WARNING
To avoid damage from the scooter's electronic
fuel injection system, do not remove or install a
battery wire when the ignition switch is at the
"ON" position.
Read this manual carefully.
This Owner’s Manual contains important information on safety, operation and maintenance of your
KYMCO People GT 125i/200i/300i scooter. Any one who operates your scooter should carefully
read and understand the contents of this manual before riding the scooter. For your safety, understand
and follow all of the warnings contained in this Owner’s Manual and the labels applied to your scooter.
This Owner’s Manual should be considered a permanent part of the vehicle, keep it with your scooter at
all times. ON-ROAD USE ONLY This scooter has been designed to be used on the road.
Particularly important information is called out in this manual by the following icons
and notations:
The SAFETY ALERT symbol with the exclamation point in the triangle
means ATTENTION! BE ALERT! YOUR SAFETY CAN BE AFFECTED.
Failure to follow instructions associated with a WARNING symbol could
WARNING
CAUTION
NOTE
result in severe injury or death to the rider, a passenger, a bystander, or a
person inspecting or repairing the scooter.
A CAUTION symbol indicates that special precautions must be taken to
avoid damaging the scooter.
The NOTE symbol indicates key information about a procedure or to clarify
an operation.
Identification Numbers Record
11 22 33
1. VEH ICLE IDENTIFICATION NUMBER ( VIN)
2. ENG INE SERIAL NUMBER (ESN)
3. FRA ME SERIAL NUMBER
Record the Vehicle Identification Number , Engine Serial Number and Frame Serial Number in
the boxes above for future reference (to assist you in ordering parts from your authorized KYMCO
dealer or for reference in case the vehicle is stolen).
11
22
33
TABLE OF CONTENTS
SECTION 1 - SAFETY ............................. 1 - 8
1
SECTION 4 - MAINTENANCE.............25- 45
4
Forward .........................................................1
Scooter Safety.............................................2 - 3
Accessories & Modifications.............................4
Locations of Parts & Controls.........................5 - 8
SECTION 2 - CONTROLS & FEATURES.9 - 20
2
Ignition Switch ................................................9
Security Shutter .............................................10
Instruments ............................................11 - 13
Digital Clock..................................................14
Right-hand Handlebar Switch..........................15
Left-hand Handlebar Switch......................16 - 17
Fuel Recommendation...................................18
Seat..............................................................19
He l me t Ho l de r.. . .. . .. . .. . .. . .. . ... . .. . .. . .. . .. . .. . ..1 9
Suspension...................................................20
SECTION 3 - OPERATION......................21 - 25
3
Pre-ride Inspection........................................21
Starting the Engine....................................22 - 23
Maintenance Schedule..........................26 - 28
Engine Oil.................................................29
Engine Oil Replacement........................30 - 31
Transmission Fluid Change........................32
Air Filter Element Change...........................33
Throttle Operation.....................................33
Spark Plug................................................34
Coolant Level Inspection............................35
Coolant Replacement.................................36
Side Stand................................................37
Brake Fluid Level Inspection.......................38
Brake Pad Inspection..................................39
Battery & Fuse..........................................40
Tires........................... ..............................41
EMISSION CONTROL .......................43
5
6
S P E C I F I C AT I O N S . . . . . . . . . . . . . . . . . . . . . 4 5
SECTION 1 -
FORWARD & SAFETY INTRODUCTION
Thank you for purchasing this KYMCO People GT 125i/200i/300i scooter, and welcome to the KYMCO
riding family.
Please read this owner's manual carefully before riding so that you will be thoroughly familiar with the
proper operation of your scooter controls, its features, capabilities, and limitations.
To ensure a long, trouble-free life for your scooter, provide it with the proper care and maintenance as
described in this manual.
For replacement parts and accessories, you should always use genuine KYMCO products, as they have
been specially designed for your vehicle and manufactured to meet KYMCO's demanding standards.
Keep this owner's manual aboard your scooter at all times so that you can refer to it whenever you need
information. This manual should be considered a permanent part of the scooter and should remain with
the scooter when it is sold.
All information, illustrations, photographs and specifications contained in this manual are based on the
latest product information available at the time of publication. Due to improvements or other changes,
there may be information in this manual that differs slightly from your vehicle. KYMCO reserves the right
to make product and publication changes at any time without notice and without incurring any obligation.
1
1
SCOOTER SAFETY
IMPO RTANT SAFETY I NFORMATION
Your scooter can provide you many years of
service and pleasure if you take responsibility for
your own safety and understand the challenges
that you can meet on the road. There is much that
you can do to protect yourself when you ride. You
will find many helpful recommend ations
1
throughout this manual. Here are some very
important safety tips:
Wear a helmet
Scooter safety equipment starts with a quality
helmet. One of the most serious injuries you can
suffer in a crash is a head injury. Always wear a
properly approved helmet. You should also wear
suitable eye protection.
Make your self easy to see
To make yourself more visible, wear bright
reflective clothing, position yourself so other
drivers can see you, signal before turning or
changing lanes, and use your horn when it will help
others notice you.
