User Manual
for the following models:
Vip Line
Elizabeth - PL92T
Dimensions:
31x27x38 cm
Net weight:
12 kg
Power supply:
230V 50Hz / 120V 60Hz
Power:
Coffee heating element: 1200 W
Steam heating element: 1000 W
Pump pressure:
15 bar
Water Tank Capacity:
2.5 lt
Brass boiler capacity:
300 ml
Stainless steel steam boiler capacity:
600 ml
EN
English
VIP Line - Elizabeth - PL92T
2
THANK YOU
FOR CHOOSING US
Careful design and choice of components are the secret
of the excellent performance of all our models.
We develop our products with the technology applied
only to the best professional machines. The materials
used meet very high standards of quality and reliability
to provide you with durable, and long-lasting products.
Write down the serial number of your product
Serial number
Purchased from Date of purchase
For more information,
please register your product on care.lelit.com
Lelit Espresso - English
Index
Safety notes 4
Main specications 9
LCC - Lelit Control Center 10
Product overview 11
Instructions for use 12
Programming menu parameters 17
The art of Espresso coffee 19
Cleaning and maintenance 23
Solving the most common problems 26
EN
3
Warranty terms 28
VIP Line - Elizabeth - PL92T
01.
Safety notes
Warnings - Please read carefully before use. This espresso machine is suita-
4
ble for the preparation of 1 or 2 cups of coffee; it is equipped with 2 wands
for dispensing steam and hot water. The controls on the front panel have
easy understandable symbols. The machine is designed for domestic use
and is not suitable for continuous professional use. The noise rating of the
unit does not exceed 70 dB (A). The data and images shown are subject to
change without notice in order to improve the performance of the machine.
Symbols used
It is absolutely essential to observe the following warnings and symbols:
Shock hazard. Failure to comply may cause electric
shock with danger to life.
Burn hazard. Failure to comply may cause severe burns.
Caution. Failure to comply may cause damage to the
appliance.
Please Note. is symbol indicates important advice and
information for the user.
Numbers in brackets
The numbers in brackets refer to the key provided in the description of the
appliance in Chapter 04 “Product overview“ and to the pictures in the
Quick start guide attached.
Lelit Espresso - English
EN
IMPORTANT
SAFEGUARDS
General warnings
This manual is an integral and essential
part of the product. Please read all these
warnings carefully as they provide important information on safe installation,
use and maintenance. These instructions
should be carefully retained for future reference.
- This appliance can be used by children
aged from 8 years and above and persons with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction concerning use
of the appliance in a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and
user maintenance shall not be made by
children without supervision.
- This appliance can be used by children
aged from 8 years and above if they have
been given supervision or instruction
concerning use of the appliance in a safe
way and if they understand the hazards
involved. Cleaning and user maintenance shall not be made by children unless
they are older than 8 and supervised.
Keep the appliance and its cord out of
reach of children aged less than 8 years.
- Appliances can be used by persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand
the hazards involved. Children shall not
play with the appliance.
- This appliance is intended to be used in
household and similar applications such
as: staff kitchen areas in shops, ofces
and other working environments; farm
houses; by clients in hotels, motels and
other residential type environments; bed
and breakfast type environments.
- The appliance is only designed for making espresso coffee or hot drinks using
the hot water or steam tubes and for
pre-heating cups.
- Store the packaging material (plastic
bags, polystyrene, etc.) out of the reach of
children.
- The appliance is only designed for making espresso coffee or hot drinks using
the hot water or steam wands and for
pre-heating cups.
5
VIP Line - Elizabeth - PL92T
- Any use other than that described above
is improper and could be hazardous; the
manufacturer accepts no liability whatsoever for any damage arising from impro-
6
per use of the appliance.
- This appliance is not intended for use
by persons (including children) with
- No liability is accepted for repairs not
carried out by authorized service centres.
- The manufacturer accepts no liability
for tampering with any of the appliance
components.
In all the above cases the warranty will be
void.
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning use
of the appliance by a person responsible
Essential
safety warnings
for their safety.
- Children must not be allowed to play
with the appliance.
- The appliance must not be left unatten-
As with all electrical appliance, the risk of
electric shock cannot be excluded, therefore, the following safety warnings should
be carefully observed.
ded or used outdoors.
- The appliance should not be immersed
in water or cleaned by spraying.
- The appliance must not be exposed to
atmospheric agents (rain, sun, ice).
- If the appliance is stored in rooms where
the temperature can go below freezing,
the tank and the water pipes must be
emptied.
