Lexmark X7500, X7550 User Guide

Lexmark 7500 Series All-In-One

User Guide

May 2007 www.lexmark.com

Contents

Safety information.........................................................................................................5

Networking the printer...................................................................................................6

General networking.............................................................................................................................6

Wireless networking............................................................................................................................9

Advanced wireless setup...................................................................................................................15

Installing an internal wireless print server..........................................................................................16

Printing.........................................................................................................................18

Getting started...................................................................................................................................18

Learning about the All-In-One software print options........................................................................22

Performing printing and related tasks................................................................................................24

Managing print jobs...........................................................................................................................33

Copying.........................................................................................................................34

Getting started...................................................................................................................................34

Performing copying and related tasks...............................................................................................37

Scanning.......................................................................................................................44

Getting started...................................................................................................................................44

Learning about the All-In-One Center scan options..........................................................................46

Performing scanning and related tasks.............................................................................................52

Scanning over a network...................................................................................................................58

Faxing...........................................................................................................................61

Getting started...................................................................................................................................61

Sending a fax.....................................................................................................................................74

Receiving a fax..................................................................................................................................78

Customizing dial settings...................................................................................................................80

Customizing fax information..............................................................................................................84

Managing fax jobs.............................................................................................................................84

Customizing settings using the Fax Setup Utility...............................................................................87

Working with photos...................................................................................................90

Connecting photo storage devices....................................................................................................90

Working with photos using the control panel.....................................................................................92

Working with photos using the computer...........................................................................................99

Contents

3

Understanding the printer.........................................................................................108

Understanding the printer parts.......................................................................................................108

Understanding the software.............................................................................................................132

Maintaining the printer..............................................................................................144

Print cartridges................................................................................................................................144

Improving print quality.....................................................................................................................148

Cleaning the scanner glass.............................................................................................................148

Cleaning the exterior of the printer..................................................................................................149

Refilling print cartridges...................................................................................................................149

Using genuine Lexmark print cartridges..........................................................................................149

Ordering print cartridges..................................................................................................................149

Ordering paper and other supplies..................................................................................................150

Finding information about the printer...............................................................................................151

Contacting Customer Support.........................................................................................................154

Troubleshooting.........................................................................................................155

Setup troubleshooting.....................................................................................................................155

Wireless troubleshooting.................................................................................................................161

Print troubleshooting........................................................................................................................172

Copy troubleshooting.......................................................................................................................181

Scan troubleshooting.......................................................................................................................183

Fax troubleshooting.........................................................................................................................186

Jams and misfeeds troubleshooting................................................................................................191

Memory card and PictBridge troubleshooting.................................................................................195

Error messages...............................................................................................................................197

Resetting factory default settings....................................................................................................206

Removing and reinstalling the software..........................................................................................207

Notices........................................................................................................................208

Edition notice...................................................................................................................................208

Product information.........................................................................................................................209

European EC directives conformity statement for radio products...................................................212

Power consumption.........................................................................................................................218

Glossary......................................................................................................................225

Contents

4

Safety information

Use only the power supply and power supply cord provided with this product or the manufacturer's authorized
replacement power supply and power supply cord.

Connect the power supply cord to a properly grounded electrical outlet that is near the product and easily accessible.

CAUTION: Do not twist, bind, crush, or place heavy objects on the power cord. Do not subject the power cord
to abrasion or stress. Do not pinch the power cord between objects such as furniture and walls. If the power
cord is misused, a risk of fire or electrical shock results. Inspect the power cord regularly for signs of misuse.
Remove the power cord from the electrical outlet before inspecting it.

Refer service or repairs, other than those described in the user documentation, to a professional service person.
This product is designed, tested, and approved to meet strict global safety standards with the use of specific Lexmark

components. The safety features of some parts may not always be obvious. Lexmark is not responsible for the use
of other replacement parts.

CAUTION: Do not use the fax feature during a lightning storm. Do not set up this product or make any electrical
or cabling connections, such as the power supply cord or telephone, during a lightning storm.

Safety information

5

Networking the printer

General networking

Networking overview

A network is a collection of devices such as computers, printers, Ethernet hubs, wireless access points, and routers
connected together for communication through cables or through a wireless connection. A network can be either
wired, wireless, or designed to have both wired and wireless devices.

Devices on a wired network use cables to communicate with each other.
Devices on a wireless network use radio waves instead of cables to communicate with each other. For a device to

be able to communicate wirelessly, it must have a wireless print server attached or installed that enables it to receive
and transmit radio waves.

Common home network configurations

For desktop computers, laptops, and printers to communicate with each other over a network, they must be
connected by cables and/or have wireless network adapters built in or installed in them.

There are different ways a network can be set up. Five common examples appear below.

Note: The printers in the following diagrams represent Lexmark printers with Lexmark internal print servers built in
or installed in them so that they can communicate over a network. Lexmark internal print servers are devices made
by Lexmark to enable Lexmark printers to be connected to wired or wireless networks.

Wired network example

• A computer, a laptop, and a printer are connected by Ethernet cables to a hub, router, or switch.

• The network is connected to the Internet through a DSL or a cable modem.

Internet

Wireless network examples

Four common wireless networks appear below:

• Scenario 1: Laptop and printer connected wirelessly with Internet

• Scenario 2: Computer, laptop, and printer connected wirelessly with Internet

• Scenario 3: Computer, laptop, and printer connected wirelessly without Internet

• Scenario 4: Laptop connected wirelessly to printer without Internet

Networking the printer

6

Scenario 1: Laptop and printer connected wirelessly with Internet

•

A computer is connected to a wireless router by an Ethernet cable.

• A laptop and a printer are connected wirelessly to the router.

• The network is connected to the Internet through a DSL or a cable modem.

Internet

Scenario 2: Computer, laptop, and printer connected wirelessly with Internet

•

A computer, a laptop, and a printer are connected wirelessly to a wireless router.

• The network is connected to the Internet through a DSL or a cable modem.

Internet

Networking the printer

7

Scenario 3: Computer, laptop, and printer connected wirelessly without Internet

•

A computer, a laptop, and a printer are connected wirelessly to a wireless access point.

• The network has no connection to the Internet.

Scenario 4: Laptop connected wirelessly to printer without Internet

A laptop is directly connected wirelessly to a printer without going through a wireless router.

•

• The network has no connection to the Internet.

Finding the MAC address

Most network equipment has a unique hardware identification number to distinguish it from other devices on the
network. This is called the Media Access Control (MAC) address.

If your printer has a factory installed internal wireless print server, the MAC address is a series of letters and numbers
located on the back of your printer.

If you purchased the internal wireless print server separately, the MAC address appears on an adhesive label that
came with the wireless print server. Attach the adhesive label to your printer so you will be able to find the MAC
address when you need it.

Note: A list of MAC addresses can be set on a router so that only devices with matching MAC addresses can be
allowed to operate on the network. This is called MAC filtering. If MAC filtering is enabled in your router and you
want to add a printer to your network, the MAC address of the printer must be included in the MAC filter list.

Related topics:

• “Printing a network setup page” on page 9

Networking the printer

8

Printing a network setup page

A network setup page lists your network configuration settings.

Note: You can print a network setup page only when an internal wireless print server is installed in the printer.
To print a network setup page:

1 From the control panel of the printer, press or repeatedly until Setup is highlighted.

2 Press .

3 Press or repeatedly until Network Setup is highlighted.

4 Press .

5 Press or repeatedly until Print Network Setup Page is highlighted.

6 Press

A network setup page prints.

Finding a printer/print server located on remote subnets

The printer software CD can automatically find the printers that are located on the same network as the computer.
If the printer and print server are located on another network (called a subnet), you must manually enter an IP address
during printer software installation.

Wireless networking

IP addresses

Finding IP addresses

An IP address is a unique number used by devices on an IP network to locate and communicate with each other.
Devices on an IP network can only communicate with each other if they have unique and valid IP addresses. A
unique IP address means no two devices on the same network have the same IP address.

How to locate a printer's IP address

You can locate the printer's IP address by printing out the printer's network setup page.

How to locate a computer's IP address

Click Apple menu  System Preferences.

1

2 Click Network.

3 From the Show pop-up menu, select Airport.

4 Click TCP/IP.

The IP address appears as four sets of numbers separated by periods, such as 192.168.0.100.

Assigning an IP address

An IP address may be assigned by the network using DHCP. The print object, created at the end of the installation,
sends all print jobs across the network to the printer using this address.

Many networks have the ability to automatically assign an IP address. Auto-IP is the ability for individual devices to
assign themselves a unique IP address. Most networks use DHCP to assign addresses.

Networking the printer

9

Related topics:

•

“Installing the printer on a network” on page 13

Finding the signal strength

Wireless devices have built-in antennas that transmit and receive radio signals. The signal strength listed on the
printer network setup page indicates how strongly a transmitted signal is being received. Many factors can affect
the signal strength. One factor is interference from other wireless devices or even other devices such as microwave
ovens. Another factor is distance. The farther two wireless devices are from each other, the more likely it is that the
communication signal will be weaker.

Sharing the printer on a network

To let other Macintosh computers on your network that use Mac OS X version 10.3 or later use any printer connected
to your Macintosh computer:

1 Click Apple menu  System Preferences.

2 Click Print & Fax.

3 From the Sharing tab, select Share these printers with other computers.

Note: If necessary, click the lock so you can make changes.

4 Select the printer(s) you want to share with other computers.

To let Windows computers on your network use any printer connected to your Macintosh computer:

1 Click Apple menu  System Preferences.

2 Click Print & Fax.

3 From the Sharing tab, select Share these printers with other computers.

Note: If necessary, click the lock so you can make changes.

4 Select the printer(s) you want to share with other computers.

5 Click Show All, and then click Sharing.

6 From the Services tab, select Windows Sharing.

Note: Windows users should see the Windows documentation for information on adding a network printer connected

to a Macintosh computer.

Types of wireless networks

Networks can operate in one of two modes: infrastructure or ad hoc. Lexmark recommends setting up a network in
infrastructure mode using the installation CD that came with the printer.

A wireless network where each device communicates with others through a wireless access point (wireless router)
is set up in infrastructure mode. All devices must have valid IP addresses and share the same SSID and channel.
In addition, they must share the same SSID and channel as the wireless access point (wireless router).

A simple type of wireless network is one where a PC with a wireless adapter communicates directly with a printer
equipped for wireless networking. This mode of communication is called ad hoc. A device in this type of network
must have a valid IP address and be set to ad hoc mode. The wireless print server must also be configured with the
same SSID and channel.

Characteristics

Infrastructure Ad hoc

Networking the printer

10

Communication Through wireless access point (wireless

router)

Security More security options

Directly between devices

Range Determined by range and number of

access points

Speed Usually faster Usually slower

Requirements for all
devices on the network

Unique IP address for each
device

Mode set to Infrastructure mode Ad hoc mode

Same SSID Yes, including the wireless access point

Same channel Yes, including the wireless access point

Infrastructure mode is the recommended setup method because it has:

Yes Yes

(wireless router)

(wireless router)

Restricted to range of individual devices
on network

Yes

Yes

• Increased network security

• Increased reliability

• Faster performance

• Easier setup

Using a wireless network connection

This printer contains an internal wireless print server, which allows the printer to be used on a wireless network. The
following settings from your existing wireless network may be needed to properly configure the printer for use on the
network:

• The network name, also known as the SSID

• The type of security used on the network (WEP, WPA, WPA2)

• Any applicable security keys or passwords used with the network security encryption type

1 Insert the printer software CD.

2 From the Finder desktop, double-click the Lexmark 7500 Series icon.

3 Double-click Install.

4 Click Continue.

5 Follow the instructions on the computer screen.

If your printer is already installed but you have not set it up for use on your wireless network, you need to add your
printer to the Printer List.

1 From the Finder desktop, click Applications.

2 From Applications, double-click Utilities.

3 Double-click Printer Setup Utility.

The Printer List dialog appears.

Networking the printer

11

4 From the menu bar, click Add.

The Printer Browser dialog appears.

5 Select XXXX Series <MAC:nnnnnn>, and then click Add.

The Printer Browser closes, and the printer is displayed in the Printer List dialog.

Note: XXXX is the printer series number, and nnnnnn is the last six digits of the printer's MAC address.

6 Run the Wireless Setup Assistant to configure the printer for use on your wireless network.

For more information, see “Run the Wireless Setup Assistant” on page 172.

Related topics:

• “Changing wireless settings after installation” on page 12

Changing wireless settings after installation

Use the Wireless Setup Assistant to change your password, network name (SSID), or other wireless setting.

1 From the Finder desktop, double-click the Lexmark 7500 Series folder.

2 Double-click Wireless Setup Assistant.

3 Follow the instructions on the computer screen.

Tips for using network adapters

• Make sure the adapter connections are secure.

• Make sure the computer is turned on.

• Make sure you entered the correct IP address.

Know your security keys

To set up your printer for wireless printing, you need the following information:

• Know the name (SSID) of your wireless network.

• If your wireless network uses a security scheme, make sure you know the password that was used to keep your

network secure. This password is also known as a security key, WEP key, or WPA key.
Note: If you do not know this information, see the documentation that came with the wireless network, or contact

the person who set up your wireless network.
Use the table below to write down the information you need to know.

Item Description

SSID (name of your network)

Security key (password)

• Make sure you copy down the security key exactly, including any capital letters, and store it in a safe place for

future reference.
The security key must follow the following criteria:

WEP key

– Exactly 10 or 26 hexadecimal characters. Hexadecimal characters are A–F and 0–9.
– Exactly 5 or 13 ASCII characters. ASCII characters are letters, numbers, and symbols found on a keyboard.

Networking the printer

12

WPA-PSK or WPA2-PSK key

– Up to 64 hexadecimal characters. Hexadecimal characters are A–F and 0–9.
– Between 8 and 64 ASCII characters. ASCII characters are letters, numbers, and symbols found on a

keyboard.

Networking the printer

Installing and configuring a printer for use on a network lets users at different computers print to a common printer.
There are two methods for networking this printer:

• Configure a wireless network connection for the printer.

Note: To set up the printer, use a computer that connects wirelessly to the network. The printer must be near

the computer you will be using to configure it. After configuration, the printer can be moved to the location where
it will reside.

• Connect the printer directly to a network computer using the USB cable, and enable it to be shared across the

network (printer sharing).
Note: Refer to Mac Help for details on how to share your printer across the network.

Why do I need an installation cable?

When you set up the printer on your wireless network, you will need to temporarily connect the printer to a computer
using the installation cable. This temporary connection is used to set up the wireless settings of the printer.

Installing the printer on a network

Follow the instructions for the networking method you want to use. Make sure the selected network is set up and
working properly, and that all relevant devices are turned on. For more information on your specific network, see
your network documentation or consult the person who set up the network.

Installing the printer on additional network computers

If you are installing your network printer for use with multiple computers on the network, insert the installation CD
into each additional computer, and follow the instructions on the computer screen.

• You do not need to repeat the connection steps for each computer you want to print to the printer.

• The printer should appear as a highlighted printer in the installation. If multiple printers appear in the list, make

sure you select the printer with the correct IP address/MAC address.

Related topics:

• “Finding IP addresses” on page 9

• “Finding the MAC address” on page 8

Selecting a network printer

You can print or scan using a network printer connected to a local or remote subnet.

1 Open the application that you want to use. The Network Selection sheet can be accessed through three different

paths:

If you are using Do this

Lexmark Setup Assistant (during
setup)

a Install the printer software. For more information, see “Installing the

printer software” on page 132.

b Once the Printer Selection screen appears, choose Add Remote

from the drop-down menu.

Networking the printer

13

If you are using Do this

All-in-One Center

a From the Finder desktop, double-click the Lexmark 7500 Series

folder.

b Double-click the Lexmark 7500 Series Center icon.
c From the menu, choose Advanced Network Scan Access.

The Network Scan Access dialog appears.

d Click +.

Network Card Reader

a From the Finder desktop, double-click the Lexmark 7500 Series

folder.

b Double-click the Lexmark Network Card Reader icon.
c Click +.

The Network Selection sheet appears.

