OWNER’S MANUAL

MFL71690516

Mini Hi-Fi Audio

Please read this manual carefully before operating your set and retain it for future reference.

MODEL

ON88

2004_Rev02

www.lg.com

Getting Started2

Safety Information

Getting Started

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK DO NOT REMOVE COVER (OR BACK)

NO USER-SERVICEABLE PARTS INSIDE REFER

SERVICING TO QUALIFIED SERVICE PERSONNEL.

WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

CAUTION: The apparatus should not be exposed to water (dripping or splashing) and no objects lled with liquids, such as vases, should be placed on the apparatus.

WARNING: Do not install this equipment in a conned space such as a book case or similar unit.

CAUTION: Do not use high voltage products around this product. (ex. Electrical swatter) This product may malfunction due to electrical shock.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This lightning ash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufcient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

CAUTION: This product employs a Laser System. To ensure proper use of this product, please read this owner’s manual carefully and retain it for future reference. S hall the unit require maintenance, contact an authorized service center. Use of controls, adjustments or the performance of procedures other than those specied herein may result in hazardous radiation exposure. To prevent direct exposure to laser beam, do not try to open the enclosure.

CAUTION: Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from over heating. The openings should never be blocked by placing the product on a bed, sofa, rug or other similar surface. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instruction has been adhered to.

NOTICE: For safety marking information including product identication and supply ratings, please refer to the main label on the bottom or the other surface of the product.

Getting Started 3

CAUTION concerning the Power Cord

The Power Plug is the disconnecting device. In case of an emergency, the Power Plug must remain readily accessible.

Check the specication page of this owner’s manual to be certain of the current requirements.

Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power cords, or damaged or cracked wire insulation are dangerous. Any of these conditions could result in electric shock or re. Periodically examine the cord of your device, and if its appearance indicates damage or deterioration, unplug it, discontinue use of the device, and have the cord replaced with an exact replacement part by an authorized service center. Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the device.

CAUTION: Be careful to make sure children do not put their hands or any objects into the *speaker duct.

* speaker duct: A hole for plentiful bass sound on speaker cabinet. (enclosure)

CAUTION: No naked ame sources, such as lighted candles, should be placed on the apparatus.

Symbols

Refers to alternating current (AC).

Refers to direct current (DC).

Refers to class II equipment.

Refers to stand-by.

Refers to “ON” (power).

Refers to dangerous voltage.

Getting Started

Table of Contents4

Table of Contents

1 Getting Started

2 Safety Information 6 Unique Features 7 Playable file Requirement 7 – Music file requirement 7 – Compatible USB Devices 7 – USB device requirement 8 Remote control 10 Top panel 12 Front panel / Rear panel

2 Connecting

14 AC Power Cord Connection 14 Optional Equipment Connection 14 – USB Connection 15 – Antenna Connection 16 – OPTICAL IN Connection 17 LG Sound Sync

3 Operating

18 Basic Operations 18 – CD/USB Operations 18 – Auto Play 19 – Selecting a folder and

an MP3/WMA file 20 – Deleting a file/folder or format 21 Playback Effect

21 – AUTO DJ 21 – DJ PAD

22 Using BLUETOOTH® wireless technology 22 – Listening to music stored on the Bluetooth

devices 25 Using the LG XBOOM App 25 – About “LG XBOOM” App 25 – Install “LG XBOOM” App onto Your

Bluetooth Device 26 – Activate Bluetooth with “LG XBOOM” App 27 Radio Operations 27 – Listening to the radio 27 – Improving poor FM reception 27 – Presetting the Radio Stations 27 – Deleting all the saved stations 28 Sound adjustment 28 – Setting the sound mode

28 – Setting the USER EQ

29 Advanced Operations 29 – JUKEBOX Playback

Table of Contents 5

30 Other Operations 30 – Turn off the sound temporarily 30 – DRC (Dynamic range control) 30 – CHILDSAFE Mode

31 – DEMO

31 – Resume stop 31 – Using your TV remote control 32 – Using Guitar 32 – Using Microphone

35 – LIGHTING

35 – Sleep Timer Setting

35 – Dimmer

36 – Auto power down 36 – AUTO POWER On 37 – Auto function change 38 Setting the Clock 38 – Setting the Clock through “LG XBOOM” App 38 – Using your unit as an alarm clock 39 WIRELESS PARTY LINK Connection

4 Troubleshooting

41 Troubleshooting

41 – General

42 – NOTES to release Demo mode

5 Appendix

43 General specifications 44 Trademarks and licenses 45 Maintenance 45 – Notes on Discs

45 – Handling the Unit

Getting Started6

Unique Features

BLUETOOTH®

Listens to music stored on your Bluetooth device.

Getting Started

Optical In

Listens to music from your optical device.

Playback effects

Listens to music with various sound and playback effects.

LG XBOOM

LG XBOOM is an app designed to let you take control of some of LG’s latest audio devices. (Page

25-26 )

LG Sound Sync

Controls volume level of this unit by the remote control of your LG TV that is compatible with LG Sound Sync.

Getting Started 7

Playable file Requirement

Music file requirement

MP3/WMA le compatibility with this unit is limited as follows.

y Sampling frequency: within 32 to 48 kHz (MP3),

within 32 to 48 kHz (WMA)

y Bit rate: within 32 to 320 kbps (MP3),

40 to 192 kbps (WMA)

y Maximum les: Data CD: 999 / USB: 2,000

y Maximum folders: Data CD: 99 / USB: 200

y File extensions: “.mp3”/ “.wma”

y Certain MP3/WMA les may not be played

depending on the type or format of the le.

y CD-ROM le format: ISO 9660/ JOLIET

y We recommend that you use Easy-CD Creator,

which creates an ISO 9660 le system.

y A protected le by DRM (Digital rights

management) cannot be played on the unit.

y The DTS disc is not supported.

You have to set the disc format option to [Mastered] in order to make the discs compatible with the LG players when formatting rewritable discs. When setting the option to Live File System, you cannot use it on LG players.

(Mastered/Live File System: Disc format system for Windows Vista)

Compatible USB Devices

y MP3 Player: Flash type MP3 player.

y USB Flash Drive:

Devices that support USB2.0 or USB1.1.

y The USB function of this unit does not support all

USB devices.

USB device requirement

y Devices which require additional program

installation when you have connected it to a computer, are not supported.

y Do not extract the USB device while in operation.

y For a large capacity USB, it may take longer than a

few minute to be searched.

y To prevent data loss, back up all data.

y If you use a USB extension cable or USB hub, the

USB device is not recognized.

y Using NTFS le system is not supported. (Only

FAT(16/ 32) le system is supported.)

y This unit recognizes up to 2,000 les.

y External HDD, Card readers, Locked devices, or

hard type USB devices are not supported.

y USB port of the unit cannot be connected to PC.

The unit cannot be used as a storage device.

y Some USB may not work with this unit.

Getting Started

Getting Started8

(R03)

Remote control

Getting Started

Replacement of battery

• • • • • • • • • • • • • • a • • • • • • • • • • • • • 1 (Standby): Turns the power on or off.

B (Open/Close): Opens and closes the disc tray.

VOL (Volume) +/-: Adjusts speaker volume.

F (Function): Selects the function and input source.

