EF-60
Envelope Feeder

PARTS LIST

First Edition, Published in January 2001

01-019

01-034

01-026

01-033

01-031

01-013

01-020

B02

01-019

01-014

01-018

01-036

B02

01-002

01-019

01-022

01-0211

01-009

01-030

B03

01-028

B02

01-032

01-025

01-033

01-008

01-029

01-A01

01-011

01-004

01-006

01-017

01-010

01-024

01-027

01-005

01-015

01-016

01-012

01-001

01-007

01-023

01-035

B01

01-037

01-038

01-003

01-037

EF-60 JAN-11-01 A-One

Ref.No. Part Code Description SP Used

SP:Spare Parts

01-A01 5AAYEF60++01 SEPARATOR EF ASSY 1 1
01-001 5MVB876SH061 BASE EF 1
01-002 5MVB866CH028 FRAME EF 1
01-003 5MVB872SH021 BOTTOM EF 1
01-004 5MVB762SH030 COVER EF L 1 1
01-005 5MVB765SH008 COVER EF R 1 1
01-006 5MVL776DH001 GUIDE L EF 1
01-007 5MVL776DH002 GUIDE R EF 1
01-008 5MVB662DH001 GUIDE PAPER EF 1 1
01-009 5MVB772SH010 COVER BOTTOM EF 1
01-010 5MVS768SH008 TRAY EF 1 1
01-012 5MVX433DN003 LEVER CAM EF 1
01-013 5MVT666SH001 SHAFT CAM EF 1
01-014 5MVX554DH001 BKT JOINT EF 1
01-015 5MVX633SH008 LOCK BOTTOM EF 1 1
01-016 5MVB443SH001 LEVER BOTTOM 1
01-017 5MVX651SH001 LEVER ACT EF 1 1
01-018 5MVX311SB010 ACTUATOR PICK EF 1 1
01-019 5AAVR0LL+055 ROLLER PICK EF ASSY 1 3
01-020 5AAVCLTCH027 CLUTCH EF ASSY 1 1
01-021 5MMT866SN038 SHAFT PICK EF 1
01-022 5MMX861SN001 SHAFT BOTTOM EF 1
01-023 5MMW681LD008 SPRING BOTTOM EF 2
01-024 5MMW251LD051 SP ACTUATOR EF 1
01-025 5MMW361LD025 SP SEPARATOR EF 1
01-026 5MMW251LD052 SP SHAFT CAM 1
01-027 5MMW161LD052 SP COVER BOTTOM 1
01-028 5AAVDAMPR005 DAMPER ASSY 1 1
01-030 5MVVL661WN35 LABLE LEVER BOTTOM 1
01-031 5MVVL721WN60 LABEL INSTRUCTION 1
01-032 5MVS731KC003 SHEET GUIDE 1
01-033 5MVM176DN016 BUSH A 1 2
01-034 5MVX111DN003 RING STOPPER 1
01-035 5MVG127DH002 GEAR GUIDE SIDE 1
01-036 5MVG138DN034 GEAR Z30 1 1
01-037 5MVM176DB005 COLLAR JOINT FD 1 2
01-038 5MVS417RF008 PAD FRICTION M/P 1 1
01-A01 5AAYEF60++01 SEPARATOR EF ASSY 1 1

EF-60 Envelope Feeder

P-001 5AAKEF60++01 PACKING ASSY 1 1

Revision 1.00. 1-Jan-01
