Lenovo PHAB Plus

Safety, Warranty & Quick Start Guide

Lenovo PB1-770M

English

Read this guide carefully before using your Lenovo PHAB Pl us.

Read before using your Lenovo PHAB Plus

Read first-Regulatory information

Device models equipped with wireless communications comply with the radio
freque ncy and s afety st andar ds of any cou ntry or r egion i n which it h as bee n
approved for wireless use. In addition, if your product contains a telecom modem, it
complies with the requirements for connection to the telephone network in your
co unt ry.

Be sure to re ad the Reg ulator y Notice fo r your cou ntry o r region b efore us ing the
wirele ss devi ces con tained i n your dev ice. To obtain a PD F versio n of the Reg ulator y
Notice, refer to the “Downloading publications” section below.

Getting support

To get support on network service and billing, contact your wireless network operator.
To learn how to us e your dev ice and vi ew its tec hnical s pecifi cation s, go to
http://support.lenovo.com.

Downloading publications

Electronic versions of your publications are available from http://support.lenovo.com.
To download the publications for your device, go to http://support.lenovo.com and
follow the instructions on the screen.

Accessing your User Guide

Your User Guide contains detailed information about your device. To access your User
Guide, go to: http://support.lenovo.com and follow the instructions on the screen.

Legal notices

Lenovo an d the Leno vo logo are t radema rks of Len ovo in the Un ited Sta tes, other
countr ies, or bo th.

Other c ompany, prod uct, or se rvic e names m ay be trade marks o r serv ice mar ks of
others.

Manufa ctured u nder li cense f rom Dolby L abora tories. D olby, Dolby At mos, and th e
double-D symbol are trademarks of Dolby Laboratories.

LIMITED A ND RESTR ICTED RIG HTS NOTICE: I f data or so ftwa re is deli vered pu rsuant
a General Services Administration “GSA” contract, use, reproduction, or disclosure is
subjec t to restri ctions s et fort h in Contr act No. GS-3 5F-05925.

Contents

Lenovo PHAB Plus overview.............................................................1

Preparing your Lenovo PHAB Plus ...................................................2

Starting to use your Lenovo PHAB Plus............................................3

Important safety and handling information ........................................4

European Union Compliance Statement ...........................................5

RF Exposure (SAR) information.........................................................5

Service and Support information.......................................................5

Warranty information ........................................................................6

Environmental, recycling, and disposal information ...........................8

Lenovo PHAB Plus overview

Model

Lenovo PB1-7 70M

Version

LTE (Voice)

5

Front camera

1

Earphone jack

4

7

Micro USB connector

Rear camera

10

Speakers

13

1

234

7.6 mm

7

6

Receiver

2

5

Card slot

8

8

On/Off button

Flash light

11

1

11101312

9

8

186.6mm

96.6 mm

Indicator light

3

Microphone

6

Volume button

9

Anti-noise

12

microphone

Preparing your Lenovo PHAB Plus

You can use cellular services by inserting the Micro SIM and Nano SIM card provided by
your carrier.
The Nano SIM card and microSD card share the card tray. You can insert either Nano SIM
or microSD card at the same time.
Install the Micro SIM card, Nano SIM card or the microSD card as shown.

Step 1.

Insert the SIM eject tool that comes with your device into the hole in the
Micro SIM & microSD card tray.

Step 2.

Pull out the Micro SIM & microSD card tray and position the Micro SIM and
Nano

Step 3.

SIM card or the microSD card into the tray in correct orientation.
Carefully insert the tray with the installed Micro SIM card,
microSD card back into the slot.

or

microSD

Micro SIM

Micro SIM

Nano SIM

microSD

Micro SIM

Nano

SIM or

microSD

Micro SIM

Nano SIM

Micro SIM

Micro SIM card and Nano SIM card work with your Lenovo PHAB Plus.

Use a standard Nano SIM card only. Inserting a modified card or a Nano SIM card
with a SIM card adapter may cause the card to not fit properly or damage the card
slot or your device.

2

Starting to use your Lenovo PHAB Plus

Before using your device, you might need to charge the battery.
Charge the battery as shown.

Connect your device to a power outlet using the included cable and USB power
adapter.

Low battery Fully charged

Turning on/off

Turn on: Press and hold th e On/Off button u ntil the Le novo

logo appears.
Tur n off : Press and hold th e On/Off button f or a few
secon ds, then ta p Power off.

Restart:

Press an d hold the O n/Of f button f or abou t 10
seconds.