Input source / Function Display

Disc CD USB USB1 / USB2

Optical OPTICAL LG Sound Sync (Optical) LG OPT

Bluetooth BT

LG Sound Sync (Wireless) LG TV

Radio FM

[ (Mute):

- Mutes the sound.

- Controls this unit using TV remote. (Page 31)

PRESET·FOLDER W/S:

- Chooses a preset number for a radio station. (Page 27)

- Searches for a folder of MP3/WMA les. When

a CD/USB containing MP3/WMA les in several folders is being played, press PRESET·FOLDER

W/S to select the folder you want to play.

JUKEBOX/MEMORY:

- Stores radio stations. (Page 27)

- Selects JUKEBOX mode. (Page 29)

- Makes JUKEBOX list.

AUTO DJ: Selects the AUTO DJ mode. (Page 21)

DELETE:

- Deletes MP3/WMA les. (USB only). (Page 20)

- Deletes a song on the JUKEBOX list.

- Deletes all the saved stations.

Remove the battery cover on the rear of the remote control, and insert the battery with 4 and 5 matched correctly.

Risk of re or explosion if the battery is replaced by an incorrect type.

Getting Started 9

• • • • • • • • • • • • • • b • • • • • • • • • • • • •

REPEAT: Listens to your tracks/les repeatedly or randomly.

TUNING-/+: Selects the radio stations. C/V (Skip/Search):

- Skips backward or forward.

- Searches for a section within a track/le.

N (Play/Pause):

- Starts or pauses playback.

- Selects stereo/mono.

- Bluetooth connection lock (BT LOCK): Select the Bluetooth function by pressing F repeatedly. And

long press N to limit Bluetooth connection to only BT and LG TV.

Z (Stop):

- Stops playback.

- Cancels DELETE function.

EQUALIZER: Chooses sound impressions.

SPECIAL EQ: Chooses special equalizer. J (Information):

- Sees information about your music. An MP3 le often come with ID3 tag. The tag gives the Title, Artist, Album or Time information.

- Sees optical source information in OPTICAL mode.

- Sees Bluetooth device name of the unit in BT

READY.

- Sees the name of connected all Bluetooth device in Bluetooth mode.

- When these units are successfully connected each

other in WIRELESS PARTY LINK mode, each of connected device names appears in the each unit.

• • • • • • • • • • • • • • c • • • • • • • • • • • • •

0 to 9 numerical buttons: Selects numbered tracks, les, or preset number.

CLOCK: Sets a clock and checks a time.

ALARM: With the ALARM function you can turn on

CD, USB play and tuner reception at a desired time.

• • • • • • • • • • • • • • d • • • • • • • • • • • • •

VOICE CANCELLER: You can reduce the vocal tones during music playback from various input sources.

SLEEP: Sets the system to turn off automatically at a specified time. (Dimmer: The display window will be darkened by half.)

SET: Conrms the setting. KEY CHANGER (L/l): Changes the key to suit your

vocal range.

MIC (Microphone) ECHO: Selects ECHO mode.

?: This button is not available.

VOCAL EFFECTS: Selects various vocal effects mode.

Getting Started

Getting Started10

Top panel

Getting Started

a 1 (Standby)

Turns the power on or off.

b DEMO In power off status, if you press DEMO, show

demo mode.

c USB 1 Port You can play sound les by connecting the USB

device.

d Display window e USB 2 Port

You can play sound les by connecting the USB

device.

f F (Function)

Selects the function and input source.

Input source / Function Display

Disc CD USB USB1 / USB2

Optical OPTICAL LG Sound Sync (Optical) LG OPT

Bluetooth BT

LG Sound Sync (Wireless) LG TV

Radio FM

f g h

Getting Started 11

g LIGHTING

Selects the lighting mode.

h 3TWIN

Connects two units for TWIN mode in WIRELESS PARTY LINK.

i C/V (Skip/Search)

- Skips backward or forward.

- Searches for a section within a track/le.

- Selects the radio stations.

N (Play/Pause)

- Starts or pauses playback.

- Selects stereo/mono.

- Bluetooth connection lock (BT LOCK): Select the Bluetooth function by pressing F repeatedly. And long press N to limit Bluetooth connection to only BT and LG TV.

Z (Stop)

Stops playback or cancels DELETE function.

VOL (Volume) -/+

Adjusts speaker volume.

MIC (Microphone) / GUITAR -/+

Adjusts Microphone volume or Guitar volume.

(Auto Music Play) Plays the audio currently playing by tagging the mobile (with “LG XBOOM” App) to this unit. (Android Only)

k VOICE CANCELLER

You can reduce the vocal tones during music playback from various input sources.

B (Open/Close)

Opens and closes the disc tray.

l CLUB, DRUM, USER (DJ PAD)

Selects CLUB, DRUM or USER sound effect to

mix.

(If you want to use USER, you have to register a source with “LG XBOOM” app.(Android Only))

1, 2, 3 (DJ PAD)

Press a desired sound pad.

m MIC (Microphone) ECHO

Selects ECHO mode.

VOCAL EFFECTS

Selects various vocal effects mode.

KEY CHANGER (l/L)

Changes the key to suit your vocal range.

n Remote sensor o SPECIAL EQ / BASS BLAST (or BASS BLAST+)

- Chooses special equalizer.

- Press and hold to select BASS (or BASS+) effect directly.

Moves to folder or file in selection mode.

Selects a folder when searching a file.

USER EQ

Selects the equalizer created by your own.

Multi jog

- Searches a folder or a file.

- Turns clockwise or counterclockwise to control the USER EQ level.

- Chooses special equalizer.

Getting Started

Getting Started12

Front panel / Rear panel

Getting Started

a Disc tray b Lighting c Remote sensor

Caution

Place the unit at a safe distance from the child’s reach. Otherwise it may result in the unit falling down and causing personal injury and/or property damage.

d OPTICAL IN: Connect an optical device. e GUITAR IN: Connect a guitar. f MIC (Microphone) IN: Connect a microphone. g ANTENNA (FM) h AC IN socket

Caution

y Connect the power cord to wall outlet

directly if possible. Or when you use an extension cable, it is highly recommended to use an extension cable of 110 V / 15 A or 230 V / 15 A, otherwise the unit may not operate properly because of the lack of power supply.

y Do not overload the extension cord with

excessive electrical load.

Useful functions for using the unit

Function Description To do Do this

TV Remote On/ Off

(Page 31)

BT Lock On/Off

(Page 24)

Auto Power On

(Page 36)

It allows you to control the volume of this unit by your TV remote control even by other company’s product.

Initial setting of this function was set to on.

It allows you to connect a Bluetooth device only on

BT (Bluetooth) and LG TV

functions.

Initial setting of this function was set to off.

It allows the unit to turn on automatically by input signals: Optical, LG TV or

BT (Bluetooth)

OFF

Press and hold [ on the remote control for 3 seconds in Optical function.

Press and hold N for 5 seconds in BT (Bluetooth) function.

Turn off the unit by pressing 1 on the unit for 5 seconds.

Getting Started 13

Getting Started

Connecting14

AC Power Cord Connection

1. Connect one end of the AC power cord (included) to the AC IN socket.

Connecting

2. Plug the other end into the wall outlet.

Note

Unplug the AC power cord from the wall outlet if you do not use for an extended period of time.

Optional Equipment Connection

USB Connection

Connect a USB device (or MP3 player, etc.) to the USB ports on the unit.

