Setup Guide
M70c
Printed in China
PN: SP40M14433
Initial Setup
* For selected models
Overview
* 1. Optical drive eject butto n
12. DisplayPort® out connector
* 2. Optical drive activity indicator
* 3. Internal speaker
4. Power button
5. Storage drive activity indicator
* 6. SD-card slot
7. Microphone connector
8. Headset connector
9. USB 3.2 connectors Gen 1
10. ThinkCentre® LED
11. Audio line-out connector
Read the statement on USB transfer rate in the User Guide. Refer to the Safety and Warranty Guide for
accessing the User Guide.
13. Serial connector
14. VGA-out connector
15. USB 2.0 connectors
16. USB 3.2 connectors Gen 1
17. Power cord connector
18. Padlock loop
19. Security-lock slot
20. Ethernet connector
21. Smart cable clip slots
* 22. Serial connector
23. PCI-Express card area
* For selected models
Customer Replaceable Units (CRUs)
• Coin-cell battery
• Computer cover
• Front bezel
* • Heat sink for the M.2 solid-state
* • Keyboard
* • M.2 solid-state drive
• Memory module
* • Mouse
Refer to the User Guide for CRU definition.
drive
* • Optical drive
* • Optical drive bracket
* • PCI-Express card
• Power cord
* • Storage drive (a 2.5-inch or 3.5-inch
storage drive)
* • Storage drive bracket
* • Vertical stand
* For selected models
Additional information
European Union — compliance with the
Radio Equipment Directive
Hereby, Lenovo (Singapore) Pte. Ltd., declares that
the radio equipment type ThinkCentre M70c is in
compliance with Directive 2014/53/EU.
The full text of the system EU declaration of
conformity is available at the following Internet
address:
https://www.lenovo.com/us/en/compliance/eudoc
This radio equipment operates with the following
frequency bands and maximum radio-frequency
power:
Technology
WLAN
802.11b/g /n
WLAN
802.11a/n/ ac
WLAN
802.11a/n/ ac
Bluetooth
BR/EDR/LE
Usage of all the radio devices is limited to indoor in
the band 5150 MHz to 5350 MHz (channels 36, 40,
44, 48, 52, 56, 60, 64).
Frequency
band [MHz]
2400 - 2 483.5 < 20 dBm
5150 - 5725 < 23 dBm
5725 - 5875 < 13.98 dBm
2400 - 2 483.5 < 20 dBm
Maximum
transmit
power
E-manual
First Edition (May 2020)
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a
General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to
restrictions set forth in Contract No. GS-35F-05925.
© Copyright Lenovo 2020.
