broadcast content that is currently being broadcast.
1
Get channel and program recommendations based on your viewing
2
history.
ENGLISH
Page 73
22
• The channels displayed in Channel List are a configuration of channels provided
by the broadcast service provider. Therefore, if the broadcast service provider
has changed its channel configuration without notice, the channels displayed in
Channel List may differ from the actual TV channels.
• Because channel information displayed in Channel List includes information
ENGLISH
provided by external Electronic Program Guide (EPG) providers, it may differ
from the actual TV channels.
• You must have a network connection with Internet access to use the Program
Recommendation feature in Recommended List.
• To receive proper recommendation services, you need to set up your network,
region and auto tuning.
• Options may vary depending on the country.
Page 74
23
My Channels
Using My Channels
If you add channels to My Channels, you can check and watch the programs being
broadcast in the added channels of any app.
Adding a Channel
1 Press the button on your remote control.
2 Select My Channels at the bottom left of the screen.
3 Selecting Add Channel displays a list of channels.
Select the channel you want to add from the channel list.
- You can continue to add other channels to My Channels in the same way.
• To add set-top box channels, you need to set Setup universal control in Device
Connector and use a Magic Remote. (This feature is available on certain models
only.)
• To switch to a set-top box channel, you need to select among the added
channels using your Magic Remote. (This feature is available on certain models
only.)
• If you select a channel already added in My Channels, you can access the
channel in other apps as well.
• You can move/delete added channels in the same way as when you manage
apps.
ENGLISH
Page 75
24
Guide
Viewing Guide
You can view programs and the schedule of each program.
ENGLISH
1 Press the button on the remote control.
2 You can launch the Guide application.
1
4 5 6 7
2
3
8
Description
You can view information about the program you are currently
1
watching as well as the focused program information.
Displays the information of the broadcasting company.
2
Navigate to a desired program and press the Wheel (OK) or
3
You can view more information on the program and perform
WATCH or REMINDER, etc.
Sets the lter.
4
Launch CHANNEL MANAGER.
5
OK.
Page 76
Description
Launch TV Scheduler.
6
Launch SEARCH.
7
Press the remote control’s button to navigate to the Guide
8
screen for the current date and time.
Viewing Set-Top Box Guide
After connecting the Set-Top Box, you can view programs and the schedule of the
Set-Top Box and use the Magic Remote.
• This function is available on certain models or in certain countries only.
25
ENGLISH
Page 77
26
Checking Program Info
Viewing Program Information
Information about the program you are currently watching, the current time, etc.
ENGLISH
are displayed.
The On Screen Display (OSD) of the projector may differ depending on the
•
model.
1 While watching a live broadcast press the Wheel (OK) or OK button.
The Channel Banner appears.
Page 78
27
2 Select the Channel Banner. You can view detailed information about the
program you are currently watching.
Using the / / / buttons on your remote control, you can view information
about upcoming programs or other channels without changing the channel.
• You can view broadcast information about other channels using the
buttons.
• You can view broadcast information about the channel you are currently
watching using the
/ buttons.
/
ENGLISH
Page 79
28
Using MAGIC LINK
It offers various videos and information related to the program you are currently
watching.
If you are watching a program via a set-top box, you should complete the universal
ENGLISH
remote control settings to use the MAGIC LINK function properly.
1 Press the remote control’s Wheel (OK) or OK button or move the
pointer to the top of the screen. The Channel Banner appears.
2 Press the MAGIC LINK button in the Channel Banner.
3 Various kinds of information related to the program you are watching will
appear at the bottom of the screen. Select the desired information.
• The search range may vary depending on the country.
• While MAGIC LINK is in use, the content provided may not always match the
program that you are watching at the time. Change the channel with the Magic
Remote before using MAGIC LINK.
• Some adult-only channels or locked channels do not support this function.
• The search results may vary depending on the information on the program you
are watching.
• The MAGIC LINK feature via set-top box is supported in some countries or
models only.
• Some set-top boxes may not support the MAGIC LINK function.
• Only set-top boxes connected via HDMI input are supported.
Page 80
29
Using Advanced Broadcast Settings
If the broadcast you are watching contains Closed Caption, AUDIO LANGUAGE,
or Multi Audio information, you can use such features.
1 Press the Wheel (OK) or OK button on your remote control.
2 Select your desired feature in the top of the screen and set the feature to your
desired value.
1 2 3
Description
You can set Closed Caption.
1
You can set AUDIO LANGUAGE.
2
• Only available with digital broadcasts.
You can set Multi Audio.
3
• Only available with analog broadcasts.
• Available features may vary depending on the broadcast signal.