- All the packing material (plastic bags,
polystyrene, etc.) should be keep out of
the reach of children.
- No liability is accepted for the use of
unauthorized spares and/or accessories.
- To avoid spilling the connector, never
pull the power cord.
- Always attach plug to appliance rst,
then plug cord into the wall outlet.
- To disconnect the appliance, turn any
control to “off”, then remove plug from
wall outlet.
- In the event of any fault or malfunction,
do not attempt to carry out repairs. Switch
the appliance off, remove the plug and
contact the Service Centre.
- In the event of damage to the plug or
the power cord, do not operate the ap-
Lelit Espresso - English
EN
pliance, these should be replaced only
and exclusively by the Service Centre.
- Unplug from outlet when not in use.
- Before cleaning the exterior surfaces of
the appliance, putting on or taking off
parts, switch it off, remove the plug from
the outlet and allow to cool.
- To reduce the risk of injury do not drape
cord over the counter top or table top
where it can be pulled on by children or
tripped over unintentionally.
- Do not let cord touch hot surfaces.
- Do not let cord hang over edge of table
or counter.
- The use of accessory attachments not
recommended by the appliance manu-
facturer may result in re, electric shock or
injury to persons.
- Do not place on or near a hot gas or
electric burner, or in a heated oven.
- Do not touch the plug with wet hands.
- Ensure that the electrical outlet is always
freely accessible so that the plug can be
easily removed when necessary.
- When removing the plug, always hold
it directly. It should never be removed by
pulling on the power cord, as this can cause damage.
- To protect against re, electric shock and
injury to persons do not immerse cord,
plugs in water or other liquid.
- Do not use adapters, multiple sockets
or extension cords. If their use is unavoidable, use simple adapters or multiple
sockets and extension cords that conform
to current safety standards, taking care
not to exceed the current limit marked
on the simple adapter or extension cord,
or the maximum capacity of the multiple
socket.
7
- Before switching on, ensure that the
power supply voltage corresponds to that
indicated on the plate on the base of the
appliance and that the power supply is
properly earthed.
- Do not tamper with the appliance. Contact an authorized technician or the nearest service centre for any problem.
- Do not touch the appliance if your hands
or feet are wet.
Warning about
burn/scald risks
This appliance produces hot water and
steam; therefore, the following safety warnings should be strictly observed.
- Warning: hot surfaces remain hot for a
certain time also after use.
VIP Line - Elizabeth - PL92T
- Take care to avoid contact with water
spray or jets of steam.
- When the appliance is switched on, do
not touch the cup warming plate as it is
8
hot.
- Never direct the steam or water spray
towards your body.
- Be careful when touching the steam
wand (12).
- Never remove the lterholder (e) during
operation.
- The parts labelled “CAUTION HOT” are
very hot, so approach and operate them
with maximum caution.
- Only place cups and glasses for use with
the coffee machine on the cup warmer
(8). Other objects should not be placed
there.
- Dry the cups thoroughly before placing
them on the cup warmer (8).
SAVE THESE
INSTRUCTIONS
02.
Main specications
Lelit Espresso - English
EN
We design our machines based on our customers’ needs.
We are sure that the features selected for this model will meet all your wishes, so
you can make perfect tasting espresso for yourself and your guests.
LCC
To adjust the boiler
temperature, control the
perfect settings for making
coffee.
Coffee Slider
An innovative dispensing
spout that can be used for
both one or two cups and
that allows the user to see
the coffee cream on its way
towards the cup.
Pre-infusion with
programmable
parameters
To moisten the coffee for a
few seconds before the start
of the actual brewing stage.
This compacts the coffee
powder and improves the
ow of the espresso.
Stainless steel
For maximum hygiene in the
kitchen and easy cleaning
of the appliance. A simple
wipe with a sponge and your
machine will shine again.
Dual boiler
Two separated boilers,
one for steaming and one
for brewing. This system
allows more temperature
stability and enables
dispensing steam and coffee
simultaneously.
Energy saving
When the machine is not
used for a long time, it
automatically enters the
power-saving mode. This
saves money for you and
valuable resources for the
planet.
9
10
VIP Line - Elizabeth - PL92T
03.
LCC - Lelit Control Center
LCC (Lelit Control Center) is the brain of the new Lelit espresso machines. It has
an elegant, graphic LED display of the latest generation. It controls all the functions of the machine and allows you to adjust the settings, as well as giving valuable tips on how to achieve the best results.
