Introduction
Overview
This edition of the Technical Reference contains information about the following printers or multifunction printers
(MFPs):
C540n
C543dn
C544n
C544dn
C544dw
C544dtn
X546dtn
Understanding letters after model numbers
Some Lexmark printers may have one or more letters after the model name to indicate printer features:
Acronym Meaning
d
duplex
1
de duplex and e-Task (electronic task) touch-screen interface
dfe duplex, finisher/stapler, and e-Task touch-screen interface
dhe duplex, high-capacity drawer, and e-Task touch-screen interface
dhn duplex, high-capacity drawer, and network
dme duplex, mailbox, and e-Task touch-screen interface
dn duplex and network
dnf duplex, network, and finisher/stapler
dnw or dw duplex, network, and wireless
dt
dte duplex, additional tray, and e-Task touch-screen interface
dtn duplex, additional tray, and network
dttn duplex, tandem tray module, and network
dtwe duplex, additional tray, wireless, and e-Task touch-screen interface
e e-Task touch-screen interface
hdn hard disk, duplex, and network
1
Duplex printing (two-sided printing) accomplished by means of an optional duplex unit or an internal duplex unit based
on the product.
2
The additional tray is part of a drawer.
duplex and additional tray
2
Introduction
5
Acronym Meaning
n network
nl network light model
ni network and ImageQuick
tn network and additional tray
1
Duplex printing (two-sided printing) accomplished by means of an optional duplex unit or an internal duplex unit based
on the product.
2
The additional tray is part of a drawer.
Introduction
6
Learning about the printer
Finding information about the printer
Setup information
Description Where to find
The Setup information gives you instructions for setting
up the printer. Follow the set of instructions for local,
network, or wireless, depending on what you need.
You can find the Setup information on the inside of the printer
box or on the Lexmark Web site at www.lexmark.com.
Help
Description Where to find
The Help gives you instructions for using the software.
While in any Lexmark software program, click Help, Tips Help,
or Help Help Topics.
Customer support
Description Where to find (North America) Where to find (rest of world)
Telephone support Call us at
• US: 1-800-332-4120
Monday–Friday (8:00 AM–11:00 PM ET)
Saturday (Noon–6:00 PM ET)
• Canada: 1-800-539-6275
Monday–Friday (8:00 AM–11:00 PM ET)
Saturday (Noon–6:00 PM ET)
Telephone numbers and support hours vary by
country or region.
Visit our Web site at www.lexmark.com. Select
a country or region, and then select the Customer
Support link.
Note: For additional information about
contacting Lexmark, see the printed warranty
that came with your printer.
• Mexico: 001-888-377-0063
Monday–Friday (8:00 AM–8:00 PM ET)
Note: Telephone numbers and support times may
change without notice. For the most recent
telephone numbers available, see the printed
warranty statement that came with your printer.
E-mail support For e-mail support, visit our Web site:
www.lexmark.com.
1 Click SUPPORT.
2 Click Technical Support.
3 Select your printer type.
4 Select your printer model.
5 From the Support Tools section, click e-Mail
Support.
6 Complete the form, and then click Submit
Request.
Learning about the printer
E-mail support varies by country or region, and
may not be available in some instances.
Visit our Web site at www.lexmark.com. Select
a country or region, and then select the Customer
Support link.
Note: For additional information about
contacting Lexmark, see the printed warranty
that came with your printer.
7
Printer Control Language (PCL) page formatting
For more information on PCL, refer to the Printer Languages and Interfaces Technical Reference. It contains a complete
listing with descriptions of PCL commands.
To determine which PCL commands your printer supports, see “Appendix A: PCL support” on page 22.
Printable areas
The printable areas and logical pages for PCL emulation (both portrait and landscape orientation) are illustrated below.
See the legend that follows for definitions of areas A through I.
Legend:
A Portrait physical page width and landscape physical page length
B Portrait physical page length and landscape physical page width
C Portrait logical page width
D Landscape logical page width
E Distance between the side edge of the physical page and the logical page in portrait
F Distance between the side edge of the physical page and the logical page in landscape
G Distance between the top and bottom edge of the physical page and logical page
H Distance between the left and right edge of the physical page and the printable area in portrait, or distance between
the top and bottom edge of the physical page and printable area in landscape
I Distance between the top and bottom edge of the physical page and the printable area in portrait, or distance between
the left and right edge of the physical page and the printable area in landscape
Note: The tables that follow in this chapter list the page sizes and dimensions of each area labeled on the preceding
diagram for all paper and envelope sizes your printer supports.
Printer Control Language (PCL) page formatting
8
Supported paper and envelope dimensions
The following table lists the page sizes and print area dimensions for all supported paper and envelope sizes. For more
information about the printable areas and logical pages for PCL emulation, see “Printable areas” on page 8.
Selection Paper/envelope
dimensions
Page size
parameters
2,602 Letter 216 x
Name mm inches A B C D E F G H I
2
8.5 x 11 5100 6600 4800 6360 150 120 0 200 200
279
3,603 Legal 216 x
8.5 x 14 5100 8400 4800 8160 150 120 0 200 200
356
12,45,612 JIS B5 182 x
7.2 x 10.1 4300 6070 4000 5830 150 120 0 200 200
257
26,626 A4 (198
3
mm)
26,626 A4 (203
3
mm)
1,601 Exec 184 x
210 x
297
210 x
297
8.3 x 11.7 4960 7014 4676 6778 142 118 0 160 200
8.3 x 11.7 4960 7014 4676 6778 80 118 0 160 200
7.25 x 10.5 4350 6300 4050 6060 150 120 0 200 200
267
13,613 A5 148 x
5.83 x 8.27 3496 4960 3196 4720 142 118 0 200 200
210
Dimensions by area (pels)
Paper
1
300 Oficio
(Mexico)
4 or 10 Folio 216 x
216 x
340
8.5 x 13.4 5100 8040 4800 7800 150 120 0 200 200
8.5 x 13 5100 7800 4800 7560 150 120 0 200 200
330
101 Universal 216 x
356
8.5 x 14 18005100
1800-
4
8502
1500-
4
4800
1500-
4
8202
75 60 0 100 100
4
Envelope
90 DL 220 x
8.66 x 4.33 2598 5196 2314 4960 142 118 0 200 200
110
1
Pel dimensions are for 600 dpi.
2
Page Size Parameters are explained in the Page Control table in the PCL chapter in the Printer Language and Interfaces
Technical Reference.
3
The width of the logical page for A4 paper can be changed from the printer control panel or your software application.
4
For the Universal paper size, the area dimensions are listed in pel ranges.
5
Paper ID 99 will be supported for backward compatibility with other Lexmark printers. Paper ID 99 has the same logical
paper size as ID 100 (compatible with HP LaserJet 5Si/5SiMx) but is 8 pels wider than the Lexmark 4039.
Note: The explanation of the printable area assumes the Print Area menu item is set to Normal. For more information, see
“Print Area Menu Item” in the PCL chapter in the Printer Language and Interfaces Technical Reference.
Printer Control Language (PCL) page formatting
9
Selection Paper/envelope
dimensions
Dimensions by area (pels)
1
Page size
parameters
91 C5 229 x
Name mm inches A B C D E F G H I
2
9.02 x 6.38 3826 5408 3542 5172 142 118 0 200 200
162
99d, 100
B5 Envelope 250 x
9.84 x 6.93 4156 5904 3872 5668 142 118 0 200 200
176
600 Other
Envelope
89 9 (Com 9) 98 x 225 8.875
229 x
356
9 x 14 5100 8400 4800 8160 0 200 200
2324 5324 2024 5084 150 120 0 200 200
x3.875
81 10 (Com 10) 241 x
9.5 x 4.125 2474 5700 2174 5460 150 120 0 200 200
105
80 7 3/4
98 x 191 3.875 x7.5 2324 4500 2024 4260 150 120 0 200 200
(Monarch)
1
Pel dimensions are for 600 dpi.
2
Page Size Parameters are explained in the Page Control table in the PCL chapter in the Printer Language and Interfaces
Technical Reference.
3
The width of the logical page for A4 paper can be changed from the printer control panel or your software application.
4
For the Universal paper size, the area dimensions are listed in pel ranges.
5
Paper ID 99 will be supported for backward compatibility with other Lexmark printers. Paper ID 99 has the same logical
paper size as ID 100 (compatible with HP LaserJet 5Si/5SiMx) but is 8 pels wider than the Lexmark 4039.
Note: The explanation of the printable area assumes the Print Area menu item is set to Normal. For more information, see
“Print Area Menu Item” in the PCL chapter in the Printer Language and Interfaces Technical Reference.
Printer Control Language (PCL) page formatting
10
Printer Job Language (PJL)
PJL commands information
Your printer supports complete PJL commands, including certain commands that cause the printer to enter PCL
emulation, PostScript emulation, and Personal Printer Data Stream (PPDS).
For a complete listing with descriptions of PJL commands, see the Printer Languages and Interfaces Technical
Reference.
To determine which commands your printer supports, see “Appendix B: PJL support” on page 32.
Printer Job Language (PJL)
11
PostScript (PS) emulation
Your printer supports complete PostScript emulation supplemental operators. For full descriptions in detail for these
operators, refer to the PostScript emulation chapter in the Printer Languages and Interfaces Technical Reference.
To determine which commands your printer supports, see “Appendix C: PostScript support” on page 79.
Paper sizes supported
= Supported
X = Not supported
Paper sizes
Printer models
Size Literal name Size (mm) Size (inches) Size (points) C540n, C543dn,
C544n/dn/dw/dtn
Letter letter 215.9 x 279.4 8.5 x 11.0 612 x 792
Legal legal 215.9 x 355.6 8.5 x 14.0 612 x 1008
JIS B5 b5* 182.0 x 257.0 7.2 x 10.1 516 x 729
A4 a4 210.0 x 297.0 8.3 x 11.7 595 x 842
Executive executive
page
A5 a5 148.0 x 210.0 5.83 x 8.27 419 x 595
11 x 17 ledger 431.8 x 279.4 17 x 11 1224 x 792 X X
Oficio oficio 215.9 x 340.4 8.5 x 13.4 612 x 965
Folio folio 215.9 x 330.2 8.5 x 13.0 612 x 936
184.2 x 266.7 7.25 x 10.5 522 x 756
(Lexmark
unique size)
612 x 972
(official
PostScript
size)
X546dtn MFP
Universal universal 216 x 356 8.5 x 14 612 x 1008
* This is a Japanese Industry Standard (JIS) paper size. The same named designation is used by JIS and International Standards
Organization (ISO) for different paper sizes.
PostScript (PS) emulation
12
PostScript paper tray support
When the printer receives one of the operators listed in “Tray selected with tray operators” on page 13, it performs
the actions listed as follows. This paper tray selection process ends as soon as a suitable paper source is chosen and
paper is fed from this tray.
• The printer checks the value of manualfeed in statusdict and the ManualFeed page device parameter. If either one
is true, the printer sends a message to load the requested size in the manual feed tray or multipurpose feeder.
• The PageSize Policy is set to 0 by means of setpagedevice.
• The printer checks the paper size loaded in the current active source to determine if it matches the requested size.
If the sizes match, the paper is fed from the active source.
Note: The current active tray is the last source that was selected from the printer control panel or by the printer
language.
• If the requested size and the size loaded in the active source do not match, the sources are searched in the order
defined by the Priority array in the InputAttributes dictionary in the pagedevice dictionary.
• If the requested media size is not found by the previous search, the following search order is used:
– Tray 1
– Optional 650-sheet duo drawer (Tray 2)
– Optional 550-sheet tray (Tray 3)
– Multipurpose feeder
• If the requested size cannot be located in any automatic source, a configurationerror is issued and the job is flushed.
For printers that support automatic duplexing:
• Automatic duplexing is not supported for custom-size paper or for envelopes in the multipurpose feeder. Automatic
duplexing is supported from the multipurpose feeder for all other papers.
• If the paper source is changed before the back side of a duplexed page prints, a blank back page prints, the paper
source changes, and the information for the back side of the page is printed on the front side of a page sent from
the new paper source.
When these operators are used, it is equivalent to executing the following PostScript emulation sequence:
<< /PageSize [x y]/ImagingBBox null /Policies << /PageSize 0>> >>
setpagedevice
where x y are the PageSize in points.
Tray selected with tray operators
= Supported
X = Not supported
Operator Tray selected (corresponding image size is set) C540n, C543dn, C544n/dn/dw/dtn X546dtn MFP
a4tray tray with A4-size paper
a5tray tray with A5-size paper
Printer models
b5tray tray with B5-size paper
customtray tray with custom-size paper X X
executivetray tray with executive-size paper
PostScript (PS) emulation
13
= Supported
X = Not supported
Operator Tray selected (corresponding image size is set) C540n, C543dn, C544n/dn/dw/dtn X546dtn MFP
foliotray tray with folio-size paper
Printer models
ledgertray tray with 279.4 x 431.8-mm (11 x 17-in.) paper with
landscape orientation
legaltray tray with legal-size paper
lettertray tray with letter-size paper
oficiotray tray with oficio-size paper
X X
PostScript envelope size support
The literal names in “Envelope sizes supported” on page 14 are also supported as operators in userdict. These
operators change the image size, but do not change the active paper source. Therefore, when these operators are used,
part of the image may be clipped.
