Introduction Catalyst Enterprises, Inc.

Introduction

What’s In this Manual

This manual describes the installation and operation of your Catalyst AirCom UWB Analyzer. Examples of some typical applications are included.

Analyzer Overview

The Catalyst AirCom UWB Analyzer is capable of capturing and analyzing UWB traffic.

The analyzer supports the following:

• Capture and Trigger of UWB events such as transactions and packets

• Pre and Post Trigger pattern capture

• Real time Protocol Error detection

• Integrated Frame Generator to send user defined UWB frames over the air

• Comprehensive Statistical Report

Catalyst Enterprises Inc. Introduction

Interface

•Power In

• USB Port

• Ethernet Port

• External trigger Input

• External trigger Output

LEDs

Each link is supported by 4 LEDs with the following functionality:

Green This LED is illuminated indicating an active link.

Yellow This LED is illuminated when there is traffic on a link.

Red This LED illuminates when an error occurs.

Blue This LED is illuminated when a trigger occurs.

Receiving Your Analyzer Catalyst Enterprises, Inc.

Receiving Your Analyzer

Your analyzer package includes the following components:

AirCom UWB Analyzer unit

UWB Antenna

Power Cable

USB Cable (1.8m)

Ethernet Cable (10’)

Software CD for AirCom UWB Analyzer

Carrying Case

SMB to BNC External Trigger Cables (24”)

Unpacking Your Analyzer

Inspect the received shipping container for any damage. Unpack the container and account for each of the system components listed on the accompanying packing list. Visually inspect each component for absence of damage. In the event of damage notify the shipper and Catalyst Enterprises. Retain all shipping materials for shipper’s inspection.

Catalyst Enterprises Inc. Installing Your Analyzer

Installing Your Analyzer

Hardware Setup

WINDOWS BASED HOST

WITH ANALYZERSOFTWARE

WUSB DUT

Figure 1 Typical WUSB Test Setup of Analyzer

WUSB HOST

Software Installation

On systems operating under Windows® 2000 and Windows® XP.

Do not connect Analyzer Do not connect the Analyzer to your host system until the software

installation is complete.

1. Insert the CD ROM with the Analyzer software in the CD ROM drive.

2. The installation will automatically start unless the Auto Run is turned off. In thi s case select the CD ROM from “My Computer” and double-click autorun.exe.

3. From the CD ROM autorun application, choose the Install Software menu item and then choose UWB AirCom Software.

System restart You must restart your computer before you can use your Analyzer

software.

Error Message If you get an error message during installation of the drivers for Windows

2000 or XP consult your system administrator. Your system may be setup to only allow an administrator level to copy such driver files.

Installing Your Analyzer Catalyst Enterprises, Inc.

Connecting via Ethernet

You may use the ethernet connection using any one of the following 3 supported configurations:

1. The Analyzer connected to a network via a hub, switch, or similar device.

2. The Analyzer connected to the host computer (machine running the application

software), via a hub, switch or similar device.

3. The An a lyz er connected directly to the host computer using a crossover cable.

Connecting to a Network

When connected to a network the Anal yzer must communicate with the DHCP server to establish a connection. The DHCP server will continually send the next available IP address to the Analyzer until the Analyzer software is started.

When the user starts the software, t he use r may be prompted if they wish the software to automatically use the offered IP address or if they wish to assign a specific IP address (the assigned IP address needs to be on the same network segment as the host computer). The menu also allows the user to save the selected option (automatic or specific address). If the assigned IP address is not available, the OS will notify the user of an IP address conflict.

After the user clicks ‘OK’ the software will search for all Analyzer units connected to the network, and will display a list of available Analyzer units. After the user selects the desired Analyzer unit, the software will assign the IP address to the selected unit, completing the connection and will launch the software.

Catalyst Enterprises Inc. Installing Your Analyzer

Connecting via Hub, Switch or Similar device

When connected to the host machine via a hub, switch or other similar device or directly using a crossover cable the Catalyst board must communicate with the host computer to establish a connection. The host computer will continually broadcast the next available IP address to the Catalyst Board until the Catalyst software is started.

When the software starts, the user may be prompted if they wish the software to automatically use the offered IP address or if they wish to assign a specific IP address (the assigned IP address needs to be on the same network segment as the host computer). The menu also allows the user to save the selected option (automatic or specific address). If the assigned IP address is not available, the OS will notify the user of an IP address conflict.

After the user clicks ‘OK’ the software will search for all Catalyst boards connected to the network, and will display a list of available Catalyst boards, after the user selects the desired Catalyst board, the software will assign the IP address to the selected board, completing the connection and will launch the software.

Launching Your Analyzer Catalyst Enterprises, Inc.

Launching Your Analyzer

Analyzer

To launch the Analyzer software, double-click the AirCom icon on your Windows desktop. You can also launch the Analyz er software from the start menu by choosing Programs, Catalyst, AirCom and then Aircom.

When you run your software it will display the Device selection Dialog. You must make a Local device selection or Hardware Not Installed to run the Analyzer software in Simulation mode and click OK. If you choose one of the Local devices and click OK a Select Device Dialog will display a list of available devices. Choose the device to be connected to and click OK to launch the software. If no devices are available you may choose to run in simulation mode. To run in simulation mode check the Hardware Not Installed [Simulation Mode] option button and click OK.

The next time you run the software, it will connect to the last used device if it is still available.

Catalyst Enterprises Inc. Launching Your Analyzer

Software Launched

New Protocol Analyzer or

Frame Generator Project

Open

Open Sample File

Save

Open Last Saved Analyzer Project

Scan UWB Channels

Run Project

Stop Project

Cancel Project

Figure 2 Analyzer Main Toolbar

Operating in Simulation Mode

If you selected the Analyzer software to run in the Simulation Mode, the Analyzer software will launch and display the appropriate tool bar, but with the limitation that the Analyzer will operate only on static, previously captured, bus data.

Limitations The Simulation mode lets you try all of the available functions, but keep

in mind that the system is not capturing any real data and is displaying

only pre-captured results.

Protocol Analyzer Projects Catalyst Enterprises, Inc.

Protocol Analyzer Projects

Protocol Analysis is performed by defining and running a Protocol Analysis Project, which defines what will be captured, what the analyzer will trigger on and capture memory settings. Defined projects may be saved as project *.wac files for later use.

Quick Start

To get a comprehensive overview of your analyzer’s capabilities:

1. Install the Analyzer software. See "Software Installation" on page 4.

2. Set up your Analyzer. See "Hardware Setup" on page 4.

3. Launch your Analyzer software. See "Launching Your Analyzer" on page 7 for

launching instructions.

4. On the Analyzer Menu Bar click File, New to open a Protocol Analyzer dialog

Project tree display

What will be captured

What will analyzer trigger on

Capture memory settings

Collapse All button hides details in Project tree

Expand All button expands collapsed Project tree

The New Project dialog opens with default settings to capture Everything on the bus and to Trigger On on Snapshot. (Meaning that the analyzer captures everything immediately without triggering on anything in particular).

Figure 3. New Protocol Analyzer Project Dialog

Catalyst Enterprises Inc. Protocol Analyzer Projects

Project Overview A comprehensive tree structured overview of the project is displayed in

the Project Tree display. The project tree shows what is to be captured, what the analyzer will trigger on and capture memory settings.

5. To get an immediate overview of the traffic to and from your Analyzer, click the

Run Project button.

Show/Hide Layers buttons

X,Y,T

Cursors

Layer ID with different colors

Protocol Error

Data direction arrows

Link Status

Time differences between cursors

Figure 4. Typical Packet View Results Display

The results display shows each transaction for every layer identified in a different color and the data direction identified with data direction arrows. Upstream traffic is identified with the arrow from right to left. This arrow direction ⇐ indicates upstream traffic. Downstream traffic is identified with the arrow left to right. This arrow direction ⇒ indicates downstream traffic.

Protocol Analyzer Projects Catalyst Enterprises, Inc.

Link Status Link status displays general link activity. To display Link Status click the

Link Status bus indicator in the Status bar.

You may hide any layer by clicking the corresponding Show/Hide button on the menu bar. All captured data is retained, but the display is limited to the layer data of interest for simpler viewing.

