P340 Tiny
User Guide
Read this first
Before using this documentation and the product it supports, ensure that you read and understand the
following:
• Appendix B “Important safety information” on page 67
• Safety and Warranty Guide
• Setup Guide
Second Edition (August 2020)
© Copyright Lenovo 2020.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services
Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS35F-05925.
Contents
About this documentation . . . . . . . . iii
Chapter 1. Meet your computer. . . . . 1
Front . . . . . . . . . . . . . . . . . . . . 1
Rear . . . . . . . . . . . . . . . . . . . . 3
Features and specifications . . . . . . . . . . . 5
Statement on USB transfer rate . . . . . . . . 6
Chapter 2. Get started with your
computer . . . . . . . . . . . . . . . . . 7
Get started with Ubuntu Desktop . . . . . . . . . 7
Connect to networks. . . . . . . . . . . . . . 7
Connect to the wired Ethernet . . . . . . . . 7
Connect to Wi-Fi networks (for selected
models) . . . . . . . . . . . . . . . . . 8
Use multimedia . . . . . . . . . . . . . . . . 8
Use audio . . . . . . . . . . . . . . . . 8
Connect to an external display . . . . . . . . 8
Chapter 3. Explore your computer . . . 9
Manage power . . . . . . . . . . . . . . . . 9
Set power button behaviors . . . . . . . . . 9
Set the power plan . . . . . . . . . . . . . 9
Connect to a Bluetooth-enabled device (for
selected models) . . . . . . . . . . . . . . . 9
Use with a Tiny-In-One monitor. . . . . . . . . 10
Purchase accessories . . . . . . . . . . . . 11
Chapter 4. Secure your computer
and information . . . . . . . . . . . . 13
Lock the computer . . . . . . . . . . . . . 13
Use passwords . . . . . . . . . . . . . . . 13
Use computrace Agent software embedded in
firmware (for selected models) . . . . . . . . . 14
Use BIOS security solutions . . . . . . . . . . 14
Erase all storage drive data . . . . . . . . 15
Use the cover presence switch . . . . . . . 15
Use Intel BIOS guard . . . . . . . . . . . 15
Use Smart USB Protection. . . . . . . . . 15
Chapter 5. UEFI BIOS . . . . . . . . . 17
What is UEFI BIOS. . . . . . . . . . . . . . 17
Enter the BIOS menu. . . . . . . . . . . . . 17
Navigate in the BIOS interface . . . . . . . . . 17
Change the display language of UEFI BIOS . . . . 17
Change the display mode of UEFI BIOS . . . . . 18
Set the system date and time . . . . . . . . . 18
Change the startup sequence . . . . . . . . . 18
Enable or disable the configuration change detection
feature . . . . . . . . . . . . . . . . . . 19
Enable or disable the automatic power-on
feature . . . . . . . . . . . . . . . . . . 19
Enable or disable the smart power-on feature . . . 19
Enable or disable the ErP LPS compliance mode . . 19
Change the ITS performance mode . . . . . . . 20
Change BIOS settings before installing a new
operating system . . . . . . . . . . . . . . 20
Update UEFI BIOS. . . . . . . . . . . . . . 21
Recover from a BIOS update failure . . . . . . . 21
Clear CMOS . . . . . . . . . . . . . . . . 21
Chapter 6. RAID . . . . . . . . . . . . 23
What is RAID . . . . . . . . . . . . . . . . 23
RAID Level. . . . . . . . . . . . . . . . . 23
Configure the system BIOS to enable SATA RAID
functionality . . . . . . . . . . . . . . . . 23
Configure RAID in UEFI mode . . . . . . . . . 23
Configure RAID in legacy mode . . . . . . . . 24
Chapter 7. Troubleshooting,
diagnostics, and recovery . . . . . . . 27
Basic procedure for resolving computer
problems . . . . . . . . . . . . . . . . . 27
Troubleshooting . . . . . . . . . . . . . . 27
Startup problems . . . . . . . . . . . . 28
Audio problems . . . . . . . . . . . . . 28
Network problems . . . . . . . . . . . . 28
Performance problems . . . . . . . . . . 30
Storage drive problems . . . . . . . . . . 30
CD or DVD problems . . . . . . . . . . . 31
Serial connector problems. . . . . . . . . 32
USB device problems . . . . . . . . . . 32
Software problems. . . . . . . . . . . . 32
Lenovo diagnostic tools . . . . . . . . . . . 32
Chapter 8. CRU replacement . . . . . 35
What are CRUs . . . . . . . . . . . . . . . 35
Replace a CRU . . . . . . . . . . . . . . . 36
ac power adapter and power cord. . . . . . 36
Rear Wi-Fi antenna. . . . . . . . . . . . 38
Vertical stand . . . . . . . . . . . . . . 39
VESA mount bracket . . . . . . . . . . . 41
External optical drive box and external optical
drive . . . . . . . . . . . . . . . . . 42
Power adapter bracket . . . . . . . . . . 43
Dust shield . . . . . . . . . . . . . . . 46
© Copyright Lenovo 2020 i
Computer cover . . . . . . . . . . . . . 47
Internal speaker . . . . . . . . . . . . . 48
System fan . . . . . . . . . . . . . . . 49
Coin-cell battery. . . . . . . . . . . . . 50
