La Crosse Technology WS-8011UM, WS-8011UM User Manual

B



WS-8011UM with TX2U

Radio Controlled Temperature Clock

Pages 2 through 12

------------------------------------------------------------------------------------



WS-8011UM with TX5U

Radio Controlled Temperature Clock

Pages 14 through 26

433 MHz

433 MHz

Battery
Cover

attery

Cover

WS-8011UM with TX2U

433 MHz

Radio Controlled Temperature Clock

Instruction Manual



Battery
Cover

2

TABLE OF CONTENTS
Topic Page

Inventory of Contents/ Additional Equipment 3
About WWVB 3
Quick Set-Up Guide 3
Detailed Set-Up Guide
Battery Installation 4
Program Mode
Function Buttons 5
Time Zone Setting 5
DST (Daylight Saving Time) Setting 6
Language Selection 6
Time Setting 6
Calendar Setting 7
12/24-Hour Setting 7
Selecting F or C
Features & Operations
Changing Display Mode (seconds, temperature ) 7
The Alarm 8
Indoor Temperature 8
Remote Temperature 8
Mounting 9-10
Maintenance & Care 10
Troubleshooting 11
Specifications 11
Warranty Information 12

7

INVENTORY OF CONTENTS

1) WS-8011UM

2) TX2U Remote temperature transmitter

3) Instruction manual and warranty card.

ADDITIONAL EQUIPMENT (not included)

1) Two fresh 1.5V AA batteries.

2) Two fresh 1.5V AAA batteries.

3) Three wall-hanging screws.

4) Appropriate screwdriver for screws.

ABOUT WWVB (Radio Controlled Time)

The NIST (National Institute of Standards and Technology—Time and Frequency
Division) WWVB radio station is located in Ft. Collins, Colorado, and transmits the exact
time signal continuously throughout the United States at 60 kHz. The signal can be
received up to 2, 000 miles away through the internal antenna in the Temperature Clock.
However, due to the nature of the Earth’s Ionosphere, reception is very limited during
daylight hours. The Temperature Clock will search for a signal every night when
reception is best. The WWVB radio station derives its signal from the NIST Atomic
clock in Boulder, Colorado. A team of atomic physicists is continually measuring every
second, of every day, to an accuracy of ten billionths of a second per day. These
physicists have created an international standard, measuring a second as 9,192,631,770
vibrations of a Cesium-133 atom in a vacuum.

QUICK SET-UP GUIDE

1) Insert two AAA batteries into the remote transmitter.

2) Insert two AA batteries into the Temperature Clock.

3) Wait 10 minutes for WWVB reception and remote temperature.

4) If there is no WWVB reception, manually set the time and date (instructions

in the Program Mode).

5) Program the settings.

6) Mount the WS-8011UM in a suitable location, where WWVB and

transmitter signals can be received.

7) Mount the transmitter where remote temperature measurement is desired

(on the North side of a house for example).

DETAILED SET-UP GUIDE
I) BATTERY INSTALLATION

Note:

To avoid start-up problems make sure that the batteries do not spring free.

3

4

A) REMOTE TEMPERATURE TRANSMITTER

A

1) Remove the battery cover. Place your thumb over

the two air-vent slots on the face of the Remote
Temperature Transmitter, push down gently, and

Battery
Cover

slide battery cover down and off. Observing the
correct polarity, install 2 AAA batteries. The
batteries will fit tightly (to avoid start-up problems make sure that they do
not spring free during installation).

2) Replace the battery cover.

B) TEMPERATURE CLOCK

1) Remove the battery cover,

located on the backside of the
unit and directly below the

Battery Cover

function buttons.

2) Observe the correct polarity,

and install 2 AA batteries.

Battery Compartment

3) Replace the battery cover.

Note: After the batteries have
been installed a tone will sound,
and all the LCD’s (Liquid Crystal
Display) will briefly light up. The
indoor temperature, the date as “1/
1”, the weekday as “MON”, and
the remote temperature will be
displayed (within three minutes).
Also, the time will appear as “-:--” for approximately 1 minute. The WWVB search
is automatically initiated, and a tower icon appears and flashes with the time colon
(no tower icon will appear if the WWVB is too weak to be detected, and the time
display will remain on “-:--”). While the WWVB search is being conducted various
numbers will appear in the time display. Within 10 minutes the Temperature Clock
will either display the WWVB time, or discontinue the search if the time is not
found. If the search is cancelled “-:--” will appear in the time LCD. The
Temperature Clock will conduct a WWVB search every hour until the first signal is
found. Once the WWVB time is found, a search is automatically conducted nightly
at midnight. If the signal is found at midnight, the tower icon will remain, if not,
another search will take place every hour (until 6:00 am) until the signal is found
successfully. If no signal is found during this period, the tower icon will not appear
and the clock will search again at 12:00 am the next night.