You may configure the viewer display for your individual test and viewing preferences. See “Data Display Manipulation” on page 32 for details about configuring the viewer display.

The Protocol Analyzer Project dialog offers you a comprehensive set of choices to create a trigger and capture project satisfying some specific need. You may set the Analyzer to:

• Capture specific patterns. (See "Data Capture Setup" on page 16)

• Capture different patterns pre and post trigger.

• Exclude parameters from capture.

• Trigger on a Pattern or sequence of patterns. (See "Triggering Setup" on page 23)

• Configure trace capture memory. (Settings)

• Select file to save trace capture in memory. (Settings)

• Include a Project Note.

Run a Sample Project Before setting up your own custom project you may wish to run one or

more of the sample projects included with your analyzer software. See "Example Projects" on page 12.

Catalyst Enterprises Inc. Protocol Analyzer Projects

Example Projects

Your Analyzer includes a number of pre-defined example projects that you may use to perform an immediate analysis without any setup.

The Analyzer system software comes with a pre-defined folder (Directory) structure for storing all files. All pre-defined example files are stored in the following Folder:

c:\Program Files\Catalyst\AirCom\Examples

It is strongly recommended that you open some of these files to get an introduction to the types of projects that can be created for the Analyzer.

Project file type definition

*.wac Protocol Analyzer file *.was Sample file *.wpg Frame Generator Pattern file

Protocol Analyzer Projects Catalyst Enterprises, Inc.

Run an Example Protocol Analyzer Project

1. Click File on the main menu bar and then choose Open.

2. Locate available example Protocol Analyzer Projects by looking in: c:\Program Files\Catalyst\AirCom\Examples.

3. Choose an example *.wac file and click Open to display the example project dialog.

Figure 5. Sample Protocol Analysis Project

4. Click the Run Project button to execute the pre-defined example.

5. Once the project runs you will see an analyzer trace capture display similar to the one shown in Figure 6.

Catalyst Enterprises Inc. Protocol Analyzer Projects

See "Data Display Manipulation" on page 32 and "Display Configuration" on page 66 for details about the results display.

Saving a Trace Capture

You may save a Trace Capture for review at a later time.

Figure 6. Analyzer Trace Capture Display

Protocol Analyzer Projects Catalyst Enterprises, Inc.

Protocol Analyzer Project Setup

You may define a new project starting with the default project definition, or modify the settings for the last project run.

Default Project Clicking File, New opens a new project with default settings that

you can modify as required.

Last Project Clicking the Green button opens the last project saved.

You may modify this project as required.

New Project T o start a New project, click File on the main menu bar and choose

New.

Figure 7. New Trigger and Capture Project Dialog

Catalyst Enterprises Inc. Protocol Analyzer Projects

Data Capture Setup

Capture Everything

The default Capture Tab opens with capture Everything selected and the corresponding default Trigger On tab with Don’t care (Snapshot) selected. Clicking run with these default settings will immediately start a data capture to give the user a quick view of bus activity.

Figure 8. Capture Everything (Default)

You may elect to exclude the Payload from the capture by checking Exclude Payload except and if desired specify the number of bytes of the payload to be included.

The data capture may be refined by choosing Pattern and then selecting a specific pattern(s) for capture. Additionally you may define a different set of patterns to capture after trigger.

Protocol Analyzer Projects Catalyst Enterprises, Inc.

Capture Pattern

To define specific patterns for capture, click the Pattern button.

Figure 9. Choosing Capture Patterns

The Parameters window displays the following pattern capture choice categories:

•Frame •Information Element

• WUSB Packet • WUSB Data Pattern

• User Defined Frame • Protocol Errors

Choose a parameter To choose a parameter for capture from any of these categories, highlight

the category in the parameter window and click the A will open selection dialogs for each of the categories displaying all of the parameters for that category. All of the patterns added will appear in the project tree.

Exclude patterns Check this box to allow for the capture of everything except the patterns

that have been added to the Project Tree. When this box is checked, the Primitive category is added to the parameter window and Exclude Idle choice is enabled.

dd>> button. This

Catalyst Enterprises Inc. Protocol Analyzer Projects

Figure 10. Exclude Patterns Checked

To remove an item from capture, highlight it in the Project tree and click the

<<Rem

ove button.

Pre and Post Trigger Data Capture

You may define one set of patterns for capture prior to the occurrence of a trigger and another set of patterns for capture after the occurrence of a trigger. The selections and setup procedure is the same for both, the Pre-Trigger capture and the Post-Trigger capture. Check Define different patterns for pre-trigger and post-trigger data capture to enable the Post-Trigger Capture tab.

Figure 11. Post-trigger Capture Dialog Enabled

Protocol Analyzer Projects Catalyst Enterprises, Inc.

Defining Patterns

To select an item for capture, either highlight the category and click the Add>> button or double-click the category to open a corresponding definition dialog.

Frame Double-click Frame to display the Frame specification dialog.

Figure 12. Frame Common Fields Setting

1. Enter values in the Common Fields area for Source ID, Destination ID, Sequence Control and Str eam Index.

2. Click the down arrow next to the Secure drop-down combo box and choose Any, Plain Text or Secure.

3. Click the down arrow next to the Burst Mode drop-down combo box and choose Any, Normal or Burst.

4. Click the down arrow next to the Type drop-down combo box and choose a

Specific Field Type for capture.

Note: You may exclude the Specific Field by checking the Not check box

Catalyst Enterprises Inc. Protocol Analyzer Projects

Figure 13. Choosing a Specific Field

Note: Beacon, Control, Command and Data specific fields offer additional options.

WUSB Packet Double-click WUSB packet to display the WUSB packet specification

dialog.

1. Enter values in the Common Fields area for Source ID, Destination ID, Sequence Control and Stream Index.

2. Choose the Specific Fields similarly to the way described for Frames.

Protocol Analyzer Projects Catalyst Enterprises, Inc.

Information Element Double-click Information Element to display the Information Element

specification dialog

1. Enter values in the Common Fields area for Source ID, Destination ID,

Sequence Control and Str eam Index.

2. Click the down arrow next to the Information Element drop-down comb o box

and choose an Information Element Type for capture.

WUSB Data Pattern Double-click WUSB Data Pattern to display the WUSB Data Pattern

specification dialog.

1. Enter values in the Common Fields area for Source ID, Destination ID,

Sequence Control and Str eam Index.

2. Enter values for specific data patterns.

Catalyst Enterprises Inc. Protocol Analyzer Projects

Protocol Errors Double-click Protocol Errors to display the Protocol Errors selection

dialog.

Check the desired Protocol Error(s) for capture and click OK.

Protocol Analyzer Projects Catalyst Enterprises, Inc.

Triggering Setup

The Trigger-on tab, allows the user to specify when the analyzer will complete a data capture. Three trigger modes are available: The default Don’t care (Snapshot), Manual Trigger and Pattern.

When a data capture is started with Don’t care (Snapshot) selected, the analyzer will trigger on the first data pattern detected. Starting a data capture with Pattern selected the analyzer will trigger when user specified pattern(s) are detected in the captured data stream. The following are three ways to trigger the analyzer with Pattern selected.

• Trigger on any added pattern (Any Trigger Mode)

• Trigger on timer

• External Trigger

• Trigger on a sequence of patterns (Sequential Trigger Mode)

Snapshot Mode

To trigger immediately on any pattern, check the Don’t care (Snapshot) button.

Manual Trigger Mode

In the Manual Trigger mode the analyzer captures traffic continually until you click the Stop Hardware button on the analyzer toolbar which triggers the analyzer. To set up to perform a manual trigger, check the Manual Trigger option button. Note that in this mode the Trigger Pointer does not appear in the captured data Packet View

Figure 14. Default Trigger Selected

Catalyst Enterprises Inc. Protocol Analyzer Projects

Pattern Mode

In Pattern mode the Analyzer will trigger whenever any one of the patterns selected for triggering occurs. The procedure for selecting trigger parameters is identical to that for selecting capture parameters. All items selected for triggering will appear in the Project Tree.

To define patterns for triggering check the Pattern button in the Trigger On dialog.

Figure 15. Select Patterns for Trigger

The Parameters window displays the following trigger pattern choice categories:

•Timer

• External Trigger

•Frame

• WUSB Packet

• User Defined Frame

Choose a parameter Either highlight the category and click the A

the category to open a corresponding definition dialog.

