LG 55EG5CD, 55EG5SD User Guide

OWNER’S MANUAL

LG Digital Signage

(MONITOR SIGNAGE)

Please read this manual carefully before operating your set and retain it for future reference.

55EG5CD

55EG5SD

www.lg.com

TABLE OF CONTENTS

ENGLISH

IMPORTANT PRECAUTIONS .........3

- Electrical Power Related Precautions ....................3

- Precautions for installing the Product ..................5

- Precautions for Moving the Product ......................6

- Precautions for Using/Cleaning the Product .....7

- Product Disposal (Only, Hg lamp used LCD

Monitor) .................................................................................7

LICENSES .......................................8

ASSEMBLY AND PREPARATION ..9

- Installing on the ceiling ...............................................11

- External Equipment Setup........................................12

REMOTE CONTROL .................... 13

MAKING CONNECTIONS ........... 15

- Connecting to a PC.......................................................15

- External Device Connection .....................................15

- Connect a USB Storage Device ..............................15

- Using the Input List ......................................................17

TROUBLESHOOTING .................. 18

PRODUCT SPECIFICATIONS ...... 20

WARNING - This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may cause radio interference.

IMPORTANT PRECAUTIONS

Please read these safety precautions carefully before using the product.

WARNING

Failure to follow those warnings may result in death, serious injury or damage to the product or other property.

CAUTION

If you ignore the caution message, you may be slightly injured or the product may be damaged.

WARNING

• Indoor Use Only.

Electrical Power Related Precautions

WARNING

• Use only the power cord supplied with the unit or another manufacturer’s authorized cord.

- Failure to do so may result in fire or electrical shock or damage to the product.

• Use only a properly grounded plug and receptacle.

- If you do not you may be electrocuted or injured. Or the product might be damaged.

• Do not use a damaged or loose plug.

- This may cause electrical shock or fire.

• Operate the display only from a power source(i.e. voltage) indicated in the product specification.

- Otherwise the product can be damaged, fire can occur or you may be electrocuted. If you are not sure what type of power supply you have, consult a certified electrician.

• In the presence of thunder and lightning, never touch the power cord and signal cable because it can be very

dangerous.

- It can cause electric shock.

• Do not connect several extension cords, electrical appliances or electrical heaters to a single outlet. Use a power strip

with a grounding terminal designed for exclusive use with the computer.

- A fire can break out due to overheating.

• Do not touch the power plug with wet hands. Additionally, if the cord pin is wet or covered with dust, dry the power

plug completely or wipe dust off before plugging in the cord.

- You may be electrocuted due to excess moisture.

ENGLISH

• If you don’t intend to use the product for a long time, unplug the power cable from the product.

ENGLISH

- Layers of dust can cause a fire, or insulation deterioration can cause electric leakage, electric shock or fire.

• Insert the power plug firm so it cannot come loose.

- A loose connection can cause fire.

• Hold the plug when pulling out the power cable. Do not pull the plug out by the wire. Do not bend the power cord

with excessive force or put heavy objects on the power cord.

- The power line can be damaged, which may cause electric shock or fire.

• Do not insert metal or other conductive materials into the product openings. Additionally, do not touch the power

cable right after plugging into the wall input terminal.

- You may be electrocuted.

• Use an appliance coupler as a disconnect device.

• Please make sure the device is installed near the wall outlet to which it is connected and that the outlet is easily

accessible.

• Do not unplug the power cord while the product is in use.

- Electrical shock can damage the product.

• As long as this unit is connected to the AC wall outlet, it is not disconnected from the AC power source even if the

unit is turned off.

Precautions for installing the Product

WARNING

• Keep away from heat sources like heaters or open flames.

- Electrical shock, fire, malfunction or deformation may occur.

• Keep the packing anti-moisture material or vinyl packing out of the reach of children.

- Anti-moisture material is harmful if swallowed. If swallowed by mistake, force the patient to vomit and visit the nearest hospital. Additionally, vinyl packing can cause suffocation. Keep it out of the reach of children.

• Do not put heavy objects on the product or sit upon it.

- If the product collapses or is dropped, you may be injured. Prevent Children from climbing or pulling on the unit.

• Do not leave the power or signal cable where someone can trip over it.

