OWNER’S MANUAL
ENGLISH
BOTTOM FREEZER
REFRIGERATOR
Please read this owner's manual thoroughly before
operating and keep it handy for reference at all times.
GR-B28ANSPP
P/No. : MFL62184520
www.lg.com
2
TABLE OF CONTENTS
TABLE OF CONTENTS
3 PRODUCT FEATURES
ENGLISH
4
IMPORTANT SAFETY
INSTRUCTIONS
7 COMPONENTS
7 Refrigerator Interior
8 INSTALLATION
8 Unpacking Your Refrigerator
8 Choosing the Proper Location
8 - Flooring
9 - Ambient Temperature
9 - Measuring the Clearances
9 Removing/Assembling the Refrigerator
Door Handles
10 Removing/Assembling the Freezer
Drawer Handle
10 Removing/Assembling the Doors and
Drawers
11 - Removing the Left Refrigerator Door
11 - Removing the Right Refrigerator Door
12 - Assembling the Left Refrigerator Door
12 - Assembling the Right Refrigerator Door
13 - Removing the Freezer Drawers
14 - Assembling the Freezer Drawers
15 Connecting the Water Line
15 - Before You Begin
15 - Water Pressure
16 Leveling and Door Alignment
16 - Leveling
16 - Door Alignment
17 HOW TO USE
17 Before Use
18 Control Panel
18 - Control Panel Features
19 Automatic Icemaker
19 - Automatic Icemaker (Freezer Room)
19 -
Turning the Automatic Icemaker On or Off
19 - When You Should Turn the Icemaker Off
19 - Normal Sounds You May Hear
19 - Preparing for Vacation
20 Storing Food
20 - Food Preservation Location
21 - Food Storage Tips
21 - Storing Frozen Food
22 Humidity Controlled Crisper and
Glide’N’Serve
Detaching and Assembling the Storage Bins
23
25 Adjusting the Refrigerator Shelves
26 MAINTENANCE
26 Cleaning
27 Light bulb replacement
27 Power interruptions
27 When you go on vacation
27 When you move
28 TROUBLESHOOTING
PRODUCT FEATURES
PRODUCT FEATURES
* Depending on the model, some of the following functions may not be available.
DOOR ALARM
The Door Alarm function is designed to prevent refrigerator malfunctioning
that could occur if a refrigerator door or freezer drawer remains open. If a
refrigerator door or freezer drawer is left open for more than 60 seconds, a
warning alarm sounds in 30 second intervals.
HUMIDITY CONTROLLED CRISPER
The Humidity Controlled Crisper is designed to help keep your fruits and
vegetables fresh and crisp. You can control the amount of humidity in the
crisper by adjusting the setting between Low and High.
GLIDE‘N’SERVE
Glide`N’Serve provides storage space that keeps the compartment colder
than the refrigerator.
It is a convenient place to store sandwiches or meat to be cooked.
3
ENGLISH
ICE PLUS
Ice production can be increased by approximately 20 percent when the
freezer section is maintained at the coldest temperature for a 24-hour
period.
AUTO CLOSING HINGE
The refrigerator doors and freezer drawers close automatically with a slight
push.
(The door only closes automatically when it is open at an angle less than 30°.)
4
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
This guide contains many important safety messages. Always
ENGLISH
This is the safety alert symbol. It alerts you to safety messages that inform you of hazards
that can kill or hurt you or others, or cause damage to the product.
All safety messages will be preceded by the safety alert symbol and the hazard signal word
WARNING or CAUTION. These words mean:
WARNING
CAUTION
You can be killed or seriously injured if you do not follow instructions.
Indicates an imminently hazardous situation which, if not avoided, may result
in minor or moderate injury, or product damage.
read and obey
all safety messages.
WARNING
To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety
precautions should be followed, including the following.
Power
NEVER unplug your refrigerator by pulling on the power cord. Always grip the plug firmly and pull
y
it straight out from the outlet.
Immediately repair or replace all power cords that have become frayed or otherwise damaged.
y
Do not use a cord that shows cracks or abrasion damage along its length or at either the plug or
connector end.
Do not use an uncertified power outlet.
y
Unplug the power plug immediately in the event of a blackout or severe thunderstorm to avoid
y
electrical surges.
Plug in the power plug with the power cord facing downward.
y
Installation
Contact an authorized service center when you install or relocate the refrigerator.
y
When moving your refrigerator away from the wall, be careful not to roll over or damage the
y
power cord.
Connect this product to a dedicated grounded electric outlet conforming with the rating prior to
y
use. The power cord supplied is to suit standard 220V 16amp 3pin earthed power outlets.
Do not install the refrigerator where there may be a danger of it falling or toppling over.
y
Use
DO NOT allow children to climb, stand, or hang on the refrigerator doors or shelves in the
y
refrigerator. They could damage the refrigerator and seriously injure themselves.
