LG GR-382R User Manual

Model(s):
GR-382R
REFRIGERATOR-
FREEZER
OWNER'S MANUAL
READ THIS MANUAL THOROUGHLY BEFORE USING THE APPLIANCE AND KEEP IT HANDY FOR FURTHER REFERENCE.
CONTENT
INSTALLATION......................................... 4
FEATURE CHART ................................. 5
OPERATION ............................................. 6
Start up Before adjusting the temperature Refrigerator controls Freezer controls Self-diagnosis Icemaking Door basket cooling Fresh meat tray Defrost Deodorizer
REVERSIBLE DOOR ................................. 8
Cautions How to switch doors
FOOD STORAGE SUGGESTIONS .......... 10
CLEANING ............................................... 11
GENERAL INFORMATION ....................... 11
LAMP REPLACEMENT ............................ 12
IMPORTANT WARNINGS ........................ 12
BEFORE CALLING
FOR SERVICE ......................................... 13
SPECIFICATIONS ................................. 14
2
THIS REFRIGERATOR IS MANUFACTURED WITH EXTREME CAUTION USING THE LATEST TECHNOLOGY. WE ARE CONFIDENT THAT YOU WILL BE COMPLETELY SATISFIED WITH IT’S PERFORMANCE AND RELIABILITY. BEFORE USING YOUR REFRIGERATOR, PLEASE READ THIS MANUAL COMPLETELY. IT INCLUDES THE EXACT INSTRUCTIONS FOR INSTALLATION, OPERATION AND MAINTENANCE ALONG WITH SOME USEFUL TIPS.
INSTALLATION
1. Install in an appropriate location. Place the refrigerator where it is easily
accessible. 
2. Avoid placing your refrigerator near heat sources, direct sunshine,or areas of high humidity. 
3. There must be an appropriate air flow
around your refrigerator in order to get a good performance. If your refrigerator is placed close to the walls, it must have a clearance of 10" on top and 2" on both sides. The refrigerator must have a 1” clearance from the floor, specially if it’s carpeted.
4. To avoid problems, the refrigerator should be properlyleveled. If necessary, adjust the leveling screws. The front must be slightly higher than the back so the doors will close properly. The leveling screws are easier to turn if you lean the refrigerator slightly backwards. Turn the leveling screws clockwise to raise the front of the refrigerator and counterclockwise to lower it.
5. Install the refrigerator in a place where the
temperature is between 50° F (10°C) and 104° F (40°C). If the temperature is higher or lower, the cooling performance of the appliance can be diminished.
NEXT
1. Clean your refrigerator and remove dust accumulated during transportation.
2. Install all accessories, such as ice trays, in the
correct places. They are packed together to prevent damage
in transit.
3. Follow the instructions for handle assembly.
4. After moving the refrigerator, wait an hour before plugging itin to allow the oil to settle in the compressor.
5. Connect the power cord to the power outlet.
Do not connect more than one appliance to the same outlet. If your refrigerator's power cord has 3 terminals, DO NOT remove the ground terminal. Grounding minimizes the risk of electric shock. This connector requires a 3-terminal power outlet. If the customer does not have the proper outlet, he must contact a qualified electrician to have the proper outlet installed.
5. Before using your refrigerator, let it run for 2 or 3
hours. Verify the cold air flow at the freezer to ensure proper cooling. Now your refrigerator is ready to use.
3
FEATURES
FEATURES
FREEZER
Temperature
Control
Shelf
Ice Trays
Twist’n Serve
REFRIGERATOR
Temperature
Control
Fresh Meat
Tray
Lamp
(Plastic or Glass)
Air flow distributor
Shelves
Deodorizer
(Absorbs
Odors)
Multi Air Flow
Vegetable Tray
(Keeps fruits and
vegetables fresh)
*
Freezer Door Baskets
Door Cooling
(Air Flow from the door.)