- Pedestrians may become entangled in the cables and cause the device to become damaged causing electrical shock, fire, or serious injury.

• Install the product in a neat and dry place. Do not use near water.

- Dust or moisture can cause electrical shock, fire or product damage.

• Do not add accessories that have not been designed for this display.

• If you smell smoke or other odors or hear a strange sound from the product unplug the power cord and contact LG

Customer Service.

- If you continue to use without taking proper measures, electrical shock or fire can occur.

• If you dropped the product or the case is broken, turn off the product and unplug the power cord.

- If you continue to use without taking proper measures, electrical shock or fire can occur. Contact LG Customer Service.

• Do not drop an object on or apply impact to the product. Do not throw any toys or objects at the product.

- It can cause injury to humans, problems to the product and damage the display.

• Keep out of reach of children and do not place toys near the product.

• Make sure the product ventilation hole is not blocked. Install the product more than 100 mm (3.9 inches) from the

wall.

- If you install the product too close to the wall, it may be deformed or fire can break out due to internal heat buildup.

• Do not cover the product with cloth or other material (eg. plastic) while plugged in.

- The product can be deformed or fire can break out due to internal overheating.

• Place the product on a flat and stable surface that is large enough to support the product.

- If the product is dropped, you may be injured or the product may be broken.

• Install the product where no Electromagnetic Interference occurs.

• Keep the product away from direct sunlight.

- The product can be damaged.

• Do not place the product on the floor.

- Small Children and others may trip over it.

• Do not install this product on a wall if it could be exposed to oil or oil mist.

- This may damage the product and cause it to fall.

• For displays with glossy bezels the user should consider the placement of the display as the bezel may cause

unwanted reflections from surrounding light and bright surfaces.

ENGLISH

Precautions for Moving the Product

ENGLISH

WARNING

• Make sure to turn off the product.

- You may be electrocuted or the product can be damaged.

• Make sure to remove all cables before moving the product.

- You may be electrocuted or the product can be damaged.

• When lifting or moving the product, do not hold it upside down while holding only the stand.

- This may cause the product to fall resulting in damage or injury.

• Do not shock the product when moving it.

- You may be electrocuted or the product can be damaged.

• Make sure the panel faces forward and hold it with both hands to move.

- If you drop the product, the damaged product can cause electric shock or fire.

• Do not place the product face down.

- This may damage the TFT-LCD screen.

Precautions for Using/Cleaning the Product

WARNING

• Do not attempt to disassemble, repair or modify the product yourself.

- Fire or electric shock can occur.

- Contact LG Customer Service for repair.

• When cleaning the product, unplug the power cord and scrub gently with a soft cloth to prevent scratching. Do not

clean with a wet cloth or spray water or other liquids directly onto the product. An electric shock may occur. (Do not use chemicals such as benzene, paint thinners or alcohol.)

• Keep the product away from water.

- Fire or electric shock accident can occur.

• Avoid high temperatures and humidity.

• Do not put or store flammable substances near the product.

- There is a danger of explosion or fire.

• Keep the product clean at all times.

• Take a comfortable and natural position when working with the product.

• Take a regular break when working with the product for a long time.

• Do not press on the panel with a hand or sharp object such as nail, pencil or pen, or make a scratch on it.

• Keep proper distance from the product and rest from time-to-time.

- Your vision may be impaired if you look at the product too closely or for too long.

• Set the appropriate resolution by referring to the User’s Guide.

• Keep small accessories out of the reach of children.

• Displaying a still image for long time on the monitor may leave persistent image or stain on the monitor screen. To

avoid this problem, use a screen saver and power off when this product is not used. Persistent image or stain caused by long time usage are not covered by the warranty on this product.

• Do not use products using high voltage around the Monitor. (ex. Electrical Swatter)

- Monitor may have malfunction as its electrical shock.

• Spray water onto a soft cloth 2 to 4 times, and use it to clean the front frame;wipe in one direction only. Too much

moisture may cause staining.

ENGLISH

WATER

CHEMICALS

Product Disposal (Only, Hg lamp used LCD Monitor)

• The fluorescent lamp used in this product contains a small amount of mercury.

• Do not dispose of this product with general household waste.

• Disposal of this product must be carried out in accordance to the regulations of your local authority.

