LG MCD112B, MCD112, MCD212 User Manual
MODEL : MCD112
MCD112B
MCD212
LGEAP_MCD112_ENG_MFL40387019
ENGLISH
As an ENERGY STA R®Partner, LG
has determined that this product
or product models meet the
ENERGY STA R®guidelines for
energy efficiency.
ENERGY STA R®is a U.S. registered mark.
2
MINI Hi-Fi SYSTEM ] USER GUIDE
There is so much your Hi-Fi system can do
Lull me to sleep
and wake me up
Go to page 9
Play CDs and
cassettes
Go to pages 6 & 7
Record from a CD,
AUX, USB or radio
to cassette
Contents
Setting up 3
About Player 4
About Remote control 5
Listening to CDs 6
Connecting your portable USB player
- OPTIONAL 6
Listening to the radio 7
Listen to cassette tapes 7
Recording 8
USER EQ 8
Setting the Clock 8
Use your player as an alarm clock 9
About MP3/WMA 9
Safety Precaution 10
Troubleshooting 11
Specifications 11
Before connecting, operating or adjusting this product, please read this instruction booklet
carefully and completely.
Go to page 8
Setting up
11
Connect the speaker cables to the player
Cables from the left-hand speaker connect to the terminal marked L
(left) + (plus) and - (minus). Cables from the right-hand speaker are
connected to the terminal marked R (right) + (plus) and - (minus).
To connect the cable to the player, press each of the four square
plastic finger pads on the rear of the player. The connector will open
ready to receive the cable.
22
Fit the AM loop aerial to its stand
Connect the AM loop aerial to the player.
33
Connect the FM aerial
The reception will be at its best when the two loose
ends of the aerial are in a straight line and horizontal.
44
Plug the power plug into a wall socket
Put the batteries in the remote
control
Make sure that the + (plus) and
- (minus) on the batteries match
those on the remote control.
MINI Hi-Fi SYSTEM ] USER GUIDE
3
ENGLISH
4
MINI Hi-Fi SYSTEM ] USER GUIDE
About Player
POWER
You can set up the unit into an economic
power save mode. In the power-on status,
press and hold 1/] (POWER) for about 3
seconds. To cancel power save mode, press
1/] (POWER).
ST./MONO
Press ST./MONO. This will change the tuner
from stereo to mono and usually improve the
reception.
Headphone jack
Connect a headphone plug ( 3.5 mm) into the
jack to listen to the sound through
headphones (not supplied).
MP3 OPT. (MP3 Optimizer)
This function is optimized for compressible
MP3 files so that it improves the bass sound.
DEMO
Press DEMO in power off state to
demonstrate the functions on the display window. To cancel it, press
11/]]
or DEMO again.
CD tray
XTS - PRO
This function creates the optimum sound for
you to play the original sound. Each time you
press XTS - PRO, “XTS -- PRO ON” or “XTS
-- PRO OFF” is displayed in turn. (The XTS
Pro function will not be operated when a
headphone has been connected.)
VOLUME
Control the volume when using any function.
USB connector - OPTIONAL
Connect a remote USB compatible player
here.
AUX
You can connect many other types of audio
or audio visual device to the system via the
auxiliary sockets (AUX IN) on the back of the
player.
D.SKIP
If more than one portable USB player is
connected to the system at the same time,
press D.SKIP to select one of them.
