SSSS
eeee
rrrr
vvvv
iiii
cccc
eeee
M
M
aaaa
nnnn
uuuu
aaaa
llll
SSSS
eeee
rrrr
vvvv
SSSS
eeee
KARMA
KARMA
KARMAKARMA
rrrr
vvvv
iiii
iiii
cccc
cccc
eeee
eeee
MM
M
M
MM
M
M
MM
aaaa
aaaa
nnnn
nnnn
uuuu
uuuu
aaaa
aaaa
llll
llll
CONTENTS
CONTENTS
CONTENTS CONTENTS
1) Structural Diagram - - - - -
2) Block Diagram - - - - - - - - -
3) Circuit Diagram - - - - - - - -
4) Diagnostics - - - - - - - - - - -
5) Parts List - - - - - - - - - - - - -
Revision: 1.00
Issued date: June 26
Issued by: KORG INC.
th
, 2001
NO. PART CODE PART NAME Q'TY
1 641041608 X-9100 PANEL KOC-C10216-1 1
2 630033000 X-9100 PANEL SHEET F30084-1 1
3 646075500 X-9100 SIDE PLATE L ASSY H30206 1
4 646075600 X-9100 SIDE PLATE R E10179-1 1
5 646075800 X-9100 FDD COVER KOC-E20206-1 1
6 641041629 X-9100 BOTTOM COVER C10218-1 1
7 641041625 X-9100 OP COVER KOC-C30550 1
8 646075700 X-9100 SIMM COVER KOC-E20207-1 1
9 646075900 X-9100 SLIDE HOOK 1 KOC-E40514 1
10 540025200 PUSH LATCH 024A 1
11 630033100 X-9100 LCD WINDOW KOC-E40513-1 1
12 620040700 X-9100 VR KNOB KOC-E40519-1 13
13 620037900 X-8110 KNOB L H40148-4 1
14 646065400
X-610/620 SVR FRAME ASSY 30 H4012
2
15 620026800 X-410 SVR KNOB (GRAY) E40239-3 2
16 620036000 X-610 ENCODER KNOB(BLK)E40466-3 1
17 646066600 X-610 ENCODER FRAME KOC-E40467 1
18 620024600 X-952 PSW KNOB KOC-E40304-2 1
19 646040000 X-011/012 JS COVER KOC-E20134 1
20 620031800
4 LINKAGE KNOB A-4-BK H40130-4-BK
1
21 620031900
4 LINKAGE KNOB A-3-BK H40130-3-BK
2
22 620032000
4-LINKAGE KNOB A-2-BK H40130-2-BK
5
23 620032100
4-LINKAGE KNOB A-1-BK H40130-1-BK
6
24 620033800
4 LINKAGE KNOB B-4-BK H40131-4-BK
3
25 620034000
4 LINKAGE KNOB B-3-BK H40131-3-BK
5
26 620032400
4-LINKAGE KNOB B-1-BK H40131-1-BK
6
27 500022500 CASE LEG FF-004 5
improved LEDs brightness
improved LEDs brightness
improved LEDs brightness
KARMA
KARMA
KARMAKARMA
How to start and operate the test mode
How to start and operate the test mode
How to start and operate the test modeHow to start and operate the test mode
How to start :
How to start :
How to start :How to start :
ENTER + 5 + POWER ON : Full test
ENTER + 2 + POWER ON : All but internal test
ENTER + 3 + POWER ON : EXB-MOSS test
( internal test + MOSS DSP1 ～ 6 waveform confirmed )
How to operate :
How to operate :
How to operate :How to operate :
ENTER : Proceed to the next test
VAL UE ▲ : Item up
VAL UE ▼ : Item down
FF
＜＜
Notes when the test mode is started:
Notes when the test mode is started:
Notes when the test mode is started:Notes when the test mode is started:
- When the test mode is started, the calibration value of the joystick is
-
: Step up
＞＞
REW : Step down
cleared. So please execute this test item by all means.
When any of the internal test items is indicated in the LCD,
the contrast of the LCD can be adjusted by turning the Rotary encoder.
However, it sometimes cannot be indicated while the internal test being executed
because the data process does not catch up with the operation.
So if the contrast of the LCD is required, please execute it after the internal test
is done.