Know your lim its
Ride within the boundaries of your own skill at all
times. Knowing these limits and staying within
them will help you to avoid accidents.
2
Keep your s cooter in safe condition
For safe riding, it's important to inspect your
scooter before every ride and perform all
recommended maintenance. Never exceed load
limits, and only use accessories that have been
approved by KYMCO for this scooter.
Insp ect your sco oter befor e riding
Do not forget to perform an entire safety inspection
to ensure you, and your passenger's safety, before
each ride.
Be extra safety conscious on bad
weather days
Riding on bad weather days, especially wet ones,
requires extra caution. Braking distance can
double on a rainy day. Stay off of the painted
surfaces, manhole covers and greasy appearing
areas on the pavement, as they can be especially
slippery. Use extreme caution at railway crossings
and on metal gratings and bridges. Whenever your
are in doubt about the road conditions, slow down.
Modi fication
Modification of your scooter, or removal of original
equipment may render the vehicle unsafe or illegal.
Obey all applicable equipment regulations in your
area.
SCOOTER SAFETY
PROTECTIVE APPAREL
For your safety, always wear an approved motorcycle
or scooter helmet, eye protection, boots, gloves, long
pants, and a long- sleeved shirt or jacket whenever you
ride your scooter.
Helm ets and protectio n
Your helmet is your most important piece of riding gear
because it offers the best protection against head
injuries. Your helmet should fit your head comfortably
and securely. Always wear a face shield or goggles to
protect your eyes and to aid your vision.
1
3
2 4
1
Additional riding ge ar
In addition to a helmet and eye protection, you should
also use:
Sturdy boots with nonslip soles to help protect your
feet and ankles.
Leather gloves to keep your hands warm and help
prevent blisters, cuts, burns and bruises.
A motorcycle or scooter riding suit or jacket that has
been designed for comfort as well as protection.
Bright colored and reflective clothing can help make
you more noticeable in traffic. Be sure to avoid loose
clothes that could get caught on any part of your
scooter.
WARNING
Not wearing a helmet increase your
chance of serious injury or death in a
crash.
5
1
Wear gloves
2
Clothes should be fit properly (not too tight or
loose)
3
Always wear a helmet. You should also wear
eye protection
4
Wear bright or reflective clothing
5
Footwear should be the proper size, have low
heels, and offer ankle protection
WARNING
Be sure you and your passenger always
wear an approved motorcycle helmet
that fits properly. You should also wear
eye protection and other protective
apparel when you ride.
3
1
ACCESSORIES & MODIFICATION
There is a large variety of accessories available to KYMCO scooter owners. KYMCO cannot have
direct control over the quality or suitability of accessories you may wish to purchase. The addition of
unsuitable accessories to your scooter can lead to unsafe operating conditions. It is not possible
for KYMCO to test each accessory on the market or combinations of all the available accessories;
1
however, your KYMCO dealer can assist you in selecting quality accessories and then install them
correctly.
Use extreme cau tion when sele cting and in stalling the accessor ies for your
scooter.
No modificat ions
KYMCO strongly advises you against removing any original equipment or modifying your scooter in
any way that would change its design or operation.
WARNING
Improper accessories or modifications can make your scooter unsafe and can lead to an accident.
Never modify your scooter through the improper installation or use of accessories. All parts and
accessories added to this vehicle should be genuine KYMCO or equivalent components designed
for use on this scooter and should be installed and used according to instruction. If you have any
questions, consult an authorized KYMCO dealer.
4
LOCATION OF PARTS & CONTROLS
Rear Brake Lever
11
Headlamp
22
33
Left Turn Signal Lamp
Side Stand
44
55
22
11
33
77
1
Seat
55
Air Filter
66
77
Taillamp, Stoplamp
44
NOTE: Your scooter may differ slightly in appearance from the images in this manual.
66
5
1
LOCATION OF PARTS & CONTROLS
Coolant Reservoir
88
Muffler
99
Oil Filler Cap/dipstick
1010
1111
Fuel Filler Cap
Rear Passenger Foot Peg
1212
1313
Right Turn Signal LED
1111
88
1313
99
1010
1212
NOTE: Your scooter may differ slightly in appearance from the images in this manual.
6
LOCATION OF PARTS & CONTROLS
1515
1414
Front Turn Signal Lamp
1414
Headlamp( Low Bean Lamp)
1515
1616
Front Brake Lever
1616
NOTE: Your scooter may differ slightly in appearance from the images in this manual.
1
7
1
LOCATION OF PARTS & CONTROLS
Rear Turn Signal LED
1717
Engine Stop Switch
1818
Ignition Switch
1919
Battery and fuses
2020
Taillamp, Stoplamp
2121
Cell Phone Socket
2222
2121
1717
2222
1818
1919
2020
8
SECTION 2 -
CONTROLS&FEATURES
IGNI TION SWITCH
To operate the ignition switch and it's functions:
“ ” Position:
All electrical circuits are off. The engine will not
start or run.
“ ” Position:
The ignition circuit is "ON" and engine can now be
started. The key can not be removed from the
ignition switch in this position.
