LG Electronics 32LH7000-ZA, 37LH7000-ZA, 42LH7000-ZA, 47LH7000-ZA User Manual

User’s Guide Specification

User’s Guide Specification

담 당 관리자

SHIN HJ

Model Description

1.

MODEL

SUFFIX

2.

“This part contain Eco-hazardous substances (Pb, Cd, Hg, Cr6+, PBB, PBDE, etc.) within LG standard level,

N
O
T
E
S

32/37/42/47LH7000-ZA

EK

Product Name

32/37/42/47LH70**

BRAND

LG

Printing Specification

1. Trim Size (Format) : 185 mm x 260 mm

2. Printing Colors : 1 Color (BLACK)

3. Stock (Paper) : Uncoated paper, 백상지 60 g/㎡

4. Printing Method : Off-set

5. Bindery : Saddle stitch

6. Language : EN (1)

7. Number of pages : 16 pages

Details should be followed Eco-SCM management standard[LG(56)-A-2524].
Especially, Part should be followed and controlled the following specification.
(1)Eco-hazardous substances test report should be submitted

when Part certification test and First Mass Production.

(2) Especially, Don’t use or contain lead(Pb) and cadmium(Cd) in ink.

09.02.04

Part No.

MFL41425833
(0904-REV03)

KIM JO

09.02.04

Special Instructions3.

(1) Origin Notification

* LGEIN : Printed in Indonesia * LGEWA : Printed in U.K. * LGEMA : Printed in Poland
* LGESP : Printed in Brazil * LGEMX : Printed in Mexico
* LGEND : Printed in China * LGEIL : Printed in India

* Other Oversea Factories : NON

Changes

3.

10

9
8

7
6
5

4

04/20/09

3

03/30/09

2

02/10/09

1

REV.

MM/DD/YY

NO.

Shin Hye Jung

Shin Hye Jung

SHIN.H.J.

SIGNATURE

S9-50428

S9-48133
S9-42817
CHANGE NO.

Added 32/37/42LG2100-ZA models.

Added LF2510-ZB & Changed Drawing for LU40 **

Amended picture for Stand Rear Cover of LH70**

CHANGE CONTENTS

Downloaded From TV-Manual.com Manuals

Front

Cover

(EN)

P/NO.

Pagination sheet

Pagination sheet

34…2

P/NO. MFL41425833
Total pages : 16 pages

16

Downloaded From TV-Manual.com Manuals

OWNER’S MANUAL

LCD TV

Please read this manual carefully before operating your TV.
Retain it for future reference.
Record the model number and serial number of the TV.
Refer to the label on the back cover and quote this
information.
To your dealer when requiring any service.

PP//NNOO:: MM FF LL4411442255883333 ((00990044--RR EEVV00 33 ))

PPrriinn tteedd ii nn KK oo rree aa

An extended Owner’s Manual that contains informa­tion on the advanced features of these LG TV sets is
located on the CD- ROM provided in an electronic
version.

To read these files, you will need to use a Personal
Computer (PC) equipped with a CD- ROM drive.

1199LLUU4400****
2222LLUU4400****
1199LLUU5500****
2222LLUU5500****
2266LLUU5500****
1199LLHH2200****
2222LLHH2200****
2266LLHH2200****
3322LLHH2200

** **

3377LLHH2200

** **

4422LLHH2200

**

**

3322LLHH3300

** **

3377LLHH3300

** **

4422LLHH3300

** **

4477LLHH3300

** **

3322LLHH4400

** **

3377LLHH4400

** **

4422LLHH4400

** **

4477LLHH4400

** **

3322LLHH5500

** **

3377LLHH5500

** **

4422LLHH5500

** **

4477LLHH5500

** **

3322LLHH7700

** **

3377LLHH7700

** **

4422LLHH7700

** **

4477LLHH7700

** **

3322LLFF2255

** **

3377LLFF2255

** **

4422LLFF2255

** **

3322LLHH4499

** **

3377LLHH4499

** **

4422LLHH4499

** **

4477LLHH4499

** **

3322LLGG2211

** **

3377LLGG2211

** **

4422LLGG2211

** **

Trade Mark of the DVB Digital Video
Broadcasting Project (1991 to 1996)

II DD NNuummbbee rr ((ss))::

6337 : 19LU4000
6423 : 19LU4010
6338 : 22LU4000
6424 : 22LU4010
6334 : 19LU5000
6428 : 19LU5010
6425 : 19LU5020
6335 : 22LU5000
6429 : 22LU5010
6426 : 22LU5020
6336 : 26LU5000
6430 : 26LU5010
6427 : 26LU5020
6200: 19LH2000
6437 : 19LH2010
6431 : 19LH2020
6201: 22LH2000
6438 : 22LH2010
6432 : 22LH2020
6202: 26LH2000
6439 : 26LH2010
6433 : 26LH2020
6203: 32LH2000
6440 : 32LH2010
6434 : 32LH2020
6204: 37LH2000
6441 : 37LH2010
6435 : 37LH2020
6205 : 42LH2000
6442 :42LH2010
6436 : 42LH2020
6206 : 32LH3000
6451 : 32LH3010
6447 : 32LH3020
6443 : 32LH3030
6208: 37LH3000
6452 : 37LH3010
6448 : 37LH3020
6444 : 37LH3030
6209: 42LH3000
6453 : 42LH3010
6449 : 42LH3020
6445 : 42LH3030
6210: 47LH3000
6454 : 47LH3010
6450 : 47LH3020
6446 : 47LH3030
6211: 32LH4000
6467 : 32LH4020
6463 : 32LH4010
6212: 37LH4000
6468 : 37LH4020
6464 : 37LH4010
6213: 42LH4000
6469 : 42LH4020
6465 : 42LH4010
6214: 47LH4000
6470 : 47LH4020
6466 : 47LH4010

