F-2110

PARTS LIST

Published in Jan.’99

5AX70771
Revision 1

F-2110

NOTE

1. Indicate parts number and machine model when placing an order.
eg. Parts Number Parts Name Machine Model Cycle Quantity

5AX04010 FRONT COVER (STD) F-2110 60Hz 1

2. Service calls and freight will be charged separately.

3. See the last page of this parts list for the classification of the screws in the illustrations.

4. Items indicated by shaded areas ( ) are supply parts and should be ordered through your Regional Office.

CONTENTS

FIG.1 EXTERIOR COVERS · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 2
FIG.2 FRAMES · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 4
FIG.3 PAPER CONVEYING SECTION I· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 6
FIG.4 PAPER CONVEYING SECTION II · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 8
FIG.5 ELEVATE SECTION · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 10
FIG.6 ELECTRICAL COMPONENTS · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 12

• INDEX· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 14

– 1 –

FIG. 1 EXTERIOR COVERS

17

15

16

10

2

2

9

1

2

7

25

21

13

3

29

18

12

11

4

2

BBG

HBO

HBO

HBO

HBO

HBO

HBO

HBO

HBO

BBG

BBG

HBO

HBO

HBO

28

1

HBO

1

HBO

24

27

26

ABCDEFGHI J

5AX-1

1

2

3

4

5

6

7

A

BCDEFGHI J

– 2 –

1

2

3

4

5

6

7

FIG. 1 EXTERIOR COVERS

Ref.

Part. No. Description

No.

1 5AX07590 STRAP 2
2 5AX07850 STEP SCREW A 6
3 5AX07910 SPRING E 1
4 5AX08060 STOPPER 2

7 5AX08150 MAGNET CATCH 1

9 5AX04030 TOP COVER(STD) 1
10 5AX04020 REAR COVER(STD) 1
11 5AX04010 FRONT COVER(STD) 1
12 5AX04120 COVER,LID(STD) 2
13 5AX08480 LEVER B 1

15 5AX04050 LOWER RIGHT COVER(STD) 1
16 5AX04040 UPPER RIGHT COVER(STD) 1
17 5AX04110 LOWER TRAY(STD) 1
18 5AX04080 FRONT COVER,RELEASE(STD) 1

21 5AX82010 SET,STAPLER 1

24 75105070 CAUTION LABEL CSA 1

25 5AX08880 STAPLER ASS'Y 1
26 5AX08870 COVER STAPLE ASS'Y 1
27 •5AX08760 STAPLE FILM 2 1

•76405130 LABEL INSTALLA TION 1

28
29

•5AX08520 FILM,STAPLE 1

Quantity

USA

(120V)

Ref.

Part. No. Description

No.

5AX-1

Quantity

USA

(120V)

– 3 –

FIG. 2 FRAMES

ABCDEFGHI J

1

2

3

4

5

6

5AX-1

HBO

HBO

48

HBO

HBO
