Kyocera 307CI User Manual

307ci

PRINT COPY SCAN FAX

OPERATION GUIDE

> Preface

Preface

Thank you for purchasing this machine.

This Operation Guide is intended to help you operate the machine correctly, perform routine maintenance, and take
simple troubleshooting measures as needed so that the machine can always be used in the optimum condition.

Please read this Operation Guide before using the machine.

To maintain quality, we recommend using genuine Kyocera toner containers, which must
pass numerous quality inspections.

The use of non-genuine toner containers may cause failure.

We will not be liable for any damages caused by the use of third party supplies in this machine.

A label is affixed to our genuine supplies, as shown below.

Checking the Equipment's Serial Number

The equipment's serial number is printed in the location shown in the figure.

You'll need the equipment's serial number when contacting your Service Representative. Please check the number
before contacting your Service Representative.