When these literal names are used as operators, it is equivalent to executing the following PostScript emulation
sequence. The following example uses a 3.875 x 7.5 envelope.
<</Policies <</PageSize 7>> /PageSize [279 540]>> >>setpagedevice
Envelope sizes supported
= Supported
X = Not supported
Envelope sizes
Printer models
Size name Literal name Size (mm) Size (inches) Size (points) C540n, C543dn,
C544n/dn/dw
/dtn
7 3/4 3.875x7.5envel
ope
Commercial 9 3.875x8.875env
elope
Commercial 10 4.125x9.5envel
ope
International DL 110x220envelope110 x 220 4.33 x 8.66 312 x 624
International C5 162x229envelope162 x 229 6.38 x 9.01 459 x 649
International B5 176x250envelope176 x 250 6.93 x 9.84 499 x 708
Other envelope otherenvelope 229.11 x 355.6 9.02 x 14 612 x 996
98.4 x 190.5 3.875 x 7.5 279 x 540
98.4 x 225.4 3.875 x 8.875 279 x 639
104.8 x 241.3 4.125 x 9.5 297 x 684
PostScript (PS) emulation
X546dtn MFP
14
= Supported
X = Not supported
Envelope sizes
Printer models
Size name Literal name Size (mm) Size (inches) Size (points) C540n, C543dn,
C544n/dn/dw
/dtn
otherenvelope Other 296.93 x 427.48 11.69 x 16.83 841 x 842 X X
X546dtn MFP
Literal names supported
= Supported
X = Not Supported
Literal names
Literal name Compatible literal name C540n, C543dn, C544n/dn/dw/dtn X546dtn MFP
monarchenvelope 3.875x7.5envelope
com10envelope 4.125x9.5envelope
dlenvelope 110x220envelope
c5envelope 162x229envelope
b5envelope 176x250envelope
Printer models
PostScript envelope tray support
If manualfeed in statusdict and the ManualFeed page device parameter are false when the printer receives one of the
envelopetray operators listed in “Envelopetray operator selections” on page 16, then the printer:
• Sets the PageSize Policy to 0.
• Checks the active source to see if it matches the requested envelope size. If the sizes match, the envelope is fed
from the active source.
Note: The active source is the last source selected from the printer control panel or data stream.
• If the requested size and the size loaded in the active source do not match, the sources are searched in the order
defined by the Priority array in the InputAttributes dictionary in the pagedevice dictionary.
• If the requested media size is not found by the previous search, the following search order is used:
– Envelope Feeder
– Multipurpose Feeder
• If the requested size and type are not available from any automatic source, you are prompted to load the requested
envelope size and type in the manual feed source.
• If the size is still not available, a configurationerror is issued and the print job is flushed.
If manualfeed or ManualFeed is true, the printer prompts you to load the requested size manually. If no manual feed
exists on the printer, a rangecheck error message is generated
PostScript (PS) emulation
15
The envelope tray the printer selects when it receives an envelopetray operator is listed in “Envelopetray operator
selections” on page 16. These operators are equivalent to executing the following PostScript emulation sequence:
<</PageSize [x y] /ImagingBBox null /Policies<</PageSize 0>> >>
setpagedevice
where x y are the PageSize in points.
Envelopetray operator selections
= Supported
X = Not supported
Tray operators
Printer models
Operator Tray selected (Corresponding image size is
set)
110x220envelopetray tray with 110 x 220 size envelopes
dlenvelopetray tray with 110 x 220 size envelopes
162x229envelopetray tray with 162 x 229 size envelopes
c5envelopetray tray with 162 x 229 size envelopes
176x250envelopetray tray with 176 x 250 size envelopes
b5envelopetray tray with 176 x 250 size envelopes
3.875x7.5envelopetray tray with 3.875 x 7.5 size envelopes
monarcenvelopetray tray with 3.875 x 7.5 size envelopes
3.875x8.875envelopetray tray with 3.875 x 8.875 size envelopes
4.125x9.5envelopetray tray with 4.125 x 9.5 size envelopes
com10envelopetray tray with 4.125 x 9.5 size envelopes
otherenvelopetray tray with other size envelopes
C540n, C543dn, C544n/dn/dw/dtn X546dtn MFP
PostScript (PS) emulation
16
Printer specifications
This chapter lists printer specifications and information about hardware, environmental conditions, and power
requirements.
Airflow requirement
The room should meet ASHRAE 62—1989 standards.
Noise emission levels
The following measurements were made in accordance with ISO 7779 and reported in conformance with ISO 9296.
C54x Color Laser Series
1-meter average sound pressure, dBA
Status
Printing (Simplex) 47 47 49 49
Printing (Auto duplex) Inapplicable 50 Inapplicable 51
Standby (Idle without
Power Saver)
Quiet Mode (Simplex) 46 46 46 46
Note: Measurements apply to 300-dpi, 600-dpi, and 1200-dpi printing.
C540n C543dn C544n C544dn, C544dw, C544dtn
Inaudible Inaudible Inaudible Inaudible
X546dtn MFP
Status 1-meter average sound p ressure, dBA Declared sound power levels, Bels
Printing (Simplex Mono) 47 6.2
Printing (Simplex Color) 48 6.3
Printing (Duplex Mono) 50 6.5
Printing (Duplex Color) 51 6.5
Copy (ADF Mono) 49 6.4
Copy (ADF Color) 50 6.5
Scan (ADF Mono) 45 6.1
Scan (ADF Color) 45 6.1
Standby (Idle without Power Saver) Inaudible Inaudible
Quiet Mode (Simplex Mono) 45 5.9
Quiet Mode (Simplex Color) 45 6.0
Note: Measurements apply to 300-dpi, 600-dpi, and 1200-dpi printing.
Printer specifications
17
Electrical specifications
Printer model Electrical specification
C54x low voltage models* 100–127 V at 47–63 Hz, nominal
90–137 V, extreme
C54x 100 volt model 100 V at 47–63 Hz, nominal
90–110 V, extreme
C54x high voltage models 220–240 V at 47–63 Hz (not available in all countries)
198–259 V, extreme
X546dtn MFP low voltage models 100–110 V (Japan) at 50–60 Hz, nominal
100–127 V at 50–60 Hz, nominal
90–110 V (Japan), extreme
90–137 V, extreme
X546dtn MFP high voltage models 220–240 V at 50–60 Hz, nominal (not available in all countries)
198–264 V, extreme
* Using a 220–110 power converter with 110 V printer is not recommended.
Warning—Potential Damage: Lexmark recommends that you do not use voltage converters with printers.
Power requirements
The following tables list the nominal average power requirements (including fuser power).
Lexmark C54x nominal average power requirements
Printing states C540n, C543dn C544n, C544dn, C544dw, C544dtn
Average power while printing continuously
1-sided (simplex)
2-sided (duplex)
Average power while idle
Power Saver on
Ready mode
Max current while printing
100–110 V
110–127 V
220–240 V
Note: Automatic duplex is not supported on the C540n and C544n.
480 W
340 W
18 W
34 W
8.7 A
7.6 A
4.1 A
500 W
340 W
18 W
36 W
8.7 A
7.6 A
4.1 A
Printer specifications
18
Lexmark X546dtn MFP nominal average power requirements
Printing states X546dtn
Printing continuously (simplex) 540 W
Printing continuously (duplex) 370 W
Copying continuously 510 W
Scanning 60 W
Average power while idle
Power Saver Mode/Sleep Mode
Standby Mode
Max (Average) current while printing
100--110 V
115--127 V
220--240 V
Physical specifications
Lexmark C54x dimensions
C540n
C543dn
C544n
C544dn
C544dw
C544dtn
C544dtn with optional 650-sheet duo
drawer
23 W
50 W
8.1 A
7.0 A
3.6 A
Height Width Depth Weight
291.2 mm (11.5 in.) 423.9 mm (16.7 in.) 399.7 mm (15.7 in.) 21 kg (46.2 lb)
422.3 mm (16.6 in.) 423.9 mm (16.7 in.) 416.4 mm (16.4 in.) 25 kg (54.9 lb)
Input option for Lexmark C54x Models
Option name Height Width Depth Weight
650-sheet duo drawer 133 mm (5.2 in.) 423.9 mm (16.7 in.) 416.4 mm (16.4 in.) 4 kg (8.7 lb)
Lexmark X546dtn MFP dimensions
Height Width Depth Weight
X546dtn 569 mm (23.5 in.) 440 mm (17.32 in.) 537 mm (21.14 in.) 31.37 kg (69.15 lb)
X546dtn with optional 650-sheet duo
drawer
X546dtn with optional 550-sheet drawer 133 mm (5.2 in.) 423.9 mm (16.6 in.) 416.4 mm (16.4 in.) 4.16 kg (9.15 lb)
133 mm (5.2 in.) 423.9 mm (16.7 in.) 416.4 mm (16.4 in.) 4.16 kg (9.15 lb)
Printer specifications
19
Clearance requirements
Lexmark C540n, C543dn, C544n/dn/dw/dtn
Model Left side Right side Front Rear Top
C540n, C543dn, C544n, C544dn,
C544dw
C544dtn 76.2 mm (3 in.) 254 mm (10 in.) 508 mm (20 in.) 101.6 mm (4 in.) 254 mm (10 in.)
Note: Allow an additional 133 mm (5.2 in.) clearance above the C54x for an optional drawer.
76.2 mm (3 in.) 152.4 mm (6 in.) 508 mm (20 in.) 101.6 mm (4 in.) 254 mm (10 in.)
Lexmark X546dtn MFP
Model Left side Right side Front Rear Top
X546dtn 76.2 mm (3 in.) 254 mm (10 in.) 508 mm (20 in.) 101.6 mm (4 in.) 360 mm (14 in.)
Note: Allow an additional 133 mm (5.2 in.) clearance above the X546dtn for an optional input drawer.
Environmental conditions
Note: When shipping or storing printers, always pack the printer supplies (cartridges and photoconductors, for examp le)
separately.
Air temperature ranges
Printer model Operating value Shipping value Storage (unpacked)
C540n, C543dn, C544n/dn/dw/dtn 15.6–32.2°C (60–90°F) -40–43.3°C (-40–110°F) 0–40°C (32–104°F)
X546dtn MFP 15.6–32.2°C (60–90°F) -40–43.3°C (-40–110°F) 0–40°C (32–104°F)
Humidity ranges
Printer model Operating value Shipping value Storage value
C540n, C543dn, C544n/dn/dw/dtn 8%–80%* 8%–80% 8%–80%
X546dtn MFP 8%–80%* 8%–80% 8%–80%
* Approaching 32°C (90°F) the maximum relative humidity is 60%.
Altitude specifications and atmospheric pressure
Altitude specifications
Altitude (above sea level)
Printer model Operating Shipping/storage
C540n, C543dn, C544n/dn/dw/dtn 0–3048 M (10,000 ft.) 10,300 M (34,000 ft.)
XC546dtn MFP 0–3048 M (10,000 ft.) 10,300 M (34,000 ft.)
