Installation
1. Interface
RJ-45 interface
All RJ-45 copper interfaces support Auto-Negotiation for
optimal speed detection through RJ-45 CAT5 UTP cables
GEP-0823
User Manual
Package Content
Please check the following items in the package before
installing the switch.
1. GEP-0823 x 1
2. AC/DC adapter x 1
3. AC power line x 1
4. User manual x 1
Brief introduction
Many thanks for purchasing this Gigabit Ethernet POE
Switch! This product supports IEEE802.3ab 1000Base-T
standard, available for both full duplex and half duplex mode.
It provides 8 UTP ports with PoE feature, suitable for most
10/100/1000M networks.
with a maximum length of 100 meters (or 328 feet). They
also support standard Auto-MDI/MDI-X that can detect the
type of connection to any Ethernet device without requiring
special straight or crossover cables.
2. Connection
All ports support 802.3af compliant Power Devices (PD) and
other network devices (e.g. work station, hub or switch).
Connect one end of the standard UTP CAT5 network cable
to the 10/100/1000Mbps RJ-45 ports on the front panel of
the switch. Connect the other of the cable to the typical
network devices.
3. Power on
Connect one end of the power adapter to the switch.Connect
the power plug of the adapter to a standard wall outlet. When
the switch is powered on, the PWR LED should be remain
static green. The LEDs of each port indicate the connection
status of corresponding port. (See Table.1 for detailed
description)
Fig.1 Basic Switch Connection
Panel
1. Front Panel
The front panel of PoE switch consists of 8 Auto-Sensing
10/100/1000Mbps Ethernet RJ-45 ports. The power LED
and LED indicators of all ports are also located on the front
panel.
Fig.2 Switch Front Panel
Rear Panel
The rear panel of the switch indicates an DC inlet power
socket, which accepts 52V DC input power.
Fig.3 Switch Rear Panel
2
Explanation for LED indicators
The LED indicators serve as device status monitoring and
error display. The following table explains each LED
indicator.
Table.1 Descriptions of LEDs
LED
Status
Description
PWR
Green
Device active
POE P1~P8
Yellow
PoE function active and
Connected PD is supplied with PoE
OFF
PoE function deactivated or
No PD identified
L/A
P1~P8
Green
Link to port
Blink
Data transfer to port
SPD
P1~P8
Green
Transfer rate is 1000Mbps
OFF
Transfer rate is 10/100Mbps
Technical parameters:
1. Standard Protocol:
IEEE 802.3 10 Base-T
IEEE 802.3u 100Base-TX
IEEE 802.3ab 1000Base-T
IEEE 802.3x flow control
IEEE 802.3af PoE
2. Connectors:
8× UTP RJ-45 connector with POE function
3. Operation mode:
10/100/1000Mbps auto-negotiation mode
4. Power supply: 52VDC@2.5A with 802.3af
5. PSE Pinout: PIN1/2: Pos(+), PIN3/6:Neg(-)
6. Operation temperature: -20℃~70 ℃
7. Storage temperature: -40℃~75 ℃
8. Operation humidity: 5%-90% non-condense
9. Storage humidity: 5%-90% non-condense
10. Twisted Pair cable: Cat5 UTP cable
11. Dimensions: 30×170.5×80.5mm (H x W x D)
Warning:
1. This product is suitable for indoor application.
2. The cable distance between the switch and PC should not
exceed 100 meters for UTP cable.
3. Cat.3/4/5 cable may be used in 10Mbps operation.
However, Cat.5 UTP or better data grade cable must be
employed for 100/1000Mbps operation.
4. The appliance inlet is used as the disconnect device and
shall remain readily operable at all time.
Trouble shooting:
1. Bad performance
Please check the transfer rate (10Mbps, 100Mbps or
100Mbps) and the duplex status (full duplex or half
duplex) of both sides. Make sure both sides are set to
identical status.
2. Link failure :
Check the L/A LED on the switch try another port on
the switch make sure the cable is well installed make sure
the cable is the right type power off the device for a while
and power it on again.