Bottle Guide
Refrigerator’s Door Baskets
Leveling Screws
*
*
NOTE
MODEL(S):
GR-382R
Magic Crisper
(Vegetable Tray cover that control humidity)
All parts listed may not be included on your model. 
*
4
OPERATION
START UP
When your refrigerator is installed or relocated, let it stand for an hour before starting it. Then let it run for 2 or 3 hours to stabilize the internal temperature before filling it with food. If power is interrupted, allow 5 minutes to pass before restarting.
BEFORE CONFIGURING THE TEMPERATURE
i This refrigerator has a temperature control button for the refrigerator compartment and a selector for the freezer compartment. i · The basic configuration for the refrigerator's temperature control is in the middle; that is, the first three LEDs are turned on. i The basic configuration of the temperature selector at the freezer compartment is “4.
REFRIGERATOR COMPARTMENT CONTROL
i You can adjust the refrigerator compartment's temperature using the Ref. Temp Control button. Each time you press the button, one LED should illuminate until it reaches Max. Continuing to press this button will continue to cycle through all settings from Min to Max and around again. i The refrigerator compartment's temperature is indicated by the number of LEDs illuminated, from Min to Max. Min is warmer and Max is cooler.
i You can select the desired temperature with this control. i To conserve energy, set the control to Min. (first LED on)
FREEZER COMPARTMENT CONTROL*
i
COLD AIR CONTROL - 1, 2, 3, 4, 5, 6, 7, 8, and 9
By placing the selector on 9, the freezer will be colder but the food stored in the refrigerator compartment will cool more slowly because of the diminishing air flow. i
In cold weather, the compressor's running time is reduced and the
freezer compartment tends to be a little warmer.  To keep the freezer colder, set the TEMP CONTROL between 6 and 9.
i
· If there is much food stored in the freezer or the door is opened
frequently, its temperature will be a little bit warmer. 
In this case, set the TEMP. CONTROL between 6 and 9 to make it colder. Set the TEMP. CONTROL to its original position to reduce the energy consumption.
i
In hot weather, or when much food is stored in the refrigerator, it tends to be a little bit warmer. 
iTo make it cooler, turn the TEMP. CONTROL between 2 and 4 to direct more air to the refrigerator and
place the REF. TEMP. CONTROL at the MAX position. If the TEMP. CONTROL is sebetween 6 and 9 at the freezer compartment, the refrigerator will cool very slowly. 
5
OPERATION
SELF-DIAGNOSIS
i The electronic control system includes a self-diagnostic mode. When an error is detected, it is is displayed on the control box LEDs. It is not possible to adjust the controls while an error message is displayed. i When this happens, do not disconnect the power cord from the outlet and call a service center immediately.
ICE MAKING -TWISTING TYPE-
iTo make ice cubes, fill the trays with water and insert them on their position. iTo remove the ice cubes, twist the tray’s knob and the cubes will fall into the ice bank instantly. iYou can detach the “Twist’n Serve” to increase the freezer’s storage capacity. First take out the ice trays and the cube box, then pull the frame to the right side.
DOOR BASKET COOLING
(Some models)
iThe cold air flow from the door makes the cooling of the beverages placed on the door baskets faster and more efficient. iWhen new food is placed in the door basket, the cooling time decreases due to the cold air flow in this area. iWhen water or other strange object gets into the air flow area when cleaning or any other moment, the cooling performance drops down. Also, performance can be lowered by air leakages due to door gasket damage.
FRESH MEAT TRAY
iWhen the door is opened, the warm air does not affect the fresh meat located inside the tray. Consequently, food can be kept fresher for longer time.
iThe fresh meat tray and shelf must be placed in the correct position.
If they are moved, they won't serve their purpose. iWhen water or other strange object gets into the air flow area, the cooling performance drops down.
DEFROSTING
iDefrost is carried out automatically. iThe water generated during the defrosting flows down to the drip tray located
at the back part of the refrigerator and its evaporated automatically.
