QCP 820, QCP 1920
and QCP 2700 PHONE
USER GUIDE
This manual is based on the production version of the QCP 820, QCP 1920 or QCP 2700 portable wireless telephone. The products and equipment described in this documentation are manufactured under license from Kyocera Wireless Corp. Incorporated under one or more of the following U.S. Pa tents:
DCN 80-B6673-1EN
[ii]

Important Information

FCC/IC Notice

This device complies with part 15 of the FCC rules. Operation is subject to the following two condition s: (1) This device may n ot cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Caution

The user is cautioned that changes or modifications not expressly appr oved by the party responsible for compli an c e could void the warranty and user’s authori ty to operate the equipment.

Warning

Use only Kyocera Wir eless Corp.-approved accessori es with Kyocer a Wireless Corp. phon es. U se of any unauthorized accessories may be dangerous and will invalidate the phon e wa rranty if said accessories cause damage or a defect to the phone.
Copyright © 2000 Kyocera Wireless Corp. All rights reserved. Portions of the document are Copyright © 1998 QUALCOMM Incorporated.

This user guide applies to the follo wing K yocera Wireless Corp. CDMA wirel ess phone models:

•The QCP 820 phone: Dual-Mode CDMA Digital and Analog Cellular Phones
•The QCP 1920 phone: CDMA Digital PCS Phones
• The QCP 2700 phone: Dual-Band, Dual-Mode CDMA Digital PCS and Analog Cellular Phones
[iii]
Dial Shuttle:
Scroll up
Push in to select
Scroll down
[iv]
CONTENTS
GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
FUNCTION KEYS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
DISPLAY ICONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
USING THE BATTERY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installing and removing the battery 4 Charging the battery 4
TURNING THE PHONE ON AND OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Turning on the phone 5
Turning off the phone 5
YOUR LOCK CODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
STANDBY STATUS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
POWER SAVE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
SHORT OR LONG FEATURES MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
BASIC FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
MAKING A CALL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
CORRECTING DIALING MISTAKES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
DISPLAYING YOUR OWN PHONE NUMBER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
LOCKING AND UNLOCKING THE KEYPAD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Locking the keypad 7
Unlocking the keypad 8
RECEIVING CALLS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Call waiting 8
Three-way calling 8
REDIALING CALLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Redialing your last outgoing call 8
Redialing from the recent calls list 8
MAKING EMERGENCY CALLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Making emergency calls 9
Saving and editing emergency numbers 9
ADJUSTING VOLUME. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
CHANGING LANGUAGES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
SETTING SERVICE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
QCP 820 phone 10
QCP 1920 phone 10
QCP 2700 phone 11
PERMANENT PHONE BOOK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
SAVING NUMBERS TO THE PHONE BOOK. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
RETRIEVING NUMBERS FROM PHONE BOOK. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Retrieving all memory locations 13
Retrieving one entry by memory 13
Retrieving by name search 13
[v]
Retrieving by part of phone number search 13
CHANGING YOUR PHONE BOOK. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Erasing a stored memory 14
Editing a stored memory location 14
DIALING NUMBERS FROM YOUR PHONE BOOK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Speed dialing 15
One/two-touch dialing 15
Dialing from a memory list 15
Dialing from a phone book memory location 15
ADVANCED PHONE BOOK FEATURES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Pause 16
Linking 16
Punctuation characters for name entry 16
Changing case during name entry 17
Viewing a number 17
Restricting an entry 17
RECENT CALLS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
PLACING A CALL FROM THE CALLS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
CALLS LIST OPTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
FEATURE MENUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
SWITCHING BETWEEN MENUS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
LONG MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
SHORT MENU. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
LONG MENU ITEM DESCRIPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Sounds (Menu 1) 21
Timers (Menu 2) 22
Directory (Menu 3) 23
Extras (Menu 4) 23
Security (Menu 5) 24
Display (Menu 6) 24
Network (Menu 7) 25
PAGING, MESSAGING, AND VOICE MAIL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
NEW MESSAGE ALERT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
VIEWING PAGES AND MESSAGES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Reading text messages and pages 27
VIEWING VOICE MAIL NOTIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Viewing voice mail notifications 27
MESSAGE OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
LOW MEMORY WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
OUT OF MEMORY WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
INTERNET BROWSER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
STARTING THE BROWSER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
STARTING A BROWSER APPLICATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
[vi]
RETURNING TO YOUR HOME PAGE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
EXITING THE BROWSER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
NAVIGATING THE PHONE BROWSER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Status indicators 30
Icons 31
INTERNET ALERTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
SETTING UP A DATA CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Data Connectivity Kit 32
Data On the Go Fax/Modem PC Card 32
SETTING UP OUTGOING DATA CALLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
SETTING UP INCOMING DATA CALLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
IN-CALL STATUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
ORDERING ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
PHONE SAFETY AND CARE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
BACKGROUND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Exposure to radio frequency signals 35
FOR BEST PERFORMANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
ANTENNA CARE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
CARING FOR THE BATTERY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
DRIVING SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
ELECTRONIC DEVICES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Pacemakers 37
Hearing aids 37
Other medical devices 38
Vehicles 38
Posted facilities 38
OTHER SAFETY GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Aircraft 38
Blasting areas 38
Potentially explosive atmospheres 38
WHERE TO FIND HELP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
YOUR SERVICE PROVIDER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
YOUR PHONE DOCUMENTATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
KYOCERA TECHNICAL SUPPORT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
[vii]
[viii]

GETTING STARTED

Kyocera Wireless Corp. appreciates your business and is pleased you have selected a CDMA wireless phone. The QCP 820, QCP 1920, and QCP 2700 phones defines new industry standards and will give you many years of dependable service. Your new phone includes time-saving features like these:
• Easy-to-read, four-line, lighted screen that includes a line for informative icons
• Lighted keypad
• Fast, convenient scroll and select “dial-shuttle,” shown in the illustration to the left
• Interactive menu prompts
• Inherent call privacy through Code Division Multiple Access (CDMA) encoding
• Exceptionally long battery life
• Any-key answer, speed dial, auto redial, and 99 memory locations for phone numbers
• Advanced features like voice mail notification, paging, and caller ID
• A variety of helpful accessories
• ... and more!
This section identifies the location of phone controls and function keys and describes the icons that appear on its screen. It explains how to charge the battery and turn the phone on and off. In addition, it descri bes some of the phone ’s features.
1. Depending on services avail able from your carrier
1
[1]

FUNCTION KEYS

Use the follo wing keys as described below.
Dial-shuttle. U se the di al-shuttle on the left si de of th e phon e as you work with menus and perform operations. Turn the dial up and down to scroll through options and press it into the phone to perform actions, such as choosing a feature or option.
Message. Pre ss t o view pages, text messages, and voice mail messages. Clear. Use to erase numbers or characters from the screen or return to a
preceding menu. Press it one time to erase text. Hold it down to erase all text. When working with a menu, press it one time to return to the preceding menu. Hold it down to return to the stan dby screen.
Send. Press to place and receive calls or use features like call waiting and three-way calling (see your service provider for details).
End. Press to disconnect a call or return to the standby screen from any menu.
... Numbers. Press to enter numbers or characters, and to choose menu items.
Power. Press to turn the phone on and off. Star. Press to scroll to the left when enterin g text. Pound. Press to scroll to the right when entering text.
[2]

