Lg GC-154GQW User Manual

P/NO.3828JS8034M

FRIDGE-FREEZER

User's Guide

Please read this User's Guide carefully
before operating and keep it handy for
reference at all times.

Table of Contents

Introduction

Installation

Operation

Suggestion on

food storage

Care and

maintenance

Important safety Instruction
Disposal of the old appliance &

packing of new appliance
Identification of Parts

Location
Electrical Connection

Starting

Storing food
Making Ice

Defrosting
Cleaning
General Information

Tips for saving Energy

4

6
7

8

9

9

10

10

11

12

13

14

Trouble shooting

To Reverse the

Doors

Trouble shooting

How to Reverse the Door
Door handle

3

15

17
18

Introduction

The appliance is suitable for storing the frozen goods.
It is restricted for household use. If it is used for industrial or

commercial purpose, observe the related regulations firmly. If
using other purpose or misuse, the manufacturer is not
responsible for the damages of occasion.

Ignoring the recommendations for environmental use will
make your appliance consume higher energy.

Important Safety Instruction

Precaution

Don't use an

extension cord

This fridge-freezer must be properly installed and
located in accordance with the Installation
Instruction before it is used.

Never unplug your fridge-freezer by pulling on the
power cord. Always grip plug firmly and pull straight

out from the outlet.

When moving your appliance away from the wall,
be careful not to roll over or damage the power
cord.

After your fridge-freezer is in operation, do not
touch the cold surfaces in the freezer compartment,
particularly when hands are damp or wet. Skin may

adhere to these extremely cold surfaces.
Pull out the power plug prior to cleaning the fridge-

freezer.
Never damage, severely bend, pull out, or twist the
power cord because power cord damage may cause a
fire or electronic shock. Never place glass products in the
freezer because they may be broken when their inner
contents are frozen.

If possible, connect the fridge-freezer to its own
individual electrical outlet to prevent it and other
appliances or household lights from causing an overload.

4

5

Introduction

ww

Danger

Important Safety Instruction

Risk of child entrapment.
Before you throw away your old refrigerator or freezer:
Take off the doors.
Leave the shelves in place so that children may not easily

climb inside.

ww

Warning

w Keep ventilation openings, in the appliance enclosure

or in the built-in structure, clear of obstruction.

w Do not use mechanical devices or other means to

accelerate the defrosting process, other than those
recommended by the manufacturer.

w Do not damage the refrigerant circuit.
w Do not use electrical appliances inside the food storage

compartments of the appliance, unless they are of the
type recommended by the manufacturer.

w The refrigerant and insulation blowing gas used in the

appliance require special disposal procedures.
At disposal, please consult with service agent or a
similarly qualified person.

Grounding

(Earthing)

In the event of an electric short circuit, grounding (earthing)
reduces the risk of electric shock by providing an escape
wire for the electric current. In order to prevent possible
electric shock, this appliance must be grounded. Improper
use of the grounding plug can result in an electric shock.

Consult a qualified electrician or service person if the
grounding instructions are not completely understood, or if
you have doubts on whether the appliance is properly
grounded.

Accessibility of

Supply Plug

Supply Cord

Replacement

The supply plug of the refrigerator-freezer should be
placed in easy accessible position for quick disconnection
in emergency.

If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.

Introduction

Disposal of the old

appliance

Disposal of the old appliance &
packing of new appliance

The old appliance whose life has expired should be
destroyed in order to make it safe prior to disposal. Take
out power plugs, separate connection wires and remove
or destroy all springs, latches or bolting, to prevent
children from being trapped during play.

For environmental protection, old refrigerators should be
disposed off by a professional disposition agency. If you
have any question, please consult with the local sale
agency or local authority.

Disposal of

packing of new

appliance

All packing materials used for this appliance are
environment-friendly.

Matters concerning material are as follows:

PE : Polyethylene – Foil or pocket for packing
PS : Formed objects made of foamed

CFC-FREE polystyrene

PP : Strapping tape made of polypropylene

Take back offer

This appliance contains fluid (refrigerant, lubricant) and is
made of parts and materials which are reusable and/or
recyclable.

All the important materials should be sent to the
collection center of waste material and can be reused
after rework (recycling). For take back, please contact
with the local agency.

6

Identification of Parts

NOTE

This is a basic model. The shape of refrigerator is
subject to change.

7

Installation

Location

This appliance is suitable for using at ambient
temperature between +16°C and +38°C. If the ambient
temperature drops below +16°C, it is possible that the
freezing foods in the freezer compartment are thawed
because the temperature of the freezer gets warm.

