IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions
should always be followed to reduce the risk of fire, electric
shock, and/or injury to persons, including the following:
- Read all instructions carefully before using.
- Use appliance only for its intended use.
- To protect against risk of electrical shock, do not put the
body of appliance in water or any other liquid.
- Close supervision is necessary when any appliance is used
near children. This appliance is not intended for use by
children.
- Unplug from outlet when not in use, before putting on or
taking off parts, and before cleaning.
- Avoid contact with moving parts. Keep hands, hair, clothing,
as well as spatulas and other utensils away during
operation to reduce the risk of injury to persons, and/or
damage to the appliance.
- Do not operate any appliance with a damaged cord or plug
or after the appliance malfunctions, or is dropped or
damaged in any manner. Return the appliance to an
authorized KRUPS Service Center for examination or repair.
- The use of attachments not recommended or sold by
KRUPS may cause fire, electric shock or injury.
- Do not use outdoors.
- Do not let cord hang over edge of table or counter.
- Do not let cord contact hot surface, including the stove.
- Double blade knife is sharp. Handle carefully.
- Bowl must be in place before replacing knife blades.
-The appliance is intended for processing small quantites of
food for immediate consumption, and is especially
recommended for preparing baby food.
-The appliance is not intended to prepare large quantites of
food at one time.
KRUPS Constance USA 2/06/06 9:47 Page a3
- A rubber/plastic spatula or wooden spoon may be used,
when the appliance is in “off” position and unplugged.
- This appliance is for household use only. Any servicing
other than cleaning and user maintenance should be
performed by an authorized KRUPS Service Center.
SAVE THESE INSTRUCTIONS
CAUTION
This appliance is intended for household use only. Do not
use it for commercial purposes. Any servicing other than
cleaning and user maintenance should be performed by the
nearest authorized KRUPS Service Center.
- Check voltage to be sure that the voltage indicated by the
name plate agrees with your voltage.
- Do not immerse the appliance in water or any other liquid.
- To reduce the risk of fire or electric shock, do not remove
the base. No user serviceable parts inside. Repairs should
be done by an authorised KRUPS Service Center only.
- Keep your hands and the cord away from hot parts during
operation.
- Never clean with scouring powders or hard implements.
- Do not place or use the appliance on hot surfaces such as
stoves, hotplates, or near open gas flames.
- Do not expose the appliance to temperatures above
105°F/41°C.
- Do not unplug the unit by pulling on the cord. Instead grasp
plug and pull to disconnect.
KRUPS Constance USA 2/06/06 9:47 Page a4
SPECIAL CORD SET INSTRUCTIONS
Regarding your cord:
This appliance has a polarized plug (one blade is wider than
the other). To reduce the risk of electric shock, this plug is
intended to fit into a polarized outlet only one way. If the plug
does not fit fully into the outlet, reverse the plug. If it still does
not fit, contact a qualified electrician. Do not attempt to
modify the plug in any way.
This is a 300 Watt appliance. If an extension cord is
absolutely necessary, a marked electrical rating should be at
least as great as the electrical rating of the appliance. Cords
rated for less amperage may overheat. Care should be
taken to arrange the cord so that it cannot be pulled or
tripped over.
KRUPS Constance USA 2/06/06 9:47 Page a5
Description
D
C
E
B
F
A
A Motor unit
B Bowl
C Seal
D Lid
E Emulsifying disc (according to model)
F Blade
G Spatula (according to model)
G
KRUPS Constance USA 2/06/06 9:47 Page 1
English
Safety instructions
- This appliance complies with applicable technical rules and s t a n d a rds at the
time of manufacture .
- Do not leave the appliance within reach of children.
- The blades supplied with this appliance are sharp, young children or severely
disabled persons should always be supervised when using this appliance.
- An electrical appliance is not a toy and should be kept out of reach of
children.
- It is designed to run only on alternating current. Please check before first use that the
main power supply corresponds to that indicated on the appliance's rating plate.