DISPLAY ICONS

Icons, described below, convey information regarding phone operations.
Memory location. Conveys information, based on the open menu, in the upper-left corner of the screen. For example, phone book memory location number “L01,” recent calls list number “C07,” or feature menu number “F01.”
Digital mode. Appears when the phone is operating in CDMA di gital mode . If it
does not appear, your ph one is eith er opera ting in an alog mod e or servi ce is not available.
Signal strength. Shows the signal strength based on the number of lines that
appear; the more lines you see, the stronger the signal. (If the signal is weak, e xten d th e an tenna. If you are in a buildin g, try standin g
near a window to increase the strength of the signal.) No signal. Indicates service is not available, which means you cannot make or
receive calls. Wait a few min utes to see if you get a signal, or try movin g into an open area.
On call. Appears when a call is in progress. Roaming. Appears when the phone is outside o f its regular service area. If the i con
is flashing, it means you ar e completely outsi de your service area and different calling rates may apply.
Envelope. Indicates you have received a new voice mail, page, or text message.
Press for details.
Battery charge. Shows the remaining battery charge. The more black you see, the
greater the charge.
Keyguard. Indicates the keypad is protected from accidental keypresses. You can
receive calls or messages when the keyguard is activated, but you can’t place a call or perform operations.
Scroll up. Allows you to scroll through menu items using the dial-shuttle. Scroll down. Allows you to scroll through menu items using the dial-shuttle. Select. Indi cates th e menu item that will be selected if you press the
dial-shuttle.
[3]

USING THE BATTERY

The phone com es with a recharg eable battery pack. Three types of batteries are available for use with this phone. Remember to fully charge the battery as soon as its charge gets low to maximize available talk and standby times.

Installing and removing the battery

The battery pack snaps easily into th e back of th e phon e , bottom en d first, for qui ck installati on and removal. To ensure you d o not lose stored numbers an d mess ages , always turn off th e phon e before rem oving the battery.

Charging the battery

The battery charge level icon appears in the upper-righ t corn er o f the phone’s screen.
FULLY CHARGED VERY LOW ALMOST OUT
When the battery charge level is low, the message “Low Battery” appears and the phone sounds a tone. If the battery level becomes too low, the phone turns itself off and any function in progress is not saved.
NOTE: Charge your battery when you see the icon begin to blink. Use the standard Kyocera
Wireless Corp. AC adapter charger or the optional travel charger, desktop charger, or cigarette lighter adapter to recharge th e battery.
NOTE: Y ou do not n eed to completely discharge the battery before charging. U nlike other battery systems, lithium ion has no memory effect that could degrade battery performance .
W ARNING: U se only K yocera Wireless Corp.-approv ed charger s and adapter s . U sin g another adapter may be dangerous and will invalidate the phone warranty if said accessories cause damage or a defect to the phone.
1. If the battery is not installed, snap it into place on the back of the phone—bottom end first.
2. Plug the standard AC adapter into a wall outlet.
3. Insert the other end of the cord into the bottom of the phone. A message indicating the battery is charging should appear immediately. Chargin g a completely discharged standard Extended Li-ion battery takes approximately 6 hours; the Slim Li-ion battery takes approximately 4 hours; and the Ultra-Light Li-ion battery takes approximately
2.5 hours (see Accessories later in this guide).
NOTE: If the phone is turned on, “CH” appears in the upper-left corner of the screen an d indicates the battery is charging. If the phone is turned off, the message “Battery is Charging” appears.
[4]

TURNING THE PHONE ON AND OFF

When you make or receive a call, always extend the antenna and hold the phone above your shoulder to ensure the best voice quality possible.

Turning on the phone

Ensure that a charged battery is installed in the back of the phone or that external power is available (that is, the AC adapter, cigarette lighter adapter, or car kit is properly plugged in).
1. Press momentarily. Th e m e ssage “LOOKING FOR SERVICE” appears on the screen.
2. Release .

Turning off the phone

1. Press for a few seconds until “POWERING OFF” appears.
2. Release .
When the phone is turned off, nothing appears on the screen (unless you are charging the battery).
NOTE: If is pressed for less than 1 second, the phone will not turn off. You must
press for more than 1 second.

YOUR LOCK CODE

Your phone is assigned a four-digit lock code. This code is used to access the Security menu items described on page 24.
Typi c ally, the lock code on a new or recently activated ph one is the last four digits of its phone number (see page 7). Your service provider may also have set your lock code to another default such as 0000, 1234, or some number assigned specifically to you.
STANDBY
Standby status results when the phone is turned on and whenever is pressed. When the phone is in standby status th e progr ammable banner, which in clud es the time an d date , appears . Y ou have access to the ph one’s features from standby.
NOTE: The time and date is automatically acquired from the CDMA digital network. You do not need to set it.
[5]

POWER SAVE

The power save mode feature automatically turns on if the pho n e has n’t been able to acquire a signal after 15 minutes of searching. While this feature is active, the phone’s battery charge is saved and the ph one automati cally rech ecks for service period ically. To man ually f orce the ph one to recheck for service, press any key. A message on the screen indicates the phone is in power save mode.

SHORT OR LONG FEATURES MENU

The phone offers the choice between the use of an extensive long features menu or an abbreviated short features m enu. Th e long m enu allows you to view and chan ge all o f the featur e settings of the phone. The short menu provides access to just a few often-used features. It’s likely that you’ll need only th e short m enu after you person alize and fully set up your phon e (see the Feature Menus chapter of this guide for more information).
NOTE: The instructions in this guide are based upon the long features menu structure.
[6]

BASIC FUNCTIONS

Your phone is easy to use and has many time-saving features.

MAKING A CALL

First, ensure that the phone is on, as described in the Getting Started chapter of this guide.

1. Press the keys to enter the phone number.

2. Press or press the dial-shuttle two times. If the phone is locked or another problem exists , a help messag e appears.

3. Press to end the call.

You can also make calls from phone book memory (page 15) or from your recent calls list (page 18).

CORRECTING DIALING MISTAKES

➤ Press to erase one character at a time.
or
➤ Press and hold for at least 1 second to delete all characters.

DISPLAYING YOUR OWN PHONE NUMBER

If your phone has service and you do not know the number, you can display the phone number assigned to the phone.

1. Select “Features,” by pressing the dial-shuttle.

2. Scroll and select “Directory” in the same way.

3. Select “My Number.”

NOTE: If the short fe a tures menu is active, select “Features” and then scroll and select “My
Number” to see your phone’s number.

LOCKING AND UNLOCKING THE KEYPAD

Y ou can lock the k eypad to avoid accid entally pr essing a k ey. When the keypad is locked , you can press to receive an incoming call or m ess a ge. However, you cannot lock the keypad when a call is in progress.
The quick method of activating the keyguar d is shown below. This feature is also available via the long features menu.

Locking the keypad

➤ Press the dial-shuttle until the message “Keypad is now guarded” appears.
[7]

Unlocking the keypad

➤ Press to unlock the keypad.

RECEIVING CALLS

Y our phone must be turned on to receive calls. Answering calls

1. Press (unless the any-key answer feature is activated).

2. Press to end the call.

NOTE: When you are outside your regular service area ( appears on the screen), a distinctive ringing sound indicates you may be billed differently if you answer the call. See your service provid er for information .

Call waiting

Call waiting1 allows you to respond to an i ncomin g call while you ar e on an othe r call. Two beeps indicate the presence of an incoming call. You can either answer the call or ignore it. If you answer it, you can alternate between the two calls. See your service provider for more information.
1. Press to respond to the incoming call.
2. Press again to alternate between two callers.

Three-way calling

Y our service provider m ay offer three-way calling. A thr ee-way call occurs when an established two-party call adds one more caller.
1. Once a call is in progress, enter th e third party’s number and press .
2. Press to connect the three parties. See your service provider for details.

REDIALING CALLS

Redialing your last outgoing call

➤ Press to redial the last outgoing phone number.