To ensure proper air circulation around the fridge -freezer,
please maintain sufficient space on both the sides as well
as top and maintain at least 2 inches (5 cm) from the rear
wall.

NOTE

Place on a flat and firm flooring. If the floor is not
even, adjust the feet by using the leveling screw
at the front edge of the cabinet.

If the front is slightly higher than the rear, the door
can close more easily.

8

Installation

Electrical connection

This appliance should be connected to the mains AC
220~240V , 50 Hz. You must connect this appliance only
to the power socket with grounding complying with the
related regulations and only an approved expert should
install this appliance.

Operation

Starting

Before switching it on, leave the appliance standing for
at least 2 hours, so that the circulation of the refrigerant
stabilizes and no operating problems occur.

°C

h

When the appliance powers on, the initial state displayed
on LED is "-18°C".

Button K1 (Defrost):

Press button K1 for three seconds the first time, indicator "-", "°C",
"h" shut off, compressor stop running and the value displayed on
LED is"OF". Press button K1 for three seconds the second time ,
indicator "-", "°C", "h" display normally, compressor running
normally and LED displays the initial state.

Button K2 (Quick freezing):

Press butoon K2 for the first time, indicator "-", "°C"shut off,
indicator "h" light on and initial freezing time displayed is"3h".
Press button K2 for the second time the freezing time displayed
is "2h". Press button K2 for the third time the freezing time
displayed is "1h". The compressor will ren from 1hour to
3 hours according to the freezing time displayed on LED.
Press button K2 for the fourth time, the indicators will recover
the state before quick freeze.

Button K3 (Temperature regulation):

Press button K3 continuously, the provided temperature
displayed will be from -14°C to -24°C circularly.

9

Suggestion on food storage

Storing food

Opening the door often or keeping the door opened a
long time, increases the inside temperature. This causes
the storage life and flavor of the foods to reduce, and
increases the energy consumption.

NOTE

Do not touch deep-frozen foods with wet hands.
You could get chilblains on your hands.

Make sure foods that are not frozen do not touch the
frozen foods. The frozen foods may melt.

The packing materials suitable for refrigerating the foods are

- Polyethylene bags, Plastic foil, freezing containers.
The suitable wrapping materials are

- Rubber band, Plastic clips, attaching tape, string.
Before sealing, get rid of air from packing bags and foil.
The remained air makes the storing foods dry.

You can freeze foods quickly when packing is level. Do
not store bottles in freezer compartment. They may
break when frozen.

Making Ice

To make ice cubes, fill ice
tray 3/4 full with water and
place it on the bottom of the
freezer compartment.

To remove ice cubes, hold the ice tray at its ends and
twist gently.

Tips

To remove ice cubes easily, run water on the tray
before twisting.

10

Care and Maintenance

Defrosting

Defrosting the fridge compartment

When the freezer is working, frost is formed at the
rear wall of the fridge compartment and melts
automatically when the compressor stops.

Defrosting the freezer compartment

Humidity forms frost or ice in the freezer compartment
while the appliance is working or when the freezer door
is opened. The thick ice and frost decrease cool air and
increase the energy consumption.

Defrost Ice Layer

If the freezer compartment is heavily iced, defrost as
follows.

- Remove the frozen food, wrap in newspaper and store
in a cool place.

- Leave the door open, and wipe out water with a
sponge.

- Dry the freezer compartment thoroughly, turn on the
appliance, and replace frozen foods.

Tips

NOTE

It is helpful to place a saucepan with hot water inside
of the freezing room in order to assist defrost.

Never place electrical devices in the refrigerator
for defrost. Take care when using defrosting sprays

for assisting defrosting. These sprays include
substances containing explosive gas, or harmful for
synthesis or human health.

11

Care and Maintenance

Cleaning

Warning

Always remove plugs or Switch off supply before
cleaning.

Do not use sharp objects (such as knife, screwdriver)
which could break refrigerant circuit resulting in
environmental and health risks.

Never use steam cleaner or steam pressure cleaner since
hot steam may damage refrigerator surface and electrical
devices. Never use sand, abrasive detergent, acid or
chemical solvent.

• The freezer compartment should be cleaned at least
once a month.

• The most appropriate time for cleaning of the freezer
compartment is a time after defrosting.

• Clean refrigerator including inside devices with clothes
or lukewarm water. You may use commercial
detergent for tableware.

• Frequently clean the water drain inlet on the inside rear
side of refrigerator. Clean the drain inlet using objects
like a toothpick so that the drain inlet is not clogged.
Care should be taken so that cleaning water does not
overflows in the drain tub.