“ ” Position:
To lock the steering, turn the handlebar all the way
to the left, push down and turn the key to the " "
position and remove the key. All electrical circuits
are off.
2
9
CONTROLS & FEATURES
SECU RITY SHUTTER
To open the ignition switch security
shut ter :
Push the shut-button on the ignition switch cover
and then the shutter should be closed.
2
To shut the ignition switch security
shut ter :
Insert the specific key until the fillister is
facing the pin.
Turn clockwise and then the security shutter
should be opened.
The keys have a unique code that is stamped on
the tab supplied with the keys. This code is not
stamped on the scooter and is not recorded in the
vehicle's basic documentation for security
reasons. Since this code is required if you need
replacement keys, record this important code in
the box provided on the inside of this Owner's
Manual.
10
CONTROLS & FEATURES
Inst r ument s
Odometer/Tripmeter: Press the "MODE" button
to toggle between the overall and trip mileage.
Press the “ADJ” button for two seconds, then
displays the ODO, TRIP(A,B) or SERVICE
mode.
Press the “ADJ” and “MODE” button
simultaneously at the TRIP mode, then the
figure reset automatically.
Speedometer: Indicates the road speed in K/PH
(kilometers per hour).
Turn Signal Indicator Light: Flashes when either
turn signal is being used.
High Beam Indicator Light:This light is
illuminated when the headlight high beam is on.
Fuel refill indicator “ “: This indicator lights
when the fuel tank is near empty to alert the rider
to refill the fuel tank as soon as possible.
2
Clock
Coolant temperature gauge
11
2
CONTROLS & FEATURES
CELP indicator: If flashing, it indicates that a
fault has been detected in the scooter’s EFI or
electrical system. Requires immediate
inspection by a KYMCO dealer.
NOTE : Th e C E LP i n dic a tor ligh t s
momentarily when the scooter is turned ON
before the engine is running.
Oil service indicator: Lights when the scooter
has reached the oil service interval mileage.
The indicator also lights when the ignition is
turned ON but should go out once the engine
is running.
Press the ADJ. button for two second, then
displays the ODO, TRIP or SERVICE mode.
Press the ADJ. and MODE button
simultaneously at the SERVICE mode, then
the indicator go out automatically.
OIL
SERVICE
12
1010
Battery voltage indicator:
If the battery voltage is too low while starting
the engine. The indicator can be lighting. The
engine fails to be restarted unless the battery
should be recharged completely.
1111
Oil pressure indicator: <People GT 300i>
This indicator lights when the oil pressure is
below the normal operating pressure. The
indicator will light when the ignition switch is
“ON” and the engine is not running. The
indicator should go out when the engine starts
(except for some occasional flickering at or
near idle when the engine is warm). If the
indicator fails to go out completely once the
engine is started, consult your KYMCO dealer
immediately.
CAUTION
Running the engine on your scooter with
insufficient oil pressure will cause serious engine
damage.
1111
1010
2
13
CONTROLS & FEATURES
2
Mult ifunction display - Digital clock
The clock indicates the time in hours and minutes
when the ignition is “ON”.
To ad just the cl ock’s ti me manually,
follow this p roced ure:
1.
Turn the ignition switch “ON”
Press and hold the ADJUST button for more
2.
than two seconds to select the ODO mode.
NOTE: The digital clock can be only adjusted
in ODO mode, don’t select the tripmeter or oil
service meter mode if you want to adjust the
time on the clock.
3.
Press and hold both the Mode button and Adjust
button at the same time for more than two seconds.
The “hour” digits will be begin flashing, indicating the
clock time can be adjusted.
4.
To set the hour display, press the ADJUST button
until it displays the correct “hour” time
5.
To change the minute display, press the MODE
button until the “minute” digits begin flashing
6.
To set the minute display, press the ADJUST
button until it displays the correct “minute” time
7.
To end the clock adjustment, press both the
MODE and ADJUST buttons at the same time.
The display will stop flashing automatically. The
adjustment will be saved the last setting figure
and back to the general display if any button is
not pressed within approximately ten seconds.
14
CONTROLS & FEATURES
Headlight switch " " position:
The headlight and taillight will be lit.
“ ” position:
The position light and taillight (running lamps) will
be lit.
“ ” position:
The headlight and taillight will be off.
Electric starter button " " position:
Press the electric starter button to activate the
starter motor.
2
Engine stop switch " " position:
The ignition circuit is off. The engine will not start or
run.
“ ” position:
The ignition circuit is on, and the engine can start
and run.
NOTE: The starter motor will not engage
unless a brake lever is squeezed at the same
time the starter button is pressed.
People GT 300i is also equipped with an
safety interlock that prevents the starter
motor from being engaged unless the sidestand is fully up.
15
CONTROLS & FEATURES
2
Turn signal switch :
Use the turn signal indicator to signal to other traffic
your intention to turn or change lanes. The turn
signal light on the dash will flash to alert the rider
that the switch is engaged.
" " for turning to the "left".
" " for turning to the "right".
To cancel the turn signal, press the switch in when
it is in the center position.
Horn button :
Press the horn button to sound the horn.