Redialing from the recent calls list

You can use the recent calls list to redial any of the last ten unique outgoing phone numbers.
➤ Press to redial the last outgoing phone number.
1. Dependent on services available from your carrier
[8]

MAKING EMERGENCY CALLS

Y ou can di al 911 or one of three other emergency numbers from your emergency number list, even if the phone is lo cked . Your service provider may have pr epr ogr amm ed th e thr ee em er g en cy numbers for you. A s lon g as appears on the phone’s screen, you can ma ke emer gency calls.

Making emergency calls

1. Press or one of the other three emergency numbers.
2. Press .

Saving and editing emergency numbers

Y ou can easily add or edit phone numbers in your emergency number list.
1. Select “Features.”
2. Scroll and select “Security.”
3. Enter the lock code. Typically, the lock code is ini tially set to the last four digits of your phone number (see page 5).
4. Scroll and select “EMERGENCY #.”
5. Select “Edit” to edit/enter the first emergency number or scroll to other emergency numbers.
6. Select “Save” to save the entered number.

ADJUSTING VOLUME

There are three ways to adjust the volume.
• When you are on a call, turn the dial-shuttle to adjust the earpiece volume.
• When the phone is ringing, turn the dial-shuttle to silence the ringer for that call.
• Use the “Sounds” menu to adjust the ringer, keybeep, and earpiece volumes.
NOTE: When your phone rings, you can also press to silence the ringer for that call. This works even if the keyguard is activated. You can still answer the call after silencing the ringer.

CHANGING LANGUAGES

The screen displays inform ation in f our languag es: English, Fr ench, P ortuguese , and Spanish. You can use the dial-shuttle to select the language you want to use.

1. Press .

2. Press the dial-shuttle one time to select the “Features” menu.

3. Press .

4. Press .

[9]

5. Turn the dial-shuttle until you see the language you want to use, then press the dial-shuttle.

SETTING SERVICE

Use the menu option “Set System” or “Set Service” to prevent your phon e from making or receiving calls outsi de your service area. Th e same m enu lets you control wh ether your d ual-band phone operates in digital or analog mode.
On the QCP 820 phone, you can limit operation to analog mode using the “Force Call” setting (see page 25).

QCP 820 phone

1. From standby mode, select “Features.”
2. Scroll and select “Network.”
3. Scroll and select “Set System.”
4. Turn the dial-shuttle to scr oll through the opti ons, th en press the di al-shuttle to select an option. Available options are:
• AUTOMATIC. This is typically the default setting, which allows the phone to search
for and acquire the preferred service.
• no roaming. This option prevents your ph one fr om makin g or receivin g calls outsid e
your home location.
• A side only or B side only. These options refer to the two cellular blocks. By
selecting one block, you prevent your phone from operating on the other block.

QCP 1920 phone

1. From standby mode, select “Features.”
2. Scroll and select “Network.”
3. Scroll and select “Set Service.” The default setting is “AUTOMATIC.”
4. Scroll and select “no roam ing” if desired.
5. From standby mode, select “Features.”
6. Scroll and select “Network.”
7. Scroll and select “Set Service.”
• AUTOMATIC. This is the default setting, which allows the phone to operate while
roaming. It searches for digital service first, then analog service. Scroll to view the other options and select by pressing the dial-shuttle.
• no roaming. The phone cannot send or receive calls outside its regular servi ce ar ea.
[10]
• dig. only . Th e ph one sends an d r eceives calls in digital mode only. Digital calls offer
clearer voice quality, enhanced privacy, and longer battery life.
• analog only. The phone sends and receives calls in analog mode only. This setting
remain s in effect until you turn o ff th e phone, at whi ch point it automatically reverts to the previous setting.

QCP 2700 phone

1. From standby mode, select “Features.”
2. Scroll and select “Network.”
3. Scroll and select “Set Service.”
• AUTOMATIC. This is the default setting, which allows the phone to operate while
roaming. It searches for digital service first, then analog service. Scroll to view the other options and select by pressing the dial-shuttle.
• no roaming. The phone cannot send or receive calls outside its regular servi ce ar ea.
• dig. only . Th e ph one sends an d r eceives calls in digital mode only. Digital calls offer
clearer voice quality, enhanced privacy, and longer battery life.
• analog only. The phone sends and receives calls in analog mode only. This setting
remain s in effect until you turn o ff th e phone, at whi ch point it automatically reverts to the previous setting.
[11]

PERMANENT PHONE BOOK

The phone has memory for 99 of your friends, relatives, and associates. You can store entries of up to 32 digits with an associated name up to 12 characters. There are two ways to access the entire phone book.
• When a call is not in prog r ess (th e ph on e is in stan dby status): Turn the dial-shuttle one
click in either directi on to th e “SAVED #S” screen. Turn it down an oth er click to enter th e
“Phone Book.”
• Regardless of whether a call is in progress: Select “Features,” then ”Directory,” then
“Phone Book.”

SAVING NUMBERS TO THE PHONE BOOK

Y ou can save numbers through the “Directory” menu or directly from the phone’s standby state (the fastest way). If you’re startin g from stan dby, begin at step 4 below. U se memory locati ons 1 to 9 for one-touch dialing of your most commonly used phone numbers.

1. Select “Features.”

2. Scroll and select “Directory.”

3. Select “Save.”

4. Enter the phone number that you want to save.

5. Select “Options.”

6. Select “Save.”

7. If you prefer, enter a name to go with the number—up to 12 characters long. Press the key labeled with the letter you want. Pr essing a key repeatedly change s th e

letter or number in the flashing cursor position on the screen. When you have the correct letter or number in position on the screen, wait about two seconds for the cursor to automatically advance one space. Press to correct any mistakes. Turn the dial-shuttle to move the cursor forward and backward.

8. Select “Save” to store entered name.

9. Select “Save” at the “Save in location...” prompt to store the entry. Or, if desired, scroll to select (or enter) a custom storage location and follow the remaining “Save” prompts.
[12]

RETRIEVING NUMBERS FROM PHONE BOOK

There are several ways to find numbers in the phone book. This section assumes you’re at the standby status display and not on a call. (Y ou can go to standby by pressin g , or the phone book can be retrieved during a call through the “Features” menu.)

Retrieving all memory locations

1. Turn the dial-shuttle up or down one click to access the “SAVED #S” screen.
2. Turn it down one more click to access “Phone Book.”
3. Scroll through the entries, one entry at a time . The location number of each entry is displayed in the upper left corner of the screen (L01, L02, etc.).
4. Select “Options” to see more information. Press to place a call to that number.

Retrieving one entry by memory

Location number
1. Enter one or two digits corresponding to the location number where the phone book memory is stored.
2. Select “Options.”
3. Scroll and select “RECALL LOC #.”

Retrieving by name search

1. Turn the dial-shuttle to the “SAVED #S” screen.
2. Select “Find Name.”
3. Enter a sequence of identifying letters. At least two letters are recommended for a quick search (su c h as "wh" f or “what’s-his-name”).
4. Select “Find.”
5. Scroll to the desired entry in the list provided.
6. Select “Options” to see more inform ation on that number or press to call.

Retrieving by part of phone number search

You can look for a phone number if you know at least three of the digits.
1. Enter any three consecutive digits from the phone number.
2. Select “Options.”
3. Scroll and select “Find Number.”
4. Any matches will appear. If there are multiple matches, scroll to the de sired entry.
[13]

CHANGING YOUR PHONE BOOK

Erasing a stored memory

There are two ways to erase a memory. From a phone book entry display (meaning you’re alread y looking at the entry you would like to
remove):
1. Select “Options.”
2. Scroll and select “Erase.”
3. Confirm that you want to erase by selecting “Erase.”
Or from the standby display:
1. Select “Features.”
2. Select “Directory.”
3. Scroll and select “Erase.”
4. Select an entry and confirm that you want to erase it.

