LD Systems STINGER 15 HP User Manual [en, de, fr]
USER´S MANUAL
BEDIENUNGSANLEITUNG
MANUEL D`UTILISATION
LD STINGER SERIES
LDEB15HP
Thank you for choosing LD-Systems!
ENGLISHDEUTSCHFRANCAIS
We have designed this product to operate reliably over many years. Therefore LD-Systems guarantees for high
quality products with its name and many years of experience as a producer.
Please, take a few moments to read these instructions carefully, as we want you to enjoy your new LD-Systems
products quickly and to the fullest.
For information about LD-Systems check out our website WWW.LD-SYSTEMS.COM
2
LD STINGER SERIES
LDEB15HP
FRANCAIS
FRANCAIS
ENGLISH
DEUTSCH
FRANCAIS
FRANCAIS
FRANCAIS
3
PREVENTIVE MEASURES:
1. Please read this information carefully.
2. Keep all information and instructions in a safe place.
3. Please follow the instructions.
4. Please observe all warnings.
5. Use the device only in the intended manner.
6. Use only stable and appropriate stands and/or mounts when the device
is permanently installed. Make certain that wall brackets are firmly secured.
Make certain that the unit is installed securely and cannot fall down.
8. Do not install the device near radiators, heat accumulators, ovens or other
sources of heat. Make certain that the device is always installed so that is cooled sufficiently and cannot
ENGLISHDEUTSCHFRANCAIS
overheat.
9. Do not place open sources of ignition, e.g., burning candles, on the device.
10. Do not cover ventilation slots.
11. Do not operate the device in the immediate vicinity of water.
12. Please make certain that dripping or splashing water cannot get inside the device. Do not put
objects filled with fluids, such as vases or drinking vessels, on top of the device.
13. Make certain that objects cannot fall into the device.
14. Use the device only with accessories with which the manufacturer intends the device to be used.
15. CAUTION: This PROTECTION CLASS I device must be connected to a mains socket with a protective ground
connection. Never disable the function of the protective ground connection of the included power cord.
If the plug on the included cord does not fit your mains outlet, contact your electrician.
16. Make certain that the power cord is not stepped on. Protect the power cord against pinching, especially at
the device plug and the power plug.
17. In order to prevent damage or accidents, for example, due to tripping hazards, check all connections once
you have connected the device.
18. When connecting the device, make certain that the power plug remains readily accessible.
19. In order to disconnect the device completely from the mains voltage, the power plug must be unplugged.
20. If your device is equipped with a Volex power connector, the matching Volex device plug must be unlocked
in order to disconnect it. This also means that a tug on the power cord can pull the device out of place, thus
causing personal injuries and/or property damage. Thus please make certain to route your cables carefully.
21. If there is a risk of lighting strike or during extended periods of disuse, unplug the power plug.
22. During transport, make certain that the equipment being transported cannot fall down and possibly
cause personal injuries and/or property damage.
23. If your device no longer works properly, if it has been exposed to liquids or an object has fallen inside it or
if it has been damaged in some other manner, turn the device off immediately und unplug the power plug. This
device should be repaired only by authorized experts.
24. Use only a dry cloth to clean the device.
25. Comply with all of the disposal laws that are applicable in your country. During disposal, please separate
plastic and paper/cardboard.
26. Plastic bags must be kept out of the reach of children.
4
04
PREVENTIVE MEASURES / INTRODUCTION:
CAUTION
RISK OF ELECTRIC SHOCK
CAUTION:
To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts inside. Refer
servicing to qualified personnel.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the
user to the presence of uninsulated “dangerous voltage” within the product´s enclosure that may be
of sufficient magnitude to constitute a risk to persons.
The exclamation mark within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
appliance.
CAUTION! HIGH VOLUME!
You will operate this transmission system for professional use. Therefore the commercial use of this equipment
is liable to the rules and regulations of the Accident Prevention & Insurance Association of your industry sector.
