Leica EG1150 H User Manual

Instructions for Use

Leica EG1150 H

Paraffin Embedding Station

Leica EG1150 H V 2.5, English 09/2014
Order No.: 14 0388 81101 RevF

Always keep this manual with the instrument.
Read carefully before working with the instrument.

IMPORTANT NOTE

The information, numerical data, notes and value
judgments contained in this manual represent
the current state of scientific knowledge and
state-of-the-art technology as we understand it
following thorough investigation in this field.
We are under no obligation to update the pres­ent manual periodically and on an ongoing basis
according to the latest technical developments,
nor to provide our customers with additional cop­ies, updates etc. of this manual.
To the extent permitted in accordance with
the national legal system as applicable in each
individual case, we shall not be held liable for
erroneous statements, drawings, technical illus­trations etc. contained in this manual. In particu­lar, no liability whatsoever is accepted for any
financial loss or consequential damage caused
by or related to compliance with statements or
other information in this manual.
Statements, drawings, illustrations and other
information regarding the contents or technical
details of the present Instructions for Use are
not to be considered warranted characteristics
of our products.

These are determined only by the contract
provisions agreed between ourselves and our
customers.
Leica reserves the right to change technical
specifications as well as manufacturing process­es without prior notice. Only in this way is it pos­sible to continuously improve the technology and
manufacturing techniques used in our products.
This document is protected under copyright laws.
All copyrights to this documentation are held by
Leica Biosystems Nussloch GmbH.
Any reproduction of text and illustrations (or of
any parts thereof) by means of print, photocopy,
microfiche, web cam or other methods – includ­ing any electronic systems and media – requires
express prior permission in writing by Leica
Biosystems Nussloch GmbH.
For the instrument serial number and year of
manufacture, please refer to the nameplate on
the back of the instrument.

© Leica Biosystems Nussloch GmbH

Issued by:
Leica Biosystems Nussloch GmbH

Heidelberger Str. 17 - 19
D-69226 Nussloch
Germany
Phone: [phone]
Fax: [phone]
Internet: http://www.LeicaBiosystems.com
Assembly contracted to Leica Microsystems Ltd. Shanghai

Leica EG1150 H – Paraffin Embedding Station

3

Table of contents

1. Important Information ................................................................................................................................ 5

1.1 Symbols in the text and their meanings ................................................................................................... 5

1.2 Intended use of instrument ......................................................................................................................... 6

1.3 Qualification of personnel ........................................................................................................................... 6

1.4 Instrument type ............................................................................................................................................. 6

2. Safety ............................................................................................................................................................ 7

2.1 Safety notes .................................................................................................................................................. 7

2.2 Warnings ....................................................................................................................................................... 8

2.3 Integrated safety devices ........................................................................................................................... 9

3. Instrument Components and Specifications........................................................................................ 10

3.1 Technical data ............................................................................................................................................ 10

3.2 Overview — instrument components ..................................................................................................... 11

3.3 Instrument specifications ......................................................................................................................... 12

4. Instrument Setup ....................................................................................................................................... 13

4.1 Unpacking and installation ....................................................................................................................... 13

4.2 Location conditions .................................................................................................................................... 14

4.3 Delivery range ............................................................................................................................................. 15

4.4 Necessary assembly work ....................................................................................................................... 16

4.5 Optional accessories ................................................................................................................................. 18

4.6 Electrical connection ................................................................................................................................. 19

5. Operation .................................................................................................................................................... 20

5.1 Instrument parts/functions ....................................................................................................................... 20

5.2 Switching the instrument on .................................................................................................................... 25

5.3 Control panel functions ............................................................................................................................. 26

5.4 Operating modes ........................................................................................................................................ 27

5.5 Time-program control ................................................................................................................................ 28

5.6 Instrument heater ....................................................................................................................................... 30

6. Maintenance and Cleaning..................................................................................................................... 32

6.1 Cleaning the instrument ............................................................................................................................ 32

6.2 Maintenance instructions ......................................................................................................................... 33

7. Troubleshooting ........................................................................................................................................ 34

7.1 Possible faults ............................................................................................................................................. 34

7.2 Changing a fuse .......................................................................................................................................... 37

8. Warranty and Service .............................................................................................................................. 39

9. Decontamination Certificate (Master) .................................................................................................. 40

4

Instructions for Use V 2.5 RevF – 09/2014

1. Important Information

1.1 Symbols in the text and their meanings

Warnings
appear in a gray box and are marked
by a warning triangle .

Notes,
i.e. important user information appear
in a gray box and are marked by an

.

(5)

ENTER

information symbol

Solvents and reagents that are inflam­mable are marked with this symbol.

This warning symbol indicates the sur­faces on the instrument that are hot
during operation.
Avoid direct contact to prevent risk of
burning.

Figures in brackets refer to item num­bers in figures.

Function keys that have to be pressed
on the input screen, are displayed in
bold type and capital letters.

Manufacturer

Observe the Instructions for Use

Date of manufacture

This product fulfills the requirements
of the Council's Directive 98/79/EC
concerning in vitro diagnostics (IVD)
medical devices.

REF

SN

~

Environmental protection symbol of the
China RoHS directive. The number in
the symbol indicates the "Environment­friendly Use Period" of the product. The
symbol is used if a substance restricted
in China is used in excess of the maxi­mum permitted limit.

Symbol for labeling electrical and elec­tronic equipment in accordance with Sec­tion 7 of the German Electrical and Elec­tronic Equipment Act (ElektroG). ElektroG
is the law regarding the sale, return and
environmentally sound disposal of electri­cal and electronic equipment.

Order No.

Serial number

Symbol for alternating current

Tip-n-Tell indicator to monitor wheth­er the shipment has been transported
and stored in upright position accord­ing to your requirements. With a pitch
of 60° or more, the blue quartz sand
flows into the arrow-shaped indicator
window and sticks there permanent­ly. Improper handling of the shipment
is immediately detectable and can be
proven definitively.

In the Shockwatch system, a precision
glass tube shows shocks or impacts
that are above a specified intensity
through red coloration. Exceeding a
defined acceleration (g value) destroys
the surface tension of the liquid in the
interior of the tube. This causes the
indicator tube to change color.

