LG KS20 User Manual
K S20
U S E R G U I D E
USER GUIDE
LG KS20
Some of contents in this manual may differ
from your phone depending on the software
of the phone or your service provider.
EN GLI SH
www.lgmobile.com
P/N : MMBB0245574(1.0)
W
KS20 User Guide
- English
Windows Mobile Pocket PC. All rights for this document are reserved
by LG Electronics. Copying, modifying and distributing this document
This document is the user guide for the LG KS20
without the consent of LG Electronics are prohibited.
2
CONTENTS
INTRODUCTION 8
FOR YOUR SAFETY
9
GUIDELINES FOR SAFE AND
EFFICIENT USE
10
KS20 FEATURES
Part of the phone
Cautions for touch keys 20
GETTING STARTED 22
Installing the USIM card and battery
Charging the batter y
Disconnecting the charger
How to use a microSD memor y card
Memory card formatting 29
Turn the device on and off
Reset the device 30
Calibrate the Device 31
CONTENT S
Manage screen settings 32
SCREEN INFORMATION 35
The Today Screen
Customising the Today screen
Default MS Today Screen
Indicators
17
Using the Start Menu 39
Editing Today screen
Program Indicators
ENTERING AND SEARCHING
INFORMATION
Overview of Input Panel
24
Using the Keyboard
26
Using the standard on-screen Keyboard 43
27
Using Letter Recognizer
Using Block Recognizer 44
Enter text using Block Recognizer
Using Transcriber 45
Transcriber Gestures 46
The Transcriber toolbar 48
42
36
37
3
Drawing and Writing on the Screen 49
Recording a Note
Searching Information 52
51
GENERAL FUNCTIONS 54
Adjust the device volume
Making a Call 55
Receiving a Call 57
In-call Options
Additional Dialing Information 59
SYNCHRONIZING YOUR DEVICE
Using ActiveSync
Setting up Windows VistaTM 62
Synchronizing Information 64
Synchronizing via Bluetooth 67
Synchronizing Music, Video, and Pictures
68
60
COMMUNICATIONS 70
Messages
To set up an e-mail account
New Text Message 71
New MMS Messages 72
To start MMS message
Messaging Message 73
Note Downloading messages 74
To reply to or forward a message
Phone 76
Make a call
Ending a call
Make a call from History
Make a call using Speed dial
Call logs 78
Save to Contacts
View Note
Delete
Send Text Message...
Send Multimedia Message
Filter 79
77
CONTENT S
4
CONTENTS
Contacts 79
Overview of contacts 80
To create a contact
To change contact information 81
To work with the contact list
To copy SIM contact to Contacts 82
To find a contact
MULTIMEDIA 84
Camera
Configuring Camera mode 85
Video Camera 86
Frame shot 87
Windows Media
Playback screen 89
Now Playing screen
Library screen 90
FM Radio 91
CONTENT S
Pictures & Videos 92
To copy a picture or video clip to your device
93
To view pictures
To play videos with audio 94
To sort pictures and video clips
To delete a picture or video clip
To edit a picture or video clip 95
To set a picture as the Today screen
background
To send pictures and video clips via e-mail 96
To send pictures and video clips via
Bluetooth
To assign pictures to contacts 97
To use advance options
Mobile Java 98
Games 99
PROGRAMS 100
Internet Explorer
Word Mobile 102
To create a file
To get more help about Word Mobile 104
5
Excel Mobile 105
Unsuppor ted features in Excel Mobile
PowerPoint Mobile 109
To start a slide show presentation
To stop a slide show 11
To navigate between slides
File Explorer 111
Messenger
To start Windows Live Messenger 113
To sign in or out
To add or delete contacts
To send an instant message
To block or unblock contacts 114
To check your own Messenger status
To change your display name
To get more help about Windows Live
Messenger
Note
Entering information in Notes 115
To set the default input mode for Notes
To create a note
Tasks 116
To create a task
To change the priority of a task
To set a default reminder for all new tasks
To show start and due dates in the task list
0
To locate a task 118
PSNotes
New document 119
Writing text
To change the font 120
Making drawings
Inserting images
Inserting Multimedia
