LG LG L322DL User Guide

USER GUIDE
ENGLISH
LG L322DL
Copyright ©2019 LG Electronics Inc. All rights reserved.
MFL71459901 (1.1)
www.lg.com
About this user guide
• Always use genuine LG accessories. The supplied items are designed
only for this device and may not be compatible with other devices.
• Descriptions are based on the device default settings.
• Default apps on the device are subject to updates, and support for
these apps may be withdrawn without prior notice. If you have any questions about an app provided with the device, please contact an LG Service Center. For user-installed apps, please contact the relevant service provider.
• Modifying the device’s operating system or installing software from
unofficial sources may damage the device and lead to data corruption or data loss. Such actions will violate your LG license agreement and void your warranty.
• Some content and illustrations may differ from your device, depending
on the area, service provider, software version, or OS version, and are subject to change without prior notice.
• Software, audio, wallpaper, images, and other media supplied with
your device are licensed for limited use. If you extract and use these materials for commercial or other purposes, you may be infringing copyright laws. As a user, you are fully responsible for the illegal use of media.
• Additional charges may incur for data services, such as messaging,
uploading, downloading, auto-syncing and location services. To avoid additional charges, select a data plan suitable to your needs. Contact your service provider to obtain additional details.
1
Instructional notices
WARNING: Situations that could cause injury to the user and third
CAUTION: Situations that may cause minor injury or damage to the
NOTE: Notices or additional information.
parties.
device.
2
Table of contents
01
Custom-designed Features
6 Camera features
7 Gallery features
10 Google Assistant
11 Multi-tasking feature
02
Basic Functions
14 Product components and
accessories
15 Parts overview
18 Turning the power on or off
19 Installing the SIM card
21 Inserting the memory card
22 Removing the memory card
22 Battery
24 Touch screen
27 Home screen
36 Screen lock
39 Memory card encryption
40 Taking screenshots
41 Entering text
49 Do not disturb
03
Useful Apps
51 Installing and uninstalling apps
52 App trash
53 App Shortcuts
54 Phone
59 Messages
60 Camera
70 Gallery
73 Chrome
74 Google apps
75 Contacts
77 QuickMemo+
80 Clock
81 Calendar
82 Music
83 Calculator
83 Email
3
84 FM Radio
84 File Manager
84 Smart cleaning
04
Settings
86 Settings
86 Network & internet
93 Connected devices
96 Sound
97 Display
98 Lock screen & security
100 Extensions
101 Apps & notifications
101 Battery
102 Storage
102 Accounts
103 Accessibility
105 Google
105 System
05
Appendix
109 LG Language Settings
109 Phone software update
111 Anti-Theft Guide
112 Open Source Software Notice
Information
112 Regulatory information
(FCC ID number, etc.)
112 Trademarks
113 FAQ
06
For Your Safety
07
Limited Warranty – USA
4Table of contents
01
Custom-designed Features
Camera features
Portrait
You can take a sharp portrait by applying the camera lens blur effect.
Tap , switch to the front camera, then tap Portrait.
1
When Portrait is available appears on the screen, tap to take a
2
photo.
• To adjust blur strength, drag the slide bar up, down (depending on
the orientation of the phone).
• This feature is not available if the surroundings are too dark.
• After applying this feature, touch and hold the the desired position on
the preview screen to automatically apply the exposure value and focus. In this case, the Portrait feature and blur strength stay the same.
Flash Jump-Cut
You can create a GIF by taking photos at three second intervals.
Tap , then tap MODE Flash Jump-Cut .
1
Tap to set how many cuts you want to take.
2
Tap to take photos.
3
Custom-designed Features 6
Gallery features
Creating a movie
You can create a new movie by putting images and videos together.
Tap , select an album, then tap Create movie.
1
Select images or videos for your movie and tap NEXT.
2
Edit the selected images and videos and then tap SAVE.
3
Deleting files
You can select images or videos to delete from your video by tapping at the top right corner of its thumbnail.
Custom-designed Features 7
Adding files
You can select images or videos to add after tapping at the bottom of the screen. You can also select the images or videos you have already previously added.
• Touch and hold a file, and then tap another file for multiple selection.
Rearranging files
To rearrange the images and videos, touch and hold the file you want to move, then dragging it to the desired location.
Adding file effects
Tap to add a theme or background music, or change the font.
Resetting the movie edits
You can reset the edits made to the movie (e.g. play time) by tapping .
Previewing a file
Check your new video before saving it by tapping . After the playback time elapses, the next file is played automatically.
• A maximum of 50 images and videos can be used to create a video.
• The playback time for an image is 3 seconds by default and it cannot be
changed. Videos can be trimmed down to a minimum of 1 second.