Printer specifications
20
Atmospheric Pressure
74.6 kPa
Printer specifications
21
Appendix A: PCL support
PCL emulation commands
= Supported
X = Not supported
Command Function
Decimal 8 BS, Backspace
Decimal 9 HT, Horizontal Tab
Decimal 10 LF, Line Feed
Decimal 12 FF, Form Feed
Decimal 13 CR, Carrier Return
Decimal 14 SO, Select Secondary Font
Printer model
C540n, C543dn, C544n,
C544dn,C544dw,
C544dtn
X546dtn
Decimal 15 SI, Select Primary Font
Decimal 32 SP, Space
ESC
ESC
ESC
ESC
ESC
E
Y
Z
z
&a#C
Printer Reset
Display Functions-On
Display Functions-Off
Print Test Page X X
Horizontal Cursor Position
(in Columns)
ESC
ESC
&a#G
&a#H
Duplex Page Side Selection
Horizontal Cursor Position
(in Decipoints)
ESC
ESC
ESC
ESC
&a#L
&a#M
&a#N
&a#P
Set Left Margin
Set Right Margin
Negative Motion X X
Print Direction
ESC
ESC
&a#R
&a#V
Vertical Cursor Position (in Rows)
Vertical Cursor Position
(in Decipoints)
Appendix A: PCL support
22
= Supported
X = Not supported
Command Function
ESC
&b#M
Monochrome Print Mode
Printer model
C540n, C543dn, C544n,
C544dn,C544dw,
C544dtn
X546dtn
ESC
&b#W[data]
ESC
&c#T
ESC
&d@
ESC
&d#A
ESC
&d#D
ESC
&f#F
ESC
&f#G
ESC
&f#O
ESC
&f#W
ESC
&f#S
ESC
&f#X
ESC
&f#Y
ESC
&k#G
ESC
&k#H
Configuration Command X X
Character Text Path Direction
Underline-Disable
Number of Collated Copies
Underline-Enable
Set Universal Height
Set Universal Width
Set Universal Feed Direction
Set Universal Custom Name
Push / Pop Cursor Position
Macro Control
Set Macro ID
Set Line Termination
Set Horizontal Motion Index
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
&k#S
&k#W
&l#A
&l#C
&l#D
&l#E
&l#F
&l#G
&l#H
&l#L
&l#O
Select Primary and Secondary Pitch
Text Scale Mode X X
Set Page Size
Set Vertical Motion Index
Set Line Spacing
Set Top Margin
Set Text Length
Set Output Bin
Paper Source
Skip Perforation
Select Orientation
Appendix A: PCL support
23
= Supported
X = Not supported
Command Function
Printer model
C540n, C543dn, C544n,
C544dn,C544dw,
C544dtn
X546dtn
ESC
&l#M(b)
ESC
&l#P
ESC
&l#S
ESC
&l#U
ESC
&l#X
ESC
&l#Z
ESC
&l1T
ESC
&n#W [operation] [string id]
ESC
&p#C
ESC
&p#I
ESC
&p#S
ESC
&p#X[data]
ESC
&r#F
ESC
&s#C
Paper Type X X
Set Page Length
Simplex/Duplex Print
Long-Edge Offset Registration
Number of Copies
Short-Edge Offset Registration
Job Separation X X
Alphanumeric ID
Palette Control
Palette Control ID
Select Palette
Transparent Print Data
Flush All Pages
End-Of-Line Text Wrap
ESC
&t#P
ESC
&u#D
ESC
(#
ESC
(#X
ESC
(3@
ESC
(f#W[data]
ESC
(s#B
ESC
(s#H
ESC
(s#P
ESC
(s#S
ESC
(s#T
Text Parsing Method
Unit of Measure
Primary Font Symbol Set
Select Primary Download Font (by
Font ID)
Select Default Primary Font
Define Symbol Set
Primary Font Stroke Weight
Primary Font Pitch
Primary Font Spacing
Primary Font Style
Primary Font Typeface Selection
Appendix A: PCL support
24
= Supported
X = Not supported
Command Function
ESC
(s#V
Primary Font Height (Point Size)
Printer model
C540n, C543dn, C544n,
C544dn,C544dw,
C544dtn
X546dtn
ESC
(s#W[data]
ESC
)#
ESC
)#X
ESC
)3@
ESC
)s#B
ESC
)s#H
ESC
)s#P
ESC
)s#S
ESC
)s#T
ESC
)s#V
ESC
)s#W[data]
ESC
*b#M
ESC
*b#V[data]
ESC
*b#W[data]
ESC
*b#Y
Load Character
Secondary Font Symbol Set X X
Select Secondary Download Font
X X
(by Font ID)
Select Default Secondary Font
Secondary Font Stroke Weight X X
Secondary Font Pitch X X
Secondary Font Spacing X X
Secondary Font Style X X
Secondary Font Typeface Selection X X
Secondary Font Height (Point Size) X X
Load Font Header
Set Raster Compression Mode
Transfer Raster Data (by Plane)
Transfer Raster Data
(by Row / Block)
Y Offset
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
*c#A
*c#B
*c#D
*c#E
*c#F
*c#G
*c#H
*c#K
*c#L
Horizontal Rectangle Size
(in PCL Units)
Verti cal Rectangle Size (in PCL Units)
Set Font ID
Set Character Code
Font Control
Area Fill ID
Horizontal Rectangle Size
(in Decipoints)
GL/2 Horizontal Plot Size (in Inches)
GL/2 Vertical Plot Size (in Inches)
Appendix A: PCL support
25
= Supported
X = Not supported
Command Function
ESC
*c#P
Fill Rectangular Area
Printer model
C540n, C543dn, C544n,
C544dn,C544dw,
C544dtn
X546dtn
ESC
*c#Q
ESC
*c#R
ESC
*c#S
ESC
*c0T
ESC
*c#V
ESC
*c#W[data]
ESC
*c#X
ESC
*c#Y
ESC
*l#O
ESC
*l#R
ESC
*l#W[data]
ESC
*m#W[data]
Pattern Control
Symbol Set ID Code
Symbol Set Control
Set Picture Frame Anchor Point
Vertical Rectangle Size
(in Decipoints)
User-Defined Pattern
Picture Frame Horizontal Size
(in Decipoints)
Picture Frame Vertical Size
(in Decipoints)
Logical Operation
Pixel Placement
Color Lookup Tables X X
Download Dither Matrix
ESC
*o#M(b)
ESC
*o#Q
ESC
*o#W[data]
ESC
*p#P
ESC
*p#R
ESC
*p#X
ESC
*p#Y
ESC
*r#A
ESC
*r#F
ESC
*r#S
ESC
*r#T
Print Quality X X
Mechanical Print Quality X X
Driver Configuration Command
Push / Pop Palette
Set Pattern Reference Point
Horizontal Cursor Position
(in PCL Units)
Vertical Cursor Position
(in PCL Units)
Start Raster Graphics
Raster Graphics Presentation Mode
Raster Width (Source)
Raster Height (Source)
Appendix A: PCL support
26
= Supported
X = Not supported
Command Function
ESC
*r#U
Simple Color
Printer model
C540n, C543dn, C544n,
C544dn,C544dw,
C544dtn
X546dtn
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ESC
*rB
*rC
*s#I
*s1M
*s#T
*s#U
*s#X
*t#H
*t#I
*t#J
*t#K
*t#R
*t#V
*g#W
*v#A
End Raster Graphics (Version B)
End Raster Graphics (Version C)
Inquire Status Readback Entity
Free Space
Set Status Readback Location Type
Set Status Readback Location Unit
Echo
Raster Width Destination
Gamma Correction
Render Algorithm X X
Scale Algorithm X X
Raster Resolution
Raster Height Destination
Set Raster Configuration X X
Color Component One
ESC
*v#B
ESC
*v#C
ESC
*v#I
ESC
*v#N
ESC
*v#O
ESC
*v#S
ESC
*v#T
ESC
*v#W[data]
ESC
*i#W[data]
ESC
9
Color Component Two
Color Component Three
Assign Color Index
Source Transparency Mode
Pattern Transparency Mode
Foreground Color
Select Current Pattern
Configure Image Data
Viewing Illuminant X X
Clear Horizontal Margins
Appendix A: PCL support
27
= Supported
X = Not supported
Command Function
ESC
=
Half Line-Feed
Printer model
C540n, C543dn, C544n,
C544dn,C544dw,
C544dtn
X546dtn
ESC
%#A
ESC
%#B
ESC
%- 12345X
Enter PCL Emulation
Enter GL/2 Language
Note: The values of -1, 2, and 3 are
not supported by any of the printers
included in this document.
Universal Exit Language (UEL) /
Start of PJL
GL/2 commands
= Supported
X = Not supported
Command Function
AA Arc Absolute
AC Anchor Corner
Printer model
C540n, C543dn, C544n,
C544dn,C544dw,
C544dtn
X546dtn
AD Define Alternate Font
AR Arc Relative
AT Arc Absolute Three Point
BR Bezier Relative
BZ Bezier Absolute
CF Character Fill
CI Circle
CO Comment
CP Character Plot
CR Set Color Range
DF Default
DI Absolute Direction
Appendix A: PCL support
28
= Supported
X = Not supported
Command Function
DR Relative Direction
DT Define Label Terminator
DV Define Variable Text Path
EA Edge Rectangle Absolute
EP Edge Polygon
ER Edge Rectangle Relative
ES Extra Space
EW Edge Wedge
FI Primary Font
FN Secondary Font
Printer model
C540n, C543dn, C544n,
C544dn,C544dw,
C544dtn
X546dtn
FP Fill Polygon, Odd/Even
FP Fill Polygon, Non-Zero Winding
FT Fill Type
FT Fill Type - 22
FT Fill Type - 9
IN Initialize
IP Input P1 and P2
IR Input Relative P1 and P2
IW Input Window
LA Line Attributes
LB Label, Default Terminator = '03'x
LO Label Origin
LO Uses PCL Label Origin
LT Line Type
MC Logical Operation
NP Number of Pens
Appendix A: PCL support
29
= Supported
X = Not supported
Command Function
PA Plot Absolute
PC Set Pen Color
PD Pen Down
PE Polyline Encoded
PM Polygon Mode
PP Pixel Placement
PR Plot Relative
PU Pen Up
PW Pen Width
RA Fill Rectangle Absolute
Printer model
C540n, C543dn, C544n,
C544dn,C544dw,
C544dtn
X546dtn
RF Define Raster Fill
RO Rotate Coordinate System
RR Fill Rectangle Relative
RT Arc Relative Three Point
SA Select Alternate Font
SB Scalable/Bitmapped Fonts
SC Scale
SD Define Standard Font
SI Absolute Character Size
SL Character Slant
SM Symbol Mode
SP Select Pen
SR Relative Character Size
SS Select Standard Font
SV Screened Vectors
SV Screened Vectors - 9, level
Appendix A: PCL support
30
= Supported
X = Not supported
Command Function
TD Transparent Data
TM Threshold Matrix
TR Transparency Mode
UL User Defined Line
WG Wedge Fill
WU Pen Width Units
Printer model
C540n, C543dn, C544n,
C544dn,C544dw,
C544dtn
X546dtn
Appendix A: PCL support
31
Appendix B: PJL support
Common variables for both printer languages
= Supported
X = Not supported
C540n, C543n,
Variable name
AUTOCONT
AUTOSELECT X X
BINDING
BITSPERPIXEL X X
CLEARABLEWARNINGS
CONTEXTSWITCH X X
COPIES
C544n/dn/dw/dtn
Printer model
X546dtn MFP
CPLOCK
DENSITY
DISKLOCK X X
DUPLEX
ECONOMODE X X
FORMATTERNUMBER
FORMLINES
HELDJOBTIMEOUT X X
HOLD X X
HOLDKEY X X
HOLDTYPE X X
IMAGEADAPT X X
INTRAY1 X X
INTRAY2
INTRAY3
INTRAY4
INTRAY5
Appendix B: PJL support
32
= Supported
X = Not supported
C540n, C543n,
Variable name
INTRAY1SIZE
INTRAY2SIZE
INTRAY3SIZE
INTRAY4SIZE
INTRAY5SIZE
IOBUFFER X X
IOSIZE X X
JOBNAME X
LANG
LOWTONER
MANUALFEED
C544n/dn/dw/dtn
Printer model
X546dtn MFP
MEDIASOURCE X X
MEDIATYPE
MPTRAY
ORIENTATION
OUTBIN
PAGEPROTECT
PAPER
PARALLEL X X
PASSWORD
PERSONALITY
POWERSAVE
POWERSAVETIME
PRINTQUALITY X X
QTY
RENDERMODE X X
REPRINT
Appendix B: PJL support
33
= Supported
X = Not supported
C540n, C543n,
Variable name
RESOLUTION
RESOURCESAVE
RESOURCESAVESIZE X X
RET X X
STRINGCODESET
TIMEOUT
USERNAME X X
WIDEA4
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Lexmark-unique PJL variables for both printer languages
= Supported