PART CODE PART NAME NOTE Q'TY
001186400
001193500 PCB ASSY KLM-1935 Z1/I30/TRITO KARMA M.PART 1
001221100 PCB ASSY KLM-2211 KARMA KARMA M.PART 1
001221200 PCB ASSY KLM-2212 KARMA KARMA M.PART 1
001221300 PCB ASSY KLM-2213/5/6 KARMA KARMA M.PART 1
001221400 PCB ASSY KLM-2214 KARMA KARMA M.PART 1
001221700 PCB ASSY KLM-2217 KARMA KARMA M.PART 1
304020230 TR 2SC3661-TA/TB(3K) (TS) KLM-2211 KARMA 10
304020400 TR 2SA1576A T106 (TS) KLM-2211 KARMA 1
304050140 DIGITAL TR DTC114EKA T146 (TS) KLM-2213/5/6 K 9
304050280 DIGITAL TR DTB113EK T146 (TS) KLM-2213/5/6 K 8
304060300 FET CPH6304-TL(TS) KLM-2214 KARMA 2
312010900 LED GL3ED8 KLM-2213/5/6 K 1
313005800 LCD MODULE NCM6602B KARMA M.PART 1
314001400 DIODE RLS-73 TE-11 (TS) KLM-2214 KARMA 2
314001400 DIODE RLS-73 TE-11 (TS) KLM-2211 KARMA 1
314010300 DIODE 1S2076TD (TA) KLM-2213/5/6 K 8
314010310 LED HLMF-K200#2UM (TR) KLM-2213/5/6 K 25
314028800 LED SLZ-190B-09-T2 (TR) KLM-2213/5/6 K 5
314030700 SCHOTTKY DIODE RB051L-40TE25 KLM-2214 KARMA 6
314031000 LED SLR-325VRT31(TR) KLM-2213/5/6 K 4
314031700 LED EL-17-21UYC/S530A2/TRB(TS) KLM-2217 KARMA 64
315001000 DOUBLE DIODE DAN217U T106(TS) KLM-2211 KARMA 5
320004538 IC HD63266F (S) KLM-2211 KARMA 1
320004675 IC HD6417709AF100B (S) KLM-2211 KARMA 1
320012223 IC MB87F1710PFV-G-BND(S) KLM-2211 KARMA 2
320012278 IC MBM29LV004TC-90TN(X9100):S KLM-2211 KARMA 1
320012280 IC MB81F643242C-10FN(S) KLM-2211 KARMA 1
320040069 MX23L12811TC12X7100BK4H/5H(S) KLM-2212 KARMA 1
320040070 MX23L12811TC12X7100BK4L/5L(S) KLM-2212 KARMA 1
324001015 IC UPC4570G2-E2 (TS) KLM-2211 KARMA 4
324001167 IC UPC78L05T-E2 (TS) KLM-2211 KARMA 2
324003010 IC TC7WU04F TE12L (TS) KLM-2211 KARMA 1
324003022 IC TC7S04FU (TE85L) (TS) KLM-2211 KARMA 1
324003060 IC TC58V64AFT(EL) (TS) KLM-2211 KARMA 1
324007010 IC BA08FP-E2 (TS) KLM-2214 KARMA 1
324009019 IC NJM2115M-TE2 (TS) KLM-1864 KARMA 1
324009031 IC NJM3414AM-T1 (TS) KLM-2211 KARMA 1
324011012 IC M51953BFP-600C (TS) KLM-2211 KARMA 1
324021005 IC AT93C66-10SI/SC2.7 (TS) KLM-2211 KARMA 1
324021014 IC SN74LV138ANS-EL (TS) KLM-2213/5/6 K 2
324021019 IC SN74AHCT32PWR(TS) KLM-2211 KARMA 2
324021026 IC SN74AHCT541PWR(TS) KLM-2212 KARMA 4
324021026 IC SN74AHCT541PWR(TS) KLM-2211 KARMA 2
324021031 IC SN74AHC1G08DBVR(TS) KLM-2212 KARMA 1
324021032 IC SN74LV4051ANSR (TS) KLM-2213/5/6 K 2
324021102 IC SN74LV08APWR (TS) KLM-2211 KARMA 1
324021103 IC SN74LV32APWR (TS) KLM-2211 KARMA 1
324021106 IC SN74LV139APWR (TS) KLM-2211 KARMA 1
PCB ASSY KLM-1864 PROPHECY KARMA M.PART 1
PART CODE PART NAME NOTE Q'TY
324021108
324021114 IC SN74LV05APWR (TS) KLM-2211 KARMA 1
