Lenovo Z575, Z475 User Manual

IdeaPad Z475/Z575

User Guide V1.0

Read the safety notices and important tips in the included manuals before using your computer.

Notes

•

Before using the product, be sure to read Lenovo Safety and General Information Guide first.

•

Some instructions in this guide may assume that you are using Windows® 7. If you are using other Windows operating system, some operations may be slightly different. If you are using other operating systems, some operations may not apply to you.

•

The features described in this guide are common to most models. Some features may not be available on your computer and/or your computer may include features that are not described in this user guide.

•

The illustrations used in this manual are for Lenovo IdeaPad Z475 unless otherwise stated.

•

The illustrations in this manual may differ from the product you are using.

Regulatory Notice

•

To refer to it, go to http://consumersupport.lenovo.com/ and click

User guides and manuals.

First Edition (April 2011)

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.

Contents

Chapter 1. Getting to know your

computer................................... 1

Top view..........................................1

Left-side view .................................4

Right-side view...............................6

Front view .......................................8

Bottom view ....................................9

Chapter 2. Learning the

basics...................................... 11

First use..........................................11

Using AC adapter and battery ...13

Using the touchpad......................15

Using the keyboard......................16

Connecting external devices.......19

Special keys and buttons.............22

System status indicators..............26

Securing your computer..............27

Chapter 3. Connecting to the

Internet ....................................29

Wired connection .........................29

Wireless connection .....................31

Chapter 4. OneKey Rescue

system .....................................33

OneKey Rescue system ............... 33

Chapter 5. Troubleshooting...36

Frequently asked questions........ 36

Troubleshooting...........................38

Appendix A. CRU

instructions.............................43

Replacing the battery pack ......... 43

Replacing the hard disk drive.... 45

Replacing memory.......................51

Removing the optical drive........ 54

Trademarks.............................56

Chapter 1. Getting to know your computer

Top v iew - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

 Z475

h i jfe

Chapter 1. Getting to know your computer

 Z575

h i jfe

Attention:



• Do NOT open the display panel beyond 130 degrees. When closing the display panel, be

careful NOT to leave pens or any other objects in between the display panel and the keyboard. Otherwise, the display panel may be damaged.

Chapter 1. Getting to know your computer

Integrated

Use the camera for video communication.

camera

Wireless module

antennas

Computer display

Speakers

Power button

OneKey Rescue

system button

Note: For details, see “OneKey Rescue system” on page 33.

System status

The built-in antennas ensure optimal reception of wireless radio.

The computer display with LED backlight provides brilliant visual output.

The stereo speakers provide rich and powerful sound.

Press this button to turn on the computer.

Press this button to start OneKey Rescue system when the computer is powered off.

For details, see “System status indicators” on page 26.

indicators

Volume buttons

OneKey Theater

Use these buttons to adjust volume.

Touch this button to select a preferred scenario mode.

button

Note: For details, see “OneKey Theater button” on page 23.

Thermal

management button

Touch this button to control the speed at which the dissipation fan spins. Touch this button to perform dust cleaning.

Note: For details, see “Thermal management button” on page 24.

Built-in

microphone

Touchpad

Note: For details, see “Using the touchpad” on page 15.

The built-in microphone (with noise reduction) can be used for video conferencing, voice narration, or simple audio recordings.

The touchpad functions as a conventional mouse.

Chapter 1. Getting to know your computer

Left-side view - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

 Z475

e f gcha

 Z575

Kensington slot

Note: For details, see “Attaching a security lock (not supplied)” on page 27.

AC power adapter

Attach a security lock (not supplied) here.

Connect the AC adapter here.

d f ga

jack

Note:For details, see “Using AC adapter and battery” on page 13.

Fan louvers

Note: Make sure that none of the fan louvers are blocked or else overheating of the

computer may occur.

VGA port

RJ-45 port

Note: For details, see “Wired connection” on page 29.

HDMI port

Dissipate internal heat.

Connects to external display devices.

This port connects the computer to an Ethernet network.

Connects to devices with HDMI input such as a TV or a display.

Chapter 1. Getting to know your computer

eSATA/USB

combo port

Note: For details, see “Connecting USB devices” on page 20.

Connects to eSATA or USB devices.

USB port

Note: For details, see “Connecting USB devices” on page 20.

Connects to USB devices.

Chapter 1. Getting to know your computer

Right-side view - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

 Z475

 Z575

acb

Headphone jack

Attention:



• Listening to music at high volume over extended periods of time may damage your

hearing.

Microphone jack

Optical drive

USB port

Note: For details, see “Connecting USB devices” on page 20.

AC power adapter

jack

Connects to external headphones.

Connects to external microphones.

Reads/Burns optical discs.

Connects to USB devices.

Connect the AC adapter here.

ecba

Note: For details, see “Using AC adapter and battery” on page 13.