Regularly clean the heat exchanger on the rear side of
refrigerator using a smooth brush so that accumulations
of dusts and residues. Do not disrupt expansion from the
inside and cause increased energy consumption.

Any damage to the heat exchanger or other events
leading to the exposure of the refrigerant to the
environment, should be avoided because of
potential environment and health risks.

12

Care and Maintenance

General information

Going away

Power failure

If you move

Anti-condensation

pipe

When you plan to be away for an extended period,
remove all food, disconnect the power cord, clean the
interior thoroughly, and leave the door OPEN to prevent
odor formation.

Most power failures are corrected in an hour or two and
will not affect your refrigerator temperatures. However,
you should minimize the number of door openings while
the power is OFF. During power failures of longer
duration, place a block of dry ice on top of your frozen
packages.

Remove all items inside the refrigerator or securely fasten
all loose items. To avoid damaging the leveling screw,
turn them all the way into the base.

• The Anti-condensation pipe is
installed around the front side
of fridge-freezer to prevent
dewing.

• Especially after installation or
when ambient temperature is
high, the fridge-freezer may
feel hot, which is quite normal.

Anti-Condensation

Pipe

13

Care and Maintenance

Tips for saving Energy

- After moving the appliance, allow 2 hours to turn
on again.

- Do not place the appliance near radiator, stove,
and heat sources. If ambient temperature is high,
the compressor will run longer.

- Place the appliance on a cool and well ventilated
room. Do not expose to direct sunlight.

- Do not keep the door opened too long.

- Do not place warm food and beverages in
appliance. Please cool down first otherwise
the steam from hot foodstuffs would contribute
to the icing up of the evaporator unit; and the
cooling period should be as short as possible, for
health and hygiene reasons.

- Do not set the temperature of appliance lower than
needed.

- Place the deep-frozen foods for thawing into the
fridge.
They can be used for cooling the fridge.

- Replace magnetic door gasket of the door if it is
not properly functioning.

Disposal of your old appliance

1. When this crossed-out wheeled bin symbol is attached to a
product it means the product is covered by the European
Directive 2002/96/EC.

2. All electrical and electronic products should be disposed of
separately from the municipal waste stream via designated
collection facilities appointed by the government or the local
authorities.

3. The correct disposal of your old appliance will help prevent
potential negative consequences for the environment and
human health.

4. For more detailed information about disposal of your old
appliance, please contact your city office, waste disposal
service or the shop where you purchased the product.

14

Before calling for service, check this list.
It may save you both time and expense.
This list includes common occurrences that are not
the result of defective workmanship or materials in
this appliance.

Problem Possible Causes

Trouble Shooting

Fridge-Freezer

does not operate

Vibration or

Rattling or

Abnormal Noise

Temperature of foods

inside refrigerator is

not cold enough

The temperature

inside the refrigerator

is too cold

• Power plug may be unplugged from the electric
outlet.

Plug it in securely.

• House fuse has blown or circuit breaker has
tripped.

Check and/or replace fuse and reset circuit breaker.

• Power cut.

Check house lights.

• The floor on which the fridge-freezer is installed
may be uneven or the fridge-freezer may be
unstable.

Make it even by rotating the leveling screw.

• Unnecessary objects placed in the back side of the
fridge-freezer.

• Too frequent or too long door openings.
There is a heat source near Fridge-Freezer.
A large quantity of food was placed inside the
fridge compartment.

• The electronic controller is setting to extremely
low figure.

15

Trouble Shooting

16

Problem Possible Causes

Fridge has odor

• Foods with strong odors should be tightly
covered or wrapped

• Check for spoiled food

• Interior needs cleaning

• Refer to "Cleaning Section"

Moisture forms on

cabinet surface

• This phenomenon is likely to occur in a wet space.

Wipe it with a dry towel

17

To Reverse the Doors

Precaution

How to Reverse the Door

Your refrigerator is designed with a reversible door, so
you may open from either left or right. It is best to
reposition the door hinge as necessary at the outset since
it is inconvenient to do so later.
To change the door hinge please refer to the diagram
below and proceed as follows.

1. First unplug the appliance.

2. Remove foods and accessories like shelves or trays

which are not fixed in the refrigerator.

3. Carefully lay the appliance on a cushion like packing

material to avoid the damage of refrigeration circuit.