324021118 IC SN74LVC541APWR (TS) KLM-2212 KARMA 3
324021119 IC SN74LV4051APWR (TS) KLM-2211 KARMA 1
324021120 IC SN74LVCC3245APWR (TS) KLM-2211 KARMA 1
324023008 IC S-8520F33MC-BNS-T2(TS) KLM-2214 KARMA 2
324024001 IC L1087MPX-ADJ (TS) KLM-2212 KARMA 1
324024001 IC L1087MPX-ADJ (TS) KLM-2211 KARMA 1
324036008 IC PCM1716E/2K(TS) KLM-2211 KARMA 2
324037004 IC HY5118164CJC-60-TE1(TS) KLM-2211 KARMA 2
334000600 PHOTO COUPLER PC-410K (TS) KLM-2211 KARMA 1
335011900 CRYSTAL OSC CA-301 24.576MHZ KLM-2211 KARMA 1
335012400 CRYSTAL OSC CA-301 8MHZ KLM-2211 KARMA 1
335400139 CERAMIC OSC CSTCV16.00MXJ0C1 KLM-2211 KARMA 1
350002233 SFR RH0615CN3J 3.3K KLM-1864 KARMA 1
350002447 SFR RH0615CS5J 470K KLM-1864 KARMA 1
360024500 VR RK11K1140ADW KLM-1511/1512 2
362009007 VR RK11K1140A9L KLM-2213/5/6 K 13
365007800 SVR RS30111AC00N KLM-2213/5/6 K 1
365009500 SLIDE VR EWA NA0C10B14 10KB KLM-2213/5/6 K 1
370005000 REC EC11B15204A5 KLM-2213/5/6 K 1
374000600 TSW EVQ11A09K (TR) KLM-2217 KARMA 11
374000600 TSW EVQ11A09K (TR) KLM-2213/5/6 K 52
375014800 PSW SDKLA10200 KLM-2214 KARMA 1
402002800 COIL 2943-666671 KLM-1935 KARMA 2
402004600 COIL 2943-666673 KLM-2214 KARMA 2
402006500 COIL TC-600M-3A-5026 KLM-2214 KARMA 1
402006600 COIL TBC0.8X18:0.3X45:0.3X27T KLM-2214 KARMA 1
402007100 COIL PLT09H-2003R KLM-2214 KARMA 1
404001050 CHIP COIL BLM21P600SGTP(TS) KLM-2214 KARMA 2
404001070 CHIP COIL BLM11B102SPT:TS KLM-2214 KARMA 2
404001070 CHIP COIL BLM11B102SPT:TS KLM-2211 KARMA 48
405011500 AC-AC ADAPTOR KA161(100/3.0A) KARMA JP M.PAR 1
405011600 AC-AC ADAPTOR KA163(120V/3.0A) KARMA US M.PAR 1
405011600 AC-AC ADAPTOR KA163(120V/3.0A) KARMA CN M.PAR 1
405011600 AC-AC ADAPTOR KA163(120V/3.0A) KARMA EX M.PAR 1
405011700 AC-AC ADAPTOR KA169(230V/3.0A) KARMA WG M.PAR 1
405011700 AC-AC ADAPTOR KA169(230V/3.0A) KARMA UK M.PAR 1
405011700 AC-AC ADAPTOR KA169(230V/3.0A) KARMA FR M.PAR 1
405011700 AC-AC ADAPTOR KA169(230V/3.0A) KARMA GE M.PAR 1
405011800 AC-AC ADAPTOR KA165(240V/3.0A) KARMA AU M.PAR 1
420005800 61TP/9S+PCBOARD+AFTERTOUCH KARMA M.PART 1
430008468 F.D KMFD-00P KARMA M.PART 1
435001900 FDD(2MODE) JU-257A726P KARMA M.PART 1
450003100 PHONE JACK LGR4609-7000 KLM-1935 KARMA 1
454004300 PHONE JACK YKB21-5012 KLM-2211 KARMA 4
454009900 PHONE JACK YKB21-5074G KLM-2211 KARMA 3
454011700 DIN CONNECTOR TCS5073-24-4151 KLM-2214 KARMA 1
464002401 FUSE 125V 2.5A GGS2.5 KARMA M.PART 1
IC SN74LV138APWR (TS) KLM-2211 KARMA 2
PART CODE PART NAME NOTE Q'TY
471070301
471101030 CONNECTOR TOP SC25-03WS KLM-2211 KARMA 1
471101040 CONNECTOR TOP SC25-04WS KLM-2214 KARMA 2
471101040 CONNECTOR TOP SC25-04WS KLM-2211 KARMA 1