6484: 32LH5000
6455 : 32LH5020
6459 : 32LH5010
6485: 37LH5000
6456 : 37LH5020
6460 : 37LH5010
6486: 42LH5000
6457 : 42LH5020
6461 : 42LH5010
6487 : 47LH5000
6458 : 47LH5020
6462 : 47LH5010
6195: 32LH7000

6529 : 32LH7010
6475 : 32LH7020
6471 : 32LH7030
6196: 37LH7000
6479 : 37LH7010
6476 : 37LH7020
6472 : 37LH7030
6197: 42LH7000
6528 : 42LH7010
6477 : 42LH7020
6473 : 42LH7030
6198: 47LH7000
6480 : 47LH7010
6478 : 47LH7020
6474 : 47LH7030
6481 : 32LF2500
6618 : 32LF2510
6482 : 37LF2500
6617 : 37LF2510
6483 : 42LF2500
6616 : 42LF2510
6488 : 32LH4900
6489 : 37LH4900
6490 : 42LH4900
6491 : 47LH4900
6755 : 32 LG 2100
6756 : 37 LG2100
6757 : 42 LG 2100

This product qualifies for ENERGY STAR in the “facto­ry default (Home Use mode)” setting and this is the
setting in which power savings will be achieved.
Changing the factory default picture setting or
enabling other features will increase power consump­tion that could exceed the limits necessary to qualify
for Energy Star rating.

Downloaded From TV-Manual.com Manuals

2

SAFETY INSTRUCTIONS

ENGLISH

• Please read these safety precautions carefully before using the product.

• In this manual, the illustration may be somewhat different from your product because it is just example to help the instruction.

If you ignore the warning message, you may be seriously injured or there is a possibility of accident or death.

If you ignore the caution message, you may be slightly injured or the product may be damaged.

PPrreecc aa uutt ii oo nn iinn IInnssttaallllii nngg tthh ee PPrr oo dd uucctt

WARNING

WARNING

CAUTION

Keep away from heat sources like electrical heaters.

- Electrical shock, fire, malfunction or deformation may occur.

If you can smell smoke or other odors or hear a strange
sound unplug the power cord and contact the service
center.

- If you continue to use without taking proper measures, elec­trical shock or fire can occur.

Do not use the product in damp place such as a bath­room or any place where it is likely to get wet.

- This may cause a fire or could give an electric shock.

Install the product on a flat and stable place that
has no risk of dropping the product.

- If the product is dropped, you may be injured or the

product may be broken.

Keep the product away from direct sunlight.

- The product can be damaged.

Do not place the product in a built-in installation
such as bookcase or rack.

- Ventilation required.

EElleecctt rriiccaall PP oowweerr RR ee ll aa tteedd PP rreeccaauu ttiioonnss

Make sure to connect the power cable to the ground­ed current.

- You may be electrocuted or injured.

Do not touch the power plug with wet hands.
Additionally, it the cord pin is wet or covered with
dust, dry the power plug completely or wipe dust off.

- You may be electrocuted due to excess moisture.

During a thunder or lightning storm, unplug the
power cable or signal cable.

- You may be electrocuted or a fire can break out.

Protect the power cord from physical or mechanical
abuse, such as being twisted, kinked, pinched, closed in
a door, or walked upon. Pay particular attention to plugs,
wall outlets, and the point where the cord exits the
appliance.

PPrreecc aa uutt ii oo nnss iinn MMoovvii nngg tthh ee PPrr oo dduucctt

Do not shock the product when moving it.

- You may be electrocuted or the product can be dam­aged.

Make the panel face forward and hold it with both
hands to move.

- If you drop the product, the damaged product can
cause electric shock or fire. Contact with the service
center for repair.

Make sure to turn off the product.
Make sure to remove all cables before moving the
product.

- You may be electrocuted or the product can be dam­aged.

PPrreecc aa uutt ii oo nnss iinn UUssiinngg tt hhee PPrroodd uucc tt

Do not disassemble, repair or modify the product at
your own discretion.

- Fire or electric shock accident can occur.

- Contact the service center for check, calibration or
repair.

To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
Apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such as
vases, shall be placed on the apparatus.

WARNING

WARNING

CAUTION

CAUTION

CAUTION

WARNING

Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power supply cord or plug
is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normal­ly, or has been dropped.

IIMMPPOORRTTAANN TT IINNFFOORRMMAATTIIOONN TTOO PPRREEVVEENNTT ““ IIMMAAGGEE BBUURRNN
//BBUURRNN--IINN”” OONN YYOOUURR TTEELLEEVVIISSIIOONN SSCCRREEEENN

-

When a fixed image (e.g. logos, screen menus, video game, computer
display and teletext pages) is displayed on the television for an extend­ed period it can become permanently imprinted on the screen. This
phenomenon is known as “image burn” or “burn-in”. Image burn is not
covered under the manufacturer’s warranty.