• This feature may not support some image or video formats.
Custom-designed Features 8
Making a GIF
You can easily make a GIF file using recorded video.
At the desired starting point while watching a video, tap .
1
Select the length of the GIF you want to create.
2
• GIF is generated for the time selected from the current time.
• For videos less than 5 seconds, GIF images are automatically
generated for the remaining time.
• You may use this feature solely for creative purposes. The use of this
feature involving infringement of any other person’s rights, such as copyright or defamatory or offensive statements, may be subject to civil, criminal, or administrative liabilities and/or penalties under applicable laws. You shall not copy, reproduce, distribute, or otherwise make illegal use of any copyrighted materials without permission of the rightful owner or copyright holder. To the fullest extent permitted by applicable law, LG Electronics disclaims all expressed and implied warranties as well as liabilities associated thereto.
Custom-designed Features 9
Google Assistant
You can manage tasks, plan your day, get answers, and much more.
• To use this feature, first connect to the network and sign in to your
Google account.
Launching Google Assistant
Press and hold from the Home screen to launch Google Assistant.
1
Tap GET STARTED.
2
Follow the on-screen instructions to configure the voice settings.
3
• The device saves your voice data for recognition.
Launching Google Assistant with your voice
Say “Ok Google” when the screen is turned off or locked.
1
Say a command or question when
2
the screen.
Launching Google Assistant from the Home screen
Touch and hold from the Home screen.
1
Say a command or question when
2
the screen.
Hi, how can I help?*
Hi, how can I help?*
appears on
appears on
• Voice recognition accuracy may decrease if you speak with an unclear
voice or in a noisy place. When you use the voice recognition feature, increase its accuracy by speaking with a clear voice in a quiet place.
* The prompt message may vary depending on the software version.
Custom-designed Features 10
Multi-tasking feature
Multi-Window
You can use two apps at the same time by separating the screen into multiple windows.
Tap from the Home touch buttons.
1
• Recently-used apps appear.
Tap at the top of the desired app to use the Multi-Window feature.
2
• The selected app appears at the top half of the screen.
You can also access this feature by doing the following:
Touch and hold while using an app.
1
• Recently-used apps appear on the split screen.
Tap at the top of the desired app to use the Multi-Window feature.
2
• The selected app appears at the bottom of the screen.
Custom-designed Features 11
• To deactivate the Multi-Window feature, touch and hold on the
Home touch button.
• To adjust the size of the split screen, drag
screen.
• The Multi-Window feature is not supported by some LG apps and apps
downloaded from Play Store.
at the center of the
Overview screen
The Overview screen provides a preview of your recently-used apps. To view the list of recently-used apps, tap
• Touch and hold an app and drag it to the top of the screen to start the
app with the Multi-Window feature. You can also tap each app preview.
on the Home touch buttons.
at the top of
Custom-designed Features 12
02
Basic Functions
Product components and accessories
The following items are included with your device.
• Device
• USB cable
• Charger
• The items supplied with the device and any available accessories may
vary depending on the area and service provider.
• Always use genuine LG Electronics accessories. Using accessories made
by other manufacturers may affect your device's call performance or cause malfunctions. This may not be covered by LG's repair service.
• Some of the device parts are made of tempered glass. If you drop your
device on a hard surface or subject it to severe impact, the tempered glass may be damaged. If this happens, stop using your device immediately and contact an LG Customer Service Center.
• If any of these basic items are missing, contact the dealer from which
you purchased your device.
• To purchase additional basic items, contact an LG Customer Service
Center.
• To purchase optional items, contact an LG Customer Service Center for
available dealers.
• Some items in the product box are subject to change without notice.
• The appearance and specifications of your device are subject to change
without notice.
• Device specifications may vary depending on the area or service provider.
• Be sure to use authentic accessories provided by LG Electronics. Using
third-party accessories may damage the device or cause malfunctions.
• Quick Start Guide
• Ejection pin
Basic Functions 14
Parts overview
Front camera lens
Volume keys (+/-)
Google Assistant keys
Nano-SIM/Memory card
Stereo headset jack Charger/USB cable port
tray
Flash
Proximity/Ambient light sensor
Earpiece
Power/Lock key
Touch screen
Rear camera lens
Speaker
Microphone
Basic Functions 15
Do NOT attempt to remove the back cover.
This device has a non-removable battery. Do not attempt to remove the back cover. Doing so may severely damage the battery and device, which could cause overheating, fire, and injury.
• Press and hold the volume down key and Power/Lock key at the same
time for a second to take a screenshot.