USB device

Note

Removing the USB device from the unit:

1. Choose a different function/mode or

press Z twice in a row.

2. Remove the USB device from the unit.

Antenna Connection

Connect the supplied FM antenna for listening to the radio.

FM antenna

Note

Be sure to fully extend the FM wire antenna.

Connecting 15

Connecting

Connecting16

OPTICAL IN Connection

1. Connect an optical output jack of external devices to the OPTICAL IN jack.

Connecting

TV or digital device etc.

Optical cable

Note

y Before connecting the optical cable, be sure

to remove the protection plug cover if your cable has the cover.

y You can enjoy the TV audio through the

speakers of this unit. In the case of some TV models, you must select the external speaker option from the TV menu. (For details, reference your TV user manual.)

Caution

Make sure to properly align and connect the optical cable; improper alignment may cause damage to the jack.

Optical jack Optical cable Optical jack Optical cable

<O> <X>

2. Press F

until OPTICAL function is selected.

LG Sound Sync

You can control some functions of this unit by your TV’s remote control with LG Sound Sync. It is compatible with LG TV that supports LG Sound Sync. Make sure your TV has the LG Sound Sync logo.

Controllable function by LG TV’s remote control: Volume up/down, mute

LG Sound Sync with wired connection

1. Connect your LG TV to the unit by using an optical cable.

2. Set up the sound output of TV to listen to the sound through this unit. (Refer to the TV’s instruction manual for the details of LG Sound Sync.)

3. Turn on the unit by pressing 1.

4. Press F

You can see “LG OPT” on the display window if

LG Sound Sync with wireless connection

1. Turn on the unit by pressing 1.

2. Press F

3. Set up the sound output of TV to listen to the

until OPTICAL function is selected.

connecting normally between this unit and your

TV.

until LG TV function is selected.

sound through this unit: “PAIRED” appears on the display window for about 3 seconds and then you can see “LG TV” on the display window if the TV and this unit are connected normally. (Refer to the TV’s instruction manual for the details of LG Sound Sync.)

Connecting 17

Note

y You can also use the remote control of

this unit while using LG Sound Sync. If you use TV’s remote control again, the unit synchronizes with the TV. (According to TV Specifications, the volume and mute of this unit synchronize with TV.)

y If the connection fails, check the conditions of

this unit and your TV: power, function.

y Make sure of the condition of this unit and

the connection in the cases below when using LG Sound Sync.

- The unit is turned off.

- Changing to a different function.

- Disconnecting the wireless connection

caused by interference or a distance.

- Disconnecting the optical cable.

y The amount of time to turn off this unit is

different depending on your TV.

y If you try to change the function on using

the LG TV function, volume will be change according to the LG TV volume level.

y If you turned off the unit directly by pressing

1, LG Sound Sync will be disconnected. To use this function again, you should reconnect the TV and the unit.

y The volume may be increased when the TV

and this unit is connected by LG Sound Sync. Decrease the TV volume and then connect with this unit.

y When you turn on your LG TV connected

by LG Sound Sync or enter LG TV function, this unit changes the function to LG TV automatically.

y You should set the TV Sound output manually

depending on the TV version.

y If you control TV volume when this unit and

TV are connected by LG Sound Sync, this unit may louder the volume due to synchronizing volume with TV’s.

Connecting

Operating18

Basic Operations

CD/USB Operations

1. Insert the disc by pressing B.

Or connect the USB device to the USB port.

2. Select CD or USB function by pressing F.

To Do this

Stop Press Z. Playback Press N. Pause Press N during playback.

Operating

Searching for a section within a track/le

Selecting a track/le directly

Skipping to the next/previous track/le

Playing

repeatedly or randomly

Press and hold C/V during playback and release it at the point you want to listen to.

Press 0 to 9 numerical buttons on the remote control to go to the desired le or track directly.

- In stop status,

Press C/V to go to the next/

previous track/le.

- During playback,

(1) By using C/V buttons:

Press V to go to the next track/

le.

Playing in less than 3 seconds, press

to go to the previous track/le.

Playing after 3 seconds, press C to go to the beginning of the track/le.

(2) By using SEARCH:

Rotate Multi jog or C/V and press N to play the track/ le.

Press REPEAT on the remote control repeatedly. Refer to the note for details about the display change.

Note

y Repeat/Shufe playback operates as follows.

On Display

OFF

ONE Plays a same song repeatedly.

FOLDER

ALL Plays all the songs repeatedly.

SHUFFLE

y When you play JUKEBOX list, only ONE and

ALL are available.

y Even after restarting the unit or switching

one function to another, you can listen to music from the point where it’s last been played.

y If you leave the disc tray open for 5 minutes,

it will close automatically.

Plays songs in order, and stops the playback.

Plays songs in a folder repeatedly. (Except AUDIO CD)

Plays all the songs once randomly, and stops the playback.

Description

Auto Play

- AUDIO/MP3/WMA CD is played automatically after disc tray is open and then closed.

- Automatically switches to the CD function if disc tray is open and then closed even when there is no disc in disc tray.

Selecting a folder and an MP3/WMA file

On the unit

1. Press SEARCH and rotate Multi Jog or C/V

until a desired file appears. You can also search a folder if you press SEARCH again.

2. Press OK or N to play the selected file. When

you search a folder, press OK to select a file in the folder, then press OK or N again. The selected file is played.

On the remote control

1. Press PRESET·FOLDER W/S repeatedly until a

desired folder appears.

2. Select the file you want by using C

3. Press N to play it.

/V.

Operating 19

Note

y CD / USB Folders/Files are recognized as

below.

y If there is no le in a folder, the folder will not

appear.

y Folders will be presented as the following

order;

ROOT

FOLDER 1 FOLDER 3 FOLDER 7 FOLDER 8 FOLDER 5 FOLDER 6

y File will be played from $ le No.1 to $ le

No.14 one by one.

y Files and folders will be presented in order

recorded and may be presented differently according to the record circumstances.

*ROOT: The rst screen you can see when a computer recognize the CD/USB is “ROOT”.

Operating

Operating20

Deleting a file/folder or format

You can delete le, folder on your USB or format the

USB.

1. Select USB function by pressing F.

2. Press DELETE on the remote control repeatedly, the display changes as followings. DEL FILE

On Display Description

If you want to exit the current mode, press Z.

Operating

3. To delete file/folder or format, press and hold

DELETE on the remote control.

y Do not extract the USB device during

operation. (play, delete, etc.)

y Regular back up is recommended to prevent

data loss.

y The delete function may not be supported

according to the USB status. (lock, etc.)

DEL FILE

DEL DIR

FORMAT

Caution

DEL DIR FORMAT

Select the le you want to delete.

Select the folder you want to

delete.

Select to format the USB device.

Operating 21

Playback Effect

The unit supports various sound and playback effects: AUTO DJ, DJ PAD.

AUTO DJ

Auto DJ blends the end of one song into the beginning of another for seamless playback. It equalizes volume across tracks/les for uninterrupted playback.

Press AUTO DJ on the remote control repeatedly, the display changes as followings.