-

In order to prevent image burn, avoid displaying a fixed image on your
television’s screen for a prolonged period (2 or more hours for LCD, 1
or more hours for Plasma).

-

Image burn can also occur on the letterboxed areas of your television
if you use the 4:3 aspect ratio setting for an extended period.

As long as this unit is connected to the AC wall outlet, it is not dis­connected from the AC power source even if you turn off this unit
by SWITCH.

Downloaded From TV-Manual.com Manuals

3

ENGLISH

PREPARATION

Ensure that the following accessories are included with your TV. If an accessory is missing, please contact the
dealer where you purchased the TV.

■

Image shown may differ from your TV.

Owner’s Manual Batteries

Remote Control

Power Cord

Polishing Cloth

Polishing cloth for

use on the screen.

This item is not included for all models.

* Lightly wipe any stains

or fingerprints on the
surface of the TV with
the polishing cloth.

Do not use excessive force.
This may cause scratching
or discolouration.

or

A
V

M

O
D

E

V
M

O
D

E

E
N

E
R

G
Y

E
N

E
R

G
Y

SA S

A

V
I
N

G

V
I
N

G

RE

TU
R

N

/ E

XIT

MENU

Q.MENU INFO GUIDE

i

M

U

T

E

M

U

T

E

POWERPOWE

R

L
I

S

T

L
I

S

T

Q

.
V

IE

W

Q

.V

IE

W

MARK

FAV

Cable management clip

(Only 32/37/42/47LH70**)

(Refer to p.10)

Stand rear cover

(Only 37/42/47LH70**)

(Refer to p.8)

(Only 47LH70**)

x 7

Protection Cover

(Except for 19/22LU40**, 19/22/26LU50**)

(Refer to p.11)

or

Cable Holder

(Only 19/22LU40**,

19/22/26LU50**)

(Refer to p.9)

Cable management clip

(Only 19/22LH20

*

*

)

(Refer to p.9)

(Refer to p.7)

1-screw for stand fixing

(Only 26LU50**, 32/37/42LF25**,

32/37/42LG21**, 26/32/37/42LH20**,

32/37/42LH30**, 32/37/42LH40**,
32/37/42LH49**, 32/37/42LH50**,

32/37LH70**)

x 8

Bolts for stand assembly

(Refer to p.

4~6

)

(Only 32LH70**)

M4x20

M4x16

(Only 42LH70**)

x 3

M4x20

M4x16

x 4

(Only

19/22LU50**)

(Only

26LU50**)

x 2 x 3

Protective Bracket

and Bolt for Power Cord

(Only 32/37/42/47LH70

*

*

)

(Refer to p.10)

USB extension cable

(Only 32/37/42/47LH70

*

*

)

Make sure to use the provided

USB extension cable, Which is

specially designed for a slim fit.

x 8

M4x20

(Only 37LH70**)

Ferrite Core

(

This item is not included for

all models.

)

(Only

32/37/42LF25**,

32/37/42LG21**,

26/32/37/42LH20**,

32/37/42/47LH30

***

,

32/37/42/47LH40

***

,

32/37/42/47LH49**,

32/37/42/47LH50**)

x 4

(Only

32/37/42LF25

**,

32/37/42LG21**)

x 4

12mm

12mm

Use screws 12mm(+0.5/-0.5) long on the SET assembly side.
(

Only 42/47LH70**

)

Set assembly side

(without guide spacer)

Set assembly side

(with guide spacer)

Guide spacer

(Only

19/22LU40**)

x 5

Stand Rear Body

Cap

(Only

19/22LU40**)

(Refer to p.6)

Downloaded From TV-Manual.com Manuals

4

PREPARATION

ENGLISH

STAND INSTALLATION

1

3

4

Carefully place the TV screen side down on a cush­ioned surface to protect the screen from damage.

2

Assemble the parts of the

SSttaa nndd BBooddyy

with

the

SSttaa nndd BBaass ee

of the TV.

Assemble the TV as shown.

Fix the 4 bolts securely using the holes in the
back of the TV.

32LH70

**

Stand Body

Stand Base

42LH70

**

Only 32/37/42/47LH70

**

47LH70**37LH70

**

Stand Body

Stand Base

32/37LH70

**

M4x20

M4x20

M4x16

M4x20

1

2

3

Carefully place the TV screen side down on a cushioned
surface to protect the screen from damage.

Assemble the TV as shown.

Fix the 4 bolts securely using the holes in the
back of the TV.

Only 26/32/37/42LH20**,
32/37/42/47LH30**, 32/37/42/47LH40**,
32/37/42/47LH49**, 32/37/42/47LH50

**

M4x20

42/47LH70

**

M4x16

■

Image shown may differ from your TV
When assembling the desk type stand, check whether the bolt is fully tightened. (If not tightened fully, the product can
tilt forward after the product installation.) If you tighten the bolt with excessive force, the bolt can deviate from abrasion
of the tightening part of the bolt.

Downloaded From TV-Manual.com Manuals

5

ENGLISH

1

2

Carefully place the TV screen side down on a cush­ioned surface to protect the screen from damage.