55
44
44
55
16
CONTROLS & FEATURES
Dimmer switch :
" " switch position turns the headlight low beam
on.
" " switch position turns the headlight high beam
on and the high beam indicator light on the dash is
activated as well.
Passing light button :
Use this button to rapidly flick the headlamp high
beam on and off to signal other vehicles that you
wish to pass.
66
77
66
77
2
17
2
CONTROLS & FEATURES
Fuel level inspection / Refilling
If the low fuel indicator on the dash begins to flash,
refill the fuel tank with nonleaded gasoline as soon
possible.
Fuel tank filler :
To add fuel to your scooter, follow this procedure:
Use the ignition key to unlock the seat.
1
Unlock the fuel filler cap counterclockwise.
2
Once unlocked , lift the cap from the fuel filler neck.
3
To install the fuel filler cap, clockwise to lock the
4
cap.
Fuel recommendation
Use nonleaded gasoline with a research octane
number of 91 or higher to prevent from spark plug
and exhaust component damaged.
After refueling, be sure to close the filler cap
securely.
18
CONTROLS & FEATURES
Seat
To unlock the seat
With the ignition key at the " " position (the
engine is running), push the key in and turn it
counterclockwise from " " to the position.
With the ignition key in the " " position (the
engine is not running), turn the counterclockwise
from the " " to the position.
Pull up on the back portion of the seat to lift it up.
" "
" "
3
2
Helmet holder
To use the helmet holders, open the seat and hook
your helmet's fastener ring to the holder and
close the seat securely.
88
WARNING
Use the helmet holder only when your scooter is
parked. Do not ride with a helmet hanging from
the holder.
88
88
19
2
CONTROLS & FEATURES
Suspension
Each shock absorber on your scooter has five
spring preload adjustment positions for different
load or riding conditions.
Use a pin spanner to adjust the rear shock spring
preload. Position 1 is for light loads and smooth
road conditions. Position 3 to 5 increase spring
preload for a stiffer rear suspension and can be
used when the scooter is heavily loaded.
Be certain to adjust both shock absorbers to the
same spring preload positions.
Standard spring preload position:
People GT 125i: 1st
People GT 300i: 2nd
CAUTION
20
Always adjust the shock absorber pre-load
position in sequence (1-2-3-4-5 or 5-4-3-2-1).
Attempting to adjust directly from 1 to 5 or 5 to 1
may damage the shock absorber.
SECTION 3 OPERATION
Pre-ride inspection
For your safety, it is very important to take a few
moments before each ride to walk around your
scooter and check its condition. If you detect any
problem, be sure to address it immediately, or have
it corrected by your KYMCO dealer.
WARNING
Improperly maintaining your scooter or failing to
correct a problem before riding can cause a
crash in which you can be seriously hurt or
killed.
Always perform a pre-ride inspection before
every ride and correct any problems.
Engine oil level: Add engine oil if required (page
1.
29). Check for leaks.
Fuel level: Fill fuel tank when necessary (page
2.
18). Check for leaks.
Tires: Check condition and inflation pressure
4.
(page 41).
Throttle: Check for smooth operation and that it
5.
closes completely in all steering positions (page
33).
6.
Lights and horn: Check that headlight, tail/brake
light, turn signals, indicators and horn function
properly.
Steering: Check for condition and smoothness.
7.
3
3.
Front and rear brakes: Check operation, make
sure there is no brake fluid leakage (page 40).
21
3
OPERATION
Starting the engine
Always follow the proper starting procedure
described here and on the following pages.
CAUTION
To protect the catalytic converter in your
scooter's exhaust system, avoid idling for
extending periods of time and do not use leaded
gasoline.
CAUTION
To prevent damage to the starter motor, do not
operate the starter motor for more than five
seconds at a time. If the scooter fails to start
immediately, check the fuel level and the battery
condition, and allow the starter motor to cool
before attempting to start the engine again.
Place your scooter on its center stand and put
1.
the side stand up.
Insert the ignition key and rotate the ignition
2.
switch to " " ON.
22
OPERATION
Squeeze the left (rear) brake lever.
3.
NOTE: The electric starter will only work when
the left(rear) or right(front) brake lever is
squeezed.
With the throttle closed, press the starter
4.
button .
Release the starter button as soon as the
engine starts.
CAUTION
Operating your scooter's engine with
insufficient oil pressure can cause serious
engine damage.
Keep the throttle closed while warming up the
5.
engine
3
Keep the engine to warm up fully before riding.
6.
23
MEMO
24
SECTION 4 MAINTENANCE
The importance of maintenance
Maintaining your scooter properly is essential for
safe, economical and trouble-free riding. It will also
help reduce air pollution and maximize fuel
economy.
To help you properly care for your scooter, the
following pages in this Owner's Manual include a
maintenance schedule to help you make sure your
scooter is serviced at the appropriate intervals.
WARNING
If your scooter tips over or becomes involved in
a crash, be sure your KYMCO dealer inspects
all major parts, even if you are able to make
some repairs.
Improperly maintaining this scooter or failing to
correct a problem before you ride could result in
a crash in which you could be seriously hurt or
killed.