SHUFFLE

On Display Description

SEQUENTIAL

SEQUENTIAL OFF

OFF -

SHUFFLE

y AUTO DJ mode does not support searching

for a section within a track/le or to play repeatedly or randomly.

y If you move to other functions or stop the

music using Z on AUTO DJ mode, AUTO DJ will be disabled.

y AUTO DJ is not supported in the music le

whose length is less than 60 seconds.

y Only SEQUENTIAL is selected when played

JUKEBOX list.

The music is played randomly on

this mode.

The music is played repeatedly on

this mode.

Note

DJ PAD

It allows you to mix CLUB, DRUM or USER sound effect. Each mode has up to 3 sounds effect.

1. Press and hold DJ PAD (CLUB, DRUM or USER) on the unit to select a desired DJ PAD sound effect.

2. Press a DJ PAD (1, 2, 3) of desired sound on the unit.

Note

y If you want to use USER, you have to register

a source with “LG XBOOM” app.(Android

Only)

If the source is not register to USER, “EMPTY” or “NO SOUND” appears on the display window.

y Initial DJ PAD mode is CLUB sound effect.

y DJ PAD mode is displayed for 3 seconds

when you press DJ PAD (CLUB, DRUM or USER) on the unit.

y The DJ PAD sound is mixed when you press a

DJ PAD (1, 2, 3) on the unit.

y The currently playing DJ PAD sound is

stopped and the selected DJ PAD sound outputs if you press a different DJ PAD (1, 2,

3) on the unit while DJ PAD sound is playing.

Operating

Operating22

Using BLUETOOTH® wireless technology

About Bluetooth

Bluetooth is wireless communication technology for

short range connection.

The sound may be interrupted when the connection interfered by the other electronic wave or you connect the Bluetooth in the other rooms.

Connecting individual devices under Bluetooth wireless technology does not incur any charges. A mobile phone with Bluetooth wireless technology

can be operated via the Cascade if the connection

Operating

was made via Bluetooth wireless technology.

y Available Devices: Smart phone, MP3, Notebook,

etc.

y Version: 4.0

y Codec: SBC, AAC

Bluetooth Profiles

In order to use Bluetooth wireless technology, devices must be able to interpret certain proles. This unit is compatible with following prole.

A2DP (Advanced Audio Distribution Prole)

Listening to music stored on the Bluetooth devices

Pairing your unit and Bluetooth device

Before you start the pairing procedure, make sure the Bluetooth feature is activated on your Bluetooth device. Refer to your Bluetooth device’s user guide. Once a pairing operation is performed, it does not need to be performed again.

1. Turn on the unit.

Note

When Bluetooth connection lock is activated, you can search Bluetooth device in BT function.

2. Operate the Bluetooth device and perform the pairing operation. When searching for this unit with the Bluetooth device, a list of the devices found may appear in the Bluetooth device display depending on the type of Bluetooth device. Your unit appears as “LG ON88 (XX)”.

Note

y XX means the last two digits of

Bluetooth address. For example, if your unit has a Bluetooth address such as 9C:02:98:4A:F7:08, you will see “LG ON88 (08)” on your Bluetooth device.

y Depending on the Bluetooth device type,

some devices have a different pairing way. For details about Bluetooth pairing, refer to your Bluetooth device manual.

y You can connect this unit with up to 3

Bluetooth devices simultaneously using the same method as described above, only in the Bluetooth function.

y The multi phone pairing connection is only

supported on Android devices. (Multi phone pairing connection may not be supported depending on the connected device specications.)

y Removable/detachable Bluetooth devices

(Ex: Dongle etc.) will not support multi phone pairing.

Operating 23

3. When this unit is successfully connected with your Bluetooth device, “PAIRED” appears on the display window and change to Bluetooth device name soon. Then “BT” will appear on the display window.

Note

y “PAIRED” will momentarily appear on the

display when you connect other devices for multi phone pairing.

y If the device name is unavailable, “_” will be

displayed.

4. Listen to music. To play a music stored on your Bluetooth device, refer to your Bluetooth device’s user guide.

Note

y When using Bluetooth technology, you have

to make a connection between the unit and the Bluetooth device as close as possible and keep the distance. However, it may not work well in certain situations as described below:

- There is a obstacle between the unit and the Bluetooth device.

- There is a device using same frequency

with Bluetooth technology such as a medical equipment, a microwave or a wireless LAN device.

y If Bluetooth connection does not work well,

try pairing it again.

y Even if this unit is connected to up to 3

Bluetooth devices in the Bluetooth mode, you can play and control music by using only one of the connected devices.

Note

y The sound may be interrupted when the

connection has interference from other electronic devices.

y Depending on the type of the device, you may

not be able to use the Bluetooth function.

y You can enjoy wireless system using phone,

MP3, Notebook, etc.

y The more distance between the unit and

the Bluetooth device, the lower the sound

quality becomes.

y Bluetooth connection will be disconnected

when the unit is turned off or the Bluetooth device gets too far from the unit.

y When Bluetooth connection is disconnected,

connect the Bluetooth device to the unit

again.

y When a Bluetooth device is not connected,

“BT READY” appears on the display window.

y When you use the Bluetooth function,

adjust the volume to a proper level on the Bluetooth device.

y When you connect Bluetooth device (iOS

device etc.) to this unit or operate the device, the volume level can be synchronized with each other.

y Bluetooth connection will be disconnected

when you change the Bluetooth function to some other function. In “LG XBOOM” app connection, only one device which you are playing keeps Bluetooth connection. You can control the Bluetooth device with this unit but you cannot use sound output.

y When entering the Bluetooth function,

this unit automatically connects to the last connected Bluetooth device or the device which played back last. (Auto connection may not be supported depending on the connected device specications.)

Operating

Operating24

Controls connected Bluetooth device

You can control connected Bluetooth device by the unit; play, pause, stop, skip.

Note

y Only Android OS and iOS is available to use

this function.

y This function may not be supported

depending on the Bluetooth device, or operated differently.

Bluetooth connection lock (BT LOCK)

You can limit Bluetooth connection to only

BT (Bluetooth) and LG TV function to prevent

Operating

unintended Bluetooth connections. To turn this function on, press and hold N for about

5 seconds in BT (Bluetooth) function. “ON-BT LOCK” appears then you can limit Bluetooth connection.

To turn this function off, press and hold N for about 5 seconds in BT (Bluetooth) function. “OFF-BT LOCK” appears.

Note

y Even if you set up Bluetooth connection

lock to On, this unit turns on by Auto Power function. Turn off Auto Power function to prevent it. (Page 36)

y When you turn on or off the Bluetooth

connection lock, search and connect again using Bluetooth after deleting the paired list of your Bluetooth device.

y When you turn on the Bluetooth connection

lock, multi phone pairing is not supported.

Operating 25

Using the LG XBOOM App

Note

It is recommended to use the latest version of app.

About “LG XBOOM” App

“LG XBOOM” app brings a suite of new features to this unit.

To enjoy more features, you are recommended to download and install free “LG XBOOM” app.

Install “LG XBOOM” App onto Your Bluetooth Device

There are two ways to install “LG XBOOM” App onto Your Bluetooth Device.

Install “LG XBOOM” App through QR code

1. Install “LG XBOOM” app through QR code. Use the scanning software to scan the QR code.

2. Tap an icon for installation.

Note

y Make sure that your Bluetooth device is

connected to the Internet.

y Make sure that your Bluetooth device

has a scanning software application. If you don’t have one, download one from “Google Android Market (Google Play Store)” or “Apple App Store”.

y Depending on the area, QR code may not

work.