PCIe card and PCIe converter . . . . . . . 52
Wi-Fi card and Wi-Fi card shield . . . . . . 53
Bottom cover . . . . . . . . . . . . . . 55
M.2 solid-state drive . . . . . . . . . . . 56
Memory module . . . . . . . . . . . . . 58
Chapter 9. Help and support . . . . . 61
Self-help resources . . . . . . . . . . . . . 61
Call Lenovo . . . . . . . . . . . . . . . . 62
Before you contact Lenovo . . . . . . . . 62
Lenovo Customer Support Center . . . . . . 62
Purchase additional services. . . . . . . . . . 63
Appendix A. System memory
speed. . . . . . . . . . . . . . . . . . 65
Appendix B. Important safety
information . . . . . . . . . . . . . . . 67
Appendix C. Accessibility and
ergonomic information . . . . . . . . 81
Appendix D. Supplemental
information about the Ubuntu operating
system . . . . . . . . . . . . . . . . . 83
Appendix E. Compliance and TCO
Certified information. . . . . . . . . . 85
Appendix F. Notices and
trademarks . . . . . . . . . . . . . . . 95
ii P340 Tiny User Guide
About this documentation
• Illustrations in this documentation might look different from your product.
• Depending on the model, some optional accessories, features, and software programs might not be
available on your computer.
• Depending on the version of operating systems and programs, some user interface instructions might not
be applicable to your computer.
• Documentation content is subject to change without notice. Lenovo makes constant improvements on the
documentation of your computer, including this User Guide. To get the latest documentation, go to:
https://pcsupport.lenovo.com
• Canonical® makes periodic feature changes to the Ubuntu® operating system through Software Updates.
As a result, some information in this documentation might become outdated. Refer to Ubuntu resources
for the latest information.
© Copyright Lenovo 2020 iii
iv P340 Tiny User Guide
Chapter 1. Meet your computer
Front
1. ThinkStation LED
2. Power button
3. Storage drive activity indicator This indicator is on when the storage drive is in use.
4. USB-C
™
(3.2 Gen 1) connector
The indicator is on when the computer is on.
Press to turn on the computer.
To turn off the computer, open the system menu, click the power icon
then select Power Off.
The indicator in the power button shows the system status of your computer.
• On: The computer is on.
• Off: The computer is off or in hibernation mode.
• Blinking: The computer is in sleep mode.
• Charge USB-C compatible devices with the output voltage and current of 5 V
and 0.9 A.
• Transfer data at USB 3.2 speed, up to 5 Gbps.
• Connect to USB-C accessories to help expand your computer functionality. To
purchase USB-C accessories, go to
https://www.lenovo.com/accessories.
, and
© Copyright Lenovo 2020 1
5. Always On USB 3.2 connector
Gen 2
With the Always On USB feature enabled, the Always On USB 3.2 connector Gen
2 can charge a USB-compatible device when the computer is on, off, in sleep
mode, or in hibernation mode.
To enable the Always On USB feature, do the following:
1. Enter the UEFI BIOS menu. See “Enter the BIOS menu” on page 17.
2. Click Devices ➙ USB Setup ➙ Front USB Ports ➙ USB Port 2 to enable
the Always On USB feature.
6. Headset connector
Connect a headset or headphones to your computer.
2 P340 Tiny User Guide
Rear
Used to install the rear Wi-Fi antenna cable connector that is available only on
1. Wi-Fi® antenna slot*
some models. The rear Wi-Fi antenna is installed on the rear Wi-Fi antenna cable
connector.
Connect to a local area network (LAN). When the green indicator is on, the
2. Ethernet connector
computer is connected to a LAN. When the yellow indicator blinks, data is being
transmitted.
3. USB 3.2 connectors Gen 2
Connect USB-compatible devices, such as a USB keyboard, USB mouse, USB
storage device, or USB printer.
Connect USB-compatible devices, such as a USB keyboard, USB mouse, USB
4. USB 3.2 connector Gen 1 (with
smart power-on)
storage device, or USB printer. This connector supports the smart power-on
feature. For more information, see “Enable or disable the smart power-on feature”
on page 19.
5. HDMI
™
1.4 out connector
6. USB 3.2 connector Gen 1
7. DisplayPort
®
1.4 out connector
8. Power cord connector
9. Security-lock slot
Send audio and video signals from the computer to another audio or video device,
such as a high-performance monitor.
Connect USB-compatible devices, such as a USB keyboard, USB mouse, USB
storage device, or USB printer.
Send audio and video signals from the computer to another audio or video device,
such as a high-performance monitor.
Connect the ac power adapter to your computer for power supply.
Lock your computer to a desk, table, or other fixtures through a Kensington-style
cable lock.