These instructions are based on the assumption
that your scooter will be used exclusively for its
designed purpose. Sustained high speed
operation or operation in unusually wet or dusty
conditions will require more frequent service than
specified in the maintenance schedule. Consult
your KYMCO dealer for recommendations
applicable to your individual needs and use.
NOTE: Always follow the inspection and
maintenance recommendations and schedules in
this Owner's Manual.
4
WARNING
When performing maintenance on your scooter
you may need to start the engine. Running your
scooter's engine indoors or in a garage can be
hazardous. Exhaust gas contains carbon
monoxide, a gas that is colorless and odorless,
and can cause death or severe injury.
Operate the engine only where these is
adequate ventilation, preferably outdoors.
25
4
MAINTENANCE
Maintenance schedule
Perform the pre-ride inspection (see page 21) at each scheduled maintenance period. This interval
should be judged by odometer reading or months, whichever comes first.
Maintenance schedule legend (see page 27 and 28):
I: INSPECT AND CLEAN, ADJUST, LUBRICATE OR REPLACE IF NECESSARY
C: CLEAN R: REPLACE A: ADJUST L: LUBRICATE
The maintenance schedule on the flowing two pages specifies the maintenance required to keep your
People GT 125i/200i/300i scooter in peak operating condition. Maintenance work should be
performed in accordance with KYMCO standards and specifications by properly trained and equipped
technicians. Your KYMCO dealer meets all of these requirements.
Should be serviced by your KYMCO dealer, unless you have the proper tools, service data and
*
are technically qualified.
In the interest of safety, we recommend these items be serviced only by your KYMCO dealer.
**
KYMCO recommends that your KYMCO dealer road test your scooter after each periodic
maintenance service is completed.
26
FREQUENCY
ITEM
＊
AIR CLEANER
＊
THROTTLE OPERATION
＊
VALVE CLEARANCE
＊
FUEL LINE
CRANKCASE BREATHER
＊
ENGINE OIL
＊
ENGINE OIL SCREEN
MAINTENANCE
WHICHEVER
COMES FIRST
X 1000 km
X 1000 mi
MONTH
1
0.6
1
C
ODOMETER READING
10
5
6
3
12
6
R R R
R
II I I
A A A
I I I
R R R
R R R
C
25
20
15
15
12
9
30
24
18
R
I
CCC C C C
C C
I
II
30
18
36
RR
RRRSPARK PLUGS
RRI II
I
RRRR
REFER
TO
PAGE
33
34
33
-
-
-
29
-
4
＊
ENGINE OIL FILTER
＊
ENGINE IDLE SPEED
＊
TRANSMISSION FLUID
＊
DRIVE BELT
RRRR R R R
I I I
R R R R
R R R
I IIII
R
-
-
32
-
27
MAINTENANCE
FREQUENCY
WHICHEVER
COMES FIRST
ODOMETER READING
4
28
＊＊
＊
＊＊
＊
＊
＊＊
＊＊
ITEM
CLUTCH SHOE WEAR
BRAKE FLUID
BRAKE PAD WEAR
BRAKE SYSTEM
BRAKE LIGHT SWITCH
STEERING BEARINGS
HEADLIGHT AIM
NUTS, BOLTS, FASTENERS
WHEELS/TIRES
COOLANT
X 1000 km
X 1000 mi
MONTH
1
0.6
1
5
3
6
I I I
I
I I I
96
12
18
12
I I
R IR
I II I
I I
II II
II II
II II
II II
I I I
24
I
I
I
30
25201510
I
II
II
II
III
1815
3630
R
II
I
RR RI I I
REFER
TO
PAGE
-
38
39
-
-
-
-
-
41
36
MAINTENANCE
Engine oil
Engine oil recommendation
Use a premium quality 4-stroke engine oil to
ensure longer service life of your scooter. Only use
oils that have a SJ rating above per the API service
classification.
Engine oil viscosity :
SAE15W-40 (for People GT 125i)
SAE 5W-50 (for People GT 200i/300i)
If these viscosities are not available, select an
alternative engine oil according to the chart shown
below.
ENGINE OIL VISCOSITIES
20W-40 , 20W-50
20W-40, 20W-50
15W-40 , 15W-50
15W-40, 15W-50
10W-40
10W-40
10W-30
10W-30
20W-40 , 20W-50
5W-50
-10 0 10 20 30 40 C
0 20 40 60 80 100 F
Engine oil capacity:
1.2 L (for People GT 125i)
1.5 L (for People GT 200i/300i)
0
0
Engi ne oil level inspection
Check the engine oil level each day before riding
your scooter. The level must be maintained
between the upper and lower level marks on
the oil filler cap/dipstick .
<People GT 200i/ 300i>
Start the engine and let it idle for a few minutes.
1.
CAUTION
Running the engine with insufficient oil pressure
can cause serious engine damage.
2.
Stop the engine and put the scooter on its center
stand on level ground.
4
29
MAINTENANCE
After a few minutes, remove the oil filler
3.
cap/dipstick, wipe it clean, and reinsert the oil
filler cap/dipstick without screwing it in. Remove
the oil filler cap/dipstick. The oil level should be
between the upper and lower marks on the oil
filler cap/dipstick.