LCC lets you manage a number of settings in your machine:
- The temperature of the coffee
dispensed
- The temperature of the steam
dispensed
- Programmable brewing times
- Programmable pre-infusion times
- Steam boiler enabling/disabling
- Chronometer of the coffee
dispensing
- Selection of the temperature unit
measure
- Backushing
Everything
under control
e user interface, that
operates the display,
constantly communicates
the machine status and
suggestions to get the best
Espresso.
Lelit Espresso - English
EN
04.
Product overview
Take your new espresso coffee machine out of the box and have a look at the
various components and accessories designed for you. The numbers refer to
the pictures in the Quick start guide attached.
11
1. On/off switch
2. Coffee switch
(with pre-infusion prole 1)
3. Coffee switch
(with pre-infusion prole 2)
4. Hot water switch
5. Hot water nozzle
6. Self-cleaning cup-holding grate
7. Water tank cover
What’s in the box
a. Plastic tamper
b. Coffee measuring spoon
c. Power cord
d. Blind lter
e. Filterholder with lter for 1 and 2 cups
f. Espresso cup rack
g. LELIT Resin lter, code MC747
8. Wide cup warmer
9. Backlight brew pressure gauge
10. Steam dispensing knob
11. LCC (Lelit Control Center)
12. Multi-directional anti-burn
steam wand
13. Coffee distribution group
14. Removable water drainage tray
12
VIP Line - Elizabeth - PL92T
05.
Instructions for use
Lelit coffee machines are not automatic. To make a good cup of coffee, you
must know how to use them properly and will need a bit of practice. Follow the
instructions carefully. You can also refer to the Quick start guide where you will
nd illustrated instructions. You’ll soon be making coffee just like in the cafes,
with the ideal smooth, creamy texture you prefer.
to start
Starting the machine
It is important to carefully follow these instructions the rst time the machine is
started, to ensure that it works properly. These instructions are only for the rst
time the machine is used. The instructions given in the subsequent chapters are
for all further use. For subsequent uses do not consider this chapter and follow
the chapter Making an Espresso.
Open the packaging
A
A.1 Open the packaging and place the machine on a at surface.
Be careful. e unit weighs 12 kg
Water lling
B
B.1 Remove the tank from its seating (7).
B.2 Fill the tank with water at room temperature.
B.3 Replace the tank in its seating.
Caution. e tank is tted with a device that automatically detects the presence
of water. When repositioning the tank, check that the tubes are not bent and that the lter
is fully inserted into the end of one of them. In case of lack of water, the LCC will shows a
warning signal. Follow the instructions in section B to rell the tank.
Switch on the coffee machine
C
Be careful. Ensure the power supply voltage is the same as that indicated on the
information plate and that the supply system has an adequate circuit breaker.
Lelit Espresso - English
C.1 Connect one end of the power cord (c) to the socket in the machine and the
other (plug) into the wall socket.
C.2 Turn on the espresso machine by pressing the main on/off switch (1). The
display (11) will show the Lelit logo, the three switches and the gauge will go
on for a short time.
EN
Note. ONLY for the rst time that the machine is switched on, the machine will
start to ll the boiler automatically. During this operation, water will ow from the coee
distribution group for about 40 seconds and the Lelit logo will ash on the LCC display.
C.3 On the LCC display (11) you’ll see the water boiler temperature ashing.
This will grow until the set temperature will be reached. During this phase,
the steam boiler will be automatically lled until the correct water level will be
reached.
C.4 Wait until the bar is fully loaded and “Ok” appears on the display. This way
the machine will reach the set temperature.
C.5 After reaching the pre-set temperature, the bar will disappear, and the
machine will be ready for use.
Checking that the machine is working properly
D
Coffee
D.1 Insert the lterholder (e) without coffee rmly onto the coffee distribution
group (13), so as to align the handle with the padlock symbol on it.
Note. With a new machine, in order to reach this position, it is advisable to moisten
the edge of the lter with water. Aer a short period of use, this position will be reached
regularly without excessive eort.
D.2 Press the coffee switch (2) to dispense about half a litre of water. The display (11) will show the coffee icon and the chronometer that detects the coffee
dispensing time.
D.3 When you’ve taken about half a litre of water, press the switch (2) to stop
dispensing.
13
Note. This procedure helps filling the hydraulic circuit completely and rinsing
the circuit itself.
Hot water
D.4 Place a jug under the hot water nozzle (5).