6
REVERSIBLE DOOR SWITCHING
Caution
1. The door can be reversed according to the users needs or preferences.
2. Before
3. Use a hexagonal screw driver to loosen the screws.
4. Be very careful when removing the lower hinges screws, the refrigerator could fall down.
5. Do not lay the refrigerator on its side when switching the doors. This could cause a malfunction
6.Be careful when switching the doors; they could fall and cause damage or injury.
HOW TO REVERSE THE DOOR
(To switch the opening from right side to left side)
1
reversing doors, remove all food and accesories placed in the baskets.
or damage.
Remove the freezes door (3)
Remove the upper hings cover (1) and then remove
the screws (2).
2
Remove the center hinge (4) and then
3
the refrigeratos door (5).
Remove the lower hinge (6) .
4
7
REVERSIBLE DOOR SWITCHING
Switch the leveling screws.
5
Assemble the lower hinge (6)
6
Switch the cap (8) to cover the hole where
7
the hinge is inserted in the door cap decoration.
8
Assemble the central hinge (4) on the other side and switch the hole
cover cap (10).
8
SUGGESTIONS ON FOOD STORAGE
STORING FOOD
iStore fresh food in the refrigerator and the freezer. Defrosting is an important factor in preserving
freshness and flavor. 
iDo not store food that can decompose under low temperatures such as bananas, melons or pineapple. iAllow hot food to cool before storing it. Placing hot food in the refrigerator damages other food
and increases energy consumption.
iWhen storing food, wrap it with vinyl film or store it in closed containers. This prevents food moisture
from evaporating and keeps food fresh.
iDo not obstruct the cold air outlets with food. The cold air flowkeeps the refrigerator temperature even. 
iDo not open the door frequently. Opening the door allows hot air into the refrigerator, raising the
temperature.
iTo adjust the temperature controls easily, keep the area near the controls clear.
FREEZER
iDo not store glass bottles in the freezer - they can break when frozen. iDo not freeze food that has been already thawed. They may lose their nutritional properties. iWhen storing frozen food for a long period, such as ice cream, place it on the shelves and not in
the door baskets.
REFRIGERATOR
iAvoid storing high humidity foods at the back of the refrigerator. They could freeze in contact with
the cold air. Store in a closed container instead.
iAlways clean food before refrigerating it. Fruits and vegetables should be washed and dried.
Packaged food should be dried to avoid contaminating adjacent items.
iStore eggs on the highest shelf in the refrigerator.
NOTE
i If the refrigerator is placed in a hot and humid place, it’s door is opened frequently, or if many vegetables are stored in it; dew may form on the inside walls of the refrigerator. This does not affect its performance. Just remove the dew with a dustfree cloth.
9
CLEANING
It is important that your refrigerator is kept clean to avoid unwanted odors. Spilled food must be cleaned immediately because it could stain the plastic surfaces.
Never use metal fibres, brushes, abrasive cleaners or alkaline solutions over any kind of surface.
Before cleaning, remember that wet objects can stick to extremelly cold surfaces. Do not touch frozen surfaces with bare, wet hands .
EXTERIOR - Use warm water and a mild
detergent solution to clean the surfaces of your refrigerator. Clean it with a damp cloth and dry it.
INTERIOR - A regular cleaning of the interior is
recommended. Use a damp cloth in a solution of one (1) teaspoon sodium bicarbonate (baking soda) dissolved in one (1) quart of warm water.
Rinse the surfaces with a damp cloth and dry.
GENERAL INFORMATION
ON VACATIONS
INTERIOR PARTS - Wash the shelves,
door baskets, storage trays, magnetic door with a damp cloth in a solution of one (1) teaspoon sodium bicarbonate (baking soda)
dissolved in one (1) quart of warm water. Rinse the surfaces with a damp cloth and dry.
WARNING
Always unplug the power cord from the power outlet before cleaning in the vicinity of electrical parts (lamps, switches, controls, etc.) Wipe out excess moisture with a sponge or cloth to prevent water or liquids to contacting
an electric part and cause a short circuit. Do not use flammable or toxic liquid cleaners.