2 Select a printer from your local subnet or from a remote subnet.

• The application searches for supported printers in the network or printers that are connected to your

computer.

• If you want to select a particular printer on a remote subnet, type the IP address of the print server to which

the printer is connected in the Search by IP field, and then press return on your keyboard. If you do not
know the IP address of the print server, consult the person who set up your network.

• If you want to search a remote subnet for supported printers, type any IP address that belongs to the

particular subnet in the Search by IP field and the subnet mask in CIDR notation, and then press return on
your keyboard. If you do not know the IP address of the print server, consult the person who set up your
network.

3 From the list of printers, select the name of the printer that you want to use.

4 Click Select.

Why do I need to disconnect the installation cable?

You need to disconnect the installation cable to complete the wireless installation.

What do the Wi-Fi indicator lights mean?

• Off indicates that the printer is not turned on, or a wireless print server is not installed.

Select this option:

– If you want to connect the printer to the computer using a USB cable.
– If the printer does not have a wireless print server installed and you want to connect the printer to the

computer using a USB cable.

• Orange indicates that the printer is ready to be configured for wireless printing, but it is not connected to a

wireless network.
Select this option if you want to set up the printer on your wireless network.

• Orange blinking indicates that the printer is configured, but it is unable to communicate with the wireless

network.
Select this option if you want to modify the wireless settings of the printer.

• Green indicates that the printer is connected to a wireless network.

Select this option to start using the printer that is already set up on your wireless network.

Networking the printer

14

Advanced wireless setup

Creating an ad hoc wireless network using Mac

The recommended way to set up your wireless network is to use a wireless access point (wireless router). A network
set up this way is called an infrastructure network. If you have an infrastructure network in your home, you should
configure your printer for use on that network.

If you don't have a wireless access point (wireless router) or would like to set up a standalone network between your
printer and a computer with a wireless network adapter, you can set up an ad hoc network.

1 Make sure the computer is on.

2 From the Finder desktop, click Applications.

3 From Applications, double-click Internet Connect.

4 From the toolbar, click AirPort.

5 From the Network pop-up menu, click Create Network.

6 Create a name for your ad hoc network, and then click OK.

7 Insert the CD for Macintosh to run the wireless setup.

8 From the Finder desktop, double-click the Lexmark 7500 Series icon.

9 Double-click the Install icon.

10 Click Continue.

11 Follow the instructions on the computer screen.

Note: Store your network name and password in a safe place for future reference.

Adding a printer to an existing ad hoc wireless network using Mac

1 From the Finder desktop, double-click the Lexmark 7500 Series folder.

2 Double-click Wireless Setup Assistant.

3 Follow the instructions on the computer screen.

Networking the printer

15

Installing an internal wireless print server

The printer you purchased may contain an internal wireless print server that allows the printer to be used on a wireless
network. If your printer does not have an internal wireless print server already installed, you can purchase one
separately. Use the following instructions to install the internal wireless print server:

1 Turn off your printer, and then unplug the power cord from the wall outlet.

Warning: Failure to unplug the printer can cause damage to your printer and to the internal wireless print server.

Make sure the printer is turned off and the power cord is unplugged from the wall outlet before you proceed.

2 Remove the back cover plate by pushing the tab down and then pulling the cover away from the printer.

3 Unpack the internal wireless print server. Save the packaging materials.

Warning: Wireless print servers are easily damaged by static electricity. Touch something metal such as the

printer frame before you touch the wireless print server.

4 Align the edges of the internal wireless print server with the guides on the left and right, and then slide the wireless

print server into the printer until it snaps into place.

5 Make sure the antenna points up.

6 Attach the adhesive label with the MAC address to the back of the printer. You will need this later to in order to

network the printer.

Networking the printer

16

You are now ready to configure the internal wireless print server to work on your wireless network.

Networking the printer

17

Printing

Getting started

Loading paper

1 Make sure:

• You use paper designed for inkjet printers.

• If you are using photo, glossy, or heavyweight matte paper, you load it with the glossy or printable side facing

you. (If you are not sure which side is the printable side, see the instructions that came with the paper.)

• The paper is not used or damaged.

• If you are using specialty paper, you follow the instructions that came with it.

• You do not force paper into the printer.

2 Before loading paper the first time, slide the paper guides out toward the edges of the paper support. You can

load up to:

• 100 sheets of plain paper

• 25 sheets of heavyweight matte paper

• 25 sheets of photo paper

• 25 sheets of glossy paper

Note: Photos require more drying time. Remove each photo as it exits, and allow it to dry to avoid ink smudging.

3 Load the paper vertically in the center of the paper support, and adjust the paper guides to rest against the edges

of the paper.

Note: To avoid paper jams, make sure the paper does not buckle when you adjust the paper guides.

Related topics:

• “Using the automatic paper type sensor” on page 18

Using the automatic paper type sensor

The printer is equipped with an automatic paper type sensing device. The Paper Type Sensor automatically detects
the type of paper that has been loaded into the printer and adjusts the settings for you. For example, if you want to
print a photo, load photo paper into the printer. The printer detects the type of paper and automatically adjusts the
settings to give you optimum photo-printing results.

Printing

18

Loading envelopes

You can load up to 10 envelopes at a time.

Warning: Do not use envelopes that have metal clasps, string ties, or metal folding bars.

1 Load envelopes in the center of the paper support with the stamp location in the upper left corner.

2 Make sure:

• The print side of the envelopes faces you.

• The envelopes are designed for use with inkjet printers.

• The paper guides rest against the edges of the envelopes.

Notes:

• Do not load envelopes with holes, perforations, cutouts, or deep embossing.

• Do not use envelopes that have exposed flap adhesive.

• Envelopes require more drying time. Remove each envelope as it exits, and allow it to dry to avoid ink

smudging.

Related topics:

• “Printing envelopes” on page 26

Loading labels

You can load up to 25 sheets of labels at a time.

1 Load labels with the print side facing you and the top of the sheet fed into the printer first.

2 Make sure:

• The print side of the labels faces you.

• The top of the labels feeds into the printer first.

• The adhesive on the labels does not extend to within 1 mm of the edge of the labels.

• You use full label sheets. Partial sheets (with areas exposed by missing labels) may cause labels to peel

off during printing, resulting in a paper jam.

• The labels are loaded in the center of the paper support.

• The paper guides rest against the edges of the labels.

Note: Labels require more drying time. Remove each sheet of labels as it exits, and allow it to dry to avoid ink

smudging.

Printing

19

Loading greeting cards, index cards, photo cards, and postcards

You can load up to 25 greeting cards, index cards, photo cards, or postcards at a time.

1 Load cards with the print side facing you.

2 Make sure:

• The cards are loaded in the center of the paper support.

• The paper guides rest against the edges of the cards.

Note: Photo cards require more drying time. Remove each photo card as it exits, and allow it to dry to avoid ink

smudging.

Related topics:

• “Printing cards” on page 25

Loading transparencies

You can load up to 50 transparencies at a time.

1 Load transparencies with the rough side facing you. If the transparencies have a removable strip, each strip

should face away from you and down toward the printer.

2 Make sure:

• The transparencies are loaded in the center of the paper support.

• The paper guides rest against the edges of the transparencies.

Notes:

• Transparencies with paper backing sheets are not recommended.

• Transparencies require more drying time. Remove each transparency as it exits, and allow it to dry to avoid

ink smudging.

Related topics:

• “Printing transparencies” on page 27

Loading iron-on transfers

You can load up to 10 iron-on transfers at once, but you will achieve best results loading them one at a time.

1 Load iron-on transfers with the print side of the transfer facing you.

2 Make sure:

• You follow the loading instructions that came with the iron-on transfers.

• The transfers are loaded in the center of the paper support.

• The paper guides rest against the edges of the transfers.

Printing

20

Related topics:

• “Printing iron-on transfers” on page 27

Loading custom-size paper

You can load up to 100 sheets of custom-size paper at a time.

1 Load paper with the print side facing you.

2 Make sure:

• The paper size fits within these dimensions:

Width:

– 76.0–216.0 mm
– 3.0–8.5 inches

Length:

– 127.0–432.0 mm
– 5.0–17.0 inches

• The stack height does not exceed 10 mm.

• The paper is loaded in the center of the paper support.

• The paper guides rest against the edges of the paper.

Loading banner paper

You can load up to 20 sheets of banner paper at a time.

1 Remove all paper from the paper support before loading the banner paper.

2 Tear off only the number of pages needed to print the banner.

3 Place the required stack of banner paper on the top cover.

4 Feed the leading edge of the banner paper into the printer first.

5 Make sure:

• The paper is loaded in the center of the paper support.

• The paper guides rest against the edges of the paper.

Related topics:

• “Printing a banner” on page 28

Printing

21

Choosing compatible specialty paper types

• Heavyweight matte paper—A photo paper with a matte finish used for printing high-quality graphics.

• Lexmark PerfectFinish

printers, but compatible with all inkjet printers. It is used specifically for printing professional quality photos with
a glossy finish. It is best when used with genuine Lexmark evercolor
water-resistant.

TM

Photo paper—A high-quality photo paper specifically designed for Lexmark inkjet

TM

2 ink, providing photos that are fade- and

• Lexmark Photo Paper—An outstanding "everyday" heavyweight inkjet photo paper designed for use with

Lexmark printers, but compatible with all brands of inkjet printers. Although inexpensive, it offers excellent image
quality and outstanding value.

• Transparency—A clear, plastic media primarily used for overhead projectors.

• Card stock—A very thick paper used for printing sturdier items, such as greeting cards.

• Iron-On transfer—A type of media that has a reverse image printed on it that can be ironed onto fabric.

Learning about the All-In-One software print options

Choosing a paper size

1 With a document open, click File  Page Setup.

2 From the “Format for” pop-up menu, choose 7500 Series.

Note: When you select Any Printer, your paper size choices are limited. By selecting the name of your printer,

you have many more paper size options.

3 From the Paper Size pop-up menu, choose a paper size.

4 Click OK.

Related topics:

• “Using the Page Setup dialog” on page 133

Choosing a paper type

By default, the paper type sensor is set to Automatic. It can detect and adjust the paper type settings for plain,
heavyweight matte, glossy/photo, and transparency paper. To manually choose the paper type:

1 With a document open, click File  Print.

2 From the Copies & Pages pop-up menu, choose Quality & Media.

3 From the Paper Type pop-up menu, choose a paper type.

4 Click Print.

Notes:

• Manually choosing a paper type turns off the paper type sensor for the current print job.

• For multiple-page jobs, the printer assumes the subsequent pages are the same paper type as the first sheet

detected.

Related topics:

• “Using the Print dialog” on page 134

Printing

22

Choosing a print quality

1 With a document open, click File  Print.

2 From the Printer pop-up menu, choose 7500 Series.

3 From the third pop-up menu from the top, choose Quality & Media.

4 From the Print Quality menu, select the appropriate print quality for the document:

• Automatic—Default selection.

• Quick Print—Best for text-only documents with reduced print quality but faster print speed.

• Normal—Recommended for most types of documents.

• Best—Recommended for photos and documents with graphics.

5 Click Print.

Related topics:

• “Using the Print dialog” on page 134

Collating copies using the computer

The printer can sort multiple copy jobs. For example, if you print two copies of a three-page document, and you
choose not to collate them, the pages print in this order: 1, 1, 2, 2, 3, 3. If you choose to collate, the pages print in
this order: 1, 2, 3, 1, 2, 3.

1 With a document open, click File  Print.

2 In the Copies field, enter the number of copies you want to print.

3 Choose Collated.

Related topics:

• “Collating copies using the control panel” on page 39

• “Using the Print dialog” on page 134

Sharpening an image

1 From the Finder desktop, double-click the Lexmark 7500 Series folder.

2 Double-click the Lexmark 7500 Series Center icon.

3 Click Preview/Edit to open the Scan dialog.

4 From the Scan dialog, click to open the Scan Settings drawer.

5 Click the Adjustments tab.

6 From the Blur/Sharpen area, move the slider to adjust the level of sharpness of the scanned image.

Related topics:

• “Customizing scan settings from the Scan dialog” on page 48

• “Enhancing photo print quality using the software” on page 105

Resetting All-In-One software settings to defaults

1 From the Finder desktop, double-click the Lexmark 7500 Series folder.

2 Double-click the Lexmark 7500 Series Center icon.

Printing

23

3 Click Defaults.

Related topics:

• “Using the All-In-One Center” on page 138

• “Customizing scan settings from the Scan dialog” on page 48

Performing printing and related tasks

Printing a document

1 Load paper.

2 With a document open, click File  Print.

3 From the Printer pop-up menu, choose 7500 Series.

4 From the third pop-up menu from the top, select the settings you want to adjust, and adjust the settings.

You can specify print quality, the number of copies to print, the type of paper you're printing on, and how you
want the pages to print.

5 Click Print.

Related topics:

• “Loading paper” on page 18

• “Using the Print dialog” on page 134

Printing photos

1 Load photo paper with the glossy or printable side facing you. (If you are not sure which side is the printable

side, see the instructions that came with the paper.)
Note: For best results, use Lexmark Photo Paper or Lexmark PerfectFinish Photo Paper. Do not use Lexmark

Premium Photo Paper. Your print cartridges are not compatible with this type of paper.

2 Customize the settings as needed in the Page Setup dialog.

a With a photo open, choose File  Page Setup.

b From the “Format for” pop-up menu, choose 7500 Series.

c From the Paper Size pop-up menu, choose the paper size loaded.

d Choose an orientation.

e Click OK.

3 Customize the settings as needed in the Print dialog.

a With a photo open, choose File  Print.

b From the Printer pop-up menu, choose 7500 Series.

c For Mac OS X version 10.4 or later, click Advanced. Otherwise, proceed to the next step.

d From the Copies & Pages pop-up menu, type the number of copies to be printed in the Copies field.

e From the same pop-up menu, choose Quality & Media.

• From the Paper Type pop-up menu, choose the type of paper you are using.

• From the Print Quality menu, choose Automatic or Best.

f Click Print.

Printing

24

Related topics:

• “Enhancing photo print quality using the software” on page 105

• “Using the Print dialog” on page 134

• “Printing borderless photos” on page 25

Printing borderless photos

1 Load photo or glossy paper with the glossy or printable side facing you. (If you are not sure which side is the

printable side, see the instructions that came with the paper.)

Notes:

• Use only the following paper sizes to print borderless photos: letter, A4, A5, B5, A6, Hagaki, 3.5 x 5 in.,

4 x 6 in., 5 x 7 in., 10 x 15 cm, 13 x 18 cm, L, and 2L.

• If you use plain paper instead of a photo paper, the printed photo may come out with small margins around

its borders.

2 Customize the settings as needed in the Page Setup dialog.

a With a photo open, choose File  Page Setup.

b From the “Format for” pop-up menu, choose 7500 Series.

c From the Paper Size pop-up menu, choose the paper size loaded.

Note: Make sure you choose an option that has (Borderless) in it. For example, if you loaded a 4 x 6 photo
card, choose US 4 x 6 in (Borderless).

d Choose an orientation.

e Click OK.

3 Customize the settings as needed in the Print dialog.

a With a photo open, choose File  Print.

b From the Printer pop-up menu, choose 7500 Series.

c For Mac OS X version 10.4 or later, click Advanced. Otherwise, proceed to the next step.

d From the Copies & Pages pop-up menu, type the number of copies to be printed.

e From the same pop-up menu, choose Quality & Media.

• From the Paper Type pop-up menu, choose the type of paper you are using.

• From the Print Quality menu, choose Automatic or Best.

f Click Print.

Related topics:

• “Enhancing photo print quality using the software” on page 105

Printing cards

1 Load greeting cards, index cards, or postcards.

Notes:

• Make sure the thickness of each card does not exceed 0.020 inch (0.50 mm).

• Make sure the print side of the card faces you.

2 Customize the settings as needed in the Page Setup dialog.

a With a document open, click File  Page Setup.

b From the “Format for” pop-up menu, choose 7500 Series.

Printing

25

c From the Paper Size pop-up menu, choose a card size.

d Choose an orientation.

e Click OK.