Operating

Operating26

Install “LG XBOOM” App through “Google Android Market (Google Play Store)” or “Apple App Store”

1. Tap the “Google Android Market (Google Play Store)” or “Apple App Store” icon.

2. In the search bar, type in the “LG XBOOM” and search it.

3. In the search result list, find and tap “LG XBOOM” to start downloading Bluetooth app.

Note

y Make sure that your Bluetooth device is

connected to the Internet.

Operating

y Make sure that your Bluetooth device is

equipped with “Google Android Market (Google Play Store)” or “Apple App Store”.

Activate Bluetooth with “LG XBOOM” App

“LG XBOOM” app helps to connect your Bluetooth device to this unit.

Tap “LG XBOOM” app icon on the home screen to open “LG XBOOM” app, and go to the main menu.

Note

y “LG XBOOM” app will be available in the

software version as follow;

- Android O/S: Ver 5.0 (or later)

- iOS O/S: iOS10 (or later)

y If you use “LG XBOOM” app for operation,

there would be some differences between “LG XBOOM” app and the supplied remote control. Use the supplied remote control as necessary.

y Depending on the Bluetooth device,

“LG XBOOM” app may not work.

y After connection of “LG XBOOM” app, music

may be output from your Bluetooth device. In this case, try connecting procedure again.

y If you operate the other applications or

change the settings on your Bluetooth device while using “LG XBOOM” app, “LG XBOOM” app may operate abnormally.

y When “LG XBOOM” app operates abnormally,

check your Bluetooth device and the connection of “LG XBOOM” app and then try to connect again.

y Depending on the smart phone's operating

system, you have some differences for “LG XBOOM” operation.

y Check Bluetooth setting on your Bluetooth

device if “LG XBOOM” app connection does not work well.

Operating 27

Radio Operations

Be sure that FM antenna is connected. (Page 15)

Listening to the radio

1. Press F until FM appears in the display window. The last received station is tuned in.

2. Auto tuning: Press and hold TUNING-/+ on the remote control or C/V on the unit until the frequency indication starts to change, then release. Scanning stops when the unit tunes in a station.

Manual tuning:

Press TUNING-/+ on the remote control or

C/Von the unit repeatedly.

3. Adjust the volume by pressing VOL +/- repeatedly.

Improving poor FM reception

Press N. This will change the tuner from stereo to mono and usually improve the reception.

Presetting the Radio Stations

You can preset 50 stations for FM.

Before tuning, make sure to turn down the volume.

1. Press F until FM appears in the display window.

2. Select the desired frequency by pressing

TUNING -/+ on the remote control or C/V on the unit.

3. Press JUKEBOX/MEMORY on the remote control. A preset number will blink in the display window.

4. Press PRESET·FOLDER W/S on the remote control to select the preset number you want.

5. Press JUKEBOX/MEMORY on the remote control. The station is stored.

6. Repeat steps 2 to 5 to store other stations.

7. To listen a preset station, press PRESET·FOLDER W/S or 0 to 9 numerical buttons on the remote control.

Deleting all the saved stations

1. Press DELETE on the remote control. “DEL ALL” will flash up on the display window

2. Press DELETE on the remote control to erase all the saved radio stations. “DELETED ALL” will scroll on the display window.

Operating

Operating28

Sound adjustment

Setting the sound mode

This system has a number of pre-set equalizers. The displayed items for the equalizer may be different depending on sound sources and effects.

You can select a desired sound mode by using EQUALIZER on the remote control.

On Display Description

Operating

BASS (BASS BLAST)

BASS+ (BASS BLAST+)

POP

CLASSIC

ROCK

JAZZ

FOOTBALL

STANDARD

Reinforces the bass and powerful sound.

This program lends an enthusiastic atmosphere to the sound, giving you the feeling you are at an actual rock, pop, jazz or classic concert.

You can enjoy the equalizer FOOTBALL

STADIUM.

You can enjoy optimized sound.

You can select a desired sound mode by using

SPECIAL EQ on the remote control or SPECIAL EQ / BASS BLAST (or BASS BLAST+) on the unit.

On Display Region Description

FUNK, REGUETON,

SAMBA,

MERENGUE, AXE,

SALSA, SERTANEJ,

FORRO

ARABIC Middle East

DANGDUT Indonesia

AFRO Africa

INDIA India

Note

By pressing and holding SPECIAL EQ / BASS BLAST (or BASS BLAST+) on the unit for 3

seconds, you can directly select BASS (BASS BLAST) or BASS+ (BASS BLAST+) effect.

Latin

America

Optimized equalizer for the music genre preferred in each region.

Setting the USER EQ

You can adjust the sound level of Bass, Middle and Treble as your preference.

1. Press USER EQ on the unit. “USER EQ” is displayed.

2. Press USER EQ on the unit repeatedly until desired setting appears in the display window.

3. Rotate Multi Jog on the unit to adjust the value.

Operating 29

Advanced Operations

JUKEBOX Playback

JUKEBOX function enables you to make a playlist of your favorite tracks/les from a disc or USB device. A playlist of up to 100 tracks/les can be entered.

Making JUKEBOX list

1. Press and hold JUKEBOX/MEMORY on the remote control to enter the edit mode. (Playing will be stopped when you press JUKEBOX/MEMORY on the remote control.)

2. Select a track/file by pressing C/V on the remote control.

3. Press JUKEBOX/MEMORY on the remote control to save the track/file.

4. Repeat steps 2 - 3 to store other tracks/files. (You can modify the list by pressing PRESET·FOLDER W/S on the remote control to select the JUKEBOX program number.)

5. Press JUKEBOX/MEMORY on the remote control once again.

To play the JUKEBOX list, press N on the remote control after you make the list.

Note

When making or modifying the JUKEBOX list, REPEAT mode is off.

Enjoying JUKEBOX

Press JUKEBOX/MEMORY on the remote control once. “ON-JUKEBOX” appears on the display window.

To play JUKEBOX list, press N on the remote control.

To cancel it, press JUKEBOX/MEMORY on the remote control once. “OFF-JUKEBOX” appears on the display window.

Editing JUKEBOX

1. Press and hold JUKEBOX/MEMORY on the remote control to enter the edit mode. (Playing will be stopped when you press JUKEBOX/MEMORY on the remote control.)

2. Press PRESET·FOLDER W/S on the remote control to select a track/file to edit.

3. Press C/V on the remote control.

4. Press JUKEBOX/MEMORY on the remote

control.

5. Repeat 2 to 4 to store the other tracks/files.

6. Press JUKEBOX/MEMORY on the remote control once again.

To play the JUKEBOX list, press N on the remote control after you edit the list.

Deleting JUKEBOX list

Deleting function only works in the edit mode.

1. Press and hold JUKEBOX/MEMORY on the remote control to enter the edit mode.

Press DELETE on the remote control while

JUKEBOX is played to enter the edit mode.

2. Select a song by pressing PRESET·FOLDER W/S on the remote control repeatedly.

3. Press DELETE on the remote control while a song is selected.

Note

y If there is no JUKEBOX list, “NO PROG”

appears on the display window when you press JUKEBOX/MEMORY on the remote control.

y JUKEBOX is switched off in the case below.

- Changing to a different function.