If required, add the specified oil so the oil level
4.
touches the upper level mark on the dipstick. Do
not overfill.
Reinstall the oil filler cap/dipstick . Check for
5.
oil leaks.
4
WARNING
The engine and related components can
become very hot. Use care when inspecting the
oil level so you do not burn yourself. If needed,
let the engine and exhaust system cool before
working in those areas.
Engine oil replacement
Engine oil quality is the primary factor that affects
engine longevity. Change your scooter's engine oil
as specified in the maintenance schedule .
NOTE: Change the engine oil with the engine at
normal operating temperature and the scooter on
its center stand to assure complete and rapid
draining.
<People GT 200i/ 300i>
Remove the oil filler/dipstick from the right
1.
crankcase cover.
2.
Place a suitable container (drain pan) under the
left crankcase.
30
MAINTENANCE
Remove the oil drain plug from the crankcase
3.
to drain the oil.
Reinstall the drain plug and tighten it to the
4.
specified torque.
Add oil to the engine per the amounts listed
5.
below, and reinstall the oil filler/dipstick.
125i
Capacity
At change
Start the engine and let it idle for 2 - 3 minutes.
6.
Stop the engine and check the oil level on the
7.
1.2L
1.0L
200i/300i
1.5L
1.3L
dipstick when the scooter is parked on the
center stand, on level ground.
Adjust the oil level as required (so the level
8.
reaches the upper mark on the dipstick).
Replace the dipstick and inspect for any leaks.
CAUTION
Running the engine with insufficient oil pressure
can cause serious engine damage.
44
<People GT 125i>
4
44
<People GT 200i/ 300i>
31
MAINTENANCE
Transmissio n fluid chan ge
Place the scooter on its center stand.
1.
4
32
Remove the transmission fluid drain bolt .
2.
Remove the transmission fluid filler bolt , then
3.
88
slowly rotate the rear wheel to drain the fluid.
Fill the transmission with the recommend fluid to
4.
the capacity listed below.
Transmission fluid type: SAE 90
200i/300i125i
Capacity
At change
Install the transmission filler bolt and tighten it to
5.
0.13L
0.12L
0.23L
0.21L
the specified torque.
77
77
88
<People GT 300i>
MAINTENANCE
Air cleaner filter element
The air cleaner filter element should be
serviced at regular intervals by a KYMCO dealer,
unless you have the proper tools, service data and
are technically qualified to do so.
Have the element serviced more often when riding
in unusually wet or dusty areas.
99
CAUTION
Using the wrong KYMCO air cleaner element or
a non-KYMCO air cleaner element which is not
of equivalent quality may cause premature
engine wear or performance problems.
Throttle operation
Before each ride, check for smooth throttle grip
1.
rotation from the fully open to the fully closed
position at both full steering positions.
Measure the throttle grip free play at the throttle
2.
grip flange (per the illustration right).
Throttle free play:
0.08-0.24 in (2.0 - 6.0 mm)
99
4
2－6 mm
(0.08－0.24 in)
33
Spark plug
MAINTENANCE
4
Remove the carbon deposits from the spark plug
with a small wire brush or a spark plug cleaning
machine. After cleaning (or when installing a new
spark plug) readjust the spark plug gap to specified
limit by using a spark plug gap thickness gauge.
The spark plug should be replaced periodically.
Whenever removing the carbon deposits, be sure
to observe the color of the removed spark plug's
porcelain tip. This color tells you whether or not the
standard spark plug is suitable for your type of
riding. Under normal usage, a spark plug's
porcelain tip should be light brown or tan color.
If the spark plug porcelain tip is very white or
glazed appearing, then the spark plug has been
operating too hot. In such a situation, you should
replace the standard spark plug with a spark plug
that has a colder heat range (usually a higher
number; consult with your KYMCO dealer when
selecting an alternate spark plug).
Recommended spark plug:CR7E (NGK)
CAUTION
An improper spark plug may have an incorrect fit
or heat range for your engine. This may cause
severe engine damage which will not be covered
under warranty. Never use a spark plug with an
improper heat range, as severe engine damage
could result.
Spark plug gap: 0.024 - 0.028 in
(0.6 - 0.7 mm)
34
MAINTENANCE
Coolant level inspection
The reserve tank is under right floorboard.
Check the coolant level through the inspection
window at the right side skirt white the engine
is at the normal operating temperature , with the
scooter in an upright position.
If the coolant level is below the LOWER level
mark , remove the floor mat , remove the
reserve tank lid and then the reserve tank cap
to add coolant mixture until it reaches the upper
level mark .
1
2
3
WARNING
Add coolant to the reserve tank only. Do not
attempt to add coolant by removing the radiator
cap. Coolant in the radiator is under pressure
and is very hot and can cause serious burns.
4
1
2
F
3
L
35
4
MAINTENANCE
36
MAINTENANCE
Side stand
Your scooter's side stand is not only necessary
when you park, but it contains an important safety
feature. This feature cuts-off the ignition if you try to
ride the scooter when the side stand is down.