To cut/copy an entire area 121
To change the zoom level
To use the personal dictionary
Auto Profile 122
Internet Share 123
117
CONTENT S
6
CONTENTS
SETTINGS 124
Phone setting
Phone
Services
Network
Band 126
Setting the time and date 127
Setting alarms
Sounds & Notifications
To set Sound & Notif ications on actions
Lock 128
To protect your phone with a PIN
To protect your device with a password
To change your password
To display owner information on the Today
screen
CONTENT S
Today 131
Today screen settings
To synchronise the Today screen
To add own background image
To set options for displaying appointments
125
on the Today screen 132
To set options for displaying tasks on the
Today screen
Alarms 133
Time
Alarm
More 134
Memory
Main 135
130
Storage card
Running Programs
Power 136
Battery
Advanced
7
Bluetooth 138
To set the bluetooth configuration
General
Accessibility
Services
Bluetooth modes
To make your device discoverable 141
Bluetooth partnerships
To accept a Bluetooth partnership 142
USB TO PC 143
To use the USB mass storage
Connections
To connect to the Internet via pre-configured
connections. 144
To connect to the Internet via My ISP 145
To reset or modif y the network card settings
on your device
139
140
146
Wireless Manager 148
Configuring Wi-Fi connection set tings 150
ACCESSORIES 152
TECHNICAL DATA
153
CONTENT S
8
INTRODUCTION
Congratulations on your purchase
of the advanced and compact KS20
Windows Mobile Pocket PC, designed
to operate with the latest digital
mobile communication technology.
IN TRO DUC TION
This user’s guide contains important
information on the use and operation
of this phone. Please read all the
information carefully for optimal
performance and to prevent any
damage to or misuse of the phone.
Any changes or modifications not
expressly approved in this user’s
guide could void your warranty for
this equipment.
9
FOR YOUR SAFETY
Please read these simple guidelines.
Not following these guidelines may be
dangerous or illegal. Further detailed
information is given in this manual.
WARNING
•
Mobile Phones must be switched off at all
times in an aircraft.
•
Do not hold the phone in your hand while
driving.
• Do not use your phone near petrol stations, fuel
depots, chemical plants or blasting operations.
•
For your safety, use ONLY specified
ORIGINAL batteries and chargers.
• Do not handle the phone with wet hands
while it is being charged. It may cause an
electric shock or seriously damage your phone.
•
Keep the phone in a safe place out of small
children’s reach. It includes small parts
which if detached may cause a choking
hazard.
CAUTION
•
Switch off the phone in any area where
required by special regulations. For
example, do not use your phone in
hospitals or it may affect sensitive medical
equipment.
•
Emergency calls may not be available
under all mobile networks. Therefore, you
should never depend solely on your mobile
phone for emergency calls.
•
Only use ORIGINAL accessories to avoid
damage to your phone.
•
All radio transmitters carry risks of
interference with electronics in close
proximity. Minor interference may affect
TVs, radios, PCs, etc.
•
Batteries should be disposed of in
accordance with relevant legislation.
•
Do not dismantle the phone or battery.
FO R YOUR SAF ETY
10
GUIDELINES FOR SAFE AND
EFFICIENT USE
Please read these simple guidelines.
Not following these guidelines may be
dangerous or illegal. Further detailed
information is given in this manual.
GU IDE LIN ES FOR SAFE AND EFFICI ENT US E
Certification
information (SAR)
This device meets international
guidelines for exposure to radio
waves
Your mobile device is a radio
transmitter and receiver. It is designed
and manufactured not to exceed the
limits for exposure to radio frequency
(RF) recommended by international
guidelines (ICNIRP). These limits are
part of comprehensive guidelines
and establish permitted levels of RF
energy for the general population.