10. Optional connectors* Depending on the computer model, the connectors might vary.
Chapter 1. Meet your computer 3
* for selected models
4
P340 Tiny User Guide
Features and specifications
• Width: 37 mm (1.5 inches)
Dimensions
Weight (without the package) Maximum configuration as shipped: 1.4 kg (3 lb)
• Height: 179 mm (7 inches)
• Depth: 182.9 mm (7.2 inches)
Hardware configuration
Power supply
Electrical input
Microprocessor
Memory
Storage device
Video features
1. Open the system menu from the top-right corner and click Settings.
2. Click About.
Your computer comes with one of the following power supplies:
• 170-watt automatic voltage-sensing power supply*
• 230-watt automatic voltage-sensing power supply*
• Input voltage: From 100 V ac to 240 V ac
• Input frequency: 50/60 Hz
To view the microprocessor information of your computer, enter Settings and
click About.
Up to two double data rate 4 (DDR4) non-error correction code (non-ECC) small
outline dual in-line memory modules (SODIMMs)
Up to two M.2 solid-state drives
To view the storage drive capacity of your computer, use the Disks application.
Note: The storage drive capacity indicated by the system is less than the nominal
capacity.
• The integrated graphics card supports:
– DisplayPort 1.4 out connector
– HDMI 1.4 out connector
• The optional discrete graphics card provides an enhanced video experience
and extended capabilities.
Audio features
Expansion
Network features
* for selected models
The integrated audio card supports:
• Headset connector
• Internal speaker
• Memory slots
• M.2 solid-state drive slots
• Optical drive*
• Ethernet LAN
• Wireless LAN*
• Bluetooth*
Chapter 1. Meet your computer 5
Statement on USB transfer rate
Depending on many factors such as the processing capability of the host and peripheral devices, file
attributes, and other factors related to system configuration and operating environments, the actual transfer
rate using the various USB connectors on this device will vary and will be slower than the data rate listed
below for each corresponding device.
USB device Data rate (Gbit/s)
3.2 Gen 1 / 3.1 Gen 1
3.2 Gen 2 / 3.1 Gen 2
3.2 Gen 2 × 2
5
10
20
6 P340 Tiny User Guide
Chapter 2. Get started with your computer
Get started with Ubuntu Desktop
Learn the basics of Ubuntu and start working with it right away. For more information about Ubuntu, see the
Ubuntu documentation site at:
The Gnome desktop is installed by default and is designed to be simple and easy to use. Details on using
Gnome are available by launching the Help application or online at
https://help.ubuntu.com/lts/ubuntu-help/index.html.
https://help.gnome.org/users/.
Launch an app
• Press the Super key (with the Windows logo) or open the Activities menu on the top left and type in the
name of the application you want to launch.
• Click the Show Applications button on the lower left, and select the application you want to launch.
Launch settings
Open the system menu from the top-right corner and click Settings.
Connect to networks
Your computer helps you connect to the world through a wired or wireless network.
Connect to the wired Ethernet
Connect your computer to a local network through the Ethernet connector on your computer with an
Ethernet cable.
© Copyright Lenovo 2020 7
Connect to Wi-Fi networks (for selected models)
If your computer includes a wireless LAN module, you can connect your computer to Wi-Fi® networks. The
wireless LAN module on your computer may support different standards. For some countries or regions, use
of 802.11ax may be disabled according to local regulations.
1. Open the system menu from the top-right corner and expand the Wi-Fi section of the menu.
2. Click Select Network. A list of available wireless networks is displayed.
3. Select a network available for connection. Provide required information, if needed.
Use multimedia
Use your computer for business or entertainment with the devices (such as a camera, a monitor, or
speakers).
Use audio
To enhance the audio experience, connect speakers, headphones, or a headset to the audio connector.
Change the sound settings
1. Open the system menu from the top-right corner and click Settings.
2. Click Sound.
3. Change the settings as you prefer.
Connect to an external display
Connect to a wired display
Connect your computer to a projector or a monitor to give presentations or expand your workspace.
Display mode
Go to Settings ➙ Devices ➙ Displays. Then, select a display mode of your preference.
• Join Displays: Extend the video output from your primary display to the secondary display. You can drag
and move items between two displays.
• Mirror: Display the same video output on both the primary display and the secondary display.
• Single Display: Display the video output on only one display attached.
Display arrangement
Go to Settings ➙ Devices ➙ Displays. Then, click Primary Display and select one of the displays as the
primary display.
Change display settings
Go to Settings ➙ Devices ➙ Displays. Then, you can change the settings for both the primary display and
other displays. You can change the resolution, orientation and refresh rate.
8
P340 Tiny User Guide
Chapter 3. Explore your computer
Manage power
Use the information in this section to achieve the best balance between performance and power efficiency.
Set power button behaviors
You can define what the power button does according to your preference. For example, by pressing the
power button, you can turn off the computer or put the computer to sleep or hibernation mode.