Leica EG1150 H – Paraffin Embedding Station

5

1. Important Information

1.2 Intended use of instrument

The Leica EG1150 H is a modern paraffin embedding station with microprocessor control system.
It is designed for embedding histological tissue specimens in molten paraffin for use in pathol-

ogy laboratories and only for the following tasks:

• Melt solid paraffin for sample embedding and maintain the molten paraffin at the required
temperature.

• Pour paraffin into embedding molds where the specimens are placed.

• Heat and maintain the temperatures of embedding cassettes with specimens and molds as

well as the required forceps.

Any other use of the instrument will be considered as improper use!

1.3 Qualification of personnel

• TheLeicaEG1150Hmaybeoperatedbytrainedlaboratorypersonnelonly.

• AlllaboratorypersonneldesignatedtooperatethisinstrumentmustreadtheseInstructions

for Use carefully and must be familiar with all technical features of the instrument before
attempting to operate it.

1.4 Instrument type

All information provided in these Instruc­tions for Use applies only to the instrument
type indicated on the cover page.
A name plate with the serial number is at­tached to the back of the instrument.

Fig. 1 is provided as an example only
and shows a valid nameplate for this
instrument with the necessary in­formation about instrument type and
power requirement. The precise data
for the various versions is specified in

Chapter 3.1, "Technical data".

6

Fig. 1

Instructions for Use V 2.5 RevF – 09/2014

The safety and caution notes in this chapter must be observed at all times.
Be sure to read these notes even if you are already familiar with the operation and use of other
Leica products.

2.1 Safety notes

2. Safety

These Instructions for Use include important
instructions and information related to the oper­ating safety and maintenance of the instrument.

The Instructions for Use are an important part of
the product, and must be read carefully prior to
startup and use and must always be kept near
the instrument.

These Instructions for Use must be appropriately supplemented as required by the existing
regulations on accident prevention and environmental safety in the operator's country.

The protective devices on the instrument and its accessories must not be removed or modified.
Only service personnel qualified by Leica may repair the instrument and access the instru­ment's internal components.

Use only the provided power cable - this must not be replaced with a different power cable.
If the power plug does not fit in your socket, contact our service.

Residual risks
The instrument has been designed and constructed with the latest state-of-the-art technology
and according to recognized standards and regulations with regard to safety technology. Oper­ating or handling the instrument incorrectly can place the user or other personnel at risk of in­jury or can cause damage to the instrument or other property. The instrument may be used only
as intended and only if all of its safety features are in proper working condition. Malfunctions
that impede safety must be remedied immediately.

This instrument has been built and tested in
accordance with the safety requirements for
electrical equipment for measurement, control,
and laboratory use.

To maintain this condition and ensure safe
operation, the user must observe all notes and
warnings contained in these Instructions for Use.

For current information about applicable guidelines, please refer to the CE declaration of
conformity and on our Internet site at:

http://www.LeicaBiosystems.com

Leica EG1150 H – Paraffin Embedding Station

7

2. Safety

2.2 Warnings

The safety devices installed in this instrument by the manufacturer only constitute the basis for
accident prevention. Operating the instrument safely is, above all, the responsibility of the owner,
as well as the designated personnel who operate, service or repair the instrument.
To ensure trouble-free operation of the instrument, make sure to comply with the following
instructions and warnings.

Warnings – Safety notes on the instrument itself

Safety notes on the instrument itself, which are marked with a warning triangle, indicate that
the correct operating instructions (as defined in these Instructions for Use) must be followed
when operating or replacing the item marked. Nonobservance can cause accidents, injuries
and/or damage to the instrument/accessories.

Certain surfaces of the instrument are hot during operation under normal conditions.
They are marked with this warning sign. Touching these surfaces can cause burns.

Safety instructions - transport and installation

• After unpacking the instrument it may only be transported in an upright position.

• Place the instrument on a laboratory table and adjust it to a horizontal position.

• The instrument must not be exposed to direct sunlight (window)!

• Plug the instrument only into a grounded power socket. The protective effect may not be

eliminated by an extension cable without a protective grounding conductor.

• The instrument automatically recognizes the applied voltage/frequency.

• The installation location must be well-ventilated; there should be no ignition sources there

of any kind.

• The instrument may not be operated in hazardous locations.

• Extreme temperature fluctuations between storage facility and setup site as well as high

humidity may cause condensation to form. In this case, wait at least two hours before
switching on.

8

Instructions for Use V 2.5 RevF – 09/2014

Safety instructions - working with the instrument

Paraffin is flammable and should therefore be handled with due care. Do not use sharp tools to
remove solidified paraffin from the work areas, as this may destroy the coating on the surface.
Use the plastic spatula supplied with the instrument.
During operation, the paraffin reservoir, embedding mold tray, cassette tray, work area as well
as the forceps holder are hot.
Risk of burning!
Do not store any combustible and flammable substances near the instrument. There is a fire
hazard if work with an exposed flame (e.g. Bunsen burner) is carried out in the direct vicinity
of the instrument (solvent vapors). Therefore, keep all ignition sources at least 2 meters away
from the instrument!

Hazards - servicing and cleaning

Switch off the instrument each time before servicing and pull out the power plug.
When using cleaners, please comply with the safety instructions of the manufacturer and the
laboratory safety regulations.
Before changing defective fuses, the instrument has to be disconnected from the power supply.
Only fuses that are easily accessible may be replaced by the user.
Liquid must not get into the instrument while operating or cleaning it.

2. Safety

2.3 Integrated safety devices

The instrument is equipped with the following safety features and devices:

Fuses in the heating elements

All of the instrument's heating elements are equipped with overheating fuses, which trip if a
heating element overheats and switch the element off.

Automatic circuit breaker in standby switch

An automatic circuit breaker is located in the standby switch. This circuit breaker separates the
power electronics from the power supply in the event of a short-circuit.
In this case, the standby switch jumps to the position "0" = Off.

Note that the only way the user has for complete disconnection from the power supply is
disconnection of the power plug.