D.5 Press the hot water switch (4). The pump starts and the water icon appears
on the display (11).
D.6 As soon as water comes out of the nozzle (5), press the switch (4) again to
stop dispensing.
VIP Line - Elizabeth - PL92T
Steam
D.7 Point the steam wand (6) onto the cup-holding grate (12)
D.8 Turn the steam knob (10) counter clockwise.
D.9 When steam comes out from the nozzle, turn the knob (10) clockwise to
close it.
14
Note. If the machine hasn’t been used for 30 minutes or more, the machine will go
in stand-by (energy saving status). e display and the heating element will be switched
o and the coee switch (2) will ash every 3 seconds to indicate the stand-by status. To
restart the machine, you’ll have to press the coee switch (2).
to start
Making an Espresso
Thanks to the pre-set function settings, the machine is immediately ready to
dispense espresso coffee. To change the settings, please refer to “Changing the
LCC settings” section.
Note. e machine comes with a cup warmer (8). Using warm cups enhances the
organoleptic qualities, the avour and aroma of an Espresso.
Preparing the machine for making coffee
E
E.1 Turn on the espresso machine by pressing the main on/off switch (1). The
display (11) will show the Lelit logo, the three switches and the gauge will go
on for a short time.
E.2 Insert the lterholder (e) without coffee rmly onto the coffee distribution
group (13), so as to align the handle with the padlock symbol on it.
E.3 On the LCC display (11) you’ll see the water boiler temperature ashing.
This will grow until the set temperature will be reached.
E.4 Wait until the bar is fully loaded and “Ok” appears on the display. This way
the machine will reach the set temperature.
E 5 After reaching the desired temperature, the bar will disappear, and the
machine will be ready for use.
Distributing the coffee
F
F.1 Insert the selected lter into the pre-warmed lterholder (e).
F.2 Fill the lter with the desired quantity of ground coffee.
Note. We suggest 7 g for one cup and 14 g for two cups.
F.3 Press the coffee with the tamper (a) and clean any coffee residues from the
Lelit Espresso - English
lter holder edge.
F.4 Insert the lter holder (e) in the distribution unit (13) and fasten it rmly, at
least up to align the handle with the padlock symbol indicated on the group
F.5 Place one or two coffee cups on the cup-holding plate (6), under the lter
holder (e).
F.6 Press the coffee switch (2) or (3) to start dispensing. The display (11) will
show the coffee icon and the chronometer that detects the coffee time dispensing.
F.7 Once the required amount of coffee is reached, press the coffee switch (2 or
3) to stop dispensing. The display (11) will show the time of the coffee dispensing for about 2 seconds, then “OK” and then the pre-set temperature.
EN
Note. If a brewing time (see the chapter 6.3) for the coee switches (2) or (3) has
been specically programmed in the menu machine parameters, the coee dispensing will
automatically stop once the programmed time has been reached.
F.8 Remove the lter holder (e), empty it and clean it carefully with a damp cloth
Caution. e lterholder must not be removed before coee brewing is completed.
Note. To prepare a good espresso, the coee pump pressure gauge (9) must be in the
green zone, while dispensing is in progress.
for experts
Steam and hot water
15
The device is equipped with a steam wand that can foam the milk to perfection,
producing the creamy and compact foam that is the mark of the real cappuccino.
Preparing the coffee machine
G
G.1 Check the water level in the tank. If there is no water, follow the instructions
in paragraph B.
G.2 When the temperature value shown on the display stops ashing, the coffee machine will be ready for use.
Caution. Never place your hands or other body parts under the steam wand or hot
water nozzle. Risk of scalding
Steam distribution
H
H.1 Open the knob (10) counter clockwise with the steam wand (12) pointed at the
cup-holding grate (6) and release the initial amount of water.
16
VIP Line - Elizabeth - PL92T
H.2 When steam comes out, close the knob (10), place a jug with the beverage to be
foamed under the steam wand (12), re-open the steam knob (10).
H.3 When the desired result has been achieved, close the steam knob (10) turning
it clockwise.
Note. e machine, thanks to its electronic controls, returns to the coee/water
function if the steam function has not been used for a certain period.
Note. See chapter 06 “e art of Espresso coee” for the best way to froth milk.
Caution. Clean the steam wand (12) aer every use by pointing the steam wand
to the cup-holding grate and dispensing some steam. oroughly clean the wand (12) with
a sponge or clean cloth. In the chapter “Cleaning and maintenance”, you will nd all the
necessary advice.