The guidelines were developed by
independent scientific organisations
through periodic and thorough
evaluation of scientific studies. The
guidelines include a substantial safety
margin designed to assure the safety
of all persons, regardless of age and
health.
v
The exposure standard for
mobile devices employs a unit of
measurement known as the Specific
Absorption Rate, or SAR. The SAR
limit stated in the international
guidelines is 2.0 W/kg*. Tests for
SAR are conducted using standard
operating positions with the device
transmitting at its highest certified
power level in all tested frequency
bands. Although the SAR is
determined at the highest certified
power level, the actual SAR of the
device while operating can be well
below the maximum value. This is
because the device is designed to
operate at multiple power levels so
11
as to use only the power required
to reach the network. In general,
the closer you are to a base station,
the lower the power output of
the device. Before a phone model
is available for sale to the public,
compliance with the European
R&TTE directive must be shown. This
directive includes as one essential
requirement the protection of the
health and the safety for the user
and any other person. The highest
SAR value for this device when
tested for use at the ear is 1.04 W/kg.
v
This device meets RF exposure
guidelines when used either in the
normal use position against the
ear or when positioned at least
1.5 cm away from the body. When
a carry case, belt clip or holder is
used for bodyworn operation,
it should not contain metal and
should position the product at
least 1.5 cm away from your body.
In order to transmit data files or
messages, this device requires a
quality connection to the network.
In some cases, transmission of data
files or messages may be delayed
until such a connection is available.
Ensure the above separation
distance instructions are followed
until the transmission is completed.
The highest SAR value for this device
when tested for use at the body is
1.24 W/kg.
* The SAR limit for mobile devices used
by the public is 2.0 watts/kilogram
(W/kg) averaged over ten grams
of body tissue. The guidelines
incorporate a substantial margin of
safety to give additional protection
for the public and to account for
any variations in measurements.
SAR values may vary depending on
national reporting requirements
GU IDE LIN ES FOR SAFE AND EFFICI ENT US E
12
GUIDELINES FOR SAFE AND EFFICIENT USE
and the network band. For SAR
information in other regions please
look under product information at
www.lgmobile.com.
GU IDE LIN ES FOR SAFE AND EFFICI ENT US E
Product care and
maintenance
WARNING
Only use batteries, chargers and
accessories approved for use with this
particular phone model. The use of
any other types may invalidate any
approval or warranty applying to the
phone, and may be dangerous.
v
Do not disassemble this unit. Take
it to a qualified service technician
when repair work is required.
v
Keep away from electrical
appliances such as a TV's, radios or
personal computers.
v
The unit should be kept away from
heat sources such as radiators or
cookers.
v
Never place your phone in a
microwave oven as it will cause the
battery to explode.
v
Do not drop.
v
Do not subject this unit to
mechanical vibration or shock.
v
The coating of the phone may be
damaged if covered with wrap or
vinyl wrapper.
v
Do not use harsh chemicals (such
as alcohol, benzene, thinners, etc.)
or detergents to clean your phone.
There is a risk of this causing a fire.
v
Do not subject this unit to excessive
smoke or dust.
13
v
Do not keep the phone next to
credit cards or transport tickets; it
can affect the information on the
magnetic strips.
v
Do not tap the screen with a sharp
object as it may damage the phone.
v
Do not expose the phone to liquid
or moisture.
v
Use accessories, such as earphones
and headsets, with caution. Ensure
that cables are tucked away safely
and do not touch the antenna
unnecessarily.
v
Please remove the data cable before
powering on the handset.
Electronic devices
All mobile phones may get
interference, which could affect
performance.
v
Do not use your mobile phone
near medical equipment without
requesting permission. Avoid
placing the phone over pacemakers
(i.e. in your breast pocket.)
v
Some hearing aids might be
disturbed by mobile phones.
v
Minor interference may affect TVs,
radios, PCs, etc.
Road safety
Check the laws and regulations on
the use of mobile phones in the areas
when you drive.
v
Do not use a hand-held phone while
driving.
v
Give full attention to driving.
v
Use a hands-free kit, if available.
GU IDE LIN ES FOR SAFE AND EFFICI ENT US E
14
GUIDELINES FOR SAFE AND EFFICIENT USE
v
Pull off the road and park before
making or answering a call if driving
conditions so require.
v
RF energy may affect some
electronic systems in your motor
vehicle such as a car stereo or safety
GU IDE LIN ES FOR SAFE AND EFFICI ENT US E
equipment.
v
If your vehicle is equipped with
an air bag, do not obstruct
it with installed or portable
wireless equipment. It can cause
serious injury due to improper
performance.
If you are listening to music whilst
out and about, please ensure that the
volume is at a reasonable level so that
you are aware of your surroundings.
This is particularly imperative when
attempting to cross the street.