• Proximity/Ambient light sensor
- Proximity sensor: During a call, the proximity sensor turns off the screen and disables touch functionality when the device is in close proximity to the human body. It turns the screen back on and enables touch functionality when the device is outside a specific range.
- Ambient light sensor: The ambient light sensor analyzes the ambient light intensity when the auto-brightness control mode is turned on.
• Volume keys
- Adjust the volume for ringtones, calls or notifications.
- While using the Camera, gently press a Volume key to take a photo. To take continuous photos, press and hold the Volume key.
- Press the Volume Down key twice to launch the Camera app when the screen is locked or turned off. Press the Volume Up key twice to launch Capture+.
• Power/Lock key
- Briefly press the key when you want to turn the screen on or off.
- Press and hold the key when you want to select a power control option.
Basic Functions 16
• Some functions may be restricted for access, depending on the device
Good example
Bad example
specifications.
• Do not put heavy objects on the device or sit on it. Doing so may
damage the touch screen.
• Screen-protective film or accessories may interfere with the proximity
sensor.
• If your device is wet or is being used in a humid place, the touch screen
or buttons may not function properly.
• Google Assistant key
- Your device has Google Assistant built in. Find answers and get things done while on-the-go. To get started, just tap the Google Assistant key on the side of the phone.
- Activate Google assistant. See
Google Assistant
for details.
Hold the device correctly as shown below. If you cover the microphone hole with a hand, finger, or protective case while using the device, you may sound unclear during a call.
Basic Functions 17
Do not cover the microphone.Microphone
Turning the power on or off
Turning the power on
When the power is turned off, press and hold the Power/Lock key.
• When the device is turned on for the first time, initial configuration
takes place. The first booting time for the smart phone may be longer than usual.
Turning the power off
Press and hold the Power/Lock key, then select Power off.
Restarting the device
When the device is not working properly or does not respond, restart it by following the instructions below.
Press and hold the Power/Lock key and the Volume Down key at the
1
same time until the power is turned off.
When the device is restarted, release the key.
2
Power control options
Press and hold the Power/Lock key, then select an option.
• Power off: Turn the device off.
• Power off and restart: Restart the device.
• Turn on Airplane mode: Block telecommunication-related functions,
including making phone calls, messaging and browsing the Internet. Other functions remain available.
Basic Functions 18
Installing the SIM card
Insert the SIM card provided by your mobile service provider to start using your device.
• Be careful with the ejection pin since it has a sharp edge.
• In order for the water-resistant and dust-resistant features to work
effectively, the card tray must be inserted correctly.
Insert the ejection pin into the hole on the card tray.
1
Pull out the card tray.
2
Basic Functions 19
Put the SIM card on the card tray with the gold-colored contacts
3
facing downwards.
SIM card
Memory card (optional-sold separately)
Insert the card tray back into the slot.
4
• This device supports only Nano SIM cards.
• For problem-free performance, it is recommended to use the device
with the correct type of SIM card.
• If you insert the card tray into your device while the card tray is wet,
your device may be damaged. Always make sure the card tray is dry.
Precautions when using the SIM card
• Do not lose your SIM card. LG is not responsible for damage and other
issues caused by loss or transfer of a SIM card.
• Be careful not to damage the SIM card when you insert or remove it.
Basic Functions 20
Inserting the memory card
Insert the memory card into your device. The device can support up to a 2 TB microSD card. Depending on the
memory card manufacturer and type, some memory card may not be compatible with your device.
Insert the ejection pin into the hole on the card tray.
1
Pull out the card tray.
2
Put the memory card on the card tray with the gold-colored contacts
3
facing downwards.
Memory card (optional-sold separately)
SIM card
Insert the card tray back into the slot.
4
• Some memory cards may not be fully compatible with the device. If you
use an incompatible card, it may damage the device or the memory card, or corrupt the data stored in it.
• Frequent writing and erasing of data may shorten the memory card
lifespan.
Basic Functions 21
Removing the memory card
Unmount the memory card before removing it for safety.
Tap Settings Storage .
1
Insert the ejection pin into the hole in the card tray and then pull out
2
the card tray from the device.
Remove the memory card from the card tray.
3
Insert the card tray back into the slot.
4
• Do not remove the memory card while the device is transferring or
accessing information. This may cause data to be lost or corrupted, or may damage the memory card or the device. LG is not responsible for losses that result from the abuse or improper use of memory cards, including the loss of data.
Battery
Charging the battery
Before using the device, fully charge the battery.
Charging cable terminal
USB port
Basic Functions 22
USB cable
• Do not charge while the device or charging cable is wet or contains
moisture. This can cause fire, electric shock, injury or damage to device. If there is moisture, stop using the device immediately and remove the moisture completely.
• Make sure to use the USB cable provided with your device.
