LG LSC24971ST User Manual

ENGLISH

OWNER’S MANUAL

SXS REFRIGERATOR

Please read this owner's manual thoroughly before operating and keep it handy for reference at all times.

LSC24971ST LSSC243ST

P/No. : MFL59475225

www.lg.com

Model/Serial record

Basic safety precautions

Identification of parts

Where to install

Door removal

Mount the freezer and refrigerator compartment doors

Water supply installation

Water connection instruction guide

Height adjustment

Dimensions

Starting

Adjusting the temperatures and functions

Adjusting the temperatures and display

Operating the dispenser

Setting the functions

Shelf

Egg holder

Nano charcoal deodorizer

Fresh compartment

Push ’N Seal Crisper compartment

Freezer/Refrigerator basket

Dairy corner

How to exchange the water purifier filter

Location of foods

Storing foods

General information

Cleaning

Trouble shooting

It is normal…

Table of contents

Introduction

Installation

Operation

Suggestion on

food storage

Care and

maintenance

13 13

14 17

22 23 27 27

29 30 30 31

34 34 35 40

ENGLISH

Model/Serial record

The model and serial numbers are found on the inner case or back of refrigerator compartment of this unit. These numbers are unique to this unit and not available to others. You should record requested information here and retain this guide as a permanent record of your purchase. Staple your receipt here.

Date of purchase : Dealer purchased from : Dealer address : Dealer phone no. : Model no. : Serial no. :

Introduction

Basic safety precautions

This guide contains many important safety messages. Always read and obey all safety messages.

This is the safety alert symbol. It alerts you to safety messages that inform you of hazards that can kill or hurt you or others or cause damage to the product. All safety messages will be preceded by the safety alert symbol and the hazard signal word DANGER, WARNING, or CAUTION. These words mean:

All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell you what can happen if the instructions are not followed.

DANGER

You will be killed or seriously injured if you don’t follow instructions.

WARNING

You can be killed or seriously injured if you don’t follow instructions.

CAUTION

Indicates an imminently hazardous situation which, if not avoided, may result in minor or moderate injury, or product damage only.

ENGLISH

Introduction

WARNING

To reduce the risk of fire, electric shock, or injury to persons when using your product, basic safety precautions should be followed, including the following.

Read all instructions before using this appliance.

1. When connecting the power

The dedicated outlet should be used.

• Using several devices at one outlet may cause a fire.

Prevent the power cord from being squeezed or imprinted if the refrigerator is pushed in after the power plug is extracted during the installation.

When moving your appliance away from the wall, be careful not to roll over the power cord or to damage it in any way.

It becomes the cause of fire or electric shock.

Do not allow the power cord bent or pressed by the heavy object to be damaged.

It may damage the power cord to cause fire or electric shock.

Do not allow the power plug to face upward or to be squeezed at the back of the refrigerator.

Water may be flown into or the plug may be damaged, which causes fire or electric shock.

Do not extend or modify the length of the power plug.

It causes electric shock or fire by the electric damage of the power cord or others.

Unplug the power cord when cleaning or handling the refrigerator.

• It may cause electric shock or injury.

Introduction

Remove water or dust from the power plug and insert it with the ends of the pins securely connected.

Dust, water or unstable connection may cause a fire or electric shock.

Unplug the power cord from the power outlet for cleaning or other requirements.

It may cause electric shock or injury.

Make sure of grounding. Consult a qualified electrician or service person if the

grounding instructions are not completely understood, or if you have doubts on whether the appliance is properly grounded.

The incorrect grounding may cause breakdown and electric shock.

Only plug the power cord into a single circuit properly grounded outlet.

It may cause a fire.

Ground

Wire

Copper

Flat

More than

30 inches

When the power cord or the power plug is damaged or the holes of the outlet are loosed, do not use them.

It may cause electric shock or short circuit to make fire.

Wait for 5 minutes or longer when reconnecting the plug.

It may cause the operation of the freezer to fail.

If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.

Pull out the power plug not by grasping the cord but the plug of its end.

It may cause electric shock or short circuit to fire.

Do not pull out the cord or touch the power plug with wet hands.

It may cause electric shock or injury.