Do not place heavy objects on the dispenser of the refrigerator or hang onto it.
y
Do not place heavy or dangerous objects (bottles with liquid) on the refrigerator.
y
Do not put live animals inside of the refrigerator.
y
Do not allow children to climb into the product when it is in or out of use.
y
In the event of a refrigerant leak (propane/LPG), ventilate sufficiently , unplug the unit and call for
y
an authorized Service center. Do not touch or disassemble any of the electrical components of the
refrigerator.
In the event of a refrigerant leak, move flammable objects away from the refrigerator. Ventilate
y
sufficiently and contact an authorized service center.
Do not use or place flammable substances (chemicals, medicine, cosmetics, etc) near the
y
refrigerator or store them inside the refrigerator. Do not place the refrigerator in the vicinity of
flammable gas or any sources of heat or flame.
This Refrigerator is designed for normal domestic, indoor use only. It is not designed for Mobile
y
applications.
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety
precautions should be followed, including the following.
Do not use this product for special purposes (storage of medicine or test materials or on ships,
y
etc).
Unplug the power plug before cleaning or maintaining the refrigerator.
y
When you replace the light bulb in the refrigerator, unplug the refrigerator or turn off the power.
y
Do not modify or extend the power cord.
y
Do not use a dryer to dry the interior. Do not light a candle to remove the interior odor.
y
For your safety, this appliance must be properly grounded. Have the wall outlet and the circuit
y
checked by a qualified electrician to make sure the outlet is properly grounded.
Do not use with an extension cord.
y
Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
y
Do not use an adapter plug and plug the power plug into a multi-outlet extension cord.
y
Disconnect the power cord immediately if you hear any abnormal noise, smell a strange odor or
y
detect smoke.
Turn the power off if water or dust penetrates into the refrigerator. Call for an authorised Service
y
Repairer.
Do not disassemble or modify the refrigerator.
y
Do not put hands, feet, or metal objects below or behind the refrigerator.
y
Do not operate the refrigerator or touch the power cord with wet hands.
y
In refrigerators with automatic icemakers, avoid contact with the moving parts of the ejector
y
mechanism or with the heating element that releases the cubes. Do not place fingers or hands on
the automatic ice-making mechanism while the refrigerator is plugged in.
When dispensing ice from the dispenser, do not use crystal ceramics.
y
Do not touch the cold surfaces in the freezer compartment with wet or damp hands, when your
y
refrigerator is in operation.
Do not put glass containers, glass bottles or soda in the freezer.
y
This appliance is not intended for use by persons (including children) with reduced physical,
y
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning the use of the appliance by a person responsible for their
safety.
Do not refreeze frozen food that have thawed completely. It may result in a serious health issue.
y
If you are throwing away your old refrigerator, make sure the CFC coolant is removed for proper
y
disposal by a qualified servicer. If you release CFC coolant, you may be fined or imprisoned in
accordance with the relevant environmental law.
Disposed or abandoned refrigerators are dangerous, even if they are sitting for only a few days.
y
When disposing the refrigerator, remove the door seals from the door or take off the doors but
leave the shelves in place so that children may not easily climb inside.
If refrigerant gas has leaked, do not touch the refrigerator or the outlet and ventilate the room
y
immediately. A spark could trigger an explosion causing a fire or burns. Because this refrigerator
uses natural gas (isobutane, R600a) as the environment-friendly refrigerant, even a small amount
(50~60g) is combustible. If gas leaks from leaked by the severe damage during delivering,
installing or using the refrigerator, any spark may cause fire or burns.
5
ENGLISH
6
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety
precautions should be followed, including the following.
ENGLISH
Installation
Use
Maintenance
CAUTION
The refrigerator must be properly installed in accordance with the Installer Instructions that
y
were taped to the front of the refrigerator.
Be careful when you unpack and install the refrigerator. Immediately dispose of packing
y
materials (plastic) out of reach of children.
Close the door carefully when children are around.
y
Keep fingers out of pinch point areas; clearances between the doors and cabinets are necessarily
y
small. Be careful closing doors when children are in the area.
If you store food properly, beware that it may fall and cause injury.
y
When using the Automatic icemaker, make sure that the ice storage bin is installed in place.
y
This model does not come with a filter. Fill the cold water supply with drinking water only.
y
When not using the automatic icemaker, you can remove the icebin.
y
Do not use strong detergents like wax or thinners for cleaning. Clean with a soft fabric.
y
Wipe foreign objects (dust, water, etc) off the prongs of the power plug and contact areas
y
regularly.
WARNING
Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of
y
obstruction.
Do not use mechanical devices or other means to accelerate the defrosting process, other than
y
those recommended by the manufacturer.
Do not damage the refrigerant circuit.
y
Do not use electrical appliances inside the food storage compartments of the appliance, unless
y
they are of the type recommended by the manufacturer.