• Make sure to use an LG-approved charger and charging cable. Charging
the battery with a third-party charger may cause the battery to explode or may damage the device.
• Your device has an internal rechargeable battery. For your safety, do not
remove the embedded battery.
• Using the device when it is charging may cause electric shock. To use the
device, stop charging it.
• Remove the charger from the power socket after the device is fully
charged. This prevents unnecessary power consumption.
• Another way to charge the battery is by connecting a USB cable
between the device and a desktop or laptop computer. This may take a longer time than plugging the adapter to a wall outlet.
• Do not charge the battery by using a USB hub that is unable to maintain
the rated voltage. Charging may fail or unintentionally stop.
Precautions when using the device
• Make sure to use the USB cable provided; do not use third party USB
cables or chargers with your device. The LG limited warranty does not cover the use of third party accessories.
• Failure to follow the instructions in this guide and improper use may
damage the device.
Basic Functions 23
Using the battery efficiently
Battery lifespan may decrease if you keep many apps and functions running simultaneously and continuously.
Stop apps and functions from running in the background to increase battery life.
To minimize battery consumption, follow these tips:
• Turn off the Bluetooth® or Wi-Fi network function when not using
them.
• Set the screen timeout to as short a time as possible.
• Minimize the screen brightness.
• Set a screen lock when the device is not in use.
• Check the battery level while using any downloaded apps.
Touch screen
You can familiarize yourself with how to control your device by using touch screen gestures.
Tapping
Lightly tap with your fingertip to select or run an app or option.
Basic Functions 24
Touching and holding
Touch and hold for several seconds to display a menu with available options.
Double-tapping
Tap the screen twice quickly to zoom in or out on a specific app.
Dragging
Touch and hold an item, such as an app or widget, then move your finger to a desired location in a controlled motion. You can use this gesture to move an item.
Basic Functions 25
Swiping
Touch the screen with your finger and move it quickly without pausing. You can use this gesture to scroll through a list, a web page, photos, screens, and more.
Pinching and spreading
Pinch two fingers to zoom out such as on a photo or map. To zoom in, spread your fingers apart.
• Do not expose the touch screen to excessive physical shock. You might
damage the touch sensor.
Basic Functions 26
• A touch screen failure may occur if you use the device near a magnetic,
metallic or conductive material.
• If you use the device under bright lights, such as direct sunlight, the
screen may not be visible, depending on your position. Use the device in a shady location or a location with an ambient light that is not too bright and bright enough to read books.
• Do not press the screen with excessive force.
• Gently tap with your fingertip on the option you want.
• The touch control may not work properly if you tap while wearing a
glove or by using the tip of your fingernail.
• Touch control may not work properly if the screen is moist or wet.
• The touch screen may not function properly if a screen-protective film
or accessory purchased from a third party store is attached to the device.
• Displaying a static image for extended periods of time may result in
after-images or screen burn-in. Turn off the screen or avoid displaying the same image for a long time when you do not use the device.
Home screen
Home screen overview
The Home screen is the starting point for accessing various functions and apps on your device. Tap screen.
You can manage all apps and widgets on the Home screen. Swipe the screen left or right to view all installed apps at a glance.
on any screen to directly go to the Home
Basic Functions 27
Home screen layout
Status bar
You can view all apps and organize widgets and folders on the Home screen.
Weather widget
Google search widget
Page icon
Home touch buttons
• The Home screen may differ depending on the manufacturer policy, user
settings, software version or service provider.
• Status bar: View status icons, the time and the battery level.
• Weather widget: View the weather information or time for a specific
area.
• Google search widget: Perform a Google search by inputting spoken
or written keywords.
• Page icon: Display the total number of Home screen canvases. You
can tap the desired page icon to go to the page. The icon reflecting the current canvas will be highlighted.
Quick access area
Basic Functions 28
• Quick access area: Fix main apps at the bottom of the screen so that
they can be accessed from any Home screen canvas.
• Home touch buttons
: Return to the previous screen. Close the keypad or pop-up
­windows.
: Tap to go to the Home screen. To launch Google Assistant, touch
­and hold.
: Tap to view a list of recently used apps or run an app from the
­list. To delete all the recently used apps, tap CLEAR ALL. To use two apps at the same time with the Multi-Window feature, touch and hold the button while using an app.
Editing the Home touch buttons
You can rearrange the Home touch buttons or add frequently used functions to the Home touch buttons area.
Settings Display Home touch buttons Button
Tap combination and customize the settings.
• Several functions, including QSlide, Notification and Capture+, are
provided. A maximum of two additional items can be added.
Basic Functions 29
Loading...
+ 119 hidden pages