3 Customize the settings as needed in the Print dialog.

a From the software application, click File  Print.

b From the Printer pop-up menu, choose 7500 Series.

c Click Print.

Notes:

• To avoid paper jams, do not force the cards into the printer.

• To prevent smudging, remove each card as it exits, and let it dry before stacking.

Related topics:

• “Loading greeting cards, index cards, photo cards, and postcards” on page 20

Printing envelopes

1 Load envelopes.

Notes:

• Do not load envelopes with holes, perforations, cutouts, deep embossing, metal clasps, metal folding bars,

string ties, or exposed flap adhesive.

• Make sure the print side of the envelopes faces you.

2 Customize the settings as needed in the Page Setup dialog.

a With a document open, click File  Page Setup.

b From the “Format for” pop-up menu, choose 7500 Series.

c From the Paper Size pop-up menu, choose the envelope size loaded.

d Choose an orientation.

Notes:

• Most envelopes use landscape orientation.

• Make sure the same orientation is also selected in the software application.

e Click OK.

3 Customize the settings as needed in the Print dialog.

a From the software application, click File  Print.

b From the Printer pop-up menu, choose 7500 Series.

c Click Print.

Related topics:

• “Loading envelopes” on page 19

Printing

26

Printing iron-on transfers

1 Load iron-on transfers.

2 Customize the settings as needed in the Page Setup dialog.

a With a document open, click File  Page Setup.

b From the “Format for” pop-up menu, choose 7500 Series.

c From the Settings pop-up menu, choose Page Attributes.

d Choose a paper size.

e Choose an orientation.
f Click OK.

3 Customize the settings as needed in the Print dialog.

a From the software application, click File  Print.

b From the Printer pop-up menu, choose 7500 Series.

c From the third pop-up menu from the top, choose Quality & Media.

d From the Paper Type pop-up menu, choose Iron-On Transfer.

Note: Choosing Iron-On Transfer automatically mirrors the image you want to print.

e Select a print quality other than Quick Print. Best is recommended.

4 Click Print.

Note: To prevent smudging, remove each iron-on transfer as it exits, and let it dry before stacking.

Related topics:

• “Using the Page Setup dialog” on page 133

• “Using the Print dialog” on page 134

Printing transparencies

1 Load transparencies.

2 Customize the settings as needed in the Page Setup dialog.

a With a document open, click File  Page Setup.

b From the “Format for” pop-up menu, choose 7500 Series.

c From the Paper Size pop-up menu, choose a paper size.

d Choose an orientation.

e Click OK.

3 Customize the settings as needed in the Print dialog.

a From the software application, click File  Print.

b From the Printer pop-up menu, choose 7500 Series.

c From the third pop-up menu from the top, choose Quality & Media.

• From the Paper Type pop-up menu, choose Transparency.

• Select a print quality.

Note: Higher print quality settings result in better quality documents but may take longer to print.

d Click Print.

Printing

27

Note: To prevent smudging, remove each transparency as it exits, and let it dry before stacking. Transparencies

may require up to 15 minutes to dry.

Related topics:

• “Loading transparencies” on page 20

Printing a banner

1 Remove all paper from the paper support.

2 Tear off only the number of pages needed for the banner (up to 20 sheets).

3 Place the required stack of banner paper on the top cover.

4 Load only the first page of banner paper into the paper support with the leading edge of the banner going into

the printer.

5 Adjust the left and right paper guides.

6 Customize the settings in the Page Setup dialog.

a With your document open, choose File  Page Setup.

b From the Settings pop-up menu, choose Page Attributes.

c From the “Format for” pop-up menu, choose the printer.

d From the Paper Size pop-up menu, choose A4 Banner or US Letter Banner.

e Select an orientation.
f Click OK.

7 Customize the settings in the Print dialog.

a With your document open, choose File  Print.

b From the Printer pop-up menu, choose the printer.

c From the third pop-up menu from the top, choose Quality & Media.

• From the Paper Type pop-up menu, choose Plain.

• Select a print quality.

Note: Higher print quality settings result in better quality documents but may take longer to print.

d Click OK.

Related topics:

• “Using the Print dialog” on page 134

• “Loading banner paper” on page 21

Printing

28

Printing multiple pages on one sheet

1 Load paper.

2 Customize the settings as needed in the Page Setup dialog.

a With a document open, choose File  Page Setup.

b From the “Format for” pop-up menu, choose 7500 Series.

c From the Settings pop-up menu, choose Page Attributes.

d Choose a paper size.

e Choose an orientation.
f Click OK.

3 Customize the settings as needed in the Print dialog.

a With a document open, click File  Print.

b From the Printer pop-up menu, choose 7500 Series.

c From the third pop-up menu from the top, choose Layout.

• From the Pages per Sheet pop-up menu, choose the number of pages you want to print on one sheet.

• From the Layout Direction area, click the icon that shows the order you want the pages to print on one

sheet.

• If you want to print a border around each page image, choose an option from the Border pop-up menu.

d Click Print.

Related topics:

• “Loading paper” on page 18

Printing color images in black and white

This setting is available only if there is a black print cartridge installed.

1 Load paper.

2 Customize the settings in the Page Setup dialog as needed.

3 With a document open, click File  Print.

4 From the Printer pop-up menu, choose 7500 Series.

5 From the third pop-up menu from the top, choose Color Options.

6 From the Document Color pop-up menu, choose Black Only.

7 Click Print.

Printing multiple copies of a stored document

1 With a document open, click File  Print.

2 From the Printer pop-up menu, choose 7500 Series.

3 From the third pop-up menu, choose Copies & Pages.

4 Enter the number of copies you want to print.

Related topics:

• “Using the Print dialog” on page 134

Printing

29

Printing the last page first (reverse page order)

For Mac OS X version 10.4.2 or later:

1 With a document open, click File  Print.

2 From the third pop-up menu, choose Paper Handling.

3 From the Page Order menu, select Reverse.

4 Click Print.

For Mac OS X version 10.3.9:

1 With a document open, click File  Print.

2 From the third pop-up menu, choose Paper Handling.

3 Select Reverse page order.

4 Click Print.

Related topics:

• “Using the Print dialog” on page 134

Printing document files from a memory card or flash drive

To use the Print Files function, your printer must be connected to a computer, and both the printer and computer
must be on. The computer must contain applications that support the desired file formats.

1 Insert a memory card or flash drive containing document files into the printer.

The following file types are recognized:

• .doc (Microsoft Word)

• .xls (Microsoft Excel)

• .ppt (Microsoft Powerpoint)

• .pdf (Adobe Portable Document Format)

• .rtf (Rich Text Format)

• .docx (Microsoft Word Open Document Format)

• .xlsx (Microsoft Excel Open Document Format)

• .pptx (Microsoft Powerpoint Open Document Format)

• .wps (Microsoft Works)

• .wpd (WordPerfect)

2 Press to select Print Files.

3 Press or to select a file to print.

4 Press .

Related topics:

• “Inserting a memory card” on page 90

• “Inserting a flash drive” on page 91

Printing

30

Assembling a booklet

1 Flip the printed stack of papers over in the paper exit tray.

2 Take the first bundle from the stack, fold it in half, and then set it aside with the front page down.

3 Take the next bundle from the stack, fold it in half, and then stack it with the front page down on top of the first

bundle.

4 Stack the rest of the bundles with the front page down, one on top of the other, until the booklet is complete.

5 Bind the bundles together to complete the booklet.

Printing on both sides of the paper (duplexing)

The printer has a built-in duplex unit that lets you print on both sides of the paper automatically for letter- or A4-size
plain paper.

If you need to print duplex using paper other than letter- or A4-size plain paper, see “Printing on both sides of the
paper (duplexing) manually” on page 32.

Printing on both sides of the paper (duplexing) automatically

The printer has a built-in duplex unit that lets you print on both sides of the paper automatically by using the settings
in the Two-Sided menu of the Print dialog.

Note: Use only letter- or A4-size plain paper.

1 Load paper.

2 With a document open, click File  Print.

3 From the Printer pop-up menu, choose 7500 Series.

4 From the third pop-up menu from the top, choose Layout.

5 From the Two-Sided menu, select Long-edged binding or Short-edged binding.

• For Long-edged binding, pages are bound along the long edge of the page (left edge for portrait, top edge

for landscape).

1

2

Printing

31

• For Short-edged binding, pages are bound along the short edge of the page (left edge for landscape, top

edge for portrait).

2

1

6 Click Print.

Related topics:

•

“Duplex unit does not operate correctly” on page 179

• “Paper jam in the duplex unit” on page 192

Printing on both sides of the paper (duplexing) manually

Note: If you are using letter- or A4-size plain paper, use automatic duplexing. For more information, see “Printing

on both sides of the paper (duplexing) automatically” on page 31.

1 With a document open, click File  Print.

2 From the third pop-up menu from the top, choose Paper Handling.

3 From the Print menu, select Odd numbered pages.

4 Click Print.

5 After printing the first set of pages, flip the stack of printouts.

Load the stack of pages back into the paper support, with the blank side of the pages facing you.

6 Repeat steps 1 and 2.

7 From the Print menu, select Even numbered pages.

8 Click Print.

Printing a test page using the computer

1 Load plain paper.

2 From the Finder desktop, double-click the Lexmark 7500 Series folder.

3 Double-click the Lexmark 7500 Series Utility icon.

4 From the Maintenance tab, click Print Test Page.

A page prints.
If the test page did not print at all or has quality problems, attend to any error messages that appear on the

screen.

Related topics:

• “Using the Utility” on page 142

• “Test page does not print” on page 159

Printing

32

Managing print jobs

Pausing print jobs

1 While the document is printing, click the printer icon on the dock.

2 From the queue window, select the job you want to pause.

3 Click the Hold icon.

Note: You can also click the Stop Jobs icon to pause printing all jobs.

Related topics:

• “Using the Print dialog” on page 134

• “Resuming print jobs” on page 33

• “Canceling a print job” on page 33

Canceling a print job

To cancel a print job using the control panel:

1 Press .

Printing stops and the print cartridge carrier returns to its home position.

2 Press to turn off the printer.

To cancel a print job using the computer:

1 While the document is printing, click the printer icon on the dock.

2 From the queue window, select the job you want to cancel.

3 Click the Delete icon.

Related topics:

• “Using the control panel” on page 113

• “Pausing print jobs” on page 33

Resuming print jobs

1 From the Finder desktop, choose Applications  Utilities  Print Center or Printer Setup Utility, depending

on the operating system version you are using.

2 From the list of printers, double-click your printer.

3 From the printer pop-up menu, click Start Jobs if you want to resume all print jobs in the queue. If you want to

resume a particular print job, select the document name, and then click Resume.

Related topics:

• “Pausing print jobs” on page 33

• “Canceling a print job” on page 33

Printing

33

Copying

Getting started

Loading paper

1 Make sure:

• You use paper designed for inkjet printers.

• If you are using photo, glossy, or heavyweight matte paper, you load it with the glossy or printable side facing

you. (If you are not sure which side is the printable side, see the instructions that came with the paper.)

• The paper is not used or damaged.

• If you are using specialty paper, you follow the instructions that came with it.

• You do not force paper into the printer.

2 Before loading paper the first time, slide the paper guides out toward the edges of the paper support. You can

load up to:

• 100 sheets of plain paper

• 25 sheets of heavyweight matte paper

• 25 sheets of photo paper

• 25 sheets of glossy paper

Note: Photos require more drying time. Remove each photo as it exits, and allow it to dry to avoid ink smudging.

3 Load the paper vertically in the center of the paper support, and adjust the paper guides to rest against the edges

of the paper.

Note: To avoid paper jams, make sure the paper does not buckle when you adjust the paper guides.

Related topics:

• “Using the automatic paper type sensor” on page 18

Loading original documents on the scanner glass

You can scan and then print photos, text documents, magazine articles, newspapers, and other publications. You
can scan a document for faxing.

Copying

34

Note: The maximum scan area for the scanner glass is 216 x 297 mm (8.5 x 11.7 in.).

1 Open the top cover.

2 Place the original document or item facedown on the scanner glass in the lower right corner.

Note: Photos should be loaded as shown.

3 Close the top cover to avoid dark edges on the scanned image.

Copying

35

Loading original documents into the Automatic Document Feeder

You can load up to 25 sheets of an original document into the Automatic Document Feeder tray for scanning, copying,
and faxing. You can load A4, letter, or legal size paper into the Automatic Document Feeder.

1 Load an original document text side up into the Automatic Document Feeder tray.

Note: Do not load postcards, photos, small items, or thin media (such as magazine clippings) into the Automatic

Document Feeder. Place these items on the scanner glass.

2 Adjust the paper guide on the Automatic Document Feeder tray against the edges of the paper.

Automatic Document Feeder paper capacity

Load up to Make sure

25 sheets of:

• Letter paper

• The document is loaded text side up.

• The paper guide is against the edge of the paper.

• A4 paper

• Legal-size paper

Copying

36

Load up to Make sure

25 sheets of:

• Custom paper

• Pre-punched paper

• Reinforced edge copier paper

• Preprinted forms

• Letterhead paper

• The document is loaded text side up.

• The paper guide is against the edge of the paper.

• The paper size fits within these dimensions:

Width:

– 210.0 mm–215.9 mm
– 8.27 in.–8.5 in.

Length:

– 279.4 mm–355.6 mm
– 11.0 in.–14.0 in.

• You allow preprinted media to dry thoroughly before loading

into the Automatic Document Feeder tray.

• You do not use media printed with metallic ink particles.

• You avoid embossed designs.

Using the automatic paper type sensor

The printer is equipped with an automatic paper type sensing device. The Paper Type Sensor automatically detects
the type of paper that has been loaded into the printer and adjusts the settings for you. For example, if you want to
print a photo, load photo paper into the printer. The printer detects the type of paper and automatically adjusts the
settings to give you optimum photo-printing results.

Performing copying and related tasks

Making a copy

1 Load paper.

2 Load an original document facedown on the scanner glass.

3 From the control panel, press or repeatedly until Copy is highlighted.

4 Press or to select the number of copies.

The number of copies is automatically set to 1.

5 Press .

Related topics:

• “Using the control panel” on page 113

• “Loading original documents on the scanner glass” on page 34

Making a color or black-and-white copy

1 Load paper.

2 Load an original document facedown on the scanner glass.

3 From the control panel, press or repeatedly until Copy is highlighted.

4 Press or to select the number of copies.

The number of copies is automatically set to 1.

Copying

37

5 Press .

6 Press repeatedly until Color is highlighted.

7 Press or to choose Color or Black & White.

8 Press to preview the copy.

9 Press to continue adjusting the settings.

10 Repeat step 8 to step 9 as needed.

11 Press to save your settings temporarily.

12 Press .

Adjusting the brightness of a copy

1 Load paper.

2 Load an original document facedown on the scanner glass.

3 From the control panel, press or repeatedly until Copy is highlighted.

4 Press or to select the number of copies.

The number of copies is automatically set to 1.

5 Press .

6 Press repeatedly until Lighter/Darker is highlighted.

7 Press or to adjust the brightness of the copy.

8 Press to preview the copy.

9 Press to continue adjusting the settings.

10 Repeat step 8 to step 9 as needed.

11 Press to save your settings temporarily.

12 Press .

Related topics:

• “Loading original documents on the scanner glass” on page 34

• “Using the control panel” on page 113

Copying photos

1 Load photo paper with the glossy or printable side facing you. (If you are not sure which side is the printable

side, see the instructions that came with the paper.)

2 Place a photo facedown on the scanner glass.

3 From the control panel, press or repeatedly until Copy is highlighted.

4 Press or to select the number of copies.

The number of copies is automatically set to 1.

Copying

38

5 Press .

6 Adjust the copy settings as needed. To make a borderless copy, choose Borderless under Resize. For more

information, see “Understanding Copy and the Copy Mode menu” on page 117.

7 After making your choices, press to save your settings temporarily.

8 Press .

Note: To prevent smudging or scratching, avoid touching the printed surface with your fingers or sharp objects. For

best results, remove each printed sheet individually from the paper exit tray, and allow the prints to dry at least 24
hours before stacking, displaying, or storing.