X = Not supported
C540n, C543dn,
Variable name
LACTIVEBINRESET X X
LADVANCEDSTATUS X X
LALARMCONTROL X
LAUTOCRLF
LAUTOLFCR
LBAYERSCREENLIMIT
LBLANKPAGES
LBONDLOADING
LBONDOUTBIN X X
LBONDTEXTURE
LBONDWEIGHT
C544n/dn/dw/dtn
Printer model
X546dtn MFP
LCANCEL
LCARDSTOCKLOADING X X
LCARDSTOCKOUTBIN X X
Appendix B: PJL support
34
= Supported
X = Not supported
C540n, C543dn,
Variable name
LCARDSTOCKTEXTURE
LCARDSTOCKWEIGHT
LCOLLATION
LCOLORCORRECTION X X
LCOLOREDLOADING
LCOLOREDOUTBIN X X
LCOLOREDTEXTURE
LCOLOREDWEIGHT
LCUSTOMPAPERUNITS
LCUSTOMPAPERWIDTH
LCUSTOMPAPERHEIGHT
C544n/dn/dw/dtn
Printer model
X546dtn MFP
LCUSTOMPAPERFEED
LCUSTOMTYPE1LOADING
LCUSTOMTYPE1MEDIA
LCUSTOMTYPE1NAME
LCUSTOMTYPE1OUTBIN X X
LCUSTOMTYPE1TEXTURE
LCUSTOMTYPE1WEIGHT
LCUSTOMTYPE2LOADING
LCUSTOMTYPE2MEDIA
LCUSTOMTYPE2NAME
LCUSTOMTYPE2OUTBIN X X
LCUSTOMTYPE2TEXTURE
LCUSTOMTYPE2WEIGHT
LCUSTOMTYPE3LOADING
LCUSTOMTYPE3MEDIA
LCUSTOMTYPE3NAME
Appendix B: PJL support
35
= Supported
X = Not supported
C540n, C543dn,
Variable name
LCUSTOMTYPE3OUTBIN X X
LCUSTOMTYPE3TEXTURE
LCUSTOMTYPE3WEIGHT
LCUSTOMTYPE4LOADING
LCUSTOMTYPE4MEDIA
LCUSTOMTYPE4NAME
LCUSTOMTYPE4OUTBIN X X
LCUSTOMTYPE4TEXTURE
LCUSTOMTYPE4WEIGHT
LCUSTOMTYPE5LOADING
LCUSTOMTYPE5MEDIA
C544n/dn/dw/dtn
Printer model
X546dtn MFP
LCUSTOMTYPE5NAME
LCUSTOMTYPE5OUTBIN X X
LCUSTOMTYPE5TEXTURE
LCUSTOMTYPE5WEIGHT
LCUSTOMTYPE6LOADING
LCUSTOMTYPE6MEDIA
LCUSTOMTYPE6NAME
LCUSTOMTYPE6OUTBIN X X
LCUSTOMTYPE6TEXTURE
LCUSTOMTYPE6WEIGHT
LDOWNLOADTARGET
LDUPLICATEHELDJOBS X X
LECOMODE
LENVELOPEOUTBIN X X
LENVELOPETEXTURE
LENVELOPEWEIGHT
Appendix B: PJL support
36
= Supported
X = Not supported
C540n, C543dn,
Variable name
LESCCHAR
LFAXJOBWAITFORTONER X X
LFAXREDIAL X
LFAXREDIALFREQUENCY X
LFAXRESOLUTION X
LFAXTRANSMISSIONLOG X
LGLOSSYLOADING
LGLOSSYOUTBIN X X
LGLOSSYTEXTURE
LGLOSSYWEIGHT
LHEAVYGLOSSYLOADING X X
C544n/dn/dw/dtn
Printer model
X546dtn MFP
LHEAVYGLOSSYOUTBIN X X
LHEAVYGLOSSYTEXTURE X X
LHEAVYGLOSSYWEIGHT X X
LHEAVYPAPERLOADING
LHEAVYPAPEROUTBIN X X
LHEAVYPAPERTEXTURE
LHEAVYPAPERWEIGHT
LHELDJOBPRTORDER X X
LHONORINIT X X
LIMAGEBRIGHTNESS X X
LIMAGECONTRAST X X
LIMAGEENHANCE X X
LIMAGEENHANCETYPE X X
LIMAGEORIENTATION
LINFEEDER X X
LINMPFEEDERSIZE
LJAMRECOVERY
LJOBPARKPERSIST X X
Appendix B: PJL support
37
= Supported
X = Not supported
C540n, C543dn,
Variable name
LJOBWAITFORSUPPLIES X X
LLABELSLOADING X X
LLABELSOUTBIN X X
LLABELSTEXTURE
LLABELSWEIGHT
LLASTTRAYRENUMBER
LLETTERHEADLOADING
LLETTERHEADOUTBIN X X
LLETTERHEADTEXTURE
LLETTERHEADWEIGHT
LLIGHTPAPERLOADING
C544n/dn/dw/dtn
Printer model
X546dtn MFP
LLIGHTPAPEROUTBIN X X
LLIGHTPAPERTEXTURE
LLIGHTPAPERWEIGHT
LLINEDETAIL
LMANUALENVELOPESIZE
LMANUALENVELOPETYPE
LMANUALPAPERSIZE
LMANUALPAPERTYPE
LMPFEEDERPAPERTYPE
LMPFEEDERRENUMBER
LMULTIPAGEBORDER
LMULTIPAGEORDER
LMULTIPAGEPRINT
LMULTIPAGEVIEW
LNPAP
LOVERFLOWOUTBIN X X
Appendix B: PJL support
38
= Supported
X = Not supported
C540n, C543dn,
Variable name
LOVERFLOWTIMER X X
LOUTBINCONFIG X X
LPAGECOUNT
LPAGEMODE
LPAPERSOURCE
LPLAINOUTBIN X X
LPLAINTEXTURE
LPLAINWEIGHT
LPOWERSAVER
LPPDS
LPPDSFORMLINES
C544n/dn/dw/dtn
Printer model
X546dtn MFP
LPPDSLINESPERINCH
LPREPRINTEDLOADING
LPREPRINTEDOUTBIN X X
LPREPRINTEDTEXTURE
LPREPRINTEDWEIGHT
LPRINTBUFFER
LPRINTSCREENS
LQUIETMODE
LRECYCLEDLOADING
LRECYCLEDMEDIA
LRECYCLEDOUTBIN X X
LRECYCLEDTEXTURE
LRECYCLEDWEIGHT
LREPEATPRINTLIMIT X X
LRESET X X
LRESOURCESAVE
Appendix B: PJL support
39
= Supported
X = Not supported
C540n, C543dn,
Variable name
LROUGHENVELOPELOADING X X
LROUGHENVELOPEOUTBIN X X
LROUGHENVELOPETEXTURE X X
LROUGHENVELOPEWEIGHT X X
LROUGHPAPERLOADING X X
LROUGHPAPEROUTBIN X X
LROUGHPAPERTEXTURE
LROUGHPAPERWEIGHT
LSEPARATORSHEETS
LSEPARATORSOURCE
LSMALLFONTENHANCER X X
LSSGALVO X X
C544n/dn/dw/dtn
Printer model
X546dtn MFP
LSTANDARDOUTBINNAME
LSTROKEWIDTH
LSUBSTITUTESIZE X X
LTOPBINROTATE X X
LTRANSPARENCYOUTBIN X X
LTRANSPARENCYTEXTURE
LTRANSPARENCYWEIGHT
LTRAY1AUTOSIZE X X
LTRAY2AUTOSIZE X X
LTRAY3AUTOSIZE X X
LTRAY4AUTOSIZE X X
LTRAY5AUTOSIZE X X
LTRAY1PAPERTYPE
LTRAY2PAPERTYPE
LTRAY3PAPERTYPE
LTRAY4PAPERTYPE
LTRAY5PAPERTYPE
Appendix B: PJL support
40
= Supported
X = Not supported
C540n, C543dn,
Variable name
LTRAY1RENUMBER
LTYPE1FONTS
LUSDEFAULTS
LVINYLLABELSLOADING X X
LVINYLLABELSOUTBIN X X
LVINYLLABELSTEXTURE X X
LVINYLLABELSWEIGHT X X
LWRITECOVERAGE
C544n/dn/dw/dtn
Printer model
Common variables for PCL emulation
= Supported
X = Not supported
Printer model
X546dtn MFP
C540n, C543dn,
Variable name
FONTNUMBER
FONTSOURCE
PITCH
PTSIZE
SYMSET
C544n/dn/dw/dtn
Printer-unique variables for PCL emulation
= Supported
X = Not supported
C540n, C543dn,
Variable name
LA4WIDTH
LASSIGNFEEDER X X
C544n/dn/dw/dtn
Printer model
8X546dtn MFP
X546dtn MFP
LASSIGNMANUALENVELOPE
Appendix B: PJL support
41
= Supported
X = Not supported
Variable name
LASSIGNMANUALPAPER
LASSIGNMPFEEDER
LASSIGNTRAY1
LASSIGNTRAY2
LASSIGNTRAY3
LASSIGNTRAY4
LASSIGNTRAY5
LBITMAPROUNDING
LCOLOREXTENSIONS
LFONTCOMPATIBILITY
LFONTPRIORITY
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Common variables for PostScript emulation
= Supported
X = Not supported
C540n, C543dn,
Variable name
JAMRECOVERY
PRTPSERRS
ADOBEMBT X X
C544n/dn/dw/dtn
Printer model
Printer-unique variables for PostScript emulation
= Supported
X = Not supported
Variable name
LPSFONTPRIORITY
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
X546dtn MFP
Appendix B: PJL support
42
Printer-unique LRESOURCE variables
= Supported
X = Not supported
C540n, C543dn,
Variable name
LDESCRIPTION
LRWLOCK
LWLOCK
C544n/dn/dw/dtn
Status Readback commands
= Supported
X = Not supported
C540n, C543dn,
Variable name
Dinquire
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Printer model
X546dtn MFP
Echo
Info
Inquire
Ustatus
Ustatusoff
USTATUS unsolicited status variables
= Supported
X = Not supported
C540n, 543dn,
Variable name
DEVICE
JOB
PAGE
C544n/dn/dw/dtn
Printer model
X546dtn MFP
TIMED
Appendix B: PJL support
43
PJL messages for auto-continuable conditions
= Supported
X = Not supported
C540n, C543dn,
Message Status code Return string
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
PPDS Font Error
Intervention Required -
Insufficient Collation
Area
Intervention Required -
Insufficient Defragment
Memory
Intervention Required -
Insufficient Memory
Intervention Required -
Insufficient Memory
Intervention Required -
Insufficient Defragment
Memory
Intervention Required -
Insufficient Defragment
Memory
30014
30016
30016
30016
30016
30016
30016
50 PPDS Font
Error
37 Insufficient
Collation Area
37 Insufficient
Defrag Memory
37 Insufficient
Memory
37 Insufficient
memory for
Flash Memory
Defragment
operation
37 Insufficient
memory, some
Held Jobs were
deleted
37 Insufficient
memory, some
Held Jobs will
not be restored
X X
X X
X X
X X
X X
X X
Intervention Required -
Insufficient Defrag
Memory
Intervention Required -
Insufficient Collation
Area
Intervention Required -
Memory Full
Intervention Required -
Configuration Change
30016
30016
30016
30016
37 Insufficient
memory for
Flash Memory
Defragment
operation
37 Insufficient
memory to
collate job
38 Memory Full
57
Configuration
Change
Appendix B: PJL support
44
X X
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Configuration Change
Intervention Required -
Held Jobs May Not Be
Restored
Intervention Required -
Held Jobs May Not Be
Restored
Intervention Required -
Complex Page
Intervention Required -
Complex Page
Intervention Required -
Parallel Error
Intervention Required -
Serial Option Error
30016
30016
30016
30017
30017
30018
30018
57
Configuration
change, some
held jobs were
not restored
Held Jobs May
Not Be Restored
Some held jobs
were not
restored
39 Complex Page
39 Complex
Page, some data
may not have
printed
54 Parallel
Error
54 Serial
option <slot #>
error
X X
X X
X X
X X
X X
X X
Intervention Required -
Standard Serial Error
Intervention Required -
Network Software Error
Intervention Required -
Standard Serial Fax
Connection Lost
Intervention Required -
Parallel Port Disabled
Intervention Required -
Parallel Port Error
Intervention Required -
Serial Option Disabled
30018
30018
30018
30018
30018
30018
54 Standard
Serial Error
54 Standard
network
software error
54 Std Ser Fax
Connection Lost
56 Parallel
Port Disabled
56 Parallel
Port [x]
Disabled
56 Serial
<slot #> Port
Disabled
Appendix B: PJL support
X X
X X
X X
X X
X X
45
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Standard Serial Disabled
Intervention Required -
Standard USB Disabled
Intervention Required Std Parallel Port Disabled
Intervention Required -
Resource Save Off
Deficient Memory
Intervention Required -
Insufficient Fax Buffer
Intervention Required -
Std Par ENA Connection
Lost
Intervention Required -
Standard Parallel Port
Disabled
Intervention Required -
Std Parallel Port Disabled
30018
30018
30018
30019
30026
30027
30027
30027
56 Standard
Serial Disabled
56 Standard USB
port disabled
56 Std Parallel
Port Disabled
35 Res Save Off
Deficient
Memory
55 Insufficient
Fax Buffer
54 Std Par ENA
Connection Lost
56 Standard
Parallel Port
Disabled
56 Std Parallel
Port Disabled
X X
X X
X X
X X
X X
X X
X X
Intervention Required -
Resolution Reduced
Intervention Required -
Print Jobs on Disk
Request
Intervention Required -
Restore Held Jobs.
Go/Stop?
Intervention Required -
Short Paper
Intervention Required -
Flash Full
Intervention Required -
Disk Full
Intervention Required -
Defective Flash
30029
30031
30031
30034
30035
30035
30036
36 Resolution
Reduced
Print Jobs on
Disk? or
Print Jobs on
Disk. Go/Stop?