- Do not place or use this appliance on a hot plate or close to a flame (gas cooker).
- Only use the appliance on a stable working surface away from water being splashed.
Do not turn it upside down.
- Disconnect the appliance:
. if it is not working correctly,
. before cleaning or maintenance,
. after use.
- Never pull the power cord to disconnect the appliance.
- Only use an extension cord if you have already checked that it is in good working
order.
- You must not use this household electrical appliance if:
. it has been dropped,
. the blade is damaged or incomplete.
- If the power supply cord is damaged, it must be replaced by our authorised service
dealer to avoid any risk of danger.
- Do not let the power cord hang down.
- Do not immerse the motor unit or put it under water.
- Never pour or mix liquids or food whose temperature is higher than 80°C (175°F) into
the bowl. At this temperature, liquid will not boil but will release a small but visible
quantity of steam.
- Do not mix hot liquids.
- When mixing food which is warm, do not fill the bowl above the 12oz mark.
- The product has been designed for domestic use and should in no event be employed
for professional use.
- This product has been designed for domestic use only. Any commercial use, in
appropriate use or failure to comply with the instructions, the manufacturer accepts
no responsibility and the guarantee will not apply.
- Do not attempt to defeat the cover interlock mecanism.
1
KRUPS Constance USA 2/06/06 9:47 Page 2
Use
1
2
3
Place the bowl (B)
on the motor unit
(A) and lock it by
turning it. (Fig. 1).
counter-clock wise.
Then remove the
plastic cover and fit
the blade (F) or
emulsifying disc (E)
onto the bowl (B).
Caution, the
blades are
extremely sharp.
Assemble the
emulsifying disc: the
emulsifying disc is
supplied in two
parts (axis + disc).
Before using this
accessory, clip the
axis onto the disc.
(Fig. 2).
After this
operation, the
accessory can no
longer be
disassembled.
Add the ingredients
(Fig. 3).
Do not go over the
"max." level shown
on the bowl (12 oz).
4
Fit the lid (D)
equipped with the
seal (C) and lock it by
turning it
counter-clock wise
(Fig. 4).
Be certain cover is
securely locked in
place before
operating the
appliance.
Press the lid (D) to
5
start up (Fig. 5).
Do not run the
appliance empty
Do not stick fingers
or other items into
the bowl while the
appliance is
plugged in.
Blades are sharp
and precaution
must be exercised.
The bowl, without
blade and lid, can
be used in the
microwave oven.
However only
non fat foods
should be used as
fatty foods can
easily overheat and
cause damage to
the plastic bowl.
2
KRUPS Constance USA 2/06/06 9:47 Page 3
Suggested Preparations
The measuring graduations on the bowl take into account the volume occupied with
the blade fitted and are provided as a guide only.
Ingrédients
Maximum
Time
Quantity
Onions (cut into quaters)
Garlic
Shallots
Parsley
Walnuts, hazelnuts and almonds
Chocolate
Soft raw beef(cut into 3/4 inch cubes)
Cooked ham
Swiss cheese (in 3/4 inch cubes)
Parmesan cheese (in 3/4 inch cubes)
Cooked soup
Hints to obtain best results:
Work in pulses. Process with a pulse action using short bursts of power. If pieces of
food remain stuck to the sides of the bowl (beef, onions, etc.), use the spatula to
scrape them down and distribute them around the bowl before applying 2 or 3
additional pulses.
1 1/2 cups
1 1/2 cups
12 OZ
1/2 cup
1/2 cup
3/4 cup
6 OZ
8 OZ
3/4 cup
1 cup
12 OZ
15 pulses
10 pulses
10 pulses
10 pulses
10 secs
15 secs
15 pulses
15 secs
10 secs
20 secs
15 secs
Cleaning
Do not immerse the motor unit or put it under running water. Just wipe clean with a
sponge.
Handle the blade with care, as the blades are extremely sharp. Do not leave
the blade to soak with cutlery or dishes in the sink.