Press and hold the On/Off button for a few seconds,
then tap Restart.

Taking screenshots

Press and hold the On/Off button and the volume down button at the same time.

3

Charging

Important safety and handling information

Plastic bag notice

DANGER: Pl astic ba gs can be d angero us. Keep p lastic b ags away fro m babie s and

childr en to avoid da nger of s uffoc ation.

Built-in rechargeable battery notice

DANGER: Do n ot attem pt to replac e the inte rnal rec harge able li thium io n batter y.

Contact Lenovo Support for factory replacement.

Polyvinyl Chloride (PVC) cable and cord notice

WARNING: Handlin g the cord on t his prod uct or co rds asso ciated wi th acce ssori es

sold wit h this prod uct wil l expose yo u to lead, a ch emica l known to th e State of
Califo rnia to cau se canc er, and bir th defec ts or other r eprodu ctive ha rm. Wash ha nds
after handling.

Prevent hearing damage

Your device has a headphone connector. Always use the headphone connector for
headphones (also called a headset) or earphones.

CAUTION: Excessive sound pressure from earphones and headphones can
cause h earin g loss. A djust ment of th e equal izer to ma ximum increa ses the
earph one and h eadph one out put volt age and t he soun d press ure leve l.
There fore, to p rotec t your hea ring, a djust t he equa lizer to a n appro priat e level.

Exces sive use of h eadph ones or e arpho nes for a lo ng peri od of time at h igh volu me
can be dangerous if the output of the headphone or earphone connectors do not
comply with specifications of EN 50332-2.

The headphone output connector of your device complies with EN 50332-2 Sub
clause 7. This sp ecific ation li mits the de vice's ma ximum w ide band t rue RMS o utput
voltag e to 150 mV. To help prote ct again st hear ing los s, ensure t hat the he adphon es or
earph ones you u se also c omply wi th EN 50332-2 (Cl ause 7 lim its) for a wi de band
charac terist ic voltag e of 75 mV. Using headp hones t hat do not co mply wi th EN
50332-2 can b e dange rous due to exc essiv e sound pr essure l evels.

If your dev ice cam e with he adphon es or ear phone s in the pac kage, as a s et, the
combination of the headphones or earphones and the device already complies with
the spec ificati ons of EN 503 32-1. If different h eadpho nes or ea rphon es are us ed,
ensure t hat they co mply wi th EN 50332-1 (Claus e 6.5 Limit ation Valu es). Using
headph ones th at do not com ply wit h EN 50332-1 can be da ngerou s due to exce ssive
sound pressure levels.

This dev ice is re stricte d to indoo r use when o perati ng in the 5.15 to 5.35 GHz
frequency band.

4

Sound pressure warning statement

For the dev ice that i s tested in a ccorda nce wit h EN 60950 -1:
2006+A11:2009+A1:2010+A12:2011, it is mandato ry to per form audio tests f or
EN50 332.

This dev ice has b een teste d to compl y with the S ound Pre ssure Le vel requ iremen t laid
down in the a pplic able EN 50 332-1 and/or EN 50332-2 st andard s. Perma nent he aring
loss may occur if earphones or headphones are used at high volume for prolonged
perio ds of time.

Warning statement:

To prevent pos sible he aring d amage, d o not liste n at high vol ume leve ls for a lon g
perio d of time.

European Union Compliance Statement

Radio and Telecommunications Terminal Equipment Directive

0560

Lenovo de clare s that this p roduct i s in comp lianc e with:

The ess ential r equire ments an d other re levant p rovisio ns of the Rad io and
Telecommunications Terminal Equipment Directive, 1999/5/EC

All othe r relevan t EU direc tives

The Declaration of Conformity information is located in the Regulatory Notice. To
obtain a PD F versio n of the Regulatory Notice, go to http://support.lenovo.com.

RF Exposure (SAR) information:

To comply wit h SAR requ iremen ts the dev ice must b e used wi th a separ ation di stanc e
of at leas t 10mm to the hum an body.
Users ha ve to adopt a ho lster/slee ve/cover or ot her ways to ma intain t his dist ance.

Service and Support information

The following information describes the technical support that is available for your
product, during the warranty period or throughout the life of your product. Refer to the
Lenovo Li mited War ranty f or a full ex planat ion of Len ovo warra nty term s. See “Le novo
Limite d Warrant y notic e” later in th is docum ent for de tails on a ccess ing the f ull
war rant y.

5