WWVB

Dat

Weekday or
seconds display

Radio reception

Indoor temperature or
seconds display

larm

Outdoor temperature

II) PROGRAM MODE

To enter the Program Mode hold down the “SET” button for 2 seconds, until
“-5EST” flashes in the Date LCD. The Program Mode is laid out in a manner that
allows you to program each function separately, or you can follow the instructions
entirely to program the Temperature Clock. Complete programming is usually done
for the initial set-up, and will require you to skip step 1 of programming sections C

through H. Press the “SNOOZE” button at any time to exit the Program Mode, or
wait approximately 15 seconds for the Temperature Clock to automatically return to
normal operation.

A) FUNCTION BUTTONS

There are 4 function buttons located on the backside of the Temperature Clock.
The function buttons are labeled: SET, +, ALARM, and SNOOZE.

B) TIME ZONE SETTING

1) Hold down the “SET” button for 2 seconds, the default setting “-5EST” will

flash in the Date LCD.

2) Press the “+” button to select the appropriate time zone. There are 13 time

zones to choose from:

-4ATL Atlantic Time

-5EST Eastern Time (default setting)

-6CST Central Time

-7MST Mountain Time

-8PST Pacific Time

-9ALA Alaskan Time

-10HAW Hawaiian Time

-11, -12 Next two time zones West of HAW
GMT Greenwich Mean Time

-1, -2, -3GMT Three time zones West of GMT

3) Press the “SET” button to confirm the time zone setting, and to advance to

DST (Daylight saving time) setting.

C) DST (DAYLIGHT SAVING TIME) SETTING

Note:

The DST default is “On”, meaning that the WWVB will automatically
change the time according to Daylight Saving Time in the spring and fall. For
areas that do not recognize DST changes (Arizona, Hawa ii and parts of
Indiana) turn the DST “OFF”.

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash); press the “SET” button once more until “On” flashes in the time
LCD and “DST” flashes where the Weekday normally appears.

2) Press the “+” button to turn the DST off, as will be indicated by the display

of “OFF” in the time LCD.

3) Press the “SET” button to confirm the DST setting, and to advance to select

the language for the weekday.

5

6

D) LANGUAGE SELECTION FOR THE WEEKDAY

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash), press the “SET” button 2 more times, until the default language
“US” flashes in the time LCD.

2) Press the “+” button to toggle through and to select the desired language.

There are 3 languages to select from:

US English
F French
E Spanish

Press the “SET” button to confirm the language setting, and to advance to
manually set the time.

8) The default weekday “MON” (depends on selected language) will flash.

Press the “+” button to select the appropriate weekday.

9) Press the “SET” button to confirm the calendar settings, and to advance to

select either 12 or 24-hour time display.

G) 12/24-HOUR SETTING

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash), press the “SET” button 9 more times, until the “12” hour time
display flashes in the time LCD.

2) Press the “+” button to toggle between 12 and 24 hour time.

3) Press the “SET” button to confirm the 12/24-hour time display, and to

advance to select either F or C.

E) TIME SETTING

Note:

When the WWVB signal is found, that time will over-ride the manually set

time.

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash), press the “SET” button 3 more times, until the hour “12” flashes in
the time LCD.

2) Press the “+” button to select the hour. Note:

will appear to the left of the hour display, if it is AM nothing will be
displayed.

3) Press the “SET” button to confirm the hour setting, and to shift to select the

minutes.

4) Press the “+” button to select the minutes.

5) Press the “SET” button to confirm the time setting, and to advance to

manually set the calendar.

F) CALENDAR SETTING

Note:

When the WWVB signal is found, that date will over-ride the manually set

date.

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash), press the “SET” button 5 more times, until the default year “00”
flashes in the date LCD.

2) Press the “+” button to select the year.

3) Press the “SET” button to confirm the year, and to set the month.

4) The default month “1” will flash. Press the “+” button to select the

appropriate month.

5) Press the “SET” button to confirm the month, and to set the date.

6) The default date “1” will flash. Press the “+” button to select the

appropriate date.

7) Press the “SET” button to confirm the date, and to set the weekday.

when setting the hour, “PM”

H) SELECTING F OR C

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash), press the “SET” button 10 more times, until the default “F” flashes
in the time LCD.

2) Press the “+” button to toggle between F and C.

3) Press the “SET” button to confirm the F or C selection, and exit the

Program Mode.

III) FEATURES & OPERATIONS

A) CHANGING DISPLAY MODE (DAY, SECONDS, AN D

TEMPERATURE)

There are three possible display modes to view the day, seconds, and
temperature. The month&date/weekday /indoor temperature/remote temperature

is the default.

