INSTALLATION GUIDE
Handmade Stainless Steel
Undermount Kitchen Sink
KHU100-26 / KHU100-28 / KHU100-30 / KHU100-32 /
KHU101-23 / KHU102-33 / KHU103-33 / KHU104-33 /
KHU105-32 / KHU121-23 / KHU122-23 / KHU123-32
www.kraususa.com I Toll Free: 1.800.775.0703 I © 2017 Kraus USA Inc. I REV. December 7, 2017
Page 2
Congratulations on the purchase of your new
Kraus plumbing xture!
Please keep teh box and packaging materials until your product is
completely installed. If you have any questions, require technical
assistance, or have any problems with your product:
DO NOT RETURN TO STORE
Please contact our Customer Service Team
1-800-775-0703 / customerservice@kraususa.com
Have the model number available, and retain a copy of your receipt
with purchase date for reference.
If for any reason this product does not meet your expectations,
please be sure to repack this product in the original box and
packaging material to avoid damage during transit.
1
Page 3
Prior to Installation:
Make sure that you have all necessary parts by checking the parts list. If any part is
•
missing or damaged, please contact Kraus Customer Service at 800-775-0703 for a
replacement
• Inspect the sink prior to installation to make sure that it has not been damaged or
during shipping
• Use the cut-out template provided by Kraus
• Observe all plumbing and building codes according to your state requirements
• Not recommended to be installed with laminate countertop
For technical assistance or replacement parts, please contact Kraus
Customer Service and one of our representatives will be happy to help:
Toll-Free: 800-775-0703 or Customerservice@kraususa.com
The step-by-step guidelines in the installation instructions are a general reference for installing a
Kraus Sink. Should there be any discrepancies, Kraus cannot be held liable. It is recommended to
install all Kraus products by hiring a licensed professional.
2
Page 4
Tools you will need:
Phillips screwdriver
Adjustable wrench
Phillips screwdriver
Hex wrench
Silicone Sealant
I
D
J
F
B
G
H
E
254mm
254mm
Safety Goggles
Drill
Putty KnifePhillips Screwdriver
Silicone Adhesive Jig Saw
Tape Measure
Pencil
Scissors
Screwdriver
NOTE: Specialized tools may be necessary to install Kraus Stainless Steel Undermount
sinks with countertop materials other than wood, marble, or granite
Parts List
• Cut-Out Template • Mounting Hardware • Bottom Grids • Drain
Dimensions
18”
16”
457mm
406mm
17”
731mm
19”
482mm
24”
609mm
26”
660mm
KHU100-26
26” x 18” x 10”
Min Cabinet Size: 30”
Matching Grid: KBG-100-26
Drain Model #: ST-1
10”
KHU100-28
28” x 19” x 10”
Min Cabinet Size: 33”
Matching Grid: KBG-100-28
Drain Model #: ST-1
26”
660mm
28”
711mm
10”
3
Page 5
Dimensions
254mm
254mm
254mm
254mm
254mm
28”
711mm
30”
762mm
KHU100-30
30” x 18” x 10”
Min Cabinet Size: 33”
Matching Grid: KBG-100-30
Drain Model #: BST-1
21”
533mm
23”
584mm
16”
10”
18”
406mm
16”
406mm
457mm
18”
457mm
30”
762mm
32”
813mm
KHU100-32
32” x 19” x 10”
Min Cabinet Size: 36”
Matching Grid: KBG-100-32
Drain Model #: BST-1
14.87”
378mm
32.75”
832mm
14.87”
378mm
17”
10”
17”
19”
432mm
19”
432mm