To change what the power button does:
1. Open the system menu from the top-right corner and click Settings.
2. Click Power.
3. In the Suspend & Power Button section choose the power button action as you prefer.
Set the power plan
For ENERGY STAR® compliant computers, the following power plan takes effect when your computers have
been idle for a specified duration:
Table 1. Default power plan (when plugged into ac power)
• Turn off the display: After 5 minutes
• Put the computer to sleep: After 60 minutes
To awaken the computer from Sleep mode, press any key on your keyboard.
To reset the power plan to achieve the best balance between performance and power saving:
1. Open the system menu from the top-right corner and click Settings.
2. Click Power.
3. Choose or customize a power plan of your preference.
Connect to a Bluetooth-enabled device (for selected models)
You can connect all types of Bluetooth-enabled devices to your computer, such as a keyboard, a mouse, a
smartphone, or speakers. To ensure that the connection is successful, place the devices 10 meters (33 feet),
at most, from the computer.
1. Turn on Bluetooth on the computer.
a. Open the system menu from the top-right corner and then click Settings ➙ Bluetooth.
b. In the Bluetooth section enable Bluetooth with the toggle button at the top.
2. Any discoverable devices will be shown in the Devices list.
3. Select a Bluetooth device, and then follow the on-screen instructions.
Your Bluetooth device and computer will automatically connect the next time if the two devices are in range
of each other with Bluetooth turned on. You can use Bluetooth for data transfer or remote control and
communication.
© Copyright Lenovo 2020 9
Use with a Tiny-In-One monitor
Note: When installing the computer to the TIO monitor, ensure that you use the ac power adapter that
comes with the computer.
Primary video display output switching
The computer works with its integrated graphics card by default when it is installed to the TIO monitor. You
can turn on or turn off the computer by pressing the power button on the TIO monitor. Any other devices
connected to TIO monitor function the same as they are connected to the computer.
To switch the primary video display output from the integrated graphics card to the discrete graphics card,
do the following:
1. Turn on or restart your computer.
2. Before the operating system starts up, repeatedly press and release F1 or Fn+F1 (depending on the
keyboard settings) until the Setup Utility program opens. If a BIOS password has been set, enter the
correct password when prompted.
3. Locate the Select Active Video submenu and select PEG. Then press F10 to save changes and exit.
4. Connect the discrete-graphic-card connector on the computer with the DisplayPort or HDMI connector
of the TIO monitor using an applicable dongle.
5. Press the mode-switching button on the TIO monitor to change from the TIO mode to the DP mode or
HDMI mode.
When the computer works with the discrete graphics card, pressing the power button on the TIO monitor
only turns on or turns off the TIO monitor. Devices connected to the TIO monitor do not function the same as
they are connected to the computer.
Intel Turbo Boost Technology
Intel Turbo Mode capability is designed to allow the processor to assess its own thermals, current, and
power to come up with a dynamic upper limit on its frequency. This means that the processor can run at
frequency higher than the advertised base frequency, and at any frequency in the inclusive range between
maximum turbo frequency and the advertised base frequency at any time.
If the computer microprocessor is i9-10900, i9-10900T, i7-10700, i7-10700T, i5-10600, i5-10600T, i5-10500,
i5-10500T, i5-10400, or i5-10400T, the computer does not support Intel Turbo mode when installed in one of
the following TIO monitors:
• ThinkCentre TIO27 (MT: 10YF)
• ThinkCentre 超级Q27 (MT: 10YF)
• ThinkCentre TIO27q (MT: 10YG)
• ThinkCentre Tiny-in-One 22
• ThinkCentre Tiny-in-One 24
• ThinkCentre TIO22Gen3
• ThinkCentre 超级Q22Gen3
• ThinkCentre TIO22Gen3Touch
• ThinkCentre 超级Q22Gen3Touch
• ThinkCentre TIO24Gen3
• ThinkCentre 超级Q24Gen3
• ThinkCentre TIO24Gen3Touch
10
P340 Tiny User Guide
• ThinkCentre 超级Q24Gen3Touch
Purchase accessories
Lenovo has a number of hardware accessories and upgrades to help expand the capabilities of your
computer. Options include memory modules, storage devices, network cards, power adapters, keyboards,
mice, and more.
To shop at Lenovo, go to
https://www.lenovo.com/accessories.
Chapter 3. Explore your computer 11
12 P340 Tiny User Guide
Chapter 4. Secure your computer and information
Lock the computer
Note: You are responsible for evaluating, selecting, and implementing the locking device and security
feature. Lenovo makes no comments, judgments, or warranties about the function, quality, or performance
of the locking device and security feature. You can purchase computer locks from Lenovo.
Kensington-style cable lock
Lock your computer to a desk, table, or other fixtures through a Kensington-style cable lock.
Use passwords
Password types
You can set the following passwords in UEFI (Unified Extensible Firmware Interface) BIOS (Basic Input/
Output System) to prevent unauthorized access to your computer. However, you are not prompted to enter
any UEFI BIOS password when your computer resumes from sleep mode.