Related topics:

• “Using the control panel” on page 113

Adjusting copy quality

1 Load paper.

2 Load an original document facedown on the scanner glass.

3 From the control panel, press or repeatedly until Copy is highlighted.

4 Press or to select the number of copies.

The number of copies is automatically set to 1.

5 Press .

6 Press repeatedly until Quality is highlighted.

7 Press or to choose among the following options: Normal, Photo, Auto, or Draft.

8 Press to preview the output.

9 Press to adjust the settings.

10 Repeat step 8 to step 9 as needed.

11 Press to save your settings temporarily.

12 Press .

Related topics:

• “Loading original documents on the scanner glass” on page 34

• “Using the control panel” on page 113

Collating copies using the control panel

If you print multiple copies of a document, you can choose to print each copy as a set (collated) or to print the copies
as groups of pages (not collated).

Collated Not collated

Copying

39

1 Load paper.

2 Load an original document facedown on the scanner glass.

3 From the control panel, press or repeatedly until Copy is highlighted.

4 Press or to select the number of copies.

The number of copies is automatically set to 1.

5 Press .

6 Press repeatedly until Collate is highlighted.

7 Press or to choose On.

8 Press to save the image of the page to the printer memory.

9 When asked if you want to copy another page, press to choose Yes.

10 Load the second page of the original document facedown on the scanner glass, and then press .

11 Repeat step 9 and step 10 until:

• All the pages you want to copy have been saved to the printer memory. (Proceed to step 12.)

• The memory has run out of space.

The printer automatically prints the copied pages. The last page copied is printed first.

12 Press to print the last page copied first.

Related topics:

• “Making a copy” on page 37

• “Collating copies using the computer” on page 23

• “Using the control panel” on page 113

Repeating an image on one page

You can print the same image multiple times on one sheet of paper. This option is helpful in creating labels, decals,
flyers, handouts, and so on.

1 Load paper.

2 Load an original document facedown on the scanner glass.

3 From the control panel, press or repeatedly until Copy is highlighted.

4 Press or to select the number of copies.

The number of copies is automatically set to 1.

5 Press .

6 Press repeatedly until Layout is highlighted.

7 Press or to choose the number of times an image is repeated on a page: once, four times, nine times, or

16 times.

8 Press to preview the output.

9 Press to adjust the settings.

Copying

40

10 Repeat step 8 and step 9 as needed.

11 Press to save your settings temporarily.

12 Press .

Related topics:

• “Loading paper” on page 18

• “Loading original documents on the scanner glass” on page 34

Enlarging or reducing an image

1 Load paper.

2 Load an original document facedown on the scanner glass.

3 From the control panel, press or repeatedly until Copy is highlighted.

4 Press or to select the number of copies.

The number of copies is automatically set to 1.

5 Press .

6 Press repeatedly until Resize is highlighted.

7 Press or to choose among the following options: 50 percent, 100 percent, 200 percent, Custom, Fit to

Page, 2x2 Poster, 3x3 Poster, 4x4 Poster, or Borderless.

8 Press to preview the output.

9 Press to adjust the settings.

10 Repeat step 8 to step 9 as needed.

11 Press to save your settings temporarily.

12 Press .

Related topics:

• “Loading original documents on the scanner glass” on page 34

• “Using the control panel” on page 113

Copying on both sides of the paper (duplexing)

The printer has a built-in duplex unit that lets you print on both sides of the paper without having to flip the paper
manually. This is useful when printing long documents that need to be compiled.

Notes:

• Use only plain paper in Letter or A4-size. Do not make duplex copies on envelopes, card stock, or photo paper.

• You cannot print duplex through the PictBridge port.

1 Load paper.

2 Load an original document facedown on the scanner glass.

3 From the control panel, press .

The light on the duplex button comes on.

Copying

41

4 From the control panel, press or repeatedly until Copy is highlighted.

5 Press or to select the number of copies.

The number of copies is automatically set to 1.

6 Press .

7 Adjust the copy settings.

Note: If you are copying a two-sided original document, set the menu item 2-Sided Original to On.

8 Press to save your settings temporarily.

9 Press .

The printer scans the first page of the original document.

10 When asked if you want to copy another page, press to choose Yes.

11 Load the second page of the original document facedown on the scanner glass, and then press .

The printer scans the second page of the original document.
The printer then prints the first page of the copy, pulls the paper inward, and prints the second page of the copy.
Warning: Do not touch the paper while the printer is actively printing.

Copying multiple pages on one sheet (N-Up)

1 Load paper.

2 Load an original document facedown on the scanner glass.

3 From the control panel, press or repeatedly until Copy is highlighted.

4 Press .

5 Press or repeatedly until N-up is highlighted.

6 Press or to choose the number of pages to copy on a single sheet of paper. You can copy one page, two

pages, or four pages on a sheet.

7 Press .

Notes:

• If you choose to copy two or four pages on a sheet, the printer saves the image of the first page of the original

document to the printer memory. Proceed to step 8.

• If you choose to copy one page on a sheet, the printer prints the copy automatically.

8 When asked if you want to copy another page, press to choose Yes.

9 Load the second page of the original document facedown on the scanner glass, and then press .

10 Repeat step 8 and step 9 until all the pages you want to copy have been saved to the printer memory.

The printer prints the copy automatically.

Copying

42

Canceling a copy job

1 Press .

Scanning stops and the scanner bar returns to its home position.

2 Press to turn off the printer.

Related topics:

• “Using the control panel” on page 113

Changing the default copy settings

1 From the control panel, press or repeatedly until Copy is highlighted.

2 Press .

3 Press repeatedly until Change Default Settings is selected.

4 Press .

From here You can

Color Choose to copy in color and black and white.

Quality Adjust the quality of a copy. You can choose among the following

options: Normal, Photo, Auto, or Draft.

Content Type Specify the type of document being copied: Text and Graphics, Photo,

Text Only, or Line Drawing.

2-Sided Original Specify whether the original document is two-sided.

Paper Handling Specify the size and type of the paper loaded.

5 Use the control panel buttons to navigate the menu items and make your choices.

6 Press to save your settings.

Copying

43

Scanning

Getting started

Loading original documents on the scanner glass

You can scan and then print photos, text documents, magazine articles, newspapers, and other publications. You
can scan a document for faxing.

Note: The maximum scan area for the scanner glass is 216 x 297 mm (8.5 x 11.7 in.).

1 Open the top cover.

2 Place the original document or item facedown on the scanner glass in the lower right corner.

Note: Photos should be loaded as shown.

Scanning

44

3 Close the top cover to avoid dark edges on the scanned image.

Loading original documents into the Automatic Document Feeder

You can load up to 25 sheets of an original document into the Automatic Document Feeder tray for scanning, copying,
and faxing. You can load A4, letter, or legal size paper into the Automatic Document Feeder.

1 Load an original document text side up into the Automatic Document Feeder tray.

Note: Do not load postcards, photos, small items, or thin media (such as magazine clippings) into the Automatic

Document Feeder. Place these items on the scanner glass.

2 Adjust the paper guide on the Automatic Document Feeder tray against the edges of the paper.

Scanning

45

Automatic Document Feeder paper capacity

Load up to Make sure

25 sheets of:

• Letter paper

• A4 paper

• Legal-size paper

25 sheets of:

• Custom paper

• Pre-punched paper

• Reinforced edge copier paper

• Preprinted forms

• Letterhead paper

• The document is loaded text side up.

• The paper guide is against the edge of the paper.

• The document is loaded text side up.

• The paper guide is against the edge of the paper.

• The paper size fits within these dimensions:

Width:

– 210.0 mm–215.9 mm
– 8.27 in.–8.5 in.

Length:

– 279.4 mm–355.6 mm
– 11.0 in.–14.0 in.

• You allow preprinted media to dry thoroughly before loading

into the Automatic Document Feeder tray.

• You do not use media printed with metallic ink particles.

• You avoid embossed designs.

Learning about the All-In-One Center scan options

Choosing where to send scanned images

1 From the Finder desktop, double-click the Lexmark 7500 Series folder.

2 Double-click the Lexmark 7500 Series Center icon.

3 From the “Send scanned image to” pop-up menu, choose the scan destination.

• File—Saves the scanned image as a file to open later.

• Clipboard—Saves the scanned image to the Clipboard so you can paste it into another document. Large

scans may not fit the Clipboard.
Note: Scanning at a high resolution to the Clipboard uses a large amount of system memory and drastically

affects system performance.

• An application—Opens the scanned image in the specified application.

Related topics:

• “Saving a scanned image” on page 57

• “Using the All-In-One Center” on page 138

Editing the Customize list

The list of applications in the Customize list is generated when you install the All-In-One software. You can expand
this list to a maximum of 50 applications. You can add, remove, or modify an application in the Customize list.

1 From the Finder desktop, double-click the Lexmark 7500 Series folder.

2 Double-click the Lexmark 7500 Series Center icon.

Scanning

46

3 From the “Send scanned image to” pop-up menu, scroll down to the bottom of the list, and choose Customize

list. The Customize list dialog appears, showing all available applications.

To add an application to the list:

1 Click +.

2 Click Browse to navigate through the list of applications available on the computer. Click the application that

you want to add to the Available Applications list.

3 Click OK.

4 From the File Type pop-up menu, choose the type of file you want to send to your chosen application.

5 Edit the display name if desired. This is the name that will appear in the “Send scanned image to” pop-up menu.

6 Click OK.

To remove an application from the list:

1 From the list of applications, choose the application you want to remove.

2 Click -.

3 If you are sure, click OK when prompted. Otherwise, click Cancel.

To modify an application in the list:

1 From the list of applications, choose the application you want to modify.

2 Click Edit.

3 Edit the name to be displayed in the “Send scanned image to” pop-up menu.

• Click Browse to choose a new path to the application.

• From the File Type pop-up menu, choose the type of file you want to send to this application. You can choose

only one type of file.

• Click OK.

Related topics:

• “Selecting the All-In-One Center Preferences setting” on page 51

Adjusting color settings when scanning

You can manually adjust the color settings for optimum color output.

1 From the Finder desktop, double-click the Lexmark 7500 Series folder.

2 Double-click the Lexmark 7500 Series Center icon.

3 From the All-In-One Center, click Preview/Edit to open the Scan dialog.

4 From the Scan dialog, click to open the Scan Settings drawer.

5 From the Settings tab:

• Select a preset scan setting corresponding to your document.

• If you are not satisfied with a preset setting, customize the scan settings by adjusting color depth and

resolution, and choosing a descreening option if you need to remove wavy patterns from images scanned
from magazines or newspapers.

• Reduce background noise, if necessary. Select Reduce Background Noise, and move the slider to adjust

the level of noise reduction.

Scanning

47

6 From the Adjustments tab:

• Adjust the brightness, contrast, and gamma (color correction curve). Move the sliders to adjust the levels.

• Sharpen the image. Move the slider to adjust sharpness of your image.

• Invert colors. Select Invert Colors to reverse the colors of your image. The effect is similar to that of a film

negative.

Related topics:

• “Customizing scan settings from the Scan dialog” on page 48

• “Adjusting the brightness of an image” on page 50

Customizing scan settings from the Scan dialog

You can adjust the scan settings and do creative scanning jobs on the Scan dialog.

1 From the Finder desktop, double-click the Lexmark 7500 Series folder.

2 Double-click the Lexmark 7500 Series Center icon.

3 Click Preview/Edit to open the Scan dialog.

4 Click to open the Scan Settings drawer and change the settings as needed.

Scanning

48

The Scan dialog has three main sections: the Settings tab, the Adjustments tab, and the Preview area.

From here Go to To

Settings tab Scan Settings Select a preset scan setting according to the color and

document type of your scan.
Note: Select Custom Settings to customize the scan setting

manually instead of using a preset scan setting.

Reduce Background Noise Remove smudges and light background shading in color

documents.

Adjustments tab Brightness Adjust the lightness and darkness of the scanned image.

Contrast Adjust the tone of the image as it is set off against a light or

dark background.

Gamma Increase or decrease the color correction curve. Enabling

gamma lets you adjust the amount of ink on the page.

Blur/Sharpen Adjust the level of sharpness of the scanned image.

Rotate Image Rotates the image 90 degrees clockwise per click.

Invert Colors Reverse the colors of the image by inverting the RGB data.

The effect created is similar to that of a film negative.

Mirror Produce a mirror image of the document or image.

Defaults Reset the Adjustment controls to the factory default settings.

Preview area See a preview of the image. Some settings in the dialog are

interactive, so you can readily view the changes on the

re-scans the

Auto-crop sensitivity Select or clear Auto-crop sensitivity to activate or deactivate

Width, height, and file size
display

These buttons are at the top of the Preview area:

Click To

Show or hide the Scan Settings drawer.

Refresh the image in the Preview area.

Start scanning.

image as you adjust the settings. Clicking
original document and shows the recent changes in the
Preview area.

auto-cropping. Adjust the slider to adjust cropping
sensitivity.

See the dimension of the scanned image. Select your
preferred unit of measurement from the pop-up menu.

Related topics:

• “Using the All-In-One Center” on page 138

Scanning

49

Cropping photos using the software

You can use the Auto-crop feature to highlight certain focal points or to show only a specific portion of an image.

1 From the Finder desktop, double-click the Lexmark 7500 Series folder.

2 Double-click the Lexmark 7500 Series Center icon.

3 From the All-in-One Center dialog, click Preview/Edit.

4 Select Auto-crop sensitivity.

Note: Selecting Auto-crop sensitivity automatically selects the area to be scanned.

5 If you are satisfied with the cropped image, click .

If you are not satisfied with the cropped image, make adjustments.

a Use any of these methods to make adjustments:

• Move the slider.

Note: The slider adjusts the file size, width, and height of the image. If the dashed border seems to

disappear, the crop area is set beyond the size of the image.

• Click and drag the nodes to expand or minimize the crop area.

• Click and drag the crop area to a part of the image you want copied.

Note: These actions will deactivate Auto-crop sensitivity.

b Click to preview the image.

c Click to scan the image.

Related topics:

• “Using the All-In-One Center” on page 138

Adjusting the brightness of an image

1 From the Finder desktop, double-click the Lexmark 7500 Series folder.

2 Double-click the Lexmark 7500 Series Center icon.

3 From the All-In-One Center, click Preview/Edit to open the Scan dialog.

4 Click to open the Scan Settings drawer.

5 Select the Adjustments tab.

6 From the Brightness area, move the slider to lighten or darken the image.

Related topics:

• “Customizing scan settings from the Scan dialog” on page 48

• “Adjusting color settings when scanning” on page 47

Sharpening an image

1 From the Finder desktop, double-click the Lexmark 7500 Series folder.

2 Double-click the Lexmark 7500 Series Center icon.

3 Click Preview/Edit to open the Scan dialog.

4 From the Scan dialog, click to open the Scan Settings drawer.

Scanning

50

5 Click the Adjustments tab.

6 From the Blur/Sharpen area, move the slider to adjust the level of sharpness of the scanned image.

Related topics:

• “Customizing scan settings from the Scan dialog” on page 48

• “Enhancing photo print quality using the software” on page 105

Selecting the All-In-One Center Preferences setting

When scanning from the control panel, you have two options:

• You can indicate that you want the Scan dialog to open on the computer screen when you press on the control

panel. With this option, you can preview the scanned document, and then adjust the scan settings using the
All-In-One Center. For more information, see “Using the All-In-One Center” on page 138.

• You can indicate that you want to skip the Scan dialog, and send the scanned document straight to your selected

application.

To modify the Preferences setting:

1 From the Finder desktop, double-click the Lexmark 7500 Series folder.

2 Double-click the Lexmark 7500 Series Center icon.

3 From the menu bar, click Lexmark All-In-One Center.

4 Choose Preferences.

5 Select or unselect Show preview when Scan button pressed on the printer to indicate your preferred

scanning option.

• If you select Show preview when Scan button pressed on the printer, the Scan dialog opens on the

computer screen when you press

on the control panel.

• If you unselect it, the scanned document is sent straight to your selected application when you press on

the control panel.

