If it’s embedded, it’s Kontron.
PCI-759 Board
User’s Guide (Version V1.02)
0-0096-4281
This page is intentionally left blank.
www.kontron.com
1. Table of Contents PCI-759 – User’s Guide (V1.02)
www.kontron.com 1
1. Table of Contents
1. Table of Contents ..................................................................................................................................... 1
1.1. Table of Figures...................................................................................................................................... 2
2. Introduction ........................................................................................................................................... 3
2.1. Symbols used in this Manual ..................................................................................................................... 4
3. Safety Instructions .................................................................................................................................. 5
3.1. Safety Instructions for the Lithium Battery.................................................................................................. 5
3.2. Basic Safety and EMC Compatibility ............................................................................................................ 5
4. Important Instructions............................................................................................................................. 6
4.1. Electrostatic Discharge (ESD) ................................................................................................................... 6
4.2. Note on the Warranty .............................................................................................................................. 6
4.3. Exclusion of Accident Liability Obligation.................................................................................................... 6
4.4. Liability Limitation / Exemption from the Warranty Obligation ........................................................................ 6
4.5. General Instruction on Usage ................................................................................................................... 6
5. Scope of Delivery ..................................................................................................................................... 7
5.1. Labeling Information .............................................................................................................................. 7
6. Features ................................................................................................................................................. 8
7. Functional Diagram.................................................................................................................................11
8. Memory Installation................................................................................................................................12
9. Jumpers and Connectors Overview.............................................................................................................13
9.1.1. Connectors located on Slot Bracket ....................................................................................................15
9.1.2. Jumpers on the PCI-759 ...................................................................................................................18
9.1.3. Connectors On-Board ...................................................................................................................... 20
9.1.4. Lithium Battery ..............................................................................................................................32
9.1.5. Replacing the Lithium Battery ...........................................................................................................32
10. AMI BIOS Configuration .........................................................................................................................33
10.1. BIOS Setup.........................................................................................................................................33
10.1.1. Navigation...................................................................................................................................33
10.2. Main .................................................................................................................................................34
10.2.1. System Time / System Date .............................................................................................................34
10.3. Advanced........................................................................................................................................... 36
10.3.1. CPU Configuration (Configure advanced CPU settings)..........................................................................37
10.3.2. IDE Configuration .........................................................................................................................39
10.3.3. Floppy Configuration .....................................................................................................................44
10.3.4. Super IO Configuration................................................................................................................... 45
10.3.5. Hardware Health Configuration .......................................................................................................47
10.3.6. ACPI Configuration ........................................................................................................................48
10.3.7. MPS Configuration......................................................................................................................... 50
10.3.8. PCI Express Configuration ...............................................................................................................51
10.3.9. Smbios Configuration ....................................................................................................................51
10.3.10. USB Configuration ....................................................................................................................... 52
10.4. PCIPnP...............................................................................................................................................54
10.5. Boot .................................................................................................................................................57
1. Table of Contents PCI-759 – User’s Guide (V1.02)
2 www.kontron.com
10.6. Security ............................................................................................................................................ 61
10.6.1. Supervisor Password ..................................................................................................................... 61
10.6.2. User Password.............................................................................................................................. 61
10.6.3. Boot Sector Virus Protection ........................................................................................................... 65
10.7. Chipset ............................................................................................................................................. 66
10.7.1. North Bridge Chipset Configuration.................................................................................................. 66
10.7.2. South Bridge Chipset Configuration ................................................................................................. 69
10.8. Exit .................................................................................................................................................. 71
10.8.1. Save Changes and Exit ................................................................................................................... 71
10.8.2. Discard Changes and Exit ............................................................................................................... 71
10.8.3. Discard Changes ........................................................................................................................... 71
10.8.4. Load Optimal Defaults ................................................................................................................... 71
10.8.5. Load Failsafe Defaults.................................................................................................................... 71
11. Technical Data...................................................................................................................................... 72
11.1. Electrical Specifications ....................................................................................................................... 73
11.2. Mechanical Specifications..................................................................................................................... 73
11.3. Environmental Specifications ................................................................................................................ 73
11.4. CE Directives, Standards ....................................................................................................................... 74
12. Declaration of Conformity...................................................................................................................... 75
13. Technical Support................................................................................................................................. 76
13.1. Returning Defective Merchandise ........................................................................................................... 76
1.1. Table of Figures
Fig. 1: PCI-759 board.................................................................................................................................... 7
Fig. 2: PCI-759 - Functional diagram...............................................................................................................11
Fig. 3: PCI-759 - Jumpers and connectors location ............................................................................................14
Fig. 4: PCI-759 - Slot Interfaces .....................................................................................................................15
Fig. 5: Placement of the battery .....................................................................................................................32
2. Introduction PCI-759 – User’s Guide (V1.02)
www.kontron.com 3
2. Introduction
Kontron Europe would like to point out that the information contained in this manual may be subject to technical
alteration, particularly as a result of the constant upgrading of Kontron Europe products. The attached documentation
does not entail any guarantee on the part of Kontron Europe with respect to technical processes described in the manual
or any product characteristics set out in the manual. Kontron Europe does not accept any liability for any printing errors
or other inaccuracies in the manual unless it can be proven that Kontron Europe is aware of such errors or inaccuracies or
that Kontron Europe is unaware of these as a result of gross negligence and Kontron Europe has failed to eliminate these
errors or inaccuracies for this reason. Kontron Europe expressly informs the user that this manual only contains a general
description of technical processes and instructions which may not be applicable in every individual case. In cases of
doubt, please contact Kontron Europe.