Hot water distribution
I
I.1 Place a jug under the hot water nozzle (5) and press the hot water switch (4).
I.2 When the desired amount has been reached, press the hot water switch (4) to
stop dispensing.
Note. e machine is equipped with an electronic control that stops the water
function aer a predetermined time. To withdraw more water, repeat the “Dispense hot
water” operation.
for experts
Adjusting the LCC settings
The LCC - Lelit Control Center (11) has pre-set default settings. Here you can
discover how to adjust them.
Changing the factory settings
J
J.1 Press the “-” button to enter settings mode, and scroll through the menu.
J.2 Press “+” to change the setting. The setting ashes.
J.3 Change its value and/or state by using the “-” and “+” buttons.
J.4 3 seconds after the last press of a button, LCC stores the data and exits from
settings mode.
Lelit Espresso - English
06.
Programming menu parameters
1
Coffee boiler temperature
Variable value: from 80°C to 110°C.
2
Steam boiler temperature
Variable value: from 120°C to 145°C.
3
Brewing time for coffee switch (2) and (3)
EN
17
If you program a brewing time higher than zero, when you press the switch (2) or (3), the coffee
dispensing starts and it will automatically stop once the programmed time has been reached.
Selecting “OFF”, you need to press again the coffee switch (2) or (3) to stop dispensing once the required
amount of coffee has been reached.
Variable value: from 1 second to 99 seconds.
Note. e coee volume in the cup can vary according to the grinding size used.
4
Pre-infusion parameters for coffee switch (2) and (3)
18
VIP Line - Elizabeth - PL92T
If you program a pre-infusion time which is higher than zero, by pressing the switch (2) or (3) to start
the coffee dispensing, the ground coffee in the lterholder will be made wet by the water without the
pressure of the pump, for the programmed time. Once the pre-infusion time is over, the pump will be
activated, and will start the coffee brewing in the cup at full pressure.
Selecting “OFF” the pre-infusion will be disabled.
Variable value: from 1 second to 20 seconds.
Nota. If the Steam boiler is disabled, the pre-infusion will not be available.
5
Steam boiler enabling/disabling
Select “OFF” or “ON” to disable or enable the steam boiler.
With the steam boiler disabled (OFF), the energy consumption of the machine will be reduced.
The pre-infusion function and the steam distribution will not be available.
The display will show the
simbol to indicate that the machine is in “Economy” mode
6
Temperature unit measure selection, Celsius or Fahrenheit
By selecting the Fahrenheit degrees, the display will show the “F” letter next to the temperature value
7
Partial and total doses counter
5”
The display shows the numbers of the partial (PaR.) and total (ToT.) doses, that have been carried out.
When the counter doses are shown, keep pressed for at least 5” the “+” button to reset the partial
counter.
Note. e total doses counter cannot be reset to zero
07.
The art of Espresso coffee
Lelit Espresso - English
EN
Contrary to what you might think, making a perfect Espresso is not that easy.
It takes experience, ability, passion and a little bit of curiosity. In this paragraph
we would like to share with you some of the basic rules for making a perfect
cup of Espresso.
Suggested doses:
Ristretto (Strong) about 20 ml – Espresso about 30 ml – Lungo (Long) about 60 ml.
The “5 M’s”
If you want to make perfect Espressos,
you should start by ensuring the ve essential factors which turn a simple cup
of coffee into an Espresso for connoisseurs! These are the “5 M’s”; in Italian:
miscela (blend), macinatura (grinding),
macchina (machine), manualità (skill) and
manutenzione (maintenance).
1 - Miscela (Blend)
Good Espressos are always made with
a good blend of coffee. An Espresso
with the right taste requires a blend of
two types of coffee, Arabica and Robusta. The rst gives the coffee its delicate
aroma and the right amount of acidity,
while the second type gives it its full
taste, body and cream. The quantities
depend on your own taste. Try out different combinations until you nd the
blend you like best!
2 - Macinatura (Grinding)
The grinder is a must for making good
Espresso. Coffee should always be
ground just before it is used so that it
preserves its taste and aroma. The Lelit
grinders let you adjust the grinding level
to suit the coffee blend in order to establish the correct extraction time and
amount of cream.
3 - Macchina espresso
(Espresso machine)
Lelit machines are designed and built
so that the water temperature can be
adjusted to suit your needs. In addition,
setting this variable correctly will allow
you to extract from the ground coffee,
not only the soluble substances that
give it taste, but also the non-soluble
ones that give body and avour to your
coffee.