Editing a stored memory location

1. Select “Features.”
2. Select “Directory.”
3. Scroll and select “Edit.”
4. Scroll to find entry or enter its location number.
5. Select to “Edit” the entry.
6. Choose to edit name, phone number, or location number.
7. Edit the name using or (or by turning the dial-shuttle) to move th e cursor through the name. Use the digit keys to replace letters or add new letters, and use to delete letters. (See page 16 for punctuation and lower case characters.) Edit the phone nu mber or storage location by turning the dial-shuttle to move the cursor to the digit(s) to be edited. Once the cursor is in position, change the number by using the digit keys to insert or replace digits, and to delete digits.
8. If necessary, select “Options.”
9. Select “Save.”
[14]

DIALING NUMBERS FROM YOUR PHONE BOOK

Y ou can ma ke a call using any phone book memory location either by speed dialin g, one-touch dialing, or by pressing while viewing the memory location.

Speed dialing

Y ou can quickl y dial n umbers that ar e saved in your phon e’s phone book with just a couple of key presses.
1. Press the key(s) that correspond to the numeric memory locati on. For example, for memory location 10, press .
2. Press . The phone will find the teleph one number in its ph one book, display it on the screen, and then dial it.

One/two-touch dialing

One/two-touch dialing enables you to dial phone book entries through one key press (for locations 1 to 9) or two key presses (for locations 10 to 99).
You can activate one-touch dialing through the “Touch Dial” item via “Extras” under the long “Features” menu (page 20).
FOR MEMORY LOCATIONS 1 TO 9:
• Press and hold the appropriate key for 1.5 seconds. The display will confirm that the
number has been dialed when it shows “CALLING...”
FOR LOCATIONS 10 TO 99:
1. Press the first digit.
2. Press and hold the second digit for 1.5 seconds.

Dialing from a memory list

1. Turn the dial-shuttle to the “SAVED #S” screen.
2. Turn it another click to enter the phone book.
3. Scroll and select the phone book memory you want.
4. Press or press the dial-shuttle twice.

Dialing from a phone book memory location

While viewing any me mory location, press or press the dial-shuttle twice.

ADVANCED PHONE BOOK FEATURES

Pause

When you call automated system s (such as voi ce m ail), you of ten have to enter a seri es o f digits (such as a password). Instead of manually entering the sam e numbers every time, you can stor e them in your phone book separated by special characters called pauses. While dialing the number, you’ll have to depress the dial-shuttle to release the pause. (The screen will indicate this.)
To insert pauses:
1. Enter the number to be dialed.
2. Select “Options.”
3. Scroll and select “Enter Pause.”
4. Enter the number tones that will follow the pause.
5. Dial the entered number by pressing ; or save it by selecting “Options” and “Save.”

Linking

Linking is an extension of the Pause feature (listed above) that allows you to establish a path between two series of di gits (for e xample , a calling car d or credit car d n umber). Y ou can link two phone book memories when a number is too long to be stored with pauses in a single location (you can store up to 32 digits in each location). While dialing the stored number, press the dial-shuttle to release the digits in the linked memory location.
NOTE: Links are valid only from the initial phone book location. To insert links:
1. Enter the number to be dialed.
2. Select “Options.”
3. Scroll and select “Enter Link.”
4. Enter a one- or two-digit number correspon ding to a phon e book mem ory location. For example, enter “10” to release all of the numbers stored in that memory location number .
5. Dial the entered number by pressing ; or save it by selecting “Options” and “Save.”

Punctuation characters for name entry

Y ou can use any o f th e nine pun ctu ati on char acters (- “ . ‘ , & ( ) :) while you’re entering names during phone book memory storage or editing. Press repeatedly until you see the appropriate character.
[16]

Changing case during name entry

When entering a name, you can use both upper and lower case letters. Press the appropriate number key until you see the letter and cas e you need. After upper case , th e sequence repeats in lower case.

Viewing a number

If the complete number doesn’t fit on the screen, you can view all 32 digits by doing the following.
1. Recall a phone book memory.
2. Select “Options.”
3. Scroll and select “View Number.”

Restricting an entry

Y ou can r e strict memory locations so they can be accessed only after a lock code is entered.
1. Select “Features.”
2. Scroll and select “Security.”
3. Enter your four-digit lock code (see page 5).
4. Scroll and select “RESTRICT #.”
5. Enter the location number that you want to restrict or scroll to the desired location.
6. Select “RESTRICT.”
Complete the same steps to “unrestrict” a previously restricted number. You will then be able to display, dial, or erase the number without first entering the security code.
[17]

RECENT CALLS LIST

To facilitate redialing, the phone keeps a list of the last 10 unique numbers that you dialed, answered, missed, or added. New entries replace older entries as calls are received.
There are two ways to access the calls list.
• In standby (not in a call): Turn dial-shuttle one click in eith er direction to the “SA VED
#S” screen, then up another click to enter the “Calls List.”
• In a call or in standby: Select “Features,” then scrol l to select ”Directory,” then “Calls
List.”
Depending on the operating mode and available features, each entry may contain the phone number, name, length of the call, and time stamp (which re minds you when the call occurred).
You may see one of the following entries when viewing a calls list entry: MISSED CALL Indicates an unanswered incoming call if the caller ID (phone number) is
available.
CALL FROM Indicates a call you received and an swered if the caller ID (phone number) is
available. CALL TO Indicates a call you placed. ADDED Indicates that the number was added using the scratch pad feature. 3-WAY CALL Indicates a three-way call (see page 8). CALL WAITING Indicates a call on hold (see page 8).

PLACING A CALL FROM THE CALLS LIST

You can place a call directly from the calls list.
• Press or press the dial-shuttle two times.

CALLS LIST OPTIONS

When viewing a particular call list entry, select “Options” for additional information or options. You can select:
•“Save” to store the number in the phone book
•“Send” to place a call
•“Duration” to find out the length of the call
•“Time/Date” to see the time and date of the call
[18]
•“View Number” to see the complete phone number
•“Number Tone” to send/play the sounds associated with each entered number system
stored in the list entry (for automated answering systems—such as credit card billing systems and voice mail systems).
[19]

FEATURE MENUS

There are two different feature menus that let you check or change different feature settings. The long menu includes every possi ble menu option. The sho rt menu consists of the most frequently used menu items. When the Long Feature menu is active, the flashing number at the top left corner of the screen indicates the menu number.

SWITCHING BETWEEN MENUS

The menu tr ees on th e following pages show the structure of the long and short menus. To use the long menu:

1. Select “FEATURES.”

2. Scroll and select “Display.”

3. Scroll and select “Menu Length.”

4. Scroll and select “LONG.”

To use the short menu:

1. Select “Features.”

2. Scroll and select “Display.”

3. Scroll and select “Menu Length.”

4. Scroll and select “short.”

LONG MENU

Y ou can access all m enu items by using either the di al-shuttle or the keypad. The blinkin g number in the upper left corner indicates the menu number. The overall structure appears as follows.
[20]
Features
F-1: Sounds
F-2: Timers
F-3: Directory
F-4: Extras
F-5: Security
F-6: Display
F-7: Network
F11: Ringer Volume F12: Mute/UnMute F13: Keybeep Volume F14: Earpiece Volume F15: Ringer Type F16: Key Sound F17: Beep Length
F18: Message Beep
F31: My Number F32: Save F33: Erase F34: Edit F35: Find Name F36: Phone Book F37: Calls List
F51: Lock Phone F52: New Code F53: Restrict # F54: Limit Calls F55: Master Reset F56: Erase Book F57: Erase Calls F58: Emergency #
F71: Roam Alert F72: Drop Alert F73: Priv. Alert F74: Auto-N.A.M. F75: Set N.A.M. F76: Set System/Set Service F77: Force Call (the QCP-820™ phone) F77: Data/Fax In (the QCP-1920™ and QCP-2700® phones)
F21: All Calls F22: Recent Calls F23: Minute Alert F24: Auto-Off
F41: Key Guard F42: Touch Dial F43: Auto-Retry F44: Auto-Answer F45: AnyKey Answer F46: Scratch Pad
F61: Banner F62: Backlight F63: Auto-Hyphen F64: Sort Book F65: Language F66: Menu Length

SHORT MENU

The short menu is a subset of the long menu. You mus t use the di al-shuttle to access any menu item; shortcut keypad entries do not work with the short menu. The short menu structure appears as follows.
Ringer Volume
My Number
Phone Book Find Name Calls List
Features
Saved #s
Lock Phone
Set Service (the QCP-1920™ and QCP-2700® phones)
Long Menu

LONG MENU ITEM DESCRIPTIONS

Menu items available only on the QCP 820 and QCP 1920 phones are identified in the following list by an asterisk (*). Menu items available only on the QCP 2700 phone are identified by two asterisks (**).

