1
Printer overview
The following illustration shows the Lexmark™ C750 printer.
Standard
output bin
Front door
Standard tray
Upper right
access door
(redrive area)
Lower right
access door
(fuser area)
5
The following illustration shows the printer configured with a duplex unit and three optional 500-sheet
drawers.
Duplex unit
500-sheet
drawers
The following illustration shows the printer configured with a duplex unit, one optional 500-sheet
drawer, and one optional 2000-sheet drawer.
Duplex unit
500-sheet
drawer
2000-sheet
drawer
6
Understanding the printer operator
2
panel
The operator panel has five buttons, a display, and a light that flashes when the printer is processing a
job indicated by the Busy message.
Ready
Display
1
Menu
Operator panel buttons
Button Function
Go
Menu Press Menu to:
Press Go to:
• Return to the Ready state if the printer is offline (the Ready message does not appear on
the display).
• Exit printer menus and return to the Ready state.
• Clear some operator panel messages.
• Resume printing after loading paper or clearing paper jams.
• Exit Power Saver.
If you have changed printer settings from the operator panel menus, press
a job to print. The printer must display Ready for jobs to print.
• Take the printer offline (out of the Ready
offline, press Menu to scroll through the menus and menu items.
• List the menu items in the Job Menu (during Busy state).
For menu items that have numerical values, such as Copies, press and hold
through the list of values. Release the button when the number you want appears.
If you see a Menus Disabled message, you will not be able to change default settings. You
can still clear messa ges an d sele ct i tems fro m the Job M enu when p rinting . When y ou send a
job to print, change printer properties to select the settings you want for your job.
2
Select 3Return
Go5Stop
4
6
Go before sending
state) and enter the menus. When the printer is
Menu to scroll
7
Button Function
Select
Press Select to:
• Open the menu shown on the second line of the display.
• Save the displayed menu item as the new user default setting.
• Clear certain messages from the display.
• Continue printing after the Change <x> message appears. See Change <x> for more
information.
Return
Stop
Press Return to go back to the previous menu level or menu item.
Press Stop at the Ready, Busy, or Waiting message to temporarily take the printer offline.
The message changes to Not Ready . No data is lost.
Go to return the printer to the Ready, Busy, or Waiting state.
Press
1, 2, 3, 4, 5, 6
Use the numbers loc ated ne xt to the na mes of the b uttons to enter y our persona l identific ation
number (PIN) after you send a confidential job.
See the menu map for a brief overview of the printer menus available from the operator panel.
8
3
Sending a job to print
To print a job from a typical Windows application:
1 Open the file you want to print.
2 From the File menu, select Print.
3 Verify that the correct printer is selected in the dialog box.
4 Modify the printer settings as appropriate (such as the pages you want to print or the number
of copies).
Note: Click Properties or Setup to adjust printer settings not available from the first
screen, and click OK.
5 Click OK or Print to send the job to the selected printer.
9
4
Canceling a print job
Cancel a job from the printer operator panel
If the job you want to cancel is printing, and Busy appears on the display:
1 Press Menu until you see Job Menu, and then press Select.
2 Press Menu until you see Cancel Job, and then press Select.
Cancel a job from the Windows taskbar
When you send a job to print, a small printer icon appears in the right corner of the taskbar.
1 Double-click the printer icon. A list of print jobs appears.
2 Select the job you want to cancel.
3 Press Delete on your keyboard.
Cancel a job from a Windows desktop
1 Minimize all programs to reveal the contents of the desktop.
2 Double-click My Computer.
3 Double-click Printers. A list of available printers appears.
4 Double-click the printer you selected when you sent the job. A list of print jobs appears.
5 Select the job you want to cancel.
6 Press Delete on your keyboard.
10
Cancel a job from a Macintosh computer
When you send a job to print, the icon for your selected printer appears on the desktop.