Avoid damage to your
hearing
Damage to your hearing can occur
if you are exposed to loud sound for
long periods of time. We therefore
recommend that you do not turn on
or off the handset close to your ear. We
also recommend that music and call
volumes are set to a reasonable level.
Blasting area
Do not use the phone where blasting
is in progress. Observe restrictions, and
follow any regulations or rules.
15
Potentially
explosive
atmospheres
v
Do not use the phone at a refueIling
point. Don’t use near fuel or
chemicals.
v
Do not transport or store flammable
gas, liquid, or explosives in the
compartment of your vehicle, which
contains your mobile phone and
accessories.
In aircraft
Wireless devices can cause
interference in aircraft.
v
Turn off your mobile phone before
boarding any aircraft.
v
Do not use it on the ground without
crew permission.
Children
Keep the phone in a safe place out of
small children’s reach. It includes small
parts which if detached may cause a
choking hazard.
GU IDE LIN ES FOR SAFE AND EFFICI ENT US E
Emergency calls
Emergency calls may not be available
under all mobile networks. Therefore,
you should never depend solely on
your mobile phone for emergency
calls. Check with your local service
provider.
16
GUIDELINES FOR SAFE AND EFFICIENT USE
v
Battery
information and care
v
You do not need to completely
discharge the battery before
recharging. Unlike other battery
GU IDE LIN ES FOR SAFE AND EFFICI ENT US E
systems, there is no memory effect
that could compromise the battery’s
performance.
v
Use only LG batteries and chargers.
LG chargers are designed to
maximize the battery life.
v
Do not disassemble or short-circuit
the battery pack.
v
Keep the metal contacts of the
battery pack clean.
v
Replace the battery when it
no longer provides acceptable
performance. The battery pack may
be recharged hundreds of times
until it needs replacing.
Recharge the battery if it has
not been used for a long time to
maximize usability.
v
Do not expose the battery charger
to direct sunlight or use it in high
humidity, such as the bathroom.
v
Do not leave the battery in hot or
cold places, this may deteriorate the
battery performance.
v
Risk of explosion if battery is
replaced by an incorrect type.
v
Dispose of used batteries according
to the manufacturer’s instructions.
17
KS20 FEATURES
1
5
Part of the phone
Front view
2
3
4
6
1. Earpiece
2. Touch Screen
Use to write, draw, or make a selection with
the stylus.
3. Send Key
v Dials a phone number and answers
incoming calls.
4. Navigation KEY
5. Internal camera lens
6. End Key
v Ends or rejects a call.
KS20 FEATURES
18
KS20 FEATURES
1
2
3
Side view
1. Charger/Cable/Handsfree
KS20 FEATURES
connector
2. Side Keys
v Press up or down to adjust the volume.
3. Stylus and Stylus Slot
v Use the stylus to write, draw, or select items
on the touch screen.
4
5
6
v Press to turn o your device temporarily
and switches the device to sleep mode;
press and hold (about ve seconds) to turn
o your device completely.
When your device is in sleep mode, you can
still use the phone function to receive calls;
however, the phone function is o when
you turn o the device completely.
5. MicroSD Card Slot
4. Power key
7
6. Internet Explorer
v Press to access Internet Explorer.
7. Camera key
v Press this key to activate camera.
19
Rear view
Cable connector/
Battery charging connector
Flash
External
Camera Lens
SIM card socket
KS20 FEATURES
Battery
20
KS20 FEATURES
v
This product’s keys on the LCD screen are touch keys.
v
Be sure to read “Cautions for Touch Keys” before using this product.
Cautions for touch
keys
1. Make sure your hands are clean
and dry.
v
Remove all moisture from the
surface of your hands or the touch
keys in a humid environment.
KS20 FEATURES
Touch keypad
Hard keys
2. You do not need to press hard on
the touch keys to make them work.
Do not subject the product to severe
impact, as this may damage the
touch key sensors.
3. Use the tip of your finger to press
exactly on the touch key you want,
being careful not to touch the keys
for other functions.
4. When both the home screen and
touch key lights are off, pressing a
touch key will not turn on the home
screen light. Press P and the home
screen light will turn back on(touch
keys do not work when the touch
key lights are off).