- Turning the unit off and on.

- Operating the numerical buttons on the

remote control.

- Playing a le by using SEARCH and Multi jog on the unit.

y JUKEBOX list is cleared in the case below.

- Removing the disc or the USB device.

Operating

Operating30

Other Operations

Turn off the sound temporarily

Press [on the remote control to mute your sound.

You can mute your unit, for example, to answer the telephone, the “MUTE” will appear in the display window.

To cancel it, press [on the remote control again or change the volume level.

DRC (Dynamic range control)

Make the sound clear when the volume is turned

Operating

down and prevent a sudden sound increase (Dolby Digital only).

Press N in OPTICAL function to turns on or off this function.

On Display Description

ON-DRC DRC function is turned on.

OFF-DRC

Note

This function only operates on OPTICAL function.

DRC function is turned off.

CHILDSAFE Mode

This function helps to prevent you from being surprised when you turn on the unit in case that the volume of the unit is set at a high level.

To turn on CHILDSAFE mode, press and hold OK on the unit when the volume of the unit is “MIN”.

In CHILDSAFE mode, the volume increase gradually.

To turn off CHILDSAFE mode, press and hold OK on the unit when the volume of the unit is “MIN” and this mode is turned on.

Note

In case of CD, USB or BT (Bluetooth) function, CHILDSAFE mode does not work after about 2 minutes from power on the unit even if this mode is enabled.

Operating 31

DEMO

In the power off state, press DEMO on the unit once. The unit will power on and display the each of functions. To cancel the DEMO function, press DEMO on the unit once more.

Resume stop

The unit records the point where you pressed Z depending on the disc or USB.

If you press Z twice, the unit will clear the stopped

point.

Using your TV remote control

You can control some functions of this unit by your TV remote control even by other company’s product. Controllable functions are volume up/down and mute.

Press and hold [on the remote control for about 3 seconds in OPTICAL function to turn on or off this function.

On Display Description

ON-TV REMOTE

OFF-TV REMOTE

Note

y Supported TV brands

LG Panasonic Philips

Samsung Toshiba Vizio

y Make sure that the sound output of your TV

is set to [External speaker].

y Depending on the remote control, this

function may not work well.

y This function does not operate on LG TV's

magic remote control.

y This function only operates on the OPTICAL

function.

TV REMOTE function is turned on.

TV REMOTE function is turned off.

Operating

Operating32

Using Guitar

1. Connect your guitar to the GUITAR IN jack.

2. Play the music you want.

3. Play your guitar with the accompaniment. Adjust the guitar volume by pressing MIC/GUITAR -/+ on the unit.

Note

y When not using the guitar, set the GUITAR

volume to minimum and remove the guitar from the GUITAR IN jack.

y If the guitar is set too near the speaker, a howling

sound may be produced. In this case, move the

Operating

guitar away from the speaker or decrease the sound level by using the MIC/GUITAR -/+ on the unit.

y If sound through the guitar is extremely loud,

it may be distorted. In this case, press MIC/

GUITAR -/+ on the unit.

y Do not connect a microphone to the GUITAR IN

jack.

Using Microphone

1. Connect your microphone to the MIC IN jack.

2. Play the music you want.

3. Sing along with the accompaniment. Adjust the microphone volume by pressing MIC/GUITAR -/+ on the unit.

Note

y When not using the microphone, set the MIC

volume to minimum or turn off the MIC and remove the microphone from the MIC IN jack.

y If the microphone is set too near the speaker,

a howling sound may be produced. In this case, move the microphone away from the speaker or decrease the sound level by using

the MIC/GUITAR -/+ on the unit.

y If sound through the microphone is extremely

loud, it may be distorted. In this case, press

MIC/GUITAR -/+ on the unit.

y You can give an echo effect or to the sound

from the microphones by pressing MIC ECHO.

y Do not connect a guitar to the MIC IN jack.

Operating 33

VOICE CANCELLER

You can reduce the vocal tones during music playback from various input sources. Press the VOICE CANCELLER and “ON-VOICE CANCELLER” will appear in display window.

To cancel it, press VOICE CANCELLER again.

The quality of the VOICE CANCELLER may be different depending on the recording conditions of the music les.

Note

y This function is available in the CD, USB or BT

(Bluetooth) Function.

y If the function is not available, “NOT

SUPPORT” appears in the display window.

y This function is available to use only when a

microphone is connected.

y If a microphone is not connected, “INSERT

MIC” appears in the display window.

y It is not available on the mono source.

y To initialize it, change the function or

disconnect the microphone.

y This function may not be initialized depending

on the status of connected devices.

KEY CHANGER

You can adjust the key to 9 steps (4 steps higher, 4 steps lower and the original key).

yTo make key more sharp, one by one, press the

KEY CHANGER(L) repeatedly during playback.

yTo make the key more atten, one by one,

press the KEY CHANGER(l) repeatedly during playback.

Note

y This function is available in the CD, USB or BT

(Bluetooth) Function.

y To initialize it, change the function, disconnect

the microphone or change the music.

y This function may not be initialized depending

on the status of connected devices.

y If the function is not available, “NOT

SUPPORT” appears in the display window.

y If a microphone is not connected, “INSERT

MIC” appears in the display window.

Operating

Operating34

VOCAL EFFECTS

When you connect your microphone to the MIC jack, you can enjoy karaoke function by changing voice in the various source.

To select various vocal effects mode, pressing VOCAL EFFECTS repeatedly when vocal effects mode appears in the display window.

BASS

Operating

SOPRANO HELIUM ROBOT

DUET MAN

SOPRANO ECHO1 HELIUM ECHO1 ROBOT ECHO1 DUET MAN1 DUET

WOMAN1

ECHO2

DUET MAN2 DUET WOMAN2 OFF

y If a microphone is not connected, “INSERT

MIC” appears in the display window.

y If you press KEY CHANGER or MIC ECHO

on VOCAL EFFECTS mode, after backing up current VOCAL EFFECTS, turn off VOCAL EFFECTS mode and operate KEY CHANGER or ECHO mode.

y To turn off VOCAL EFFECTS mode, press and

hold VOCAL EFFECTS.

DUET WOMAN BASS ECHO1

BASS ECHO2 SOPRANO

HELIUM ECHO2 ROBOT ECHO2

Note

ECHO

When you connect your microphone to the MIC jack, you can give an echo effect to the sound from the microphones by pressing MIC ECHO.

ECHO 1

ECHO 2 OFF

Note

y If a microphone is not connected, “INSERT

MIC” appears in the display window.

y If you press VOCAL EFFECTS button on

ECHO mode, after backing up current ECHO, turn off ECHO mode and operate VOCAL EFFECTS mode. Press MIC ECHO again, after backing up

current VOCAL EFFECTS, operate ECHO mode.

Operating 35

LIGHTING

This function offers a party atmosphere by operating the lighting on the unit.

Press LIGHTING on the unit repeatedly.

PARTY

WATER FOREST (MY STYLE) OFF

Note

y Lighting function is available in all functions.

y Lighting mode retains its previous mode

when you first press LIGHTING on the unit, press again to change modes.

y If you want to use MY STYLE, you have to

y Do not look directly at the light emitting part

when the LIGHTING is turned on.

y Operation may be different depending on the

played music, connected device or setting status.

y If the illumination brightness is glaring, switch

on the room lights or turn off the LIGHTING of the unit.

y You can also turn off the light by pressing

and holding LIGHTING on the unit.