1 Double-click the printer icon on your desktop. A list of print jobs appears.
2 Press Control and click the print job you want to cancel.
3 Select Stop Queue from the pop-up menu that appears.
11
5
Conserving supplies
Several settings in your application software or on the display let you conserve toner and paper:
For more information,
Supply Setting What the setting does
T oner T oner Darknes s in
the Color Me nu
Lets you adjust the amount of toner
released on a shee t of p ape r. The values
range from 1 (lightest setting) to 5
(darkest setting).
see...
Toner Darkness
Paper and
specialty media
Paper and
specialty media
Multipage Print in
the Finishing
Menu
Duplex in the
Finishing Menu
Use your so ftware
application or
printer driver to
send a V erify Print
job.
Use Held Jobs in
the Job Menu to
access you r V erify
Print job.
Prints two or more page images on one
side of a sheet.
Values for Multipage Print are 2 Up, 3
Up, 4 Up, 6 Up, 9 Up, 12 Up, and 16 Up.
Combined with the duplex setting,
Multipage Print lets you print up to 32
pages on one sheet of p ape r (16 im ages
on the front and 16 on the back).
Ava ila ble when you attach an optional
duplex unit.
Lets you examine the first copy of a
multiple-copy job to be sure it is
satisfactory before you print the other
copies. If the job is unsatisfactory, you
cancel the job .
Multipage Print
Duplex
Verify Print
Canceling a print job
Holding a job in the
printer
12
6
Holding a job in the printer
When sending a job to the printer, y ou can specify in the driver that you want the printer to hold the job
in memory. When you are ready to print the job, you must go to the printer and use the operator panel
menus to identify which held job you want to print.
Note: Print and Hold functions require a minimum of 16MB available printer memory . We
recommend a minimum of 32MB available printer memory and a hard disk.
To learn more about this function, click a topic:
• Printing and deleting held
jobs
• Recognizing when format
errors occur
• Verifying print jobs
• Accessing held jobs from
the operator panel
• Repeating print jobs at a
later time
• Printing confidential jobs
• Reserving print jobs
Printing and deleting held jobs
Once held jobs are stored in printer memory, you can use the printer operator panel to specify what
you want to do with one or more of the jobs. You can select either Confidential Job or Held Jobs
(Repeat Print, Reserve Print, and Verify Print jobs) from the Job Menu. If you select Confidential Job,
you must enter the personal identification number (PIN) you specified in the driver when you sent the
job. See Confidential jobs for more information.
From either the Confidential Job or the Held Jobs menu items, you have five choices:
• Print All Jobs
• Print A Job
• Delete All Jobs
• Delete A Job
• Print Copies
13
Accessing held jobs from the operator panel
1 To access held jobs from the operator panel:
– If the printer is Busy, press Menu and the Job Menu appears.
– If the printer is Ready, continue to step 2.
2 Press Menu until you see Held Jobs or Confidential Job on the operator panel display,
depending on the type of job you want to access.
3 Press Select.
User Name appears on the first line of the operator panel. The second line displays the names
of users currently associated with Print and Hold jobs.
4 Press Menu until you see your user name.
Note: If you are looking for a Confidential Job, you are prompted to enter your PIN. See
Confidential jobs for more information.
5 Press Select.
6 Press Menu until the action you want to take is on the second line of the operator panel (Print
A Job, Delete A Job, and so on).
7 Press Select.
– If you are looking for a particular job, press Menu to scroll through the list of available jobs,
and press Select when the correct job is displayed. An asterisk (*) appears next to the job
name indicating you have chosen to print or delete that job.
– If you are prompted to enter the number of copies you want to print, use the Menu button
to increase or decrease the number on the display, and then press Select.
8 Press Go to print or delete specific jobs you have marked.
The printer briefly shows messages indicating what Print and Hold functions it is performing.
Recognizing when format errors occur
If the symbol appears on the display, it indicates that the printer had trouble formatting one or more
of the held jobs. These formatting problems are most commonly the result of insufficient printer
memory or invalid data that might cause the printer to flush the job.