To remove an item from trigger, highlight it in the Project tree and click the

<<Rem

ove button.

• Information Element

• Transaction

• WUSB Data Pattern

• Protocol Error

dd>> button or double-click

Protocol Analyzer Projects Catalyst Enterprises, Inc.

Triggering on a Timer

A timer may be set independently of any other trigger selection to cause an unconditional trigger after a set time.

To set the timer value, double-click Timer in the Patterns window of the Capture Project dialog to open the Timer dialog.

Check the Time unit desired, enter the Timer Value and click OK.

External Trigger

You may trigger on an external trigger. To set up the trigger click the External Trigger category.

Click a desired triggering condition option button and click OK.

Catalyst Enterprises Inc. Protocol Analyzer Projects

Sequential T rigger Mode

In the Sequential Trigger mode, triggering occurs whenever a specific sequence of patterns are detected. The sequence is established by the order in which the triggering patterns are defined.

To define a triggering sequence, check the Define Sequential Trigger Mode check box.

Figure 16. Select Sequential Trigger Mode

Timer The sequential triggering mode offers the option of triggering on a timer

or inserting a timer in the triggering sequence to delay detection of the next pattern in the sequence. To insert a timer in the trigger list Doubleclick Timer to open the timer definition dialog.

Enter the desired Time Value, choose the Time Unit and click OK.

Defining Patterns The definition of patterns for the sequential trigger mode is identical to

the Pattern mode with the following exception: In the sequential triggering mode the definition dialogs for these triggering patterns enable the setting, to count the number of occurrences. This allows the user to specify the number of times that the pattern must occur before triggering or proceeding in the trigger sequence.

Protocol Analyzer Projects Catalyst Enterprises, Inc.

Figure 17. Number of Occurrences

Triggering order As triggering patterns are defined and added they are displayed in the

Project Tree sequentially in the order that they were entered under the Trigger On category. When the project is run, the analyzer will detect the occurrence of each pattern in order and trigger on the last one.

The sequence of triggering patterns can be re ordered if desired. To change the sequence order, highlight a trigger pattern and use the enabled green Up or Down arrow to move it to a new position.

Catalyst Enterprises Inc. Protocol Analyzer Projects

Project Settings

To set project options click the Settings tab.

Figure 18. Setting Project Options

Trace Memory Status

Memory Size To reduce the capture memory size, check Partial Memory and enter the

desired buffer size or, check entire memory to allow capture for the entire memory (1 GB) if you want to capture the maximum amount of trace data.

Note: In cases where the size of a data packet exceeds the set buffer

memory allocation, the project will run, but no capture will result. In such cases you must increase the buffer memory size to a value greater than the packet size.

Trigger Position Pre-Trigger is set to define the percentage of data to be captured before

and after the triggering event. It is set by default to 1% in the Snapshot mode and to 50% in the Manual trigger and Pattern mode. You may change this percentage by dragging the slider to the desired value.

The capture of the specified percentage of the data prior to the triggering event cannot be guaranteed and may in some cases be 0. This can occur in cases where the triggering event occurs before the required number of pre-trigger event data can be stored. In these cases the data display will show fewer than the specified data points prior to the triggering event. For more detail see "Pre-Trigger" on page 30.

Sample File Name Click the ellipses next to the Sample File Name text box and choose a file

name and location for the results of your current project.

Auto Run To repeat the current capture and trigger setup automatically, check the

Auto Run checkbox and enter the number of times in the Number to Run text box. The capture and trigger will repeat automatically for the

specified number of times and the results saved in consecutively numbered User Defined Sample File Name.was files.

Protocol Analyzer Projects Catalyst Enterprises, Inc.

Analyzer Settings

Scan Channels Click the Scan Channels button to scan for active channels. Start Channel Set the Start Channel number to the active channel to be analyzed. Protocol Error Mask Click the Protocol Error Mask button to open the Protocol Error Mask

dialog.

Add a Project Note

To enter and save information about the current project click the Note button and enter the data about the project.

Check the Protocol Errors that you wish to not display in the sample view.

Figure 19. Project Note

To run the project, click the run button.

Catalyst Enterprises Inc. Protocol Analyzer Projects

Pre-Trigger

The amount of data to be captured before and after the trigger may be set as a percentage of pre-trigger, between 1% and 99%. This may be done by positioning the pre-trigger slider to the desired percentage. This feature allows the evaluation of bus activity leading up to and after the triggering event. The operation of the pre-trigger in the data memory is conceptually illustrated in Figure 20.

Pre-trigger Data is the capture of the specified percentage of the data prior to the triggering event cannot be guaranteed and may in some cases be 0. This can occur in cases where the triggering event occurs before the required number pre-trigger event data can be stored. In these cases the data display will show fewer than the specified data points prior to the triggering event.

Figure 20. Pre-Trigger Example, 20% Pre-Trigger

Frame Generator Projects Catalyst Enterprises, Inc.

Fr ame Generator Projects

Defining and running a Frame Generator Project will enable you to transmit user defined frames over the air. To run a Frame Generator Project you must first create Frame Generator files, which define the frames that you want to transmit.

For instructions how to create a Frame Generator file see “Appendix A” on page 69.

Note: To create a new Frame Generator project, click the New button and select Frame

Generator

Frame Generator Setup

1. Check the Run Frame Generator check box and then click the ellipses button

next to the Frame File Name list box and choose a Frame Generator *.wpg file.

2. Choose Transmission mode by checking the corresponding option button.

• Check the Infinite Transmission check box to transmit the pattern

continually.

Figure 21. Initiator Dialog

Catalyst Enterprises Inc. Data Display Manipulation

Data Display Manipulation

View Packets Display

The data viewer display may be configured to meet your individual test and viewing preference needs. Toolbars are available for quick access to data viewer display features.

Figure 22. View Packets Display

Enabling Toolbars To customize your Sample Viewer Display workspace you can enable/

disable and reposition the available toolbars. To display or hide toolbars click View, Toolbar and check or uncheck the desired toolbar.

Once enabled, the toolbars can be docked to the viewer display window or allowed to float on the desktop.

Data Display Manipulation Catalyst Enterprises, Inc.

Spec View

To get a comprehensive specification of frame content, position a Frame to be the first item in the sample viewer and click View on the main toolbar and choose Show Spec View. You may also get a Frame specification by right-clicking on any frame in the sample viewer.

Note: If you scroll the sample viewer display with an open Spec View, the contents of the

Spec View will change to those for whichever Frame is the first item in the viewer display.

First item in viewer is a Frame

Figure 23. Spec View of Frame

Catalyst Enterprises Inc. Data Display Manipulation

Spec View Options

To change the Spec View options, right click in the Spec View window and choose the data radix (Hexadecimal or Binary), choose to show data only or copy Field Contents or all Contents to save in a different format.

Figure 24. Spec View Format

Data Display Manipulation Catalyst Enterprises, Inc.

Data View

Whenever the payload data exceeds what can conveniently be displayed in a Frame data field only the initial data values are displayed and an Expand/Collapse Data Payload toggle is enabled. Click this toggle to display all of the Payload Data.

Expand/Collapse Data Payload toggle

Search for Data Pattern

To search for specific data patterns, right-click the Frame Data Field and choose Open as Data View. Enter a Pattern to search for and click Find. Repeat to find the next

instance of the data pattern.

Figure 25. Complete Payload Data Display

Pattern to search for

Figure 26. Search for Data Pattern

You may configure the data display to Show/Hide the ASCII Pane (Default is Show), specify the number of bytes per row (Default is 16) or Byte Count of Data (Default is

1).

Catalyst Enterprises Inc. Data Display Manipulation

To save the data in a special file, click the Export button to open a Save As dialog.

Choose a folder where to save the file, a file name and Save As type (Either Text or Binary) and click OK.

Figure 27. Data Exported as Text

Data Display Manipulation Catalyst Enterprises, Inc.

Viewer Toolbar

Search button opens the search dialog.

Statistical Report button displays the statistical report setup dialog.

Click the Full Screen button to increase the data display area to full on the screen.

Click the Zoom In button to magnify the data display area of interest on the screen. In column and frame text view it increases the column width only.