To change the display:

1) Press the “+” button. The display should now show the

month&date/weekday/seconds/remote temperature

2) Press the “+” button a second time and the display will now show the

month&date/seconds/indoor temperature/remote temperature

3) Press the “+” button a third time and the display will return to the normal

display.

B) THE ALARM

1) SETTING THE ALARM

Note:

The duration of the alarm is 85 seconds. After each of the first two

25 second periods, the rate of the alarm increases.

(a) Hold down the “ALARM” button for 5 seco n ds. The “TIME” icon to

the right of the minutes (in the time LCD) shifts to “ALARM”, and the
hour digit of the alarm flashes.

(b) Press the “+” button to set the alarm hour.

7

8

(c) Press the “ALARM” button to confirm the hour, and to set the alarm



minutes.

(d) The alarm minutes flash, press the “+” button to set the alarm minutes.
(e) Press the “ALARM” button to confirm and to exit the alarm setting

mode.

Note:

The alarm will be automatically set to sound when exiting the

alarm-setting mode (indicated by the alarm “sound” icon to the right
of the time).

2) ACTIVATING/DEACTIVATING THE ALARM

(a) The alarm will be automatically set to sound when exiting the alarm-

setting mode (indicated by the alarm “sound” icon to the right of the
time).

(b) Press the “ALARM” button to activate and deactivate the alarm. The

alarm “sound” icon to the right of the time will appear or disappear,
and the alarm time will be displayed briefly before returning to the
normal display mode.

3) ACTIVATING THE SNOOZE FUNCTION

(a) While the alarm is sounding, press the “SNOOZE” button to activate

the snooze function. The alarm “sound” icon and “SNOOZE” icon (to
the right of the time) will flash. The duration of the snooze function is
10 minutes, then the alarm will resume.

4) SUSPENDING ALARM

(a) While the alarm is sounding or the SNOOZE is active, press the

“ALARM” button to suspend the alarm until the next day.

C) INDOOR TEMPERATURE

The Indoor Temperature appears on the right side of the Date LCD. The
temperature is checked every 10 seconds, and updated whenever there is a
change.

D) REMOTE TEMPERATURE

The remote temperature will be shown on the right side of the lower LCD
screen. The Weather Temperature Station receives the outdoor temperature (F
or C) from the Remote Temperature Transmitter, and the temperature appears
in the OUTDOOR LCD. The Remote Temperature Transmitter transmits a new
temperature to the Weather Temperature Station 3 times every 10 minutes.

MOUNTING

Hanging Holes

Function Buttons

Foldout Table Stands

There are two possible ways to mount the Temperature Clock: 1) use of the foldout table
stands, or 2) wall mounting.

E) FOLDOUT TABLE STANDS

The Foldout table stand legs are located on the
backside, at the lower corners, and on both sides of
the battery cover. The hinges are towards the edges
of the Temperature Clock, and the ends (with no
hinge) need to be folded out towards the edge. Once
the Foldout table stands are extended, place the
Temperature Clock in an appropriate location.

F) WALL MOUNTING

1) Using a straightedge, horizontally space at 3-

15/16 of an inch (100.58mm) three screw
positions on a wall.

2) Install three mounting screws (not included) into

a wall within transmission range—leaving
approximately 3/16 of an inch (5mm) extended
from the wall.

3) Place the Temperature Clock onto the screws, using the hanging holes on

the backside. Gently pull the Temperature Clock down to lock the screws
into place.

IV) THE REMOTE TEMPERATURE TRANSMITTER

A) The Remote Temperature Transmitter can be mounted in two ways: 1) with the

use of screws, or 2) using the adhesive tape.

9

10

B) MOUNTING WITH SCREWS

1) Remove the mounting bracket from the Remote Temperature Transmitter.

The bracket should snap off easily.

2) Place the mounting bracket over the desired location. Through the three

screw holes of the bracket, mark the mounting surface with a pencil.

3) Where marked, start the screw holes into the mounting surface.

4) Screw mounting bracket onto the mounting surface. Ensure that the screws

are flush with the bracket.

5) Snap the Remote Temperature Transmitter onto the mounted bracket.

C) MOUNTING WITH ADHESIVE TAPE

1) With a nonabrasive solution, clean and dry the back of the mounting bracket

and the mounting surface to ensure a secure hold. The mounting surface
should be smooth and flat.

2) Remove the protective strip from one side of the tape. Adhere the tape to

the designated area on the back of the mounting bracket. Remove the
protective strip from the other side of the tape. Position the Remote
Temperature Transmitter in the desired location, ensuring that the Weather
Temperature Station can receive the signal.

V) MAINTENANCE & CARE

 Extreme temperatures, vibrations, and shock should be avoided to prevent

damage to the units.

 Clean displays and units with a soft, damp cloth. Do not use solvents or

scouring agents—they may mark and damage the displays and casings.