Fix the 2 or 3 bolts securely using the holes.

Only 19/22/26LU50

**

1

Carefully place the TV screen side down on a cush­ioned surface to protect the screen from damage.

2

Assemble the TV as shown.

Only 19/22LH20

**

Cover Base

(Only 26LU50**)

1

3

4

Carefully place the TV screen side down on a
cushioned surface to protect the screen from
damage.

2

Assemble the parts of the

SSttaa nndd BBooddyy

with

the

CCoovv eerr BBaa ssee

of the TV.

Assemble the TV as shown.

Fix the 4 bolts securely using the holes in the
back of the TV.

Stand Body

Cover Base

Only 32/37/42LF25

**,

32/37/42LG21

**

Downloaded From TV-Manual.com Manuals

6

PREPARATION

ENGLISH

1

3

4

Carefully place the TV screen side down on a cush­ioned surface to protect the screen from damage.

2

Fix the 3 bolts securely using the holes in the
CCoovv eerr BBaa ssee

.

Assemble the parts of the

SSttaa nndd RRee aa rr BB oo dd yy

with the TV.

Assemble the parts of the

CC aa pp

with the

SSttaann dd

RReeaarr BBooddyy

of the TV.

Only 19/22LU40

**

Stand Rear Body

Cover Base

Stand Rear Body

Cap

DETACHING STAND

■

Image shown may differ from your TV.

1

3

4

Carefully place the TV screen side down on a cush­ioned surface to protect the screen from damage.

2

Detach the

CC aa pp

from TV.

Press in the direction of the arrow to detach the
cap.

Loose the bolts and then detach the

SSttaann dd

RReeaarr BBooddyy

from TV.

Loose the bolts and then detach the

CC oo vvee rr

BB aa ssee

from TV.

Cap

Only 19/22LU40

**

Stand Rear Body

Cover Base

5

Loose the bolts and then detach the

SSttaann dd

BB oo dd yy

from TV.

Stand Body

Downloaded From TV-Manual.com Manuals

7

ENGLISH

2

Loose the bolts and then detach the stand from TV.

3

Loose the bolts from TV.
Detach the

CCoovv eerr BB aa ssee

from

TT VV

.

4

Detach the

SSttaa nndd BBooddyy

from

TT VV

.

Stand Body

1

Carefully place the TV screen side down on a cush­ioned surface to protect the screen from damage.

Cover Base

(Only 26LU50**)

Only 19/22/26LU50

**

(Only 26LU50**)

ATTACHING THE TV TO A DESK

(Only 26LU50**, 32/37/42LF25**, 32/37/42LG21**,
26/32/37/42LH20**, 32/37/42LH30**,
32/37/42LH40**, 32/37/42LH49**,
32/37/42LH50**, 32/37LH70**)

■

Image shown may differ from your TV.

The TV must be attached to desk so it cannot be
pulled in a forward/backward direction, potentially
causing injury or damaging the product. Use only an
attached screw.

1-Screw

(provided as parts of the product)

Desk

Stand

WARNING

!

G

To prevent TV from falling over, the TV should
be securely attached to the floor/wall per
installation instructions. Tipping, shaking, or
rocking the machine may cause injury.

4 inches

4 inches

4 inches

4 inches

DESKTOP PEDESTAL INSTALLATION

For adequate ventilation allow a clearance of 4”
(10cm) all around the TV.

Downloaded From TV-Manual.com Manuals

8

ENGLISH

CAREFUL INSTALLATION ADVICE

A

You should purchase necessary components to fix the TV

safety and secure to the wall on the market.

A

Position the TV close to the wall to avoid the possibility
of it falling when pushed.

A

The instructions shown below are a safer way to set up
the TV, by fixing it to the wall, avoiding the possibility of
it falling forwards if pulled. This will prevent the TV from
falling forward and causing injury. This will also prevent
the TV from damage. Ensure that children do not climb
or hang from the TV.

NOTE

!

G

When moving the TV undo the cords first.

G

Use a platform or cabinet strong and large enough
to support the size and weight of the TV.

G

To use the TV safely make sure that the height of the
bracket on the wall and on the TV is the same.

3

1

2

Use the eye-bolts or TV brackets/bolts to fix the
product to the wall as shown in the picture.

(If your TV has bolts in the eyebolts, loosen then
bolts.)

* Insert the eye-bolts or TV brackets/bolts and tight-

en them securely in the upper holes.

Secure the wall brackets with the bolts on the wall.
Match the height of the bracket that is mounted on
the wall.

3

Use a sturdy rope to tie the product for alignment. It
is safer to tie the rope so it becomes horizontal
between the wall and the product.

2

1

2

1

SWIVEL STAND

(Except for 19/22LH20**, 19/22LU40**, 19/22/26LU50**)

■

Image shown may differ from your TV.

After installing the TV, you can adjust the TV set
manually to the left or right direction by 20 degrees
to suit your viewing position.

Grip the knob in your fingers and pull it.

TO USE THE STAND REAR
COVER (Only 37/42/47LH70

**

)

■

Image shown may differ from your TV.

Install the

SSTTAANNDD RREEAARR CCOOVVEERR

as shown.