• Power-on password
When a power-on password is set, you are prompted to enter a valid password each time the computer is
turned on. The computer cannot be used until the valid password is entered.
• Supervisor password
Setting a supervisor password deters unauthorized users from changing configuration settings. If you are
responsible for maintaining the configuration settings of several computers, you might want to set a
supervisor password.
When a supervisor password is set, you are prompted to enter a valid password each time you try to enter
the BIOS menu.
© Copyright Lenovo 2020 13
If both the power-on password and supervisor password are set, you can enter either password.
However, you must use your supervisor password to change any configuration settings.
• Hard disk password
Setting a hard disk password prevents unauthorized access to the data on the storage drive. When a hard
disk password is set, you are prompted to enter a valid password each time you try to access the storage
drive.
Note: After you set a hard disk password, your data on the storage drive is protected even if the storage
drive is removed from one computer and installed in another.
• System management password (for selected models)
You can enable the system management password to have the same authority as the supervisor
password to control security related features. To customize the authority of the system management
password through the UEFI BIOS menu:
1. Restart the computer. When the logo screen is displayed, press F1 or Fn+F1.
2. Select Security ➙ System Management Password Access Control.
3. Follow the on-screen instructions.
If you have set both the supervisor password and the system management password, the supervisor
password overrides the system management password.
Set, change, and remove a password
Before you start, print these instructions.
1. Restart the computer. When the logo screen is displayed, press F1 or Fn+F1.
2. Select Security.
3. Depending on the password type, select Set Supervisor Password, Set Power-On Password, Set
System Management Password, or Hard Disk Password and press Enter.
4. Follow the on-screen instructions to set, change, or remove a password.
5. Press F10 or Fn+F10 to save the changes and exit.
You should record your passwords and store them in a safe place. If you forget the passwords, see “Clear
CMOS” on page 21 to remove them by yourself. You can also contact a Lenovo-authorized service provider
to have the passwords removed.
Notes:
• If the supervisor password is forgotten, it might not be removed by clearing CMOS depending on your
BIOS settings.
• If the hard disk password is forgotten, Lenovo cannot remove the password or recover data from the
storage drive.
Use computrace Agent software embedded in firmware (for selected models)
The Computrace Agent software is an IT asset management and computer theft recovery solution. The
software detects if changes have been made on the computer, such as hardware, software, or the computer
call-in location. You might have to purchase a subscription to activate the Computrace Agent software.
Use BIOS security solutions
This section provides BIOS solutions to secure your computer and information.
14
P340 Tiny User Guide
Erase all storage drive data
It is recommended that you erase all storage drive data before recycling a storage drive or the computer.
To erase all storage drive data:
1. Set a hard disk password for the storage drive you will recycle. See “Use passwords” on page 13.
2. Restart the computer. When the logo screen is displayed, press F1 or Fn+F1.
3. Select Security ➙ Hard Disk Password ➙ Security Erase HDD Data and press Enter.
4. Select the storage drive you will recycle and press Enter.
5. A message is displayed, prompting you to confirm the operation. Select Yes and press Enter. The
erasing process begins.
Note: During the erasing process, the power button and the keyboard are disabled.
6. After the erasing process is completed, a message is displayed, prompting you to reset the system.
Select Continue.
Note: Depending on the storage drive capacity, the erasing process will take half an hour to three hours.
7. After the resetting process is completed, one of the following will happen:
• If the data on the system storage drive is erased, you will be prompted that no operating system is
available.
• If the data on the non-system storage drive is erased, the computer restarts automatically.
Use the cover presence switch
The cover presence switch prevents the computer from logging in to the operating system when the
computer cover is not properly installed or closed.
To enable the cover presence switch connector on the system board:
1. Restart the computer. When the logo screen is displayed, press F1 or Fn+F1.
2. Select Security ➙ Cover Tamper Detected and press Enter.
3. Select Enabled and press Enter.
4. Press F10 or Fn+F10 to save the changes and exit.
When the cover presence switch connector on the system board is enabled, if the cover presence switch
detects that the computer cover is not correctly installed or closed, an error message will be displayed when
you turn on the computer. To bypass the error message and log in to the operating system:
1. Properly install or close the computer cover.
2. Enter the BIOS menu, save and then exit.
Use Intel BIOS guard
The BIOS guard module cryptographically verifies all the BIOS updates to the system BIOS flash. Therefore,
the malware is blocked from attacking the BIOS.
Use Smart USB Protection
The Smart USB Protection function is a security function that helps prevent data from being copied from the
computer to USB storage devices connected to the computer. You can set the Smart USB Protection
function to one of the following modes:
• Disabled (default setting): You can use the USB storage devices without limitation.
Chapter 4. Secure your computer and information 15
• Read Only: You cannot copy data from the computer to the USB storage devices. However, you can
access or modify data on the USB storage devices.
• No Access: You cannot access the USB storage devices from the computer.