You can wash the bowl, the blade and emulsifying disc in the dishwasher (top basket).
To clean the lid correctly, you can remove the seal by pulling it out of the lid.
6
To fit again, be careful to position it correctly in the groove to
secure it (Fig.6). Do not use the appliance without the seal.
3
KRUPS Constance USA 2/06/06 9:47 Page 4
Recipes
Apple Compote
3 cup cooked apples, half a lemon,
2/3 cup superfine sugar , 1 tablespoon
of rum
Place the warm (but not hot) cooked
apples, the lemon juice, sugar and rum
in the bowl. Blend using the blade for
15 to 20 seconds. Leave to cool and
serve. Process in batches as necessary to
avoid exceeding the capacity of the
bowl.
Pesto sauce
1 1/2 cup Parmesan cheese, 5 sprigs of
fresh basil, 3 cloves of garlic, ,
15 walnut halves, 1/2 cup of olive oil
Place the basil and the garlic cloves and
cloves into the bowl. Blend finely.
Add the Parmesan cheeses in small
lumps along with the walnut halves
and chop finely for about 20 seconds.
Add the olive oil and blend to obtain
an even paste
Guacamole
1 large avocado , 1 clove of garlic, 1/2 a
skinned tomato, 1 tablespoon olive oil,
2 chilli peppers, 1/2 onion, 3 sprigs of
cilantro, 1 dash of lemon juice, salt and
pepper to taste.
Chop the garlic, onion, cilantro and
chilli peppers finely.
Peel the avocado, remove the pit and
cut it up before putting in the bowl.
Blend for 20 seconds to obtain a
smooth purée. Add salt and pepper to
taste.
Anchovy Paste
15 fillets of anchovies in oil, 2 cloves of
garlic, 3 hard-boiled egg yolks, 3
tablespoons of olive oil
Chop the garlic cloves finely. Add the
anchovies and mix again. Blend in the
egg yolks with 3 tablespoons of oil.
Blend to obtain a cream.
Add oil to achieve the desired consistency.
USING THE EMULSIFYING DISC
(according to model)
Whipped cream
3/4 cup +2 tbsp heavy cream.
11/2 tbsp superfine sugar and 1 sachet of
vanilla sugar (optional).
Tip to obtain superb, really stiff
whipped cream.
Use very cold whipping cream straight
from the refrigerator.
Fit the emulsifying disc in the bowl.
Pour in the ingredients and lock the lid.
Process continuously for 30 seconds.
MAYONNAISE
Tips to make really superb, stiff
mayonnaise:
- Use ingredients at room temperature
- Clean the bowl and the disc with cold
water
- Respect the quantities of ingredients
stated in each recipe.
Note: For best results use olive oil or
sunflower oil, or a mixture of both.
Mayonnaise with mustard
Fit the emulsifying disc to the bowl.
Add the ingredients: l egg yolk, 1
tablespoon of French mustard, 1/2
tablespoon of wine vinegar, salt and
pepper. Measure out 3 tablespoons of
oil and set aside.
Lock the lid and run for 15 seconds.
Pour in about 1 tablespoon of oil, process briefly then add the rest of the oil
and process continuously for about 20
to 30 seconds.
4
KRUPS Constance USA 2/06/06 9:47 Page 5
Mayonnaise without mustard
Proceed as for mayonnaise with mustard, replacing the mustard with 3
tablespoons of lemon juice.
PANCAKE MIX
For 12/3 cups of mix::
2/3 cup plain flour, 2 eggs, 1/2
teaspoon of fine salt, 2/3 cup milk, 1
teaspoon of oil.
Put all the ingredients in the bowl and
pulse until you obtain an even mix
(about 10 to 15 seconds).
WAFFLE MIX
2/3 cup plain flour, 1 teaspoon
Easybake or Fast Action dried yeast ,
1 egg, 1/2 cup milk, 21/2 tbsp melted
butter, 1 tablespoon of vanilla sugar.