LICENSES

ENGLISH

Supported licenses may differ by model. For more information of the licenses, visit www.lg.com.

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.

Manufactured under license from Dolby Laboratories. Dolby, Dolby Vision, Dolby Audio, Dolby Atmos, and the double-D symbol are trademarks of Dolby Laboratories.

For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licensing Limited. DTS, the Symbol, & DTS and the Symbol together, DTS 2.0 Channel, DTS 2.0+Digital Out, DTS-HD, and DTS Virtual:X are registered trademarks or trademarks of DTS, Inc. in the United States and/or other countries. © DTS, Inc. All Rights Reserved.

ASSEMBLY AND PREPARATION

CAUTION

• Always use genuine components to ensure safety and product performance.

• The product warranty will not cover damage or injury caused by the use of counterfeit components.

• Connect the power cord to the product before you plug it into a wall outlet. Plugging the power cord into a wall

outlet first may cause an electric shock, which can also damage the product.

NOTE

• The accessories provided with your product may vary depending on the model or region.

• Product specifications or contents in this manual may be changed without prior notice due to upgrade of product

functions.

• SuperSign Software & Manual

- Downloading from the LG Electronics website.

- Visit the LG Electronics website (http://partner.lge.com) and download the latest software for your model.

• The warranty will not cover any damage caused by using the product in an excessively dusty environment.

WARNING

• The product warranty does not cover any electrostatic damage to parts that may occur during product installation.

Wear the appropriate gear that can prevent electrostatic discharge (ESD) when installing the product.

• The serial number on the panel and that on the T-Con Box must match. If they do not, spots may appear on the

screen or the product may not function properly.

(Depending on model)

ENGLISH

Installing on the ceiling

ENGLISH

(Only for 55EG5CD model)

When installing, do not install more than 30cm (11.8inches) away from the ceiling for safe cable connection.

30cm (11.8inches)

or less

CAUTION

• Disconnect the power cord before moving or installing the monitor to avoid risk of electric shock.

• Use a stainless steel wire rope that can bear enough weight (100kgf or above). (Sold separately)

2mm (0.07inches) Diameter Stainless Steel Wire Rope

Crimp sleeve

• If you are using an installation accessory, make sure that you use a stainless steel wire rope that is 2mm

(0.07inches) in diameter.

- Use a press for compression when using a crimp sleeve. If not, the wire may fall out.

NOTE

• The illustration shows a general example of installation and may look different from the actual product.

• The distance from the ceiling may be 30cm (11.8inches) or less after installation depending on the state of the

ceiling.

External Equipment Setup

IR RECEIVER

This allows a remote control sensor to be placed in a custom location. Then that display can control other displays via an RS-232C cable.

ENGLISH

REMOTE CONTROL

ENGLISH

The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully to use the monitor correctly. To install batteries, open the battery cover, place batteries (1.5V AAA) matching and

terminals to the labels inside the compartment, and close the battery cover. To remove the batteries, perform the

installation actions in reverse. The illustrations may differ from the actual accessories.

CAUTION

• Do not mix old and new batteries, as this may damage the remote control.

• Ensure the remote control is always pointed toward the monitor’s IR receiver.

• Some features of the remote control may not be supported in certain models.

(POWER) Turns the monitor on or off.

Turns the monitor on.

Turns the monitor off.

Reduces power consumption by adjusting peak screen

brightness.

(INPUT) Selects the input mode.

Used for viewing 3D videos.

Toggles between numerical and alphabetical.

Number and Alphabet buttons

Enters numerical or alphabetical characters depending upon the setting.

Deletes the entered numerical or alphabetical character.

Volume Up/Down Button Adjusts the volume.

Selects the Aspect Ratio mode.

Automatically adjusts picture position and minimizes image instability

(available for RGB input only).

(MUTE) Mutes all sounds.

Adjusts the brightness of the display.

PAGE function is not supported in this model.

Selects the Picture Mode.

(HOME) Activates the Launcher.

Enters the White Balance menu.

(SETTINGS) Accesses the main menus or saves your input and exit menus.

SuperSign menu key.

Navigation Buttons Scrolls through menus or options.

Selects menus or options and confirms your input. (BACK) Allows you to move back one step in the user interaction function.

Quit all OSD tasks and applications.