Note: By default, Show preview when Scan button pressed on the printer is selected.

6 Click OK to close the Preferences dialog with your scan settings applied and go back to the scan job, or you

can click the Customize list icon to edit the Available Applications list.

Click

to go to the Help Center for more information.

Related topics:

• “Editing the Customize list” on page 46

• “Performing scanning and related tasks” on page 52

Resetting All-In-One software settings to defaults

1 From the Finder desktop, double-click the Lexmark 7500 Series folder.

2 Double-click the Lexmark 7500 Series Center icon.

3 Click Defaults.

Related topics:

• “Using the All-In-One Center” on page 138

• “Customizing scan settings from the Scan dialog” on page 48

Scanning

51

Performing scanning and related tasks

Scanning a document

1 Make sure the printer is connected to a computer, and both the printer and the computer are on.

2 Load an original document facedown on the scanner glass.

3 From the control panel, press or until Scan is highlighted.

4 Press .

5 If your printer is connected to more than one computer:

a Press or repeatedly until the computer to which you want to scan is highlighted.

b Press .

If you set a PIN during network setup and are being asked for it:

1 Enter the PIN using the and to select a digit location and the and to select a value for that

digit.

2 Press .

6 Wait until the printer has finished downloading the scan applications list.

7 Make your selections using the control panel buttons.

8 Press .

Related topics:

• “Loading original documents on the scanner glass” on page 34

• “Using the control panel” on page 113

• “Understanding the parts of the printer” on page 109

Making a color or black-and-white scan

1 Make sure the printer is connected to a computer, and both the printer and the computer are on.

2 Load an original document facedown on the scanner glass.

3 From the control panel, press or until Scan is highlighted.

4 Press .

5 If your printer is connected to more than one computer:

a Press or repeatedly until the computer to which you want to scan is highlighted.

b Press .

If you set a PIN during network setup and are being asked for it:

1 Enter the PIN using the and to select a digit location and the and to select a value for that

digit.

2 Press .

6 Wait until the printer has finished downloading the scan applications list.

7 Press repeatedly until Color is highlighted.

8 Press or to choose Color or Black & White.

Scanning

52

9 Press to preview the copy.

10 Press to continue adjusting the settings.

11 Repeat step 9 to step 10 as needed.

12 Press .

13 Follow the instructions on your computer screen.

Related topics:

• “Loading original documents on the scanner glass” on page 34

• “Using the control panel” on page 113

Scanning multiple pages using the scanner glass

1 Load an original document facedown on the scanner glass.

2 From the Finder desktop, double-click the Lexmark 7500 Series folder.

3 Double-click the Lexmark 7500 Series Center icon.

4 Select Prompt for multiple pages.

5 Click Scan.

6 In the Save dialog, enter a file name for your scan job.

7 From the Where pop-up menu, choose a destination for the scanned items.

8 From the “Format for” pop-up menu, choose a file type.

9 Click Save.

10 When prompted, place the next item on the scanner glass, and then click Scan on the dialog. Continue this for

every page you want to scan.

11 Click Done when you are finished scanning all items.

Notes:

• You can also select Prompt to name each page if you want to save each scanned item under a different file

name. Otherwise, scanned items will be given the file name you specified and numbered accordingly.

• When a scan job is saved as a PDF, the Save dialog will only prompt once. All scanned pages are saved to only

one file since PDF supports multiple-page scanning.

Scanning

53

Related topics:

• “Loading original documents on the scanner glass” on page 34

Scanning a text-only document

1 Make sure the printer is connected to a computer, and both the printer and the computer are on.

2 Load an original document facedown on the scanner glass.

3 From the Finder desktop, double-click the Lexmark 7500 Series folder.

4 Double-click the Lexmark 7500 Series Center icon.

5 From the “What is being scanned?” menu, choose Black Text.

6 Adjust the settings as needed.

7 Click Scan.

Related topics:

• “Loading original documents on the scanner glass” on page 34

Scanning a text and graphics document

1 Make sure the printer is connected to a computer, and both the printer and the computer are on.

2 Load an original document facedown on the scanner glass.

3 From the Finder desktop, double-click the Lexmark 7500 Series folder.

4 Double-click the Lexmark 7500 Series Center icon.

5 From the “What is being scanned?” menu, choose Mixed Graphics and Text.

6 Adjust the settings as needed.

7 Click Scan.

Related topics:

• “Loading original documents on the scanner glass” on page 34

Scanning an item for Web page viewing

1 Make sure the printer is connected to a computer, and both the printer and the computer are on.

2 Load an original document facedown on the scanner glass.

3 From the Finder desktop, double-click the Lexmark 7500 Series folder.

4 Double-click the Lexmark 7500 Series Center icon.

5 From the “How will the scanned image be used?” pop-up menu, choose To be viewed on monitor/web

page.

6 Adjust the settings as needed.

7 Click Scan.

Related topics:

• “Loading original documents on the scanner glass” on page 34

Scanning

54

Scanning images for editing

1 Make sure the printer is connected to a computer, and both the printer and the computer are on.

2 Load an original image facedown on the scanner glass.

3 From the Finder desktop, double-click the Lexmark 7500 Series folder.

4 Double-click the Lexmark 7500 Series Center icon.

5 From the “What is being scanned?” menu, choose Photo or Magazine or Newspaper.

6 From the “How will the scanned image be used?” pop-up menu, choose To be printed or To be viewed on

monitor/Web page.

7 From the “Send scanned image to” pop-up menu, choose a destination folder or application for your scanned

photo.

8 Select Prompt for multiple pages if you have several photos to scan.

9 Click Preview/Edit to open the Scan dialog and adjust settings.

From the Settings tab, you can select a preset scan setting, descreen magazine or newspaper scans, and reduce
background noise.

From the Adjustments tab, you can customize the settings as needed.

10 Crop photos, if needed. For more information, see “Cropping photos using the software” on page 50.

11 Click .

Related topics:

• “Loading original documents on the scanner glass” on page 34

Scanning a portion of an image

You can scan certain portions of an image or a document using the cropping function of the Scan dialog. This option
is good for scanning logos, parts of a magazine page, or sections of a photo.

1 Make sure the printer is connected to a computer, and both the printer and the computer are on.

2 Load an original document or image facedown on the scanner glass.

3 From the Finder desktop, double-click the Lexmark 7500 Series folder.

4 Double-click the Lexmark 7500 Series Center icon.

5 Click Preview/Edit.

6 Click inside the document or image in the preview area.

7 Drag the nodes on the crop area to select the part of the image that you want to scan.

Note: Drag the nodes on the dashed border to expand or minimize the crop area.

8 Click .

9 Click . Only the designated cropped area is saved or sent to an application.

Related topics:

• “Loading original documents on the scanner glass” on page 34

Scanning

55

Scanning clear images from magazines or newspapers

Descreening helps to remove wavy patterns from images scanned from magazines or newspapers.

1 Make sure the printer is connected to a computer, and both the printer and the computer are on.

2 Load an original document facedown on the scanner glass in the lower right corner.

3 From the Finder desktop, double-click the Lexmark 7500 Series folder.

4 Double-click the Lexmark 7500 Series Center icon.

5 From the “What is being scanned?” menu, select Magazine or Newspaper.

6 Click Preview/Edit.

7 Click to open the Scan Settings drawer.

8 From the Descreen pop-up menu on the Settings tab, choose Magazine or Newspaper.

9 Click .

Related topics:

• “Loading original documents on the scanner glass” on page 34

Scanning text for editing

Use the Optical Character Recognition (OCR) software feature to scan a document and produce text you can edit
with a word-processing application.

Note: This function will work only if you have installed ABBYY FineReader 5 SprintX.

1 Load an original document facedown on the scanner glass.

2 From the Finder desktop, double-click the Lexmark 7500 Series folder.

3 Double-click the Lexmark 7500 Series Center icon.

4 From the “What is being scanned?” menu, select a document type other than Photo.

5 From the “How will the scanned image be used?” pop-up menu, choose To be edited (OCR).

6 From the “Send scanned image to” menu, choose a word-processing application to use for editing.

7 Click Scan.

8 Open the scanned document from the word-processing application for previewing and editing.

9 Edit and save the document.

Related topics:

• “Loading original documents on the scanner glass” on page 34

Scanning documents or images for e-mailing

When you want to scan a new item and send it through e-mail:

1 Load an original document facedown on the scanner glass.

2 From the Finder desktop, double-click the Lexmark 7500 Series folder.

3 Double-click the Lexmark 7500 Series Center icon.

Scanning

56

4 From the “What is being scanned?” menu, select a document type other than Photo.

5 From the “How will the scanned image be used?” menu, choose To be viewed on monitor/web page.

6 From the “Send scanned image to” menu, choose an application.

7 Click Scan.

8 Retrieve the scanned image from the application, and send it through e-mail as an attachment.

Related topics:

• “Loading original documents on the scanner glass” on page 34

Saving a scanned image

1 Make sure the printer is connected to a computer, and both the printer and the computer are on.

2 Load an original document facedown on the scanner glass.

3 From the Finder desktop, double-click the Lexmark 7500 Series folder.

4 Double-click the Lexmark 7500 Series Center icon.

5 From the “Send scanned images to” pop-up menu, choose the application where you want to save the scanned

image.

6 Adjust the settings as needed.

7 Click Scan.

The scanned image opens in the specified application.

8 From the software application, click File  Save As.

9 Enter the file name, format, and location where you want the scanned image to be saved.

10 Click Save.

Related topics:

• “Loading original documents on the scanner glass” on page 34

Canceling a scan job

To cancel a scan using the control panel:

1 Press .

Scanning stops and the scanner bar returns to its home position.

2 Press to turn off the printer.

To cancel a scan using the software:

1 From the Finder desktop, double-click the Lexmark 7500 Series folder.

2 Double-click the Lexmark 7500 Series Center icon.

3 From the Progress dialog, click Cancel.

Related topics:

• “Using the control panel” on page 113

Scanning

57

Changing the default scan settings

1 From the control panel, press or repeatedly until Scan is highlighted.

2 Press .

3 If your printer is connected to more than one computer:

a Press or repeatedly until the computer to which you want to scan is highlighted.

b Press .

If you set a PIN during network setup and are being asked for it:

1 Enter the PIN using the and to select a digit location and the and to select a value for that

digit.

2 Press .

4 Wait until the printer has finished downloading the scan applications list.

5 Press repeatedly until Change Default Settings is highlighted.

6 Press .

From here You can

Color Choose to scan your document in color or black and white.

Quality Choose a scan quality: Automatic, 150 dots per inch (dpi), 300 dpi, or 600 dpi.

Original Size Set the size of the original document: Auto Detect, L, 2L, A6, A5, B5, A4, Wallet,

3 in x 5 in, 4 in x 6 in, 4 in x 8 in, 5 in x 7 in, 8 in x 10 in, or letter.

7 Use the control panel buttons to navigate the menu items and make your choices.

8 Press to save your settings.

Scanning over a network

Setting a network printer to scan

Assigning a name to your computer

You can assign a name to your computer when you install the printer software for the first time. Choose this name
when you scan an item on the network printer and want to send the scanned image to your computer. The name of
the computer can be changed, as needed.

1 From the Finder desktop, double-click the Lexmark 7500 Series folder.

2 Double-click the Lexmark 7500 Series Center icon.

3 From the menu, choose Advanced  Network Scan Settings.

4 In the Computer Name field, type in the name of your computer.

5 Click Save.

Related topics:

•

“Setting a “scan to network” PIN” on page 59

Scanning

58

Setting a “scan to network” PIN

Assigning a “scan to network” PIN lets you control the sending of scanned items to your computer. You can assign
a “scan to network” PIN when you install the printer software for the first time. You can also change it as needed.

1 From the Finder desktop, double-click the Lexmark 7500 Series folder.

2 Double-click the Lexmark 7500 Series Center icon.

3 From the menu, choose Advanced  Network Scan Settings.

4 Select the check box to specify a PIN.

5 Type in a four-digit PIN. Use a combination of numbers from 1-9.

6 Click Save.

Related topics:

•

“Assigning a name to your computer” on page 58

Selecting printers that can scan to your computer

1 From the Finder desktop, double-click the Lexmark 7500 Series folder.

2 Double-click the Lexmark 7500 Series Center icon.

3 From the menu, choose Advanced Network Scan Access.

The Scan Network Access dialog appears.

4 Press + to search for printers connected to the local subnet.

The Network All-in-One Selection dialog appears.

5 In the search field, type the IP address of the print server. Consult your network administrator for help finding

the IP address of the print server.
If you want to narrow your search to a certain subnet, type the IP address of the print server and the subnet

mask in CIDR notation.

6 On your keyboard, press return.

7 From the Network All-in-One Selection dialog, select the printer you want to scan to your computer.

8 Click Select.

9 Repeat step 4 to step 8 for every printer that you want to scan to your computer.

10 When finished, click Done.

Note: To remove a printer from the list, select the printer, and then click —.

Scanning to a computer over a network using the control panel

1 Make sure:

• The printer is connected to a network through a print server or through the wireless network connection.

• The printer, the print server (if used), and the computer receiving the scan are all turned on.

• The printer is configured to scan over a network.

2 Load an original document facedown on the scanner glass.

3 From the control panel, press or repeatedly until Scan is highlighted.

Scanning

59

4 Press .

5 Press or repeatedly until the computer to which you want to scan is highlighted.

6 Press .

If you set a PIN during network setup and are being asked for it:

a Enter the PIN using the and to select a digit location and the and to select a value for that digit.

b Press .

7 Wait until the printer has finished downloading the scan applications list.

8 Make your selections using the control panel buttons.

9 Press .

Related topics:

• “Setting a network printer to scan” on page 58

• “Loading original documents on the scanner glass” on page 34

Scanning

60

Faxing

Getting started

Choosing a fax connection

You can connect the printer with equipment such as a telephone, an answering machine, or a computer modem. If
problems occur, see the topics listed under “Setup troubleshooting” in the “Troubleshooting” chapter.

Notes:

• The printer is an analog device that works best when directly connected to the wall jack.

• Other devices (such as a telephone or answering machine) can be successfully attached to pass through the

printer, as described in the setup steps.

• If you want a digital connection such as ISDN, DSL, or ADSL, a third-party device (such as a DSL filter) is

required. For more information, see “Using a digital phone service” on page 70.

You do not need to attach the printer to a computer, but you do need to connect it to a telephone line to send and
receive faxes.

You can connect the printer to other equipment. See the following table to determine the best way to set up the
printer.

Equipment Benefits See this section

• The printer

• A telephone

cord

• A telephone wall

jack

• The printer

• An answering

machine

• Two telephone

cords

• A telephone wall

jack

• The printer

• A computer

modem

• Two telephone

cords

• A telephone wall

jack

• Use the fax line as a normal

telephone line.

• Send and receive faxes

without using a computer.

• Use the fax line as a normal

telephone line.

• Send and receive faxes

without using a computer.

• Receive incoming voice

messages.

• Use the fax line as a normal

telephone line.

• Send and receive faxes

without using a computer.

• Send faxes using the

computer.

For more information, see “Connecting directly to a
telephone wall jack” on page 65.

For more information, see “Connecting to an answering
machine” on page 68.

For more information, see “Connecting to a computer with
a modem” on page 69.

Related topics:

• “Using a digital phone service” on page 70

• “Connecting directly to a telephone wall jack” on page 65

Faxing

61

• “Connecting to an answering machine” on page 68

• “Connecting to a computer with a modem” on page 69

Setting the printer to use the Fax feature without a computer

You use this method to set up your printer for faxing when the printer is not connected to a computer or to a network.
This method is used when your printer functions as a standalone fax machine.

1 Turn the printer on.

2 Press or repeatedly until Fax is highlighted.

3 Press .

The Fax Mode menu appears.

4 Press or repeatedly until the Fax Setup submenu is highlighted.

5 Press .

6 Press or repeatedly until the Dialing and Sending submenu is highlighted.

7 Press .

The Dialing and Sending menu appears.