 Do not submerge in water.
 Immediately remove all low powered batteries to avoid leakage and damage.

Replace with new batteries only, and of recommended size.

 Opening the casings invalidates the warranty. Do not try to repair the units.

Contact La Crosse Technology for Repairs.

TROUBLESHOOTING
Problem:
Solution:
Problem:
Solution:

Problem:
Solution:

The LCD is faint.

1) Replace the batteries.
“OFL” appears in the indoor temperature LCD.

1) Move unit to an area with warmer or cooler surrounding
temperature. Current surrounding temperatures are outside
measuring range.
No reception of WWVB signal.

1) It may help reception to face the front of the Temperature

2) Wait overnight for signal.

3) Be sure the Temperature Clock is at least 6 feet from any

Clock in the general direction of Ft. Collins, Colorado.

electrical devices, i.e. TV sets, computers, or other radio
controlled clocks.

4) Remove batteries for five minutes, reinsert and leave the unit

alone overnight without pressing buttons.

5) If problems persist contact La Crosse Technology.

Problem:
Solution:

Problem:
Solution:

Problem:
Solution:

Note:

For any questions not answered, contact La Crosse Technology with the contact

information found at the end of this instructional manual.

SPECIFICATIONS FOR WS-8011UM
Temperature:

Measuring range:

Checking intervals: Every 10 seconds indoor, 3 times in 10 minutes

Power source:
Battery type: Station: 2 x AA, 1.5V (Alkaline)

Battery life: Approximately 12 months

Dimensions (L x W x H):

WARRANTY INFORMATION

La Crosse Technology provides a 1-year warranty on this Temperature Clock. Contact
La Crosse Technology immediately upon discovery of any defects covered by this
warranty.

Before sending the Temperature Clock in for repairs, contact La Crosse Technology. The
Temperature Clock will be repaired or replaced with the same or similar model.

This warranty does not cover any defects resulti ng from improper use, unauthorized
repairs, faulty batteries, or the Clocks inability to receive a signal due to any source of
interference.

Hour is incorrect (minute and date are correct).

1) Be sure correct time zone and daylight saving time are
selected.
“--.-” appears in outdoor temperature LCD

1) Check batteries in remote

2) If batteries are replaced in remote, the unit must be re-started.
Remove all batteries, and then follow start up procedure.
“OFL” appears in the outdoor temperature LCD

1) Remote temperature is out of range.

2) Check batteries.

3) Interference from an outside source (cordless telephone, etc.)

4) Contact La Crosse Technology.

32F to 122F with 0.2F resolution (indoor)

-21.8F to 140F with 0.2F resolution (outdoor)
(0C to 50C with 0.1C resolution)

for remote temperature.

Transmitter: 3 x AAA, 1.5V (Alkaline)

11.4 x 0.98 x 7.5 in (290 x 25 x 190mm)

11

12

B

LA CROSSE TECHNOLOGY WILL NOT ASSUME LIABILITY FOR I NCI DEN TA L,
CONSEQUENTIAL, PUNITIVE, OR OTHER SIMILAR DAMAGES ASSOCIATED
WITH THE OPERATION OR MALFUNCTION OF THIS TEMPERATURE CLOCK.
THIS PRODUCT IS NOT TO BE USED FOR MEDICAL PURPOSES OR FOR
PUBLIC INFORMATION. THIS PRODUCT IS NOT A TOY. KEEP OUT OF
CHILDRENS’ REACH.

This warranty gives you specific legal rights. You may also have other rights specific to
your State. Some States do not allow the exclusion of consequential or incidental
damages; therefore the above exclusion of limitation may not apply to you.

For warranty work, technical support, or information contact:

La Crosse Technology, Ltd

2809 Losey Blvd. S.
La Crosse, WI 54601
Phone: [phone]

Fax: [phone]

e-mail: [e-mail] (warranty work)

[e-mail] (information on other products)

web: www.lacrossetechnology.com

FCC ID: OMO-01RX (receiver)

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO
THE FOLLOWING TWO CONDITIONS:

1. THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND

2. THIS DEVICE MUST ACCEPT INTERFERENCE RECEIVED, INCLUDING INTERFERENCE
THAT MAY CAUSE UNDESIRED OPERATION.

WS-8011UM – TX6U

433 MHz

Radio Controlled Temperature Clock

Instruction Manual



attery

Cover

13

14

TABLE OF CONTENTS
Topic Page

Inventory of Contents/ Additional Equipment 16
About WWVB 16
Quick Set-Up Guide 16-17
Detailed Set-Up Guide
Battery Installation 17-18
Program Mode
Function Buttons 18
Time Zone Setting 18-19
DST (Daylight Saving Time) Setting 19
Language Selection 19
Time Setting 19
Calendar Setting 20
12/24-Hour Setting 20
Selecting F or C
Features & Operations
Changing Display Mode (seconds, temperature) 21
The Alarm 21
Indoor Temperature 22
Remote Temperature 22
Mounting 23-24
Maintenance & Care 24
Troubleshooting 24-25
Specifications 25
Warranty Information 26

21

INVENTORY OF CONTENTS

4) WS-8011UM

5) TX6U remote temperature transmitter

6) Instruction manual and warranty card.