Restore Held
Jobs. Go/Stop?
34 Short Paper
52 Flash Full
62 Disk Full
51 Defective
Flash
X X
X X
X X
X X
X X
X X
Appendix B: PJL support
46
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Unformatted Flash
Intervention Required -
Defective Disk
Intervention Required -
Unformatted Disk
Intervention Required -
Unformatted Flash
Intervention Required -
Defective Flash
Intervention Required -
Scheduled Maintenance
Intervention Required -
Scheduled Maintenance
Intervention Required -
Res Save Off Deficient
Memory
30036
30036
30036
32052
32056
30075
30075
30076
53 Unformatted
Flash
61 Defective
Disk
63 Unformatted
Disk
53 Unformatted
flash detected
53 Defective
flash detected
80 Scheduled
Maintenance
80 Scheduled
maintenance ADF
kit
35 Insufficient
memory to
support
Resource Save
feature
X X
X X
X X
X X
X X
Intervention Required -
Insufficient Memory
Intervention Required -
Resource Save Off
Deficient Memory
Intervention Required -
Insufficient Collation
Area
Intervention Required -
Service Required
Intervention Required -
Empty Box M
Intervention Required -
Empty Hole Punch Box
30076
30076
30076
30095
30107
30107
35 Insufficient
memory to
support
Resource Save
feature
35 Res Save Off
Deficient
Memory
37 Insufficient
Collation Area
36 Printer
service
required
Empty Box M
Empty Hole
Punch Box
X X
X X
X X
X X
X X
Appendix B: PJL support
47
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Insert Box M
Intervention Required -
Insert Staple Cartridge
Intervention Required -
Insert Stapler
Intervention Required -
Priming Failed
Intervention Required -
Network <x> Software
Error
Intervention Required -
Serial <x> Fax Connection
Lost
Intervention Required -
Serial Option <x> Error
Intervention Required -
Serial Port <x> Disabled
30107
30107
30107
30107
30112
30112
30112
30112
Insert Box M
Insert staple
cartridge
Insert Stapler
Priming Failed,
Retry. Go/Stop?
54 Network <x>
Software Error
54 Ser <x> Fax
Connection Lost
54 Serial
Option <x>
Error
56 Serial
Port <x>
Disabled
X X
X X
X X
X X
X X
X X
X X
Intervention Required -
USB Port Disabled
Intervention Required -
Parallel <x> ENA
Connection Lost
Intervention Required -
Parallel <x> Port Disabled
Intervention Required -
Disk Operation Failed
Faxes on Disk
Intervention Required -
Disk Operation Failed
Jobs on Disk
Intervention Required -
Flash Full
30112
30113
30113
32001
32001
32002
56 USB Port <x>
Disabled
54 Par <x> ENA
Connection Lost
56 Parallel
Port <x>
Disabled
Operation
Failed Faxes on
Disk
Operation
Failed Jobs on
Disk
52 Flash Full
X X
X X
X X
X X
X X
X X
Appendix B: PJL support
48
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Flash Full
Intervention Required -
Disk Full
Intervention required -
Disk Corrupted
Intervention required -
Disk Corrupted.
Reformat?
Intervention Required -
Too Many Bins Attached
Intervention Required -
Too Many Flash Options
Installed
Intervention Required -
Too Many Flash Options
Installed
32002
32002
32015
32015
32030
32030
32030
52 Not enough
free space in
flash memory
for resources
62 Disk full
Disk corrupted
Disk Corrupted.
Reformat?
58 Too many
bins attached
58 Too Many
Flash Options
58 Too many
flash options
installed
X X
X X
X X
X X
Intervention Required -
Unformatted Flash
Intervention Required -
Unformatted Flash
Detected
Intervention Required -
Unformatted Disk
Intervention Required -
Unsupported Disk
Format
Intervention Required -
Defective Flash
Intervention Required -
Defective Flash
Intervention Required -
Defective Disk
Intervention Required -
Defective Disk
32052
32052
32052
32052
32056
32056
32056
32056
53 Unformatted
Flash
53 Unformatted
flash detected
63 Unformatted
disk
64 Unsupported
Disk Format
51 Defective
Flash
51 Defective
flash detected
61 Defective
Disk
61 Remove
defective disk
X X
X X
X X
X X
X X
X X
Appendix B: PJL support
49
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Scheduled Maintenance
Intervention Required -
Scheduled Maintenance
Intervention Required -
Belt Exhausted
Intervention Required -
Belt Life Warning
Intervention Required -
Fuser/Belt Exhausted
Intervention Required -
Fuser/Belt Life Warning
Intervention Required -
Fuser Exhausted
Intervention Required -
Fuser Life Warning
Intervention Required -
Fuser Maintenance
35075
35075
40038
40038
40038
40038
40038
40038
40038
80 Scheduled
Maintenance
81 Scheduled
Maintenance
80 Belt
Exhausted
80 Belt Life
Warning
80 Fuser/Belt
Exhausted
80 Fuser/Belt
Life Warning
80 Fuser
Exhausted
80 Fuser Life
Warning
80 Fuser
Maintenance
X X
X X
X X
X X
X X
X X
X X
X X
X X
Intervention Required -
ITU Maintenance
40038
83 ITU
Maintenance
X X
PJL messages for attendance conditions
= Supported
X = Not supported
C540n, C543dn,
Message Status code Return string
Intervention Required -
Too Many Bins Attached
Intervention Required -
Too Many Flash Options
Installed
* This message contains a subset of letters CMYK, where CMYK denotes Cyan, Magenta, Yellow, and Black cartridges,
respectively.
32030
32030
58 Too many bins
attached
58 Too many
flash options
installed
C544n/dn/dw/dtn
X X
Printer model
X546dtn MFP
Appendix B: PJL support
50
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Remove Defective Disk
Intervention Required -
Defective Flash
Intervention Required -
Insert Hole Punch Box
Intervention Required -
Insert PC Cartridge
Intervention Required -
30 CMYK* Print Unit
Missing
Intervention Required -
30 Coating Roll Missing
Intervention Required -
Remove Originals from
Scanner ADF
Intervention Required -
Remove Paper Standard
Bin
32056
32056
40010
40010
40010 30 CMYK* Print
40010
40019
40019
61 Remove
defective disk
61 Defective
flash detected
Insert Hole
Punch Box
Insert PC
Cartridge
Unit Missing
30 Coating Roll
Missing
Remove
originals from
the scanner
automatic
document feeder
Remove paper
from standard
output bin
X X
X X
X X
X X
X X
X X
Intervention Required -
Install MICR cartridge
Intervention Required -
Cartridge Life Expired
Intervention Required -
Cartridge Life Warning
Intervention Required -
Change Cartridge Invalid
Refill
Intervention Required -
Close Cover <c>
Intervention Required -
Printer Cover Open
* This message contains a subset of letters CMYK, where CMYK denotes Cyan, Magenta, Yellow, and Black cartridges,
respectively.
40020
40021
40021
40021
40021
40021
Install MICR
cartridge
Cartridge Life
Expired CMYK*
Cartridge Life
Warning CMYK*
Change
Cartridge
Invalid Refill
Close Cover <c>
Close Cover
X X
X X
X X
X X
X X
X X
Appendix B: PJL support
51
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Close Toner Box Cover
Intervention Required -
Close Deflector G
Intervention Required -
Close Door
Intervention Required -
Close Door <d>
Intervention Required -
Close Door Insert
Cartridge
Intervention Required -
Close Finisher Door
Intervention Required -
Close Finisher Side Door
Intervention Required -
Close Finisher Top Cover
Intervention Required -
Close Front Door
40021
40021
40021
40021
40021
40021
40021
40021
40021
Close Cover
Close Deflector
G
Close Door
Close Door <d>
Close door or
insert
cartridge
Close Finisher
Door
Close Finisher
Side Door
Close Finisher
Top Cover
Close Front
Door
X X
X X
X X
X X
X X
X X
X X
X X
Intervention Required -
Close Side Door
Intervention Required -
Close Surface
Intervention Required -
Close Cover
Intervention Required -
Close Cover and Door
Intervention Required -
Close Door
Intervention Required -
Close Tray <x> Top Cover
* This message contains a subset of letters CMYK, where CMYK denotes Cyan, Magenta, Yellow, and Black cartridges,
respectively.
40021
40021
40021
40021
40021
40021
Close Side Door
Close surface H
Close top
access cover
Close top
access cover
and front door
Close <tray>
door
Close Tray <x>
Top Cover
X X
X X
X X
X X
X X
X X
Appendix B: PJL support
52
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Printer Upper Door Open
Intervention Required -
Insert Print Cartridge
Intervention Required -
Open Cover
Intervention Required -
Open Rear Door
Intervention Required -
Invalid Refill
Intervention Required -
Defective Ink Cartridge
Intervention Required -
Defective Print Cartridge
Intervention Required -
Missing Cartridge
40021
40021
40021
40021
40021
40021
40021
40021
Cover Open,
Close Top
Covers, Close
Door, or Insert
Cartridge
Insert Print
Cartridge
Open Cover
Open Rear Door
30 Invalid
Refill Change
Cartridge
31 Defective
Cartridge CMYK*
31 Defective
Print Cartridge
31 Missing
Cartridge CMYK*
X X
X X
X X
X X
X X
X X
X X
X X
Intervention Required -
Missing Printhead
Intervention Required -
Defective Print Cartridge
Intervention Required -
Invalid Refill
Intervention Required -
Defective Print Cartridge
Intervention Required -
Defective Print Cartridge
Intervention Required -
Unsupported Cartridge
* This message contains a subset of letters CMYK, where CMYK denotes Cyan, Magenta, Yellow, and Black cartridges,
respectively.
40021
40021
40021
40021
40021
40021
31 Missing
Printhead
31 Replace
defective
cartridge
31.yy Invalid
refill, change
cartridge
31.yy Replace
defective
cartridge
31.yy Replace
defective print
cartridge
32 Unsupported
Cartridge
X X
X X
X X
X X
X X
X X
Appendix B: PJL support
53
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Unsupported CMYK*
Cartridge
Intervention Required -
Unsupported Print
Cartridge
Intervention Required -
Unsupported Printhead
Intervention Required -
Unsupported Cartridge
Intervention Required -
Tray Size Sense Error
Intervention Required -
Open Bin Exit Tray
Intervention Required -
Cartridge Region
Mismatch
40021
40021
40021
40021
40021
40021
40021
32 Unsupported
CMYK* Cartridge
32 Unsupported
Print Cartridge
32 Unsupported
Printhead
32.yy Cartridge
part number
unsupported by
device
40 Tray <x> Size
Sense Error
41 Open Bin 1
Exit Tray
42.xy Cartridge
region mismatch
X X
X X
X X
X X
X X
X X
X X
Intervention Required -
Paper Jam
Intervention Required -
Remove Packaging
Material
Intervention Required -
Waste Toner Missing
Intervention Required -
Waste Toner Box Missing
Intervention Required -
Check Tray Connection
Intervention Required -
Install Tray <x> or Cancel
Job
* This message contains a subset of letters CMYK, where CMYK denotes Cyan, Magenta, Yellow, and Black cartridges,
respectively.
40022
40025
40025
40025
40027
40027
2xx Paper Jam
Remove
packaging
material
82 Waste toner
box missing
82.yy Waste
toner box
missing
Check tray
<source #>
connection
Install
Tray <x>
X X
X X
X X
X X
Appendix B: PJL support
54
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Install Tray <x> or Cancel
Job
Intervention Required -
Install Envelope Feeder
Intervention Required -
Install Env Feeder or
Cancel Job
Intervention Required -
Reattach Envelope
Feeder
Intervention Required -
Reattach MP Feeder
Intervention Required -
Check Finisher
Installation
Intervention Required -
Check Mailbox
Installation
40027
40028
40028
40028
40028
40029
40029
Install
Tray <x> or
Cancel Job
Install
envelope feeder
Install Env
Feed or Cancel
Job
Reattach
Envelope Feeder
Reattach MP
Feeder
Check Finisher
Installation
Check Mailbox
Installation
X X
X X
X X
X X
X X
X X
X X
Intervention Required -
Install Bin <x> or Cancel
Job
Intervention Required -
Reattach Bin
Intervention Required -
Reattach Bins
Intervention Required Reattach Output Bin
Intervention Required -
Tray Config Error
Intervention Required -
Input Config Error
Intervention Required -
Too Many Bins Attached
* This message contains a subset of letters CMYK, where CMYK denotes Cyan, Magenta, Yellow, and Black cartridges,
respectively.