ENGLISH

Introduction

2. When using the refrigerator

Do not place the heavy object or the dangerous object (container with liquid) on the refrigerator.

It may be dropped to cause injury, fire or electric shock when opening or closing the door.

Do not install the refrigerator in the wet place or the place which water or rain splashes.

Deterioration of insulation of electric parts may cause electric leakage.

Do not allow children to hang on the refrigerator doors or shelves.

It may cause the refrigerator to tip.

Prevent children from entering the product.

It may endanger the life of a child if the child enters the refrigerator.

Opening and closing the door of the refrigerator vigorously may cause the stored food in the refrigerator basket to fall by shock and hurt the foot, so take precautions.

Do not use or store inflammable materials ether, benzene, alcohol, medicine, LP gas, spray or cosmetics near or in the refrigerator.

It may cause explosion or fire.

Benzene



Ether

Thinner

Do not use drier to dry the inside, nor light a candle to remove odor.

It may cause explosion or fire.

Introduction

Do not put heavy things on the Home Bar. (Only for the models with the Home Bar)

Falling objects may hurt people.

Use the submerged refrigerator after checking it.

It may cause electric shock or fire.

In case of thunder and lightning, or not in use for a long period of time, detach the power plug.

There is a danger of electric shock or fire.

Do not place flower vase, cup, cosmetics, medicine or any container with water on the refrigerator.

It may cause fire, electric shock or injury by falling.

Install in places away from the fire such as the place where flammable gas is leaked.

It may cause fire.

Do not use the combustible spray near the refrigerator.

It may cause fire.

Do not spray water at the outside or the inside of the refrigerator or do not clean it with benzene or thinner.

Deterioration of insulation of electric parts may cause electric shock or fire.

ThinnerThinner

When any strange smell or smoke is detected from the refrigerator, disconnect the power plug immediately and contact to the service center.

It may cause fire.

Service

center

ENGLISH

Introduction

Do not use the refrigerator for non-domestic purpose (storing medicine or testing material, using at the ship, etc.).

It may cause an unexpected risk such as fire, electric shock, deterioration of stored material or chemical reaction.

When disposing the refrigerator, remove the packing materials from the door or take off the doors but leave the shelves in place so that children may not easily climb inside.

It may cause to lock out the child.

This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance.

Install the refrigerator on the solid and level floor.

Installing it on the unstable place may cause death by tipping the refrigerator when opening or closing the door.

Do not insert the hands or the metal stick into the exit of cool air, the cover, the bottom of the refrigerator, the heatproof grill (exhaust hole) at the backside.

It may cause electric shock or injury.

Do not allow any person except the qualified engineer to disassemble, repair or alter the refrigerator.

It may cause injury, electric shock or fire.

CAUTION

Violating this direction may cause injury or damage house or furniture. Always be careful, please.

Do not insert the hands into the ice bucket or the ice dispenser.

Operating the ice maker may cause injury.

Introduction

Do not touch food or containers at the freezer with wet hands.

It may cause frostbite.

Do not put ice in thin crystal cup or ceramic ware.

It may break cup or ceramic ware to cause injury.

When the electricity is off, remove ice from the ice bucket (only for the model with the dispenser).

The long-time power failure may thaw ice to damage the floor. When the long-time power failure is expected, remove ice from the ice bucket.

Supply the automatic ice maker with drinkable water only (only for the model with the dispenser).

Otherwise, it may cause any risk.

Do not remove the cover of the automatic ice maker. (Only for the models with automatic ice maker)

The operation mechanic parts of the ice maker may hurt people.

Do not place the food in disorder inside the refrigerator.

The food may fall during opening and closing the door of the refrigerator and hurt people.

Drinkable

water

Do not put bottle in the freezer.

It may freeze the contents to break the bottle to cause injury.

Do not insert the hands into the bottom of the refrigerator.

The iron plate of the bottom may cause injury.

ENGLISH

Introduction

Identification of parts

•

Parts, features, and options vary by model. Your model may not include every option.