Perform the following side stand inspection.
Interlock function check:
Check the side stand ignition cut-off system:
Place the scooter on its center stand.
1.
Put the side stand up and start the engine.
2.
Lower the side stand. The engine should stop as
3.
you put the side stand down.
NOTE: If the side stand system does not
operate as described, see your KYMCO dealer
for service.
Up
4
Down
37
4
MAINTENANCE
Brake fluid
Brake fluid level inspection
With the scooter in an upright position, check the
front and rear fluid level.
The level should be above the lower level mark. If
the level is at or below the lower level mark "L",
check the brake pads for wear.
NOTE: Other checks - make sure there are no
fluid leaks. Check for deterioration or cracks in the
hoses and fittings.
WARNING
Worn brake pads should be replaced
immediately. If the pads are not worn, have your
brake system inspected for leaks. Do not ride
your scooter unless the brakes are in perfect
working order.
L
Brake fluid type: DOT 4
38
MAINTENANCE
WARNING
For appropriate brake action, make sure the
groove of the adjusting nut is aligned with the pin
in the brake arm.
Inspect the brake pad and shoe thickness to verify
there is enough material for the brakes to function
properly.
If the wear indicator grooves in the front brake
1.
pads are no longer visible , it is an indication
that the brake pads are worn and require
replacement.
If the wear indicator grooves in the rear brake
2.
pads are no longer visible , it is an indication
that the brake pads are worn and require
replacement.
44
WARNING
The brakes will wear quickly if the lever is
continually applied during riding (dragging the
brake).
Consult your KYMCO dealer for braking system
service.
4
44
39
MAINTENANCE
Battery
Your KYMCO scooter is equipped with a
maintenance-free (sealed) type battery so it is not
necessary to check the battery's electrolyte level or
add distilled water.
NOTE: If your battery seems weak and/or is
leaking electrolyte (causing hard starting or other
electrical troubles), contact your KYMCO dealer
immediately.
CAUTION
Your battery is a maintenance-free type and can
4
be permanently damaged if the cap strip is
removed.
Fuse
When frequent fuse failures occur, it usually
indicates a short circuit or an overload in the
electrical system.
NOTE: See your KYMCO dealer for electrical
system diagnosis and repair.
WARNING
Never use a fuse with a different rating from that
specified. Serious damage to the electrical
system or a fire may result, causing a
dangerous loss of lights or engine power.
Fuses list
30A ... CHARGE fuse protects battery charging
system.
15A ... MAIN fuse protects all electrical circuits.
15A ... HEAD-HI/LO fuse protects the headlight
high/lower beam and clock.
10A ... IGNITION fuse protects the ignition system.
10A ... FAN fuse protects the cooling fan motor.
40
MAINTENANCE
Tires
WARNING
Failure to follow these warnings may result in an
accident due to tire failure. The tires on your scooter
are a crucial link between your scooter and the road.
You and your passenger's personal safety are
dependant upon the condition of your scooter's tires.
Follow these instructions:
Check tire condition and pressure, and adjust the
inflation pressure before each ride.
Avoid overloading your scooter.
Replace a tire when worn to the specified limit, or if you
find any damage such as cuts or cracks.
Always use the proper size and type of tires as
specified in this Owner's Manual.
Balance the wheel after tire installation.
Read this section of Owner's Manual carefully.
Failure to perform a reasonable break-in of the tires
could cause tire slip and loss of control.
Use extra care when riding on new tires as the grip
will be limited. Perform proper break-in of the tires, as
stated in the break-in recommendation section of this
manual. Avoid hard acceleration, hard cornering, and
hard braking for the first 100 miles (160 km).
NOTE: Check the tire inflation pressure and tire
tread condition at the periods listed in the periodic
maintenance schedule. For maximum safety and
good tire life, the tire pressures should be
inspected more often.
Tire pressure
Insufficient air pressure in the tires not only
accelerates tire wear but it also affects the stability
of your scooter. Under-inflated tires make smooth
cornering difficult and overinflated tires decrease
the amount of tire in contact with the ground, which
can lead to skids and loss of control. Make sure
that the tire pressures on your scooter are within
the specified limits at all times.
NOTE: Tire pressure should only be adjusted
when the tires are cold.
Front tire (rider only): 24.85 PSI (1.75 kgf/cm )
Rear tire (rider only): 28.40 PSI (2.00 kgf/cm )
Front tire (rider & passenger):24.85 PSI (1.75 kgf/cm )
Rear tire (rider & passenger): 32.0 PSI (2.25 kgf/cm )
2
2
2
2
4
41
MEMO
42
EMISSION CONTROL
Crankcase Emission Co ntrol System
Your People GT 125i/200i/300i engine is equipped with a closed crankcase system. Blow-by gases are
routed back in to the combustion chamber via the intake system. This system does not allow the blow-by
gases to enter the atmosphere.
Exha ust Emission Control System
The exhaust emissions from your People GT 125i/200i/300i scooter are controlled by engine design, factory-
set fuel delivery, ignition settings, and exhaust system design. This system also includes a catalyzer in the
exhaust system.