When a symbol appears next to a held job, you can:
• Print the job. Be aware, however, that only part of the job may print.
• Delete the job. You may want to free up additional printer memory by scrolling through the list
of held jobs and deleting others you have sent to the printer.
If formatting errors are a recurring problem with held jobs, your printer may require more memory.
14
Repeat Print
If you send a Repeat Print job, the printer prints all requested copies of the job and stores the job in
memory so you can print additional copies later. You can print additional copies as long as the job
remains stored in memory.
Note: Repeat Print jobs are automatically deleted from printer memory when the printer
requires extra memory to process additional held jobs.
Reserve Print
If you send a Reserve Print job, the printer does not print the job immediately, but stores the job in
memory so you can print the job later. The job is held in memory until you delete it from the Held Jobs
menu. Reserve Print jobs may be deleted if the printer requires extra memory to process additional
held jobs.
See Printing and deleting held jobs for information.
Verify Print
If you send a Verify Print job, the printer prints one copy and holds the remaining copies you requested
from the driver in printer memory. Use Verify Print to examine the first copy to see if it is satisfactory
before printing the remaining copies.
See Printing and deleting held jobs if you need help printing the additional copies stored in memory.
Note: Once all copies are printed, the Verify Print job is deleted from printer memory.
Confidential jobs
When you send a job to the printer, you can enter a personal identification number (PIN) from the
driver. The PIN must be four digits using the numbers 1–6. The job is then h el d i n print e r m e mo ry unt i l
you enter the same four-digit PIN from the printer operator panel and choose to print or delete the job.
This ensures that the job does not print until you are there to retrieve it, and no one else using the
printer can print the job.
15
When you select Confidential Job from the Job Menu and then select your user name, the following
prompt is displayed:
Enter PIN:
=____
Use the buttons on the operator panel to enter the four-digit PIN associated with your confidential job.
The numbers next to the button names identify which button to press for each digit (1–6). As you enter
the PIN, asterisks are displayed on the operator panel to ensure confidentiality.
Enter PIN
=****
If you enter an invalid PIN, the message No Jobs Found. Retry? appears. Press
PIN, or press
When you enter a valid PIN, you have access to all print jobs matching the user name and PIN you
entered. The print jobs matching the PIN you entered appear on the display when you enter the Print A
Job, Delete A Job, and Print Copies menu items. You can then choose to print or delete jobs matching
the PIN you entered. (See Printing and deleting held jobs for more information.) After printing the
job, the printer deletes the confidential job from memory.
Stop to exit the Confidential Job menu.
Go to reenter the
16
P aper and specialty media
7
specifications
The following table lists supported paper and specialty media sizes and types for the standard and
optional trays, as well as for the multipurpose feeder. We recommend that you try a limited sample of
any paper or specialty media you are considering using with the printer before purchasing large
quantities.
Source Paper sizes supported Paper types supported Capacity
500-sheet trays Letter, A4, A5, Legal,
2000-sheet tray Letter, A4, A5, Legal,
Multipurpose
feeder
1
Supported as selected paper with tray size sensing turned off in the appropriate trays.
2
When selected, the page is formatted for 215.9 x 355.6 mm (8.5 x 14 in.) unless otherwise specified.
3
Load narrow media with the length in the feed direction (portrait).
4
If you print large quanti ties of labels or other gl ossy prin t media , replac e the fuser ho using with a web oil er field
upgrade kit (P/N 12G6307 for a 115 V printer, P/N 12G6308 for a 220 V printer).