IF YOU MOVE
During average length vacations, probably prefer to leave the refrigerator running. Some foods may be frozen for extended storage.
If you plan to be away for an extended period, remove remove the food, disconnect the power cord, clean the interior (as described above,) and block the door open to prevent odors.
POWER FAILURE
Most power failures are fixed within one or two hours and won’t affect your refrigerator’s temperatures. However, you should minimize the door openings while the power is out. During long term power breakdowns place an EPS bar over your stored food, this will help to keep them fresh for longer time.
Remove or fix all loose articles inside the refrigerator. To avoid damaging the leveling screws, turn them until they reach the base.
ANTI-CONDENSATION PIPE
Anti-Condensation
The outside of the refrigerator may become hot, especially immediately after installation and start-up.This is normal.
It is caused by the anti­condensation pipe which
pumps hot refrigerant to prevent condensation
on the outer cabinet.
Pipe
10
LAMP REPLACEMENT
REFRIGERATOR LAMP
1. Unplug the refrigerator’s power cord.
2. Remove the refrigerator compartment’s shelves and the vegetable tray cover.
3. To remove the lamp cover, pull the lower part with your hand or a tool.
4. Twist the light bulb counterclockwise.
5. Assembly on the opposite way as disassembly. The replacement light bulb must be the same specification of the original. (125V, 20W). Part No. 6912JB2002J
IMPORTANT WARNINGS
DO NOT USE AN EXTENSION CORD
Do not connect any other appliance in the same plug of the refrigerator, if many appliances are connected the wires might be overloaded, increasing the risk of voltage variation and improper operation.
POWER CORD REPLACEMENT
If the power cord gets damaged, you must replace it for a new one available with the manufacturer or its service agent.
DANGER
RISK OF CHILD ENTRAPMENT
An empty refrigerator can be a very dangerous attraction for children. Before you throw away your old refrigerator or freezer, please take off the doors and leave the shelves in place so that children may not easily climb inside.
Please do not let the area near the door switch get dirty by sweet food or candy, as ants could interrupt the normal operation of this switch.
ABOUT GROUNDING (EARTHING)
In the event of a short circuit, the ground connection reduces the risk of electric shock while providing an escape line for electric current.
Prevent a possible electric shock, this appliance must be grounded.
The wrong use of the plug’s earth terminal can result in an electric shock. Consult a qualified electrician or service person if the grounding instructions are not fully understood, or if you have any doubts about if your appliance is properly grounded.
This appliance must be grounded
DON’T WAIT! DO IT NOW!
NEVER STORE EXPLOSIVE
OR CHEMICAL SUBSTANCES IN
YOUR REFRIGERATOR.
11
BEFORE CALLING FOR SERVICE
SERVICE CALLS CAN OFTEN BE AVOIDED!
IF YOU THINK YOUR REFRIGERATOR IS NOT WORKING PROPERLY, FIRST VERIFY THESE POSSIBLE CAUSES:
PROBLEM POSSIBLE CAUSES
Did a fuse blow or a circuit breaker trip?
Is the power cord loose in the connector or unplugged?
Check your electric plug for damage. Connect another appliance 
REFRIGERATOR IS NOT WORKING
THE TEMPERATURE IN THE REFRIGERATOR COMPARTMENT OR FREEZER COMPARTMENT IS TOO HOT.
ABNORMAL NOISE (S)
or lamp to make sure the outlet works. 
Make sure your circuit is not overloaded. The refrigerator should  be on its own circuit. Unplug other appliances that are overloading
the circuit and causing voltage drop or other electrical problems. 
• The temperature control is not in the right position.
• The appliance is located near the wall or a heat source (stove, sun rays, etc.)
Hot weather - Frequent door openings.
The door is not completely closed. Check to ensure there is no  damage to the gasket or some item blocking the door.
• The door is left open for long time.
• Large food amounts are stored in the refrigerator.
• The refrigerator is placed over an uneven or weak surface, or the leveling screws need to be adjusted.