Nois e Exhaust Emission Control Syst em
5
The engine, intake and exhaust systems of your People GT 125i/200i/300i scooter were designed to comply
with federal, state and local noise level requirements. Do not modify the engine ,intake or exhaust
components, as doing so will affect compliance these noise level requirements.
Please do not modify or change any KYMCO-designed components that may alter the sound or emission
level from your People GT 125i/200i/300i scooter.
43
MEMO
44
SPECIFICATIONS - People GT 125i
Dime nsions
Overall length........................................85 in (2130 mm)
Overall width..........................................30 in ( 750 mm )
Overall height........................................51 in (1280 mm)
Wheel base...........................................58 in (1450 mm)
Capacities
Engine oil................................................................1.2L
Transmission oil....................................................0.13L
Fuel tank....................................................................9L
Net weight...............................................334lbs(152kg)
Engi ne
Type...........................Four-stroke,liquid -cooled SOHC
Displacement.................................124.8 cc (7.49 cu. in)
Bore and stroke..............2.16in X 2.18in (54 X 54.5 mm)
Compression ratio................................................11.7:1
Max. Horsepower Engine.....................14.3ps/9000rpm
Spark plug............................................................CR7E
Idle speed..................................................... 1800 RPM
Cooling system.........................................liquid-Cooled
Starting system.......................................Electric starter
Transmission......................................... Automatic CVT
Chas sis
Tire size, front ...............................................110/70-16
Tire size, rear.................................................140/70-16
Brake(front).......................................................... DISK
Brake(rear)........................................................... DISK
Elec trical
Ignition type ..............................Digital Inductive Ignition
Ignition timing.............................................ECU control
Battery............................................................12V12AH
Headlight.................................................12V60W/55W
Tail/brake light...........................................12V5W/21W
Turn signal light(Front/Rear)............12V10W/2W(LED)
Fuse.........................................................30A/15A/10A
5
6
6
45
SPECIFICATIONS - People GT 200i
6
Dimensions
Overall length........................................85 in (2130 mm)
Overall width..........................................30 in ( 750 mm)
Overall height........................................51 in (1280 mm)
Wheel base...........................................58 in (1450 mm)
Capacities
Engine oil
Transmission oil..................................0.23L
Fuel tank..................................................9L
Net weight................................344lbs(156.2kg)
..................................................1.5L
Electrical
Ignition type ..................Digital Inductive I
Ignition timing..................................ECU control
Battery................................................12V12AH
Headlight.....................................12V60W/55W
Tail/brake light................................12V5W/21W
Turn signal light(Front/Rear)....12V10W/2W(LED)
Fuse.............................................30A/15A/10A
gnition
Engine
...................................................Four-stroke OHC
Type
Valve train................................OHC & CENTER PIVOT
Displacement.......................................................205cc
Bore and stroke.................2.64in X 2.40in (66X 60 mm)
Compression ratio
Max. Horsepower Engine.....................20.6ps/8000rpm
Max. Torque Engine.........................2.03kg.m/6500rpm
Spark plug............................................................CR7E
Idle speed..................................................... 1600 RPM
Cooling system.........................................
Starting system.......................................Electric starter
Transmission.........................................Automatic CVT
................................................10.3:1
liquid-Cooled
Chassis
Tire size,front ................................................110/70-16
Tire size,rear..................................................140/70-16
Brake(front).......................................................... DISK
Brake(rear)........................................................... DISK
46
SPECIFICATIONS - People GT 300i
Dime nsions
Overall length........................................85 in (2130 mm)
Overall width..........................................30 in ( 750 mm )
Overall height........................................51 in (1280 mm)
Wheel base...........................................58 in (1450 mm)
Capacities
Engine oil..................................................1.5L
Tr a n s mission oil...... . . . . . . . ............. . . . . . . . .0.23L
Fuel ta n k............. . . . .............. . . . .............. . . . 9L
Net weight ....... ....... ...... ....... .....36 3lbs(16 5kg)
Elec trical
Ignition type ..................Digital Inductive Ignition
Ignition timing..................................ECU control
Battery................................................12V12AH
Headlig ht............ ......... .............. ..12V60W/55W
Tail/brake light................................12V5W/21W
Turn signal light(Front/Rear)....12V10W/2W(LED)
Fu se.............................................30A/15A/10 A
Engi ne
Type...................................................Four-stroke OHC
Valve train................................OHC & CENTER PIVOT
Displacement...................................................298.9 cc
Bore and stroke..............2.91in X 2.88in (72.7 X 72 mm)
Compression ratio................................................10.8:1
Max. Horsepower Engine........................28ps/7750rpm
Max. Torque Engine...........................2.7kg.m/6500rpm
Spark plug............................................................CR7E
Idle speed..................................................... 1600 RPM
Cooling system.........................................liquid-Cooled
Starting system.......................................Electric starter
Transmission......................................... Automatic CVT
Chas sis
Tire size,front ................................................110/70-16
Tire size,rear..................................................140/70-16
Brake(front).......................................................... DISK
Brake(rear)........................................................... DISK
6
6
47
Loading...