40029
40029
40029
40029
40030
40030
40030
Install Bin <x>
or Cancel Job
Reattach bin
<x>
Reattach
Bins <bin #x—
bin #y>
Reattach Output
Bin <bin #>
33 Tray <x>
Config Error
58 Input config
error
58 Too Many Bins
Attached
X X
X X
X X
X X
X X
X X
X X
Appendix B: PJL support
55
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Too Many Disks Installed
Intervention Required -
Too Many Trays Attache d
Intervention Required -
Too Many Disks Installed
Intervention Required -
PerfectFinish Missing
Intervention Required -
PerfectFinish Empty
Intervention Required -
Replace Oil Coating Roll
Intervention Required -
Replace PC Kit
Intervention Required -
Replace PC Kit To
Continue
40030
40030
40036
40037
40037
40038
40038
40038
58 Too many
disks installed
58 Too many
trays attached
58 Too Many
Disks Installed
31
PerfectFinish
Missing
87
PerfectFinish
Empty
Replace Oil
Coating Roll
Replace PC Kit
Replace PC Kit
To Continue
X X
X X
X X
X X
X X
X X
X X
Intervention Required -
Replace Toner Cartridge
Intervention Required -
Replace Toner Cartridge
To Continue
Intervention Required -
84 All Photo Devs
Exhausted
Intervention Required -
84 Black Photo Dev
Exhausted
Intervention Required -
84 Black Photo Dev Life
Warning
Intervention Required -
84 Color Photo Dev Life
Warning
* This message contains a subset of letters CMYK, where CMYK denotes Cyan, Magenta, Yellow, and Black cartridges,
respectively.
40038
40038
40038
40038
40038
40038
Replace Toner
Cartridge
Replace Toner
To Continue
84 All Photo
Devs Exhausted
84 Black Photo
Dev Exhausted
84 Black Photo
Dev Life
Warning
84 Color Photo
Dev Life
Warning
X X
X X
X X
X X
X X
X X
Appendix B: PJL support
56
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Cartridge Low
Intervention Required -
[Color] Cartridge Low
Intervention Required -
Toner Low
Intervention Required -
Cartridge Low
Intervention Required -
Toner Low
Intervention Required -
Toner Low
Intervention Required -
Toner Low
40038
40038
40038
40038
40038
40038
40038
88 Cartridge
Low
88
[Color] cartrid
ge is low
88 Cartridge
low
88 Cartridge
Low <CMYK>
88 Toner is low
88 Toner Low
88 Yellow Toner
Low
88 Magenta
Toner Low
88 Cyan Toner
Low
88 Black Toner
Low
X X
X X
X X
X X
X X
X X
88 Color Print
Cartridge Low
88 Black Print
Cartridge Low
88 Photo Print
Cartridge Low
88 Yellow Toner
Empty
88 Magenta
Toner Empty
88 Cyan Toner
Empty
88 Black Toner
Empty
Intervention Required -
Cartridge Nearly Low
* This message contains a subset of letters CMYK, where CMYK denotes Cyan, Magenta, Yellow, and Black cartridges,
respectively.
40038
88.yy Cartridge
nearly low
X X
X X
X X
Appendix B: PJL support
57
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Cartridge Empty
Intervention Required -
Load Staples
Intervention Required -
Priming Failed. Retry?
Intervention Required -
OPMSG
Intervention Required -
PJL OP Message
Intervention Required -
STMSG
Intervention Required -
PJL ST Message
Intervention Required -
Replace Fuser
Intervention Required -
Replace Transfer Kit
40039
40040
40041
40048 OPMSG message X X
40048
40049 STMSG message X X
40049
40050
40050
89 Cartridge
Empty <CMYK>
Load Staples
Priming Failed.
Retry?
OPMSG message
STMSG message
Replace Fuser
Replace
Transfer Kit
X X
X X
X X
X X
X X
Intervention Required -
Incompatible Bin <x>
Intervention Required -
Incompatible Bin <x>
Intervention Required -
Incompatible Duplex
Intervention Required -
Incompatible Duplex
Intervention Required -
Incompatible Tray <x>
Intervention Required -
Incompatible Tray <x>
Intervention Required -
Incompatible Envelope
Feeder
* This message contains a subset of letters CMYK, where CMYK denotes Cyan, Magenta, Yellow, and Black cartridges,
respectively.
40087
40087
40088
40088
40089
40089
40090
59 Incompatible
Bin <x>
59 Incompatible
output bin <x>
59 Incompatible
Duplex
59 Incompatible
duplex
59 Incompatible
Tray <x>
59 Incompatible
tray <x>
59 Incompatible
Envelope Feeder
X X
X X
X X
X X
X X
Appendix B: PJL support
58
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Incompatible Envelope
Feeder
Intervention Required -
Check Duplex
Connection
Intervention Required -
Check Duplex
Connection
Intervention Required -
Install Duplex or Cancel
Job
Intervention Required -
Install Duplex or Cancel
Job
Intervention Required -
Duplex Cover Open
Intervention Required -
Insert Duplex Option
40090
40095
40095
40095
40095
40096
40096
59 Incompatible
envelope feeder
Check Duplex
Connection
Check duplex
connection
Install Duplex
or Cancel Job
Install duplex
Close Duplex
Door
Insert Duplex
Option
X X
X X
X X
X X
X X
X X
X X
Intervention Required -
Load Staples
Intervention Required -
Insert Hole Punch Box
Intervention Required -
Replace Color PC Units
Intervention Required -
Replace Photoconductor
Intervention Required -
Replace Waste Toner Box
Intervention Required -
Replace Waste Toner
Intervention Required -
Waste Toner Box Nearly
Full
* This message contains a subset of letters CMYK, where CMYK denotes Cyan, Magenta, Yellow, and Black cartridges,
respectively.
40101
40107
40129
40129
40141
40141
40141
Load Staples
Insert the hole
punch box
84 Replace
color PC Units
84.yy Replace
<color>
photoconductor
82.yy Replace
waste toner box
82 Replace
waste toner box
82.yy Waste
toner box
nearly full
X X
X X
X X
X X
X X
X X
Appendix B: PJL support
59
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Waste Toner Nearly Full
Intervention Required -
Transfer Module Missing
Intervention Required -
Cartridge Low
Intervention Required -
Cartridge Nearly Low
Intervention Required -
Replace Cartridge
Intervention Required -
Cartridge Low
Intervention Required -
Cartridge Nearly Low
Intervention Required -
Replace Cartridge
Intervention Required -
Cartridge Low
40141
40143
40200
40200
40200
40201
40201
40201
40202
82 Waste toner
box nearly full
83.yy Transfer
module missing
88.yy black
cartridge low
88.1x black
cartridge
nearly low
88.2x Replace
black cartridge
88.yy cyan
cartridge low
88.1x cyan
cartridge
nearly low
88.2x Replace
cyan cartridge
88.yy magenta
cartridge low
X X
X X
X X
X X
X X
X X
X X
X X
Intervention Required -
Cartridge Nearly Low
Intervention Required -
Replace Cartridge
Intervention Required -
Cartridge Low
Intervention Required -
Cartridge Nearly Low
Intervention Required -
Replace Cartridge
Black PC Unit Life
Warning
* This message contains a subset of letters CMYK, where CMYK denotes Cyan, Magenta, Yellow, and Black cartridges,
respectively.
40202
40202
40203
40203
40203
40204
88.1x magenta
cartridge
nearly low
88.2x Replace
magenta
cartridge
88.yy yellow
cartridge low
88.1x yellow
cartridge
nearly low
88.2x Replace
yellow
cartridge
84 Black pc unit
life warning
X X
X X
X X
X X
X X
X X
Appendix B: PJL support
60
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Unsupported PC Unit
Intervention Required -
Color PC Units Life
Warning
Intervention Required -
PC Kit Life Warning
Intervention Required -
Photoconductor Low
Intervention Required -
Photoconductor Low
Intervention Required -
Photoconductor Nearly
Low
Intervention Required -
Transfer Module Life
Warning
40204
40204
40204
40204
40204
40204
40215
84 unsupported
[color] pc unit
84.yy Color PC
Unit Life
warning
84 PC kit life
warning
84.yy <color>
photoconductor
low
84
Photoconductor
low
84.yy [color]
photoconductor
nearly low
83.yy Transfer
module life
warning
X X
X X
X X
X X
X X
X X
X X
Intervention Required -
Transfer Module Near
Life Warning
Intervention Required -
Fuser Life Warning
Intervention Required -
Fuser Life Warning
Intervention Required -
Fuser Near Life Warning
Intervention Required -
Replace Toner
Intervention Required -
Replace Toner
Intervention Required -
Replace Toner
* This message contains a subset of letters CMYK, where CMYK denotes Cyan, Magenta, Yellow, and Black cartridges,
respectively.
40215
40216
40216
40216
40300
40301
40302
83.yy Transfer
module near
life warning
87 Fuser Life
Warning
80.yy Fuser
life warning
80.yy Fuser
near life
warning
88 Replace
black toner
88 Replace cyan
toner
88 Replace
magenta toner
X X
X X
X X
X X
X X
X X
X X
Appendix B: PJL support
61
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Replace Toner
Intervention Required -
Replace PC Kit
Intervention Required -
Replace Photoconductor
Intervention Required -
84 Replace Black PC Unit
Intervention Required -
Cartridge Part Number
Unsupported
Intervention Required -
Replace unsupported
cartridge
Intervention Required -
Invalid Refill, Change
Cartridge
40303
40304
40304
40305
40309
40309
40309
88 Replace
yellow toner
84 Replace PC
Kit
84 Replace
photoconductor
84 Replace
black PC Unit
32.yy black
cartridge part
number
unsupported by
device
32.yy Replace
unsupported
black cartridge
40 black
invalid refill,
change
cartridge
X X
X X
X X
X X
X X
X X
X X
Intervention Required -
Cartridge Part Number
Unsupported
Intervention Required -
Replace unsupported
cartridge
Intervention Required -
Invalid Refill, Change
Cartridge
Intervention Required -
Cartridge Part Number
Unsupported
* This message contains a subset of letters CMYK, where CMYK denotes Cyan, Magenta, Yellow, and Black cartridges,
respectively.
40310
40310
40310
40311
32.yy cyan
cartridge part
number
unsupported by
device
32.yy Replace
unsupported
cyan cartridge
40 cyan invalid
refill, change
cartridge
32.yy magenta
cartridge part
number
unsupported by
device
X X
X X
X X
X X
Appendix B: PJL support
62
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Replace unsupported
cartridge
Intervention Required -
Invalid Refill, Change
Cartridge
Intervention Required -
Cartridge Part Number
Unsupported
Intervention Required -
Replace unsupported
cartridge
Intervention Required -
Invalid Refill, Change
Cartridge
Intervention Required -
Scheduled Maintenance
40311
40311
40312
40312
40312
40315
32.yy Replace
unsupported
magenta
cartridge
40 magenta
invalid refill,
change
cartridge
32.yy yellow
cartridge part
number
unsupported by
device
32.yy Replace
unsupported
yellow
cartridge
40 yellow
invalid refill,
change
cartridge
80 Scheduled
maintenance [x]
Note: [x] indicates
600k kit.
X X
X X
X X
X X
X X
X X
Intervention Required -
Replace Transfer Module
Intervention Required -
Replace Fuser
Intervention Required -
Replace Fuser
Intervention Required -
Scheduled Maintenance
Intervention Required -
Replace Cartridge
* This message contains a subset of letters CMYK, where CMYK denotes Cyan, Magenta, Yellow, and Black cartridges,
respectively.
40315
40316
40316
40316
40400
83.yy Replace
transfer module
80.yy Replace
fuser
87.yy Replace
fuser
80 Scheduled
maintenance [x]
Note: [x] indicates
100k kit.
31.yy Replace
defective or
missing
cartridge
X X
X X
X X
X X
X X
Appendix B: PJL support
63
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Insert Photoconductor
Intervention Required - 40404
Intervention Required -
<Color> PC Unit Missing
Intervention Required -
<Color> Photoconductor
Missing
Intervention Required -
<Color> PC Unit Missing
Intervention Required -
<Color> Photoconductor
Missing
Intervention Required -
<Color> PC Unit Missing
Intervention Required -
<Color> Photoconductor
Missing
40404
40405
40405
40406
40406
40407
40407
84 Insert
photoconductor
84
Photoconductor
abnormal
84.41 Black PC
Unit missing
84.41 Black
photoconductor
missing
84.41 Cyan PC
Unit missing
84.41 Cyan
photoconductor
missing
84.41 Magenta
PC Unit missing
84.41 Magenta
photoconductor
missing
X X
X X
X X
X X
X X
X X
X X
X X
Intervention Required -
<Color> PC Unit Missing
Intervention Required -
<Color> Photoconductor
Missing
Intervention Required -
Toner Cartridge Missing
Intervention Required -
Defective Cartridge
Intervention Required -
Missing or Defective
Cartridge
Intervention Required -
Toner Cartridge Missing
* This message contains a subset of letters CMYK, where CMYK denotes Cyan, Magenta, Yellow, and Black cartridges,
respectively.
