Le Pan M97 Operating Instructions
Matsunichi
M97 (
Wi
-
Fi) User Manual
Table of Contents
CH1. BEFORE GETTING STARTED ............................................................................................................................... - 1 -
Care and Maintenance ........................................................................................................................... - 1 -
CH2. GETTING TO KNOW YOUR TABLET .................................................................................................................... - 2 -
Your Tablet ............................................................................................................................................ - 2 -
In the Box............................................................................................................................................... - 2 -
Install the Storage Card .......................................................................................................................... - 2 -
Battery .................................................................................................................................................. - 3 -
Headphone Jack ..................................................................................................................................... - 4 -
Tablet Controls....................................................................................................................................... - 4 -
Get Around Your Tablet .......................................................................................................................... - 5 -
CH3. GETTING STARTED ............................................................................................................................................ - 6 -
Turn Your Tablet On / Off ....................................................................................................................... - 6 -
Start Using Your Tablet .......................................................................................................................... - 6 -
Customize the Home Screen ................................................................................................................... - 7 -
Status and Notifications ......................................................................................................................... - 8 -
Settings.................................................................................................................................................. - 8 -
Adjust the Volume .................................................................................................................................. - 9 -
Use the On-Screen Keyboard .................................................................................................................. - 9 -
Connect to Computer ........................................................................................................................... - 10 -
Create and Manage Contacts ............................................................................................................... - 11 -
CH4. SETTINGS ........................................................................................................................................................ - 12 -
Change Basic Settings .......................................................................................................................... - 12 -
Protect Your Tablet and Personal Data ................................................................................................. - 14 -
Manage Applications ........................................................................................................................... - 15 -
Reset to Factory Defaults ..................................................................................................................... - 16 -
CH5. MESSAGING ................................................................................................................................................... - 17 -
Email ................................................................................................................................................... - 17 -
Gmail ................................................................................................................................................... - 18 -
CH6. CONNECTING.................................................................................................................................................. - 19 -
Connect to the Internet ........................................................................................................................ - 19 -
Wi-Fi .................................................................................................................................................... - 19 -
View Web Pages .................................................................................................................................. - 20 -
Browser Settings .................................................................................................................................. - 22 -
Manage Bookmarks ............................................................................................................................. - 23 -
Bluetooth ............................................................................................................................................. - 23 -
CH7. MULTIMEDIA .................................................................................................................................................. - 25 -
Camera ................................................................................................................................................ - 25 -
Viewing, Sharing, and Editing Pictures .................................................................................................. - 26 -
Watch and Share Video ........................................................................................................................ - 28 -
Music ................................................................................................................................................... - 28 -
LIMITED WARRANTY .............................................................................................................................................. - 30 -
FCC STATEMENT ..................................................................................................................................................... - 31 -
CH1. BEFORE GETTING STARTED
Your tablet is a highly sophisticated electronic device. Please read this manual before using your tablet, battery, charger or any accessories.
Care and Maintenance
Keep your tablet and all its parts out of the reach of children.
Keep your tablet dry.
Avoid exposing your tablet to extreme hot or cold temperatures.
Avoid placing your tablet close to lit cigarettes, naked flames or any heat source.
Do not attempt to disassemble your tablet. Non-expert handling of the device may damage it.
Do not drop, knock, or shake your tablet. Rough handling may break internal circuit boards.
Do not paint your tablet as the paint could obstruct the ports and prevent normal use.
Treat your tablet with care, and keep it in a clean and dust free place.
- 1 -
CH2. GETTING TO KNOW YOUR TABLET
M
icro SD Slot Location
Your Tablet
1. Headphone Jack 7. Power On/Off Button
2. 30 Pin Connector 8. Reset Button
3. Microphone 9. Camera
4. Micro SD Card Slot 10. Ambient Light Sensor
5. Volume Up/Down Button 11. Speaker
6. Screen Rotation Lock
In the Box
Quick Start Guide
USB Power Adapter
30 Pin Connector to USB Cable
Micro SD Card
Cleaning Cloth
Install the Storage Card
The internal storage capacity is 4GB; you can install a micro SD card up to 32 GB to save more pictures, music, applications, etc.
Install Micro SD Card
1. Turn off the tablet.
2. Locate the slot for the micro SD card.
3. Open the slot door.
4. Insert the micro SD card.
- 2 -
Remove Micro SD Card
Turn off the tablet or unmount the micro SD card:
1. Go to Applications > Settings > Storage > Unmount SD Card.
2. Push the micro SD card to eject it from the slot.
3. Pull out the micro SD card from the slot.
Battery
Your tablet has an internal 6800 mAh rechargeable lithium-ion battery. The battery can only be replaced by the original manufacturer.
To reduce the risk of fire or burns:
Do not crush, puncture, short external contacts, or dispose of battery in fire or water.
Do not expose to temperatures above 60°C (140°F).
Recycle or dispose of used battery as stipulated by local regulations.
Battery Performance
Battery performance depends on many factors, including the network configuration, signal strength, temperatur e, features or settings, items attached to
connecting ports, and usage of programs or functions.
Charge the Battery
Your tablet comes with a USB Power Adapter (Wall Charger Output: 5V, 2A) to charge your tablet from any standard AC power outlet.