STAND REAR COVER

PREPARATION

Downloaded From TV-Manual.com Manuals

9

ENGLISH

BACK COVER FOR WIRE ARRANGEMENT

LCD TV Models :
19/22LU40**, 19/22/26LU50

**

After Connecting the cables as necessary, install

CABLE HOLDER as shown and bundle the cables.

LCD TV Models : 32/37/42LF25**,
32/37/42LG21**, 26/32/37/42LH20**,
32/37/42/47LH30**, 32/37/42/47LH40**,
32/37/42/47LH49**,

32/37/42/47LH50**

Connect the cables as neces­sary.

To connect additional equip­ment, see the EXTERNAL

EQUIPMENT SETUP section.

1

Open the CABLE MANAGEMENT CLIP as
shown.

2

CABLE MANAGEMENT CLIP

Fit the

CCAABBLLEE MMAANNAAGGEEMMEENNTT CC LLIIPP

as

shown.

3

LCD TV Models :

19/22LH20

**

Connect the cables as neces­sary.

To connect additional equip­ment, see the EXTERNAL

EQUIPMENT SETUP section.

1

Install the CABLE MANAGEMENT CLIP as shown.

2

CABLE MANAGEMENT CLIP

Fit the CABLE MANAGEMENT CLIP as shown.

3

Hold the CABLE MANAGEMENT
CLIP with both hands and pull it

backward.

NOTE

!

GG

Do not use the CABLE MANAGEMENT CLIP to
lift the TV.

- If the TV is dropped, you may be injured or the
TV may be damaged.

How to remove the cable management
clip

(LCD TV Models : 19/22LH20**)

■

Image shown may differ from your TV.

Downloaded From TV-Manual.com Manuals

10

ENGLISH

LCD TV Models : 32/37/42/47LH70

**

Connect the cables as necessary.
To connect additional equipment, see the

EExx tteerrnnaall ee qq uuiippmmeenntt SSeettuupp

section.

1

2

Align the hole with the tab on the

CC AABB LLEE

MMAANNAAGGEEMM EENNTT CCLL II PP

.

Turn the

CCAABBLLEE MMAANNAAGGEEMMEENNTT CCLLIIPP

as shown.

Note : that excessive force might cause damage to
the product when using Cable Management clip.

NOTE

!

GG

Do not use the CABLE MANAGEMENT CLIP to lift the TV.

- If the TV is dropped, you may be injured or the TV may be damaged.

CABLE MANAGEMENT CLIP

How to secure the power cable

(Only 32/37/42/47LH70**)

PROTECTIVE BRACKET

Secure the power cable with the PROTECTIVE
BRACKET and the bolt as shown. It will help prevent

the power cable from being removed by accident.

1

Installing Batteries

■

Open the battery compartment cover on the
back and install the batteries matching cor­rect polarity (+with +,-with -).

■

Install two 1.5V AAA batteries. Do not mix old
or used batteries with new ones.

■

Close cover.

Install the power plug

closely.

Use of ferrite core (This feature is
not available for all models.)

Ferrite core can be used
to reduce the electro­magnetic wave when
connecting the power
cord.
The closer the location
of the ferrite core to
the power plug, the bet­ter it is.

PREPARATION

Downloaded From TV-Manual.com Manuals

11

ENGLISH

■

Image shown may differ from your TV.

When installing the wall-mounted unit, use the protection cover.

NOT USING THE DESK-TYPE STAND

(Except for 19/22LU40

**

, 19/22/26LU50

**

)

After removing the protection paper
from the protection cover, adhere it
to the TV as shown.

PROTECTION COVER

Only 26/32/37/42LH20**,
32/37/42/47LH30**, 32/37/42/47LH40**,
32/37/42/47LH49**, 32/37/42/47LH50

**

Insert the

PPRROOTTEECCTTIIOONN

CCOO VVEERR

into the TV until

clicking sound.

Only 32/37/42LF25**, 32/37/42LG21

**

Insert the

PPRROOTTEECCTTIIOONN

CCOO VVEERR

into the TV until

clicking sound.

Only 32/37/42/47LH70

**

Fix the 4 bolts securely using the holes in the
back of the TV.

5

Only 19/22LH20

**

PROTECTION COVER

PROTECTION COVER

1

3

4

Carefully place the TV screen side down on a
cushioned surface to protect the screen from
damage.

2

Loose the bolts from TV.

Detach the stand from TV.

Insert the

PPrrootteeccttiioonn CCoovveerr

into the TV.

PROTECTION COVER

Downloaded From TV-Manual.com Manuals

12

ENGLISH

A

The TV can be installed in various ways such as on

a wall, or on a desktop etc.

A

The TV is designed to be mounted horizontally.

Power Supply

Circuit breaker

EARTHING

Ensure that you connect the earth wire to prevent
possible electric shock. If grounding methods are not
possible, have a qualified electrician install a separate
circuit breaker.

Do not try to earth the TV by connecting it to tele­phone wires, lightening rods or gas pipes.

WALL MOUNT: HORIZONTAL
INSTALLATION

A

We recommend the use of a LG Brand wall mounting
bracket when mounting the TV to a wall.

A

We recommend that you purchase a wall mounting
bracket which supports VESA standard.

A

LG recommends that wall mounting be performed by a
qualified professional installer.

A

First you connect the USB extension cable to the USB
IN terminal, and then hang it on the wall.