Leica EG1150 H – Paraffin Embedding Station

9

3. Instrument Components and Specifications

3.1 Technical data

General data

Approvals: The instrument-specific approval marks are located on

the rear panel of the instrument next to the type plate.
Voltage of power supply: 100-120 V, 50/60 Hz
230-240 V, 50/60 Hz
Power consumption: 1100 VA
Protection class1: I
Pollution degree1: 2
Overvoltage category: II
Operating temperature range: +18 °C to + 40 °C
Operating temperatures: 55 °C to 70 °C, adjustable in 5
Relative humidity: Max. 60 % non-condensing.

1)

according to IEC-1010, UL 3101, EN 61010

Fuses

Standby switch: Circuit breaker manufactured by ETA, model

3120-F421-P7T1-W01D-5A

Fine-wire fuses 6.3 x 32 mm: 2x T2.0 A; 2x T4.0 A; 4x T5.0 A; 2x T6.25 A
Fuse type: Schurter: Type Fst

K increments.

Dimensions and weights

Dimensions:
Height: 360 mm
Width: 500 mm
Depth: 640 mm
Weight: Approx. 22 kg

Capacities

Paraffin reservoir: Approx. 3 l
Cassette tray: Approx. 100 cassettes
Embedding mold tray: Approx. 50 embedding molds

Programmable parameters

Temperature: Paraffin reservoir/dispenser
(heating-up time = 4 h)
Embedding mold tray, cassette tray, work top
Time: Working day, current weekday
Working times (start, end), current time

10

Instructions for Use V 2.5 RevF – 09/2014

3. Instrument Components and Specifications

3.2 Overview — instrument components

Standby
switch

Forceps holder

Paraffin reservoir
with lid

Control panel

Work area illumination

Dispenser

Lid

Cassette tray

Cassette tray

Work area

Lid
Embedding
mold tray

Embedding
mold tray

Leica EG1150 H – Paraffin Embedding Station

Paraffin collection tray
left

Cooling spot

Paraffin

collection tray

right

Fig. 2

11

3. Instrument Components and Specifications

Instrument rear view

Secondary fuses
F1-F3

Heat sink

Port for power cord

Sliding elements

Secondary

fuses

F4-F5

Port for

foot switch

Fig. 3

3.3 Instrument specifications

• Paraffin reservoir with a capacity of 3 liters.

• The paraffin flow is activated by means of a height-adjustable, pivotable clip - activated either

manually by the mold or a foot switch (optional).

• Controllable flow rate.

• Removable, heatable (indirectly, via the work surface) paraffin collection trays.

• Spacious, easy-to-clean, heated work area, with integrated cooling spot, also for extra large cas-

settes ("Super Mega Cassettes") with paraffin drain system.

• Trays for cassettes and/or molds with sliding lid, removable and interchangeable.

• Removable, heated forceps holder for 6 forceps, accessible from both sides.

• Optimum illumination of the work surface by the individual adjustable LED lamp.

• Temperature range of cassette and embedding mold tray, work area and paraffin reservoir adjust-

able from 55 °C to 70 °C.

• Permanent temperature display for all the work areas.

• The beginning and end of the work time and work days can be programmed.

12

Instructions for Use V 2.5 RevF – 09/2014

4.1 Unpacking and installation

When the instrument is delivered, check the tilt indicators on the packaging.
If the arrowhead is blue, the shipment was transported laying flat, was tilted at
too great an angle or fell over during transport.
Note this on the shipping documents and check the shipment for possible damage.

1

2

4. Instrument Setup

These unpacking instructions only
apply if the box is placed with the

symbols facing upwards for
unpacking.

1. Remove 8x screws (1) for the cover (2).

2. Remove the cover (2).

3. Lift up and remove the accessories (3) and
inside cover (4).

4

3

Leica EG1150 H – Paraffin Embedding Station

3

Fig. 4

13

4. Instrument Setup

8

6

5

6

Fig. 5

4. In order to lift the instrument (5) take hold of

it only at the lower housing base in the front
and rear (arrow in the detail for Fig. 5) and lift
it off of the bottom pad and out (6).

The packaging must be retained for the duration of the warranty period. To return the instru­ment, follow the instructions above in reverse order.

4.2 Location conditions

• Stable,vibration-freelaboratorytablewith

horizontal, flat table top, as far as possible
vibration-free ground.

• Theinstrument must not be placed in the

vicinity of the air outlet of an air conditioner
and must be shielded from strong sunlight
(window).

7

5

Important!
Lifting the instrument by the dispenser
(7) or paraffin reservoir (8) can cause
serious damage.

• Toensureafully functional heatsink,there

must be gap of at least 15 cm behind the instru­ment.

• Thevicinityoftheworkareamustbefreeof

oil and chemical vapors.

14

The installation location must be well-ventilated and free of ignition sources of any kind. The
instrument should not be operated in hazardous locations.

Instructions for Use V 2.5 RevF – 09/2014

4. Instrument Setup

4.3 Delivery range

The standard equipment for the Leica EG1150 H contains the following components:

1 basic unit Leica EG1150 H
1 Power cable, dependant on country specifications

Power cable "BR" 14 0411 47870

Power cable “EU” 14 0411 33613

Power cable “UK” 14 0411 33614

Power cable “USA” 14 0411 33615

Power cable “China” 14 0411 32591
2 cassette or embedding mold trays, removable 14 0388 32522
2 lids for cassette or embedding mold trays 14 0388 32480
1 lid for paraffin reservoir 14 0388 33148
1 paraffin scraper 14 0388 33133
1 forceps holder, removable 14 0388 32497
1 filter screen with holder 14 0388 32208
2 paraffin drip trays 14 0388 38138

1 LED lamp (12 V, 0.5 W) 14 0388 32464

1 set of spare fuses: 14 0388 46335

2 fuses T 2.0 A 14 6000 01479

2 fuses T 4.0 A, 6 x 32 14 6000 01480
4 fuses T 5.0 A, 6 x 32 14 6000 01481

2 fuses T 6.25 A, 6 x 32 14 6000 01482
1 Instructions for Use bundle Leica EG1150 H (Instructions for Use & language CD) 14 0388 81001

Please compare the delivered components against the packing list, delivery note, and your or­der. Should there be any discrepancy, please contact the Leica distributor handling your order.