40408
40408
40409
40409
40409
40410
84.41 Yellow PC
Unit missing
84.41 Yellow
photoconductor
missing
30.yy Black
toner cartridge
missing
31.yy Defective
black cartridge
31.41 Missing
or defective
black cartridge
30.yy Cyan
toner cartridge
missing
X X
X X
X X
X X
X X
X X
Appendix B: PJL support
64
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Defective Cartridge
Intervention Required -
Missing or Defective
Cartridge
Intervention Required -
Toner Cartridge Missing
Intervention Required -
Defective Cartridge
Intervention Required -
Missing or Defective
Cartridge
Intervention Required -
Toner Cartridge Missing
Intervention Required -
Defective Cartridge
40410
40410
40411
40411
40411
40412
40412
31.yy Defective
cyan cartridge
31.41 Missing
or defective
cyan cartridge
30.yy Magenta
toner cartridge
missing
31.yy Defective
magenta
cartridge
31.41 Missing
or defective
magenta
cartridge
30.yy Yellow
toner cartridge
missing
31.yy Defective
yellow
cartridge
X X
X X
X X
X X
X X
X X
X X
Intervention Required -
Missing or Defective
Cartridge
Intervention Required -
Fuser Missing
Intervention Required -
Fuser Missing
Intervention Required -
Insert Duplex Pages in
Tray <x>
* This message contains a subset of letters CMYK, where CMYK denotes Cyan, Magenta, Yellow, and Black cartridges,
respectively.
40412
40416
40416
41202
31.41 Missing
or defective
yellow
cartridge
80.yy Fuser
missing
87.yy Fuser
missing
Reload printed
pages in
Tray <x>
X X
X X
X X
Appendix B: PJL support
65
PJL messages for paper handling
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Tray <x> Empty
Intervention Required -
Tray <x> Missing
Intervention Required -
Bin <x> Full
Intervention Required -
Wrong Paper Size in
Tray <x>
Intervention Required -
Wrong Paper Size
Manual Feed
Intervention Required -
Remove Paper All Output
Bins
Intervention Required -
Remove Paper From All
Bins
Intervention Required -
Remove Paper From
<bin #>
11xyy
12x01
15ww1
30034
30034
40019
40019
40019
Tray <source #>
Empty
Tray <source #>
Missing
Bin <Bin #>
Full
34 Wrong Paper
Size in
Tray <x>
34 Wrong Paper
Size Manual
Feed
Remove Paper
All Output Bins
Remove paper
from all bins
Remove paper
from bin
<bin #>
X X
X X
X X
X X
X X
X X
X X
X X
Intervention Required -
Remove Paper <linked
set bin name>
Intervention Required -
Remove Paper From
Standard Output Bin
Intervention Required -
Remove Paper <linked
set bin name>
Intervention Required -
Remove Paper Outbin
<bin #>
Intervention Required -
Remove Paper Standard
Bin
40019
40019
40019
40019
40019
Remove paper
from <linked
set bin name>
Remove paper
from standard
output bin
Remove
Paper <linked
set bin name>
Remove Paper
Output Bin
<bin #>
Remove Paper
Standard Bin
Appendix B: PJL support
66
X X
X X
X X
X X
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Photoconductor
Exposure Warning
Intervention Required -
Check <Source>
Orientation or Guides
Intervention Required -
Check <Source> Paper
Guide
Intervention Required -
Incorrect Media
Intervention Required -
Load [src] [Custom Type
Name]
Intervention Required -
Load [src] [Custom
String]
Intervention Required -
Load [src] [size]
40025
4100x
4100x
41xy
41xyy
41xyy
41xyy
Photoconductor
exposure
warning
Check <source>
orientation or
guides
Check <source>
Paper Guide
Paper changes
needed
Load [src] with
[Custom Type
Name]
Load [src] with
[Custom String]
Load [src] with
[size]
X X
X X
X X
X X
Intervention Required -
Load [src] [type] [size]
Intervention Required -
Load Manual [Custom
Type Name]
Intervention Required -
Load Manual [Custom
String]
Intervention Required -
Load Manual [size]
Intervention Required -
Load Manual [type] [size]
41xyy
41xyy
41xyy
41xyy
41xyy
Load [src] with
[type] [size]
Load single
sheet feeder
with [Custom
Type Name]
Load single
sheet feeder
with [Custom
String]
Load single
sheet feeder
with [size]
Load single
sheet feeder
with [type]
[size]
Appendix B: PJL support
67
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Change Request
Intervention Required -
Load Manual Request
Intervention Required -
Load Manual Request
Intervention Required -
Load Manual Request
41xyy
41xxy
41xxy
41xxy
Change <source>
<Custom Type
Name>
<Custom String>
<size>
<type><size>
Load Manual
<Custom Type
Name>
<Custom String>
<size>
<type><size>
Load Manual
Feeder
with <Custom
Type Name>
Load Manual
Feeder
with <Custom
String>
X X
X X
X X
X X
Intervention Required -
Load Manual Request
Intervention Required -
Load Manual Request
Intervention Required -
Load Request
Intervention Required -
Load Request
41xxy
41xxy
41xyy
41xyy
Load Manual
Feeder
with <size>
Load Manual
Feeder
with <type><siz
e>
Load <source>
<Custom Type
Name>
<Custom String>
<size>
<type><size>
Load <source>
with <Custom
Type Name>
<Custom String>
with <size>
with <type><siz
e>
X X
X X
X X
X X
Appendix B: PJL support
68
= Supported
X = Not supported
Message Status code Return string
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Incorrect Media
Intervention Required -
Insert Duplex Pages &
Press Go.
Intervention Required -
Insert Tray Request
41xyy
412yy
4300x
34 Incorrect
Media
Insert Duplex
Pages & Press
Go.
Insert Tray <x>
PJL messages for paper jams
= Supported
X = Not supported
Message Status code
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
4200x X X
4200z
X X
X X
X X
Printer model
C540n, C543dn,
C544n/dn/dw/dtn
X546dtn MFP
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
w indicates this message includes a letter indicating a door or cover that needs to be opened.
x represents the number of jammed pages in the printer.
y represents the tray number.
z represents the bin number.
4201x X X
4201z
4202x X X
4202z
4203x X X
4203z
Appendix B: PJL support
69
= Supported
X = Not supported
Message Status code
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
4204x X X
4205x X X
4206x X X
4207x X X
4208x X X
4209x X X
4210x X X
4211x X X
4220x X X
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
w indicates this message includes a letter indicating a door or cover that needs to be opened.
x represents the number of jammed pages in the printer.
y represents the tray number.
z represents the bin number.
4221x X X
4222x X X
4230x X X
4230z
4231x X X
4231z X X
Appendix B: PJL support
70
= Supported
X = Not supported
Message Status code
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
4232x X X
4233x X X
4234 X X
424yx X X
424xz X X
4241wy X X
4241z X X
4242wy X X
4242z X X
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
w indicates this message includes a letter indicating a door or cover that needs to be opened.
x represents the number of jammed pages in the printer.
y represents the tray number.
z represents the bin number.
4243w X X
4243z X X
4244wy X X
4244z X X
4245w X X
4246w X X
Appendix B: PJL support
71
= Supported
X = Not supported
Message Status code
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
4247wy X X
4248w X X
4249w X X
4250w X X
4250x X X
4250z
4251wy X X
4251x X X
4252w X X
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
w indicates this message includes a letter indicating a door or cover that needs to be opened.
x represents the number of jammed pages in the printer.
y represents the tray number.
z represents the bin number.
4253w X X
4254wy X X
4255 X X
4256w X X
4257w X X
4258w X X
Appendix B: PJL support
72
= Supported
X = Not supported
Message Status code
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
4259wy X X
4260w X X
4260x X X
4260z X X
4261w X X
4261x X X
427xz X X
427zx X X
4271 X X
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
w indicates this message includes a letter indicating a door or cover that needs to be opened.
x represents the number of jammed pages in the printer.
y represents the tray number.
z represents the bin number.
4271z X X
4272 X X
4272z X X
4273 X X
4280w X X
4280x X X
Appendix B: PJL support
73
= Supported
X = Not supported
Message Status code
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
4280z X X
4281w X X
4281x X X
4281z X X
4282w X X
4282x X X
4282z X X
4283w X X
4283x X X
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
w indicates this message includes a letter indicating a door or cover that needs to be opened.
x represents the number of jammed pages in the printer.
y represents the tray number.
z represents the bin number.
4283z X X
4284w X X
4284x X X
4284z X X
4285w X X
4285z X X
Appendix B: PJL support
74
= Supported
X = Not supported
Message Status code
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
4286w X X
4286z X X
4287 X X
4287z X X
4288 X X
4288z X X
4289 X X
4289z X X
4290 X X
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
Intervention Required -
Paper Jam
w indicates this message includes a letter indicating a door or cover that needs to be opened.
x represents the number of jammed pages in the printer.
y represents the tray number.
z represents the bin number.
4291 X X
4292 X X
4293 X X
4294 X X
4295 X X
Appendix B: PJL support
75
Service errors
= Supported
X = Not supported
C540n, C543dn,
Message Error code
ALL SERVICE MESSAGES 50000 X X
C544n/dn/dw/dtn
Printer model
Device attendance messages
= Supported
X = Not supported
Message
RDYMSG
OPMSG
STMSG
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
X546dtn MFP
Lexmark-unique PJL commands
= Supported
X = Not supported
Command
LADVANCEDSTART
LBEEP
LCLOSEFILE
LDEFRAG
LDELETEFILE
LDOWNLOADTARGET
LENGINEPRT
LENTERRETAILMODE
LESCAPECHAR
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
LEXITRETAILMODE
Appendix B: PJL support
76
= Supported
X = Not supported
Command
LFAX PHONENUMBER X
LFORMAT
LINITIALIZEPRINTER
LOPENFILE
LPORTROTATE
LPRINT testpage
LPRINTDIRECTORY
LPRINTMENUS
LPRINTPCLFONTS
LPRINTPSFONTS
LPRINTTESTPAGE
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
LPRINTDIAG1TEST
LPRINTDIAG2TEST
LPRINTDIAG3TEST
LREADFILE
LRENAMEFILE
LRUNFILE
LWRITEFILE
File and device protection commands
= Supported
X = Not supported
C540n, C543dn,
Command
LBYPASSPASSWORD KEY
C544n/dn/dw/dtn
Printer model
X546dtn MFP
LDECLARE LRESOURCE
LDELETEPASSWORD
Appendix B: PJL support
77
= Supported
X = Not supported
Command
LQUERYSEED
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Appendix B: PJL support
78
Appendix C: PostScript support
Supplemental operators
= Supported
X = Not supported
C540n, C543dn,
Operator name
appletalktype
buildtime
byteorder
checkpassword
currentfilenameextend
currentmanualduplexmode
currentuniversalsize
C544n/dn/dw/dtn
Printer model
X546dtn MFP
defaulttimeouts
deletefile
devcontrol
devdismount
devforall
devformat
devmount
devstatus
diskonline
diskstatus
displayoperatormsg
doidlefonts
dojamrecovery
doprinterrors
doret X X
Appendix C: PostScript support
79
= Supported
X = Not supported
Operator name
dostartpage
dosysstart
duplexer
duplexmode
enginesync
file
filenameforall
fileposition
firstside
fontnonzerowinding
hardwareiomode
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
idlefonts
ignoresize
initializedisk
jobname
jobsource
jobtimeout
manualfeed
manualfeedtimeout
newsheet
pagecount
pagesprinted
papertray
printername
product
PS2fonts
Appendix C: PostScript support
80
= Supported
X = Not supported
C540n, C543dn,
Operator name
PS3fonts
quiet
ramsize
realformat
renamefile
resolution
revision
sccbatch
sccinteractive
setcoverpage X X