ADDITIONAL EQUIPMENT (not included)

5) Two fresh 1.5V AA batteries (for the temperature clock).

6) Two fresh 1.5V AA batteries (for the remote temperature transmitter).

7) Three wall-hanging screws.

8) Appropriate screwdriver for screws.

ABOUT WWVB (Radio Controlled Time)

The NIST (National Institute of Standards and Technology—Time and Frequency
Division) WWVB radio station is located in Ft. Collins, Colorado, and transmits the exact
time signal continuously throughout the United States at 60 kHz. The signal can be
received up to 2, 000 miles away through the internal antenna in the temperature clock.
However, due to the nature of the Earth’s Ionosphere, reception is very limited during
daylight hours. The temperature clock will search for a signal every night when
reception is best. The WWVB radio station derives its signal from the NIST Atomic
clock in Boulder, Colorado. A team of atomic physicists is continually measuring every
second, of every day, to an accuracy of ten billionths of a second per day. These
physicists have created an international standard, measuring a second as 9,192,631,770
vibrations of a Cesium-133 atom in a vacuum. For more information about WWVB
please see the NIST website at http://www.boulder.nist.gov/timefreq/stations/wwvb.htm

QUICK SET-UP GUIDE

Hint: Use good quality Alkaline Batteries and avoid rechargeable batteries.

1. Have the indoor station and outdoor remote 3 to 5 apart.

2. Batteries should be out o f both units for 10 minutes.

3. Place the batteries into the remote temperature sensor first then into the

temperature clock.
(All remote temperature sensors must be started before the temperature
clock)

4. DO NOT PRESS ANY BUTTONS FOR 10 MINUTES.

In this time the temperature clock and remote temperature sensor will start to talk to each
other and the temperature clock will show both the indoor temperature and an outdoor
temperature. If the temperature clock does not display both temperatures after the 10
minutes please retry the set up as stated above. After both indoor and outdoor
temperatures are displayed for 10 minut es you can place your remote temperature sensor
outdoors and set your time.

15

16

B

A

The remote temperature sensor should be placed in a dry, shaded area. The remote
temperature sensor has a range of 80 feet. Any walls that the signal will have to pass
through will reduce distance. An outdoor wall or window will have 20 to 30 feet of
resistance and an interior wall will have 10 to 20 feet of resistance. Your distance plus
resistance should not exceed 80 ft. in a straight line.

NOTE: Fog and mist will not harm your remote temperature sensor but direct rain must

be avoided.

To complete the set up of your temperature clock after the 10 minutes have passed please
follow the steps below.

DETAILED SET-UP GUIDE
VI) BATTERY INSTALLATION

Note:

To avoid start-up problems make sure that the batteries do not spring free.

A) REMOTE TEMPERATURE TRANSMITTER

1) Remove the battery cover. Place your thumb over

the two air-vent slots on the face of the remote
temperature sensor, push down gently, and slide

attery

Cover

battery cover down and off.

2) Observing the correct polarity, install 2 AA batteries.

The batteries will fit tightly (to avoid start-up
problems make sure that they do not spring free
during installation).

3) Replace the battery cover.

B) TEMPERATURE CLOCK

1) Remove the battery cover,

located on the backside of the
temperature clock and directly

Battery Cover

below the function buttons.

2) Observe the correct polarity,

and install 2 AA batteries.

3) Replace the battery cover.

Note: After the batteries have
been installed a tone will sound,
and all the LCD’s (Liquid
Crystal Display) will briefly
light up. The indoor

WWVB

17

Battery Compartment

Radio reception

Dat

Weekday or
seconds display

larm

Outdoor temperature

Indoor temperature or
seconds display

temperature, the date as “1/ 1”, the weekday as “MON”, and the remote temperature
will be displayed (within three minutes). Also, the time will appear as “-:--” for
approximately 1 minute. The WWVB search is automatically initiated, and a tower
icon appears and flashes with the time colon (no tower icon will appear if the
WWVB is too weak to be detected, and the time display will remain on “-:--”).
While the WWVB search is being conducted various numbers will appear in the
time display. Within 10 minutes the temperature clock will either display the
WWVB time, or discontinue the search if the time is not found. If the search is
cancelled “-:--” will appear in the time LCD. The temperature clock will conduct a
WWVB search every hour until the first signal is found. Once the WWVB time is
found, a search is automatically conducted nightly at midnight. If the signal is found
at midnight, the tower icon will remain, if not, another search will take place every
hour (until 6:00 am) until the signal is found successfully. If no signal is found
during this period, the tower icon will not appear and the clock will search again at
12:00 am the next night.