Click the Zoom Out button to scale the data display area to display more data lines on the screen. In column and frame text view it decreases the column width only.

Catalyst Enterprises Inc. Data Display Manipulation

Click the Normal Zoom button to reset the zoom to default normal on the screen and in column and frame text view.

Click the Wrap Packets button to wrap the packet data in the display to eliminate the need for horizontal scrolling.

Expand/Collapse all Layers button expands or collapses layers to simplify the results display. Click the down arrow to expand or collapse specific layers.

GOTO button locates cursors in the results display. Click the down arrow to select cursor to go to.

Data Display Manipulation Catalyst Enterprises, Inc.

Layers Toolbar

Click the Show/Hide Transfer button on the Layers Toolbar to toggle between show and hide of the Transfer layer.

Click the Show/Hide Transaction button on the Layers Toolbar to toggle between show and hide of the Transaction layer.

Click the Show/Hide WUSB Packet button on the Layers Toolbar to toggle between show and hide of WUSB Packets.

Click the Show/Hide Frame button on the Layers Toolbar to toggle between show and hide of the Frame Layer.

Collapsing Layers

You may simplify the viewer display by collapsing layers below a chosen layer. For example right clicking in a Transfer layer header and choosing Collapse All will hide all lower level layers displaying only the Transfer Layers. To redisplay the expanded view right click in the Transfer layer and choose Expand All. Performing this on a lower layer will configure the display to show only that layer and the one(s) above.

Catalyst Enterprises Inc. Data Display Manipulation

Interpretation Aids

There are several user selectable options available to assist in interpreting the results displayed in the Sample View. To select any of the available options, right click in a data field in the Sample Viewer and choose the desired option.

Show/Hide Field Y ou may simplify the Viewer display by hiding some of the fields that are

of no current interest. You may hide fields such as Duration, Idle Time, External Signals, Packet number etc. by right clicking on the corresponding field title and choosing Hide Field.

To restore a field to the display, right click on in any field and choose the hidden field to be restored.

Note: Only the fields previously hidden will appear in the restore list.

Byte Order For reviewing enhancement you may change the byte order in fields

marked by an arrow. Right click in the field Select Byte Order and choose the ordering Big Endian (Default) or Little Endian.

Bit Order Right click on a data field, choose Bit Order and then to toggle the bit

order between MSB -> LSB (Default) and LSB -> MSB.

Format Right click on any field, choose Format and then select the desired

format from Name, Decimal, Hexadecimal or Binary.

Note: Not all format options are available for each field.

Data Display Manipulation Catalyst Enterprises, Inc.

Set Time Stamp Origin Right click on any field and choose Time Stamp Origin and select the

desired time stamp origin.

Set Direction Alias

Direction Alias allows you to assign a meaningful name to each traffic direction to assist in interpreting the Sample View.

1. To assign direction names in an open Sample View , click Configuration on the

Menu Bar and choose Set Direction Alias.

2. Assign a meaningf ul name to each traffic direction and click OK.

Directions named

3. The assigned direction alias will apply to all sample files that are opened after it

has been set.

Catalyst Enterprises Inc. Data Display Manipulation

User Defined Decoding (UDD)

User Defined Decoding allows you to assign custo m decoding for the data stream. The AirCom software includes some pre-defined scripts. Custom decoding is created by using scripts that are described in “Appendix B” on page 83.

To assign a previously defined script click View on the main toolbar and choose UDD Assignment to display the UDD Assignment dialog.

Figure 28. UDD Assignment Dialog

To make the pre-defined scripts available for assignment click the ADD button and locate the scripts in \Application Directory\System\Script folder. Choose the required script and click Open.

Repeat for additional files as required.

To assign a script to an endpoint click that endpoint and highlight the script to be assigned to that endpoint and click the Assign Protocol button.

Data Display Manipulation Catalyst Enterprises, Inc.

Assign Protocol Button

Figure 29. Assign Script

Choose an endpoint stage assignment from the Command dropdown list and click OK,

Figure 30. Script Assigned

Click OK to complete assignment.

A Show Decoding icon will appear in the Sample View for the endpoints with the script assignment

Catalyst Enterprises Inc. Data Display Manipulation

Show Decoding Icon

Click the Show Decoding Icon to display the decoding table for that endpoint.

Figure 31. Decoding Table

Faded Packets Catalyst Enterprises, Inc.

F aded Packets

Faded Packets are used to display certain packets that are unrelated to a WUSB Transfer and also to show packets that are related to two or more different WUSB Transfers. Faded Packets are only used when the WUSB Transfer Layer is shown in View Packets.

The following are reasons for showing packets as faded:

1. WUSB Transaction Group (TG) Packets: Because a TG packet can relate to

more than one transfer packet, the first TG is shown as non-faded and the subsequent ones are shown as faded.

2. WUSB MMC Packets: MMC Packet fading is the same as its related TG

packet.

3. WUSB In, Out and Handshake Packets: If these packets are shown beneath

their related Transfer, then they are shown as non-faded; otherwise, they are shown as faded.

4. WUSB DN Packets: If these packets are shown beneath a Transfer, then they

are shown as faded.

5. Frames: Frame fading is the same as its related WUSB Packet (MMC, DN, or

In/Out/Handshake).

In the following snapshot the Handshake Packet is faded under Transfer 1 because it is not related to this Transfer (Transfer and Handshake Packet differ in Device Address), but it is not faded under Transfer 2, because it is related to this Transfer.

Additionally, Transaction Group 1 is related to two different Transfers, so in the first occurrence, it is shown as non-faded, but in subsequent places it is shown as faded.

Catalyst Enterprises Inc. Faded Packets

Figure 32. Illustration of Faded Packets

Statistical Report Catalyst Enterprises, Inc.

Statistical Report

Whenever a captured sample is displayed in the sample viewer, the Statistical Report selection in the Report menu and a Statistical Report Button on the viewer toolbar are enabled. You may create a Statistical Report for the entire capture or a select portion of it as desired.

To display a Statistical Report, click the Statistical Report button on the viewer toolbar, or select Statistical Report from the Report menu.

Figure 33. Statistical Report Range Dialog

The default statistical report is generated using all samples. You may, however, set a specific Statistic report range between defined cursor positions or events.

Report Between Cursors Click the option button next to the From cursor selection drop down list.

Then click the From down arrow and choose the 1st. cursor, click the To down arrow to choose the 2nd cursor and click OK. The resulting report is limited to the capture between the cursors.

Report Between Events Click the option button next to the From the event selection dropdown

list. Then click the From down arrow to choose the 1st event and enter the number of its occurrence. Next click the To down arrow to choose the 2nd event, and enter the number of its occurrence.

Click OK. The resulting report will be limited to the capture between the defined events.

Catalyst Enterprises Inc. Statistical Report

Statistical Report Content

A complete statistical report consists of the following reports a that are accessed by clicking on the corresponding report tab in the dialog:

Note: Results are displayed only for items that have been captured in the sample.

Report Options

Note: Some report categories offer options to display only items of interest.These report

categories incorporate drop-down list boxes offering pre-defined and custom options. For details see “Formatting the Statistical Report View” on page 57.

Frame Report

To display the Frame report view, click the Frame Tab.The Frame report displays the report data in columns with the following information:

•Frame

• WUSB Packet

• Transaction Group

• Transfer

•Type

•Sub Type

• Destination Address

• Source Address

•Rate

•IE

• HW Protocol Error

• Performance

•Other

• Channel

• Security

• Duration

• Count

• Occurrence Percent

Statistical Report Catalyst Enterprises, Inc.

WUSB Packet Report

To display the WUSB Packet report view, click the WUSB Packet tab. The WUSB Packet report displays the report data in columns with the following information:

•Type

•Host Address

• Device Address

•End Point

• Acknowledge

Transaction Group Report

• Channel

•Length

• Duration

• Count

• Occurrence Percent

To display the Transaction Group Report, click the Transaction Group tab. The Transaction Group report displays the report data in columns with the following information:

•Host Address

• Channel

• Number of Frames

• Count

• Occurrence Percent

Catalyst Enterprises Inc. Statistical Report

Transfer Report

To display the Transfer Report, click the Transfer tab.The Transfer report displays the report data in columns with the following information:

IE Report

•Type

•Host address

• Device Address

To display the IE Report, click the IE tab. The STP Transport report displays the report data in columns with the following information:

•Protocol

•Type

•Host Address

• Count

• Occurrence Percent

• Channel

• Count

• Occurrence Percent

Statistical Report Catalyst Enterprises, Inc.