8 In the Your Fax Number field, enter your fax number using the keypad.

9 Press or repeatedly until you reach Your Fax Name.

10 Use the keypad to enter your name. Spell out a name using the numbers associated with each letter as you

would on a telephone or cell phone.

11 Press to save the information and exit.

Using an RJ11 adapter

Country/region

• United Kingdom

• Ireland

• Finland

• Norway

• Denmark

To connect your printer to an answering machine or other telecommunications equipment, use the telephone line
adapter included in the box with the printer.

1 Connect one end of the telephone cord into the Line port of the printer.

• Italy

• Sweden

• Netherlands

• France

• Portugal

Faxing

62

2 Connect the adapter to the telephone line that came with the printer.

Note: The UK adapter is shown. Your adapter may look different, but it will fit the telephone outlet used in your

location.

3 Connect the telephone line of your chosen telecommunications equipment to the left outlet of the adapter.

If your telecommunications equipment uses a US-style (RJ11) telephone line, follow these steps to connect the
equipment:

1 Remove the plug from the EXT port on the back of the printer.

Note: Once this plug is removed, any country- or region-specific equipment you connect to the printer by the

adapter, as shown, will not function properly.

2 Connect your telecommunications equipment directly to the EXT port on the back of the printer.

Faxing

63

Warning: Do not touch cables or the printer in the area shown while actively sending or receiving a fax.

Country/region

• Saudi Arabia

• United Arab Emirates

• Egypt

• Bulgaria

• Czech Republic

• Belgium

• Australia

• South Africa

• Israel

• Hungary

• Poland

• Romania

• Russia

• Slovenia

• Spain

• Turkey

• Greece

To connect an answering machine or other telecommunications equipment to the printer:

1 Remove the plug from the back of the printer.

Note: Once this plug is removed, any country- or region-specific equipment that you connect to the printer by

the adapter, as shown, will not function properly.

2 Connect your telecommunications equipment directly to the EXT port on the back of the printer.

Warning: Do not touch cables or the printer in the area shown while actively sending or receiving a fax.

Faxing

64

Country/region

• Germany

• Austria

• Switzerland

There is a plug installed in the EXT port of the printer. This plug is necessary for the proper functioning of the printer.

Note: Do not remove the plug. If you remove it, other telecommunications devices in your home (such as telephones
or answering machines) may not work.

Connecting directly to a telephone wall jack

Connect the printer directly to a telephone wall jack to make copies or to send and receive faxes without using a
computer.

1 Make sure you have a telephone cord and a telephone wall jack.

2 Connect one end of the telephone cord into the LINE port of the printer.

3 Connect the other end of the telephone cord into an active telephone wall jack.

Connecting directly to a telephone wall jack in Germany

Connect the printer directly to a telephone wall jack to send and receive faxes without using a computer.

Faxing

65

Note: In Germany (and some other countries), the printer ships with a special RJ-11 plug in the EXT port. Do not

remove the RJ-11 plug. It is required for both the fax and telephone to work properly.

1 Make sure you have a telephone cord (provided with the product) and a telephone wall jack.

2 Connect one end of the telephone cord into the LINE port of the printer.

3 Connect the other end of the telephone cord into the N slot of an active telephone wall jack.

4 If you would like to use the same line for both fax and telephone communication, connect a second telephone

line (not provided) between the telephone and the F slot of an active telephone wall jack.

5 If you would like to use the same line for recording messages on your answering machine, connect a second

telephone line (not provided) between the answering machine and the other N slot of the telephone wall jack.

Faxing

66

Connecting to a telephone

Connect a telephone to the printer to use the fax line as a normal telephone line. Then set up the printer wherever
your telephone is located to make copies or to send and receive faxes without using a computer.

Note: Setup steps may vary depending on your country or region. For more information on connecting the printer
to telecommunications equipment, see the related topic, “Using an RJ11 adapter.”

1 Make sure you have the following:

• A telephone

• Two telephone cords

• A telephone wall jack

2 Connect one telephone cord to the LINE port of the printer, and then plug it into an active telephone wall jack.

3 Remove the protective plug from the EXT port of the printer.

Faxing

67

4 Connect the other telephone cord to a telephone, and then plug it into the EXT port of the printer.

Related topics:

• “Using an RJ11 adapter” on page 62

Connecting to an answering machine

Connect an answering machine to the printer to receive both incoming voice messages and faxes.

Note: Setup steps may vary depending on your country or region. For more information on connecting the printer
to telecommunications equipment, see the related topic, “Using an RJ11 adapter.”

1 Make sure you have the following:

• A telephone

• An answering machine

• Three telephone cords

• A telephone wall jack

2 Connect one telephone cord into the LINE port of the printer, and then plug it into an active telephone wall

jack.

Faxing

68

3 Remove the protective plug from the EXT port of the printer.

4 Connect a second telephone cord from the telephone to the answering machine.

5 Connect a third telephone cord from the answering machine to the EXT port of the printer.

Related topics:

• “Using an RJ11 adapter” on page 62

Connecting to a computer with a modem

Connect the printer to a computer with a modem to send faxes from the software application.

Note: Setup steps may vary depending on your country or region. For more information on connecting the printer
to telecommunications equipment, see the related topic, “Using an RJ11 adapter.”

1 Make sure you have the following:

• A telephone

• A computer with a modem

• Two telephone cords

• A telephone wall jack

Faxing

69

2 Connect a telephone cord into the LINE port of the printer, and then plug it into an active telephone wall jack.

3 Remove the protective plug from the EXT port of the printer.

4 Connect a second telephone cord from the computer modem to the EXT port of the printer.

Related topics:

• “Using an RJ11 adapter” on page 62

Using a digital phone service

The fax modem is an analog device. Certain devices can be connected to the printer so that digital telephone services
can be used.

• If you are using an ISDN telephone service, connect the printer to an analog telephone port (an R-interface port)

on an ISDN terminal adapter. For more information and to request an R-interface port, contact your ISDN
provider.

• If you are using DSL, connect to a DSL filter or router that will support analog use. For more information, contact

your DSL provider.

Faxing

70

• If you are using a PBX telephone service, make sure you are connecting to an analog connection on the PBX.

If none exists, consider installing an analog telephone line for the fax machine. For more information on faxing
when using a PBX telephone service, see the related topic, “Setting up to fax while behind a PBX.”

Related topics:

• “Setting up to fax while behind a PBX” on page 82

Loading paper

1 Make sure:

• You use paper designed for inkjet printers.

• If you are using photo, glossy, or heavyweight matte paper, you load it with the glossy or printable side facing

you. (If you are not sure which side is the printable side, see the instructions that came with the paper.)

• The paper is not used or damaged.

• If you are using specialty paper, you follow the instructions that came with it.

• You do not force paper into the printer.

2 Before loading paper the first time, slide the paper guides out toward the edges of the paper support. You can

load up to:

• 100 sheets of plain paper

• 25 sheets of heavyweight matte paper

• 25 sheets of photo paper

• 25 sheets of glossy paper

Note: Photos require more drying time. Remove each photo as it exits, and allow it to dry to avoid ink smudging.

3 Load the paper vertically in the center of the paper support, and adjust the paper guides to rest against the edges

of the paper.

Note: To avoid paper jams, make sure the paper does not buckle when you adjust the paper guides.

Related topics:

• “Using the automatic paper type sensor” on page 18

Loading original documents on the scanner glass

You can scan and then print photos, text documents, magazine articles, newspapers, and other publications. You
can scan a document for faxing.

Faxing

71

Note: The maximum scan area for the scanner glass is 216 x 297 mm (8.5 x 11.7 in.).

1 Open the top cover.

2 Place the original document or item facedown on the scanner glass in the lower right corner.

Note: Photos should be loaded as shown.

3 Close the top cover to avoid dark edges on the scanned image.

Faxing

72

Loading original documents into the Automatic Document Feeder

You can load up to 25 sheets of an original document into the Automatic Document Feeder tray for scanning, copying,
and faxing. You can load A4, letter, or legal size paper into the Automatic Document Feeder.

1 Load an original document text side up into the Automatic Document Feeder tray.

Note: Do not load postcards, photos, small items, or thin media (such as magazine clippings) into the Automatic

Document Feeder. Place these items on the scanner glass.

2 Adjust the paper guide on the Automatic Document Feeder tray against the edges of the paper.

Automatic Document Feeder paper capacity

Load up to Make sure

25 sheets of:

• Letter paper

• The document is loaded text side up.

• The paper guide is against the edge of the paper.

• A4 paper

• Legal-size paper

Faxing

73

Load up to Make sure

25 sheets of:

• Custom paper

• Pre-punched paper

• Reinforced edge copier paper

• Preprinted forms

• Letterhead paper

• The document is loaded text side up.

• The paper guide is against the edge of the paper.

• The paper size fits within these dimensions:

Width:

– 210.0 mm–215.9 mm
– 8.27 in.–8.5 in.

Length:

– 279.4 mm–355.6 mm
– 11.0 in.–14.0 in.

• You allow preprinted media to dry thoroughly before loading

into the Automatic Document Feeder tray.

• You do not use media printed with metallic ink particles.

• You avoid embossed designs.

Sending a fax

Entering a fax number

1 Make sure the printer is on and it is connected to a working phone line.

2 From the control panel, press or repeatedly until Fax is highlighted.

3 Press .

The Fax Mode menu appears.

4 Enter a fax number using:

Method How to

The text box Enter a fax number using the keypad.

Notes:

• You can include a calling card number as part of the fax number.

• A fax number can include up to 64 numbers, commas, periods, and/or

the symbols * or #.

• Press the Redial / Pause button to insert a three-second pause in a

number you are entering to wait for an outside line or get through an
automated answering system.

Name Search

a Press or repeatedly until Phone Book is highlighted.

b Press .

The Phone Book menu appears with Name Search highlighted.

c Press .
d Press or repeatedly until the name you want is highlighted.

e Press .

f Press to start the fax job.

Faxing

74

Method How to

Phone Number Search

Group Search

a Press or repeatedly until Phone Book is highlighted.

b Press .

The Phone Book menu appears with Name Search highlighted.

c Press or repeatedly until Phone Number Search is

highlighted.

d Press .
e Press or repeatedly until the phone number you want is

highlighted.

f Press .

g Press to start the fax job.

a Press or repeatedly until Phone Book is highlighted.

b Press .

The Phone Book menu appears with Name Search highlighted.

c Press or repeatedly until Group Search is highlighted.

d Press .
e Press or repeatedly until the group you want is highlighted.

f Press .

g Press to start the fax job.

On Hook Dial On Hook Dial is a manual dialing feature that lets you dial a telephone

number while listening to the call through a speaker on the printer. It is
useful when you must navigate through an automated answering system
or enter a calling card number before sending your fax.

Note: You cannot use On Hook Dial when you are using the Speed Dial,
Group Dial, or broadcast fax functions.

a Press or repeatedly until On Hook Dial is highlighted.

b Press .

You can now hear the dial tone of the telephone line.

c Press the keypad numbers to navigate through an automated

answering system.

d Enter a fax number using any of the methods listed in this table.

Note: Only one fax number can be entered for On Hook Dial.

e Press to start the fax job.

Note: If you want to send a fax to a group of numbers (broadcast fax), repeat step 4, using any combination of

the methods, until a maximum of 30 fax numbers have been entered. Once all fax numbers are entered,
press to start the fax job.

Related topics:

• “Using the Phone Book” on page 80

• “Setting up Speed Dial using the computer” on page 81

Faxing

75

Sending a fax using the control panel

1 Make sure the printer is on and is connected to a working phone line.

2 Load an original document faceup into the Automatic Document Feeder (ADF) or facedown on the scanner

glass.
Note: Do not load postcards, photos, small items, transparencies, photo paper, or thin media (such as magazine

clippings) into the Automatic Document Feeder (ADF). Place these items on the scanner glass.

3 From the control panel, press or repeatedly until Fax is highlighted.

4 Press .

The Fax Mode menu appears.

5 Enter a fax number. For more information on the methods you can use to enter a fax number, see the table that

begins with step 4 on page 74.

Notes:

• You can include a calling card number as part of the fax number.

• A fax number can include up to 64 numbers, commas, periods, and/or the symbols * or #.

6 Press to start the fax job.

Note: If you are scanning individual pages using the scanner glass, after each page is scanned, the message

Would you like to include another page in the fax? appears to prompt you either to scan another
page or to send the fax right away.

7 If you want to send a fax to a group of numbers (broadcast fax), enter the fax numbers using any combination

of the methods listed in the table that begins with step 4, until a maximum of 30 fax numbers have been entered.

Related topics:

• “Entering a fax number” on page 74

Sending a broadcast fax at a scheduled time

You can send a fax to a combination of up to 30 people or groups at a time you choose.

1 Make sure the printer is connected to a working phone line.

2 Load an original document faceup into the Automatic Document Feeder (ADF) or facedown on the scanner

glass.
Note: Do not load postcards, photos, small items, transparencies, photo paper, or thin media (such as magazine

clippings) into the Automatic Document Feeder. Place these items on the scanner glass.

3 From the control panel, press or repeatedly until Fax is highlighted.

4 Press .

The Fax Mode menu appears.

5 Enter a fax number. For more information on the methods you can use to enter a fax number, see the table that

begins with step 4 on page 74.

Notes:

• Group Dial is not supported with broadcast fax.

• You can include a calling card number as part of the fax number.

• A fax number can include up to 64 numbers, commas, periods, and/or the symbol: * or #.

Faxing

76

6 To send a fax to a group of numbers (broadcast fax), use any combination of the methods in step 4 on

page 74, until a maximum of 30 fax numbers have been entered.

7 Press or repeatedly until Delay Sending Fax is highlighted.

8 Press .

The Delay Sending Fax menu appears. The current time is shown.

9 Use the keypad to enter the hour you want to send the fax in the Time to Send Fax field. You can enter the

hour based on a 12-hour or 24-hour system.

10 Press once.

11 Enter the minute you want to send the fax in the Time to Send Fax field.

12 Press once.

13 Press keypad 1 for AM, keypad 2 for PM, or keypad 3 for 24 Hr.

Note: You can also press

or repeatedly to scroll through AM, PM, or 24 Hr.

14 Press .

Note: At the designated time, the fax numbers are dialed and the fax is sent to all of the designated fax numbers. If

the fax transmission is unsuccessful to any of the numbers on the broadcast list, the unsuccessful numbers will be
dialed again.

Related topics:

• “Entering a fax number” on page 74

Sending a fax while listening to a call (On Hook Dial)

The manual dialing feature lets you dial a telephone number while listening to the call through a speaker on the
printer. It is useful when you must navigate an automated answering system or enter a calling card number before
sending your fax.

1 Make sure the printer is on and connected to a working phone line.

2 From the control panel, press or repeatedly until Fax is highlighted.

3 Press .

The Fax Mode menu appears.

4 Press or repeatedly until On Hook Dial is highlighted.

5 Press .

You can now hear the dial tone of the telephone line.

6 Press the keypad numbers to navigate through an automated answering system.

7 Enter a fax number. For more information on the methods you can use to enter a fax number, see the table that

begins with step 4 on page 74.

Faxing

77

Notes:

• You can include a calling card number as part of the fax number.

• A fax number can include up to 64 numbers, commas, periods, and/or the symbols * or #.

• Only one fax number can be entered for On Hook Dial.

8 Press .

Related topics:

• “Entering a fax number” on page 74

Receiving a fax

Receiving a fax automatically

1 Make sure the printer is on and is connected to a working phone line.

2 Make sure that Auto Answer is on. For more information, see “Setting Auto Answer to On” on page 79.

Note: An indicator, resembling a telephone handset with the word FAX under it, is shown in the top left corner

of the display when Auto Answer is on.

3 Set the number of times the telephone rings before the printer automatically receives faxes. To set this, see

“Setting the number of rings before receiving a fax automatically” on page 83.

Receiving a fax with an answering machine

Note: You must set up the equipment as shown in the related topic, “Connecting to an answering machine” on
page 68.

To receive a fax with an answering machine connected to the printer:

1 Make sure that Auto Answer is on.

Note: An indicator, resembling a telephone handset with the word FAX under it, is shown in the top left corner

of the display when Auto Answer is on.