Adam Hall as a manufacturer is bound to inform you formally about the existence of eventual sanitary risks.
Hearing damage, prolonged exposure to excessive SPL, the loudspeaker is easily capable of generating sound
pressure levels (SPL) sufficient to cause permanent hearing damage to performers, production crew and audience members. Caution should be taken to avoid prolonged exposure SPL in excess of 90 dB.
DO NOT OPEN
FRANCAIS
FRANCAIS
ENGLISH
DEUTSCH
FRANCAIS
FRANCAIS
FRANCAIS
INTRODUCTION
The LDEB15HP is a 2-way, high power Fullrange speakersystem which, thanks to its characteristics, is a combination of Biamping mode as well as Fullrange mode. Both modes can be used separate.
The characteristics make the LDEB15HP an indispensible and flexible tool for any artist, musician, DJ or sound
reinforcement specialist.
5
BACK PANEL / CONTROL ELEMENTS:
ENGLISHDEUTSCHFRANCAIS
1
2
6
BACK PANEL / CONTROL ELEMENTS:
1
INPUT
Both 4-pole Speakon sockets are parallel wired and can be used for both operating modes, Fullrange and
Biamping mode.
If one socket is used as Input, the other socket can be used as Link Output.
For Fullrange mode (operating mode switch2in position FULLRANGE) only pin 1+ and 1- of the SPEAKON
sockets are used. Frequency separation for high and low frequencies will be done by the internal passive
crossover.
For Biamping mode (operating mode switch in2position BIAMPING) pin 1+ and 1- of the Speakon sockets
are used for low frequencies (woofer) and pin 2+ and 2- are used for high frequencies (tweeter). Frequency
separation has to be done by an active crossover (LDDS21 or LDDPA260) before amplification (recommended
crossover frequency 1000Hz).
2
OPERATING MODE SWITCH
For Fullrange mode set to FULLRANGE.
For Biamping mode set to BIAMPING.
FRANCAIS
FRANCAIS
ENGLISH
DEUTSCH
FRANCAIS
FRANCAIS
FRANCAIS
7
CROSSOVER:
ENGLISHDEUTSCHFRANCAIS
IN
+
-
Xover
Switch
4 x A/B
woofer
+ +
tweeter
-
tweeter -
GREEN
-
4
4a
4b
33µF/250V
tweeter
+
green
blue
3
3a
3b
tweeter +
BLUE
-
2
2b
BLACK
woofer
2a
+
1b
red
1
1a
Inside connection Stinger 15 HP
black
woofer + RED
1-
2-
2+
NL-4 OUT
2-
2+
NL-4 IN
1+1+1-
8
BIAMPING:
FULLRANGE MODE
1+
1-
CROSSOVER
2+
2-
n/c
+
-
+
-
TWEETER
WOOFER
FRANCAIS
FRANCAIS
ENGLISH
DEUTSCH
FRANCAIS
FRANCAIS
FRANCAIS
BIAMPING MODE
2+
2-
1+
1-
TWEETER
WOOFER
+
-
+
-
9
SPECIFICATIONS:
Model LDEB15HP
Type Bass Reflex
Woofer
Compression Driver
Dispersion 60° x 40°
Power Capacity [Cont./Peak] 800 W / 3200 W
ENGLISHDEUTSCHFRANCAIS
Frequency Range 50 Hz - 19 kHz
SPL [1 W / 1 m] 101 dB
Max SPL 130 dB
Impedance 8 ohms
Crossover Frequency 1000 Hz
Connectors
Cabinet Material 18 mm Plywood
Dimensions [W x H x D] 445 x 720 x 425 mm
Features
LD STINGER 15HP
Faital PRO 15FX560
Faital Pro HF200
Input: Speakon Neutrik NL4
Output: Speakon Neutrik NL4
Biamping switchable, Heavy Duty steel handles, stand
support 36 mm
10
MANUFACTURER´S DECLARATIONS:
LIMITED WARRANTY
This Limited Warranty applies to the Adam Hall, LD Systems,LD Premium, Defender, Palmer, Cameo and Eminence
branded products.