HW Protocol Error Report

To display the HW Protocol Error Report, click the HW Protocol error tab. The HW Protocol Error report displays the report data in columns with the following information:

Performance Report

To display the Performance Report, click the Performance tab.The Performance report displays the report data in columns with the following information:

•Packet

• PE ID

• Channel

• Count

• Occurrence Percent

•Host Address

• Device address

•End Point

• Throughput

• Bus Utilization

• Efficiency

• Count

• Occurrence Percent

Catalyst Enterprises Inc. Statistical Report

Other Report

To display the Other Report, click the Other tab. The Other report displays the report data in columns with the following information:

•Sample Time

•Total Idle Time

• Total Traffic Time

• Average Bytes Per Frame

Statistical Report Catalyst Enterprises, Inc.

Statistical Report Toolbar

The Statistical report toolbar provides the following functions accessible by buttons on the toolbar:

• Export to Excel

• Save as Text

• Print Report

•Print Preview

• Report Display Settings

Export as Microsoft® Excel file

Click the Export to Excel Button on the Statistical Report Toolbar to open the Export to Excel dialog.

Choose a folder to save the Excel file in and an appropriate file name and click

Save.

Save as Text

Click the Save as Text Button on the Statistical Report Toolbar to open the Export to Text dialog.

Choose a folder to save the Text file in and an appropriate file name and click Save.

Print Statistical Report

Click the Print Button on the Statistical Report Toolbar to open the select printer dialog. Choose an available printer and click OK.

Catalyst Enterprises Inc. Statistical Report

Print Preview

Click the Print Preview Button on the Statistical Report Toolbar to display a preview of the report to be printed.

Figure 34. Sample Print Preview of Report

Statistical Report Catalyst Enterprises, Inc.

Report Display Settings

You may set up the report columns for display to suit a particular analysis need. You may globally choose the columns for display thereby eliminating the need to show hide columns individually. Use the Setting dialog to configure the display for each page.

Click the Setting Button on the Statistical Report Toolbar to open the Setting dialog.

Figure 35. Statistical Report Column Setting

Catalyst Enterprises Inc. Statistical Report

Link With Sample View

Whenever a Type is selected on any page of the statistical report, a set of navigation buttons is enabled allowing you to examine each instance of that type in the sample viewer.

Click the Jump to Previous Button on the Statistical Report Toolbar to go to the previous instance of the selected type in the Sample Viewer.

Click the Jump to Next Button on the Statistical Report Toolbar to go to the next instance of the selected type in the Sample Viewer.

Click the Jump to Specific Button on the Statistical Report Toolbar to go to the instance specified as N of M items on the Statistical Report Toolbar.

Statistical Report Catalyst Enterprises, Inc.

Formatting the Statistical Report View

Initially the Statistical Report View contains all of the information in columns, but you may customize the display for your needs by:

• Sorting items by column

• Filtering Columns by item

• Hiding any column on the display

Filtering Column Content

To filter column content click the down arrow in the heading for that column and choose the items that you wish to be displayed. The default is All. By checking a specific item you exclude everything but that item for display.

Choosing Custom allows you to specify more than one item for display.

Check the items you wish to display and click OK.

Catalyst Enterprises Inc. Statistical Report

Hiding Columns

To hide a column, right click in the column and choose Hide. To unhide a column, right click on any column and choose Unhide.

Sorting Column Content

To sort column content, click the heading for that column. Repeated clicking of the column heading will sort the column in ascending or descending order.

Figure 36. Toggling Type Sort Order

Statistical Report Catalyst Enterprises, Inc.

Filtering Toolbar

Filter Enable button enables the Advanced Filter selection button.

Advanced Filter button opens the Advanced Filter specification dialog.

Hide Device button hides packets associated with specific hardware. Click the

down arrow on the button to select hardware.

Figure 37. Specify Hardware to Hide

Hide Transaction Group Packets with no WUSB Data Packets button.

Hide Naked Packets button.

Hide no Handshake WUSB Packets button.

Catalyst Enterprises Inc. Statistical Report

Advanced Filter

The Filtering patterns option allows you to modify the Sample Viewer display to show or hide Packets with a set of user defined patterns.

In order to set up filtering, you must have a viewer display open and enable the filter.

Filter Setup

Click the Filter Enable button to enable the filter.

To display the Filter setup dialog, click the Filter button on the Viewer toolbar or, click Filter on the main menu bar and choose Advanced Filter.

Figure 38. Filter Setup Dialog

1. Choose the packets that you wish to filter in the Filter Item area.

2. Define the filtering domain by choosing options for Secure Packets, Rate, Src Address, Dest Address and Stream Index.

3. Items selected for filtering may be designated as Show or Hide by selecting the corresponding option for Filter Typ e.

Statistical Report Catalyst Enterprises, Inc.

Using Pointers and Bookmarks

Pointers

The data viewer display incorporates three cursors labeled X, Y and T. The X,Y pointers are initially overlaid and positioned at location 0. The Trigger, or T, pointer shows the trigger point in the captured sample and is the measurement reference.

Positioning the X Pointer To position the X-Pointer within the viewer data display, click the left

mouse button in the gray bar on the left side of the sample viewer next to the line where you wish to see the pointer.

Positioning the Y Pointer To position the Y-pointer within the viewer data display, click the right

mouse button in the gray bar on the left side of the sample viewer next to the line where you wish to see the pointer.

Note: You may also left click to set the X-pointer and right click to set the Y pointer in the

frame and the column view by clicking in the narrow strip on the very left side of a cell.

Time differences between the pointers are displayed in the pointer position toolbar. To display the pointer position toolbar, click View on the main menu bar then Toolbar and choose Pointers.

Locate Pointers To quickly locate any of the pointers within the sample viewer display,

click the Go To button and choose the pointer to locate. You may also locate the cursors by selecting Go To from the Edit menu and choosing the pointer to locate.

Catalyst Enterprises Inc. Statistical Report

Bookmarks

Bookmarks is a convenient way to mark a point in the data viewer display by name, such that you can rapidly return to that point. To create a bookmark:

1. Right click in the sample viewer on a packet where you wish to place the bookmark.

2. Choose Bookmark from the shortcut menu to open the Bookmark dialog.

3. Choose a name for the b ookmark. enter a description for the bookmark and click the Add button. Repeat for additional bookmarks.

Bookmark

Statistical Report Catalyst Enterprises, Inc.

Finding a Bookmark To find a bookmark, right click the mouse in the sample viewer and click

bookmark.

Figure 39. Go To Bookmark Dialog Box

Highlight the bookmark that you wish to go to and click the Go button.

Catalyst Enterprises Inc. Statistical Report

Search

The search option permits you to examine any data capture file to quickly locate packets of interest.

Whenever an initial sample file is displayed, the Search, button is enabled on the Viewer toolbar.

To perform a search, click the Search button to open the search setup dialog as shown in Figure 40. You may also perform the search by selecting Search from the Edit menu.

Note: Only items captured in the sample file are enabled for search.

Figure 40. Search Parameter Definition Dialog Box

Search Category Choose a search category by checking a category box in the Search

Category area. Each of the search categories when selected offers additional choices to

refine the search. Check the desired items for the selected category.

Search Direction The default setting is Forward. With this setting clicking Find Next will

locate the specified search item from the current position forward. Check

Backward to search backward from the current position.

Search From Choose a starting to begin or continue a search.

• Start of the sample file

• Trigger Pointer

• X Pointer

• Y Pointer

• Last Found

Click the Find Next button to perform the specified search.

Statistical Report Catalyst Enterprises, Inc.

You may continue to search the output file for the same pattern by clicking the Find Next button until you redefine the data capture search parameters.

Data Pattern Search for Data Pattern allows you to search for:

• A specific Data Pattern

• Data Payload Length

• Data Pattern and Data Payload Length

Figure 41. Search for Data Pattern

Search Domain Define the search domain by choosing options for Secure Packets, Rate,

Src Address, Dest Address and Stream Index.