ENGLISH
Page 81
30
HOW TO USE VARIETY OF CONTENTS
LG Content Store
ENGLISH
You can quickly and conveniently browse for TV Shows, Movies, and more to
watch immediately.
You can also download and use apps from various categories such as education,
entertainment, lifestyle, news, and games.
1 Press the button on the remote control.
2 Launch the LG Content Store application.
• This feature is available in certain countries only.
• Features may be limited in certain countries.
• Content may differ depending upon the model or country.
• Exercise caution when in used by children. Children may have access to
inappropriate online content through this product.
• You can block inappropriate online content by restricting access to some apps
such as the Internet browser. Restrictions can be set in
Safety Application Locks.
Recommended Content on the Main Screen
The main screen of the LG Content Store shows the most popular content for
each category. Select any content to view its details.
• Internet connection is required to use this feature.
(Q. Settings)
Page 82
31
Creating Wish List
Using My Content
By adding your desired content to My Content, you can use the content easily and
quickly anytime.
1 Press the button on your remote control.
2 Select My Content in the top left of the screen.
3 Select Add Content.
4 Search for content.
5 Select your desired content from the search results to add it to My Content.
• You can also select from among recommended content shown under the
search box and directly add it to My Content.
• This feature is only available in certain countries.
• The type of content you can add to My Content may vary depending on the
country.
• You must have a network connection to use this feature.
• You can move/delete added content in the same way you manage apps.
• Some of the content services added to My Content may not be available if the
service has been terminated due to the provider’s circumstances.
ENGLISH
Page 83
32
Account Creating
Creating LG Account
In Account Management, you can use your email address to create a new LG
ENGLISH
account.
1 Press the (Q. Settings) button on the remote control and select
General Account Management.
2 Select CREATE ACCOUNT. Read and accept the Terms of Service.
3 Enter an ID and a password. Your ID must be your email address.
4 Enter your birthday.
5 Select OK. Go to your email to verify your email address. Please verify your
email before the time expires.
6 Log in with your new account to start using the service.
• Internet connection is required to create an account.
• Required information may vary depending upon the country.
• Existing IDs that do not use an email address can be converted to your email
address.
• You can log in with your Facebook or Google account. (Features other than login
may not be available.)
• You may be restricted from the service depending upon your age.
Page 84
Account Management
Managing your LG Account
You can manage the information of your LG account.
1 Press the (Q. Settings) button on the remote control.
2 Go to General Account Management to log in.
Personal Information
You can view or edit your information of the account currently logged in.
You can change the password or press EDIT to edit your personal information.
This feature is available in certain countries only.
33
ENGLISH
Page 85
34
Search Content
Search
Search allows you to nd and use a variety of content and information. You can
ENGLISH
search for les, including image, video, audio, and recording les.
Searching for Content
1 Run Search by pressing the (SEARCH) button on your remote control.
2 Search for a variety of content and information by typing in your desired
search terms.
2 1
Description
Enter your desired search term.
1
Change the settings of the features provided by Search.
• Some apps provide a feature that lets you search within your
2
• Search results may vary depending on the channel, region, network settings, and
whether you have agreed to the terms and conditions.
projector. If you run a search in such apps, the search will be
carried out in Search.
Page 86
Use App & Contents
Installing Apps
You can use your LG account to install various apps on your projector.
1 Press the button on the remote control.
2 Launch the LG Content Store application.
3 Select your desired category from the categories shown at the top of the
screen. The list of available apps in the selected category will be shown.
4 Select an app to set up from the list.
5 Read the details of the app and then press Install.
6 When the installation is complete, you can run the app immediately.
• Available categories may vary depending on the country or service status.
• If the storage on your projector is insufficient, you can install the apps by
connecting an external memory device.
• Some USB storage devices may not be supported or may not work properly.
• USB drivers containing apps from other LG TVs or LG Projectors may not be
used.
35
ENGLISH
Page 87
36
Watching VOD Content
You can immediately enjoy dramas, movies, and more with real-time streaming.
1 Press the button on the remote control.
ENGLISH
2 Launch the LG Content Store application.
3 Select your desired category from the categories shown at the top of the
screen, such as TV Shows and Movies. The list of available content in the
selected category will be shown.
4 Select an item from the list.
5 Read the details of the content and then press Watch Now.
6 Select a playback option. An app may be required to play the content with the
selected playback option. If not installed, install the app to play the content.
7 The content is played using the selected option.
• This feature is only available in certain countries.
• Available categories may vary depending on the country or service status.
• Adult authentication is required for playing adult content.
Page 88
PLAY OTHER DEVICE FILES
37
Photo & Video
Viewing Photos and Videos
You can view photos and videos using the Photo & Video app.