4 - Manualità (Skill)
Half of the result depends on how you
use the machine. A passionate expert
is an essential part of the Espresso
production chain and can enhance the
result to bring additional value to the
nal product. Passion and practice are,
therefore, the secrets to learning how to
use the machine. You can experiment
with different blends of coffee, grinding,
pressing, water temperature and pressure, not just to make an Espresso, but
19
VIP Line - Elizabeth - PL92T
Arabica
It is grown between 900/2000 m
Rich aroma.
Caffeine between 0.9 ~ 1.7%
Robusta
It is grown between 200/600 m
Spicy aroma.
Caffeine between 1.8 ~ 4%
Arabica
It is grown between 900/2000 m
Rich aroma.
Caffeine between 0.9 ~ 1.7%
20
to make the one that is just right for you.
5 - Manutenzione (Maintenance)
Daily maintenance, scheduled maintenance and care of the machine will
ensure the quality of the beverage and
the durability of the product you have
purchased. A clean machine says a lot
about your passion for coffee making.
Coffee varieties
The choice of the blend is an essential
factor for making the ideal coffee for
your taste. There are a lot of different
varieties of coffee blends on the market to choose from. The differences in
avour, aroma and texture depend on
the quantities of the two varieties of
coffee that make the blend.
Arabica
This is a sweeter and more delicate
variety of coffee, with a rich aroma
and cream that is very thin, dense and
compact.
Robusta
This variety is woody, bitter, fullbodied and spicy, with little aroma.
Its cream is more frothy and grey.
No variety of coffee can make an ideal
Espresso on its own.
The perfect Espresso has a top layer
of cream 2-3 mm thick, a nut brown to
dark brown colour, with reddish tinges
and light streaks, a harmonious avour, a strong, balanced aroma and a
sweet, long-lasting aftertaste.
It has a strong aroma with notes of
o-wers, fruits, toast and chocolate.
These sensations can last just a moment or can persist for a few minutes
in your mouth. The taste is round and
well structured. The acid and bitter
perceptions are well balanced whereas there is little or no astringency.
The ideal parameters to obtain this type
of coffee are:
7 ± 0,5 g. of ground coee.
25 seconds to brew 30 ml.
88 / 92°C when brewing and 80°C in the cup.
8 /10 bar pressure during extraction.
Even Arabica blends often contain a
small amount of Robusta, which is necessary to enhance the cream and add
aroma and body to the espresso.
Blends made for coffee bars usually
contain 20% Robusta but in southern
Italy, where they prefer a stronger
taste, the percentage can reach 4050%. At the end of the day, it’s just a
matter of taste…Experiment until you
nd the blend you like best!
Cappuccinos
There’s nothing better than a cappuccino to start your day. Although they are
made and served everywhere, few people know how to make one properly.
Making the coffee is only part of this
Lelit Espresso - English
EN
complex procedure. The froth often
creates major problems, but thanks to
the steam wand on our machine, with
a few suggestions and a little practice
you’ll soon be making cappuccinos
just like in the coffee bars!
Milk and jug
You need 100 ml of milk to make a
cappuccino.
MILK
5°C
100ml
Fresh whole milk provides a smoother, creamier and tastier froth. Milk
will not froth at over 65°C, so cold
milk from the fridge should be used
to allow more time for it to froth.
The best jug, on the other hand, is
one made of stainless steel, provided
with a spout, such as Lelit models (codes PL101 PL102-not included).
The level of milk should never exceed
half the volume of the jug.
Frothing the milk
Before using the steam wand, some
steam should be released for about
two seconds, as it always contains
some water due to condensation.
2 SEC
Insert the wand so that the end of
the nozzle is near the side of the jug
(pretend you have split the top section into four parts and insert the
nozzle into one of them) and about
one centimetre below the surface of
the milk. Since the milk will start to
expand in volume, you will have to
gradually lower the jug so that the
nozzle is always kept immersed at the
same depth. This process is complete
when the milk reaches a temperature
of about 37°C, or when you can feel
the warmth with your hand. You can
use the thermometer too (code PL107
- not included).
Processing the milk
This phase is very important to make
the cream thick, with a ne texture and
a shiny surface.
65°C
Insert the wand all the way down and tilt
the jug to create a vortex. Heat the milk
to the desired temperature, without exceeding 65°C. Close the steam.
Prepare the milk by rst tapping the jug
on the countertop to remove any air
bubbles and then rotating it to keep the
milk and froth well amalgamated. The
nal result should be a smooth, creamy
surface without any bubbles.