Catalyst Enterprises Inc. Display Configuration

Display Configuration

The Analyzer ships with a default display configuration of field and viewer settings. You may, however, define your own field and viewer settings for a particular testing scenario. The View Packets Display Configuration dialog allows the user to change the following display settings:

• Field settings – Data format

– Fields, header, data background and text color. – Hide/Show field (Check/uncheck Visible)

• Viewer Settings – Change fonts

– Wrap packets – Enable/Disable tool tip – Fit Text to cells

• Time Stamp Origin

• Save Display Configurations in a file.

• Load Display Configuration settings from a file.

To configure the display for your preferences click Configuration on the main toolbar and choose Viewer Configuration.

Figure 42. View Packets Viewer Configuration Dialog

Field Settings To view a packet field, select a field from the packet field tree and check

the V isi ble box . Unch eck it to hide th e field. To change the data format of a packet field, select the field and choose a data format from the Format drop-down list.

Display Configuration Catalyst Enterprises, Inc.

Viewer Settings Check the Wrap Packet box to enable the wrapping of packets in the

display. Check the Enable Tooltip box to enable tool tips for packet fields. To change the length of long byte fields displayed, enter a number of

bytes to display in the Long Field Byte Count text box. Choose Time S tamp Origin by checking Absolute, Trigger, Current

Position or System time option button.

Color To change the background or text color in a packet field header or data,

select it from the packet field tree and click the desired button. Choose an appropriate color and click OK.

Display Fonts To change display fonts, click the F

box. Choose the desired font, font style, size and click OK.

When finished, click OK to save changes and close the Display Configuration dialog.

ont button to open the Font dialog

Catalyst Enterprises Inc. Display Configuration

Appendix A Catalyst Enterprises, Inc.

Appendix A

Creating a Frame Generator Pattern File

A Frame Generator pattern file (*.wpg) is a user defined text file that is used by the Analyzer hardware to generate specific frames. To create a Pattern file you may use any text editor or word processor observing the following criteria:

File Size

Each file is limited to a maximum of 128K 4-byte wide lines.

Commenting

You may add comments to each line, which must be preceded by double slashes (//) as shown in the following example.

File Structure

Each 32-bit line of a Pattern file uses a bit and byte structure as described in Figure 43.

01 00 00 00 01 00 00 00 01 00 00 00 01 00 00 00 // Line 1 00 00 00 00 01 00 00 00 01 00 00 00 01 00 11 00 // Line 2 00 00 00 00 01 00 00 00 01 00 00 00 01 00 00 00 // Line 3

Figure 43. Bit and Byte Format for Each Line in Pattern File.

Catalyst Enterprises Inc. Appendix A

Byte Definitions

Each line in a Pattern file consists of four bytes, Bytes 3, 2, 1 and 0.

Byte 3 is the Flag Byte and is the left-most byte on each line. This byte must be defined for all lines in the Pattern file. Definitions for Byte 3 are as follows:

Bit31 and 30: Reserved Bit29: Must be set to zero in Frames and to one in Delay values. Bit28 and 27: Must be set in Manual Loop-Back mode (used for internal test of

Analyzer).

Bit26: Must set to one in the fourth line of each Frame and to zero in all

other lines.

Bit25: Must set to one in the end line of Frames and to zero in all other

lines.

Bit24: Must set to one in the start line of Frames and zero in all other

lines.

Bytes 2 and 1 are not used and are reserved for future use.

Byte 0 is the Data Byte, located as the right-most byte on each line. This byte contains

either frame bytes (for frame blocks) or a delay value, which is used to define delays between successive frames.

Frame Format

The frame block format is defined to be consistent with definitions prescribed by the MBOA/WiMedia MAC/PHY Interface Specification, Release 1.0. Based on this specification, a transmit frame consists of PHY header, MAC header, MAC payload, and an FCS. The Frame structure is shown in Figure 44.

Appendix A Catalyst Enterprises, Inc.

Figure 44. Frame Fields Definition.

As seen in the figure above, a frame is a stream of structured, formatted bytes, defined in a specific order. The user must insert the desired bytes/values of the frame in the data byte portion of the Pattern file (Byte 0).

Catalyst Enterprises Inc. Appendix A

Frame Example

The following is a Pattern (*.wpg) example of an application-specific control frame. Figure 45.shows the information defined for the frame.

01 00 00 00 // Start of PHY Header - Octets 0 through 4 00 00 00 38 00 00 00 00 04 00 00 90 00 00 00 00 // End of PHY Header

00 00 00 48 // Start of MAC Header - Octets 5 through 14 00 00 00 1C 00 00 00 00 00 00 00 01 00 00 00 EF 00 00 00 BE 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 C0 // End of MAC Header

00 00 00 00 // Start of MAC Payload - Begins at Octet 15 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 24 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 FF 00 00 00 FF 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 1A 00 00 00 80 00 00 00 70 00 00 00 1A

Appendix A Catalyst Enterprises, Inc.

00 00 00 00 00 00 00 30 00 00 00 05 00 00 00 00 00 00 00 A7 00 00 00 25 00 00 00 0A 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 80 00 00 00 06 00 00 00 00 00 00 00 01 00 00 00 00 00 00 00 00 00 00 00 40 00 00 00 00 00 00 00 00 00 00 00 FF 00 00 00 03 00 00 00 FF 00 00 00 11 00 00 00 11 00 00 00 11 00 00 00 11 00 00 00 11 00 00 00 11 00 00 00 11 00 00 00 11 //End of MAC Payload

00 00 00 43 // Start of FCS - Octet Length + 15 00 00 00 23 00 00 00 BA 02 00 00 05 // End of FCS

Catalyst Enterprises Inc. Appendix A

Delay Block

Fixed Delay

Figure 45. Information in Frame Example

In addition to a frame block, a Pattern file allows the insertion of delay blocks. A delay block format is a 4-line instruction, used by the Analyzer hardware to create delays between frames. A delay block is a 32-bit time interval, which counts with a 66MHz clock and can define an up to 65-second interval. The follow i ng formula describes delay time:

Delay Value = Delay time(S) * 66000000

There is a fixed delay between frames even if the user has not defined a delay value between frames. (It is about 2uSec for Single frames and 1.875uSec for Burst frames). Delay Block Format

Appendix A Catalyst Enterprises, Inc.

To add an additional delay between frames, the user must add a delay block between the desired frames. The format of delay block is described in Figure 46.

Figure 46. Delay Block Definition Format

Location of Delay Blocks

Delay block bytes must be inserted in the data byte fields (i.e., Byte 0). The following is an example that defines a delay block in a Pattern file:

For example (6us):

Delay Value = 396 (0x18C)

20 00 00 8C 20 00 00 01 20 00 00 00 20 00 00 00

Example

The following is an example file including an MMC packet and three DATA packets.

//---------------- MMC 1

// PHY header 01 00 00 00 00 00 00 38 00 00 00 00 04 00 00 90 00 00 00 00

// MAC header 00 00 00 48 00 00 00 1C 00 00 00 00 00 00 00 01 00 00 00 EF 00 00 00 BE 00 00 00 00 00 00 00 00 00 00 00 00

Catalyst Enterprises Inc. Appendix A

00 00 00 C0

// Security 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 24 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00

// WUSB App Code 00 00 00 00 00 00 00 01

//MMC Code 00 00 00 01

// Next MMC 00 00 00 FF 00 00 00 FF

// Reserved 00 00 00 00 00 00 00 00

// WUSB channel Time 00 00 00 00 00 00 00 00 00 00 00 00

//////////////// WCTA IE

// IE Length 00 00 00 1a

// IE Identifier = WCTA_IE 00 00 00 80

//////////////// W_DR_CTA (12 bytes)

// EP, Setup flag, WCTA Type 00 00 00 70

Appendix A Catalyst Enterprises, Inc.