VII) PROGRAM MODE

To enter the Program Mode hold down the “SET” button for 2 seconds, until
“-5EST” flashes in the Date LCD. The Program Mode is laid out in a manner that
allows you to program each function separately, or you can follow the instructions
entirely to program the temperature clock. Complete programming is usually done
for the initial set-up, and will require you to skip step 1 of programming sections C
through H. Press and release the “SNOOZE” button at any time to exit the Program
Mode, or wait approximately 15 secon ds f o r the temperature clock to automatically
return to normal operation.

A) FUNCTION BUTTONS

There are 4 function buttons located on the backside of the temperature clock.
The function buttons are labeled: “SET”, “+”, “ALARM”, and “SNOOZE”.

B) TIME ZONE SETTING

1) Hold down the “SET” button for 2 seconds, the default (factory) setting

“-5EST” will flash in the Date LCD.

2) Press and release the “+” button to select the appropriate time zone. There

are 13 time zones to choose from:

-4ATL Atlantic Time

-5EST Eastern Time (default setting)

-6CST Central Time

-7MST Mountain Time

-8PST Pacific Time

-9ALA Alaskan Time

-10HAW Hawaiian Time

-11, -12 Next two time zones West of HAW
GMT Greenwich Mean Time

-1, -2, -3GMT Three time zones West of GMT

18

3) Press and release the “SET” button to confirm the time zone setting, and to

advance to DST (Daylight saving time) setting.

C) DST (DAYLIGHT SAVING TIME) SETTING

Note:

The DST default is “On”, meaning that the WWVB will automatically
change the time according to Daylight Saving Time in the spring and fall. For
areas that do not recognize DST changes (Arizona, Hawa ii and parts of
Indiana) turn the DST “OFF”.

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash).

Note: when setting the hour, “PM” will appear to the left of the hour display, if
it is AM nothing will be displayed.

4) Press and release the “SET” button to confirm the hour setting, and to shift

to select the minutes.

5) Press and release the “+” button to select the minutes.

6) Press and release the “SET” button to confirm the time setting and to

advance to manually set the calendar.

F) CALENDAR SETTING

Note:

When the WWVB signal is found, that date will over-ride the manually set

date.

2) Press and release the “SET” button once more until “On” flashes in the time

LCD and “DST” flashes where the Weekday normally appears.

3) Press and release the “+” button to turn the DST off, as will be indicated by

the display of “OFF” in the time LCD.

4) Press and release the “SET” button to confirm the DST setting, and to

advance to select the language for the weekday.

D) LANGUAGE SELECTION FOR THE WEEKDAY

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash).

2) Press and release the “SET” button 2 times until the default language “US”

flashes in the time LCD.

3) Press and release the “+” button to toggle through and to select the desired

language. There are 3 languages to select from:

US English
F French
E Spanish

4) Press and release the “SET” button to confirm the language setting, and to

advance to manually set the time.

E) TIME SETTING

Note:

When the WWVB signal is found, that time will over-ride the manually set
time.

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash).

2) Press and release the “SET” button 3 times until the hour “12” flashes in

the time LCD.

3) Press and release the “+” button to select the hour.

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash).

2) Press and release the “SET” button 5 times until the default year “00”

flashes in the date LCD.

3) Press and release the “+” button to select the year.

4) Press and release the “SET” button to confirm the year, and to set the

month.

5) The default month “1” will flash.

6) Press and release the “+” button to select the appropriate month.

7) Press and release the “SET” button to confirm the month and to set the date.

8) The default date “1” will flash.

9) Press and release the “+” button to select the appropriate date.

10) Press and release the “SET” button to confirm the date and to set the

weekday.

11) The default weekday “MON” (depends on selected language) will flash.

12) Press and release the “+” button to select the appropriate weekday.

13) Press and release the “SET” button to confirm the calendar settings and to

advance to select either 12 or 24-hour time display.

G) 12/24-HOUR SETTING

Note:

12-hour uses AM/PM, 24-hour is also known as “military” time.

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash).

2) Press and release the “SET” button 9 times until the “12” hour time display

flashes in the time LCD.

3) Press and release the “+” button to toggle between 12 and 24 hour time.

4) Press and release the “SET” button to confirm the 12/24-hour time display

and to advance to select either F or C.

19

20

H) SELECTING F OR C

1) Hold down the “SET” button for 2 seconds (the selected time zone will

flash).