471101050 CONNECTOR TOP SC25-05WS KLM-2214 KARMA 1
471101050 CONNECTOR TOP SC25-05WS KLM-2211 KARMA 1
471101060 CONNECTOR TOP SC25-06WS KLM-2213/5/6 K 1
471101060 CONNECTOR TOP SC25-06WS KLM-2211 KARMA 1
471102030 CONNECTOR TOP SJ20-03WX KLM-2211 KARMA 1
471102030 CONNECTOR TOP SJ20-03WX KLM-1935 KARMA 1
471102050 CONNECTOR TOP SJ20-05WX KLM-2213/5/6 K 1
471102050 CONNECTOR TOP SJ20-05WX KLM-2211 KARMA 1
471102060 CONNECTOR TOP SJ20-06WX KLM-2211 KARMA 1
471102090 CONNECTOR TOP SJ20-09WX KLM-2217 KARMA 1
471102090 CONNECTOR TOP SJ20-09WX KLM-2213/5/6 K 1
471102110 CONNECTOR TOP SJ20-11WX KLM-2213/5/6 K 1
471102110 CONNECTOR TOP SJ20-11WX KLM-2211 KARMA 1
471102120 CONNECTOR TOP SJ20-12WX KLM-2217 KARMA 1
471102120 CONNECTOR TOP SJ20-12WX KLM-2213/5/6 K 1
471102140 CONNECTOR TOP SJ20-14WX KLM-2213/5/6 K 1
471102140 CONNECTOR TOP SJ20-14WX KLM-2211 KARMA 1
471102150 CONNECTOR TOP SJ20-15WX KLM-2213/5/6 K 2
471102160 CONNECTOR TOP SJ20-16WX KLM-2213/5/6 K 2
474019500 CONNECTOR 1-215079-6 16P (AMP) KLM-2211 KARMA 2
474019700 CONNECTOR 76382-404 KLM-1864 KARMA 1
474028900 SIMM CONNECTOR 52706-7220 KLM-2212 KARMA 2
474031000 CONNECTOR B16B-PHDSS KLM-2211 KARMA 1
474032000 CONNECTOR 8802-080-170S KLM-2212 KARMA 1
474032100 CONNECTOR 8812-080-170S KLM-2211 KARMA 1
474032800 CONNECTOR 302A-34PGASA(OR B)03 KLM-2211 KARMA 1
474032900 CONNECTOR 302A-40PGAS003 KLM-2211 KARMA 1
475002964 HARNESS HNS-2964 KARMA M.PART 1
475002965 HARNESS HNS-2965 KARMA M.PART 1
475002966 HARNESS HNS-2966 KARMA M.PART 1
475002967 HARNESS HNS-2967 KARMA M.PART 1
475002968 HARNESS HNS-2968 KARMA M.PART 1
475002969 HARNESS HNS-2969 KARMA M.PART 1
475002970 HARNESS HNS-2970 KARMA M.PART 1
475002971 HARNESS HNS-2971 KARMA M.PART 1
475002972 HARNESS HNS-2972 BOARD IN KLM-1511/1512 1
475002973 HARNESS HNS-2973 KARMA M.PART 1
475002974 HARNESS HNS-2974 KARMA M.PART 1
475002975 HARNESS HNS-2975 KARMA M.PART 1
475002976 HARNESS HNS-2976 KARMA M.PART 1
475002977 HARNESS HNS-2977 KARMA M.PART 1
475002978 HARNESS HNS-2978 KARMA M.PART 1
475102268 HARNESS HNS-2268(F) L=31CM KARMA M.PART 1
475102269 HARNESS HNS-2269(F) L=25CM KARMA M.PART 1
475102979 HARNESS DDD34101-40C(HNS-2979) KARMA M.PART 1
CONNECTOR TOP B3B-PH-K-S (U) KLM-1864 KARMA 1
PART CODE PART NAME NOTE Q'TY
480010380
500022500 CASE LEG FF-004 KARMA M.PART 5
500032700 X-9200 PCB SPACER KOC-C40920 KARMA M.PART 1
500032800 X-9100 SPONGE SPACER C40944 KARMA M.PART 1
515400100 FUSE HOLDER CNT47-0003A(TR) KLM-2214 KARMA 2
525001400 FERRITE CORE F5 T 25X12X15 KARMA M.PART 1
540023500 POWER PLUG ECP01 05A KARMA UK M.PAR 1
540023900 PCB SPACER MSPLS-6 KARMA M.PART 1
