La Crosse Technology WS-7013TWC User Manual

Quick Start for your WS-7013U

Hint: Use good quality Alkaline Batteries and avoid rechargeable batteries.

1. Have the indoor station and outdoor remote 3 to 5 apart.

2. Batteries should be out of both units for 10 m i nut es.

3. Place the batteries into the outdoor remote first then into the indoor station.

(All outdoor remotes must be started before the indoor station)

4. DO NOT PRESS ANY BUTTONS FOR 10 MINUTES.

In this time the display and sensor will start to talk to each other and the display will show both the indoor
temperature and an outdoor temperature. If the station does not display both temperatures after the 10
minutes please retry the set up as stated above. After both indoor and outdoor temperatures are displayed
for 10 minutes you can place your sensor outdoors and set your time.

The remote sensor should be placed in a dry, shaded area. The remote sensor has a range of 80 feet. Any
walls that the signal will have to pass through will reduce distance. An outdoor wall or window will have
20 to 30 feet of resistance and an interior wall will have 10 to 20 feet of resistance. Your distance plus
resistance should not exceed 80 ft. in a straight line.

NOTE: Fog and mist will not harm your remote sensor but direct rain must be avoided.

To complete the set up of your temperature station after the 10 minutes have passed please follo w the steps
below.

1. Press and hold the SET button for 5 seconds.

A 12h or 24h will appear on the top line. (12h for AM/PM, 24h for military time)

a. To change between 12h and 24h press and release the MIN/MAX button.

When you have your choice shown on the display press and release the SET button
once.

2. Degree Fahrenheit will now show.
a. To change between Fahrenheit and Celsius, press and release the MIN/MAX button.

When you have your choice shown on the display press and release the SET button
once.

3. An hour will now be flashing.
a. Press and release the MIN/MAX button until the correct hour is shown.

NOTE: When in the 12h mode there is “PM” displayed under the word TIME when in the PM
hours. During the AM hours this area will be blank.

When the correct hour is shown press and release the SET button once.

4. A minute will now be flashing.
a. Press and release the MIN/MAX button until the correct minutes are displayed.

Press and release the SET button once more and you are done.

WS-7013U

Wireless 433 MHz

Temperature Station

Instruction Manual

7,0(

1

TABLE OF CONTENTS

Topic Page

Inventory of Contents 1
Quick Setup 2
Detailed Setup Guide

Battery Installation 3-4
Setting the Time 5
Selecting Units of
Measurement

Features

Minimum and Maximum
Temperatures

Resetting Minimum and

Maximum Temperatures
Additional remote control
senders (optional)
Mounting 10-11
Troubleshooting 12-14
Maintenance and Care 14-15
Specifications 15-16
Warranty Information 17-19

6

6-7

7

7-10

2

INVENTORY OF CONTENTS

1.

The Indoor Temperature Station (Figure

1)

2.

The Remote Control Sensor (TX2U)
and mounting bracket. (Figure 2)

3.

3 each, 1/2” Philips screws.

4.

One strip of double sided adhesive tape.

5.

Instruction Manual and Warranty Card.

Figure 1

7,0(

ADDITIONAL EQUIPMENT

(not included)

1.

1 Philips screwdriver.

2.

2 Fresh AAA 1.5V batteries.

3.

2 Fresh AAA 1.5V batteries.

Figure 2

1

QUICK SETUP

1.

Insert two AAA batteries into the
Remote Control Sender.

2.

Insert two AAA batteries into the
Indoor Temperature Station.

3.

Wait 5-6 minutes, or until the outdoor
temperature is displayed in the
OUTDOOR LCD of the Temperature
Station.

4.

Set the Time

5.

Mount units.

(See complete instructions for details).

Note:

The Remote Control Sender transmits
a signal every 3 minutes. After the batteries
have been installed, the Indoor Temperature
Station searches for these signals for a
duration of 6 minutes. If there is no
temperature reading in the OUTDOOR LCD
after 6 minutes, make sure the units are
within range of each other, or repeat battery
installation process.

2

DETAILED SETUP GUIDE

I.

BATTERY INSTALLATION

A.

REMOTE CONTROL SENDER

Battery compartment

1.

Remove the mounting bracket.

2.

Remove battery cover

3.

Observing the correct polarity, install
2 AAA batteries—make sure they do
not spring free, or start-up problems
may occur. Replace cover.

B.

TEMPERATURE STATION

Note:

After the batteries are installed, DO

NOT press any buttons. This may interfere

with the signals, causing temperatures to
register incorrectly.

Battery cover

3

1.

Remove the battery cover on the
backside. To do this, push up and pull
out.

2.

Observing
the correct
polarity,

Battery
Cover

install 2 AA
batteries.

3.

Replace
battery
cover.

4.

Wait 5-6 minutes or until both indoor
and outdoor temperatures are shown
on the Indoor Temperature Station.

5.

The Temperature
Station should now
show: “-:- -” in the

7,0(

TIME LCD, and
temperatures in the
INDOOR and
OUTDOOR
LCD’s.

4