2) Press and release the “SET” button 10 times until the default “F” flashes in

the time LCD.

3) Press and release the “+” button to toggle between F and C.

4) Press and release the “SET” button to confirm the F or C selection and

exit the program mode.

VIII) FEATURES & OPERATIONS

A) CHANGING DISPLAY MODE (DAY, SECONDS, AN D

TEMPERATURE)

There are three possible display modes to view the day, seconds, and
temperature. The month&date/weekday /indoor temperature/remote temperature

is the default.

To change the display:

1) Press and release the “+” button.

2) The display should now show the month&date/weekday/seconds/remote

temperature

3) Press and release the “+” button.

4) The display will now show the month&date/seconds/indoor

temperature/remote temperature.

5) Press and release the “+” button.

6) The display will return to the normal display.

B) THE ALARM

1) SETTING THE ALARM

Note:

The duration of the alarm is 85 seconds. After each of the first two 25
second periods, the rate of the alarm increases.

(a) Hold down the “ALARM” button for 5 seconds.
(b) The “TIME” icon to the right of the minutes (in the time LCD) shifts to

“ALARM” and the hour digit of the alarm flashes.

(c) Press and release the “+” butto n to set the alarm hour.
(d) Press and release the “ALARM” button to confirm the hour and to set

the alarm minutes.

(e) The alarm minutes flash.
(f) Press and release the “+” button to set the alarm minutes.
(g) Press and release the “ALARM” button to confirm and to exit the alarm

setting mode.

Note: The alarm will be automatically set to sound when exiting the alarm­setting mode (indicated by the alarm “sound” icon to the right of the tim e).

2) ACTIVATING/DEACTIVATING THE ALARM

(a) The alarm will be au tomatically set to sound when exiting the alarm-

setting mode (indicated by the alarm “sound” icon to the right of the
time).

(b) Press and release the “ALARM” button to activate and deactivate the

alarm. The alarm “sound” icon to the right of the time will appear or
disappear, and the alarm time will be displayed briefly before returning
to the normal display mode.

3) ACTIVATING THE SNOOZE FUNCTION

While the alarm is sounding, press and release the “SNOOZE” button to
activate the snooze function.
The alarm “sound” icon and “SNOOZE” icon (to the right of the time) will
flash.
The duration of the snooze function is 10 minutes, then the alarm will
resume.

4) SUSPENDING ALARM

While the alarm is sounding or the SNOOZE is active, press and release the

“ALARM” button to suspend the alarm until the next day.

C) INDOOR TEMPERATURE

The Indoor temperature appears on the right side of the Date LCD. The
temperature is checked every 10 seconds, and updated whenever there is a
change.

D) REMOTE TEMPERATURE

The remote temperature will be shown on the right side of the lower LCD
screen. The temperature clock receives the outdoor temperature (F or C) from
the remote temperature sensor, and the temperature appears in the OUTDOOR
LCD. The remote temperature sensor transmits a new temperature to the
weather temperature clock 3 times every 10 minutes.

21

22

IX) MOUNTING



Hanging Holes

Function Buttons

Foldout Table Stands

There are two possible ways to mount the temperature clock:

 use of the foldout table stands
 wall mounting

A) FOLDOUT TABLE STANDS

The Foldout table stand legs are located on the
backside, at the lower corners, and on both sides of
the battery cover. The hinges are towards the edges
of the temperature clock and the ends (with no hinge)
need to be folded out towards the edge. Once the
foldout table stands are extended place the
temperature clock in an appropriate location.

B) WALL MOUNTING

1) Using a straightedge, horizontally space at 3-

15/16 of an inch (100.58mm) three screw
positions on a wall.

2) Install three mounting screws (not included) into

a wall within transmission range—leaving
approximately 3/16 of an inch (5mm) extended
from the wall.

3) Place the temperature clock onto the screws, using the hanging holes on the

backside. Gently pull the temperature clock down to lock the screws into
place.

X) THE REMOTE TEMPERATURE SENSOR

The remote temperature sensor can be mounted in two ways

 with the use of screws
 using the adhesive tape

A) MOUNTING WITH SCREWS

1) Remove the mounting bracket from the remote temperature sensor. The

bracket should snap off easily.

2) Place the mounting bracket over the desired location.

3) Through the three screw holes of the bracket, mark the mounting surface

with a pencil.

4) Where marked, start the screw holes into the mounting surface.

5) Screw mounting bracket onto the mounting surface. Ensure that the screws

are flush with the bracket.

6) Snap the remote temperature sensor onto the mounted bracket.

B) MOUNTING WITH ADHESIVE TAPE

1) With a nonabrasive solution, clean and dry the back of the mounting bracket

and the mounting surface to ensure a secure hold. The mounting surface
should be smooth and flat.

2) Remove the protective strip from one side of the tape.