Leica EG1150 H – Paraffin Embedding Station

15

4. Instrument Setup

4.4 Necessary assembly work

Install the following accessories and make the appropriate adjustments to
make the instrument ready for use:

• Installaccessories.

• Adjustinstrumentfeetifnecessary.

• Installmagnifier(optional).

• Connectfootswitch(optional).

• Connecttothepowersupply.

Install accessories

 Install embedding mold tray (2) and cassette tray (3).
Depending on the preferred working direction, the two heated trays (11)

can be used for molds or cassettes as required.

 Close mold/cassette tray with the corresponding lids (4), (5).

 Push the paraffin collection tray (6) into the respective guide underneath

the work top.

 Insert the forceps holder (1).

Adjustable instrument feet

To ensure a safe stand, all of the four feet must be adjusted to the same height.

16

 Insert the filtering screen (7) in the paraffin outlet hole (8) inside the

paraffin reservoir so that the black O-ring seals the hole.

 Place the lid (9) on the paraffin reservoir.

The four feet are height-adjustable to allow the instrument to be adjusted
to match the height of other devices or to compensate slight depressions
on the surface.
Lift the instrument slightly and turn the instrument foot (10 in Fig. 6) to adjust
it to the proper height.

Instructions for Use V 2.5 RevF – 09/2014

Installing the accessories

4. Instrument Setup



9

7

8



4



2

11

11





5





3

10



1

Fig. 6

Leica EG1150 H – Paraffin Embedding Station

6



6

17

4. Instrument Setup

4.5 Optional accessories

Magnifying glass

The magnifying glass provides a magnified view of the work area. When
properly adjusted, an enlarged view of the dispenser and cooling spot is
available.

5

1 2

5

4

3

1

3

Fig. 7

Installing the magnifying glass

• On thedispenser(5) a tap hole (1) is provided, which is closed with a nylon
screw (2).

• Remove the screw(2) with a screwdriver and store it in a safe place. Then
screw the knurled screw (3) of the stand (4) firmly into the tap hole and align
the magnifier.

Foot switch

The foot switch can be used to actuate the dispenser
valve, leaving the operator's hands free.

• To connectanduse thefootswitch, seeChapter 4.6

and 5.1.

4

18

Fig. 8

Instructions for Use V 2.5 RevF – 09/2014

4.6 Electrical connection

The instrument MUST be connected to a grounded power socket.
The instrument is supplied with a set of different power cords. Only the power cord intended
for the local power supply (socket) may be used.
Do not use an extension cord.

1

2

4. Instrument Setup

4 6

3

Before connecting the power cord to the foot switch, ensure that the standby switch (1)
(control panel, front) is set to "O" ("O" = OFF).

Connecting the power cord

• Connecttheplug(2) of the power cord to the
connection socket (3) on the rear of the in­strument.

• Plugthepowercordintothewalloutlet.

Leica EG1150 H – Paraffin Embedding Station

5

Fig. 9

Connecting the foot switch (optional)

• Inserttheplug(4) of the foot switch into the
connecting port (5) on the rear of the instru­ment.

• Tightenthescrews(6) of the plug.

19

5. Operation

5.1 Instrument parts/functions

1

2

14

2

13

The flow cannot be stopped complete­ly with the metering screw (11). It must
not be turned while cold!

13

12

1

Fig. 10

11

Paraffin reservoir (1)

The paraffin reservoir has a capacity of approx.
3 liters. The paraffin temperature can be set be­tween 55 °C and 70 °C in 5 K increments. The lid
should always be in place otherwise the adjusted
temperature cannot be maintained.

An overtemperature cutout is provided to prevent
overheating the paraffin if temperature control
fails.
A built-in filtering screen prevents any particles
contained in the paraffin from getting in the par­affin block.

Recycled paraffin may NOT be used in
the Leica EG1150 H due to the danger
of contamination.

Dispenser (2)

The dispenser is heated separately. The tem­perature setting of the dispenser and paraffin
reservoir is coupled.
The quantity of paraffin released from the filler
tube (14) can be adjusted continuously with the
metering screw (11).
The dispenser handle (12) is used for manually
operating the paraffin flow. It is provided with
a pressure clip (13). The pressure clip is height­adjustable and can be shifted to the side (left or
right) depending whether the dispenser handle is
released with the mold or the finger .
The dispenser handle can be operated by simply
pushing the mold (or the finger) against the pres­sure clip. Slightly pushing the handle backwards
will open the dispenser valve . Once released,
the handle flips back in the original position and
the valve shuts.

20

Instructions for Use V 2.5 RevF – 09/2014

5. Operation

Work top (3)

The temperature of the work top can be adjust­ed between 55 °C and 70 °C in 5 K increments.
This includes the embedding area, forceps
holder (5) and the cooling spot (4).
The working area has a groove around it and
several drain holes (15), through which excess

5

paraffin rapidly drains.

3

4

3

Cooling spot (4)

The cooling spot is an integral part of the work
area. Its position directly in front of the em-

15

bedding area enables convenient working in
ergonomically most favorable conditions.
To orientate the samples, the mold is filled
about one third with liquid paraffin. The liquid
paraffin begins to solidify rapidly on the cool­ing spot.

4

While the paraffin is semi-liquid, the sample
can be oriented as required. Finally, the mold
can rapidly be filled up with paraffin.

While orienting the tissue, the paraf­fin should not become too solid, as
this may cause different phases in

5

the finished block, including fissures
inside, as a result of which the block
may break during sectioning.

Forceps holder (5)

The removable forceps holder under the dis­penser can accommodate up to 6 forceps.

Fig. 11

The forceps holder is constantly heated
to approximately 70 °C.
Risk of burning!

Leica EG1150 H – Paraffin Embedding Station

21

5. Operation

Paraffin collection tray (8)

Two indirectly-heated paraffin collection trays
for excess paraffin are located under the work
surface.

7

6

8

8

The paraffin collection tray must be
emptied daily. To prevent contami­nation, do not reuse paraffin collect­ed in this tray.
If the instrument is operated without
the paraffin collection trays there is
risk of burning.