2 Make sure you have set the number of times the telephone rings before receiving a fax automatically. For more

information, see “Setting the number of rings before receiving a fax automatically” on page 83
When a telephone ring is detected, the answering machine picks up the call.

• If the printer detects a fax, it receives the fax and disconnects the answering machine.

• If the printer does not detect a fax, the answering machine receives the call.

3 Set the answering machine to answer incoming calls before the printer does.

For example, if you set the answering machine to answer calls after three rings, set the printer to answer calls
after five rings.

Related topics:

• “Setting Auto Answer to On” on page 79

• “Connecting to an answering machine” on page 68

• “Setting the number of rings before receiving a fax automatically” on page 83

Receiving a fax manually

1 Make sure the printer is on and is connected to a working phone line.

2 Make sure that Auto Answer is off.

Faxing

78

Note: An indicator, resembling a telephone handset with the word FAX under it, is shown in the top left corner

of the display when Auto Answer is on.
To disable auto answer:

a From the control panel, press or repeatedly until Fax is highlighted.

b Press .

The Fax Mode menu appears.

c Press or repeatedly until you reach Auto Answer.

d Press or repeatedly until Off appears.

e Press to save and exit.

3 To receive the fax, press .

or

4 Press * 9 * on the telephone after you answer it and hear fax tones.

5 Hang up the telephone. The printer receives the fax.

Receiving a two-sided fax

The printer has a built-in duplex unit that lets you print received faxes on both sides of the paper.

Note: For two-sided printing, use only plain paper in letter or A4-size.

1 From the control panel, press .

The

light comes on.

2 From the control panel, press or repeatedly until Fax is highlighted.

3 Press .

4 Press or repeatedly until Fax Setup is highlighted.

5 Press .

6 Press or repeatedly until Fax Printing is highlighted.

7 Press .

8 Press or repeatedly until 2-Sided Print is highlighted.

9 Press or repeatedly until Always is highlighted.

10 Press to save and exit.

Setting Auto Answer to On

1 From the control panel, press or repeatedly until Fax is highlighted.

2 Press .

The Fax Mode menu appears.

3 Press or repeatedly until you reach Auto Answer.

Faxing

79

4 Press or repeatedly until On appears.

5 Press to save and exit.

Using Caller ID

Caller ID is a service provided by some telephone companies that identifies the telephone number (and possibly the
name) of the person who is calling. If you subscribe to this service, it works with the printer. When you receive a fax,
the telephone number of the person who is sending you the fax appears on the display.

Note: Caller ID is available only in some countries and regions.
The printer supports two distinct Caller ID patterns: Pattern 1 (FSK) and Pattern 2 (DTMF). Depending on the country

or region you live in and the telecommunications company you subscribe to, you may need to switch the pattern to
display Caller ID information.

1 Make sure the printer is on and is connected to a working phone line.

2 From the control panel, press or repeatedly until Fax is highlighted.

3 Press .

4 Press or repeatedly until the Fax Setup submenu is highlighted.

5 Press .

6 Press or repeatedly until the Ringing and Answering submenu is highlighted.

7 Press .

8 Press or repeatedly until you reach the Caller ID Pattern menu item.

9 Press or repeatedly until the setting you want appears.

10 Press to save the setting and exit.

Customizing dial settings

Using the Phone Book

The Phone Book is a directory of Speed Dial entries (1–89) and Group Dial entries (90–99).
To access the Phone Book submenu:

1 From the control panel, press or repeatedly until Fax is highlighted.

2 Press .

The Fax Mode menu appears.

3 Press or repeatedly until Phone Book is highlighted.

4 Press .

The Phone Book menu appears.

Faxing

80

5 Press or repeatedly until you highlight one of the following as needed:

Use this To

Name Search View names previously added using Add Entry, and add names to a fax list.

Phone Number Search View phone numbers previously added using Add Entry, and add numbers to a fax

list.

Add Entry Add a name and a fax number. The printer automatically assigns a new entry a Speed

Dial number.
Note: Enter a name and a fax number in the provided fields using the keypad

numbers. You spell out a name using the numbers associated with each letter as you
do on a telephone or cell phone.

Group Search Search for a previously defined group, and add it to a fax list.

Add Group Create a group name, and select previously defined names to be added to the group.

Print List Print a list with the name, the fax number, and the Speed Dial number of each person.

Note: This is available when Phone Book entries exist.

6 Press to enter the menu item you highlighted, and follow the instructions on the display.

7 Press to exit and save any entries you made.

Note: For instructions on how to add Speed Dial or Group Dial entries to the Phone Book using the computer, see

“Setting up Speed Dial using the computer” on page 81.

Setting up Speed Dial using the computer

1 From the Finder desktop, double-click the Lexmark 7500 Series folder.

2 Double-click the 7500 Series Fax Setup Utility icon.

3 Select the Speed Dials tab.

4 Set your Speed Dial list.

To enter individual contacts:

a Select the Individuals tab.

b Double-click a line in the Contact Name column

c Type the name of the contact.

d Double-click the line beside the name of the contact (in the Fax Number column).

e Type the fax number of the contact.

To enter group contacts:

a Select the Groups tab.

b Double-click a line in the Group Name column.

c Type the name of the group.

d On the Group Members area, click + to enter the contact names and fax numbers of the contacts who belong

to the group.

Note: You can also add contacts from the Address Book to your Speed Dial list. For more information, see
“Adding contacts from the Address Book” on page 82.

Faxing

81

To delete an entry from the Speed Dial list, select it, and then click -.

5 Click Save Settings.

Adding contacts from the Address Book

1 From the Finder desktop, double-click the Lexmark 7500 Series folder.

2 Double-click the Fax Setup Utility icon.

3 Select the Speed Dials tab.

4 Click .

5 From the Address Book, click and drag the contact that you want to add to your printer's Speed Dial list.

Note: Only the fax numbers specified in the Address Book contact is reflected on the Speed Dial list. If there is

more than one fax number for a contact, the application automatically creates separate entries.

6 Click Save Settings.

Setting up a dialing prefix

You can add a prefix of up to eight characters to the beginning of each number dialed. Characters can include
numbers, commas, and/or the symbols * or #.

1 From the control panel, press or repeatedly until Fax is highlighted.

2 Press .

3 Press or repeatedly until the Fax Setup submenu is highlighted.

4 Press .

5 Press or repeatedly until the Dialing and Sending submenu is highlighted.

6 Press .

7 Press or repeatedly until you reach the Dial Prefix menu item.

8 Press or repeatedly until Create appears.

9 Press .

10 Enter the prefix to be dialed before each telephone number.

11 Press to save and exit.

Setting up to fax while behind a PBX

If the printer is being used in a business or office, it may be connected to a Private Branch Exchange (PBX) telephone
system. Ordinarily, when dialing a fax number, the printer waits to recognize the dial tone and then dials the fax
number. However, this method of dialing may not work if the PBX telephone system uses a dial tone that is not
recognizable to most fax machines. The “Dialing while behind a PBX” feature enables the printer to dial the fax
number without waiting to recognize the dial tone.

1 From the control panel, press or repeatedly until Fax is highlighted.

2 Press .

3 Press or repeatedly until the Fax Setup submenu is highlighted.

Faxing

82

4 Press .

5 Press or repeatedly until the Dialing and Sending submenu is highlighted.

6 Press .

7 Press or repeatedly until you reach the Dial Method menu item.

8 Press or repeatedly until Behind PBX (Dial Tone Detect Off) appears.

9 Press to save and exit.

Setting the distinctive ring

Distinctive ring is a service provided by some telephone companies that assigns multiple phone numbers to a single
telephone line. If you subscribe to this service, you can program your printer to have a distinctive ring pattern and
phone number for incoming faxes.

1 From the control panel, press or repeatedly until Fax is highlighted.

2 Press .

3 Press or repeatedly until the Fax Setup submenu is highlighted.

4 Press .

5 Press or repeatedly until the Ringing and Answering submenu is highlighted.

6 Press .

7 Press or repeatedly until you reach the Distinctive Ring menu item.

8 Press or repeatedly until the ring pattern you want appears.

9 Press to save and exit.

Setting the number of rings before receiving a fax automatically

1 Make sure that Auto Answer is on. For more information, see “Setting Auto Answer to On” on page 79.

Note: An indicator, resembling a telephone handset with the word FAX under it, is shown in the top left corner

of the display when Auto Answer is on.

2 From the control panel, press or repeatedly until Fax is highlighted.

3 Press .

4 Press or repeatedly until the Fax Setup submenu is highlighted.

5 Press .

6 Press or repeatedly until the Ringing and Answering submenu is highlighted.

7 Press .

8 Press or repeatedly until you reach the Pick-up On menu item.

9 Press or repeatedly until the setting you want appears.

10 Press to save and exit.

Faxing

83

When the number of rings you set is detected, the printer automatically receives the incoming fax.

Customizing fax information

Creating a fax cover page using the control panel

1 From the control panel, press or repeatedly until Fax is highlighted.

2 Press .

3 Press or repeatedly until the Edit Fax Settings submenu is highlighted.

4 Press .

5 Press or repeatedly until Cover Page is highlighted.

6 Press or repeatedly until Yes appears.

7 Press .

Wait for the fax Cover Page menu to appear. Use this menu to edit items for your fax cover page, such as your
From #, your name, your fax number, and the priority of the fax you plan to send.

8 Press or to choose a From #.

9 Press to edit other items for the cover page. Use the keypad to enter numbers or characters.

10 Press to save and exit when you finish creating the cover page.

Setting up a fax footer

1 From the control panel, press or repeatedly until Fax is highlighted.

2 Press .

3 Press or repeatedly until the Fax Setup submenu is highlighted.

4 Press .

5 Press or repeatedly until the Fax Printing submenu is highlighted.

6 Press .

7 Press or repeatedly until you reach the Fax Footer menu item.

8 Press or repeatedly until On appears.

9 Press to save and exit.

Managing fax jobs

Forwarding faxes

Use the fax forwarding feature if you are going to be away, but still want to receive your faxes. There are three fax
forwarding values or settings:

• Off—(Default)

• Forward—The printer sends the fax to the designated fax number.

Faxing

84

• Print & Forward—The printer prints the fax and then sends it to the designated fax number.

To set up fax forwarding:

1 Make sure the printer is on and is connected to a working phone line.

2 From the control panel, press or repeatedly until Fax is highlighted.

3 Press .

The Fax Mode menu appears.

4 Press or repeatedly until the Fax Setup submenu is highlighted.

5 Press .

6 Press or repeatedly until the Ringing and Answering submenu is highlighted.

7 Press .

8 Press or repeatedly until you reach Fax Forward.

9 Press or repeatedly until the value you want appears.

10 Press .

11 Enter the number to which you want to forward the fax.

12 Press to save the number.

Printing fax activity reports

You can print reports of faxes sent and/or received.

1 From the control panel, press or repeatedly until Fax is highlighted.

2 Press .

The Fax Mode menu appears.

3 Press or repeatedly until the Fax Setup submenu is highlighted.

4 Press .

5 Press or repeatedly until the History and Reports submenu is highlighted.

6 Press .

7 Press or until you reach Report.

8 Press or repeatedly until the type of report you want to print appears.

9 Press to print the report and exit.

Setting up a fax footer

1 From the control panel, press or repeatedly until Fax is highlighted.

2 Press .

3 Press or repeatedly until the Fax Setup submenu is highlighted.

Faxing

85

4 Press .

5 Press or repeatedly until the Fax Printing submenu is highlighted.

6 Press .

7 Press or repeatedly until you reach the Fax Footer menu item.

8 Press or repeatedly until On appears.

9 Press to save and exit.

Blocking junk faxes

If you have Caller ID, you can block faxes sent from specific numbers and/or all faxes which do not include a Caller
ID number.

1 To turn on the Block List feature:

a From the control panel, press or repeatedly until Fax is highlighted.

b Press .

c Press or repeatedly until the Fax Setup submenu is highlighted.

d Press .

e Press or repeatedly until the Fax Blocking submenu is highlighted.

f Press .

g Press or repeatedly until you reach the Block List menu item.
h Press or repeatedly until On appears.

i Press to save and exit.

2 To add each fax number you want to block:

a From the control panel, press or repeatedly until Fax is highlighted.

b Press .

c Press or repeatedly until the Fax Setup submenu is highlighted.

d Press .

e Press or repeatedly until the Fax Blocking submenu is highlighted.

f Press .

g Press or repeatedly until you reach Blocked Fax Add Entry.

h Press .

i Use the keypad numbers to enter the name of the person associated with the fax number in the Name field.
j Press once.

k Use the keypad numbers to enter the fax number in the Fax Number field.

l Press to save and exit.

3 To block faxes sent from an unidentified number (a number with no Caller ID):

a From the control panel, press or repeatedly until Fax is highlighted.

b Press .

c Press or repeatedly until the Fax Setup submenu is highlighted.

Faxing

86

d Press .

e Press or repeatedly until the Fax Blocking submenu is highlighted.

f Press .

g Press or repeatedly until you reach the Block No-ID menu item.
h Press or repeatedly until On appears.

i Press to save and exit.

4 If you want to print a list of blocked faxes:

a From the control panel, press or repeatedly until Fax is highlighted.

b Press .

c Press or repeatedly until the Fax Setup submenu is highlighted.

d Press .

e Press or repeatedly until the Fax Blocking submenu is highlighted.

f Press .

g Press or repeatedly until you reach Print Blocked Fax List.

h Press to print the list.

Note: This feature is only available when blocked fax entries exist.

Blocking unwanted changes to fax settings

This feature blocks network users from changing fax settings through the Fax Setup Utility.

1 From the control panel, press or repeatedly until Setup is highlighted.

2 Press .

3 Press or repeatedly until the Change Printer Default Settings submenu is highlighted.

4 Press .

5 Press or repeatedly until you reach the Block Host Settings menu item.

6 Press or repeatedly until On appears.

7 Press to save and exit.

Customizing settings using the Fax Setup Utility

You can adjust the fax settings in the Fax Setup Utility. These settings apply to the faxes you send or receive.

1 From the Finder desktop, double-click the Lexmark 7500 Series folder.

2 Double-click the 7500 Series Fax Setup Utility icon.

3 From the Fax Setup Utility dialog, choose the printer from the Device pop-up menu.

Note: If you are using a network printer to send a fax, the MAC address of your printer is shown on the Device

pop-up menu. Otherwise, only the printer name is shown.

Faxing

87

From here You can

Send

Receive

• Select the telephone dial method you want to use.

• Enter a dialing prefix.

• Select a dialing volume.

• Select the number of times you want the machine to redial and the time between

those attempts if the fax cannot be sent on the first try.

• Select whether to scan the entire document before dialing the number.

• Select a maximum send speed and print quality for outgoing faxes.

• Select the print quality of your fax job.

• Select Automatically convert fax send quality to match the resolution setting of

the receiving fax machine.

• Enter your name and fax number.

Notes:

– You can include a calling card number as part of the fax number.
– Enter a maximum of 64 digits in a fax number.

• Select incoming call options.

• Select Auto Answer options.

• Select whether you want to forward a fax, or print it and then forward it.

• Enter a fax forwarding number.

• Manage blocked faxes.

Faxing

88

From here You can

Fax/Report Printing

• Choose to reduce an incoming fax to fit to the paper size loaded, or print it on two

sheets of paper.

• Choose whether to print a footer (the date, time, and page number) to appear on

each page you receive.

• If your printer has duplex unit is installed, specify whether you want to print on both

sides of the page.

• Select when to print fax activity and confirmation reports.

Speed Dials Create, add to, edit, or delete entries from the Speed Dial list, including Group Dial entries.

4 Click Save Settings after you finish customizing the settings. To change settings back to the factory default

settings, click Factory Defaults. To load your saved settings, click Revert to Saved.

5 Close the Fax Setup Utility.

Related topics:

• “Using the Fax Setup Utility” on page 142

Faxing

89

Working with photos

Notes:

• For best results when printing photos or other high-quality images, use Lexmark Photo Paper or Lexmark

PerfectFinish Photo Paper. Do not use Lexmark Premium Photo Paper. Your print cartridges are not compatible
with this type of paper.