Pouring the milk
You should leave the milk to settle for
21
VIP Line - Elizabeth - PL92T
a least half a minute, so we suggest
you always prepare it before making
the coffee. The doses for a cappuccino should be one part Espresso and
two equal parts of milk and froth.
22
milk
coffee
Clean the steam wand with a damp
cloth.
To see the tutorial,
please scan the QR-Code.
To read the QR code,
download the proper app
from your store.
Lelit Espresso - English
EN
08.
Cleaning and maintenance
Cleaning and maintenance of the machine are essential for the quality of the
coffee and the durability of the appliance.
Cleaning
The machine must be cleaned at least
once a week. Before starting, remove
the plug from the electrical outlet and
allow the machine to cool. Use a soft
cloth, preferably microber, like the
Lelit cloth (code MC972 - not included), and moisten it with plain water.
Do not use abrasive detergents and
do not immerse the machine in water.
For thorough maintenance, we suggest you use the Lelit brush (code
PL106 - not included), which will help
you clean the nozzles and the spaces
between the ga-skets more effectively,
removing stains and coffee residues
from even the smallest cracks.
Warm running water can be used
to clean the removable parts of the
machine. The lters and lterholder
should never be washed in a dishwasher.
There is no need to clean the lters
after each use, but just to ensure they
are not clogged.
However, to ensure the best performance from your machine, it is essential to thoroughly clean the steam
wand and lterholder after each use.
The lterholder should be cleaned
to remove the greasy coffee residues
that can negatively affect the taste of
your espresso. Wash the exterior part
of the steam wand with a damp cloth
and release a little steam to remove any milk residues from inside the
tube, as these could obstruct the steam output, making it more difcult to
froth milk properly.
Descaling the machine
Use of the machine creates a natural
formation of lime scale, over a time
period depending on how frequently
the machine is used and on the hardness of the water.
Lime scale deposits can obstruct the
tubes and decrease the brewing tem-
23
VIP Line - Elizabeth - PL92T
24
perature, altering the quality of the
coffee and reducing the lifetime of
your machine.
35lt70lt
To avoid the formation of limescale,
which can also deposit in the internal
circuits, we recommend the use of our
Lelit resin lter to soften the water.
Please insert the lter in the tank following the instructions on the packaging.
The lter puries the water from the
calcium and magnesium salts which
are deposited to form lime scale and
affect the taste of your coffee. Remember that the lter loses its effectiveness after a certain number of gallons treated, so replace it periodically.
Instructions for the use and replacement of the lter are given on the box.
To avoid any possibility of damaging
the machine’s components,
NEVER, UNDER ANY CIRCUMSTANCES, ADD ANY DESCALING PRODUCTS TO THE WATER TANK.
Watch the tutorial
to understand how
the water softener
lters work.
Backushing
It is advisable to backush the
machine once a month (washing
the operational parts used during
brewing) using the blind lter supplied (d) and the Lelit detergent
sachets (code PL103 - not included).
In order to backush, follow these instructions:
a) Insert the blind lter (d) provided
into the lter holder (e).
b) Add 1 tea spoon of detergent powder (3-5 grams) in the blind lter (d)
c) Insert the lter holder (e) without
coffee rmly into the coffee distribution group (13), to align the handle
with the padlock symbol on it.
d) Keep the switch (2) pressed and
press the hot water switch (4) within 2
seconds.
e) The LCC display (11) will show a ashing drop and the two switches will
keep ashing until the procedure is
nished.
f) When the procedure is nished, the
display (11) returns to its normal status.
g) Remove the lter holder (e), press
the coffee switch (2) to start dispensing and rinse the lter holder under
the hot water that comes out of the
group (13). Press again the switch (2)
to stop dispensing.
h) Clean the distribution group (13)
and the brew gasket rst with the brush (code PL106 - not included) and
then with a damp cloth in order to remove all coffee powder residues.
i) To rinse, insert again the lter holder
(e) into the coffee distribution group
(13) and repeat the operations d), e),
f), without using the detergent powder.
j) Remove the lter holder (e) and the
blind lter (d) from it.
Lelit Espresso - English
EN
25
26
VIP Line - Elizabeth - PL92T
09.
Solving the most common problems
We recommend careful reading of this guide in order to solve the most common
problems before referring to an authorised service centre.
1
The coffee is too cold when dispensed
The machine has not reached its operating
temperature yet.