Embedding mold tray and cassette tray (16)

Depending on the preferred working direc­tion, the two heated instrument trays (6, 7)
can be used for embedding molds or cas­settes. The temperature is adjustable between
55 °C and 70 °C.
A removable tray (16) for cassettes or embed­ding molds can be placed in each instrument

17

16

tray.
Each receptacle can hold approx. 100 cas­settes or approx. 50 molds.
A lid (17) is provided for each of the trays (16)
to prevent loss of heat and contamination in-

Fig. 12

side the tray. For easy access, the lid can be
slid back and folded up.

22

When working with half-open lids (17),
raise the temperature one level to ensure
that the paraffin remains molten.

Only operate the cassette and em­bedding mold tray and paraffin res­ervoir with lid; otherwise the set
temperature cannot be maintained.

Instructions for Use V 2.5 RevF – 09/2014

5. Operation

21

Standby switch (8)

After the unit has been commissioned, the

8

standby switch should only be used if the
unit is to be switched off for a longer period
of time.

20

In daily routine operation, the ON/OFF button
on the control panel should be used.

9

Pressing the ON/OFF button (20) switches the
instrument into active standby mode.
All displays are switched off, only the LED (21)
of the ON/OFF button remains lit.

If programmed procedures are to be
carried out: the standby switch (8)
must be switched on and the unit
must be in standby mode.
For more information, see Chapter 5.4

Work area illumination (9)

18

A non-glare light system for the working area
provides homogeneous diffuse illumination
of the embedding area and cooling spot. This
produces optimum visibility conditions when

19

pouring out the paraffin and positioning the
specimen.

Leica EG1150 H – Paraffin Embedding Station

Fig. 13

To turn on the LED lamp for the first time after
the instrument goes into the active mode,
press the button (18) on the control panel
and on/off button (19) on the lamp head suc­cessively. It is recommended to turn the LED
lamp on/off through the button (19) on the lamp
head during daily operation.

23

5. Operation

Foot switch (22) optional

22

12

14

11

12

The foot switch (22) actuates the mag­net valve of the dispenser.
It must be connected as described in

Chapter 4.6.

The plug of the foot switch
MUST be screwed to the
socket. Otherwise hot paraf­fin can escape, even if the
switch is not activated.

Pressing the foot switch opens the
valve, releasing it closes it. This keeps
the operator's hands free to work with
the instrument.
The flow volume can be adjusted with
the metering screw (11).
The dispenser handle (12) is not re­quired when using the foot switch and
can be folded upwards.

Proceed as follows:

• Setthemeteringscrew(11) to mini-
mum.

• Carefully fold the dispenserhandle

(12) back/up with your thumb and
index finger.

24

14

Take care when folding back
the dispenser handle! Hot
paraffin may come out of the
filler tube (14).

DANGER OF BURNS!

Fig. 14

Instructions for Use V 2.5 RevF – 09/2014

5.2 Switching the instrument on

• Activate the standby switch (left-hand side, next to control panel)
(see Fig. 15, 17).

• AllLEDsoftheoperatingpanellightupbrieflyandtheinstalledsoftware

version is shown on the display for around 2 seconds.

All displays go out, the unit changes to standby mode.
The green LED in the ON/OFF button indicates that the instrument is

ready to operate.

Fig. 15

5. Operation

• Press the ON/OFF button down for approx. 2 seconds to
switch over to the operating mode. The time indicator flashes
on the display, indicating that the instrument has been dis­connected from the power supply.

Press any key to acknowledge.

The unit's normal operating mode is STANDBY/ON; i.e. switch on/
off with the ON/OFF key only.
Use the standby switch only if the device is to be switched off for
an extended period.

• The heaters become active and the LEDs indicate the values last set.
The target value LEDs for the heating areas (1, 3, and 4 in Fig. 18) flash

quickly for the duration of the heating phase (cf. "Display of the heating
intervals").

Fig. 16

The LED for the paraffin reservoir (2 in Fig. 18) flashes in 1-second inter-

vals and thereby indicates the intensified heating of the paraffin reser­voir (for 4 hours).

If temperature settings are modified during the heating phase, the in-

strument will store the new settings and the heating phase will then
correspondingly take longer.

• Fill the paraffin reservoir with paraffin.

Prior to leaving the factory, the Leica EG1150 H is tested thoroughly under laboratory condi­tions. For this reason, you will find a small quantity of clean, hardened paraffin. You can work
with this paraffin without any problem.

Leica EG1150 H – Paraffin Embedding Station

25

5. Operation

5.3 Control panel functions

The control panel beside the standby switch (8) consists of a foil keyboard
with push buttons, LEDs and a single-line display.
It is divided into two control areas:
temperature setting and display and instrument control and programming.

8

LED display for the

individual heating areas

31 2 4

Temperature setting buttons

of the heating areas

1 - Cassette or embedding mold tray, left
2 - Paraffin reservoir and dispenser
3 - Work surface
4 - Cassette or embedding mold tray, right

Temperature control

and display

Set time

6
5

Working day

selection

LEDs for mode indication of:

5 - Working day/weekday
6 - Start and end time, current time
7 - Current working day

Instrument control and

programming

Display:

standard indication

is real time

7

Set buttons for

Programming

Activation of

enhanced mode

Fig. 17

Illumination

On/Off

Selector switch for

Standby mode

or

working day ON/OFF

Fig. 18

26

Instructions for Use V 2.5 RevF – 09/2014

5.4 Operating modes

21

5. Operation

Standby mode

The display and all LEDs are switched off in standby mode. The unit switch­es on or off automatically at the programmed start and ending times.
Only the green LED (21) in the ON/OFF button indicates that the instrument
is ready to operate.

Enabling operating mode

• Hold down the ON/OFF button for approx. 2 seconds.

• Theinstrumentswitchesfromstandbymodetooperatingmode.The

LEDs of the currently selected values are illuminated, the display reads
the current time.

The time in the display flashes when switching to operating mode
if the device was disconnected from AC power for an extended
period (> 5 min).
Acknowledge the flashing display by pressing any button and
check whether all required heating phases (especially the paraffin
reservoir) are complete.