The refrigerant and insulation blowing gas used in the appliance require special disposal
y
procedures. When disposal, please consult with service agent or a similarly qualified person.
This appliance contains a small amount of isobutane refrigerant (R600a), natural gas with high
environmental compatibility, but it is also combustible. When transporting and installing the
appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged.
Refrigerant squirting out of the pipes could ignite or cause an eye injury. If a leak is detected,
avoid any naked flames or potential sources of ignition and air the room in which the appliance is
standing for several minutes.
In order to avoid the creation of a flammable gas air mixture if a leak in the refrigerating circuit
occurs, the size of the room in which the appliance may be sited depends on the amount of
refrigerant used. The room must be 1m
appliance. The amount of refrigerant in your particular appliance is shown on the identification
plate inside the appliance. Never start up an appliance showing any signs of damage. If in doubt,
consult your dealer.
2
in size for every 8g of R600a refrigerant inside the
SAVE THESE INSTUCTIONS
COMPONENTS
COMPONENTS
Use this page to become more familiar with the parts and features of your refrigerator.
Page references are included for your convenience.
*The appearance and specifications of the actual product may differ depending on the model.
Refrigerator Interior
Digital Control Panel
Simple electronic controls are user-friendly.
The LED screen shows refrigerator and freezer
temperatures, displays water filter status,
LED Interior Lamps
Two separate LED arrays light the freezer
and refrigerator interiors.
dispenser information, and more.
Dairy Product Bin
7
ENGLISH
Mullion
Folds in when the
left door is opened.
Fixed Door Bin
Modular Door Bins
Crispers
LG’s crispers preserve
humidity and help
vegetables stay crisp.
Fixed Door Bin
Glide’N’Serve
Provides storage space with a
variable temperature control that
keeps the compartment colder
than refrigerator.
Removable Ice Storage Bin
The ice storage bin store the ice that is
made by automatic icemaker.
Adjustable
Refrigerator Shelving
The refrigerator
compartment shelves
are adjustable to allow
flexibility for storage
needs.
Modular Door Bins
Fixed Door Bin
Auto Closing Hinge
When you slightly
push the door of
the refrigerator, it is
automatically closed.
(The door is automatically
closed within 30° of the
opening angle.)
LED Interior Lamps
Two separate LED arrays light the freezer and
refrigerator interiors.
Automatic Icemaker
8
INSTALLATION
INSTALLATION
Unpacking Your Refrigerator
ENGLISH
WARNING
Use two or more people to move and
y
install the refrigerator. Failure to do so
can result in back or other injury.
Your refrigerator is heavy. When moving
y
the refrigerator for cleaning or service,
be sure to protect the floor. Always pull
the refrigerator straight out when moving
it. Do not wiggle or walk the refrigerator
when trying to move it, as floor damage
could occur.
Keep flammable materials and vapors,
y
such as gasoline, away from the
refrigerator. Failure to do so can result in
fire, explosion, or death.
Remove tape and any temporary labels from your
refrigerator before using. Do not remove any
warning-type labels, the model and serial number
label, or the Tech Sheet that is located under the
front of the refrigerator.
To remove any remaining tape or glue, rub the
area briskly with your thumb. Tape or glue residue
can also be easily removed by rubbing a small
amount of liquid dish soap over the adhesive with
your fingers. Wipe with warm water and dry.
Do not use sharp instruments, rubbing alcohol,
flammable fluids, or abrasive cleaners to remove
tape or glue. These products can damage the
surface of your refrigerator.
Refrigerator shelves are installed in the shipping
position. Please reinstall shelves according to
your individual storage needs.
Choosing the Proper Location
Select a place where a water supply can
y
be easily connected for the automatic
icemaker.
NOTE
The water pressure must be between
140 and 860 kPa on models without a
water filter and between 275 and 860
kPa on models with a water filter.
The refrigerator should always be plugged
y
into its own individual properly grounded
electrical outlet rated for 220 Volts, 50 Hz,
AC only, and fused at 16 amperes. This
provides the best performance and also
prevents overloading house wiring circuits
which could cause a fire hazard from
overheated wires. It is recommended
that a separate circuit serving only this
appliance be provided.
WARNING
To reduce the risk of electric shock, do not
install the refrigerator in a wet or damp
area.
Flooring
To avoid noise and vibration, the unit must be
leveled and installed on a solidly constructed
floor. If required, adjust the leveling legs to
compensate for unevenness of the floor. The
front should be slightly higher than the rear to
aid in door closing. Leveling legs can be turned
easily by tipping the cabinet slightly. Turn the
leveling legs to the left to raise the unit or to
the right to lower it. (See Leveling and door
AlIgnment.)
NOTE
Installing on carpeting, soft tile surfaces,
a platform or weakly supported structure
is not recommended.