To configure the Smart USB Protection function:
1. Restart the computer. When the logo screen is displayed, press F1 or Fn+F1.
2. Select Security ➙ Smart USB Protection and press Enter.
3. Select the desired setting and press Enter.
4. Press F10 or Fn+F10 to save the changes and exit.
16
P340 Tiny User Guide
Chapter 5. UEFI BIOS
This chapter provides information about configuring and updating UEFI BIOS, and clearing CMOS.
What is UEFI BIOS
Note: The operating system settings might override any similar settings in UEFI BIOS.
UEFI BIOS is the first program that the computer runs when the computer is turned on. UEFI BIOS initializes
the hardware components and loads the operating system and other programs. Your computer comes with a
setup program with which you can change UEFI BIOS settings.
Enter the BIOS menu
Restart the computer. When the logo screen is displayed, press F1 or Fn+F1 to enter the BIOS menu.
Note: If you have set BIOS passwords, enter the correct passwords when prompted. You also can select No
or press Esc to skip the password prompt and enter the BIOS menu. However, you cannot change the
system configurations that are protected by passwords.
Navigate in the BIOS interface
Attention: The default configurations are already optimized for you in boldface. Improper change of the
configurations might cause unexpected results.
Depending on your keyboard, you can navigate in the BIOS interface by pressing the following keys, or
combinations of Fn and the following keys:
F1 or Fn+F1
Esc or Fn+Esc Exit the submenu and return to the parent menu.
↑↓ or Fn+↑↓ Locate an item.
← → or Fn+← → Select a tab.
+/– or Fn++/– Change to a higher or lower value.
Enter Enter the selected tab or submenu.
F9 or Fn+F9 Restore to the default settings.
F10 or Fn+F10 Save your configuration and exit.
Display the General Help screen.
Change the display language of UEFI BIOS
UEFI BIOS supports three or four display languages: English, French, simplified Chinese, and Russian (for
selected models).
To change the display language of UEFI BIOS:
1. Select Main ➙ Language and press Enter.
2. Set the display language as desired.
© Copyright Lenovo 2020 17
Change the display mode of UEFI BIOS
You can use UEFI BIOS in the graphic mode or the text mode according to your needs.
To change the display mode of UEFI BIOS:
1. Restart the computer. When the logo screen is displayed, press F1 or Fn+F1.
2. Select Main ➙ Setup Mode Select and press Enter.
3. Set the display mode as desired.
Set the system date and time
1. Restart the computer. When the logo screen is displayed, press F1 or Fn+F1.
2. Select Main ➙ System Time & Date and press Enter.
3. Set the system date and time as desired.
4. Press F10 or Fn+F10 to save the changes and exit.
Change the startup sequence
If the computer does not start up from a device as expected, you can change the startup device sequence
permanently or select a temporary startup device.
Change the startup device sequence permanently
1. Depending on the type of the storage device, do one of the following:
• If the storage device is internal, go to step 2.
• If the storage device is a disc, ensure that the computer is on or turn on the computer. Then, insert
the disc into the optical drive.
• If the storage device is an external device other than a disc, connect the storage device to the
computer.
2. Restart the computer. When the logo screen is displayed, press F1 or Fn+F1.
3. Select Startup, and then follow the on-screen instructions to change the startup sequence.
4. Press F10 or Fn+F10 to save the changes and exit.
Select a temporary startup device
Note: Not all discs and storage drives are bootable.
1. Depending on the type of the storage device, do one of the following:
• If the storage device is internal, go to step 2.
• If the storage device is a disc, ensure that the computer is on or turn on the computer. Then, insert
the disc into the optical drive.
• If the storage device is an external device other than a disc, connect the storage device to the
computer.
2. Restart the computer. When the logo screen is displayed, press F12 or Fn+F12.
3. Select the storage device as desired and press Enter.
If you want to change the startup device sequence permanently, select Enter Setup on Startup Device Menu
and press Enter to enter the BIOS menu.
18
P340 Tiny User Guide
Enable or disable the configuration change detection feature
If you enable configuration change detection, when the POST detects configuration changes of some
hardware devices (such as storage drives or memory modules), an error message will be displayed when you
turn on the computer.
To enable or disable the configuration change detection feature:
1. Restart the computer. When the logo screen is displayed, press F1 or Fn+F1.
2. Select Security ➙ Configuration Change Detection and press Enter.
3. Enable or disable the feature as desired.
4. Press F10 or Fn+F10 to save the changes and exit.
To bypass the error message and log in to the operating system, press F2 or Fn+F2. To clear the error
message, enter the BIOS menu, save and then exit.
Enable or disable the automatic power-on feature
The Automatic Power On item in UEFI BIOS provides various options for you to make your computer start up
automatically.
To enable or disable the automatic power-on feature:
1. Restart the computer. When the logo screen is displayed, press F1 or Fn+F1.
2. Select Power ➙ Automatic Power On and press Enter.
3. Select the feature as desired and press Enter.
4. Enable or disable the feature as desired.
5. Press F10 or Fn+F10 to save the changes and exit.
Enable or disable the smart power-on feature
Ensure that the keyboard is connected to a USB connector supporting the smart power-on feature. With the
smart power-on feature enabled, you can start up or wake up the computer from the hibernation mode by
pressing Alt+P.