4. Use ‘+’ driver or spanner to fix or remove the bolts.

1. Unscrew the 2xBOLTS , then remove the hinge (L) .

2. Remove the LEG .

3. Gently pull the door downwards to remove it.

4. Before refitting the door, swap the Hinge Cap  by pulling
it out from its current location and repositioning it on the
other side of the door. Care should be taken not to damage
the adjacent surfaces when removing the Hinge Cap.

5. Unscrew the Upper Hinge pin (U)  and screw it into the
opposite side hole.

4

4

To Reverse the Doors

How to Reverse the Door

6. After refitting the door, fix the Lower Hinge(L) in the
opposite side by using 2xBOLTS.

7. Fix the Leg.

8. Carefully place the appliance in an upright position.
Adjust the Leveling screw to make sure the appliance
is steady and check that the door opens and closes
properly.

NOTE

In case of applying Reversible door, when you close
the door with excessive force, there could be the case
that the door doesn
force. Please ascertain if the door closes properly.

’t close because of Reaction

Door handle

NOTE

Reversing the doors is not covered by the warranty.

18

FRYSESKAP

Brukerveiledning

Les denne brukerveiledningen
grundig før du bruker fryseskapet,
og oppbevar den slik at den er lett
tilgjengelig når du måtte trenge den.

Innhold

Innledning

Installering

Bruk

Tips om oppbev-
aring av matvarer

Vedlikehold

Viktig sikkerhetsinformasjon
Kassering av gammelt fryseskap og

av emballasje fra nytt fryseskap

Produktark

Plassering

Nettilkopling

Oppstart

Oppbevaring av matvarer
Lage isbiter

Avtining
Rengjøring
Generell informasjon

Tips om energisparing

4

6

7

8

9

9

10
10

11
12

13

14

Feilsøking

Sette på døren
motsatt vei

Feilsøking

Hvordan sette på døren motsatt vei

Dørhåndtak

3

15

17

18

Innledning

Forholdsregler

Fryseskapet brukes til å oppbevare frysevarer.
Skapet skal kun brukes i privat husholdning. Dersom
det brukes til kommersielle formål, les gjeldende for-
skriftene nøye. Dersom fryseskapet brukes til andre
formål enn det er ment for, eller brukes på feil måte,
er ikke produsenten ansvarlig for skader som måtte
oppstå.
Dersom anbefalingene for miljøvennlig bruk ikke
følges, vil fryseskapet bruke mer energi.

Viktig sikkerhetsinformasjon

Dette fryseskapet må installeres riktig og plasseres
i samsvar med installeringsinstruksen før det tas i
bruk.

Kople aldri fra fryseskapet ved å trekke i strømled-
ningen. Ta godt tak i støpselet, og trekk det rett ut av

stikkontakten.

Når du skal flytte fryseskapet ut fra veggen, vær
forsiktig så du ikke trekker det over strømlednin-
gen slik at den blir skadet.

Når fryseskapet er slått på, må du ikke røre ved
overflatene inne i fryseskapet, spesielt hvis du
er våt eller fuktig på hendene. Huden kan nemlig

fryse fast i de svært kalde overflatene.
Trekk ut stikkontakten før du rengjør fryseskapet.
Du må aldri vri eller bøye strømledningen, trekke

ledningen ut av støpselet eller skade den på
andre måter. Skader på strømledningen kan
forårsake brann eller elektrisk støt. Sett aldri
glassbeholdere i fryseren, da de kan sprekke når
innholdet fryser og utvider seg.

Ikke bruk
skjøteledning

Kople om mulig fryseskapet til en egen stikkontakt
for å hindre at skapet, lamper eller andre apparater
forårsaker overbelastning.

4

Tilgang til
stikkontakt

Utskifting av
strømledning

Fare

Innledning

Viktig sikkerhetsinformasjon

Stikkontakten som fryseskapet er koplet til, bør plasseres
på et lett tilgjengelig sted, slik at skapet enkelt kan koples
fra i et nødstilfelle.

Hvis strømledningen er skadet, må den skiftes ut av
produsenten eller dennes serviceleverandør - eller av en
tilsvarende kvalifisert person - for å unngå at det oppstår
farlige situasjoner.

Barn kan bli stengt inne i fryseskapet.
Gjør derfor følgende før du kaster det gamle skapet
ditt: Ta av dørene.
La hyllene stå i fryseskapet slik at barn ikke så lett kan
krype inn.

Jording

Advarsel

Ved kortslutning reduserer jording risikoen for elektrisk støt
ved at strømmen ledes til jord. For å forhindre elektriske
støt må fryseskapet jordes. Feil bruk av jordingsstøpselet
kan føre til elektrisk støt.Kontakt en autorisert elektriker
eller servicetekniker dersom du ikke forstår instruksene
for jording, eller hvis du er i tvil om hvorvidt fryseskapet er
forsvarlig jordet.