Sounds (Menu 1)

This lets you adjust any sound-related feature.
Ringer Volume (Menu 11): Adjust incoming call ringer and new message alert volume
with or . The “escalating” setting starts the ringing out quietly and gradually gets
[21]
louder with each rin g.
Mute/Unmute (Menu 12): Switch the microphone on and off during a call. When the
microphone is off, the othe r party can’t hear you.
Keybeep Volume (Menu 13): Adjust the volume that the keys make when you press them. Earpiece Volume (Menu 14): Adjust the earpiece (speaker) volume. Turning the di al -sh uttle
during a call will adjust this setting as well.
Ringer Type (Menu 15): Choose from ten possible ringer sounds.
NOTE: Calls will automatically g en er ate a distinc tive ringi n g soun d wh en you are outsi d e
your regular service area, as noted on page 8.
Key Sound (Menu 16): Select either beep tones or click sounds. Beep Length (Menu 17): Set key beep tone length (how l ong th e beeps will be played over the
air from a single key press). The “long” setting may be ne cessa ry for older answering machines or automated systems that require long key press tones.
Message Beep (Menu 18): The beep signaling an incoming message can be deactivated if
desired, or an additiona l reminder beep can be added.

Timers (Menu 2)

These features include items that keep track of your air time and make the m ost of your battery life.
All Calls (Menu 21): Displays length of all calls d urin g the lifetime o f the han dset in min utes
and seconds and the number of calls made. This infor mation is not resettable.
Recent Calls (Menu 22): Displays length of all calls in minutes and seconds and number of
calls. This information is resettable.
Minute Alert (Menu 23): Produces an audible alert 10 seconds before the end of each minute
during a ca ll.
Auto-Off (Menu 24): Enables you to set the phone to turn off automatically after a specified
time. Time rem aining bef ore sh utoff is sh own on the display. Pressing any key will restart the countdown. When the phone is turned off, the auto-off feature is disabled until activated again.
Bill Timer (Menu 25): If enabled by your service provider, this feature provides addi tional
timer information accordin g to their billing methods. It is usually used only on phon es that are being rented.
[22]

Directory (Menu 3)

This allows access into the phone number storage capabiliti es including the phone book, recent calls list, and your phone’s own number.
My Number (Menu 31): Displays the phone’s telephone number (page 7). Save (Menu 32): Saves memory locations (page 12). Erase (Menu 33): Erases memory locations (page 14). Edit (Menu 34): Edits memory locations (page 14). Find Name (Menu 35): Finds stored numbers by entering letters of the name (page 13). Phone Book (Menu 36): Finds either one specific memory or an entire list of phone book
entries (page 13).
Calls List (Menu 37): Accesses the last ten calls made, received, missed, or added and to see
the duration and time/date of a call (page 18).

Extras (Menu 4)

This allows you to access various extra features.
Key Guard (Menu 41): Allows you to lock the ke ypad so you won’t accidentally press the keys
(page 7).
Touch Dial (Menu 42): Allows you to dial memory location s by just pressing an d holdin g di git
keys (page 15).
Auto-Retry (Menu 43): Set length of tim e that th e phon e w aits befor e autom atically r edi aling
a number when a call attempt has failed. Busy-line tones through the earpiece speaker (that is, if the call encounters the called party’s busy signal) are not considered call failures.
Auto-Answer* (Menu 44): Sets the phone to automatically answer incoming calls. This works
only if you’re using the hands-free car kit accessory.
Any-Key Answer* (Menu 45): Allows you to answer the phone using any key except . Scratch Pad (Menu 46): Allows you to enter a ph one n umber and s ave it to the tempor ary calls
list.
[23]

Security (Menu 5)

Y ou must en ter the four-di git lock code to see an y items in this menu. Th e typical d efault code is the last four digits of your phone number (see page 5).
Lock Phone (Menu 51): Locks phone from use. When it is locked, you can only make
emergency ca lls.
New Code (Menu 52): Allows you to enter a new four-dig it lock code, replacing the old code. Restrict # (Menu 53): Allows you to restrict (o r unrestrict) a phone book memory so that the
number can’t be displayed, searched for, dialed, erased, or edited without entering the four-digit lock code.
Limit Calls* (Menu 54): Restricts (or unrestricts) outgoing calls to those numbers stor ed in
the phone book and to designated emergency numbers. Also, when this feature is activated, you cannot save, edit, or erase phone book entries.
Master Reset (Menu 55): Resets the phone’s settings back to the factory defaults except the
phone book memories and calls list.
Erase Book (Menu 56): Clears all phone book memories. Erase Calls (Menu 57): Clears all calls list entrie s. Emergenc y # (Menu 58): Lets you enter three numbers that can be entered and dialed even
when the phone is locked (page 9).

Display (Menu 6)

This allows you to choose what you see on the display.
Banner (Menu 61): Lets you enter and edit a banner that appears in line 1 of the display
during standby. You might want to put your name here.
Backlight (Menu 62): Lets you to choose the length of time the display and keypad
backlightin g stays on after any k eypr e ss is made .
Auto-Hyphen (Menu 63): If set to on, the phone will automatically add h y phens as you enter
numbers according to the North Ameri c an Numbering Plan. For example, “619-123-4567.”
Sort Book (Menu 64): Determines order of phone book memory entries. The “BY LOC #”
setting will sort numbers sequentially (by their phone book location number) and the “alphabetic” settin g will sort th e en tries alphabetically.
Language (Menu 65): Lets you to select English, Frenc h, Portuguese, or Spanish text.
[24]
Menu Length (Menu 66): Selects long or short feature menu. The short menu includes only a
few often-used items while the lon g men u inclu des all of th e man y features o f the ph one . See pages 20 and 21 for menu tr ee layouts.

Network (Menu 7)

This allows you to set some service provider n etwork settings.
Roam Alert (Menu 71): Sounds an audible alert when roaming conditions occur. Drop Alert (Menu 72): Displays text and sounds an audible alert when a call is d ropped d ue to
a signal fade.
Privacy Alert (Menu 73): Sounds an audible alert whenever the enhanced voice privacy
availability changes after call setup.
Auto-N.A.M. (Menu 74): Allows the phone to autom ati c ally swi tch on one of the pr ogrammed
NAMs (Number Assignment Module—which is basically another way to say “phon e number”), if necessary.
Set N.A.M. (Menu 75): Allows you to set two different NAMs (Number A ssignment
Module—which is basically another way to say “phone number”).
Set System*/Set Service** (Menu 76): This feature is set in accordance with the cellular or PCS
company system your phone uses. Leave this setting as “AUTOMATIC” unless you want to alter the system selection as described in the Basi c Functions section.
Force Call* (Menu 77 for the QCP-820 phone): forces the phone in to an alog mode for the
next c all or the next ten minutes.
Data/Fax In (Menu 77 for the QCP-1920 and QCP-2700 phones; Menu 78 for th e QCP-820 phone): Sets the
phone in a m ode capable o f r eceiving in coming data calls or f ax calls . (I t is not n ecess ary for outgoing data/fax calls.) Normal incoming voice calls cannot be received when this feature is activated.
[25]

