La Pavoni P3 User Manual
P3 / P3 EVOLUTION
®
Cod. 2850017 - Rev. 00 - Marzo 2009
TECHNICAL CHARACTERISTICS
Dimensions: Height 62 cm
Width 42 cm
Depth 40 cm
Weight: 35 Kg
Voltage supply: 230 Vac. 50 Hz or 120 Vac. 60Hz on request
Absorbed power: 1,6 KW
Selections: 11 selections.
System of payment: predisposed for
Obliterator / token system 24Vdc
Selector 12Vac or 24Vac
Executive / MDB system
Water connection: inside tank 15lit.
Optional:
connection kit to the mains water
Small cabinet with puck & waste containers
beniamino filter (anti-limestone filter)
Cables for Executive / MDB connection
LEGEND
F WATER FILTER
VA ONE-WAY VALVE
D ANTI-LIMESTONE FILTER (optional)
CV FLOWMETER
P PUMP
V ONE-WAY VALVE
C BOILER
Ev1 TEA OR SOLUBLE COFFEE VALVE
Ev2 MILK & CHOCOLATE VALVE
Ev3 HOT WATER VALVE (OPTIONAL)
EvE ESPRESSO COFFEE VALVE
GE ESPRESSO GROUP
S WASTE
M1 TEA OR COFFEE MIXER
M2 MILK & CHOCOLATE MIXER
U1 TEA SPOUT
U2 MILK&CHOCOLATE SPOUT
U3 HOT WATER SPOUT (OPTIONAL)
UC ESPRESSO SPOUT
Pag. 2
Pag. 27
WATER FLOW DIAGRAM
GRINDER
The quantity of ground coffee is adjustable through a screw (2); screwing it the
quantity decreases, while unscrewing it, the quantity increases..
To adjust the degree of grinding, after having pushed the lock (6), act on the
grind-stone holder (1), clockwise to have a finer grinding, while in counterclockwise to obtain a bigger grinding.
Make sure that the lock comes back in the hole of block of the grind-stone holder,
before starting the grinder
.
Pag. 26
Pag. 3
INSTALLATION
Before installing the machine, read carefully this manual.
Install the machine in a dry and hygienic place.
ELECTRIC CONNECTION
Before connecting the machine to an electric plug, please follow these precautions:
• The main supply must correspond to the power requirements of the machine
(1600W).
• Check that the power supply voltage correspond to the voltage shown in the
rating label.
• Check that the main socket is correctly earthed.
• If the power supply cable is replaced, use only original type cables (request the
special cable with M type connection to the manufacturer).
The manufacturer will not accept responsibility for any
damage arising if these precautions are not complied
with.
The machine is provided of a general lighted switch, located on the back panel
and of a security push button placed on the chassis that breaks off the power to
the electronic board when you open the door. To restore the power also with the
door opened, take out the push button.
All the electric devices in the machine work with a 24 Vdc voltage, except the
boiler heating element and the transformer that work with 230 or 115 Vac.
LEGEND
A Main power
B Main switch
C “Anti-interference” filter
D Transformer 230/24 Vac or 120/24 Vac
E Coffee group heating elem. 24 Vac
F Ventilator
G Safety clixon 145°C
H Boiler heating element 1200 W
IP “Door” safety switch
S Boiler temperature sensor
MG “Supply” group-microswitch
MS “Pause” group-microswitch
MD “Coffee-doser” microswitch
GA Float
MC “Token system” contact.
CV Flowmeter
1 GRINDER MOTOR
2 COFFEE-RELEASER SOLENOID
3 COFFEE-GROUP MOTOR
4 COFFEE ELECTRO-VALVE
5 PUMP
7 “MILK & CHOCOLATE” ELECTRO-VALVE & MIXER
8 MILK DOSER-MOTOR
9 “TOKEN SYSTEM” COIL
10 CHOCOLATE DOSER-MOTOR
11 TEA ELECTRO-VALVE & MIXER
12 TEA DOSER-MOTOR
13 HOT WATER ELECTRO-VALVE
F1 1.6A FUSE
F2 10A FUSE
00 black 66 Blue
11 Brown 77 Violet
22 Red 88 Grey
33 Orange 99 White
44 Yellow XX Pink
55 Green YY Light blue
WIRE COLORS
Pag. 4
Pag. 25
ELECTRICAL DIAGRAM
HYDRAULIC CONNECTION
The machine could be installed on:
• a cabinet with place for cups, spoons and sugar and a water tank of 15lt
• a small base with waste containers (the machine has to be with mains water
connection).
On cabinet
Place the dispenser on the base and fix it with the screws.
Fill up the special water tank with potable water, insert the tube with the
filter and the one-way valve , and if it's present, the float.
Insert in the tank of 5 lt. the waste pipe.
Fix a bag to the apposite hook for the coffee grounds.
Fill the containers, with the apposite products.
On small base
Check the mains pressure doesn’t exceed 2 bar, otherwise it is necessary to
install a pressure-reductor.
Connect the mains pipe to the electro valve.
Verify, through the manometer inside the machine, that the pressure doesn’t
overcome 1 bar, otherwise adjust it with the inside reductor.
Fill the containers, with the apposite products.
PAYMENT SYSTEM CONNECTION
• VALIDATOR 12V connect to the keyboard connector COIN12V (see
figure at page 6).
• VALIDATOR 24V connect to the keyboard connector COIN12V (see
figure at page 6).
• EXECUTIVE / MDB connect to the relative cables (optional)
• SINGLE IMPLUSE SYSTEM (obliterator, token system, etc.) connect to the
connector 6 pins in the right up angle of the machine.
After the electric connection, it is necessary to set the used system into the program (see page 13).
Pag. 24
Pag. 5