Before using your tablet for the first time, you must fully charge the battery for a minimum of eight hours.
When battery is being charged, the icon will be displayed at the button of screen when tablet pc is on .
After the battery has been fully charged, a full battery icon will be displayed in the status bar .
Steps:
1. Insert the 30 Pin Connector into your tablet’s charger port.
2. Insert the USB Connector into the USB Power Adapter.
3. Plug the USB Power Adapter (Wall Charger) into a standard AC power outlet to start charging the battery.
USB Power Adapter Wall Charger
- 3 -
Headphone Jack
Headphone Jack Location
For listening to music and watching videos, insert the headset into the headphone jack.
Tablet Controls
Function Keys
Touch the control keys on the screen to do the followings:
Key Icon Function
Text search
Voice search
Text search on Google.
Voice search on Google.
Multi-task
Drop – down
Return
Home
APPS
Option
Close
Return to the previous screen.
Return to the Home screen.
Open the list of recently used applications and running applications.
View all applications installed on the tablet.
Open an options menu.
Close the keyboard.
Open a drop-down menu.
- 4 -
Get Around Your Tablet
There are different ways to navigate around the home screen, menus and applications on your tablet.
You can also change the screen orientation of the tablet as well.
Touch
Touch and hold
Drag
Flick
Double-touch
Pinch
Touch application or other element with your finger to open or select them.
Touch an item with your finger and do not release it until the tablet responds.
Touch and hold an item and move it to a desired position.
Move your finger quickly either vertically or horizontally across the screen.
Quickly touch the screen twice.
Pinch your fingers together or move them apart.
Rotate
To change the screen orientation from portrait to landscape, or vice versa, simply turn the tablet
sideways. When entering text, you can turn the tablet sideways to bring up a bigger keyboard.
- 5 -
CH3. GETTING STARTED
Unlock the screen
Turn Your Tablet On / Off
Turn On the Tablet
Press the POWER key on the right side of the top of the tablet.
Turn Off the Tablet
Press and hold the POWER key until the options menu opens.
On the options menu, touch the Power Off button to turn off the tablet.
Start Using Your Tablet
After you get into the welcome page, touch and hold the UNLOCK icon and slide up to the right to unlock your
tablet.
Set Up Your Tablet for the First Time
When you turn on the tablet for the first time, you will be requested to sign in to your Google account. Please follow the instruction displayed on the tablet.
Turn Off the Screen When Not in Use
To save battery power, your tablet screen automatically turns off when you leave it idle after a certain period of time. You can also turn off the screen by
briefly pressing the POWER key. Pressing the POWER key again will turn on your tablet screen.
- 6 -
Home Screen
Home Screen
The Home screen is your starting point for using the applications on your tablet. You can customize the Home screen
to display application icons, shortcuts, folders, and widgets.
Extended Home Screen
The Home screen extends beyond the screen width to provide more space for adding icons, widgets, and more. Slide
your finger horizontally across the screen (to the left or the right) to go to the left side or right side of the extended home screen. Press the Home key to go
back to the main screen. Your tablet supports 5 extended Home screens.
Customize the Home Screen
Home Screen Items
Apps. Add shortcuts such as application, a bookmarked web page, a favorite contact, an email label, or a music playlist.
Widgets. Add wireless manager, profile mode, clock, Facebook widget, Weather widget, music player, FM player, picture frame, Google Search bar,
power control, or a calendar that shows upcoming appointments.
Wallpapers. Change the Home screen wallpaper.
Add a Home Screen Item
Add Icons to the Home Screen: Long press the icon till it magnifies, you can locate the icon at any extended home screens.
Add Widgets to the Home Screen: Press , then touch WIDGETS, long press any widgets till it magnifies, you can locate it at any extended home screens.
Reposition a Home Screen Item
1. Touch and hold the item on the screen you want to reposition to activate Move mode.
**Note: When Move mode is activated, the item will magnify.
2. Without lifting your finger, drag the icon to the desired position on the screen, and then release it.
**Tip: To move an item from the Home screen to an extended Home screen, touch and hold the item and then drag it to the left or right edge of the
screen until the display shifts to the extended Home screen. Position the item on the screen, and then release it.
- 7 -
Remove a Home Screen Item
Change wallpaper
Notification
1. Touch and hold the item on the screen you want to remove to activate Move mode.
2. Drag the icon to .
Change the Home Screen Wallpaper
1. While on the Home screen, touch > Settings > Display > Wallpaper; or you can long press the empty
area of the home screen to Choose wallpaper from Gallery/ Live Wallpapers/ Wallpapers.
2. Touch Gallery, Live wallpapers or Wallpapers.
Touch Gallery to use a picture you captured using the camera or copied to your tablet as wallpaper.
Touch Live wallpapers or Wallpapers to use preset wallpapers that came with the tablet.
3. Touch Save or Set Wallpaper.
Status and Notifications
Status Bar
At the right down corner of the screen is the status area. Notifications such as Wi-Fi connection, battery, time and etc.
will be displayed here. Touch the icon to open it.
To go back, touch to return to the home screen.
Settings
Control and customize tablet settings on the Settings screen.
Open the Settings Screen:
Press Home , touch Applications , then select Settings.
- 8 -