Executive, JIS B5, Folio
Statement
Executive, JIS B5
Letter, A4, A5, Legal,
Executive, JIS B5, Folio
Statement
7¾, 9, 10, DL, C5, B5, other
1
, Universal
1
, Universal
1
2,3
1
2,3
Paper, transparencies,
,
labels, card stoc k
Paper 2000 sheets of 20 lb paper
Paper, transparencies,
,
labels, card stoc k
2
Envelopes 10 envelopes
500 sheets of 20lb paper
400 transparencies
250 sheets of labels or
card stock
100 sheets of 20lb paper
85 transparencies
85 sheets of labels or
card stock
4
For more details about the types of paper and specialty media your printer supports, refer to the Card
Stock & Label Guide available on Lexmark’s Web site at www.lexmark.com.
17
8
Loading the trays
Loading the 500-sheet trays
Follow these instructions to load any of the 500-sheet trays.
1 Remove the tray.
2 Squeeze the front guide lever and slide the guide to the front of the tray.
18
Squeeze the side guide lever and slide the guide to the correct position for the size paper you
3
are loading.
Icons along the back of the tray indicate paper sizes.
4 Flex the sheets back and forth to loosen them, and then fan them.
Do not fold or crease the paper. Straighten the edges of the stack on a level surface.
5 Place the paper against the back left corner of the tray, print side down.
Do not load bent or wrinkled paper.
Note: Do not exceed the maximum stack height. Overfilling the tray may cause jams.
19
Squeeze the front guide lever and slide the guide until it lightly touches the stack of paper.
6
7 Reinstall the tray.
Make sure the tray is pushed completely into the printer.
Loading the 2000-sheet tray
Follow these instructions to load a 2000-sheet tray. Do not load any print media other than paper in the
2000-sheet tray.
1 Pull open the tray.
20
Squeeze the side guide lever, lift the guide, and place it into the appropriate slot for the size
2
paper you are loading.
3 Squeeze the two front guide levers and slide the guide to the correct position for the size
paper you are loading.
4 Slide the bottom support toward the front of the tray until it touches the front guide.
21
Flex the sheets back and forth to loosen them, and then fan them.
5
Do not fold or crease the paper. Straighten the edges of the stack on a level surface.
6 Place the paper against the back left corner of the tray, print side down.
Do not load bent or wrinkled print media.
7 Close the tray.
Make sure the tray is pushed completely into the printer.
Note: Do not exceed the maximum stack height. Overfilling the tray may cause paper
jams.
22
9
Loading the multipurpose f eeder
You can use the multipurpose feeder one of two ways:
• Paper tray—As a paper tray, you can load print media in the feeder with the intention of
leaving the media in the feeder.
• Manual bypass feeder—As a manual bypass feeder, you send a print job to the feeder while
specifying the type and size of media from your computer. The printer then prompts you to
load the appropriate print media before it prints.
Follow these instructions to load the multipurpose feeder.
1 Open the multipurpose feeder.
2 Squeeze the paper guide lever and slide the guide all the way toward the front of the printer.
23
Flex the sheets back and forth to loosen them, and then fan them.
3
Do not fold or crease the print media. Straighten the edges of the stack on a level surface.
4 Arrange the stack of print media correctly for the size, type, and print method you are using.
5 Place the print media, print side up, along the left side of the multipurpose feeder, and then
push it in as far as it will go.
Do not force the print media.
Note: Do not exceed the maximum stack height. Overfilling the feeder may cause jams.
6 Squeeze the paper guide lever and slide the guide until it lightly touches the side of the stack.
24
10
Linking trays
• If you load the same size and type of paper or specialty media in more than one tray, the
printer automatically links the trays. This means that when one tray is empty, it feeds from the
next linked tray.
For example, if you have the same size and type of paper or specialty media loaded in tray 2
and tray 4, the printer feeds from tray 2 until it becomes empty, and then it feeds from the next
linked tray—tray 4.
• If you load the same size paper or specialty media in each tray, make sure it is also all the
same type to link the trays.
Once the trays you selected are loaded with the same size and type of paper or specialty
media, select the same Paper Type setting in the Pap er Menu for these sources.
• To disable tray linking, set the Paper Type to a unique value in each one of the trays.