Allows you to control various multimedia devices to enjoy

multimedia simply by using the remote control through the SimpLink menu.

Selects the TILE Mode.

When the Picture ID number matches the Set ID number,

you can control whichever monitor you want in multi-display format. USB Menu Control Buttons Controls media playback.

Trick key May not be supported on some models.

ENGLISH

MAKING CONNECTIONS

ENGLISH

You can connect various external devices to your monitor. Change the input mode and select the external device you want to connect. For more information about external device connections, see the user manual provided with each device.

Connecting to a PC

Some of the cables are not provided. This monitor supports the Plug and Play* feature.

* Plug and Play: a feature that enables a PC to recognize devices attached by the user without device configuration or

user intervention when powering up.

External Device Connection

Some of the cables are not provided. Connect a HD receiver, DVD, or VCR player to the monitor and select an appropriate input mode.

For the best picture and sound quality, connecting external devices to your monitor using HDMI cables is recommended.

Connect a USB Storage Device

Some USB devices may not work if it does not meet the USB 3.0 standards.

NOTE

• For the best image quality, using the monitor with HDMI connection is recommended.

• To comply with the specifications of the product, use a shielded interface cable with ferrite core, such as a HDMI

cable.

• If you turn the monitor on when the set is cold, the screen may flicker. This is normal.

• Sometimes red, green, or blue spots may appear on the screen. This is normal.

• Use a High Speed HDMI®/TM cable (shorter than 3meters (9.8 ft)).

• Use a certified cable with the HDMI logo attached. If you do not use a certified HDMI cable, the screen may not

display or a connection error may occur.

• Recommended HDMI Cable Types

- High-Speed HDMI®/TM Cable

- High-Speed HDMI®/TM Cable with Ethernet

• If you cannot hear any sound in HDMI mode please check your PC settings. Some PCs require you to manually change

the default audio output to HDMI.

• If you want to use HDMI-PC mode, you must set your PC/DTV to PC mode.

• You may experience compatibility issues if you use HDMI-PC mode.

• Make sure the power cable is disconnected.

• If you connect a gaming device to the monitor, use the cable provided with the gaming device.

CAUTION

• Do not press the screen with your finger for a prolonged period as this may result in temporary distortion on the

screen.

• Avoid displaying static images on the screen for a long period of time to prevent image retention. Use a screensaver

if possible.

• A wireless communication device near your monitor can affect the image.

ENGLISH

Using the Input List

ENGLISH

(HOME) →

• HDMI → DISPLAYPORT → OPS

TROUBLESHOOTING

No image is displayed.

Problem Action

Is the product power cord connected? • Check if the power cord is correctly plugged into the power outlet.

Does the “Invalid Format” message appear?

Does the “No Signal” message appear? • The signal cable between PC and product is not connected. Check the

The “Unknown Product” message appears when the product is connected.

Problem Action

Did you install the driver? • Check if the Plug and Play function is supported by referring to the

The screen image looks abnormal.

Problem Action

Is the screen position wrong? • Check if the graphics card resolution and frequency are supported by

The screen is displayed abnormally. • The proper input signal is not connected to the signal port. Connect

• The signal from the PC (Graphics card) is out of the vertical or

horizontal frequency range of the product. Adjust the frequency range by referring to the Specifications in this manual.

signal cable.

• Access the input menu to check the input signal.

graphics card user manual.

the product. If the frequency is out of range, set to the recommended resolution in the [Control Panel] → [Display] → [Setting] menu. (The settings may differ depending on your operating system.)

the signal cable that matches with the source input signal.

ENGLISH

The audio function does not work.

ENGLISH

Problem Action

No sound? • See if the audio cable is connected properly.

• See if the sound is set properly.

Sound is too dull. • Select the appropriate equalizer sound.

Screen color is abnormal.

Problem Action

Screen has poor color resolution (16 colors).

Screen color is unstable or mono-colored. • Check the connection status of the signal cable. Or, re-insert the PC

Do black spots appear on the screen? • Several pixels (red, green, blue, white, or black color) may appear on

The operation does not work normally.

Problem Action

The power suddenly turned off. • Is the Timer set?

• Set the number of colors to more than 24bits (true color). Select

[Control Panel] → [Display] → [Settings] → [Color Table] in Windows. (The settings may differ depending on your operating system.)

graphics card.

the screen, which can be attributable to the unique characteristics of the OLED panel. This is not a malfunction of the OLED.

