Lenco Tab 712 Operating Instructions

TAB-712

18 CM (7") INTERNET TABLET WITH

ANDROID™ 4.0

User manual

www.lenco.eu

V1.0

Table of contents

What is in the box? ..................................................................................................... 5

Exploring the tablet .................................................................................................... 6

Exploring the home screen ..................................................................................... 7

Getting started............................................................................................................ 8

Where to use .......................................................................................................... 8

Charging the battery ............................................................................................... 8

Battery maintenance ............................................................................................... 8

Create a Google account ........................................................................................ 8

Operating the touch screen ..................................................................................... 8

Configuration of the tablet .......................................................................................... 9

Connect to the internet via Wi-Fi ............................................................................. 9

Connect to the internet via a 3G Dongle ............................................................... 10

Basic operation ........................................................................................................ 11

Switch the tablet on / off ........................................................................................ 11

Lock / unlock the touch screen and buttons .......................................................... 11

Operating the notifications panel ........................................................................... 11

Add apps to the home screen ............................................................................... 11

Add Widgets to the home screen .......................................................................... 11

Move items on the home screen ........................................................................... 12

Create folders on the home screen ....................................................................... 12

Delete items from the home screen....................................................................... 12

Opening apps ....................................................................................................... 12

Recently used apps .............................................................................................. 12

Multi-tasking .......................................................................................................... 12

Managing apps ..................................................................................................... 12

System settings ........................................................................................................ 13

Wireless & networks.............................................................................................. 13

Device, sound ....................................................................................................... 14

Device, display ...................................................................................................... 15

Device, storage ..................................................................................................... 15

Device, battery ...................................................................................................... 15

Device, Apps ......................................................................................................... 15

Personal, Accounts & sync ................................................................................... 16

Personal, Location services .................................................................................. 16

Personal, Security ................................................................................................. 16

Personal, Language & input .................................................................................. 17

Personal: backup & reset ...................................................................................... 18

System: date & time .............................................................................................. 18

System: accessibility ............................................................................................. 18

System: developer options .................................................................................... 18

System: about tablet ............................................................................................. 18

Preinstalled apps ...................................................................................................... 19

Adobe reader ................................................................ ........................................ 19

Aldiko ................................................................................................ .................... 19

Browser................................................................................................................. 19

Calculator .............................................................................................................. 20

Calendar ............................................................................................................... 20

Camera ................................................................................................................. 20

Clock ..................................................................................................................... 20

Documents to go ................................................................................................... 21

Downloads ............................................................................................................ 21

E-Mail ................................................................................................................... 21

File manager ................................................................ ......................................... 21

Gallery .................................................................................................................. 22

Hi-Q MP3 Recorder .............................................................................................. 22

Maps ..................................................................................................................... 23

Music .................................................................................................................... 23

Connect the tablet with a computer .......................................................................... 23

Trouble shooting ................................ ................................................................ .... 24

3G Dongles. This tablet supports the following 3G Dongles. .................................... 25

Specifications ........................................................................................................... 26

Keep your personal and important data safe ............................................................ 26

Safety instructions ................................................................ .................................... 28

National Restrictions ................................................................................................ 30

Declaration of Conformity ......................................................................................... 30

Do not distribute copyright-protected material .......................................................... 30

Disclaimer ................................................................................................................ 31

Service and support ................................................................................................. 32

End of life ................................................................................................................. 33

Dear customer,

Thank you for buying this Lenco product. Quality and usability is our top priority. In order to let you fully enjoy this tablet, we have manufactured this product using high quality standards, materials, components, and care.

Please read all safety instructions and national restrictions, before you use this tablet.

Note:

This user manual was printed prior to the development of this product. When operability or other functions needed improvement, priority went to the product specification itself, and not to this manual.

In such instances, the instruction manual may not entirely match all the functions of the actual product. Therefore, the actual product and packaging, as well as the name and illustration, may differ from the manual. The screen shown as an example in this manual may differ from the actual screen display.

Lenco is not liable for any consequential damage.

What is in the box?

This tablet has been assembled with the utmost care. If, however, an accessory is missing, please contact your local dealer immediately.

Checking the accessories supplied:

1 x Tablet 1 x AC Power adaptor 1 x USB cable 1 x USB host cable 1 x Quick guide

Exploring the tablet

Volume + button: Press this button to increase the volume. Volume - button: Press this button to lower the volume. Return button: Press this button to go back to the previous screen / menu. Micro SD slot: This is to insert an SD card. DC in 5V socket: This is to connect the AC adaptor to charge the internal battery. Reset button: Press this button if the tablet does not respond. Use a thin object like

a paperclip to push the reset button. USB socket: This is to insert the USB cable so you can establish a connection between the tablet and a PC. This USB host socket supports external hardware like

3G dongles or keyboards. Check with your external hardware seller to see if the hardware is compatible with the tablet.