483mm
483mm
KHU101-23
23” x 18” x 10”
Min Cabinet Size: 27”
Matching Grid: KBG-101-23
Drain Model #: BST-1
10”
10”
KHU102-33
32 3/4” x 19” x 10”
Min Cabinet Size: 36”
Matching Grid: KBG-102-33-1
and KBG-102-33-2
Drain Model #: BST-1 & ST-1
10”
4
Page 6
254mm
254mm
476mm
254mm
203mm
254mm
254mm
254mm
254mm
32.75”
832mm
16.87”
429mm
12.87”
327mm
19”
483mm
17”
432mm
10”
254mm
10”
254mm
Dimensions
17”
432mm
19”
483mm
20”
508mm
18”
457mm
16”
406mm
18”
457mm
KHU103-33
32 3/4” x 19” x 10”
Min Cabinet Size: 36”
Matching Grid: KBG-103-33-1
and KBG-103-33-2
Drain Model #: BST-1 & ST-1
426mm
18.75”
16.75”
21”
533mm
23”
584mm
10”
12.87”
327mm
32.75”
832mm
10”
KHU104-33
32 3/4” x 19” x 10”
Min Cabinet Size: 36”
Matching Grid: KBG-104-33-1
and KBG-104-33-2
Drain Model #: BST-1 & ST-1
476mm
21.75”
552mm
23.75”
603mm
16.87”
429mm
10”
426mm
16.75”
10”
18.75”
10”
14”
356mm
30.5”
775mm
13.5”
343mm
10”
KHU105-32
30 1/2” x 20” x 10”
Min Cabinet Size: 36”
Matching Grid: KBG-105-32-1 and
KBG-105-32-2
Drain Model #: BST-1 & ST-1
20”
508mm
18”
10”
457mm
18”
457mm
32”
813mm
11”
279mm
15”
381mm
8”
17”
432mm
KHU121-23
23” x 18 3/4” x 10”
Min Cabinet Size: 27”
Matching Grid: KBG-121-23
Drain Model #: BST-1
5
KHU122-23
23 3/4” x 18 3/4” x 10”
Min Cabinet Size: 27”
Matching Grid: KBG-122-23
Drain Model #: BST-1
KHU123-32
32” x 20” x 10”
Min Cabinet Size: 36”
Matching Grid: KBG-123-32-1
and KBG-123-32-2
Drain Model #: BST-1 & ST-1
Page 7
1. Determine Reveal Type
DETERMINE REVEAL TYPE
3/8“ Positive Reveal
DETERMINE REVEAL TYPE
Flushed/Zero Reveal
3/8“ Positive Reveal
DETERMINE REVEAL TYPE
Use scissors to cut along the line of the paper template for your desired
reveal type (Negative, Positive, or Flushed Reveal)
3/8“ Positive Reveal
Flushed/Zero Reveal
1/8“ Negative Reveal
KRAUS Recommended Installation Type
3/8”POSITIVE
1/8”NEGATIVE
FLUSHED/ZERO
Centerline
6
Page 8
2. Position Template
Step1
• Check the cut-out template against the actual sink to ensure a proper
sized cut-out
• Place the cut-out template in the desired location on the countertop
NOTE: Make sure clearance is suitable for backsplash, faucet, and plumbing for the sink
7
Page 9
3. Trace Template
Step2
• Trace template on countertop with a pencil
8
Page 10
4. Cut Countertop
Step3
• Cut the opening in the countertop by carefully following the traced line
NOTE: Please use the appropriate saw that best ts your countertop
material
9
Page 11
Flushed/Zero Reveal
1/8“ Negative Reveal
Determine location for mounting brackets; space
Centerline
3/8”POSITIVE
1/8”NEGATIVE
FLUSHED/ZERO
Step5
Step6
Step5
3/8
1/2
Step6
5. Set up Mounting Brackets
• Turn countertop over and align sink with countertop. Decide location for
mounting brackets
• Mounting holes should be ½” from edge of sink
1/2"
(13mm)
6. Drill Hole in Countertop
• Drill 3/8” diameter x 1/2” deep hole in the countertop
3/8
1/2
10
Page 12
7. Install Anchors
Step7
Step7
Step7
Step8 Step9
• Insert anchors into drilled holes and lightly tap with a hammer until ush
8. Secure Sink to Countertop
• Use a bead of silicone (or preferred adhesive) around the rim of the sink.