• Check the power control settings. Power interrupted.

• Are the fans functioning properly?

- View the fan status in HOME → Information → Fan Status.

CAUTION

• Image sticking may occur when displaying a fixed image for an extended period of time. It is recommended that you

display videos for 18hours or less per day to decrease the likelihood of image sticking.

• A few horizontal lines may appear on the screens while running the Clear Panel Noise feature (OFF-RS). This is

normal, so there is no need for concern. Turning the power on while the Clear Panel Noise feature (OFF-RS) is operating may cause the product to malfunction. The external speakers connected to the product may make a sound while you are running the Clear Panel Noise feature (OFF-RS).

• OFF-RS: Removes image sticking through TFT degradation compensation. Runs after 4hours of use.

JB: Removes image sticking through OLED degradation compensation. Runs after 2000hours of use.

PRODUCT SPECIFICATIONS

The product specifications below may be changed without prior notice due to upgrade of product functions. “ ” refers to alternating current (AC), and “ ” refers to direct current (DC).

OLED screen Pixel Pitch 0.630mm (H) X 0.630mm (V)

Screen type Thin Film Transistor (TFT)

OLED Screen

Operating conditions Daily usage 18 hours (video)

Video signal Maximum resolution HDMI / DisplayPort: 3840x2160@30Hz

OPS: 1920x1080 @60Hz

- This may not be supported on some OS or graphics card types.

Recommended resolution

Horizontal frequency HDMI/ DisplayPort/ OPS: 30kHz to 83kHz

Vertical frequency HDMI/ DisplayPort/ OPS: 50Hz to 60Hz

Synchronization Separate/Digital

Input/ Output ports IR IN, RS-232C IN/OUT, AUDIO OUT, HDMI IN, DP IN/OUT, USB3.0 IN, LAN IN/OUT, HDMI

OUT, 16/22PIN POWER

Embedded battery Applied

Environmental Conditions Operating Temperature 0°C to 40°C (32 °F to 104 °F)

Operating Humidity 10% to 80%

Storage Temperature -20°C to 60°C (-4 °F to 140 °F)

Storage Humidity 5% to 85%

Power Rated Voltage AC100-240V ~ 50/60Hz 3.0A

Power Consumption On Mode: 190W (Typ.)

Dimensions (Width x Height x Depth)

/ Weight

Display Module 55EG5CD 861.3X1406.2X13 (mm) / 31.2 (kg)

Signage Box 412.6X222.4X64.3 (mm) / 4.3 (kg)

T-con Box 312.2X213.4X16 (mm) / 1.6 (kg)

HDMI / DisplayPort / OPS: 1920x1080@60Hz

- This may not be supported on some OS or graphics card types.

Sleep Mode (HDMI, DisplayPort): ≤3.0W Off Mode: ≤0.5W

33.9X55.3X0.5 (inches) / 68.7 (lbs)

55EG5SD 861.3X1600X13 (mm) / 35.6 (kg)

33.9X62.9X0.5 (inches) / 78.4 (lbs)

16.2X8.7X2.5 (inches) / 9.4 (lbs)

12.2X8.4X0.6 (inches) / 3.5 (lbs)

ENGLISH

 

ENGLISH

Display

55EG5CD 55EG5SD

1406.2 (55.3)

861.3 (33.9)

(0.5)

Signage Box

412.6 (16.2)

1600

(62.9)

861.3 (33.9)

[Unit : mm (inches)]

(0.5)

[Unit : mm (inches)]

222.4 (8.7)

64.3 (2.5)







T-con Box

312.2 (12.2)

ENGLISH

[Unit : mm (inches)]

213.4 (8.4)

16 (0.6)

HDMI/ DisplayPort/ OPS (PC) Support mode

ENGLISH

Resolution Horizontal frequency (kHz) Vertical frequency (Hz) Remarks

800 x 600 37.879 60.317

1024 x 768 48.363 60

1280 x 720 44.772 59.855

1366 x 768 47.7 60

1280 x 1024 63.981 60.02

1680 x 1050 65.29 59.954

1920 x 1080 67.5 60

3840 x 2160 67.5 30

HDMI/ DisplayPort/ OPS (DTV) Support Mode

Resolution Horizontal frequency (kHz) Vertical frequency (Hz) Remarks

480/60p 31.5 60

576/50p 31.25 50

720/50p 37.5 50

720/60p 45 60

1080/50i 28.1 50

1080/60i 33.75 60

1080/50p 56.25 50

1080/60p 67.432 59.94

1080/60p 67.5 60

2160/30p 67.5 30

Only applies to HDMI /

DisplayPort

Only applies to HDMI /

DisplayPort

NOTE

• Resolutions available for the Input Label option in HDMI/ DisplayPort/ OPS input modes.