The lterholder has not been heated
adequately.
2
The coffee is dispensed too quickly and without cream
The grind is too coarse. Grind the coffee more nely.
The quantity of coffee is insufcient. Increase the amount of coffee.
The coffee has not been pressed enough. Press coffee more rmly.
The coffee used is old or unsuitable. Replace the coffee.
3
The coffee is not dispensed or is only dispensed in drops
The grind is too ne. Grind the coffee more coarsely.
The amount of coffee is too much. Decrease the amount of coffee.
The coffee has been pressed too much. Press the coffee less.
The dispenser head is clogged. Run a backflush, see the “Cleaning and Care” section.
4
The LCC does not light up and the machine does not work
The plugs of the power cable are not inserted
correctly.
The power cable is damaged. Contact the service centre
5
The machine does not dispense steam
The hole at the end of the steam/hot water
wand is obstructed.
6
The power is on, but the set temperature is not reached
The circuit breaker is interrupted. Contact the service centre.
The LCC is not working. Contact the service centre.
Follow the instructions in the “Prepare an
Espresso” paragraph.
Follow the instructions in the paragraph “Turn
on the machine.”
Insert the power cord plugs into their
respective sockets correctly.
Free the hole with the aid of a needle.
7
Alarms shown on the display
Missing water into the tank.
Temperature probe of the coffee boiler in
short circuit.
Temperature probe of the coffee boiler is
faulty or disconnected.
Lelit Espresso - English
There is no water into the tank.
Remove the water tank from its housing (7).
Fill the tank with water at room temperature.
Reposition the tank in the housing
The temperature probe of the coffee boiler is
in short circuit. All the machine functions are
disabled.
Contact the service center.
The temperature probe of the coffee boiler
is faulty or disconnected. All the machine
functions are disabled.
Contact the service center.
The steam boiler lling phase has exceeded
the maximum time of 150 seconds.
Contact the service center.
EN
27
Steam boiler lling alarm.
Temperature probe of the steam boiler in short
circuit. The display will alternately show the
04 Alarm and the icon of the machine ready
to use.
Temperature probe of the steam boiler is
faulty or disconnected. The display will
alternately show the 05 Alarm and the icon of
the machine ready to use.
the temperature probe of the steam boiler is in
short circuit, the steam boiler functions will be
disabled. The machine will be able to dispense
just coffee and hot water.
Contact the service center.
the temperature probe of the steam boiler
is faulty or disconnected, the steam boiler
functions will be disabled. The machine
will be able to dispense just coffee and hot
water.
Contact the service center.
28
VIP Line - Elizabeth - PL92T
10.
Warranty terms
Legal warranty
This product is covered by the warranty laws valid in the country where the
product has been sold; specic information about the warranty terms can be
given by the seller or by the importer in
the country where the product has been
purchased. The seller or importer is
completely responsible for the product.
The importer is completely responsible also for the fulllment of the laws in
force in the country where the importer
distributes the product, including the
correct disposal of the product at the
end of its working life.
Inside the European countries the laws
in force are the national laws implementing the EC Directive 44/99/CE.
Lelit Espresso - English
IMPORTANT INFORMATION
EN
For the correct disposal of the product in accordance with EU DIRECTIVE 2002/96/EC and with Legislative Decree no. 151 of 25 July
2005. At the end of its working life, the product must not be disposed
of as urban waste. It must be taken to a special authorised dierential
waste collection centre or to a dealer providing this service. Disposing
of a household appliance separately avoids possible negative consequences for the environment and health caused by improper disposal
and enables recovery of the materials it contains, with signicant savings in energy and resources. e product is marked with a crossed-out wheelie bin as a reminder of the need to dispose of household
appliances separately.
EC DECLARATION OF CONFORMITY
Gemme Italian Producers srl declares under its own responsibility
that the product:
Coee machine type: PL92T
to which this declaration relates conforms to the following standards:
EN 60335/1 - EN 60335/2/15 - EN 61000/3/2 - EN 55014
pursuant to directives:
2014/35/UE - 2014/30/UE
NB: is declaration is null and void should the machine be modied
without our specic authorisation.
Castegnato, 15/01/2018 - Managing Director
29
Gemme Italian Producers srl
25045 Castegnato (Bs)
User manual code 7800034, REV 01, dated 20/09/18
©2018 Gemme Italian Producers Srl. All Rights Reserved
The information and pictures provided may be changed
without notice to improve the machine performance.
Art. PL92T
Loading...