setdefaulttimeouts
C544n/dn/dw/dtn
Printer model
X546dtn MFP
setdoidlefonts
setdojamrecovery
setdoprinterrors
setdoret X X
setdostartpage
setdosysstart
setduplexmode
setenginesync
setethernetaddress
setfilenameextend
setfileposition
sethardwareiomode
setidlefonts
setignoresize
setjobtimeout
Appendix C: PostScript support
81
= Supported
X = Not supported
Operator name
setmanualduplexmode
setpapertray
setprintername
setquiet
setresolution
setsccbatch
setsccinteractive
setsoftwareiomode
settumble
setuniversalsize
setuserdiskpercent
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
softwareiomode
tumble
userdiskpercent
waittimeout
Page device parameters
= Supported
X = Not supported
Key
BeginPage
Collate
DeferredMediaSelection
DeviceRenderingInfo
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
• AutoMediaType
• ColorBalance
Appendix C: PostScript support
82
= Supported
X = Not supported
Key
• ColorCorrection
• ColorSaver
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
• DefaultPoliciesPageSize
X X
• EdgeToEdge
• ImageBrightness
• ImageContrast
• ImageEnhancement
• ImageEnhancementType
X X
• ImageSaturation
• LineDetail
• ManualColor
• PrintDarkness
• PictureGrade
• PrintQuality
• Screening
- ColorGrade X X
X X
X X
X X
- IET X X
- IETImagesOnly X X
- IETPictureGrade X X
- None X X
- PictureGrade X X
• SubstituteSize
• TonerSaver
• Type
Duplex
EndPage
ExitJamRecovery
HWResolution
Appendix C: PostScript support
83
= Supported
X = Not supported
Key
ImagingBBox
InputAttributes
• 0 - Tray 1
• 1 - Tray 2
• 2 - Envelope Feeder
• 3 - Tray 3
• 4 - Multipurpose Feeder
• 5 - Tray 4
• 6 - Tray 5
- InputLocation
- MatchAll
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
- MediaColor
- MediaType
- MediaWeight
- PageSize
• Mode
• Priority
Install
Jog
ManualFeed
ManualFeedTimeout
MediaColor
MediaPosition
MediaType
MediaWeight
NumCopies
Appendix C: PostScript support
84
= Supported
X = Not supported
Key
Nup
NupDetails
• Border
• Columns
• LandscapeOverride
• Order
• Orientation
• Rows
• Type
OutputAttributes
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
• 0 - Standard Bin
- OutputLocation
- OutputType
- Priority
OutputPage
OutputType
PageDeviceName
PageSize
Policies
• PolicyNotFound
• PolicyReport
• PageSize
PostRenderingEnhance X X
PostRenderingEnhanceDetails X X
• REValue
• Type
PowerSave
X X
X X
Appendix C: PostScript support
85
= Supported
X = Not supported
C540n, C543dn,
Key
ProcessColorModel X X
Punch X X
SlipSheet X X
SlipSheetDetails
C544n/dn/dw/dtn
Printer model
• SlipSheetSource
• Type
Staple X X
TraySwitch
Tumble
UniversalDetails
X546dtn MFP
User interpreter parameters
= Supported
X = Not supported
Key Default
AccurateScreens false
CollatedCopies Collation - Collated Copies
(QTY) value
HalftoneMode 0
IdiomRecognition true
JobName ( )
JobTimeout JobTimeout system
parameter
MaxDictStack 255
MaxExecStack 10015
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
MaxFontItem 12500
MaxFormItem 100000
MaxLocalVM 2147483647
Appendix C: PostScript support
86
= Supported
X = Not supported
Key Default
MaxOpStack 100000
MaxPatternItem 20000
MaxScreenItem 48000
MaxSuperScreen 1024
MaxUPathItem 5000
MinFontCompress 2147483647
PageCount 0
UseOldcopypage false
VMReclaim 0
VMThreshold 25000 per MB of RAM
WaitTimeout WaitTimeout system
parameter
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
System interpreter parameters
= Supported
X = Not supported
Key
BuildTime
ByteOrder
CurDisplayList
CurFontCache
CurFormCache
CurInputDevice
CurOutlineCache
CurOutputDevice
CurPatternCache
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Appendix C: PostScript support
87
= Supported
X = Not supported
Key
CurScreenStorage
CurSourceList
CurUPathCache
DisableFastProcs
DoPrintErrors
DoStartPage
EnableExtraFonts
EngineBoot
EngineCode
EngineSpeed
EnvironmentSave
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
FactoryDefaults
FatalErrorAddress
FontResourceDir
FontVersion
GenericResourceDir
GenericResourcePathSep
InstalledRam
JobTimeout
languagelevel
MaxDisplayList
MaxDisplayAndSourceList
MaxFontCache
MaxFormCache
MaxImageBuffer
MaxOutlineCache
Appendix C: PostScript support
88
= Supported
X = Not supported
Key
MaxPatternCache
MaxPermanentVM
MaxRasterMemory
MaxScreenStorage
MaxSourceList
MaxUPathCache
PageCount
PanelCode
PrinterCode
PrinterName
RamSize
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
RealFormat
Revision
SearchBuiltinFontsFirst
SerialNumber
StartJobPassword
StartupMode
StaticRamSize
SystemParamsPassword
UseOldcopypage
UseOldfonts
ValidNV
WaitTimeout
Appendix C: PostScript support
89
Devices supported
= Supported
X = Not supported
Device
%AppSocketA%
%AppSocketB%
%AppSocketC%
%AppSocketD%
%EthernetPhysicalA%
%EthernetPhysicalB%
%EthernetPhysicalC%
%EthernetPhysicalD%
%EtherTalkA%
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
%EtherTalkB%
%EtherTalkC%
%EtherTalkD%
%IP_A%
%IP_B%
%IP_C%
%IP_D%
%IR_A% X X
%IR_B% X X
%IR_C% X X
%IR_D% X X
%LexLinkA%
%LexLinkB%
%LexLinkC%
%LexLinkD%
%LocalTalkA%
Appendix C: PostScript support
90
= Supported
X = Not supported
C540n, C543dn,
Device
%LocalTalkB%
%LocalTalkC%
%LocalTalkD%
%LPR_A%
%LPR_B%
%LPR_C%
%LPR_D%
%ParallelA% X X
%ParallelB% X X
%ParallelC% X X
%ParallelD% X X
C544n/dn/dw/dtn
Printer model
X546dtn MFP
%PrintServerA%
%PrintServerB%
%PrintServerC%
%PrintServerD%
%RemotePrinterA%
%RemotePrinterB%
%RemotePrinterC%
%RemotePrinterD%
%SerialA% X X
%SerialB% X X
%SerialC% X X
%SerialD% X X
%TokenRingPhysicalA% X X
%TokenRingPhysicalB% X X
%TokenRingPhysicalC% X X
%TokenRingPhysicalD% X X
%TokenTalkA% X X
Appendix C: PostScript support
91
= Supported
X = Not supported
C540n, C543dn,
Device
%TokenTalkB% X X
%TokenTalkC% X X
%TokenTalkD% X X
%USB_A%
%USB_B%
%USB_C%
%USB_D%
C544n/dn/dw/dtn
Printer model
Device parameters
= Supported
X = Not supported
Printer model
X546dtn MFP
C540n, C543dn,
Key
Device Parameters for the Communication Device %Parallel%,
%ParallelA%, %ParallelB%, %ParallelC%, %ParallelD%
DelayedOutputClose X X
Enabled X X
Filtering X X
Handshake X X
HasNames X X
Interpreter X X
On X X
OutputDevice X X
PCLSmartSwitch X X
PortLocation X X
PSSmartSwitch X X
Type X X
Device Parameters for the Communication Device %Serial%,
%SerialA%, %SerialB%, %SerialC%, %SerialD%
C544n/dn/dw/dtn
X546dtn MFP
Baud X X
CheckParity X X
Appendix C: PostScript support
92
= Supported
X = Not supported
C540n, C543dn,
Key
DataBits X X
DelayedOutputClose X X
Enabled X X
Filtering X X
FlowControl X X
HasNames X X
HonorDSR X X
Interpreter X X
On X X
Parity X X
PCLSmartSwitch X X
PortLocation X X
PSSmartSwitch X X
C544n/dn/dw/dtn
Printer model
X546dtn MFP
RobustXon X X
SerialMode X X
StopBits X X
Type X X
Device Parameters for the Communication Device %LocalTalk%,
%LocalTalkA%, %LocalTalkB%, %LocalTalkC%, %LocalTalkD%
DelayedOutputClose
Enabled
Filtering
HasNames
Interpreter
LocalTalkType
NodeID
On
PCLSmartSwitch
PortLocation
PSSmartSwitch
Appendix C: PostScript support
93
= Supported
X = Not supported
Key
Type
Device Parameters for the Communication Device %EtherTalk%,
%EtherTalkA%, %EtherTalkB%, %EtherTalkC%, %EtherTalkD%
DelayedOutputClose
Enabled
EthernetAddress
EtherTalkType
EtherTalkZone
Filtering
HasNames
Interpreter
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
NodeID
On
PCLSmartSwitch
PortLocation
PSSmartSwitch
Type
Device Parameters for the Communication Device %IR%, %IR_A%,
%IR_B%, %IR_C%, %IR_D%
DelayedOutputClose X X
Enabled X X
Filtering X X
HasNames X X
Interpreter X X
On X X
PCLSmartSwitch X X
PortLocation X X
PSSmartSwitch X X
Type X X
Appendix C: PostScript support
94
= Supported
X = Not supported
Key
Device Parameters for the Communication Device %USB%,
%USB_A%, %USB_B%, %USB_C%, %USB_D%
DelayedOutputClose
Enabled
Filtering
HasNames
Interpreter
On
PCLSmartSwitch
PortLocation
PSSmartSwitch
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Type
Device Parameters for the Communication Device %TokenTalk%,
%TokenTalkA%, %TokenTalkB%, %TokenTalkC%, %TokenTalkD%
Address X X
Bridging X X
DelayedOutputClose X X
Enabled X X
Filtering X X
HasNames X X
Interpreter X X
NodeID X X
On X X
PCLSmartSwitch X X
PortLocation X X
PSSmartSwitch X X
TokenTalkType X X
Type X X
Zone X X
Appendix C: PostScript support
95
= Supported
X = Not supported
Key
Device Parameters for the Communication Device %AppSocket%,
%AppSocketA%, %AppSocketB%, %AppSocketC%,
%AppSocketD%
DelayedOutputClose
Enabled
Filtering
HasNames
Interpreter
On
PortLocation
Type
Device Parameters for the Communication Device
%RemotePrinter%, %RemotePrinterA%, %RemotePrinterB%,
%RemotePrinterC%, %RemotePrinterD%
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
DelayedOutputClose
Enabled
Filtering
HasNames
Interpreter
On
PortLocation
Type
Device Parameters for the Communication Device %PrintServer%,
PrintServerA%, PrintServerB%, %PrintServerC%,
%PrintServerD%
DelayedOutputClose
Enabled
Filtering
HasNames
Appendix C: PostScript support
96
= Supported
X = Not supported
Key
Interpreter
On
PortLocation
Type
Device Parameters for the Communication Device %LPR%,
%LPR_A%, %LPR_B%, %LPR_C%, %LPR_D%
Enabled
Filtering
HasNames
Interpreter
On
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
PortLocation
Type
Device Parameters for the Communication Device %LexLink%,
%LexLinkA%, %LexLinkB%, %LexLinkC%, %LexLinkD%
DelayedOutputClose
Enabled
HasNames
Interpreter
On
PortLocation
Type
Device Parameters for the Communication Device %IP%, %IP_A%,
%IP_B%, %IP_C%, %IP_D%
GatewayAddress
IPAddress
IPAddressDynamic
NetworkMask
Appendix C: PostScript support
97
= Supported
X = Not supported
Key
On
Physical
PortLocation
Type
Device Parameters for the Communication Device
%EthernetPhysical%, %EthernetPhysicalA%,
%EthernetPhysicalB%, %EthernetPhysicalC%,
%EthernetPhysicalD%
EthernetAddress
On
PortLocation
Type
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Device Parameters for the Communication Device
%TokenRingPhysical%, %TokenRingPhysicalA%,
%TokenRingPhysicalB%, %TokenRingPhysicalC%,
%TokenRingPhysicalD%
Address X X
On X X
PortLocation X X
Speed X X
Type X X
Device Parameters for the Parameters Device %Engine%
BSizeStandard
Darkness
PageCount
TimeToStandby
Type
Device Parameters for the Parameters Device %Console%
Language
Type
Appendix C: PostScript support
98
= Supported
X = Not supported
Key
Device Parameters for the Parameters Device %Calendar%,
%CalendarA%, %CalendarB%, %CalendarC%, %CalendarD%
Day
Hour
Minute
Month
Running
Second
Type
Year
DateTime
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
DayOfWeekLong
DayOfWeekNum
DayOfWeekShort
Device Parameters for the Parameters Device %disk1%
BlockSize X X
Free X X
HasNames X X
InitializeAction X X
LogicalSize X X
Mounted X X
PhysicalSize X X
Removable X X
Searchable X X
SearchOrder X X
Type X X
Writeable X X
Device Parameters for the Parameters Device %flash1%
BlockSize
Appendix C: PostScript support
99
= Supported
X = Not supported
Key
Free
HasNames
InitializeAction
LogicalSize
Mounted
PhysicalSize
Removable
Searchable
SearchOrder
Type
Writeable
C540n, C543dn,
C544n/dn/dw/dtn
Printer model
X546dtn MFP
Device Parameters for the Parameters Device %rom%
BlockSize
Free
HasNames
InitializeAction
LogicalSize
Mounted
PhysicalSize
Removable
Searchable
SearchOrder
Type
Writeable
Appendix C: PostScript support
100
Loading...
