SIMPLE MANUAL
MFL71714710
DVD Mini
Hi-Fi Audio
ENGLISH DEUTSCH FRANÇAIS ITALIANO
Please read this manual carefully before operating your set and retain it for
future reference.
To view the instructions of advanced features, visit http://www.lg.com and
then download Owner’s Manual. Some of the content in this manual may
differ from your unit.
MODEL
ON2DN
2005_Rev01
ON2D-N.EFRALLK_SIM_ENG_MFL71714710.indd 1 2020-05-12 8:31:57
Copyright © 2020 LG Electronics Inc. All Rights Reserved.
www.lg.com
Top panel
a
(Standby)
a 1
Turns the power on or off.
USB Port
b
You can play MP3 les by connecting the USB device.
Display window
c
F (Function)
d
Selects the function and input source.
(Open/Close)
e B
Opens and closes the disc tray.
C/V
(Skip/Scan)
- Skips backward or forward.
- Scans for a section within a track/file/chapter.
f
b
c
d
e
Z (Stop)
Stops playback.
VOL (Volume) -/+
Adjusts speaker volume.
N (Play/Pause)
Starts or pauses playback.
MIC VOL (Microphone volume) -/+
f
Adjust microphone volume.
MIC (Microphone) ECHO -/+
Adjusts microphone echo level.
BASS -/+
Adjusts bass level.
EQ
Chooses sound impressions.
ON2D-N.EFRALLK_SIM_ENG_MFL71714710.indd 2 2020-05-12 8:31:58
c d
e f
g
a
b
Front panel / Rear panel
Remote sensor
a
Disc tray
b
HDMI Connection:
Connect with the Unit and TV using HDMI .
a
b
c
TV Connection1 Home Menu2
Connect the Unit to the TV using HDMI cable.
Set the input selector to HDMI on the TV.
Follow the instructions on the TV screen using
remote control.
Power cord
c
SERVICE ONLY: S/W download connector.
d
HDMI OUT TO TV: Connect to TV.
e
AUX IN (L/R): Connect an auxiliary device.
f
MIC (Microphone) 1/2: Connect a microphone.
g
Home menu appears on the TV screen. Enjoy various
functions on the player.
Home menu only appears on DVD.CD function.
ON2D-N.EFRALLK_SIM_ENG_MFL71714710.indd 3 2020-05-12 8:31:59
Additional Information
Specifications
Power Requirements
Power Consumption
Dimensions (W x H x D)
Bus Power Supply (USB)
Design and specications are subject to change without
notice.
Refer to the main label on
the unit.
Refer to the main label on
the unit.
Approx. 300.0 mm x
390.0 mm x 324.0 mm
5 V 0 500 mA
Declaration of Conformity
Hereby, LG Electronics declares that the radio equipment type
DVD Mini Hi-Fi Audio is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the
following internet address:
http://www.lg.com/global/support/cedoc/cedoc#
For consideration of the user, this device should be installed and
operated with a minimum distance of 20 cm between the device
and the body.
Frequency range Output power (Max.)
2402 to 2480 MHz 10 dBm
Replacement of battery
ON2D-N.EFRALLK_SIM_ENG_MFL71714710.indd 4 2020-05-12 8:31:59
