LG AN-VC200 User Manual

OWNER’S MANUAL

Video Call Camera

Please read this manual carefully before operating your set and retain it for future reference.

AN-VC200

www.lg.com

CONTENTS

PREPARATION

Overview ............................................................... 3

Installing the Video Call Camera

USING Skype

Start Skype ........................................................... 5

Create account / Sign in Skype menu

Contacts .............................................................................7

Add Contact

Call Phones

History

................................................................................ 8

..................................... 5

..........................................................7

......................................................................7

.......................................................................7

....................... 4

My Information

Settings

Make a Video Call to the Contact ...................... 9

Make a Call (Voice only) to a Contact Receiving a Call Call when watching TV

............................................................................ 8

APPENDIX

Troubleshooting ...................................................11

Product Specifications

............................................................... 8

..............10

..................................................10

.......................................10

.......................................12

Product Handling

■ Do not let the camera get wet. Liquid getting into the camera could cause a short circuit.

■ Wipe the camera gently with a dry cloth to remove any dust or dirt. If the product is very dirty, spray a mild detergent on the cloth first.

■ Do not clean with thinner, alcohol, benzene or any other volatile agent. These may damage the product's surface or affect its operation.

■ Do not disassemble, repair or alter the product. Incorrect disassembly may cause a fire, electric shock, or injury.

■ Do not shake the camera.

■ Do not pull on the cable.

Installation Instructions

■ Make sure you have enough space for connections when installing the product.

■ Do not install in a dusty, dirty or moist area.

■ Do not install in direct sunlight or near a heat source.

■ Magnetic objects, such as speakers, may interfere with the camera’s operation.

■ Install the product in a place with moderate temperature and humidity. The recommended temperature range is 0 °C (32 °F) to 40 °C (104 °F).

■ Strong electromagnetic waves from other devices could interfere with the camera’s operation.

■ Remove all the protective plastic bags (Vinyl) before use.

The product and company names contained in this manual may or may not be registered trademarks or copyrights, and are only used for identification or explanatory purposes. All trademarks reserved.

The AN-VC200 is a Video Call Camera that can be used with some LG TVs. The following model lines are supported:

LCD TV: LX9500, LX6500, LE8500, LE7500, LE5500, LE5400, LE5350, LD650, LD550 PDP TV: PX950, PK950, PK750

(*every model line listed is not available in every country).

PREPARATION

OVERVIEW

Microphones

Lens

Microphones

Stand-Arm

Stand-Support

Activity Indicator

Stand

Stand-Bottom

NOTE:

► For best results when using a external speakers on your TV, only use the front right/left (stereo) speakers when using

Skype.

► When making a video call with Skype using a PC, the Skype software version for Windows should be 4.2 or newer.

(Visit the Skype homepage (www.skype.com) for operating systems other than Windows, e.g. OS X, Linux, etc.)

► Video calls can not be made to a Mac that runs Skype 2.8 or lower. ► Content can be changed or deleted depending on Content Provider. ► Please visit the content providers web site for specific information on their services. ► The software update screen will automatically appear when an update is available.

PREPARATION

INSTALLING THE VIDEO CALL CAMERA

Unfold the stand and put it on the top center of

the TV set.

Fold the stand.

Video Call Camera

PREPARATION

(A) For a TV with thick bezel, connect just the end

of the stand to the back of the TV as shown in (A).

(B) For a TV with slim bezel, place the entire

bottom side of the stand on the back of the TV set.

Connect the USB cable to the side of the TV.

(A)

(B)

USB IN 1 USB IN 2

IN 4

NOTE

► For the best quality video and audio outputs, install the camera on the top-center of your TV. ► Set up with the television switched off.

► When using external speakers, allow sufficient space between the microphones and the speakers. ► The TV must be connected to a network for Skype to work.
