SPEC |
Spec No. |
TQ3C-8EA00-E1DES05-00 |
Date |
September 16, 2009 |
TYPE : TCG150XGLBB-C00
< 15.0 inch XGA transmissive color TFT
with touch panel >
CONTENTS
1.Application
2.Mechanical specifications
3.Absolute maximum ratings
4.Electrical characteristics
5.Optical characteristics
6.Lot number identification
7.Warranty
8.Reliability test data
9.Inspection
10.Outline drawing
Sep 18, 2009
KYOCERA CORPORATION KAGOSHIMA HAYATO PLANT LCD DIVISION
This specification is subject to change without notice. Consult Kyocera before ordering.
Original |
Designed by: Engineering dept. |
|
Confirmed by: QA dept. |
|||
Issue Date |
Prepared |
Checked |
|
Approved |
Checked |
Approved |
|
|
|||||
September 16, 2009 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Spec No. |
Part No. |
Page |
|
TQ3C-8EA00-E1DES05-00 |
TCG150XGLBB-C00 |
- |
|
|
|
|
Warning
1.This Kyocera LCD module has been specifically designed for use only in electronic devices and industrial machines in the area of audio control, office automation, industrial control, home appliances, etc. The module should not be used in applications where the highest level of safety and reliability are required and module failure or malfunction of such module results in physical harm or loss of life, as well as enormous damage or loss. Such fields of applications include, without limitation, medical, aerospace, communications infrastructure, atomic energy control. Kyocera expressly disclaims any and all liability resulting in any way to the use of the module in such applications.
2.Customer agrees to indemnify, defend and hold Kyocera harmless
from and against any and all actions, claims, damages, liabilities, awards, costs, and expenses, including legal expenses, resulting from or arising out of Customer's use, or sale for use, or Kyocera modules in applications.
|
|
|
|
|
|
|
Spec No. |
|
|
|
Part No. |
|
|
Page |
||
|
|
|
|
|
|
|
TQ3C-8EA00-E1DES05-00 |
|
TCG150XGLBB-C00 |
|
- |
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Revision record |
|
|
|
|
|
|
|
||||
|
|
|
Date |
Designed by : Engineering dept. |
|
Confirmed by : QA dept. |
|
|
|
|||||||
|
|
|
Prepared |
Checked |
Approved |
|
Checked |
Approved |
|
|
|
|||||
|
|
|
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
Rev.No. |
Date |
Page |
|
|
|
Descriptions |
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Spec No. |
Part No. |
Page |
|
TQ3C-8EA00-E1DES05-00 |
TCG150XGLBB-C00 |
1 |
|
|
|
|
1.Application
This document defines the specification of TCG150XGLBB-C00. (RoHS Compliant)
This specification consists of LCD section and Touch panel section, and each section defines the LCD and the touch panel separately.
Please refer the corresponding section for each part. (The product is ROHS compliant)
|
|
LCD with touch panel |
|
|
LCD |
|
|
|
|
|
|
Type |
|
TCG150XGLBA-A00 |
|
|
|
|
|
Spec. No. |
|
TQ3C-8EA00-E1DES04-00 |
|
|
Type |
|
TCG150XGLBB-C00 |
Inspection spec. No. |
|
- |
|
|
|
|
Touch panel |
|
|||
|
Spec.No. |
|
TQ3C-8EA00-E1DES05-00 |
|
|
||
|
|
Type |
|
KTP150AGAC-C00 |
|
||
|
|
|
|
Spec. No. |
|
TQ3C-8EA00-E1BYD02-01 |
|
|
|
|
|
Inspection spec. No. |
|
- |
|
2. Mechanical specifications
Item |
Specification |
Unit |
|
|
|
Outline dimensions 1) |
326.5 (W) × 253.5 (H) × 14.54 (D) |
mm |
|
|
|
Active area |
Please refer to the LCD specification |
mm |
|
|
|
Mass |
(TBD) |
g |
|
|
|
1) Projection not included. Please refer to outline for details. 3. Absolute maximum ratings
3-1. Electrical absolute maximum ratings
Please refer to the individual LCD and Touch Panel specifications. 3-2. Environmental absolute maximum ratings
Please refer to the individual LCD and Touch Panel specifications.
4. Electrical characteristics
Please refer to the individual LCD and Touch Panel specifications.
5. Optical characteristics
Temp. = 25°C
Item |
Symbol |
Condition |
Min. |
Typ. |
Max. |
Unit |
|
|
|
|
|
|
|
|
|
Brightness |
LWH |
IF=80mA/1LED |
(240) |
(280) |
- |
cd/m2 |
|
line (center point) |
|||||||
|
|
|
|
|
|
1 Please refer to the LCD specification for measuring conditions and other optical characteristics.
M426090
|
Spec No. |
Part No. |
Page |
|
TQ3C-8EA00-E1DES05-00 |
TCG150XGLBB-C00 |
2 |
|
|
|
|
6. Lot number identification
The lot number shall be indicated on the back of the backlight case of each LCD.