// Start time 00 00 00 1A 00 00 00 00

// Device ID 00 00 00 30

// TXAttribute 00 00 00 05 00 00 00 00 // High bit is control status 00 00 00 A7 00 00 00 25

// bvDINAck 00 00 00 0A 00 00 00 00 00 00 00 00 00 00 00 00

// setup bytes 00 00 00 80 00 00 00 06 00 00 00 00 00 00 00 01 00 00 00 00 00 00 00 00 00 00 00 40 00 00 00 00

//////////////// EOL

// EP, Setup flag, WCTA Type 00 00 00 00

// Start time 00 00 00 FF 00 00 00 03

// Device ID 00 00 00 FF

/////////////

// MIC 00 00 00 11 00 00 00 11 00 00 00 11

Catalyst Enterprises Inc. Appendix A

00 00 00 11 00 00 00 11 00 00 00 11 00 00 00 11 00 00 00 11

//////////////

// FCS 00 00 00 56 00 00 00 51 00 00 00 90 02 00 00 E3

//------------------- IN DATA 1

//PHY header 01 00 00 00 00 00 00 1E 00 00 00 00 04 00 00 90 00 00 00 00

// MAC header 00 00 00 C8 00 00 00 12 00 00 00 EF 00 00 00 BE 00 00 00 30 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 C0

// Security 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 02 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00

Appendix A Catalyst Enterprises, Inc.

00 00 00 00 00 00 00 00

// WUSB header 00 00 00 00 00 00 00 00 // Low 4 bit is sequence number

// Data payload 00 00 00 12 00 00 00 01 00 00 00 00 00 00 00 01 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 08

// MIC 00 00 00 11 00 00 00 11 00 00 00 11 00 00 00 11 00 00 00 11 00 00 00 11 00 00 00 11 00 00 00 11

// FCS 00 00 00 CE 00 00 00 FD 00 00 00 E6 02 00 00 83

//------------------- IN DATA 2

//PHY header 01 00 00 00 00 00 00 1E 00 00 00 00 04 00 00 90 00 00 00 00

// MAC header 00 00 00 C8 00 00 00 12 00 00 00 EF

Catalyst Enterprises Inc. Appendix A

00 00 00 BE 00 00 00 30 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 C0

// Security 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 02 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00

// WUSB header 00 00 00 00 00 00 00 01 // Low 4 bit is sequence number

// Data payload 00 00 00 FA 00 00 00 04 00 00 00 01 00 00 00 42 00 00 00 A2 00 00 00 00 00 00 00 00 00 00 00 00

// MIC 00 00 00 11 00 00 00 11 00 00 00 11 00 00 00 11 00 00 00 11 00 00 00 11 00 00 00 11 00 00 00 11

// FCS 00 00 00 B6

Appendix A Catalyst Enterprises, Inc.

00 00 00 E3 00 00 00 35 02 00 00 93

//------------------- IN DATA 3

//PHY header 01 00 00 00 00 00 00 18 00 00 00 00 04 00 00 90 00 00 00 00

// MAC header 00 00 00 C8 00 00 00 12 00 00 00 EF 00 00 00 BE 00 00 00 30 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 C0

// Security 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 02 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00

// WUSB header 00 00 00 00 00 00 00 02 // Low 4 bit is sequence number

// Data payload 00 00 00 00 00 00 00 01

// MIC

Catalyst Enterprises Inc. Appendix A

00 00 00 11 00 00 00 11 00 00 00 11 00 00 00 11 00 00 00 11 00 00 00 11 00 00 00 11 00 00 00 11

// FCS 00 00 00 B2 00 00 00 22 00 00 00 82 02 00 00 0E

Appendix B Catalyst Enterprises, Inc.

Appendix B

Advanced Script Language (ASL)

The Advanced Script Language (ASL) is an extension of the Upper Level Protocol Decodes that allows you to define custom upper level protocol decodes in addition to those provided with the product.

The ASL, as defined, enables the user to extract and interpret arbitrary data from the UWB stream by creating custom scripts.

The ASL protocol decodes may be used to decode any class or vendor-specific requests and descriptors, protocols or an y structured data transferred over the USB bus, or can be used to complement pre-defined protocols.

This appendix is the essential reference for ASL users including definitions, code snippets, and complete examples. The decode script files can be written in any text editor or using the Catalyst script editor and must be saved with an *.asl file extension.

Document conventions

This appendix uses the following convention to describe the script syntax.

Text Style Meaning bold Functions, statements, or other reserved keywords italics Identifiers underscored < > Code enclosed in "<" and ">" is optional normal Integer constants " " Strings parameter1 ,…, parameterN Multiple entries option1 | option2 Choice of options

Expressions

Catalyst Enterprises Inc. Appendix B

Language Elements

Integers

ASL accepts integer values in decimal, binary, or hexadecimal formats. Floating point and negative numbers are not accepted.

Examples:

Hexadecimal: 0x21, 0x0001, 0xA5A5 Binary: 0b00100001, 0b1, 0b101001011010010110100101 Decimal: 33, 1, 42405

Strings

Strings in ASL are permitted to be static character strings, or can contain variable values that are calculated at runtime.

“Constant1 (optional) %d (%x, %b) Constant2 (Optional), Value”

Operators

Constant1 and constant2 are optional. These can be any character string. The value of the expressions is replaced by the corresponding strings in

either decimal (%d), hexadecimal (%x), or binary (%b) formats.

Examples:

"This is a static string" "Field length is %d, LengthOf(F1)"

The following lists the operators accepted by ASL. Operator precedence is that same as in C.

Operator Function

( ) Associative and Logical And or Logical Or not Logical Not > Greater than < Less than <> Equal to = Assignment + Arithmetic Addition

- Arithmetic Subtraction * Arithmetic Multiplication / Arithmetic Division

Appendix B Catalyst Enterprises, Inc.

Expressions

The expressions consist of one or more Integers, Functions, or Operators. For more detail about functions see page 96.

Examples:

Expression 1: 0x2A and LengthOf(F1) Expression 2:(ValueOf(F1)<2) or not (LengthOf(F2)<>10) Expression 3:(4 + LengthOf(F1))* ValueOf(F2)

The priority of evaluation is as follows:

Not, ( *, and +, or

Comments

Comments are enclosed in ‘/*’ and ‘*/’ and may span multiple lines.

Examples: /* This is a single line comment */ /* This is a multi-line comment */

Catalyst Enterprises Inc. Appendix B

ASL Structure

An ASL Script file includes two types of sections:

• Protocol Extraction Section

• Protocol Decoding Section

Each ASL script may include only one of each section type. Each script file must contain a Protocol Extraction section, and a Protocol Decoding section.

Each section serves a specific function during the decoding process.

Section Type Function

Protocol Extraction

Protocol Decoding

Instructs the decoder on how to extract the high-level protocol data from UWB transactions.

Breaks the extracted data stream into protocol fields and decodes the data per each field.

A section consists of one or more blocks. A block is a procedure that is formed with a series of statements that are enclosed within the block. Each block has a dedicated function within the section and follows one of two formats as shown:

Blockname

Statement1; Statement2; …. StatementN;

EndBlock

{

Statement1; Statement2; …. StatementN;

}

Appendix B Catalyst Enterprises, Inc.

Protocol Extraction Section

The decoding section is written as follows starts with [Decoding] and ends with the End keyword.

[Decoding]

Define Field Option Block Value Ranges Block Main Block

End

The Main block contains statements. See “ASL Statements” on page 89

Product Section

The product section identifies the product by name, such as SBAE for UWB.

[ProductName= SBAE]

End

Protocol Decoding Section

This Section consists of a Define Option Block a Valid Range Bock and a Decoding Statement. Keywords designate the start and the end of each block.

Define Option Block

DefineOptions

fieldId 2 = ( Description4, Value4 ;

EndOptions

Remark

If a protocol has a field such that each value of that field has an equivalent string, ASL names this field as an optional field. User can define different options of all optional fields by the Define option statement.

FieldId is a string that specifies Id of optional field.

Parameters

fieldId1 = ( Description1, Value11-Value12 ;

Description2, Value21-Value22; Description3, Value3);

Description5, Value51, Value52; …);

Value1 is the lower range for the data of the field with the specified fieldId.

Value2 is the upper range for the data of the field with the specified fieldId.

This value is optional. If you want to specify a range for one of the options of a field, you must use Value2 for this purpose.

Catalyst Enterprises Inc. Appendix B

Description:

This string is the description for specified range (Value1 to Value2) or specified value.