1 Press the button on your remote control.
2 Launch the Photo & Video application.
3 Select your desired storage device.
4 Select and view your desired photo or video.
1 2 3 4
Description
Select your desired type of content and viewing method.
1
Select and delete your desired content.
2
(You cannot delete les that are shared from other devices.)
Select the content you want to play. You can only select the same
3
type of content as you rst selected.
Launch Search.
4
• Certain content may not be displayed on the list if the number of all content
exceeds 40,000.
ENGLISH
Page 89
38
Photo Player
Selecting a photo in the Photo & Video app runs the photo player. You can view
your saved photos.
ENGLISH
1 2 3 4 5 6 7
Description
Returns to the entire content list.
1
You can play background music by running the music player.
2
You can zoom the photos in/out.
3
Starts the slide show.
4
Rotates photos.
5
360-degree photos can be viewed in 360 degrees.
6
• Using the 360-degree mode on a normal photo may distort the
image.
• This feature is available on certain models only.
You can set the size of a photo or change the speed and effect of a
7
slide show.
Page 90
Supported Photo Files
File type Format Resolution
.jpeg
.jpg
.jpe
.png PNG
.bmp BMP
JPEG
Minimum: 64 x 64
Maximum
Normal Type: 15360 (W) x 8640 (H)
Progressive Type: 1920 (W) x 1440 (H)
Minimum: 64 x 64
Maximum: 5760 (W) x 5760 (H)
Minimum: 64 x 64
Maximum: 1920 (W) x 1080 (H)
39
ENGLISH
Page 91
40
Video Player
Selecting a video in the Photo & Video app runs the video player. You can view
your saved videos.
ENGLISH
2 1 5 6 7 3 4
Description
Returns to the entire content list.
1
You can select other content by displaying the playlist while watching
2
a video.
You can control basic video playback functions.
3
Rotates videos.
4
• This feature is available on certain models only.
360-degree videos can be viewed in 360 degrees.
5
• Using the 360-degree mode on a normal video may distort the
image.
• This feature is available on certain models only.
By zooming in the projector display, you can view images in a larger
6
size than the originals.
You can set additional options.
7
Page 92
Setting Additional Options
You can change subtitle settings.
1
You can set audio tracks.
2
You can set continue watching to resume playing from the last viewed
3
scene.
You can set continuous playback.
4
If continuous playback is set, the next video is automatically played
after the playback of a video is over.
Returns to the basic operation screen.
5
41
ENGLISH
1 2 3 4 5
Description
Page 93
42
Supported Video Files
Maximum data transfer rate:
• Full HD video
ENGLISH
H.264 1920 x 1080@60P BP/MP/HP@L4.2 40 Mbps
HEVC 1920 x 1080@60P MP@L4.1, Main10 Profile@L4.1 40 Mbps
•
ULTRA HD video (ULTRA HD model only)
[Depends on the model.]
H.264 4096 × 2160@60P BP/MP/HP@L5.1 60Mbps
HEVC 4096 × 2160@60P MP@L5.1, Main10 Profile@L5.1 60Mbps
Supported external subtitles:
*.smi, *.srt, *.sub (MicroDVD, SubViewer 1.0/2.0), *.ass, *.ssa, *.txt (TMPlayer),
*.psb (PowerDivX), *.dcs (DLP Cinema)
Supported embedded subtitles format:
• Matroska (mkv):
SRT
• MP4 (mp4): Timed Text
Sub Station Alpha (SSA), Advanced Sub Station Alpha (ASS),
Page 94
Supported video codecs
Extension Codec
.asf
.wmv
.avi
.mp4
.m4v
.mov
.3gp
.3g2
.mkv
.ts
.trp
.tp
.mts
.mpg
.mpeg
.dat
.vob
Video
Audio
Video
Audio
Video H.264/AVC, MPEG-4, HEVC
Audio
Video H.264/AVC, MPEG-4
Audio AAC, AMR-NB, AMR-WB
Video MPEG-2, MPEG-4, H.264/AVC, VP8, VP9, HEVC
Audio
Video H.264/AVC, MPEG-2, HEVC
Audio
Video MPEG-1, MPEG-2
Audio MPEG-1 Layer I, II, MPEG-1 Layer III (MP3)
Video MPEG-1, MPEG-2
Audio Dolby Digital, MPEG-1 Layer I, II, DVD-LPCM
VC-1 Advanced Prole (except for WMVA), VC-1
Simple and Main Proles
WMA Standard (except for WMA v1/ WMA
Speech)
Xvid (except for 3 warp-point GMC), H.264/AVC,
Motion Jpeg, MPEG-4
MPEG-1 Layer I, II, MPEG-1 Layer III (MP3),
Dolby Digital, LPCM, ADPCM, DTS
Dolby Digital, Dolby Digital Plus, AAC, MPEG-1
Layer III (MP3)
Dolby Digital, Dolby Digital Plus, AAC, PCM, DTS,
MPEG-1 Layer I, II, MPEG-1 Layer III (MP3)
MPEG-1 Layer I, II, MPEG-1 Layer III (MP3),
Dolby Digital, Dolby Digital Plus, AAC, PCM
43
ENGLISH
Page 95
44
Cautions for Video Playback
• Some user-created subtitles may not work properly.