• Unnecesary objects are placed on the back side of the refrigerator.
• If a voltage drop occurs check if the bulbs’ light is low, if so, call your electricity company to get the failure fixed.
THE REFRIGERATOR KEEPS BAD ODORS
DEW FORMS ON THE CABINET SURFACE.
COMPRESSOR OPERATES CONTINUOUSLY FOR LONG TIME
Fragrant food must be stored in closed containers or wrapped.
• The interior needs to be cleaned.
• Check that the deodorizer is clean and if needed, expose it to the sun for a couple hours to re-charge it.
It is normal when the humidity is high. 
The door may have been left ajar. 
• Temperature controls are set to the Maximum, please set them to Medium.
• Check that doors are closed properly.
• Hot food is stored.
• Doors are left open for long periods of time.
• The refrigerator is too close to a heat source or sun rays.
12
SPECIFICATIONS
MODEL(S) POWER SUPPLY
GR-382R 115V 60Hz 1,8A 140W 196W
TECHNICAL SPECIFICATIONS
OPERATING
FREQUENCY
NOMINAL CURRENT
NOMINAL
CONSUM PTION
DEFROST
POWER
CONSUM PTION
CAPACITY: 331.13 Liters (11.8 cuft)
13
LG ELECTRONICS CANADA INC.
d
u
LG REFRIGERATOR
LG Electronics will repair or at its option replace, without charge, your product which proves to be defective in material or workmanship under normal use, during the warranty period listed below from the date of original purchase.
as long as it is in any Canadian Province.
This warranty is good only to the original purchaser of the product during the warranty period
WARRANTY PERIOD
MODEL # GR-382R
LABOR
2 Year
PARTS
2 Year
SEALED SYSTEM
Serial Number
5 Years
(Compressor, condenser, and evaporator)
No other express warranty is applicable to this product.
HOW SERVICE IS HANDLED
Call
1-888-542-2623
choose the appropriate prompt. Please have prod type (refrigerator) and ZIP Code ready. See our website at
(1-888-LG-CANADA) an
http://www.lg.ca
This warranty provides in-home service.
THE DURATION OF ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY, IS LIMITED TO THE DURATION OF THE EXPRESS WARRANTY HEREIN. LG ELECTRONICS USA, INC. SHALL NOT BE LIABLE FOR THE LOSS OF THE USE OF THE PRODUCT, INCONVENIENCE, LOSS OR ANY OTHER DAMAGES, DIRECT OR CONSEQUENTIAL, ARISING OUT OF THE USE OF, OR INABILITY TO USE, THIS PRODUCT OR FOR ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY APPLICABLE TO THIS PRODUCT.
Some provinces do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long an implied warranty lasts; so these limitations or exclusions may not apply to you. This warranty gives you specific legal rights and you may also have other rights which vary from province to province.
THE ABOVE WARRANTY DOES NOT APPLY TO:
1. Service trips to your home to deliver and pickup, install, instruct, or replace house fuses or correct wiring, plumbing, or correction of unauthorized repairs.
2. Damage to the product caused by accident, vermin, fire, flood, alteration, misuse, abuse, improper installation, or acts of God.
3. Commercial use or use for other than the intended purpose.
Therefore, these costs are the responsibility of the consumer.
CUSTOMER ASSISTANCE NUMBERS:
To Prove Warranty Coverage:
Retain your Sales Receipt to prove date of purchase.
A copy of your Sales Receipt must be submitted at the time warranty service is provided.
To Obtain Product, Customer, or Service Assistance by phone:
or by Internet:
To Obtain Nearest Authorized Service Center, Parts Distributor, or Sales Dealer by phone:
or by Internet:
Call
1-888-542-2623
appropriate prompt.
http://www.lg.ca
Call
1-888-542-2623
appropriate prompt. Please have your product type (refrigerator) and ZIP Code ready.
h t t p : / / www. lg .ca
(1-888-LG-CANADA) and choose the
(1-888-LG-CANADA) and choose the
Loading...