Earphone socket: This is to connect a 3,5mm ear- or headphone. ON/OFF button: Press and hold this button for 5 seconds to turn the tablet on, or off.

To put the tablet in standby mode, press and hold this button briefly. If the tablet is in the standby mode, press this button briefly to switch it on.

Exploring the home screen

1. Return icon: touch this icon to go back to the previous screen.

2. Home icon: touch this icon to return to the home screen (app(s) will continue to run on the background).

3. Multi-task icon: touch this icon to display all running apps, touch an app to open it.

4. Options icon: touch this icon to open the options for the screen or app.

5. Clock: this icon shows the actual time.

6. Battery status: This icon shows how much time the battery has left before it needs a recharge. If the charger is connected, it also shows that it is charging.

7. App menu icon: touch this icon to open the app menu.

8. Voice control icon: touch this icon to activate voice control.

9. Google search icon: touch this icon to open Google search.

This tablet has multiple home screens. Put your index finger on the screen and leave it there. Then move it left or right to go to the next or previous home screen.

Getting started

Where to use

Never leave this tablet in direct sunlight or any other strong light. For comfortable viewing, we recommend a soft light. Always make sure that direct sunlight does not fall on the screen. When the tablet is not in use, place it on a sturdy platform of which

the surface should be flat and steady, so the tablet can’t fall. Make sure the tablet is

stored in such a manner that nothing can fall on top of it, as pressure will damage or break the screen. Prevent insertion of small objects into the ventilation slots, or openings in the cabinet at all time.

Charging the battery

Important note: When the tablet was produced, the battery wasn't fully charged.

Before using the tablet for the first time, charge the battery for a minimum of 8 hours. If the battery isn't fully charged before using it for the first time, it may influence the battery lifetime.

Connect the AC adaptor to a wall outlet before you connect it with your tablet. When the battery is charging, the battery symbol displays as follows: .

Once the battery is fully charged, the battery symbol displays as follows: It is possible to use the tablet while charging. However, this will extend the charging time and reduces the battery lifetime. Note: You can also use an USB cable to charge the battery. However, this charging process takes more time. Remark: If the battery is empty, the tablet does not work during the first 30 minutes of charging.

Battery maintenance

To maximize the battery lifetime, please follow these instructions:

 Use the tablet at least once a week.  Charge the battery regularly.  Do not keep the battery too low for a long time.  Always keep the tablet away from a heat source.

Create a Google account

If you want to use the tablet online for downloading apps etc, you need to have a Google account. Visit www.google.com to create an account.

Operating the touch screen

 Touch the screen to select an option, and then tap twice to open an

app.

 Touch and hold your finger on the screen to open extra options. When you

already are in the app menu and you touch and hold, the app will create a shortcut to the home screen.

 To move through the menus, quickly move your index finger up,

down, left, or right.

 Tap on an item, hold it, and drag it to a new location.

Configuration of the tablet

Important note: Before you start the configuration, make sure that there is an

internet connection available.

Turn the tablet on

Press and hold the power button for 5 seconds to switch the tablet on. Please wait until the tablet is booted. This may take a few minutes. Then, to unlock the home screen, move the circle to the lock.

Connect to the internet via Wi-Fi

Open system settings by tapping on the “options” icon and then select "system settings" in the menu.

Now go to the WIRELESS & NETWORKS menu, tap on, and hold Wi-Fi. Then move it to the right so that the slider changes to ON. The tablet will now start scanning for networks.

 Select your access point.  Enter the password (if required).  Select connect.

If you have a "hidden network," select ADD NETWORK and follow the instructions on the screen.

Connect to the internet via a 3G Dongle

Important note: this tablet does not support every 3G Dongle. Check the

compatibility list to make sure you can use your 3G Dongle.

 Install the SIM card into the 3G Dongle.  Connect the USB host cable to the Dongle.  Connect the 3G Dongle to the tablet.  Open system settings by tapping on the “options” icon and then select in the

menu "system settings.”

 Select more...  Select mobile networks  Switch on mobile data. To do this, mark the checkbox behind "data enabled.”  Now you can configure the Dongle.

Note: This manual does not describe how to setup your Dongle because this depends on the operator and the kind of Dongle or Dongle brand that is connected.

The symbol appears on the screen after connecting to a 3G network. If the symbol is grey, the Dongle is scanning for a network (so it is not connected).

When data is being transferred, the following symbol is shown: .