PAGING, MESSAGING, AND VOICE MAIL

This feature lets you receive mess ages wh en your phon e is turned on. A single k ey, , allows you to access your messages while a four-line display permits easy viewing. While reading a message, you can return a call to the callback number provided in the message simply by pressing .
Messages ar e stored in the phone’s memory. Older, previously viewed messages ar e de leted when space is required, unless you “lock” a message. The phone has the capability of storing at least twenty 30-character messages. However, the number of messages decreases if messages contain more than 30 characters.
NOTE: Check with your service provider regar ding the availability of this feature . Th e information
contained in a mess age , su ch as time stamp and callback number, depends on the mod e in which the phone is operating and the service provider’s network capabilities.
This phone supports four types of messages:

1. MESSAGE: Typically contains text.

2. PAGE: Typically contains digits.

3. VOICE MAIL NOTIFICATION:

4. NET ALERT: A message set up on the Internet has been received. See page 31.

NEW MESSAGE ALERT

The phone will notify you of a new message by a display on the screen, four short beeps (if enabled by the Message Beep setting, page 20), flashing backlight, and the icon at the top of the display. If a message is marked URGENT, this icon will flash. Plus, the first line of the display will contain asterisks (*) on each side of the label, as shown below.
Typically indicates the number of new voice mail messages in your voice mailbox. You must call your voice mail number to listen to these messages. Follow your service provider’s directions for retrieving voice mail messages. (Your service provider administers voice mail services.)
Only one step is needed to acknowledge the new message.
➤ Press to access the “MESSAGES” menu, or press any other key to return to the display
that was present before the alert. The backlight will flash and (if enabled) a reminder beep will occur every three minutes until the new message is acknowledged.
[26]

VIEWING PAGES AND MESSAGES

These messages may consist of a time stamp, a callback number, a name (only if the callback number matches on e o f your stor ed ph on e book numbers ), and te xt. You can view both new and old text messages.

Reading text messages and pages

1. Press . The display will show the number of voice, new text, and old text messages.
2. Scroll and select the “NEW TEXT” line. You will see the messages in the order they were received except for any urgent messages, which will be displayed first. You can also select “OLD TEXT” to see the old messages in the order that they were read.
Messag es will autom a tically scroll page by page. To manually scroll through the message line by line, rotate the dial-shuttle. To
manually scroll page by page, press the dial-shuttle in. The end of the message is signified by a solid line and the “OPTIONS” text. Select “OPTIONS” or follow the next step. (The available options are listed on the next page of this guide under the “MESSA G E OPT IONS” section.)
3. Press to place a call to the callback number.
NOTE: When th ere are no new messag es, the p hone will indica t e t his. When viewing a ca l lb ack
number, you can save it in your phone book memory by selecting “OPTIONS” then “SAVE.” However, the number is already saved in your phone book if a name is displayed above the callback number.

VIEWING VOICE MAIL NOTIFICATIONS

Voi ce m a il n otification s tell you h ow many new voice m ail messages are in your mailbox. Only the most recent voice mail notification will be stored in the phone; previous messages will be overwritten. The messages themselves are not stored on your phone. You must call your voice mail service to retrieve them.

Viewing voice mail notifications

1. Press .
2. Select the “NEW VOICE” line.
The voice mail n otification m essag e will automatically scr oll page by pag e. To manually scroll through the notification line by line, rotate the dial-shuttle. To manual scroll page by page, press the dial-shuttle in. At the end of the notification, select “OPTIONS” (as described below) or follow the next step.
3. Press to place a call to the callback number, if included, to retri e ve your messages.
[27]

MESSAGE OPTIONS

At the end of any message, you can choose “OPTIONS.” There are separate options for text messages an d voice mail n otification s. Y ou can select on e of the followin g option s for both types of messages:
•“ERASE M S G ” to delete the message from memory
•“SEND” to make a call to the callback number if it has been included with the message
•“SAVE NUMBER” to store the number in your phon e book. You can select one of the
following options for text messages only.
•“NEXT MSG” t o view the next message in the stack
•“LOCK MSG” to keep the message from being automatically deleted when space is
required
NOTE: Lock only the important messages or memory may become limited, as discussed below.

LOW MEMORY WARNING

The phone will alert you by beeping and with a text display when the amount of available messag e memory is less than 25%. Although th e phone can still receive new messages, this is a warning that you should erase messages you no longer need to avoid running out of memory.

OUT OF MEMORY WA RNING

When the phone has no more available message memory, it cannot accept new messages. When this occurs, the phone will display an “OUT OF MEMORY” m e ssage. At this point you must immediately delete unneeded messages if you wish to receive new messages. The network may not be able to keep them for very long.
[28]

INTERNET BROWSER

Y ou can use your phone to browse the Intern et if you subscribe to phone Internet services, and over-the-air Internet access for your ph on e m od el is available in your area. Con tact your servi ce provid er for details . Th e micr obr owser in your p hon e can access In ternet-based inf ormati on su ch as:
• Stock quotes
• Weather
• News headlines
• White pages
• Travel
• Entertainment
You may also have access to personal information such as e-mail, your calendar, or a personal address book. Your service provider determines the type of applications you can use, and will notify you when new applications become available .
These applications are designed to work seamlessly on your phone. They provide information quickly and conveniently right on the phone display. Please keep in mind, however, that while the number of accessible sites on the World Wide Web continues to grow, not all sites are properly formatted for your phone.

STARTING THE BROWSER

1. Make sure your phone is turned on, th en pr ess . The MESSAGES screen appears.

2. Use the dial-shuttle to scroll and select “Launch Net.” The phone automatically connects to the Internet. After a brief introductory screen, the phone displays your phone browser home page. Your service provider determines what appears on this home page, but may permit you to edit it from your Web page on a computer. The following illustration shows a typical home page.
[29]
More

STARTING A BROWSER APPLICATION

1. From the home page, use the dial-shuttle to scroll through the list of available applications.

2. When the arrow cursor points to the application you want, press the dial-shuttle.

RETURNING TO YOUR HOME PAGE

You can return to the home page at any time.
• Press to go directly to the home page or press to back up one step for each
keypress.
NOTE: When entering data, press to erase the last character. When you backsp ace in this way to the beginning of the line, pressing again backs you out of the screen. Alternatively , pr ess and to move the text cursor and press to return to the preceding level.

EXITING THE BROWSER

• When you are on the home page, press to exit the browser and return to standby
mode.
or
At any time, press and hold for about 2 seconds to exit th e browser and return to standby mode.

NAVIGATING THE PHONE BROWSER

Getting around in the ph one browser is easy. If you are already familiar with both the W orld Wid e Web and your Kyocera Wireless Corp. phone, it will be even easier.
One or two context-sensitive menu choices appear at the bottom of the phone’s scr een. One quick press of the dial-shuttle selects the option in the lower left corner. When applicable, a longer press of the dial-shuttle selects the option in the lower right. A second tone indicates that the right-most menu choice has been successfully selected. Use the phone’s digit keys to select menu items or to enter numbers, letters , and punctu ation. M ake en tries th e sam e way you do in the phone book (see pages 12 and 16).

Status indicators

WA ITING The browser is searching for In ternet service in respon se to a command you have
entered.
RECEIVING The browser is downloadin g data from the In ternet onto your phone. The phone
is on a call while it is receiving, and your service provider will bill you for the call. The call re mains active for a few seconds after the information is received.
[30]
Once it is received you can look at that page for any length of time without incurring additional phone charges. However, as soon as you follow a link or press the dial-shuttle to submit an entry, the phone establishes a new call.
SENDING When you enter data on a screen and press the dial-shuttle to accept it, the
phone sends, or “uploads,” the data to the application.