To enable or disable the smart power-on feature:
1. Restart the computer. When the logo screen is displayed, press F1 or Fn+F1.
2. Select Power ➙ Smart Power On and press Enter.
3. Enable or disable the feature as desired.
4. Press F10 or Fn+F10 to save the changes and exit.
Enable or disable the ErP LPS compliance mode
Lenovo computers meet the eco-design requirements of the ErP Lot 3 regulation. For more information, go
to:
https://www.lenovo.com/us/en/compliance/eco-declaration
You can enable the ErP LPS compliance mode to reduce the consumption of electricity when the computer
is off or in sleep mode.
To enable or disable the ErP LPS compliance mode:
Chapter 5. UEFI BIOS 19
1. Restart the computer. When the logo screen is displayed, press F1 or Fn+F1.
2. Select Power ➙ Enhanced Power Saving Mode and press Enter.
3. Depending on whether you select Enabled or Disabled, do one of the following:
• If you select Enabled, press Enter. Then, select Power ➙ Automatic Power On and press Enter.
Check whether the Wake on LAN feature is disabled automatically. If no, disable it.
• If you select Disabled, press Enter. Then, go to the next step.
4. Press F10 or Fn+F10 to save the changes and exit.
When the ErP LPS compliance mode is enabled, you can wake up the computer by doing one of the
following:
• Press the power button.
• Enable the Wake Up on Alarm feature to make the computer wake up at a set time.
Change the ITS performance mode
You can adjust the acoustic and thermal performance of your computer by changing the ITS performance
mode. Three choices are available:
• Best Performance (default setting): The computer works at the best system performance with normal
acoustic level.
• Best Experience: The computer works at the best experience with balanced noise and better
performance.
• Full Speed: All fans in the computer will run at full speed.
To change the ITS performance mode:
1. Restart the computer. When the logo screen is displayed, press F1 or Fn+F1.
2. Select Power ➙ Intelligent Cooling and press Enter.
3. Select Performance Mode and press Enter.
4. Set the performance mode as desired.
5. Press F10 or Fn+F10 to save the changes and exit.
Change BIOS settings before installing a new operating system
BIOS settings vary by operating system. Change the BIOS settings before installing a new operating system.
To change the BIOS settings:
1. Restart the computer. When the logo screen is displayed, press F1 or Fn+F1.
2. From the main interface, select Security ➙ Secure Boot and press Enter.
3. Depending on the operating system to be installed, do one of the following:
• To install the Windows 10 (64-bit) and many Linux operating systems, select Enabled for Secure
Boot.
• To install an operating system that does not support secure boot, select Disabled for Secure Boot.
4. Press F10 or Fn+F10 to save the changes and exit.
20
P340 Tiny User Guide
Update UEFI BIOS
When you install a new program, device driver, or hardware component, you might need to update UEFI
BIOS. You can update the BIOS from your operating system or a flash update disc (supported only on
selected models).
Download and install the latest UEFI BIOS update package by one of the following methods:
• Using the built-in software update service:
Ubuntu software update will check the LVFS site for any firmware updates and notify you when updates
are available.
• From the Lenovo Support Web site:
1. Go to
2. Download the flash BIOS update driver for the operating system version or the ISO image version
3. Print the installation instructions and follow the instructions to update the BIOS.
https://pcsupport.lenovo.com.
(used to create a flash update disc). Then, download the installation instructions for the flash BIOS
update driver you have downloaded.
Recover from a BIOS update failure
1. Remove all media from the drives and turn off all connected devices.
2. Insert the BIOS update disc into the optical drive, and then turn off the computer.
3. Disconnect all power cords from electrical outlets. Then, remove any parts that impede access to the
Clear CMOS /Recovery jumper.
4. Move the jumper from the standard position to the maintenance position.
5. Reconnect the power cords for the computer and the monitor to electrical outlets.
6. Turn on the computer and the monitor. When the computer beeps, the recovery process begins.
7. After the recovery process is completed, the computer will be turned off automatically.
Note: Depending on the computer model, the recovery process will take two to three minutes.
8. Disconnect all power cords from electrical outlets.
9. Move the jumper back to the standard position.
10. Reinstall all the parts that have been removed. Then, reconnect the power cords for the computer and
the monitor to electrical outlets.
11. Turn on the computer and the monitor. When the logo screen is displayed, press F1 or Fn+F1.
12. To prevent data loss, ensure that BIOS settings are restored to an earlier point. For BIOS configurations,
see Chapter 5 “UEFI BIOS” on page 17.
Clear CMOS
1. Remove all media from the drives and turn off all connected devices and the computer.
2. Disconnect all power cords from electrical outlets. Then, remove any parts that impede access to the
Clear CMOS /Recovery jumper.