(Only

32/37/42/47LH70

*

*

)

4 inches

4 inches

4 inches

4 inches

4 inches

NOTE

!

G Should Install wall mount on a solid wall perpendicular to

the floor.

G Should use a special wall mount, if you want to install it to

ceiling or slanted wall.

G The surface that wall mount is to be mounted on should

be of sufficient strength to support the weight of TV set;
e.g. concrete, natural rock, brick and hollow block.

G Installing screw type and length depends on the wall

mount used. Further information, refer to the instructions
included with the mount.

G LG is not liable for any accidents or damage to property or

TV due to incorrect installation:

- Where a non-compliant VESA wall mount is used.

- Incorrect fastening of screws to surface which may cause

TV to fall and cause personal injury.

- Not following the recommended Installation method.

AA

BB

Model

VESA

(A *B)

Standard

Screw

Quantity

19/22LU40**
19/22LU50**

26LU50**

32LF25**

37/42LF25**

32LG21**
37/42LG21**
19/22LH20**
26/32LH20**
37/42LH20**

32LH30**

37/42LH30**

47LH30**
32LH40**

37/42/47LH40**

32LH49**

37/42/47LH49**

32LH50**

37/42/47LH50**

32LH70**

37/42/47LH70**

100 * 10 0

100 * 10 0
200 * 10 0
200 * 10 0
200 * 200
200 * 10 0
200 * 200

100 * 10 0
200 * 10 0
200 * 200
200 * 10 0
200 * 200
200 * 200
200 * 10 0
200 * 200

200 * 10 0
200 * 200

200 * 10 0
200 * 200

200 * 10 0
200 * 200

M4
M4
M4
M4
M6
M4
M6
M4
M4
M6
M4
M6
M6
M4
M6
M4
M6
M4
M6
M4
M6

4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4

Wall Mounting Bracket(Separate purchase)

(19/22LU50

**

/19/22LU40

**

/19/22LH20**)

RW120

(26LU50**/32LF25

**

/32LG21**/26/32LH20**/

32LH30**/32LH40**/

32LH49

**

/32LH50**/32LH70**)

RW230

(32/37/42LF25

**

/32/37/42LG21

**

/32/37/42LH20

**

/32/37/42/47LH30

**

/32/37/42/47LH40

**

/32/37/42/47LH49

**

/32/37/42/47LH50

**

/32/37/42/47LH70**)

AW-47LG30M

PREPARATION

Downloaded From TV-Manual.com Manuals

13

WATCHING TV /PROGRAMME CONTROL

ENGLISH

USB memory stick

■

Image shown may differ from your TV

■

To connect an additional equipment, see the

EExx tt eerrnn aa ll eeqq uuiippmmee nntt SSeettuu pp

section in CD Manual.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CONNECTING YOUR UNIT

(RGB)

(RGB)

VCR Connection

2

DVD/STB

2

Antenna Connection

1

Power Cord

3

DVD/STB back

TURNING ON THE TV

Firstly, connect the power cord correctly and check the main power on the TV.
At this stage, the TV switches to standby mode.

In standby mode to turn TV on, press the INPUT or P

D E

(or P ) button on the TV or press the

POWER, INPUT, P or NUMBER button on the remote control and the TV will switch on.

2

1

Initializing setup

Note:

a. If you close without completing the initial setting, the Initial Setting menu can be displayed again.
b. Press the RETURN button to change the current OSD to the previous OSD.
c. For those countries without confirmed DTV broadcasting standards, some DTV features might not

work, depending on the DTV broadcasting environment.
d. "Home Use” mode is the optimal setting for home environments, and is the TV's default mode.
e. "Store Demo" mode is the optimal setting for store environments. If a user modifies image quality data,

“Store Demo” mode initializes the product to the image quality set by us after a certain period of time.
f. The mode (Home Use, Store Demo) can be changed by executing Mode Setting in the OPTION menu.

If the OSD (On Screen Display) is displayed on the screen after turning on the TV, you can adjust the
LLaanngguuaagg ee, MMooddee SSeettttiinngg, CC oo uunnttrryy, AAuu ttoo TTuu nniinn gg

.

- When your TV is turned on, you will be able to use its features.

Downloaded From TV-Manual.com Manuals

14

ENGLISH

MAINTENANCE

TO VIEW THE USER'S GUIDE ON THE CD-ROM

Early malfunctions can be prevented. Careful and regular cleaning can prolong the life of your new TV.
Caution: Be sure to switch the power off and unplug the power cord before you begin any cleaning.

Cleaning the Screen

A good way to keep the dust off your screen for a while is to wet a soft cloth in a mixture of lukewarm water
and a little fabric softener or dish washing detergent. Wring the cloth until it is almost dry, and then use it
to wipe the screen.

Ensure there is no excess water on the screen. Allow any water or dampness to evaporate before switching on.

Cleaning the Cabinet

A

To remove dirt or dust, wipe the cabinet with a soft, dry, lint-free cloth.

A

Do not to use a wet cloth.

Extended Absence

G

If you expect to leave your TV dormant for prolonged periods (such as a holiday), unplug the power
cord to protect against possible damage from lightning or power surges.

CAUTION

1

2

To view the User's guide on the CD-ROM, Adobe Acrobat Reader must be installed on your PC.
The "ACRORD" folder on the CD-ROM contains the installation program for Acrobat Reader.
If you want to install Acrobat Reader, Open "My Computer" Open the folder "LG" Open the folder "ACRORD"

double-click your language.