Icons

Padlock. Indicates that the current Web page is secure. This means it is safe to enter
confid e ntial data, such as a credit card number. This data encryption is much more secure than using your cordless phone at home.
On call. Indicates that you are on a call and may be incurring phone charges. The phone browser is designed to minimize billable time. Your service provider can tell you exactly how you are billed for In ternet calls.
Scroll up. Indicates that you can scroll through menu items using the dial-shuttle. Scroll down. Indicates that you can scroll through menu items using the dial-shuttle.

INTERNET ALERTS

Some browser applications allow you to set up the Internet to send you a “net alert” when an important action has occurred. For example, you may want to know when you’ve received new e-mail or when you’ve sold shares of stock. Th e ph one will beep, and and “NET ALE R T” appear on the screen when one o f th ese alerts is received (similar to receiving page s , m ess ages , or voice mail notifications).
To access more detail on the net alert:

1. Press and scroll down to NET ALERTS.

2. Select “NET ALERTS.” Newly received net alerts are marked by an asterisk (*).

NOTE: If you select one of the items on the net alerts list, the browser will be launched and more information will be accessed from the Internet server.
T o erase net alerts:

1. Move within the Net Alerts folder as instructed above and select “Erase...”.

2. Scroll and select the alert you wish to erase.

[31]

DA TA

Some service providers allow you to use your phone to make d ata calls (f or example, e-mail and Internet access) or to send and receive faxes. To do this you must connect the phone to a computer or other computing device using the Data/Fax Cable or the Data On the Go® Fax/Modem PC Card (available separately; see the Accessories chapter of this guide).
NOTE: Your phone cannot receive voice calls when the Data feature is activated.

SETTING UP A DATA CONNECTION

Data Connectivity Kit

To set up a connection using the Data Connectivity Kit:
1. Install the product software that sets up your phone as a wireless modem.
2. Plug the flat connector on one end of the Data Cable into the port on the bottom of the phone.
3. Plug the serial connector at the other end of the Data Cable into the serial port on your computer.
4. Open a communications software package on your computer to access data.

Data On the Go Fax/Modem PC Card

To set up a connection using Data On the Go PC card:
1. Install the Data on the Go Fax/Modem PC Card.
2. Read the Quick Start card for installation instructions.
3. Plug the flat connector on one end of the Data On the Go Fax/Modem PC Card data cable into the port on the bottom of the phone.
4. Plug the other end of the data cable into the PC card slot.
5. Open a communications software package on your computer to access data.

SETTING UP OUTGOING DATA CALLS

With the data connection made, just originate a call through the PC’s communi cation software. Do not enter the number you are dialing on the phone keypad, and do not press the Send key.
[32]

SETTING UP INCOMING DATA CALLS

Due to infrastructure limitations, there may be times when your phone cannot determine if an incoming CDMA call contains voice or data information. Check with your service provider to see if they support both voice and data signals . If th e n e twork does not know how to distinguish between voice and data calls, and you are expecting a data call, you can set the phone to data mode as discussed below. Incoming voice calls are not possible when you are in this mode.

1. From standby mode, select “Features.”

2. Scroll and select “Network.”

3. Scroll and select “Data/Fax In.” The default setting is OFF.

4. Scroll in either directi on and select fr om the list o f da ta/fax ch oices . T o m ake a settin g for just the next call or the next 10 minutes, select either:
• fax call
or
• data call To make a setting that will persist until it is changed or un til the phone is turned off
and on again, select either:
• fax only
or
• data only
Again, please remem ber that no voice calls can be received if “Data/Fax In ” is set to anything other than OFF.

IN-CALL STATUS

During a data or fax call, the screen on your phone will show:
• A time counter for the call
• The data call type
• The data rate
• Whether the phone is transmi tti ng or receiving
[33]

ACCESSORIES

ORDERING ACCESSORIES

To order accessories, contact your service provider or visit the Kyocera Wireless Corp. website at http://www.kyocera-wireless.com/store/ or order by phone at 800-211-1537 (510-683-4004).
You can purchase a number of accessories for your phone, including the following:
• batteries
• desktop chargers
• portable chargers
• car-lighter adapters
• hands-free car kits
• leather carrying cases
• data connectivity cables and software
[34]

PHONE SAFETY AND CARE

The hand-held portable telephone is on e of the m ost exci ting and inn ovative electronic pr oducts ever developed. It lets you stay in touch wherever you go.

BACKGROUND

Y our telephone is a low-power radio tran smitter and receiver. When it’s on, it receives and also sends out radio frequency (RF) si gnals. When you use your phone , the system handlin g your call controls the power level at which your phone transmits.

Exposure to radio frequency signals

In August 1996, the Federal Communic ations Commission (FCC) adopted RF exposure guidelines with safety levels for hand-h eld wir eless phon es . Those gui de lines ar e con sistent with th e s afety standards previously set by both U.S. and international standards bodies:
• American National Standards Institute (ANSI) C95.1 1992
• National Council on Radiation Protection and Measurements (NCRP) Report ‘86 1986
• International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1996
Those standar ds wer e based on compr ehe nsive an d periodi c evalu ation s of th e r elevant sci en tific literature. For example, 120 scientists, engineers, and physicians from universities, gov ernment health agencies, and industry reviewed the available body of research to develop the ANSI standard (C95.1). The design of your phone complies with the FCC guidelines (and those standards).

FOR BEST PERFORMANCE

To properly operate the phone and maintain safe and satisfactory service, follow these rules.
• Extend the antenna fully.
• Hold the phone with the antenna extended and over your shoulder.
• Do not hold th e phon e an tenna at an y tim e . Contact with th e antenn a affects call quality
and may cause the phone to operate at a higher power level than otherwise needed.
• Do not use the phone if the antenna is damaged.
• Speak directly into the mouthpiec e.
• Use the phone when the car is stopped.
Avoid exposin g the ph one and accessori es to rain or liquid spills. If th e phone becom es wet, turn the power off immediately an d remove the battery pack. If the ph one becomes in operable , return it to the dealer for service.
[35]
Only authorized personnel should install or service the phone and its accessories. Faulty installation or service ma y be dangerous and may invalidate the warranty.

ANTENNA CARE

Use only the supplied or an approved replacement antenna. Unauthorized antennas, modifications, or attachments could damage the phone and may violate FCC regulations.

CARING FOR THE BATT ERY

For best battery performance, follow these guidelin es.
• Use only Kyocera Wireless Corp.-approved battery packs and Kyocera Wireless Corp.
chargers.
• Do not charge the battery pack in temperatures outside of 32°F to 122°F (0°C to 50°C)
because damage could occur.
• Do not use the battery charger in direct sunlight or in places with high humidity su ch as
the bathroom.
• Never dispose of the battery pack by a fire.
• Keep the metal contacts on the battery pack clean.
• Do not attempt to disassemble or short circuit the battery pack.
• You may need to recharge the battery if it has not been used for a long time.
• Replace the battery when it no l ong er provi des acceptable perf orm an ce . Th e battery pack
may be recharged hundreds of times before it will need to be replaced.
• Do not store the battery pack for long periods in places where high temperatures
frequently occur. Follow these storage rules:
LESS THAN 1 MONTH: -4°F to 140°F
(-20°C to 60°C)
MORE THAN 1 MONTH: -4 °F to 113°F
(-20°C to 45°C)
• Li-ion batteries do no t have a “memory” effect.