- PC resolutions: 1280x720 / 60Hz, 1920x1080 / 60Hz

- DTV resolutions: 480p, 720p and 1080p

• Vertical frequency: The product display functions by the screen image changing dozens of times every second like a

fluorescent lamp. The vertical frequency or refresh rate is the number of image displays per second. The unit is Hz.

• Horizontal frequency: The horizontal interval is the time taken to display one horizontal line. When 1 is divided by

the horizontal interval, the number of horizontal lines displayed every second can be tabulated as the horizontal frequency. The unit is kHz.

ENGLISH

Make sure to read the Safety Precautions before using the product.

The model and serial numbers of the SET are located on the back and one side of the SET. Record it below should you ever need service.

MODEL

SERIAL

Temporary noise is normal when powering ON or OFF this device.

USER GUIDE

LG Digital Signage

(MONITOR SIGNAGE)

Please read this manual carefully before operation and retain it for future reference.

webOS 3.2

www.lg.com

CONTENTS

ENGLISH

SETTINGS ......................................4

- Home ....................................................................................... 4

[Global Buttons]

[Dashboard]

[Content Manager]

- Ez Setting ............................................................................. 5

[Video Wall]

[On/Off Scheduler]

[SI Server Setting]

[Server Setting]

[Fail Over]

[Status Mailing]

[Play via URL]

[Setting Data Cloning]

[Sync Mode]

[Signage 365 Care]

[Multi Screen]

- General ................................................................................11

[Language]

[System Information]

[Set ID]

[Time & Date]

[Power]

[Network]

[Safety Mode]

[Expert Controls]

- Display .................................................................................25

[Picture Mode]

[Aspect Ratio]

[Rotation]

[Expert Controls]

- Sound ................................................................................... 31

[Sound Mode]

[Sound Out]

[Audio Out]

[Volume Increase Amount]

[AV Sync. Adjust]

[Digital Audio Input]

- Admin ................................................................................... 34

[Lock Mode]

[Change PIN Code]

[Enterprise Settings]

[Reset to Initial Settings]

[Factory Reset]

CONTENT MANAGER ................ 36

- Web Login ..........................................................................36

- Content Manager ..........................................................36

[Player]

[Scheduler]

[Template]

- Group Manager 2.0 ......................................................43

- ScreenShare ......................................................................46

MANAGEMENT TOOLS .............. 47

- Control Manager ............................................................47

- Picture ID ............................................................................48

TOUCH ........................................ 49

- Touch Assistive Menu ..................................................49

- IDB (Interactive Digital Board)................................50

ENGLISH

IR CODE ...................................... 51

CONTROLLING MULTIPLE

PRODUCTS .................................. 53

- Connecting cables .........................................................53

- Communication Parameter ......................................54

- Command Reference List ..........................................55

- Transmission/Reception Protocol .........................59

To obtain the source code under GPL, LGPL, MPL, and other open source licenses, that is contained in this product, please visit http://opensource.lge.com.

In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download.

LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com.

This offer is valid for a period of three years after our last shipment of this product. This offer is valid to anyone in receipt of this information.

ENGLISH

NOTE

• Software-related content may be changed without prior notice due to upgrades of the product functions.

• Some features described in the User Manual may not be supported in certain models and countries.

• SNMP 2.0 is supported.

SETTINGS

Home

[Global Buttons]

• [MOBILE URL]: Provides information necessary to access the monitor set through an external device's browser.

With this feature, you can view QR code and URL information. In addition, by accessing the URL, you can also run Content Manager and Group Manager 2.0, and Control Manager. (This featured is optimized for Google Chrome.)