24-hour mode – working in shift mode

If the switch-on and switch off times of the timer are set to the same value,
the instrument will run continuously, even on days that are not defined as
work days.
Example: Start time = 00:00 and end time = 00:00.
To set the timer, see Chapter 5.5

Important
The timer is disabled if the end time is before the start time.
For example, start time: 08:00 and end time: 06:00.

In 24-hour mode, activate enhanced mode (see Ch. 5.6) to acceler­ate the melting process after replenishing solid paraffin.

Leica EG1150 H – Paraffin Embedding Station

27

5. Operation

5.5 Time-program control

The value shown in the display must be set to the current local time to
ensure the correct operation of the time-program control.

Setting the time

• PresstheCLOCK button as many times as required until the green "TIME"
LED lights up.

Fig. 19

• Set the current time with the

The required value is reached faster when holding down the button in

question.

Start time

The start time is the time at which the instrument automatically switches
from standby to operating mode.

Setting the start-of-work and end-of-work times:

• PresstheCLOCK button as many times as required until the green LED
"START" lights up.

• Set the start time with the / buttons.

The required value is reached faster when holding down the button in

question.

End time

Automatic switch-over of the unit from operating to standby mode takes
place at the set ending time.

Setting the start-of-work and end-of-work times:

• PresstheCLOCK button as many times as required until the green "END"
LED lights up. Set the time as described above.

/ buttons.

28

All the set times are stored until they are changed, even if the instru­ment is switched off with the standby switch.

Instructions for Use V 2.5 RevF – 09/2014

Weekdays/working days

5. Operation

The automatic switch-on feature is linked with the individual weekdays. It is
therefore necessary to define the days for which the automatic switch-on
feature shall operate.

Only on those weekdays that have been defined as working days,
the instrument will be at the required temperature and ready to
operate.

Setting the current weekday:

• PresstheDAY button as many times as required until the green "TODAY"

LED lights up. The green LED of the current weekday is illuminated.

Fig. 20

• If necessary, set the current day with the

/ buttons - the associ-

ated LED lights up.

Defining the working days:

• PresstheDAY button as many times as required until the green LED

"WORKINGDAY" lights up. The LEDs of the weekdays defined as working
days light up, while the LED of the current day flashes.

• Use the

/ buttons to select the day to be defined or canceled as

the working day.

The LED of the selected day (FRI) flashes.

• PresstheON/OFF button.
If that day had not been a working day (LED off), it will now be added to

the working day list (LED on).

Otherwise (see Fig. 20, FRI was defined as a working day, LED on), the

day will no longer be defined as a working day (LED off).

If the programmed values are to be effective on the following days
(the instrument is operational at the programmed time and switches
off automatically when the end time is reached), the standby mode
must be active --> press ON/OFF.

Leica EG1150 H – Paraffin Embedding Station

29

5. Operation

5.6 Instrument heater

31 2 4

1 - Cassette/embedding mold tray, left
2 - Paraffin reservoir/Dispenser
3 - Temperature of work area
4 - Cassette/embedding mold tray, right

Indication of the heating intervals

In the display field for the temperature ranges, the LED for the set tempera­ture will always be lit. While heating for the area in question is active, the
LED flashes as long as heating continues.

It is possible to deactivate the heating activity display (and thereby the
flashing).

Proceed as follows:

• Switchofftheinstrumentwiththestandbyswitch(

Fig. 21

Setting temperature values

The temperatures for the instrument's four heat­ing areas can be adjusted separately from 55 °C
to 70 °C in 5 K increments.

When setting the temperature, please
observe the paraffin manufacturer's
specifications for the maximum per­missible temperature.

Press the buttons for the temperature range once
to increase the value by 5 K. The red LED for the
associated temperature value will light up – after
70 °C has been reached, the temperature will
revert to 55 °C.
Once set, the temperature value for one range
will be retained until it is changed.

, not ON/OFF).

30

+

+

• HolddowntheWORKAREA button and switch the instrument on again
with the standby switch.

• Toreturntothe"flashing"mode,switchofftheinstrumentwithstandby

switch as described under 1.

Hold down the PARAFFIN DISPENSER button when switching back on.

Fig. 22

Instructions for Use V 2.5 RevF – 09/2014

Advance times

Display

Enhanced mode

5. Operation

To ensure that the instrument is ready (all working temperatures reached)
at the programmed start time, the various sections are activated in advance
as follows:

Paraffin tank: Heating starts 4 hours before working time begins.
Work top: Heating starts 4 hours before working time begins.
Dispenser tube: Heating starts 1 hour before working time begins.
Cooling spot: Cooling starts 1 hour before working time begins.

During the heating phase, the display reads - - : - - ; the colon flashes in
intervals of seconds.
The advance times cannot be modified.

A large amount of heat is needed for melting paraffin. This is only account­ed for in standby mode for a respective preliminary time. In the operating
mode, the paraffin reservoir is heated just enough to maintain the paraffin
at the selected temperature. Therefore the melting process can be sped
up by increasing the heat supply (enhanced mode) whenever necessary
(e.g. when solid paraffin has to be added to the reservoir when working in
shifts). The paraffin reservoir is then heated for a period of four hours to a
higher temperature (enhanced mode).

Press simultaneously

Leica EG1150 H – Paraffin Embedding Station

Fig. 23

To activate the enhanced mode, push and hold
the and buttons simultaneously.
The brief lighting up of all four target value
LEDs of the paraffin reservoir confirms that the
on-demand heater has been activated. In other
words, the buttons have to be held until all 4 LEDs
light up.
The selected set value LED flashes while en­hanced mode is enabled.
The enhanced mode can be switched off at any
time by pressing and holding the same key com­bination. Deactivation of the on-demand heater
is also confirmed by all four target value LEDs
lighting up.

31

6. Maintenance and Cleaning

6.1 Cleaning the instrument

Do not use xylene for cleaning. Xylene vapors are heavier than air and can ignite at a consider­able distance from the source of heat.
A fire hazard exists!
To avoid scratching the surface of the instrument only the plastic spatula that is supplied with
it should be used for cleaning – on no account use metal tools!