Sleep Timer Setting

Press SLEEP on the remote control repeatedly to select delay time between 10 and 180 minutes. After the delay time, the unit will be turned off.

To cancel the sleep function, press SLEEP on the remote control repeatedly until “OFF” appears.

Note

y You can check the remaining time before the

unit is turned off. Press SLEEP on the remote control to check or change the remaining

time.

y You can edit the remain time when the

remaining time or “DIMMER” is displayed.

Dimmer

Press SLEEP on the remote control once. The display window will be darkened by half.

To cancel it, press SLEEP on the remote control repeatedly until “OFF” appears.

Note

All the lighting turns off when Dimmer is being operated.

Operating

Operating36

Auto power down

This unit will turn itself off to save electricity in the case were the main unit is not connected to an external device and is not used for 15 minutes. The unit will also turns itself off after six hours if the main unit has been connected to another device using the analog inputs. Auto power down function is applied to only MAIN unit in case of WIRELESS PARTY LINK connection. In case of OTHER unit, Auto power down is available after disconnection OTHER unit and MAIN unit.

How to disconnect the wireless network

connection or the wireless device Turn off the unit by

pressing the power button for more than 5 seconds.

Operating

AUTO POWER On

This unit automatically turns on by an input source: LG TV, Bluetooth or Optical.

When you turn on your TV connected to this unit, this unit recognizes the input signal and selects the suitable function. You can hear the sound from the unit.

If you try to connect your Bluetooth device, this unit turns on and connects your Bluetooth device. You can play your music.

When you turn off this unit by pressing 1 on the unit for 5 seconds each time, you can turn on or off the AUTO POWER function.

Note

y Depending on the connected device, this

function may not operate.

y Depending on the connected device, the unit

turns on but Bluetooth function may not be connected.

y If you disconnect Bluetooth connection by

this unit, some Bluetooth devices try to connect to the unit continually. Therefore it is recommended to disconnect the connection before turning off the unit.

y If you try to connect to the “LG XBOOM” app,

Bluetooth function of this unit is turned on. (Android Only)

y If you turn on the unit using LG TV or

Bluetooth function, proper function of this unit is turned on.

y If you have already paired with this unit, this

unit can automatically turn on by an input source when this unit is turned off.

y If you turned off the unit directly, it cannot

be turned on automatically by AUTO POWER function. However the unit can be turned on by AUTO POWER function when an optical signal comes in after 5 seconds of no signal.

On Display Description

ON-AUTO POWER

OFF-AUTO POWER

AUTO POWER function is turned on.

AUTO POWER function is turned off.

Auto function change

This unit recognizes input signals such as Optical, Bluetooth and LG TV and then automatically changes to the suitable function.

When you try to connect Bluetooth device

When you try to connect your Bluetooth device to this unit, Bluetooth function is selected. Play your music on the Bluetooth device.

When optical signal comes in

When you turn on the external device connected to this unit by an optical cable, this unit changes the function to optical. You can hear the sound from your device.

When LG TV is connected

When you turn on your LG TV connected by LG Sound Sync (Wireless connection), this unit changes the function to LG TV. You can hear the sound from your TV.

Operating 37

Note

y If the Bluetooth connection lock function

is set, Bluetooth and LG TV connection will

be only available on Bluetooth and LG TV function.

y LG Sound Sync (Optical) changes the same

OPTICAL function.

Operating

Operating38

Setting the Clock

1. Turn the unit on.

2. Press and hold CLOCK on the remote control.

3. Select time mode by pressing remote control.

- AM 12:00 (for an AM and PM display) or 0:00

(for a 24 hour display)

4. Press SET on the remote control to confirm your selection.

5. Select the hours by pressing remote control.

6. Press SET on the remote control.

7. Select the minutes by pressing

Operating

remote control.

8. Press SET on the remote control.

Setting the Clock through “LG XBOOM” App

Install “LG XBOOM” app on your Android or iOS device. (Page 25-26)

Your unit’s clock will be automatically synchronized with your device by activating Bluetooth connection through “LG XBOOM” app.

C/V

on the

Using your unit as an alarm clock

1. Turn the unit on.

2. Press and hold ALARM on the remote control.

3. Press

the hours and minutes and press SET on the remote control to save.

4. Press

function and press SET on the remote control to save.

- Press

a preset number when you select tuner and then, press SET on the remote control. If there is no preset number, this step is skipped.

5. Press

the volume and press SET on the remote control to save.

y If you set the clock time, you can check the

time by pressing CLOCK on the remote control even when the unit is turned off.

y You can set alarm after you set the clock

time.

y If you set the clock time and alarm, you

can check the alarm setting information by pressing ALARM on the remote control even when the unit is turned off.

y You can select ALARM ON/OFF mode by

pressing ALARM on the remote control.

on the remote control to change

C/V

on the remote control to select

C/V

on the remote control to select

C/V

on the remote control to change

C/V

Note

Operating 39

WIRELESS PARTY LINK Connection

You can enjoy the sound by using two units. For enjoying WIRELESS PARTY LINK, you need to purchase another unit.

It is compatible with unit that supports WIRELESS PARTY LINK.

1. Press 3 TWIN on the unit. ROLE SELECT appears in the display window.

2. Press

Two units try to connect with each other.

3. When these units are successfully connected

TWIN on the unit to select MAIN or

OTHER.

unit: Selects MAIN.

unit: Selects OTHER.

each other, each of connected device names appears in the each unit.

Operating

Operating40

Operating

Note

y If you are using the LG Sound Sync or

OPTICAL connection, this function is not available.

- If you try to connect WIRELESS PARTY LINK when using LG Sound Sync function or OPTICAL function, “NOT SUPPORT” appears in the display window.

- If you change the function from any other to OPTICAL or connected LG Sound Sync /OPTICAL when using WIRELESS PARTY LINK, the WIRELESS PARTY LINK will be

released.

y You can use microphone or guitar in the

OTHER unit only. In case of OTHER unit, some functions are supported only.

y When WIRELESS PARTY LINK is

disconnected, OTHER unit is changed to BT

(Bluetooth) function.

y If the connection is failed, “FAILED” appears in

the display window.

y Mute function is synchronized with each

other.

y WIRELESS PARTY LINK connection will be

disconnected when you turn off the unit or press

3 TWIN on the unit.

y Sound of MAIN unit and OTHER unit may be

different depending on playback status or source.

Note

y Check the following information when

connecting to Bluetooth.

- You can connect only one Bluetooth device in the MAIN unit. You cannot connect Bluetooth device to the OTHER unit.

- WIRELESS PARTY LINK connection is only supported on Android devices. (WIRELESS PARTY LINK connection may not be supported depending on the connected device specications or OS.)

- Removable/detachable Bluetooth devices (ex. Dongle etc.) will not support WIRELESS PARTY LINK connection.

- When WIRELESS PARTY LINK is connected, Bluetooth connection is not available in status of deleting.

- If you connect WIRELESS PARTY LINK while you are playing connected Bluetooth device, it may be reconnected again, depending on phone specication.

Troubleshooting

General

Problem Cause & Solution

y Turn off the power of this unit and the connected external device (TV, Woofer,

DVD-player, Amplier, etc.) and turn them on again. The unit does not work properly.