Note: To link trays loaded with Executive, Legal, JIS B4, or JIS B5 size paper, see Size
Sensing.
25
11
Linking bins
If you attach an optional finisher or mailbox to your printer, you can link output bins, or otherwise
specify how the printer sends jobs to the bins, by changing the Configure Bins settings in the Paper
Menu.
Value Description
Mailbox
Link
Mail Overflow*
Type Assignment
Lets you select an output bin when you send a job to print. (If you
prefer, you can select a default output bin for all print jobs to go to.)
The printer alerts you when the bin you selected becomes full, and
stops printing until you empty the bin.
Links all available bins so that when one bin becomes full, the printer
sends jobs to the next linked bin.
Sends jobs automatically to a preassigned overflow bin when the
current bin becomes full.
Lets you assign di ff erent type s of media to spe cific outp ut bins or set o f
linked bins. Th e printer the n sends all printed m edia to th e bin or set of
linked bins that you designated to receive each type of paper or
specialty media .
Only available if you have attached an optional mailbox.
To change the Configure Bins setting:
1 Press Menu until you see Paper Menu, and then press Select.
2 Press Menu until you see Configure Bins, and then press Select. Mailbox appears on the
second line of the display.
3 Press Menu until you see the value you want, and then press Select to save the value as the
bin configuration default.
4 Press Go to return the printer to the Ready state.
For more information, see Configure Bins and Bin <x> Full.
26
12
Tips for successful printing
Storing paper
Use the following guidelines to avoid paper feeding problems and uneven print quality.
• Store paper in an environment where the temperature is approximately 21°C (70°F) and the
relative humidity is 40%.
• Store cartons of paper on a pallet or shelf rather than directly on the floor.
• If you store individual packages of paper out of the original carton, make sure they rest on a
flat surface so the edges do not buckle or curl.
• Do not place anything on top of paper packages.
Storing supplies
Choose a cool, clean storage area for your printer supplies. Store supplies right side up in their original
packaging until you are ready to use them.
Do not expose supplies to:
• Direct sunlight
• Temperatures above 35°C (95°F)
• High humidity (above 80%)
• Salty air
• Corrosive gases
• Heavy dust
27
Avoiding jams
You can avoid most paper jams by correctly loading paper and specialty media in the printer.
See the following for loading instructions:
• Loading the 500-sheet trays
• Loading the 2000-sheet tray
• Loading the multipurpose feeder
The following hints can help you avoid paper jams:
• Use only recommended paper. Refer to the Card Stock & Label Guide available on Lexmark’s
Web s ite at www.lexmark.com for more information about which paper provides optimum
results for your printing environment.
• If you need detailed information before purchasing large quantities of customized paper, refer
to the Card Stock & Label Guide.
• Do not load wrinkled, creased, or damp paper.
• Flex, fan, and straighten paper before you load it.
• Do not overload the trays or the multipurpose feeder. Make sure the stack height does not
exceed the maximum height indicated.
• Push all trays firmly into the printer after loading them.
• Make sure the guides in the trays are properly positioned for the size paper you have loaded.
• Do not load paper in a tray while a job is printing. Wait for a Load Tray <x> message before
you remove the tray from the printer.
You may remove another tray and load it so long as the print job is not selecting the paper
from it.
• Do not send jobs to staple, hole punch, or offset for transparencies, labels, or card stock.
• We recommend that transparencies, labels, card stock, and envelopes not be sent to the
optional mailbox or optional finisher. These specialty media types should be sent to the
standard bin.
• If an optional finisher or mailbox is attached to your printer, make sure the printer and option
are correctly aligned. Refer to the Setup Guide for alignment instructions.
• Make sure all cables that connect the duplex unit, high capacity feeder, finisher, or mailbox to
the printer are correctly attached. Refer to the Setup Guide for more information.
• If a jam should occur, clear the entire paper path. See Clearing the paper path for more
information.
28
Loading...