21
5. Touch keys may not work normally if
a mobile phone case or plastic cover
is covering them.
6. Keep metal and other conductive
materials away from the surface of
the touch keys, as contact with them
may result in an error.
7. This phone allows to use a pen or a
stylus to select Menu. Also you can
use your finger to select Menu.
Use the tip of your finger may not
press the key correctly.
8. Touch key cannot be activated
properly in hot and humid
environment.
KS20 FEATURES
22
GETTING STARTED
Installing the USIM
card and battery
1. Installing the USIM card.
Your USIM card contains your
phone number, service details and
contacts and must be inserted into
your handset. If your USIM card is
removed then your handset becomes
unusable (except for emergency calls
depending on which Country you
are in at the time) until a valid one
is inserted. Always disconnect the
charger and other accessories from
your handset before inserting and
GE TTING STAR TED
removing your USIM card. Slide the
USIM card into the USIM card holder.
Make sure that the USIM card is
properly inserted and the gold contact
area on the card is facing downwards.
To remove the USIM card, press
down lightly and pull it in the reverse
direction.
To insert the USIM card
To remove the USIM cad
23
Note
v
The metal contact of the USIM
card can easily be damaged by
scratches. Pay special attention
to the USIM card while handling.
Follow the instructions supplied
with the USIM card.
2. Installing the battery.
Insert the Battery into the battery
compartment as the metal contacts
meet in the middle of the phone.
Push down the top of the battery until
it snaps into place. Place the battery
cover to the phone as shown.
GE TTING STAR TED
24
GETTING STARTED
3. To remove the battery.
Turn the phone up-side down, as
shown, gently push down the battery
cover to release and lift off. Then lift up
the battery with your fingers and pullout the battery.
GE TTING STAR TED
Charging the battery
Before connecting the charger to the
phone you must first check the battery
is installed.
25
<Charging mode>
1. When you recharge your phone
after device switch off, the phone’s
LED lights up red and displays a
charging animation.
2. When the phone is fully charged,
the LED lights up green and the
animation stops.
3. If you press and hold the power
button for approx. 2 seconds in
charging mode, the phone is turned
on.
4. If you disconnect the travel adapter
from the phone in charging mode,
the phone is turned off.
CAUTION!
• When you charge a fully discharged
battery, it may take over a minute for
the display to respond. This is not a
malfunction but completely normal.
(If using a USB cable, it may take over 10
minutes.)
• Do not force the connector as this may
damage the phone and/or the charger.
• If you use the charger out of your own
country, use an attachment plug adaptor
for the proper configuration.
• Do not remove your battery or the SIM
card while charging.
• There is risk of explosion if battery is
replaced by an incorrect type. Dispose of
used batteries according to the maker's
instructions.
GE TTING STAR TED
26
GETTING STARTED
GE TTING STAR TED
WARNNING
• Unplug the charger from the mains and
phone during lightning storms to avoid
electric shock or fire.
• Make sure that no sharp-edged items
such as animal teeth or nails come into
contact with the battery. There is a risk of
this causing a fire.
Disconnecting
the charger
Disconnect the travel adapter from the
phone as shown in the diagram. Make
sure you pull by the plug, not the cord.
27
How to use a
microSD memory
card
<MicroSD memory card>
<How to insert a microSD memory
card>
1. Lift the plastic cover which protects
the microSD slot.
2. Insert the memory card into the
slot with the metal contacts facing
down. Do not force the memory
card into the slot, if the card does
not slide in easily, please check that
the card is being inserted the correct
way or if there is a foreign object in
the slot.
GE TTING STAR TED
28
GETTING STARTED
3. Once inserted, push the memory
card until you hear a Click, meaning
that the microSD has been correctly
engaged.
4. Close the plastic slot protection.
5. Do not remove the memory card
when reading/writing the memory
card.
GE TTING STAR TED
Attention:
v
Avoid using the Flash Memory Card
when the battery is low.
v
When writing to the card, wait for
the operation to complete before
removing the card.
v
The card is designed to fit easily into
the system one way only.
v
Do not bend the card or force it into
the slot.
v
Do not insert any memory cards
other than microSD.
Support up to 2GB microSD. For more
information on the microSD, please
refer to the memory card instruction
manual.
Loading...