Pass på at ingenting stenger for ventilasjonsåpnin-
gene inne i eller utenpå fryseskapet.

Ikke bruk mekaniske innretninger eller andre hjelpe-
midler for å tine av fryseskapet raskere, med mindre
disse er uttrykkelig anbefalt av produsenten.

Pass på så du ikke skader kjølevæskekretsen.
Ikke bruk elektriske innretninger inne i oppbevaring-

srommene i fryseskapet, med mindre disse innret-
ningene er anbefalt av produsenten.

Gasser fra fryseskapets kjølevæske og isolasjon skal
håndteres som spesialavfall.Når du skal kassere
fryseskapet, konsulter en servicetekniker eller en
annen kvalifisert fagperson.

5

Innledning

Kassering av gammelt fryseskap og
av emballasje fra nytt fryseskap

Kassering av
gammelt fryseskap

Kassering av
emballasje fra nytt
fryseskap

Tilbakelevering Apparatet inneholder væsker (kjølevæske og

Det gamle, utgåtte fryseskapet bør behandles slik at
det er trygt å kassere det. Trekk ut støpselet, ta fra
hverandre tilkoplingskabler og demonter eller ødelegg
alle fjærer, låser eller bolter for å unngå at barn
stenges inne i skapet under lek.
Av miljømessige hensyn bør gamle frysere kasseres
av et firma som håndterer spesialavfall. Hvis du har
spørsmål om kassering, ta kontakt med ditt lokale
utsalgssted eller med kommunen der du bor.

All emballasje for dette fryseskapet er laget av
miljøvennlig materiale.
Beskrivelse av materialet:

PE: Polyetylen - folie eller bobleplast
PS: Skumgummigjenstander av KFK-fri polystyren
PP: Pakketeip av polypropylen

smøremiddel) og er laget av deler og materialer som
er gjenbrukbare og/eller resirkulerbare.
Alle viktige materialer bør fraktes til din lokale av-
fallsstasjon for resirkulering. For tilbakelevering, ta
kontakt med ditt lokale utsalgssted.

6

Fryseskuff

Innledning

Produktark

Magnetisk
tetningsbånd

Høydejuster-
ingsskruer

MERK

Dette er en grunnmodell. Det fryseskapet du kjøper
kan se annerledes ut.

7

Installering

MERK:

For å sikre tilstrekkelig luftsirkulasjon rundt
fryse/kjøleskapet, må det være tilstrekkelig klaring
på begge sider sant på oversiden, og avstanden til
veggen bak kjøleskapet skal minst være 5 cm.

Elektroniske
kontroller

Installering

Nettilkopling

Dette apparatet skal koples til hovednett AC 220 - 240V, 50
Hz. Apparatet skal koples til jordede stikkontakter, i hen-
hold til gjeldende regler. Dette skal utføres av en autorisert
fagperson.

Bruk

Oppstart

La fryseskapet stå i minst to timer før du slår det på,
slik at kjølevæskesirkulasjonen stabiliserer seg.

¡C

h

Når fryseskapet er slått på, er standardtemperaturen
som vises i displayet «-18 °C».

Knapp K1 (DEFROST):

Trykk først på knapp K1 i tre sekunder, til indikatorene
«-», «°C» og «h» slås av, kompressoren stopper og
displayet viser «OFF». Hvis du deretter trykker på
knapp K1 i tre sekunder, vil indikatorene «-», «°C» og
«h» vises som normalt, kompressoren kjøre og den
opprinnelige temperaturverdien vises i displayet.

Knapp K2 (QUICK FRZ):

Trykk først på knapp K2, til indikatorene «-» og «°C» slås
av, «h» lyser og innfrysingstiden vises som «3h».Trykk
på knapp K2 igjen hvis du vil at innfrysingstiden skal vis-
es som «2h». Trykk på knapp K2 en tredje gang dersom
innfrysingstiden skal vises som «1h». Kompressoren vil
kjøre fra én til tre timer, alt etter hvilken verdi som vises i
displayet.Dersom du trykker på knapp K2 en fjerde gang,
vil indikatorene gå tilbake til de gjeldende innstillingene
fra før du stilte inn fryseren på quick freeze.

Knapp K3 (FRZ TEMP.):

Dersom du holder knapp K3 inne, vil temperaturen kunne
stilles inn fra -14 °C til -24 °C.