TToo vv iiee ww tthhee UU sseerr''ss gg uuiiddee
The User's guide files are included in the supplied CD-ROM.
Load the supplied CD-ROM into the CD-ROM drive of your PC.
After a while, the web page of the CD-ROM will open automatically.(Windows users only)
If the web page does not appear automatically, open the User's guide file directly.
Open "My computer" Open the folder "LG" Double click the "index.htm" file.

TO VIEW THE SIMPLE MANUAL

You can easily and effectively access the TV information by viewing the simple manual on the TV.

Press the

MMEENNUU

button and then

IINNFFOO

button to enter the

SSiimmppllee MM aa nnuu aall

menu.

Press the

RR EETTUU RRNN

button to return to normal TV viewing.

1
2

APPENDIX

■

The specifications shown above may be changed without prior notice for quality improvement.

WEIGHT

with stand

without stand

MODELS

Weight

32LH4000-ZA

32LH4010-ZD

32LH4020-ZC

32LH40

**

37LH4000-ZA
37LH4010-ZD
37LH4020-ZC

37LH40

**

42LH4000-ZA
42LH4010-ZD
42LH4020-ZC

42LH40

**

47LH4000-ZA
47LH4010-ZD
47LH4020-ZC

47LH40

**

12.7 kg / 28.0 lbs

11.5 kg / 25.4 lbs

15.8 kg / 34.9 lbs

14.0 kg / 30.9 lbs

18.9 kg / 41.7 lbs

17.1 kg / 37.7 lbs

22.2 kg / 49.0 lbs

19.6 kg / 43.2 lbs

with stand

without stand

MODELS

Weight

23.6 kg / 52.1 lbs

21.0 kg / 46.3 lbs

32LG2100-ZA

42LG2100-ZA

37LG2100-ZA

32LG21

**

42LG21

**

37 LG 21

**

13.4 kg / 29.6 lbs

11.9 kg / 26.3 lbs

18.8 kg / 41.5 lbs

16.2 kg / 35.7 lbs

Downloaded From TV-Manual.com Manuals

15

ENGLISH

■

The specifications shown above may be changed without prior notice for quality improvement.