Work surfaces

• Allcommonlaboratorycleaningproductssuitablefortheremovalofparaffin(e.g.Paraguard

or xylene substitutes) can be used to clean the work area.

• Avoidprolongedcontactoforganicsolventsonthesurfaceoftheinstrument.

Paraffin reservoir

• Keepcontaminantsoutoftheparaffinreservoir.

• Ensurethataresidualamountofparaffinremainsinthereservoirafterdrainingtoprevent

solid contaminants from entering the dispenser.

• Absorbthisparaffinwithtissueorapapertowel.Donotremovethescreenuntiltheresidual

paraffin has been removed.

• Theinteriorsurfacesofthereservoircanthenbecleanedwithatissue.

Forceps holder

• Theforcepsholderisoftenasourceofcontaminationandextremelysusceptibletodirt.

Therefore, clean the forceps holder thoroughly.

Important!
The forceps holder is constantly heated to approximately 70 °C. Risk of burning!

32

Instructions for Use V 2.5 RevF – 09/2014

Paraffin collection tray

• Beforetheparaffincollectiontraydrawerscanbeemptied,anyexcessparaffinonthe

work area must be removed with cellulose wadding in order to prevent any paraffin from
penetrating into the instrument.

Use care with paraffins with a low melting point - risk of burning when removing the paraffin
collection trays due to liquid paraffin.

• Onlyremoveandemptytheparaffincollectiontrayswhiletheyarewarm.

• Theparaffininthecollectiontraysmustnotbereused.Dangerofparaffincarry-overinto

the instrument.

• Emptybothparaffincollectiontraysregularlyinordertopreventthemfromoverflowing

into the instrument. While emptying intervals may vary depending on use, the trays should
be emptied at least daily.

If the paraffin collection trays are not emptied regularly, excess paraffin may flow into the
instrument or onto the work surface.
This presents a burn hazard and may damage the instrument.

6. Maintenance and Cleaning

6.2 Maintenance instructions

Only Leica service technicians are authorized to open the instrument for maintenance and
repair work.

The Leica EG1150 H is very low maintenance but please observe the following points to ensure
the instrument’s reliability.

• Cleantheinstrumentwithcaredaily.

• Regularlyremovedustfromtheventilationslotsonthebackoftheinstrumentwithabrush

or vacuum cleaner.

• HavetheinstrumentinspectedatleastonceayearbyanauthorizedLeicacustomerservice

technician.

• Enterintoaservicecontractattheendofthewarrantyperiod.Formoreinformation,contact

the relevant customer service organization.

Leica EG1150 H – Paraffin Embedding Station

33

7. Troubleshooting

7.1 Possible faults

This chapter will help you remedy problems that may occur when working
with Leica EG1150 H.

If a problem cannot be remedied by following the instructions in this chap­ter, please contact your Leica technical service center.

For further instructions, please refer to Chapter 8.
The table below lists the most common problems that may occur as well as

possible causes and remedies.

Problem Possible cause Corrective action

1. Display:

The

in the display.

The colon flashes.

2. Instrument doesn't work. - Standby switch is not turned on

message appears

- The instrument is in the heating
phase (standby mode).

- This is not an error!
The instrument will switch

to the operating mode at the
programmed start time.

- Standby switch ON.

34

or

- Cut-out function of the standby
switch has been activated.

- ON/OFF button has not been
pressed long enough.

Instructions for Use V 2.5 RevF – 09/2014

- Check instrument's connec­tion, then turn standby switch
on.

- Hold down ON/OFF button
for several seconds (at least
2 secs)

7. Troubleshooting

Problem Possible cause Corrective action

3. Paraffin reservoir

Paraffin does not melt or melts only

very slowly.

- Selected temperature too low.

- Increase temperature for par-

affin reservoir.

4. Paraffin dispenser

No paraffin flow.

Paraffin drops when valve is shut.

Non-homogeneous paraffin

flow (e.g. air pockets).

- No enhanced mode set.

- Temperature indication incor-

rect, or paraffin reservoir is not
heated.

- Incorrect start time selected.

- Fuse for the heater of the paraf-

fin reservoir activated.

- Technical fault.

- Paraffin not completely molten.

- The paraffin outlet is clogged or

the magnetic switch defective.

- Air bubbles in dispenser at start
of operation

- Activate on-demand heater.
(see Chapter 5.6)

- Check temperature settings
and repeat if necessary.

- Check start time.

- Check fuses and replace as

required. (see Chapter 7.3)

- Contact customer service.

- Wait until paraffin is entirely

molten; then check again.

- Contact customer service.

- Keep dispenser open at maxi-

mum flow for a period of time.

Leica EG1150 H – Paraffin Embedding Station

35

7. Troubleshooting

Problem Possible cause Corrective action

5. Illumination

does not work. - Button on the head of the lamp

has not been pressed.

- Press the On/Off button on the
head of the lamp.

6. Individual heating areas
(Despite correct temperature indi-

cation) heating does not work.

7. Error message in display

The

in the display.

Program and time are lost.

message appears

- Bulb defective.

- Fuse defective.

- Fuse for this heated area has

responded.

- Heater defective.

- The battery is empty
and also

- Power failure or

- Device switched off with stand-

by switch or

- Power plug disconnected.

- Ask technical service to re-

place the lamp.

- Change fuse.

(See Chapter 7.3)

- Change fuse.
(see Chapter 7.3)

- Contact customer service.

- Acknowledge fault by pressing

any key.
Work can resume after repro­gramming.

Important!
Do not disconnect the instru-

ment from the power supply
anymore.

Ask technical service to replace

battery.

36

Instructions for Use V 2.5 RevF – 09/2014

7.2 Changing a fuse

Before changing a fuse switch the instrument off and pull out the power plug. Use ONLY the
provided replacement fuses.
Important!
The instrument has a number of circuits that are protected by fuses with different values. Ob­serve the following instructions exactly to ensure that the correct spare fuse is used for the
matching fuse holder.

1
2
3

7. Troubleshooting

The instrument has five electrical areas with separate secondary fuse pro­tection. The secondary fuses are located in individual fuse inserts at the
back of the instrument.