Put all the ingredients into the bowl
and blend for about 15 to 20 seconds
until you get a smooth mix, then leave
to stand for 1 hour.
5
KRUPS Constance USA 2/06/06 9:47 Page 6
LIMITED WARRANTY
This Krups product is warranted for 1 year from the date of purchase against defects in
material and workmanship. During this period, the Krups product that, upon
inspection by Krups, is proved defective, will be repaired or replaced, at Krups’ option,
without charge to the customer. If a replacement product is sent, it will carry the
remaining warranty of the original product. This warranty does not apply to any
defect arising from a buyer’s or user’s misuse of the product, negligence, failure to
follow Krups’ instructions, use on current or voltage other than that stamped on the
product, wear and tear, alteration or repair not authorized by Krups, or use for
commercial purposes.
THE WARRANTIES SET FORTH HEREIN ARE EXCLUSIVE AND NO OTHER WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OR USE, ARE MADE BY
KRUPS OR ARE AUTHORIZED TO BE MADE WTH RESPECT TO THE PRODUCT.
Some states do not allow limitation on how long an implied warranty lasts or do not
allow the exclusion or incidental or consequential damages, so the above limitations
may not apply to you. This warranty gives you specific legal rights, and you may also
have other rights, which vary from state to state. If you believe you product is
defective:
USA: Please bring the product (or send it, postage prepaid) along with proof of purchase to the nearest authorized Krups Service Center.
CANADA: Please contact the Consumer Service Department for service center
locations. If you send the product, please include a letter explaining the nature of the
claimed defect and a copy of the sales receipt to validate the warranty.
USA Service center information is subject to change. Please confirm the location
is current by visiting our website at www.KrupsUSA.com or by calling our consumer
service department.
When shipping the product to the service center, please include a note explaining the
issue, a copy of the sales receipt and provide a valid return address on the outside of
the shipping box (no PO Boxes please). If the product is out of warranty or warranty
can’t be validated, the service center will send an estimate of repair for your approval.
6
KRUPS Constance USA 2/06/06 9:47 Page 7
USA Service Centers:
California
CES Concord
1170-G Burnett Ave.
Concord, CA 94520
925-827-1011
California
CES Covina
612 S. Shoppers Lane
Covina, CA 91723
626-915-4935
Florida
Southern Electric
510 N. Paramore Ave.
Orlando, FL 32801
407-841-8824
Illinois
Authorized Appliance
1644 West Ogden Ave.
Downers Grove, IL 60515
630-852-1550
If you have additional questions, please call our Consumer Service Department for
assistance. Please have the type number of your KRUPS appliance available. The type
number can generally be located on the bottom of the appliance. It would be helpful if
you had the product available at the time of your call in the event additional
information is needed.
CONSUMER SERVICE USA:
1-800-526-5377
Monday -Thursday from 8:00 am - 7:00 pm. (EST)
Friday from 8:00 am - 6:00 pm. (EST)
www.KrupsUSA.com
*Please note hours are subject to change.
KRUPS
196 Boston Avenue
Medford, MA 02155
Only letters can be accepted at this address. Shipments and packages that do not
have a return authorization number will be refused.
Maryland
Waters Appliance
216 E. Diamond Ave.
Gaithersburg, MD 20877
301-258-7500
New York
Turnpike Appliance
3495A Lawson Blvd.
Oceanside, NY 11572
516-486-5700
Washington
Action Small Appliance
1500 145th Place SE
Bellevue, WA 98007
425-643-9806
CONSUMER SERVICE CANADA:
1-800-418-3325
Mon – Fri 8:30 a.m. – 4:30 p.m. (EST)
www.Krups.ca
*Please note hours are subject to change.
Groupe SEB Canada Inc.
455 Finchdene Square
Scarborough, Ontario M1X 1B7
7
KRUPS Constance USA 2/06/06 9:47 Page 8
2 544744
Loading...
