Colour Television

By chatchai at 10:41 am, Oct 20, 2008

OWNER’S MANUAL

Please read this manual carefully before operating your set. Retain it for future reference. Record model number and serial number of the set. See the label attached on the back cover and quote this information to your dealer when you require service.

Model number : Serial number :

P/NO : MFL58380402(0808 REV00)

Contents

By chatchai at 10:41 am, Oct 20, 2008

Installation..........................................................2

Connection of external equipment..................2

Location and function of controls...................3

Basic operation.................................................5

On screen menus..............................................5

Setting up TV stations......................................6

Picture adjustment............................................7

Installation

Power

This set operates on an AC mains supply, the voltage is as indicated on the label on the back cover. Never apply DC power to the set. In the event of thunderstorms or powercuts, please pull out the aerial and mains plugs.

DISCONNECTING DEVICE FROM MAINS

- Mains plug is the disconnecting device. The plug must remain readily operable

Warning

To prevent fire or shock hazard, do not expose the set to rain or moisture. Do not place anything containing liquid on top of the set, this may cause a fire or could give an electric shock.

Service

Never remove the back cover of the set as this can expose you to very high voltage and other hazards. If the set does not operate properly,

Connection of external equipment

Aerial socket

1. Connect the RF out socket of the VCR to the aerial socket on the back of the set.

2. Connect the aerial cable to the RF aerial in socket of the VCR.

3. Store the VCR channel on the programme number 0 using the ‘Manual programme tuning’ section. Select the programme number where the

4. VCR channel is stored.

Press the PLAY button on the VCR.

Audio/Video in/out sockets (option)

1. Connect the audio/video out sockets of the VCR to audio/video in sockets of the set.

2. If the VCR is connected to the AV sockets on the set, press the TV/AV button to select

(or AV 1 ),or

3. Press the PLAY button on the VCR. You can also record programmes received by the TV on video tape via audio/video out sockets.

Euro scart socket (option)

1. Connect the Euro scart socket of the VCR to the Euro scart socket of the set.

2. Press the PLAY button on the VCR. If your VCR outputs a switching voltage when connected to Euro scart socket, the set will switch to if you want to keep on watching TV mode, press the Otherwise press the TV/AV button on the remote control handset to select You can also record programmes received by the TV on video tape.

AV 2.

AV (or AV 1 )

or NUMBER buttons.

D /E

mode automatically. But

AV (or AV 1 )

Sound adjustment.............................................8

Time setting.......................................................9

Other functions.................................................9

PIP operation (option).....................................10

Teletext (option)...............................................10

Troubleshooting check list

unplug it and call your dealer.

Aerial

Connect the aerial cable to the socket on the back cover. For the best reception an outdoor aerial should be used.

Location

Position your set so that no bright light or sunlight falls directly onto the screen. Care should be taken not to expose the set to any unnecessary vibration, moisture, dust or heat. Also ensure that the set is placed in a position to allow a free flow of air. Do not cover the ventilation openings on the back cover.

Note:

To remove dirt or fingerprint on the surface of your TV, please rub with a line-free cloth Do not pose too much pressure in cleaning so as to prevent any risk of damage to the product.

Component in sockets (option)

1. Connect the COMPONENT video output sockets (Y Cb Cr, Y Pb Pr or Y B-Y R-Y) of the DVD player to the COMPONENT INPUT sockets (Y PB PR) on the set.

2. Connect the audio cable from the DVD player to AUDIO IN sockets of

3. Press the TV/AV button to select COMPO-

NENT.

4. Press the PLAY button on the DVD player. The COMPONENT playback picture appears on the screen.

S-video / Audio in sockets (S-AV) (option)

When connecting the S-video socket of the VCR to the S-VIDEO socket of the set, the picture quality will be further improved.

1. Connect the S-video socket of the VCR to the S-VIDEO socket of the set.

2. Connect the audio cable from the VCR to the AUDIO sockets of the set.

3. Select AV 2 by pressing the TV/AV button repeatedly.

4. Press the PLAY button on the VCR. The VCR playback picture appears on the screen.

Note : If both S-VIDEO and VIDEO sockets have been connected to the VCR simultaneously, only the S-VIDEO can be received.

Headphone socket (option)

You can listen to the sound through the headphones. To adjust the headphone volume, press

the F / G button. If you press the MUTE button, the sound from the headphone’s is switched off.

AV (or AV1 )