The secondary fuses are secured with two metal plates (6, 7) that must be
removed first.

4 5

The individual fuses apply to the following areas:
1 - Peltier element of the cooling spot and work area illumination.
2 - Heating for forceps holder and dispenser.
3 - Control electronics.
4 - Heating for work top and cassette tray, right.
5 - Heating for paraffin reservoir and cassette tray, left.

Leica EG1150 H – Paraffin Embedding Station

6

7

Fig. 24

37

7. Troubleshooting

Select the correct spare fuse

This marking (2A) on the fuse and the labeling next to the fuse holder on the rear of

the instrument MUST agree!

Fig. 25

The metal caps on the spare fuses are labeled

- the labeling looks similar to that shown in the
figure above, but can vary depending on the type
of fuse.

The labeling important for the correct allocation
stands for the current intensity to be protected by

Change fuse

Using a screwdriver (8) lightly press in the fuse
holder (9) and then turn anti-clockwise one
1/4 turn and let go.

The fuse holder is pressed out and can be
removed.

the fuse (in the marked example: T2A)

On the back there are five dif­ferent fuse holders (Fig. 24).

One spare fuse must be se­lected from the five spare
fuses available that has the
marking 2A written on it.
(see Fig. 25, left)

Only the spare fuse with the
marking 2A may be inserted
in this fuse holder (T2A).

This is also applicable in the
same way for the other fuse
holders.

38

10

Take the defective fuse (10)
out of the fuse holder (9) and
replace it by the selected
spare fuse.

Insert the fuse holder with
the spare fuse, press in
using screwdriver (1) and
secure by turning it clock-

8

9

9

Fig. 26

Instructions for Use V 2.5 RevF – 09/2014

wise 1/4 turn.
Replace fuse cover (6,7).

Warranty

Service information

8. Warranty and Service

Leica Biosystems Nussloch GmbH guarantees that the contractual product
delivered has been subjected to a comprehensive quality control procedure
based on the Leica in-house testing standards, and that the product is fault­less and complies with all technical specifications and/or characteristics
warranted.

The scope of the warranty is based on the content of the concluded agree­ment. The warranty terms of your Leica sales organization or the organiza­tion from which you have purchased the contractual product shall apply
exclusively.

If you require technical service or replacement parts, please contact your
Leica sales representative or dealer who sold the product.

Please provide the following information:

• Modelnameandserialnumberoftheinstrument.

• Locationoftheinstrumentandnameofthepersontocontact.

• Reasonfortheservicecall.

• Dateofdelivery.

Decommissioning and disposal

The instrument or parts of the instrument must be disposed of in compliance
with the local laws.

Leica EG1150 H – Paraffin Embedding Station

39

9. Decontamination Certificate (Master)

Tick Box A if applicable. Otherwise please complete all parts of B, providing further
information as requested or appropriate.

Decontamination Certificate

Nameplate information Model (see nameplate)*

SN (see nameplate)*

REF (see nameplate)*

This equipment has not been in contact with unfixed biological samples.

A
B

This equipment has been exposed internally or externally to hazardous materials as indicated
below:

Yes

No

Blood, body fluids, pathological samples

Other biohazards

Chemicals/substances hazardous to health

Other hazards

Yes

This equipment has been cleaned and decontaminated:

Yes

No

If yes, give details of the method:

If no**, please indicate why not:

Please provide further detail here:

Please provide further detail here:

**

Such equipment must not be returned without the written agreement of Leica Biosystems.

The equipment has been prepared to ensure safe handling/transportation.
Whenever possible, please use the original transportation case/box.

Yes No

1

3

2

Dear Customer,
Any product that is to be returned to Leica Biosystems or serviced on site, must be cleaned and decontaminated in the appropriate manner. Since it is not possible to
decontaminate for prion diseases, such as CJD, BSE, CWD etc., equipment exposed to specimens containing prion diseases cannot be returned to Leica Biosystems
for repair. On-site repair of prion contaminated equipment will only be conducted after the Field Service Engineer has been educated in the risks, instructed in the
policies and procedures of the institution, and provided with personal protective equipment. Please fill out this confirmation carefully and enclose a copy with the
instrument. Attach the confirmation to the outside of the flight case or hand it directly to the service technician.
Packages will not be opened, nor servicing commenced until the Company or service engineer have received a satisfactory certificate. Should returned
goods be considered a hazard by the Company, they will be returned immediately to the customer at his/her expense. Note: Microtome knives must be in boxes.

Mandatory information: Fields marked with * are mandatory. Depending on whether the instrument is contaminated, please also complete either section A
or section B.

Radioactivity

40

Instructions for Use V 2.5 RevF – 09/2014

Phone: ++49 (0) 6224 143 0
Fax: ++49 (0) 62 24 143 268
www.LeicaBiosystems.com

Tick Box A if applicable. Otherwise please complete all parts of B, providing further
information as requested or appropriate.

SN (see nameplate)*

REF (see nameplate)*

This equipment has not been in contact with unfixed biological samples.

This equipment has been exposed internally or externally to hazardous materials as indicated
below:

Yes

No

Blood, body fluids, pathological samples

Other biohazards

Chemicals/substances hazardous to health

Other hazards

Yes

This equipment has been cleaned and decontaminated:

Yes

No

If yes, give details of the method:

If no**, please indicate why not:

Please provide further detail here:

Please provide further detail here:

**

Such equipment must not be returned without the written agreement of Leica Biosystems.

The equipment has been prepared to ensure safe handling/transportation.
Whenever possible, please use the original transportation case/box.

Yes No

1

3

2

*

*

*

Institute*

Department*

Address*

Phone*

Fax

Version 3.5 - 01/2013, Order-No. 14 0700 83101

Radioactivity

9. Decontamination Certificate (Master)

Leica EG1150 H – Paraffin Embedding Station

41

www.LeicaBiosystems.com

Leica Biosystems Nussloch GmbH
Heidelberger Strasse 17-19
D- 69226 Nussloch
Tel.: +49 - (0) 62 24 - 143 0
Fax: +49 - (0) 62 24 - 143 268
Web: www.LeicaBiosystems.com