3) Adhere the tape to the designated area on the back of the mounting bracket.

4) Remove the protective strip from the other side of the tape.

5) Position the remote temperature sensor in the desired location, ensuring that

the temperature clock can receive the signal.

XI) MAINTENANCE & CARE

 Extreme temperatures, vibrations, and shock should be avoided to prevent

damage to the units.

 Clean displays and units with a soft, damp cloth. Do not use solvents or

scouring agents—they may mark and damage the displays and casings.

 Do not submerge in water.
 Immediately remove all low powered batteries to avoid leakage and damage.

Replace with new batteries only, and of recommended size.

 Opening the casings invalidates the warranty. Do not try to repair the units.

Contact La Crosse Technology for Repairs.

TROUBLESHOOTING
Problem:
Solution:
Problem:
Solution:

The LCD is faint.
Replace the batteries.
“OFL” appears in the indoor temperature LCD.

1) Move unit to an area with warmer or cooler surrounding

temperature.

23

24

2) Current surrounding temperatures are outside measuring

range.

Problem:
Solution:

No reception of WWVB signal.

1) It may help reception to face the front of the temperature

clock in the general direction of Ft. Collins, Colorado.

2) Wait overnight for signal.

3) Be sure the temperature clock is at least 6 feet from any

electrical devices, i.e. TV sets, computers, or other radio
controlled clocks.

4) Remove batteries for five minutes, reinsert and leave the unit

alone overnight without pressing buttons.

5) If problems persist contact La Crosse Technology.

Problem:
Solution:
Problem:
Solution:

Hour is incorrect (minute and date are correct).
Be sure correct time zone and daylight saving time are selected.
“--.-” appears in outdoor temperature LCD

1) Check batteries in the remote temperature sensor.
If batteries are replaced in remote temperature sensor the
temperature clock must be re-started.
Remove all batteries, and then follow start up procedure.

Problem:
Solution:

“OFL” appears in the outdoor temperature LCD

5) Remote temperature is out of range.

6) Check batteries.

7) Interference from an outside source (cordless telephone, etc.)

8) Contact La Crosse Technology.

Note: For any questions not answered, contact La Crosse Technology with the contact
information found at the end of this instructional manual.

SPECIFICATIONS FOR WS-8011UM
Temperature:

Measuring range:

32F to 122F with 0.2F resolution (indoor)

-21.8F to 140F with 0.2F resolution (outdoor)
(0C to 50C with 0.1C resolution)

Checking intervals: Every 10 seconds indoor, 3 times in 10 minutes

for remote temperature.

Power source:
Battery type: Station: 2 x AA, 1.5V (Alkaline)

Transmitter: 2 x AA, 1.5V (Alkaline)

Battery life: Approximately 12 months

Dimensions (L x W x H):

11.4 x 0.98 x 7.5 in (290 x 25 x 190mm)

WARRANTY INFORMATION

La Crosse Technology provides a 1-year warranty on this temperature clock. Contact
La Crosse Technology immediately upon discovery of any defects covered by this
warranty.

Before sending the temperature clock in for repairs, contact La Crosse Technology. The
temperature clock will be repaired or replaced with the same or similar model.

This warranty does not cover any defects resulti ng from improper use, unauthorized
repairs, faulty batteries, or the clocks inability to receive a signal due to any source of
interference.

LA CROSSE TECHNOLOGY WILL NOT ASSUME LIABILITY FOR I NCI DEN TA L,
CONSEQUENTIAL, PUNITIVE, OR OTHER SIMILAR DAMAGES ASSOCIATED
WITH THE OPERATION OR MALFUNCTION OF THIS TEMPERATURE CLOCK.
THIS PRODUCT IS NOT TO BE USED FOR MEDICAL PURPOSES OR FOR
PUBLIC INFORMATION. THIS PRODUCT IS NOT A TOY. KEEP OUT OF
CHILDRENS’ REACH.

This warranty gives you specific legal rights. You may also have other rights specific to
your State. Some States do not allow the exclusion of consequential or incidental
damages; therefore the above exclusion of limitation may not apply to you.

For warranty work, technical support, or information contact:

La Crosse Technology, Ltd

2809 Losey Blvd. S.
La Crosse, WI 54601
Phone: [phone]

Fax: [phone]

e-mail:

[e-mail]

(warranty work)

[e-mail]

(information on other products)

web:

www.lacrossetechnology.com

FCC ID: OMO-01RX (receiver)

OMO-01TX (transmitter)

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO
THE FOLLOWING TWO CONDITIONS:

1. THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND

2. THIS DEVICE MUST ACCEPT INTERFERENCE RECEIVED, INCLUDING INTERFERENCE
THAT MAY CAUSE UNDESIRED OPERATION.

25

26