• A video file and its subtitle file must be located in the same folder. For subtitles
ENGLISH
to be displayed properly, make sure that the video file and the subtitle file have
the same name.
• Subtitles on a Network Attached Storage (NAS) device may not be supported
depending on the manufacturer and model.
• Streams that include Global Motion Compensation (GMC) and Quarterpel
Motion Estimation (Qpel) are not supported.
• Playable file sizes may vary depending on the encoding conditions.
• Only Window Media Audio V7 and later are supported.
• The AAC main profile is not supported.
• Video files created by some encoders may not be played.
• Video files in a different format than specified may not be played properly.
• Video files stored on a USB storage device that does not support High Speed
may not be played properly.
• DTS codecs are supported only for playbacks of USB and HDMI video files.
ULTRA HD video (ULTRA HD model only)
[Depends on the model.]
• ULTRA HD video (ULTRA HD model only): 3840 x 2160, 4096 x 2160
• Some HEVC-encoded ULTRA HD videos other than the content officially
provided by LG Electronics may not be played.
Some codecs can be supported after a software upgrade.
Extension Codec
mkv / mp4 / ts
Video H.264/AVC, HEVC
Audio Dolby Digital, Dolby Digital Plus, AAC
Page 96
45
Music
Playing Music
You can listen to music by using the Music app.
1 Press the button on your remote control.
2 Launch the Music application.
3 Select your desired storage device.
You can select your desired songs from all of your storage devices and add
them to MY PLAYLIST.
4 Select your desired music content and enjoy it.
1
3
5
2
4
Description
Select the desired type of content list.
1
Select and delete content.
2
(Files shared from other devices cannot be deleted.)
Select content and add it to MY PLAYLIST.
3
Open the music player.
4
Launch SEARCH.
5
• If the number of all content is more than 5,000, some content may not be listed
up.
ENGLISH
Page 97
46
Using the Music Player
The music player lets you choose music from other apps and use it as background
music.
ENGLISH
1 2 3 4 5 6
7
Description
You can play music from the selected storage device.
1
You can set repeat playback and random playback.
2
The congurable items differ depending upon model.
3
: You can turn the screen off while listening to music or display
the music player in full-screen mode.
: You can listen to music with the screen turned off.
Page 98
Description
You can change the position of the music player.
4
You can minimize the music player.
5
This feature closes the music player.
6
Lyrics are available for music les that provide them.
7
In some music les, you can choose a lyric section and move the
playback position.
• The lyrics feature is only supported on some devices.
• The lyrics may not be displayed in sync depending on the lyrics data
in the music file.
47
ENGLISH
• Reopen your music player by pressing the
control.
• You may not be able to use the music player for some features.
• You can also run the music player as follows:
• Select
• Select
in the Music app.
while viewing photos in the Photo & Video app.
buttons on your remote
Page 99
48
Audio Format
ENGLISH
.mp3
.wav
.ogg
.wma
.flac
File Format Item Info
Bit rate 32 kbps ~ 320 kbps
Sample freq. 16 kHz ~ 48 kHz
Support MPEG-1, MPEG-2
Channels mono, stereo
Bit rate -
Sample freq. 8 kHz ~ 96 kHz
Support PCM
Channels mono, stereo
Bit rate 64 kbps ~ 320 kbps
Sample freq. 8 kHz ~ 48 kHz
Support Vorbis
Channels mono, stereo
Bit rate 128 kbps ~ 320 kbps
Sample freq. 8 kHz ~ 48 kHz
Support WMA
Channels up to 6 ch
Bit rate -
Sample freq. 8 kHz ~ 96 kHz
Support FLAC
Channels mono, stereo
• The number of supported channels may vary depending upon the sample
frequency.
Page 100
File Viewer
Viewing Files
You can see document les stored on a connected device.
1 Press the button on your remote control.
2 Launch the File Viewer application.
3 Select your desired storage device.
4 Select and view your desired document le.
1 2
Description
Select your desired type of content and viewing method.
1
Select and delete your desired content.
2
(You cannot delete les that are shared from other devices.)
• Certain content may not be displayed on the list if the number of all content
exceeds 40,000.
49
ENGLISH
Loading...