INSTALLATION
9
Ambient Temperature
Install this appliance in an area where the
temperature is between 13°C and 43°C. If the
temperature around the appliance is too low or
high, cooling ability may be adversely affected.
Do not store the refrigerator in Direct Sunlight
or sheltered outdoor areas.
Measuring the Clearances
Too small of a distance from adjacent items
may result in lowered freezing capability and
increased electricity consumption charges.
Allow at least 24 inches (61 cm) in front of
the refrigerator to open the doors, and at
least 2 inches (5 cm) between the back of the
refrigerator and the wall.
24” (61 cm)
2” (5 cm)
Removing/Assembling the
Refrigerator Door Handles
NOTE
Removing the doors is always
recommended when it is necessary to
move the refrigerator through a narrow
opening. If it is necessary to remove the
handles, follow the directions below.
Removing the Handles
Loosen the set screws with a 3/32 in.
1
Allen wrench and remove the handle.
Loosen the mounting fasteners that
2
connect to the refrigerator door and handle
using a 1/4 in. Allen wrench, remove the
mounting fasteners.
ENGLISH
Assembling the Handles
Assemble the mounting fasteners at
1
both ends of the handle using a 1/4 in.
Allen wrench.
Place the handle on the door by fitting
2
the handle footprints over the mounting
fasteners and tightening the set screws
with a 3/32 in. Allen wrench.
10
INSTALLATION
Removing/Assembling the
Freezer Drawer Handle
Removing the Handles
Loosen the set screws located on the
1
ENGLISH
lower side of the handle with a 1/8 in. Allen
wrench and remove the handle.
Loosen the mounting fasteners that
2
connect to the freezer drawer and handle
using a 1/4 in. Allen wrench, and remove
the mounting fasteners.
Removing/Assembling the
Doors and Drawers
Removing the doors is always recommended
when it is necessary to move the refrigerator
through a narrow opening.
WARNING
If your entrance door is too narrow for the
y
refrigerator to pass through, remove the
refrigerator doors and move the refrigerator
sideways through the doorway.
Use two or more people to remove and
y
install the refrigerator doors. Failure to do
so can result in back or other injury.
Disconnect the electrical supply to the
y
refrigerator before installing. Failure to do
so could result in serious injury or death.
Do not put hands, feet or other objects into
y
the air vents or bottom of the refrigerator.
You may be injured or receive an electrical
shock.
Be careful when handling the hinge and
y
stopper. It may result in injury.
Remove food and bins from the doors and
y
drawers before detaching.
Assembling the Handles
Assemble the mounting fasteners at
1
both ends of the handle using a 1/4 in. Allen
wrench.
Place the handle on the door by fitting
2
the handle footprints over the mounting
fasteners and tightening the set screws
with a 1/8 in. Allen wrench.
INSTALLATION
11
Removing the Left Refrigerator Door
(2)
(4)
(5)
(6)
(7)
Open the door. Remove the top hinge
1
cover screw (1 ).
Use a flat-head screwdriver to pry back the
2
hooks (not shown) on the front underside
of the cover (2). Lift up the cover.
Disconnect all the wire harnesses (3).
3
Remove the grounding screw(4).
4
Rotate hinge lever (5) counterclockwise.
5
Lift the top hinge (6) free of the hinge lever
latch (7).
CAUTION
When lifting the hinge free of the latch, be
careful that the door does not fall forward.
(1)
(3)
Removing the Right Refrigerator Door
(1)
(3)
Open the door. Remove the top hinge
1
cover screw (1 ). Lift up the cover (2).
Remove the cover.
2
Rotate the hinge lever (3) clockwise. Lift
3
the top hinge (4) free of the hinge lever
latch (5).
CAUTION
When lifting the hinge free of the latch, be
careful that the door does not fall forward.
(2)
(4)
(5)
ENGLISH
12
INSTALLATION
Assembling the Left Refrigerator
Door
Install the left refrigerator door after the right
door is installed.
ENGLISH
Lower the door onto the middle hinge pin.
1
(4)
(2)
(1)
(3)
Fit the top hinge (1) over the hinge lever
2
latch (2) and into place. Rotate the lever (3)
clockwise to secure the hinge.
Install the grounding screw (4) and connect
3
all the wire harnesses (5).
Assembling the Right Refrigerator
Door
Install the right-side door first.
Lower the door onto the middle hinge
1
pin. Make sure that the plastic sleeve is
inserted into the bottom of the door.
(5)
(5)
Fit the top hinge (1) over the hinge lever
2
latch (2) and into place. Rotate the lever (3)
counterclockwise to secure the hinge.
Hook the tab on the door-switch side of
3
the cover (4) under the edge of the wire
opening in the cabinet top. Position the
cover into place. Insert and tighten the
cover screw (5).
(4)
(3)
(2)
(1)
Loading...