• [Input]: Navigate to the external input selection screen

• [Settings]: Navigate to the Settings screen

[Dashboard]

• This feature displays key information about your Signage monitor in the center of the home screen. In the Dashboard,

you can manually change settings by selecting the corresponding items.

NOTE

• If the dashboard is locked, the focus does not move.

[Content Manager]

• [Player]: Play a variety of content including images, videos, and SuperSign content.

• [Scheduler]: Manage schedules for content that will be played at different times.

• [Template]: You can create your own content using templates and media files.

• [Group Manager 2.0]: Distribute content schedules and setting data to the connected device.

Ez Setting

[Video Wall]

[Ez Setting] [Video Wall]

Set Video Wall options to create a wide visual canvas.

• [Tile Mode]: Turn [Tile Mode] on or off.

• [Tile Mode Setting]: Display a single integrated screen on multiple Signage monitors.

• [Natural Mode]: Display the image excluding the area that overlaps with the monitor's bezel so that the image

displayed has a more natural feel to it.

• [Frame Control]: Adjust the sets that run [Scan Inversion] and frame deviation.

- When running [Scan Inversion], please run [Frame Control] for the sets that do not run [Scan Inversion].

• [Scan Inversion]: Reduce screen deviation between adjoining video walls by changing screen scanning method.

• [White Balance]: Configure white balance settings (White Pattern, R/G/B-Gain, and Luminance).

• [RESET]: Reset to initial settings.

NOTE

• When Tile Mode is enabled, automatically set [Frame Control] for odd numbered rows and [Scan Inversion] for even

numbered rows.

[On/Off Scheduler]

[Ez Setting] [On/Off Scheduler]

Set a schedule to use your signage by time and day of the week.

• [On/Off Time Setting]: Set on/off times for each day of the week.

• [Holiday Setting]: Set holidays by date and by day of the week.

ENGLISH

[SI Server Setting]

[Ez Setting] [SI Server Setting]

Set up to connect your signage to an external SI server. Set up a server environment for SI app installation.

[Ez Setting] [SI Server Setting] [Developer Mode & Beanviser] This feature provides great convenience to the app developers. Set up to install and activate the Developer mode and BEANVISER app.

NOTE

• To use these features, an account (ID/Password) for webOS Signage developer website (http://webossignage.

developer.lge.com/) is required.

[Server Setting]

ENGLISH

Set up to connect your signage to a SuperSign server.

• CMS servers

• Control servers

[Ez Setting] [Server Setting]

[Fail Over]

[Ez Setting] [Fail Over]

This feature enables automatically switching to other input sources in order of priority if the primary signal is interrupted. It also enables the automatic playback of the content stored on your device.

• [On/Off]: Turns [Fail Over] on or off.

• [Input Priority]: Set the priority of input sources for fail over.

• [Backup via Storage]: Automatically play the content stored on the device when there is no input signal. Set to [On]

to activate Auto, Manual, and [SuperSign Contents].

- Auto: When the automatic input switches due to taking screenshots of an image or video that is playing at regular intervals, this feature will play back the file. (OLED model is not supported.)

>- [Capture time Interval]: The time interval can be set to 30 min, 1 hour, 2 hours and 3 hours.

- Manual: When the automatic input switches due to the image and video file being uploaded, the feature will play back the file.

>- [Backup media select]: Using the settings button, you can upload a single file in the internal / external memory. >- [Preview]: You can preview the uploaded file.

- [SuperSign Contents]: When the automatic input switches, this feature will play the file(s) distributed in SuperSign CMS.

• [RESET]: Reset to initial settings.

[Status Mailing]

[Ez Setting] [Status Mailing]

This feature configures the system so that the status of the device is assessed and then notified to the administrator by e-mail.

• [On/Off]: Turns [Status Mailing] on or off.

• [Mailing Option], [SCHEDULE]: Sets the email sending interval.

• [User E-mail Address]: Set the user email address of the sender.

• [Sending Server(SMTP)]: Set the address of the SMTP server.

• [ID]: Enter the account ID of the sender.

• [Password]: Enter the password for the sender's account.

• Recipient E-mail Address: Set the email address of the recipient.

• Message Delivery: Immediately assess the status of the device and deliver the information to the specified email

address.

• [RESET]: Reset to initial settings.

+ 75 hidden pages