TCG150XGLBB-C00 - □□- □□- □ |
MADE IN □□□□□ |
||
↓ ↓ |
↓ |
↓ |
↓ |
1 2 |
3 |
4 |
5 |
No1. - No5. above indicate
1.Year code
2.Month code
3.Date
4.Version Number
5.Country of origin (Japan or China)
Year |
2009 |
2010 |
2011 |
2012 |
2013 |
2014 |
|
|
|
|
|
|
|
Code |
9 |
0 |
1 |
2 |
3 |
4 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Month |
Jan. |
Feb. |
Mar. |
Apr. |
May |
Jun. |
|
|
|
|
|
|
|
Code |
1 |
2 |
3 |
4 |
5 |
6 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Month |
Jul. |
Aug. |
Sep. |
Oct. |
Nov. |
Dec. |
|
|
|
|
|
|
|
Code |
7 |
8 |
9 |
X |
Y |
Z |
|
|
|
|
|
|
|
7.Warranty
Please refer to the LCD specification.
8.Reliability test data Please refer to the LCD specification.
9.Inspection
Please refer to the individual LCD and Touch Panel specifications
M426090
SPEC |
Spec No. |
TQ3C-8EA00-E1DES04-00 |
Date |
August 24, 2009 |
TYPE : TCG150XGLBA-A00
< 15.0 inch XGA transmissive color TFT with LED backlight>
CONTENTS
1.General Description
2.Functional Block Diagram
3.Absolute Maximum Ratings
4.Electrical Characteristics
5.Signal Characteristic
6.Connector & Pin Assignment
7.Reliability Test Criteria
8.Mechanical Characteristics
9.Lot number identification
10.Warranty
11.Operating Precautions
Sep 14, 2009
KYOCERA CORPORATION KAGOSHIMA HAYATO PLANT LCD DIVISION
This specification is subject to change without notice. Consult Kyocera before ordering.
Original |
Designed by: Engineering dept. |
|
Confirmed by: QA dept. |
|||
Issue Date |
Prepared |
Checked |
|
Approved |
Checked |
Approved |
|
|
|||||
August 24, 2009 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Spec No. |
Part No. |
Page |
|
TQ3C-8EA00-E1DES04-00 |
TCG150XGLBA-A00 |
- |
|
|
|
|
Warning
1.This Kyocera LCD module has been specifically designed for use only in electronic devices and industrial machines in the area of audio control, office automation, industrial control, home appliances, etc. The module should not be used in applications where the highest level of safety and reliability are required and module failure or malfunction of such module results in physical harm or loss of life, as well as enormous damage or loss. Such fields of applications include, without limitation, medical, aerospace, communications infrastructure, atomic energy control. Kyocera expressly disclaims any and all liability resulting in any way to the use of the module in such applications.
2.Customer agrees to indemnify, defend and hold Kyocera harmless
from and against any and all actions, claims, damages, liabilities, awards, costs, and expenses, including legal expenses, resulting from or arising out of Customer's use, or sale for use, or Kyocera modules in applications.
|
|
|
|
|
|
|
Spec No. |
|
|
|
Part No. |
|
|
Page |
||
|
|
|
|
|
|
|
TQ3C-8EA00-E1DES04-00 |
|
TCG150XGLBA-A00 |
|
- |
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Revision record |
|
|
|
|
|
|
|
||||
|
|
|
Date |
Designed by : Engineering dept. |
|
Confirmed by : QA dept. |
|
|
|
|||||||
|
|
|
Prepared |
Checked |
Approved |
|
Checked |
Approved |
|
|
|
|||||
|
|
|
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
Rev.No. |
Date |
Page |
|
|
|
Descriptions |
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Spec No. |
Part No. |
Page |
|
TQ3C-8EA00-E1DES04-00 |
TCG150XGLBA-A00 |
1 |
|
|
|
|
1. General Description
TCG150XGLBA-A00 is a Color Active Matrix Liquid Crystal Display composed of a TFT-LCD display, a driver circuit, and a backlight system. The screen format is intended to support XGA (1024(H) x 768(V)) screen and 16.2M (RGB 8-bits) or 262k colors (RGB 6-bits). All input signals are LVDS interface compatible. All design rules of this module can correspond to PSWG standard. TCG150XGLBA-A00 is designed for industrial display applications
.
1-1. Display Characteristics
The following items are characteristics summary on the table under 25 condition:
M400180
|
Spec No. |
Part No. |
Page |
|
TQ3C-8EA00-E1DES04-00 |
TCG150XGLBA-A00 |
2 |
|
|
|
|
1-2. Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature):
Note 1: Measurement method
Equipment: Pattern Generator, Power Supply, Digital Voltmeter, Luminance meter (SR_3 or equivalent)
Aperture |
1°with 50cm viewing distance |
Test Point |
Center |
Environment |
< 1 lux |
M400180