Check the alignment of the sink to the cutout in the countertop. Place sink
over cutout hole and press rmly
11
Page 13
9. Attach Mounting Hardware
• Attach mounting hardware to secure bowl. Remove excess sealant
from inside lip
• Allow sealant to set for 30 – 60 minutes
NOTE: Use acetone or
rubbing alcohol to
remove any excess sealant
10. Install Plumbing Fixtures
• Connect drain to sink. Connect trap to drain. Connect water supply
connections to faucet according to manufacturer’s instructions
• Run water into sink and check for leaks
12
Page 14
Codes / Standards Applicable:
Kitchen Sink Warranty
Kraus products are manufactured and tested to the highest quality standards by Kraus USA Inc. (“Kraus”).
Kraus extends this warranty to the original purchaser for personal household use of the “Kitchen Sink” in its original
location. The warranty is non-transferable.
Kraus warrants the structure and nish of the product to be free from defects in material and workmanship under normal
usage for the lifetime of the product. The warranty commences from the initial date of purchase by the owner or trade
professional, from an authorized Kraus dealer, through the lifetime of the original owner or end-user.
Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or
replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and
is not transferable to a subsequent owner.
Restrictions
This warranty does not cover antediluvian, discontinued, or display products, whether such items are purchased at
discount outlets, unauthorized dealers, and/or sold on clearance.
This warranty does not cover instances of negligence, misuse, abuse, improper installation, carelessness, accident, hard
water or mineral deposits, exposure to corrosive materials, misapplication, damages caused by improper maintenance,
alteration of the product, or failure to follow care or installation instructions enclosed with your product. Avoid using
abrasive cleaners such as powders, bleach, ammonia, alcohol, or chlorine. Avoid using abrasive pads, steel wool, or wire
brushes, as these will damage and wear down the nish.
This warranty does not apply to Products that have not been installed or operated in accordance with instructions
supplied by Kraus and all applicable rules, regulations, and legislation pertaining to such installations.
This warranty does not apply unless the Kraus product is installed by a fully insured and licensed trade professional. Kraus
insists that such professionals have experience in the installation of bathroom and kitchen manufactured goods.
This warranty does not cover labor charges or costs of removal and reinstallation of said product. This warranty does not
allow recovery of incidental or consequential damages, such as loss of use, delay, property damage, or other consequential
damages, and Kraus accepts no liability for such damages.
This warranty does not cover Marine or Outdoor Installation.
This warranty does not cover any free gifts included with purchase.
Except as otherwise provided above, Kraus makes no warranties, expressed or implied, including warranties of
merchantability and tness for a particular purpose, or compliance with any code.
Shipping charges will be covered for the rst (1) year of the warranted replacement part or product (HI, AK, and Puerto
Rico shipping charges may apply). International shipping fees are not included.
13
Page 15
Commercial Warranty
Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and
business use.
All incidental or consequential damages are specically excluded. No additional warranties, express or implied are given,
including but not limited to, any implied warranty of merchantability or tness for a particular purpose.
Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long an
implied warranty lasts, so the above limitations or exclusions may not apply to you.
This warranty gives you specic legal rights, and you may also have other rights which vary from state to state.
KRAUS USA has the right to change, modify, and/or update the warranty policy at any time. For the latest, most up to date
comprehensive warranty, go to www.kraususa.com/warranty
If you are a homeowner please contact a Kraus Customer Service Representative at:
Kraus USA, Inc.
12 Harbor Park Drive
Port Washington, NY 11050
Toll-free 800-775-0703
Customerservice@kraususa.com
If you are a plumbing contractor or trade professional please contact a Kraus
Pro Representative at:
Kraus USA, Inc.
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8955
Proservice@kraususa.com
If you are an Authorized Partner please contact a Partner Support Representative at:
Kraus USA, Inc.
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8954
Partnersupport@kraususa.com
In requesting warranty service, please be ready to provide:
1. Proof of purchase.
2. A description of the problem.
Download the Kraus Care & Maintenance Guide at:
http://www.kraususa.com/maintenance
14
Page 16
IMPORTANT
Register Your Kraus Product
Activate Your Warranty
Access Premium Customer Support
Get Product Information
REGISTER TODAY
http://www.kraususa.com/registration