Chapter 1. Getting to know your computer

RJ-45 port

Note: For details, see “Wired connection” on page 29.

This port connects the computer to an Ethernet network.

Chapter 1. Getting to know your computer

Front view - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

a b

Integrated

wireless device

Slide this switch to turn on or turn off the wireless radio of all wireless devices on your computer.

switch

Memory card slot

Note: For details, see “Using memory cards (not supplied)” on page 19.

Insert memory cards (not supplied) here.

Chapter 1. Getting to know your computer

Bottom view - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

 Z475

a b

Chapter 1. Getting to know your computer

 Z575

Battery latch -

manual

Battery pack

Hard disk drive / Memory / Central processing unit / Mini PCI Express Card slot compartment

Battery latch -

spring loaded

The manual battery latch is used to keep the battery pack secured in place.

For details, see “Using AC adapter and battery” on page

13.

The spring-loaded battery latch keeps the battery pack secured in place.

Chapter 2. Learning the basics

First use

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

 Reading the manuals

Read the supplied manuals before using your computer.

 Connecting to the power

The supplied battery pack is not fully charged at purchase. To charge the battery and begin using your computer, insert the battery pack

and connect the computer to an electrical outlet. The battery is automatically charged while the computer is running on AC power.

Installing the battery pack

Refer to the supplied Setup Poster to install the battery pack.

Connecting the computer to an electrical outlet

Connect the power cord to the AC adapter.

Connect the AC adapter to the AC power adapter jack of the computer firmly.

Plug the power cord into an electrical outlet.

 Turning on the computer

Press the power button to turn on the computer.

 Configuring the operating system

You may need to configure the operating system when it is first used. The configuration process may include the procedures below.

• Accepting the end user license agreement

• Configuring the Internet connection

• Registering the operating system

• Creating a user account

Chapter 2. Learning the basics

 Putting your computer into sleep state or shutting it down

When you finish working with your computer, you can put it into sleep state or shut it down.

Putting your computer into sleep state

If you will be away from your computer for only a short time, put the computer into sleep state. When the computer is in sleep state, you can quickly wake it to resume use, and bypass the startup process.

To put the computer into sleep state, do one of the following.

• Click and select Sleep from the Start menu.

• Press Fn + F1.

Note: Wait until the power indicator light starts blinking (indicating that the computer is

in sleep state) before you move your computer. Moving your computer while the hard disk is spinning can damage the hard disk, causing loss of data.

To wake the computer, do one of the following.

• Press the power button.

• Press any key on the keyboard.

 Shutting down your computer

If you are not going to use your computer for a day or two, shut it down. To shut down your computer, click and select Shut down from the Start

menu.

Chapter 2. Learning the basics

Using AC adapter and battery

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

 Checking battery status

You can determine the percentage of battery power remaining by checking the battery icon in the notification area.

Note: As each computer user has different habits and needs, it is difficult to predict how

long a battery charge will last. There are two main factors:

• The amount of energy stored in the battery when you commence work.

• The way you use your computer: for example, how often you access the hard disk drive and how bright you make the computer display.

 Charging the battery

When you find that the battery power is low, you need to charge the battery or replace it with a fully charged one.

You need to charge the battery in any of the following situations:

• When you purchase a new battery

• If the battery status indicator starts blinking

• If the battery has not been used for a long time

Notes:

• You are advised to insert the battery pack when using your computer to prevent small

particles from entering the inside of your computer.

• To increase the life of the battery pack, the computer does not start recharging the

battery immediately after it drops from fully charged.

• Charge the battery at a temperature between 50 °F and 86 °F (10 °C-30 °C).

• Full charge or discharge is not required.

Chapter 2. Learning the basics

 Removing the battery pack

If you are not going to use the computer for an extended period of time, or if you need to send your computer to Lenovo for service, etc. remove the battery pack from the computer. Before removing the battery pack, make sure the computer has been shut down.

 Handling the battery

If the rechargeable battery pack is replaced with an incorrect type, there may be danger of an explosion. The battery pack contains a small amount of harmful substances. To avoid possible injury and detriment to the environment, pay attention to the following points:

• Replace only with a battery of the type recommended by Lenovo.

• Keep the battery pack away from fire.

• Do not expose the battery pack to water or rain.

• Do not attempt to disassemble the battery pack.

• Do not short-circuit the battery pack.

• Keep the battery pack away from children.

• Do not put the battery pack in trash that is disposed of in landfills. When disposing of the battery, comply with local ordinances or regulations and your company’s safety standards.

Chapter 2. Learning the basics

Using the touchpad

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Touchpad

Touchpad button

Note: You can enable/disable the touchpad using Fn + F6. When the touchpad indicator is

lit, the touchpad is disabled.

To move the cursor on the screen, slide your fingertip over the pad in the direction in which you want the cursor to move.

The function of the left/right side corresponds to that of the left/right mouse button on a conventional mouse.