with stand

without stand

MODELS

Weight

19LU4000-ZB

19LU4010-ZC

19LU40

**

22LU4000-ZB

22LU4010-ZC

22LU40

**

19LH2000-ZA

19LH2010-ZB

19LH2020-ZC

19LH20

**

22LH2000-ZA

22LH2010-ZB
22LH2020-ZC

22LH20

**

4.4 kg / 9.7 lbs

3.9 kg / 8.6 lbs

5.5 kg / 12.1 lbs

5.0 kg /11.0 lbs

3.8 kg / 8.4 lbs

3.6 kg / 8.0 lbs

4.8 kg / 10.6 lbs

4.6 kg / 10.2 lbs

with stand

without stand

MODELS

Weight

26LH2000-ZA
26LH2020-ZC

26LH2010-ZB

26LH20

**

32LH2000-ZA
32LH2020-ZC

32LH2010-ZB

32LH20

**

37LH2000-ZA
37LH2020-ZC

37LH2010-ZB

37LH20

**

42LH2000-ZA
42LH2020-ZC

42LH2010-ZB

42LH20

**

8.9 kg / 19.7 lbs

7.8 kg / 17.2 lbs

11.5 kg / 25.4 lbs

10.3 kg / 22.7 lbs

14 . 8

kg / 32.6 lbs

13 . 0

kg / 28.7 lbs

18.0 kg / 39.7 lbs

16.2 kg / 35.7 lbs

with stand

without stand

MODELS

Weight

32LH3000-ZA
32LH3020-ZD

32LH3010-ZB
32LH3030-ZE

32LH30

**

37LH3000-ZA
37LH3020-ZD

37LH3010-ZB
37LH3030-ZE

37LH30

**

42LH3000-ZA
42LH3020-ZD
42LH3010-ZB
42LH3030-ZE

42LH30

**

47LH3000-ZA
47LH3020-ZD

47LH3010-ZB

47LH3030-ZE

47LH30

**

12.1 kg / 26.7 lbs

11.0 kg / 24.3 lbs

14.9 kg /

32.9 lbs

13.1 kg /

28.9 lbs

18.0 kg / 39.7 lbs

16.2 kg / 35.7 lbs

22.5 kg / 49.6 lbs

19.9 kg /

43.9 lbs

with stand

without stand

MODELS

Weight

32LH7000-ZA

32LH7010-ZD

32LH7020-ZC

32LH7030-ZE

32LH70

**

37LH7000-ZA

37LH7010-ZD
37LH7020-ZC
37LH7030-ZE

37LH70

**

42LH7000-ZA

42LH7010-ZD

42LH7020-ZC

42LH7030-ZE

42LH70

**

47LH7000-ZA

47LH7010-ZD
47LH7020-ZC
47LH7030-ZE

47LH70

**

13.5kg / 29.7 lbs

11.6kg /25.5 lbs

16.2kg / 35.7 lbs

14.1 kg / 31.0lbs

19.8 kg / 43.7 lbs

17.2 kg / 37.9lbs

26.4 kg / 58.2 lbs

22.8 kg / 50.2 lbs

with stand

without stand

MODELS

Weight

with stand

without stand

MODELS

Weight

32LH4900-ZD

32LH49

**

37LH4900-ZD

37LH49

**

42LH4900-ZD

42LH49

**

47LH4900-ZD

47LH49

**

12.7 kg / 28.0 lbs

11.5 kg / 25.4 lbs

15.8 kg / 34.9 lbs

14.0 kg / 30.9 lbs

18.9 kg / 41.7 lbs

17.1 kg / 37.7 lbs

22.2 kg / 49.0 lbs

19.6 kg / 43.2 lbs

with stand

without stand

MODELS

Weight

23.6 kg / 52.1 lbs

21.0 kg / 46.3 lbs

32LF2500-ZA

32LF2510-ZB

42LF2500-ZA

42LF2510-ZB

37LF2500-ZA

37LF2510-ZB

32LF25

**

42LF25

**

37LF25

**

13.4 kg / 29.6 lbs

11.9 kg / 26.3 lbs

18.8 kg / 41.5 lbs

16.2 kg / 35.7 lbs

with stand

without stand

MODELS

Weight

32LH5000-ZB
32LH5010-ZD

32LH5020-ZE

32LH50

**

37LH5000-ZB
37LH5010-ZD
37LH5020-ZE

37LH50

**

42LH5000-ZB
42LH5010-ZD

42LH5020-ZE

42LH50

**

47LH5000-ZB

47LH50

**

12.6 kg / 27.8 lbs

11.4 kg / 25.2 lbs

16.3 kg / 35.9 lbs

14.5 kg / 32.0lbs

19.0 kg / 41.9 lbs

17.2 kg / 37.9 lbs

23.4 kg / 51.6 lbs

20.8 kg / 45.9 lbs

47LH5010-ZD
47LH5020-ZE

23.6 kg / 52.0 lbs

20.8 kg / 45.9 lbs

8.9 kg / 19.6 lbs

7.7 kg / 17.0 lbs

19LU5000-ZA

19U5010-ZB

19LU5020-ZC

26LU5000-ZA

26U5010-ZB

26LU5020-ZC

22LU5000-ZA

22U5010-ZB

22LU5020-ZC

19LU50

**

26LU50

**

22LU50

**

4.4 kg / 9.7 lbs

3.7 kg / 8.2 lbs

5.4 kg / 11.9 lbs

4.6 kg / 10.2 lbs

Downloaded From TV-Manual.com Manuals

16

ENGLISH

APPENDIX

TROUBLESHOOTING

TThhee TTVV ddooeess nnoott ooppeerraattee pprrooppeerrllyy..

The remote control

does not work

Power is suddenly

turned off

A

Check to see if there is any object between the TV and the remote control causing
an obstruction. Ensure you are pointing the remote control directly at the TV.

A

Ensure that the batteries are installed with correct polarity (+ to +, - to -).

A

Ensure that the correct remote operating mode is set : TV, STB etc.

A

Install new batteries.

A

Is the sleep timer set?

A

Check the power control settings. Has the Power supply been interrupted.

A

If the TV is switched on and there is no input signal, it will switch off automatical­ly after 15 minutes.

No picture & No sound

No or poor colour

or poor picture

Poor reception on

some channels

Lines or streaks

in pictures

No picture

when connecting HDMI

Horizontal/vertical bars

or picture shaking

Picture appears slowly

after switching on

A

Check whether the TV is switched on.

A

Try another channel. The problem may be with the broadcast.

A

Is the power cord inserted correctly into the mains?

A

Check your antenna direction and/or location.

A

Test the mains outlet by plugging another TV into the same outlet.

A

This is normal, the image is muted during the TV startup process. Please contact
your service centre, if the picture has not appeared after five minutes.

A

Adjust Colour in menu option.

A

Allow a sufficient distance between the TV and the VCR.

A

Try another channel. The problem may be with the broadcast.

A

Are the video cables installed properly?

A

Activate any function to restore the brightness of the picture.

A

Check for local interference such as an electrical appliance or power tool.

A

Station or cable channel experiencing problems, tune to another station.

A

Station signal is weak, reposition the antenna to receive weaker stations.

A

Check for sources of possible interference.

A

Check antenna (Change the position of the antenna).

A

Check that your HDMI cable is version 1.3 or higher.

If the HDMI cables don’t support HDMI version 1.3, flickering or no screen display
can result. Please use the latest cables that support at least HDMI version 1.3.

TThhee vviiddeeoo ffuunnccttiioonn ddooeess nnoott wwoorrkk..

TThheerree iiss aa pprroobblleemm wwiitthh PPIICCTTUURREE sseettttiinnggss..

A

It means that the TV is currently set to

SSttoo rree DDee mmoo

mode.

To switch to

HHoomm ee uussee

mode you should do the followings:

From the TV Menu, choose

OO PPTT II OO NN

-> Choose

MMooddee SSeettttii nngg

-> Choose

HHoomm ee uuss ee

. Now, you have completed switching to the

HHoomm ee uuss ee

mode.

When the user changes

the picture settings, the
TV automatically converts
back to the initial settings

after a certain period of

time.

Downloaded From TV-Manual.com Manuals