No Power.

y Disconnect the power cord of this unit and the connected external device (TV,

Woofer, DVD-player, Amplier, etc.) and then try connecting again.

y Previous setting may not be saved when device power is shut off.

y The power cord is not plugged in. Plug in the power cord.

y Check whether electricity failed.

Check the condition by operating electronic devices using the same AC outlet.

Troubleshooting 41

No sound.

The unit does not start playback.

Radio stations cannot be tuned in properly.

y Check whether you select right function.

Press function button and check if you have selected the right function.

y An unplayable disc is inserted. Check the playable disc.

y No disc is inserted. Insert a disc.

y The disc is dirty. Clean the disc. (Page 45)

y The disc is inserted upside down.

Place the disc with the label or printed side facing upwards.

y The antenna is positioned or connected poorly.

Connect the antenna securely.

y The signal strength of the radio station is too weak.

Tune to the station manually.

y No stations have been preset or preset stations have been cleared (when tuning

by scanning preset channels).

Preset some radio stations, see page 27 for details.

Troubleshooting

Troubleshooting42

Problem Cause & Solution

y The remote control is too far from the unit.

Operate the remote control within about 7 m (23 feet).

The remote control does not work properly.

y There is an obstacle in the path of the remote control and the unit.

Remove the obstacle.

y The batteries in the remote control are exhausted.

Replace the batteries with new ones.

No speaker light.

LG Sound Sync does not work.

The AUTO POWER ON function does not work.

USB is not recognized.

Troubleshooting

y Check the light effects by pressing LIGHTING (Page 35).

y Check whether your LG TV supports LG Sound Sync.

y Check connection of LG Sound Sync.

y Check sound setting of your TV and this unit.

y Check connection of the external device such as TV or Bluetooth device.

y Depending on the connected device, this function may not operate.

y Format the USB device and connect it again. When formatting the USB device,

NOTES to release Demo mode

Problem Cause & Solution

Can not change input source with ‘F’ key such as

BT(Bluetooth), USB etc. and only DEMO mode is

showing in the display.

Remote Control does not work properly.

select the available le system. (Page 7).

y Press ‘DEMO’ Key on the unit for 15 seconds.

General specifications

General

Power requirements Refer to the main label on the unit.

Refer to the main label on the unit.

Power consumption

Dimensions (W x H x D) Approx. 330.0 mm x 785.0 mm x 344.0 mm Operating temperature 5 °C to 35 °C Operating humidity 5 % to 60 % RH

Inputs

Digital audio in (OPTICAL IN) 3.3 V (p-p), Optical jack x 1 Microphone (MIC IN) Sensitivity 20 mV (1 kHz), 6.3 mm jack x 1

Guitar (GUITAR IN) Sensitivity 190 mV (1 kHz), 6.3 mm jack x 1

Tuner

FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz

Networked standby : 0.5 W (If all network ports are activated.)

Appendix 43

System

Frequency Response 250 to 20,000 Hz Signal-to-noise ratio More than 80 dB Dynamic range More than 80 dB Bus Power Supply (USB) Available Digital Input Audio

Sampling Frequency Available Digital Input Audio format Dolby Audio, PCM

y Design and specications are subject to change without notice.

5 V 0 500 mA

32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz

Appendix

Appendix44

Trademarks and licenses

All other trademarks are trademarks of their respective owners.

Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the double-D symbol are trademarks of Dolby Laboratories.

The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by LG Electronics is under license.

Other trademarks and trade names are those of their respective owners

Appendix

“Made for iPhone,” and “Made for iPod” mean that an electronic accessory has been designed to connect specically to iPhone or iPod, respectively, and has been certied by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPhone or iPod may affect wireless performance.

Compatible iPhone/iPod

y The unit supports the models as follows ;

- iPhone XS Max

- iPhone XS

- iPhone XR

- iPhone X

- iPhone 8 Plus

- iPhone 8

- iPhone 7 Plus

- iPhone 7

- iPhone SE

- iPhone 6s Plus

- iPhone 6s

- iPhone 6 Plus

- iPhone 6

- iPhone 5s

- iPod touch (6th generation)

The system is compatible with the latest iOS. Depending on your iPhone/iPod software version, you may not control your iPhone/iPod from the unit.

Appendix 45

Maintenance

Notes on Discs

Handling Discs

Never stick paper or tape on the disc.

Storing Discs

After playing, store the disc in its case. Do not expose the disc to direct sunlight or sources of heat and never leave it in a parked car exposed to direct sunlight.

Cleaning Discs

Fingerprints and dust on the disc can cause poor picture quality and sound distortion. Before playing, clean the disc with a clean cloth. Wipe the disc from the center to out.

Do not use strong solvents such as alcohol, benzine, thinner, commercially available cleaners, or anti-static spray intended for old vinyl records.

Handling the Unit

When shipping the unit

Please save the original shipping carton and packing materials. If you need to ship the unit, for maximum protection, re-pack the unit as it was originally packed at the factory.

Keeping the exterior surfaces clean

Do not use volatile liquids such as insecticide spray near the unit. Wiping with strong pressure may damage the surface. Do not leave rubber or plastic products in contact with the unit for a long period of time.

Cleaning the unit

To clean the unit, use a soft, dry cloth. If the surfaces are extremely dirty, use a soft cloth lightly moistened with a mild detergent solution. Do not use strong solvents such as alcohol, benzine, or thinner, as these might damage the surface of the unit.

Maintaining the Unit

The unit is a high-tech, precision device. If the optical pick-up lens and disc drive parts are dirty or worn, the picture quality could be diminished. For details, please contact your nearest authorized service center.

Appendix

LG ON88 User guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Safety Information

Getting Started

Unique Features

Playable file Requirement

Music file requirement

Compatible USB Devices

USB device requirement

Remote control

Top panel

Front panel / Rear panel

AC Power Cord Connection

Connecting

Optional Equipment Connection

USB Connection

Antenna Connection

OPTICAL IN Connection

LG Sound Sync

Basic Operations

CD/USB Operations

Operating

Auto Play

Selecting a folder and an MP3/WMA file

Deleting a file/folder or format

Playback Effect

AUTO DJ

DJ PAD

Using BLUETOOTH® wireless technology

Listening to music stored on the Bluetooth devices

Using the LG XBOOM App

About “LG XBOOM” App

Install “LG XBOOM” App onto Your Bluetooth Device

Activate Bluetooth with “LG XBOOM” App

Radio Operations

Listening to the radio

Improving poor FM reception

Presetting the Radio Stations

Deleting all the saved stations

Sound adjustment

Setting the sound mode

Setting the USER EQ

Advanced Operations

JUKEBOX Playback

Other Operations

Turn off the sound temporarily

DRC (Dynamic range control)

CHILDSAFE Mode

DEMO

Resume stop

Using your TV remote control

Using Guitar

Using Microphone

LIGHTING

Sleep Timer Setting

Dimmer

Auto power down

AUTO POWER On

Auto function change

Setting the Clock

Setting the Clock through “LG XBOOM” App

Using your unit as an alarm clock

WIRELESS PARTY LINK Connection

Troubleshooting

General

Troubleshooting

NOTES to release Demo mode

General specifications

Appendix

Trademarks and licenses

Maintenance

Notes on Discs

Handling the Unit
