SIMPLE MANUAL
MFL71664332
Mini Hi-Fi
Audio
Please read this manual carefully before operating your set and retain it for
future reference.
To view the instructions of advanced features, visit http://www.lg.com and
then download Owner’s Manual. Some of the content in this manual may
differ from your unit.
MODEL
ON66
ENGLISH
2004_Rev02
ON5-F.DRUSLLK_SIM_ENG_MFL71664332.indd 1 2020-10-22 2:46:32
Copyright © 2020 LG Electronics Inc. All Rights Reserved.
www.lg.com
Top panel
n
l
k i
j
d
c
e
b
a
o
m
(Standby)
a 1
Turns the power on or off.
DEMO
b
In power off status, if you press DEMO, show demo mode.
USB 1 Port
c
You can play sound les by connecting the USB device.
Display window
d
USB 2 Port
e
You can play sound les by connecting the USB device.
F (Function)
f
Selects the function and input source.
LIGHTING
g
Selects the lighting mode.
TWIN
h 3
Connects two units for TWIN mode in WIRELESS PARTY LINK.
i C/V
N (Play/Pause)
- Starts or pauses playback.
- Selects stereo/mono.
(Skip/Search)
- Skips backward or forward.
- Searches for a section within a track/le.
- Selects the radio stations.
- Bluetooth connection lock (BT LOCK): Select the Bluetooth
function by pressing F repeatedly. And long press N to limit
Bluetooth connection to only BT and LG TV.
Z (Stop)
Stops playback or cancels DELETE function.
VOL (Volume) -/+
f
g
h
Adjusts speaker volume.
MIC (Microphone) / GUITAR -/+
Adjusts Microphone volume or Guitar volume.
(Auto Music Play)
j
Plays the audio currently playing by tagging the mobile (with
“LG XBOOM” App) to this unit. (Android Only)
VOICE CANCELLER
k
You can reduce the vocal tones during music playback from
various input sources.
B (Open/Close)
Opens and closes the disc tray.
CLUB, DRUM, USER (DJ PAD)
l
Selects CLUB, DRUM or USER sound effect to mix.
(If you want to use USER, you have to register a source with
“LG XBOOM” app. (Android Only))
1, 2, 3 (DJ PAD)
Press a desired sound pad.
MIC (Microphone) ECHO
m
Selects ECHO mode.
VOCAL EFFECTS
Selects various vocal effects mode.
KEY CHANGER (l/L)
Changes the key to suit your vocal range.
Remote sensor
n
SPECIAL EQ / BASS BLAST (or BASS BLAST+)
o
- Chooses special equalizer.
- Press and hold to select BASS (or BASS+) effect directly.
SEARCH
Moves to folder or file in selection mode.
OK
Selects a folder when searching a file.
USER EQ
Selects the equalizer created by your own.
Multi jog
- Searches a folder or a file.
- Turns clockwise or counterclockwise to control the USER EQ
level.
- Chooses special equalizer.
ON5-F.DRUSLLK_SIM_ENG_MFL71664332.indd 2 2020-10-22 2:46:34
a
g
b
Front panel / Rear panel
c
d
e
f
Disc tray
a
Lighting
b
Remote sensor
c
Controller App
Android iOS
Download the LG XBOOM App to your device.
GUITAR IN: Connect a guitar.
d
MIC (Microphone) IN: Connect a microphone.
e
ANTENNA (FM)
f
AC IN socket
g
LG Sound Sync (Wireless)
For more information, download the online owner’s
manual. http://www.lg.com
ON5-F.DRUSLLK_SIM_ENG_MFL71664332.indd 3 2020-10-22 2:46:35
Additional Information
(R03)
(R03)
Specifications
Power Requirements
Power Consumption
Dimensions (W x H x D)
Bus Power Supply (USB)
Design and specications are subject to change without
notice.
Refer to the main label on
the unit.
Refer to the main label on
the unit.
Networked standby : 0.5 W
(If all network ports are
activated.)
Approx. 330.0 mm x
685.0 mm x 344.0 mm
5 V 0 500 mA
Caution
y Connect the power cord to wall outlet directly if
possible. Or when you use an extension cable, it is
highly recommended to use an extension cable of 110
V / 15 A or 230 V / 15 A, otherwise the unit may not
operate properly because of the lack of power supply.
y Do not overload the extension cord with excessive
electrical load.
Note
y Do not look directly at the light emitting part when the
LIGHTING is turned on.
y If the illumination brightness is glaring, switch on the
room lights or turn off the LIGHTING of the unit.
How to disconnect the wireless network
connection or the wireless device
Turn off the unit by pressing the power button for more
than 5 seconds.
Replacement of battery
Declaration of Conformity
Hereby, LG Electronics declares that the radio equipment type MINI HI-
FI AUDIO is in compliance with Directive 2014/53/EU. The full text of
the EU declaration of conformity is available at the following internet
address:
http://www.lg.com/global/support/cedoc/cedoc#
For consideration of the user, this device should be installed and
operated with a minimum distance of 20 cm between the device
and the body.