• To prevent smudging or scratching, avoid touching the printed surface with your fingers or sharp objects. For

best results, remove each printed sheet individually from the paper exit tray, and allow the prints to dry at least
24 hours before stacking, displaying, or storing.

Connecting photo storage devices

Inserting a memory card

1 Insert a memory card.

• Insert the card with the brand name label facing up.

• If there is an arrow on the card, make sure it points toward the printer.

• If needed, make sure you connect the memory card to the adapter that came with it before inserting it into

the slot.

Slot Memory card

1

• xD-Picture Card

• xD-Picture Card (Type H)

• xD-Picture Card (Type M)

• Secure Digital (SD)

• Mini Secure Digital (with adapter)

• Micro Secure Digital (with adapter)

• MultiMedia Card (MMC)

• Reduced Size MultiMedia Card (with adapter)

• MultiMedia Card mobile (with adapter)

• Memory Stick (MS)

• Memory Stick PRO

• Memory Stick Duo (with adapter) or Memory Stick Duo PRO (with adapter)

2

• Compact Flash Type I and Type II

• Microdrive

2 Wait for the light located to the right of the slots on the printer to come on. The light blinks to indicate the memory

card is being read or is transmitting data.

Working with photos

90

Warning: Do not touch cables, any network adapter, the memory card, or the printer in the area shown while

actively printing, reading, or writing from the memory card. A loss of data can occur. Also, do not remove the
memory card while actively printing, reading, or writing from it.

When the printer detects the memory card, the message Memory Card Detected appears on the control
panel display.

If the printer does not read the memory card, remove and reinsert it.

Notes:

• The printer recognizes one memory card at a time. If you insert more than one memory card, a message appears

on the display prompting you to remove all memory cards inserted.

• If a USB flash drive is inserted together with the memory card, a message appears on the display prompting

you to choose which memory device to use.

Related topics:

• “Inserting a flash drive” on page 91

• “Using the control panel” on page 113

Inserting a flash drive

1 Insert the flash drive into the PictBridge port on the front of the printer.

Note: An adapter may be necessary if your flash drive does not fit directly into the port.

2 Wait for the printer to recognize that a flash drive is installed. When the flash drive is recognized, the message

Storage Device Detected appears.

If the printer does not read the flash drive, remove and reinsert it.
Warning: Do not touch cables, any network adapter, the flash drive, or the printer in the area shown while

actively printing, reading, or writing from the flash drive. A loss of data can occur. Also, do not remove the flash
drive while actively printing, reading, or writing from the flash drive.

Working with photos

91

Note: The printer recognizes one active media device at a time. If you insert more than one media device, a message

appears on the display prompting you to designate the device you want the printer to recognize.

Related topics:

• “Inserting a memory card” on page 90

• “Using the control panel” on page 113

Removing a memory card or flash drive

A memory card or a flash drive has to be properly removed from the printer to avoid corruption of the device or loss
of stored data.

Warning: Do not remove a memory device from the printer while actively printing, reading, or writing from it.
If the printer is connected to the computer through a USB cable:

1 Click on the Finder desktop, and then drag it to the trash icon on the dock.

2 Remove the memory card or flash drive.

If the printer is connected to the computer through a wireless network, and you are using the Network Card Reader
to view and download photos from the memory device:

1 Click .

2 Remove the memory card or flash drive.

Related topics:

• “Inserting a flash drive” on page 91

• “Inserting a memory card” on page 90

Working with photos using the control panel

Note: To prevent smudging or scratching, avoid touching the printed surface with your fingers or sharp objects. For

best results, remove each printed sheet individually from the paper exit tray, and allow the prints to dry at least 24
hours before stacking, displaying, or storing.

Printing a photo or selected photos

1 Load photo paper with the glossy or printable side facing you. (If you are not sure which side is the printable

side, see the instructions that came with the paper.)

2 Insert a memory card or flash drive.

Working with photos

92

3 From the control panel, press .

4 Press to select Browse and Print Photos.

5 Press or to navigate through the photos.

6 Press to select a photo for printing.

7 If you want to edit the photo, view the photo in full screen mode, change the print settings, or see a print preview

of the photo:

a Press .

b Make your selections using the control panel buttons.

c Press to save your changes.

d Press .

8 Press or to select the number of copies to print.

9 You can select more photos for printing and editing by repeating step 5 through step 8.

10 Press to go to the print preview screen.

11 If you want to adjust the print settings:

a Press .

b Make your selections.

c Press to save your selections, and then go back to the print preview screen.

12 Press to print.

Note: To prevent smudging or scratching, avoid touching the printed surface with your fingers or sharp objects.

For best results, remove each printed sheet individually from the paper exit tray, and allow the prints to dry at
least 24 hours before stacking, displaying, or storing.

Related topics:

• “Loading paper” on page 18

• “Inserting a memory card” on page 90

• “Inserting a flash drive” on page 91

Printing all photos from a memory device

1 Load photo paper with the glossy or printable side facing you. (If you are not sure which side is the printable

side, see the instructions that came with the paper.)

2 Insert a memory card or flash drive.

3 From the control panel, press .

4 Press repeatedly until Print All Photos is highlighted.

5 Press .

6 Press or to select the number of photos to be printed on a page.

7 Press .

Working with photos

93

8 If you want to adjust the print settings:

a Press .

b Make your selections using the control panel buttons.

c Press to save your selections.

9 Press to print.

Note: To prevent smudging or scratching, avoid touching the printed surface with your fingers or sharp objects.

For best results, remove each printed sheet individually from the paper exit tray, and allow the prints to dry at
least 24 hours before stacking, displaying, or storing.

Related topics:

• “Loading paper” on page 18

• “Inserting a memory card” on page 90

• “Inserting a flash drive” on page 91

Printing photos stored on a memory device using the proof sheet

1 Load plain letter- or A4-size paper.

2 Insert a memory card or flash drive.

3 From the control panel, press .

4 Press repeatedly until Photo Proof Sheet is highlighted.

5 Press .

6 Press or to specify which category of photos you want to print.

You can print a proof sheet:

• For all photos on the memory card

• For the 20 most recent photos, if there are 20 or more photos on the card

• By date, if the photos on the card were taken on different dates. If you choose this option, use the arrow

buttons on the control panel to choose the date range, then press

to save your selections.

7 Press .

8 Press again.

One or more proof sheets print.

9 Follow the instructions on the proof sheet to select which photos to print, the number of copies per photo, red-eye

reduction, page layout, print options, and paper size.

Note: When making selections, make sure to fill in the circles completely.

10 Load the proof sheet facedown on the scanner glass.

11 From the control panel, press to select Scan Proof Sheet.

12 Press .

The printer scans the proof sheet.

Working with photos

94

13 Load photo paper with the glossy or printable side facing you. (If you are not sure which side is the printable

side, see the instructions that came with the paper.)

Note: Make sure the paper matches the size you selected on the proof sheet.

14 Press to print your photos.

Note: To prevent smudging or scratching, avoid touching the printed surface with your fingers or sharp objects. For

best results, remove each printed sheet individually from the paper exit tray, and allow the prints to dry at least 24
hours before stacking, displaying, or storing.

Related topics:

• “Loading paper” on page 18

• “Inserting a memory card” on page 90

• “Inserting a flash drive” on page 91

Printing photos from a PictBridge-enabled digital camera

PictBridge is a technology available in most digital cameras that lets you print directly from your digital camera without
using a computer. You can connect a PictBridge-enabled digital camera to the printer, and use the camera to control
printing photos.

1 Insert one end of the USB cable into the camera.

Note: Use only the USB cable that came with the camera.

2 Insert the other end of the cable into the PictBridge port on the front of the printer.

Notes:

• Make sure the PictBridge-enabled digital camera is set to the correct USB mode. If the camera USB selection

is incorrect, the camera will be detected as a USB storage device, or an error message will be displayed on
the control panel of the printer. For more information, see the camera documentation.

• The printer reads only one media device at a time.

Warning: Do not touch the USB cable, any network adapter, or the printer in the area shown while actively

printing from a PictBridge-enabled digital camera. A loss of data can occur. Also, do not remove the USB cable
or network adapter while actively printing from a PictBridge-enabled digital camera.

Working with photos

95

3 If the PictBridge connection is successful, the following message appears on the display: Camera Connected.

Refer to Camera display or Camera owners manual for further information.

After a few seconds, the following message appears: Use Camera to choose and print photos.

Press

to select printer default settings.

4 If you want to use the camera to control printing photos, see the instructions in the camera documentation.

Press
made on the camera.

on the control panel to specify the PictBridge default print settings, which are used if no selections are

Printing photos from a digital camera using DPOF

Digital Print Order Format (DPOF) is a feature available on some digital cameras. If your camera supports DPOF,
you can specify which photos to print, how many of each, and print settings while the memory card is still in the
camera. The printer recognizes these settings when you insert the memory card into the printer.

Note: If you specified a photo size while the memory card is still in the camera, make sure the size of the paper
loaded in the printer is not smaller than the size you specified in the DPOF selection.

1 Load photo paper with the glossy or printable side facing you. (If you are not sure which side is the printable

side, see the instructions that came with the paper.)

2 Insert a memory card.

3 From the control panel, press .

4 Press repeatedly until Print Camera Selections is highlighted.

5 Press .

6 Press again.

7 Press or to preview the photos.

8 Press to print.

Note: To prevent smudging or scratching, avoid touching the printed surface with your fingers or sharp objects.

For best results, remove each printed sheet individually from the paper exit tray, and allow the prints to dry at
least 24 hours before stacking, displaying, or storing.

Related topics:

• “Using the control panel” on page 113

• “Inserting a memory card” on page 90

• “Loading paper” on page 18

Working with photos

96

Editing photos using the control panel

1 Load photo paper with the glossy or printable side facing you. (If you are not sure which side is the printable

side, see the instructions that came with the paper.)

2 Insert a memory card or flash drive.

3 From the control panel, press .

4 Press to select Browse and Print Photos.

5 Press or to navigate through the photos.

6 Press to select a photo for editing and printing.

7 Press .

8 Press to select Edit Photo.

From here You can

Brightness Adjust the brightness of a photo.

Rotate Rotate a photo in 90-degree increments clockwise or counterclockwise.

Crop Crop a photo.

Auto Enhance Enhance a photo automatically.

Remove Red Eye Reduce the red-eye effect caused by light reflection.

Colorized Effect Select whether to print a photo in black and white, sepia, antique brown,

or antique gray.

Frames Select a frame for the photo.

9 Make your selections using the control panel buttons.

10 Press to save your changes.

11 Press to go back to the photo.

12 Press or to select the number of copies to print.

Note: The number of copies is automatically set to 1.

13 You can select more photos for printing and editing by repeating step 5 through step 12.

14 Press to go to the print preview screen.

15 If you want to adjust the print settings:

a Press .

b Make your selections using the control panel buttons.

c Press to save your selections, and then go back to the print preview screen.

16 Press to print.

Note: To prevent smudging or scratching, avoid touching the printed surface with your fingers or sharp objects.

For best results, remove each printed sheet individually from the paper exit tray, and allow the prints to dry at
least 24 hours before stacking, displaying, or storing.

Working with photos

97

Related topics:

• “Inserting a memory card” on page 90

• “Inserting a flash drive” on page 91

• “Understanding Photo and the Photo Card Mode menu” on page 118

Transferring photos from a memory card to a flash drive

1 Insert a memory card that contains the images you want to transfer.

2 After the memory card is detected, press .

3 Press repeatedly until Save Photos is highlighted.

4 Press .

5 Press or to select USB Flash Drive.

6 Insert the flash drive.

7 Press .

8 Press or to highlight your selection among the following options:

• Save All “N” Photos (Where “N” is the number of photos on the memory card detected by the printer.)

• Save Recent Date Photos

• Save Date Range

9 Press .

10 Follow the instructions on the control panel display of the printer.

Notes:

• If there is not enough memory on the flash drive, a prompt appears on the display.

• Do not remove the flash drive until a message appears on the display indicating that copying is complete.

Related topics:

• “Connecting photo storage devices” on page 90

Transferring photos from a memory device to the computer using the control panel

If the printer is connected directly to a computer, or connected to a computer through a wireless network connection,
you can transfer photos from a memory card or flash drive to the computer.

Notes:

• You cannot transfer photos from a memory device to a computer through an external network adapter that does

not support memory device connection.

• The printer may require that you select a computer (and a PIN if required by that computer).

1 Insert a memory card or a flash drive that contains the images you want to transfer.

2 After the memory device is detected, press .

3 Press repeatedly until Save Photos is highlighted.

4 Press .

Working with photos

98

5 Press or to select Computer.

6 Press .

If the computer is connected directly to the printer through a USB cable:

a Press to begin saving photos to your computer.

b Follow the instructions on the computer screen.

If the printer is connected to a wireless network, you will be asked to select the computer that you want to use.

a Press or to select a computer.

b Press .

If you set a PIN during network setup and are being asked for it:

1 Enter the PIN using the and to select a digit location and the and to select a value for that

digit.

2 Press .

c Press to begin saving photos to the computer.

d Follow the instructions on the computer screen.

Related topics:

• “Connecting photo storage devices” on page 90

• “Transferring photos from a memory device to the computer over a wireless network” on page 106

Viewing a slideshow of photos on the control panel display

1 Insert a memory card or flash drive.

2 From the control panel, press .

3 Press repeatedly until View Slideshow is highlighted.

4 Press .

5 Press or to select a speed for the slideshow.

6 Press .

Note: Pressing

while viewing a photo selects that photo for printing.

Related topics:

• “Inserting a memory card” on page 90

• “Inserting a flash drive” on page 91

Working with photos using the computer

Note: To prevent smudging or scratching, avoid touching the printed surface with your fingers or sharp objects. For

best results, remove each printed sheet individually from the paper exit tray, and allow the prints to dry at least 24
hours before stacking, displaying, or storing.

Printing cards

1 Load greeting cards, index cards, or postcards.

Working with photos

99

Notes:

• Make sure the thickness of each card does not exceed 0.020 inch (0.50 mm).

• Make sure the print side of the card faces you.

2 Customize the settings as needed in the Page Setup dialog.

a With a document open, click File  Page Setup.

b From the “Format for” pop-up menu, choose 7500 Series.

c From the Paper Size pop-up menu, choose a card size.

d Choose an orientation.

e Click OK.

3 Customize the settings as needed in the Print dialog.

a From the software application, click File  Print.

b From the Printer pop-up menu, choose 7500 Series.

c Click Print.

Notes:

• To avoid paper jams, do not force the cards into the printer.

• To prevent smudging, remove each card as it exits, and let it dry before stacking.

Related topics:

• “Loading greeting cards, index cards, photo cards, and postcards” on page 20

Printing borderless photos

1 Load photo or glossy paper with the glossy or printable side facing you. (If you are not sure which side is the

printable side, see the instructions that came with the paper.)

Notes:

• Use only the following paper sizes to print borderless photos: letter, A4, A5, B5, A6, Hagaki, 3.5 x 5 in.,

4 x 6 in., 5 x 7 in., 10 x 15 cm, 13 x 18 cm, L, and 2L.

• If you use plain paper instead of a photo paper, the printed photo may come out with small margins around

its borders.

2 Customize the settings as needed in the Page Setup dialog.

a With a photo open, choose File  Page Setup.

b From the “Format for” pop-up menu, choose 7500 Series.

c From the Paper Size pop-up menu, choose the paper size loaded.

Note: Make sure you choose an option that has (Borderless) in it. For example, if you loaded a 4 x 6 photo
card, choose US 4 x 6 in (Borderless).

d Choose an orientation.

e Click OK.

3 Customize the settings as needed in the Print dialog.

a With a photo open, choose File  Print.

b From the Printer pop-up menu, choose 7500 Series.

c For Mac OS X version 10.4 or later, click Advanced. Otherwise, proceed to the next step.

d From the Copies & Pages pop-up menu, type the number of copies to be printed.

Working with photos

100