NOTE

Freezer Compartment

Refrigerator Compartment

Dairy corner

LED Lamp

Automatic

Icemaker

Shelf

Door rack

Drawer (2)

Door rack

Lower cover

Shelf

Nano charcoal deodorizer Egg holder

LED Lamp

Filter

Door Rack

Fresh compartment

Push ’N Seal Crisper compartment

Because opening or closing the door of the refrigerator may cause injury to the person around it, be careful, please.

Opening or closing the door may cause feet or hands to be caught in the chink in door or the child to be get hurt by the corner.

Do not put any living animal in the refrigerator.

Installation

Strong

and even floor

A proper

distance from

adjacent items

Where water

supply can be

easily connected

in a dry place

Where it is free

from heat

To ensure proper air circulation around the refrigerator -freezer, please maintain sufficient space on both the sides as well as top and maintain at least 2 inches (5 cm) from the rear wall.

Select a place where a water supply can be easily connected between the automatic ice maker and dispenser. Installing the refrigerator in a wet or damp area may cause rust and may be an electrical hazard.

If this refrigerator is installed where the ambient temperature is high, the freezing capacity is deteriorated and the cost of electricity used increases.

Where to install

Unstable installation may cause vibration and noise. If the floor to install the refrigerator on is not even, make the refrigerator level by rotating the height adjusting screw. Carpet or floor covering on which a refrigerator is installed may be discolored by heat from the bottom of the refrigerator. Do not allow carpet or flooring to block airflow under the refrigerator.

•

Install the refrigerator at a place where the ambient temperature is 41˚F~110˚F (5˚C ~ 43˚C). Ambient temperature outside this range may cause product malfunction. Also, the tube between the dispenser and automatic ice maker may freeze.

NOTE

Bottom Pad

Height

More than

2"(5 cm)

to back

ENGLISH

Installation

Door removal

Electric Shock Hazard

Disconnect electrical supply to refrigerator before installing. Failure to do so could result in death or serious injury.

If your access door is too narrow for the refrigerator to pass through, remove the refrigerator door and pass the refrigerator laterally.

Remove 2 screws holding the lower cover in place. Pull up the feed water tube while pressing area  shown in the figure to the right.

Remove lower

cover and

then feed water

tube

Remove the

freezer

compartment

door

Remove the

refrigerator

compartment

door

1) Removing the hinge cover by loosening the screws. Separate all connection wires except for the earth line after.

2) Remove the keeper by rotating it counter clockwise () and then lifting the upper hinge up ().

3) Remove the freezer compartment door by lifting it upward. This time, the door should be lifted enough for the feed water pipe tube to be completely pulled out.

1) Loosen the hinge cover screws and remove the cover. Remove connection wire, if any, except for the earth line.

2) Remove keeper by rotating it clockwise () and then remove the upper hinge by lifting it up ( ).

3) Remove the refrigerator compartment door by lifting it up.

•

If a tube end is deformed or abraded, cut the part away.

NOTE

•

When removing the upper hinge, be careful that the door does not fall forwards .

NOTE

•

Move the freezer compartment door passing through the access door and lay it down, but be careful not to damage the feed water pipe tube.

NOTE

Lower cover

Lower hinge

Keeper

Feed water tube

Connection wires

Hinge cover

Upper hinge

Keeper

Upper hinge

Ground Line

Upper hinge

Connection

wires

WARNING

Installation

Pass the refrigerator laterally through the access door as shown in the right figure.

Pass the

refrigerator

M a x

R Z

E M P R E F T E M P

M i n

M a x

Mount the freezer and refrigerator compartment doors

Water supply installation



Automatic icemaker operation needs water pressure of 21~121 psi (1.5~8.5 kgf/cm2) (That is, a paper cup (6 oz. or 180 cc) will be fully filled within 3 seconds.)



If water pressure does not reach the rating 21 psi (1.5 kgf/cm2) or below, it is necessary to purchase a separate pressure pump for normal automatic icemaking and cool water feed.



Keep the total length of the feed water pipe tube within 26 ft (8 m). Be careful for the tube to avoid being kinked. If the tube is 26 ft (8 m) or longer it may cause trouble in water feed.



Install the water supply line where it will not be affected by heat.

Mount them in the reverse sequence of removal after they pass through the access door.

Before

installation