3. Move the jumper from the standard position to the maintenance position.
4. Reconnect the power cords for the computer and the monitor to electrical outlets.
5. Turn on the computer and the monitor. When the computer beeps, wait for approximately 10 seconds.
6. Turn off the computer by holding the power button for approximately four seconds.
7. Disconnect all power cords from electrical outlets.
Chapter 5. UEFI BIOS 21
8. Move the jumper back to the standard position.
9. Reinstall all the parts that have been removed. Then, reconnect the power cords for the computer and
the monitor to electrical outlets.
10. Turn on the computer and the monitor. When the logo screen is displayed, press F1 or Fn+F1.
11. To prevent data loss, ensure that BIOS settings are restored to an earlier point. For BIOS configurations,
see Chapter 5 “UEFI BIOS” on page 17.
22
P340 Tiny User Guide
Chapter 6. RAID
What is RAID
Redundant Array of Independent Disks (RAID) is a technology that provides increased storage functions and
reliability through redundancy. It also can improve data storage reliability and fault tolerance compared with
single-drive storage systems. Data loss resulting from a drive failure can be prevented by reconstructing
missing data from the remaining drives.
When a group of independent physical storage drives is set up to use RAID technology, they are in a RAID
array. This array distributes data across multiple storage drives, but the array appears to the host computer
as one single storage unit. Creating and using RAID arrays provides high performance, such as the expedited
I/O performance, because several drives can be accessed simultaneously.
RAID Level
Your computer must have the minimum number of SATA storage drives installed for the supported level of
RAID:
• RAID 0: striped disk array
– Consists of at least two SATA storage drives
– Supported strip size: 4 KB, 8 KB, 16 KB, 32 KB, 64 KB, or 128 KB
– Better performance without fault tolerance
• RAID 1: mirrored disk array
– Consists of two SATA storage drives
– Improved reading performance and 100% redundancy
Configure the system BIOS to enable SATA RAID functionality
To enable SATA RAID functionality:
1. Restart the computer. When the logo screen is displayed, press F1 or Fn+F1.
2. Select Devices ➙ ATA Drive Setup and press Enter.
3. Select Configure SATA as and press Enter.
4. Select RAID and press Enter.
5. Press F10 or Fn+F10 to save the changes and exit.
Configure RAID in UEFI mode
This section provides instructions on how to configure RAID in UEFI mode.
Create RAID volumes in UEFI mode
Attention: All the existing data stored on the selected drives will be erased while the RAID volume is being
created.
To create RAID volumes:
1. Restart the computer. When the logo screen is displayed, press F1 or Fn+F1.
2. Select Devices ➙ ATA Drive Setup and press Enter.
© Copyright Lenovo 2020 23
3. Select Intel (R) Rapid Storage Technology and press Enter.
4. Select Create RAID Volume and press Enter.
5. Select Name and press Enter. When prompted, type a proper RAID Volume name in the field.
6. Select RAID Level and press Enter. When prompted, select a RAID level in the field.
7. Use the arrow keys and the space key to mark individual physical storage drives to be added in the RAID
volume.
8. Select Strip Size and press Enter. When prompted, select a strip size in the field.
9. Select Capacity and type a volume size in the field.
10. Select Create Volume and press Enter to initiate volume creation.
Delete RAID volumes in UEFI mode
Attention: All the existing data stored on the selected drives will be erased after you delete RAID volumes.
To delete RAID volumes:
1. Restart the computer. When the logo screen is displayed, press F1 or Fn+F1.
2. Select Devices ➙ ATA Drive Setup and press Enter.
3. Select Intel (R) Rapid Storage Technology and press Enter.
4. Select the RAID volume to be deleted and press Enter.
5. Select Delete and press Enter.
6. Select Yes to confirm the deletion of the selected RAID volume. Deleting a RAID volume will reset the
storage drives to non-RAID.
Reset storage drives to non-RAID in UEFI mode
To reset your storage drives to non-RAID:
1. Restart the computer. When the logo screen is displayed, press F1 or Fn+F1.
2. Select Devices ➙ ATA Drive Setup and press Enter.
3. Select Intel (R) Rapid Storage Technology and press Enter.
4. Select the RAID volumes and press Enter to view the detailed information. Select the storage drives you
want to reset to non-RAID and then press Enter.
5. Select Reset to Non-RAID and press Enter.
6. Select Yes to reset the storage drives to non-RAID.
Configure RAID in legacy mode
This section provides instructions on how to configure RAID in legacy mode.
Create RAID volumes in legacy mode
To create RAID volumes:
1. Press Ctrl+I when prompted to enter the Intel (R) Rapid Storage Technology configuration utility during
the computer startup.
2. Use the up and down arrow keys to select Create RAID Volume and press Enter.
3. Type a proper RAID Volume name in the Name field and press Tab.
4. Use the arrow keys to select a RAID level in the RAID Level field and press Tab.
5. If appropriate, use the arrow keys to select a Stripe Size in the Stripe Size field and press Tab.
6. Type a volume size in the Capacity field and press Tab.
24
P340 Tiny User Guide
Loading...