575018400 LED SPACER LH-5-4.5 L=4.5MM KLM-2213/5/6 K 1
620024600 X-952 PSW KNBOB KOC-E40304-2 KARMA M.PART 1
620026800 X-410 SVR KNOB (GRAY) E40239-3 KARMA M.PART 2
620031800 4 LINKAGE KNOB A-4-BK H40130-4 KARMA M.PART 1
620031900 4 LINKAGE A-3-BK E20180/H40130 KARMA M.PART 2
620032000 4-LINKAGE KNOB A-2-BK KARMA M.PART 5
620032100 4-LINKAGE KNOB A-1-BK KARMA M.PART 6
620032400 4-LINKAGE KNOB B-1-BK KARMA M.PART 6
620033800 4 LINKAGE KNOB B-4-BK H40131-4 KARMA M.PART 3
620034000 4 LINKAGE KNOB B-3-BK H40131-3 KARMA M.PART 5
620036000 X-610 ENCODER KNOB(BLK)E40466- KARMA M.PART 1
620037900 X-8110 KNOB L H40148-4 KARMA M.PART 1
620040700 X-9100 VR KNOB KOC-E40519-1 KARMA M.PART 13
630032100 X-9200 LED FILTER KOC-E40507 KARMA M.PART 1
630033000 X-9100 PANEL SHEET F30084-1 KARMA M.PART 1
630033100 X-9100 LCD WINDOW KOC-E40513-1 KARMA M.PART 1
630033500 X-9100 SHIELD SHEET KOC-F40940 KARMA M.PART 1
641041436 GND METAL FITTING M1866-A KLM-2214 KARMA 2
641041436 GND METAL FITTING M1866-A KLM-1935 KARMA 1
641041534 X-7100/7110 LCD ANGLE C41145 KARMA M.PART 1
641041608 X-9100 PANEL KOC-C10216-1 KARMA M.PART 1
641041609 GND METAL FITTING M1698A KLM-2214 KARMA 2
641041623 X-9100 JACK PLATE 2 C41068-2 KLM-2211 KARMA 3
641041624 X-9100 SIDE CHASSIS KOC-C30549 KARMA M.PART 1
641041625 X-9100 OP COVER KOC-C30550 KARMA M.PART 1
641041626 X-9100 PCB CHASSIS KOC-C10220 KARMA M.PART 1
641041627 X-9100 CHASSIS L KOC-C10219 KARMA M.PART 1
641041628 X-9100 SUPPORT ANGLE C30551 KARMA M.PART 1
641041629 X-9100 BOTTOM COVER C10218-1 KARMA M.PART 1
641041630 X-9100 PLATE KOC-C41204 KARMA M.PART 1
644006200 X-011/012 WHEEL SPRING C40848 KARMA M.PART 2
644009000 X-8510 GND SPRING(K) KOC-C4116 KARMA M.PART 2
646038900 X-011/012 JS FRAME KOC-E30145 KARMA M.PART 1
646039000 X-011/012 VR PLATE KOC-E40309 KARMA M.PART 1
646039100 X-011/012 WHEEL SUPPORT E40308 KARMA M.PART 1
646039200 X-011/012 JS LEVER KOC-F40523 KARMA M.PART 1
646039300 X-011/012 JS WHEEL KOC-E30148 KARMA M.PART 1
646040000 X-011/012 JS COVER KOC-E20134 KARMA M.PART 1
646065400 X-610/620 SVR FRAME ASSY 30 KARMA M.PART 2
646066600 X-610 ENCODER FLAME KOC-E40467 KARMA M.PART 1
646074500 X-9100 LCD FRAME KOC-E30257 KARMA M.PART 1
DIN JACK YKF51-5041 KLM-2211 KARMA 1
PART CODE PART NAME NOTE Q'TY
646075500
646075600 X-9100 SIDE PLATE R E10179-1 KARMA M.PART 1
646075700 X-9100 SIM COVER KOC-E20207-1 KARMA M.PART 1
646075800 X-9100 FDD COVER KOC-E20206-1 KARMA M.PART 1
646075900 X-9100 SLIDE HOOK 1 KOC-E40514 KARMA M.PART 1
646076000 X-9100 SLIDE HOOK 2 KOC-E40515 KARMA M.PART 1
X-9100 SIDE PLATE L ASSY KARMA M.PART 1
Loading...