The statutory warranty rights towards the seller are not affected by this guarantee. In fact, it justifies, additional
independent warranty claims towards Adam Hall.
Adam Hall warrants that the Adam Hall product you have purchased from Adam Hall or from an Adam Hall authorized reseller is free from defects in materials or workmanship under normal use for a period of 2 or 5 years from
the date of purchase.
The Limited Warranty Period starts on the date of purchase. In order to receive warranty services you are required
to provide proof of the purchase date. Your dated sales or delivery receipt, showing the date of purchase, is your
proof of the purchase date. Should products of the brands named above be in need of repair within the limited warranty period, you are entitled to warranty services according to the terms and conditions stated in this document.
This Limited Warranty extends only to the original purchaser of this Adam Hall branded product and is not transferable to anyone who obtains ownership of the Adam Hall branded product from the original purchaser. During
the Limited Warranty Period, Adam Hall will repair or replace the defective component parts or the product. All
component parts or hardware products removed under this Limited Warranty become the property of Adam Hall.
In the unlikely event that your Adam Hall product has a recurring failure, Adam Hall, at its discretion, may elect to
provide you with a replacement unit of Adam Hall´s choice that is at least equivalent to your Adam Hall branded
product in hardware performance.
Adam Hall does not warrant that the operation of this product will be uninterrupted or error-free. Adam Hall is not
responsible for damage that occurs as a result of your failure to follow the instructions included with the Adam
Hall branded product.
This Limited Warranty does not apply,
-to wear parts (e.g. accumulator)
-to any product from which the serial number has been removed or that has been damaged or rendered defective as the result of an accident
-in case of, misuse, abuse, or other external causes
-by operation outside the usage parameters stated in the user´s documentation shipped with the product by use
of spare parts not manufactured or sold by Adam Hall
-by modification or service by anyone other than Adam Hall
FRANCAIS
FRANCAIS
ENGLISH
DEUTSCH
FRANCAIS
FRANCAIS
FRANCAIS
These terms and conditions constitute the complete and exclusive warranty agreement between you and Adam
Hall regarding the Adam Hall branded product you have purchased.
11
MANUFACTURER´S DECLARATIONS:
LIMITATION OF LIABILITY
If your Adam Hall branded hardware product fails to work as warranted above, your sole and exclusive remedy
shall be repair or replacement. Adam Halls’ maximum liability under this limited warranty is expressly limited
to the lesser of the price you have paid for the product or the cost of repair or replacement of any hardware
components that malfunction in conditions of normal use.
Adam Hall is not liable for any damages caused by the product or the failure of the product, including any lost
profits or savings or special, incidental, or consequential damages. Adam Hall is not liable for any claim made by
a third party or made by you for a third party.
ENGLISHDEUTSCHFRANCAIS
This limitation of liability applies whether damages are sought, or claims are made, under this Limited Warranty
or as a tort claim (including negligence and strict product liability), a contract claim, or any other claim. This limitation of liability cannot be waived or amended by any person. This limitation of liability will be effective even if
you have advised Adam Hall of an authorized representative of Adam Hall of the possibility of any such damages.
This limitation of liability however, will not apply to claims for personal injury.
This Limited Warranty gives you specific legal rights. You may also have other rights that may vary from state to
state or from country to country. You are advised to consult applicable state or country laws for a full determination of your rights.
REQUESTING WARRANTY-SERVICE
To request warranty service for the product, contact Adam Hall or the Adam Hall authorized reseller from which
you purchased the product.
12
CORRECT DISPOSAL OF THIS PRODUCT (ELECTRICAL WASTE)
(Applicable in the European Union and other European countries with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed with other household
wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government
office, for details on where and how they can recycle this item in an enviromentally friendly manner.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product should not be mixed with other commercial wastes for disposal.