DRIVING SAFETY

Talking on the phone while driving is extremely dangerous, and in some states in the U.S. and some countries it is illegal. Remember, safety comes first.
[36]
Check the laws and regulations on the use of phones in the areas where you drive. Always obey them.
Also, if using your phone while d riving please:
• Give full attention to driving. Driving safely is your first responsibi lity.
• Use hands-free operation, if available.
• Pull off the r oad and park befor e m aking or an swerin g a call, if dri ving con diti ons r equir e .
• If you must use the phone while driving, please use one-touch, speed dialing, and
auto-answer modes.
An airbag inflates with great forc e. DO NOT place objects, including both installed or portable wireless equipment, in the area over the airbag or in the air bag deployment area. If in-vehicle wireless equipment is improperly installed and the air bag inflates, serious injury could result.
WARNING: Failure to follow these instructions may lead to serious personal injury and possible
property damage.

ELECTRONIC DEVICES

Most modern electronic equipment is shielded from RF energy. However, certain electronic equipment may not be shielded against the RF signals from your wireless phone.

Pacemakers

The Health Ind ustry Man uf acturers A ssoci ation (U S A) recomm ends that a minim um separati on o f six inche s (6”) be maintained between a hand-held wireless phone and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research by and recommendations of Wireless Technology Research.
If you have a pacemaker:
• ALWAYS keep the phone more than six inches from your pacemaker when the phone is
turned on.
• Do not carry the phone in a breast pocket.
• Use the ear opposite the pacemaker to minimize the poten tial for interference.
• If you have any reason to suspect that interference is taking place, turn your phone off
immediately.

Hearing aids

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider (or call the customer service line to discuss alternatives).
[37]

Other medical devices

If you use any other personal medical device, consult the manufacturer of your de vice to determine if it is ad equately shi elded fr om RF ener gy. Your ph ysici an may be able to assist you in obtaining this information.
Turn your phone off in health care facilities when an y regulations posted in th ese areas instruct you to do so. Hospitals or healthcare fac ilities may be using equipment that could be sensitive to RF energy.

Vehicles

RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles. Check with th e manufacturer or its r epresentative regarding your vehicle. You should also consult the manufacturer of any equipment that has been added to your vehicle.

Posted facilities

Turn your phone off in any facility where posted notices so require.

OTHER SAFETY GUIDELINES

Aircraft

FCC regulations pr ohibi t usin g your ph one while in the air. Switch off your phone before boardi n g an aircraft.

Blasting areas

To avoi d interferin g with blasting oper ation s, turn your ph one o ff when in a “blastin g area” or in areas posted: “Turn off two-way radio.” Obey all signs and instructions.

Potentially explosive atmospheres

Turn your phon e o ff when in any ar ea with a potenti ally explosive atmosph er e and obey all si gns and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.
Areas with a potentially explosive atmosphere are often, but not always, clearly marked. They include fueling areas such as gas stations; below deck on boats; fuel or chemi cal transfer or storage facilities; vehicles using liquefied petroleum gas (suc h as propane or butane); areas where the air contains chemicals or particles, such as grain, dust, or metal powders; and any other area where you would normally be advised to turn off your vehicle engine.
[38]
[39]

WHERE TO FIND HELP

There are several ways for you to get help with your Kyocera Wireless Corp. phone.

YOUR SERVICE PROVIDER

For questions about your phone and phone service, contact your service provider first. Your service provider’s custom er support department can answer questi ons about your phone, phone bill, call coverage area, and specific features (s uch as call forwar ding or voice mail ) available to you.

YOUR PHONE DOCUMENTATION

If you have questions about the features of the phone, refer to this guide and other materials provided with your phone. To view or download the most current version of this user’s guide, visit us at www.kyocera-wireless.com.

KYOCERA TECHNICAL SUPPORT

If you have additional questions, contact the Kyocera Wireless Customer Care Center in any of these ways:
• Website: www.kyocera-wireless.com/store
• U.S.and Canad a: 1 (800) 349-4478
• Other Countries: 1 (858) 882-1400
• Email: phone-help@kyocera-wireless.com
Before requesting support, please try to reproduce and isolate the problem. When you contact support, be ready to provide the following information:
• The name of your service provider
• The actual error message or problem you are ex periencing
• The steps you take to reproduce the problem
• The Electronic Serial N umber (ESN) of the ph one . You will find the ESN on the back of the
phone by removing the battery.
[40]
INDEX
A
AC adapter 4–5 accessories 1 aircraft 38 analog mode 10 answering a call 8, 23 antenna 3, 5 any-key ans wer 1, 23 auto-hyphen 24 automatic power off 22 automatic redial 1, 8, 23 automatic scroll 27 auto-N.A.M. 20, 25
B
backlight 24 banner 5, 24 battery
36
care charge level 4 charging 4–5
installing 4 best battery performance 36 best performance 5, 35 browser 29–31
C
call history 8, 18–19
erasing 24 call waiting 2, 8 calls
credit card
dialing 7, 8, 15
emergency 9
incoming 8
receiving 8, 18
redialing 8
three-way 8 car kit 5 CDMA 1 cigarette lighter adapter 4–5 clear digits 7 clear key 2 code division multiple access 1 correcting dialing mistakes 7
16
D
data calls 25 data connectivity kit 32 Data on the Go 32 desktop charger 4
dialing calls 7, 8, 15 dialing from memory location 15 dial-shuttle 2 digital mode 3, 10 directory 23 display indicators 3, 4, 9 driving safety 36
E
editing
numbers editing numbers 7 e-mail 29, 31, 32 emergency numbers 9, 24 end key 2, 5 entering
a number
lock code 17, 24
name 12
punctuation 16 erase numbers or characters 2 erasing
calls list
phone book 24 explosive atmospheres 38 extra features 23
14, 23
7, 8–9, 12
24
F
fax calls 25, 32 FCC 35–36, 38 features 1–2, 7, 16–17 features menu 6, 20–25 finding
my number
phone numbers 13, 23 frequency 35 function keys 2
7, 23
I
incoming calls 8, 18 Internet 29–31
K
key beep
tone length keybeep
sound
volume 22 keyguard 3, 23
keypad lock 7
22
22
L
language 9, 24
[41]
linking 16 lock code 5, 24 locking
keypad
7, 23
memory locations 17
message 28 long menu 6, 20 low battery 4
M
making a call 7, 9, 15, 18 manual pauses 16 master reset 24 memory
clearing
14, 23
editing 23
locations 9, 12, 13–15, 23
low 28
memory locations 1
out of 28
retrieving 13
storage 23 menu
item descriptions
6, 20–25
message key 2 messages 26–28 minute alert 22 mute 22 my number 7, 23
O
on call 3, 31 one-touch dialing 15 own phone number 7, 23
P
paging 26–28 pause dialing 16 performance tips 5, 35–36 phone book
advanced features
dialing from 15
editing 14
retrieving from 13
saving numbers to 12 phone number
viewing your own pound key 2 power 2, 6
off 5
on 5
save mode 5, 6 privacy alert 25 punctuation entries 16
16
7, 23
R
radio frequency energy exposure 35, 37–38 recalling last number dialed 23 recalling memory locations 13 receive signal strength indicator 3, 9 receiving calls 8, 18 receiving messages 2, 3, 26–27 recent calls list 8, 18 redial 8 restricting numbers 17, 24 ringer 9
type 22
volume 21 roam alert 25 roaming 3, 8, 10, 11
S
safety 4, 35–38 saving numbers in phone book 12 scratch pad 23 scrolling 3, 31 searching 13 security 17, 24, 31 select 3 send key 2 set N.A.M. 25 setting servi ce 10 short menu 6, 21 signal strength 3, 9 sorting phone book 24 sounds 21 speed dial 1, 15 standby screen 2 standby status 5 standby time 4 star key 2 storing
names with numbers
12
numbers 12–16
T
talk time 4 three-way calling 2 timers 22 travel charger 4
V
voice mail 26–28 volume 9, 21–22
[42]
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