Example

/* F3, F4, F1 and BlockStatus are fields. */ DefineOptions

F3 = (“First Option”, 0x0000-0x1000;

“Second Option”, 0x1001-4352);

F4 = (“Option 1 for F4”, 0x0-14,

“Option 2 for F4”, 0x0f); F1 =(“Option for F1”, 0x00-0xff); BlockStatus = (“Option for BlockStatus”, 0-

0x1100);

EndOptions

Valid Range Block

ValidRanges

filedId 1 = ( Value1 , Value2 ); filedId 2 = ( Value1 , Value2 ); …

EndValidRanges

Remark

Parameters

Example

This statement specifies the valid range of data that can be set in a field. If the data set in the field is not within a valid range a protocol error will be generated at run time.

Value1 is the lower range for the data of the field with the specified fieldId.

Value2 is the upper range for the data of the field with the specified fieldId.

/*F4, F1, BlockID are fields.*/

ValidRanges

F4=(0x00, 0xAA); BlockID = (0,32); F1=(0b00001,0b0101010);

EndValidRanges

Appendix B Catalyst Enterprises, Inc.

ASL Statements

Addfield

fieldId = AddField (StartBit, Length, Name, Description, Abbreviation,

BitOrder )

Remark

This statement adds a field to a packet with given specification. This function increases CURPOS one Length.

CURPOS is a pointer that when a field added moves on input data, it points to the current index of the data for the next field.

fieldId: FieldId is a string that specifies Id of fields. Each field has a

unique Id. This Id is used to refer to that field.

Parameters

Example

StartBit This parameter specifies the start bit position of the specified

field. The value of this parameter can be an Expression.

Length This parameter specifies the length of the specified field in

bits. The value of this parameter can be an Expression. Name This parameter specifies the Name of the field. Description This parameter specifies the description of the field. For the

format of this parameter see “Strings” on page 84. Abbreviation This parameter specifies the Abbreviation of the field. If the

field name is long you can use an abbreviation for the filed.

In the first version of ASL the abbreviation of a field does not

show in viewer. For the format of this parameter see

“Strings” on page 84. BitOrder This parameter specifies the bit order of data of a field. The

value of this parameter can be either MSBLEFT or

LSBLEFT.

This parameter is optional and if user does

not specify a value the default value MSBLEFT.

/* This statement adds a field at bit #2 of packet with the length of 3 bits. The data of this field will be read from // Lowest Bit. */

F1 = AddField(2, 3, ”Name of Field”, ”This field is the flag field.”, ”Abbreviation of field”, LSBLEFT);

Catalyst Enterprises Inc. Appendix B

BitStuff

BitStuff ( FieldId , n )

Remark

If in a protocol one field transfer after bitstuffing algorithm the user can see the value of that field by using the BitStuff statement. This statement runs an unstuff algorithm on the specified field.

Parameters

FieldId The field Id that was defined by AddField. n The number of bits for bitstuffing.

Example

Note : The BitStuff function must be placed after all AddFields.

GetData

Remark

Note: INPUTDATA is an ASL keyword that identifies the input data stream that will be

/* run the bitstuff algorithm on 5 bits of continuous 1 . */

Flag = AddField(0,8, "Falg","Falg",""); Data = AddField(8,LengthOf(INPUTDATA) - (CURPOS

+16),"Data","Data",""); FCS = AddField(CURPOS,16, "FCS","FCS",""); BitStuff(Data,5);

DataId = GetData ( StartBit, Length )

This statement copies a data segment with a given specification from INPUTDATA to DataId. The user can use from copied data with referring to DataId. This function does not increases CURPOS. If user needs to know the value of a segment of data without adding a field, he can use this statement.

passed to the script for decoding.

DataId The fieldId that was defined by AddField.

Parameters

Example

StartBit Specifies the start bit position of the specified field. Value of

this parameter can be an Expression.

Length Specifies the length of the specified Data in bits. The value of

this parameter can be an Expression.

/*This function Puts the Data from Bit#0 to Bit#9 in a dataId named D31. */

DataSegment = GetData (0,9);

Appendix B Catalyst Enterprises, Inc.

If Expresssion Then

Block1

Else If

Else If Expresssion

… Else

Remark

The if statement evaluates expressions.(For information about expressions see “Expressions” on page 85

The if executes block1 if the expression is true (nonzero); if else is present and expression is false (zero), it executes block2 ;…

Expresssion Then

Block2

Then

Block3

Block4

Example

After executing block1 or block2, control passes to the next statement.

Each block may have several inner if.

If CURPOS > 5 and ValueOf(F1) < 8 Then

{ H1 = AddField(CURPOS,8,"H1","Field H1","H1"); }

Else if(CURPOS < 9) then

{

H2 = AddField(CURPOS,8,"H2","Field H2","H2"); } else

{

H4 = AddField(CURPOS,548,"H4","Field H4","H4");

}

Catalyst Enterprises Inc. Appendix B

Repeat

Repeat Expresssion Block

Remark

This statement repeats all commands in block until the Expression is TRUE.

Example

F1 = AddField(0, 20, "Field1", "It starts form bit# 2", "F1");

F2 = AddField(20, 40, "Field2", "This field is used for..", "F2");

F31 = GetData(32, 10);

Repeat Count

Remark

Example

/* This loop will repeat till current position > 34 (in bits)*/

Repeat CURPOS < 100 {

F1 = AddField(CURPOS, 23, "SubField of field f1", "subfield of f1", "subfield");

}

Repeat Count = Expression Block

This statement repeats all commands in block as many times as the value of Expression

F1 = AddField(2, 3, "Field1", "It starts form bit# 2",

"F1");

F2 = AddField(2, 3, "Field2", "This field is used

for..", "F2"); F31 = GetData(32, 343); F31 = GetData(0b01010101, 349843);

/* this loop will be run 2 times. */ Repeat Count = 2 {

F1 = AddField(CURPOS, 23, "SubField of field f1",

"subfield of f1",

"subfield"); }

LeCroy SWAE10 Users Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Copyright

Introduction

What’s In this Manual

Analyzer Overview

Interface

LEDs

Receiving Your Analyzer

Unpacking Your Analyzer

Installing Your Analyzer

Hardware Setup

Figure 1 Typical WUSB Test Setup of Analyzer

Software Installation

Connecting via Ethernet

Connecting to a Network

Connecting via Hub, Switch or Similar device

Launching Your Analyzer

Analyzer

Software Launched

Figure 2 Analyzer Main Toolbar

Operating in Simulation Mode

Protocol Analyzer Projects

Quick Start

Figure 3. New Protocol Analyzer Project Dialog

Figure 4. Typical Packet View Results Display

Example Projects

Run an Example Protocol Analyzer Project

Figure 5. Sample Protocol Analysis Project

Saving a Trace Capture

Figure 6. Analyzer Trace Capture Display

Protocol Analyzer Project Setup

Figure 7. New Trigger and Capture Project Dialog

Data Capture Setup

Capture Everything

Figure 8. Capture Everything (Default)

Capture Pattern

Figure 9. Choosing Capture Patterns

Figure 10. Exclude Patterns Checked

Pre and Post Trigger Data Capture

Figure 11. Post-trigger Capture Dialog Enabled

Defining Patterns

Figure 12. Frame Common Fields Setting

Figure 13. Choosing a Specific Field

Triggering Setup

Snapshot Mode

Manual Trigger Mode

Figure 14. Default Trigger Selected

Pattern Mode

Figure 15. Select Patterns for Trigger

Triggering on a Timer

External Trigger

Sequential T rigger Mode

Figure 16. Select Sequential Trigger Mode

Figure 17. Number of Occurrences

Project Settings

Figure 18. Setting Project Options

Trace Memory Status

Analyzer Settings

Add a Project Note

Figure 19. Project Note

Pre-Trigger

Figure 20. Pre-Trigger Example, 20% Pre-Trigger

Fr ame Generator Projects

Frame Generator Setup

Figure 21. Initiator Dialog

Data Display Manipulation

View Packets Display

Figure 22. View Packets Display

Spec View

Figure 23. Spec View of Frame

Spec View Options

Figure 24. Spec View Format

Data View

Search for Data Pattern

Figure 25. Complete Payload Data Display

Figure 26. Search for Data Pattern

Figure 27. Data Exported as Text