This manual is protected by copyright. All rights are reserved by Kontron Europe. Copies of all or part of this manual or
translations into a different language may only be made with the prior written consent of Kontron Europe. Kontron
Europe points out that the information contained in this manual is constantly being updated in line with the technical
alterations and improvements made by Kontron Europe to the products and thus this manual only reflects the technical
status of the products by Kontron Europe at the time of printing.
© 2012 by Kontron Europe
Printing and duplication, even of sections, is only permissible with the express approval of
Kontron Europe GmbH
Oskar-von-Miller-Str. 1
85386 Eching near Munich
Germany
2. Introduction PCI-759 – User’s Guide (V1.02)
4 www.kontron.com
2.1. Symbols used in this Manual
Symbol Meaning
This symbol indicates the danger of injury to the user or the risk of damage to the product if the
corresponding warning notices are not observed.
This symbol indicates that the product or parts thereof may be damaged if the corresponding warning
notices are not observed.
This symbol indicates general information about the product and the user manual.
This symbol indicates detail information about the specific product configuration.
This symbol precedes helpful hints and tips for daily use.
3. Safety Instructions PCI-759 – User’s Guide (V1.02)
www.kontron.com 5
3. Safety Instructions
3.1. Safety Instructions for the Lithium Battery
The PCI-759 board is equipped with a Lithium battery. For the replacing of this battery please observe the instructions
described in the subsection
9.1.5 “ Replacing the Lithium Battery”.
Caution!
Danger of explosion when replaced with wrong type of battery. Replace the battery only with
UL recognized Lithium battery that has the same or equivalent type recommended by Kontron.
Do not dispose of lithium batteries in domestic waste. Dispose of the battery according to the local
regulations dealing with the disposal of these special materials (e.g. to the collecting points for the
disposal of batteries).
3.2. Basic Safety and EMC Compatibility
The PCI-759 board is a fixed component that shall be installed into a stationary system by applying good engineering
practices and respecting the information on the intended use of the components with a view to meeting the protection
requirements [refer to (a) and (b)].
The PCI-759 board was designed and manufactured, having regard to the state of the art, as to ensure that:
(a) the electromagnetic disturbance generated does not exceed the level above which radio and telecommunications
equipment or other equipment cannot operate as intended;
(b) it has a level of immunity to the electromagnetic disturbance to be expected in its intended use which allows it to
operate without unacceptable degradation of its intended use.
The PCI-759 board was designed, manufactured and checked according to the basic safety requirements in the scope of
the low-voltage (LVD) directive.
4. Important Instructions PCI-759 – User’s Guide (V1.02)
6 www.kontron.com
4. Important Instructions
The manufacturer’s instructions provide useful information on your PCI-759 board.
4.1. Electrostatic Discharge (ESD)
The components on the board are sensitive to static electricity. Care must therefore be exercised at all times during
handling and inspection of the PCI-759 board, in order to ensure the product integrity.
Do not handle this product while it is outside its protective enclosure, while it is not used for operational purposes,
unless it is otherwise anti-static protected.
Unpack or install this product only at EOS/ESD safe workstations. When safe work station are not guaranteed, it is
important for the user to be electrically discharged before touching the PCI-759 board with his/her hands or tools.
This is most easily done by touching a metal part of your system housing.
Only hold the assemblies at the edge.
Do not touch any connection pins or conductors on the assembly.
4.2. Note on the Warranty
Due to their limited service life, parts which, by their nature, are especially subject to wear (wearing parts) are not
included in the guarantee beyond the legal stipulations. This applies to the batteries, for example.
4.3. Exclusion of Accident Liability Obligation
Kontron Europe shall be exempted from the statutory accident liability obligation if the user fails to observe the safety
instructions.
4.4. Liability Limitation / Exemption from the Warranty Obligation
In the event of damage to the device caused by failure to observe the hints in this manual and eventually on the device
(especially the safety instructions), Kontron Europe shall not be required to honor the warranty even during the warranty
period and shall be exempted from the statutory accident liability obligation.
4.5. General Instruction on Usage
In order to ensure safe operation, the user must observe the instructions and warnings contained in this manual.
The PCI-759 board must be used in accordance with the instructions for use.
The PCI-759 board is designed to be built-in to a system, which fulfill all necessary technical and environmental
requirements.
When installing the board into a system, ensure that the system is switched off and the systems power cord is
disconnected from the power source. Disconnect all cable connections of peripheral devices from the system.
Ensure that the DC operating voltages adheres to the specification given in the section
11.1“Electrical Specifications”.
Only devices and components which fulfill the requirements of a SELV circuit (security extra low voltage) in
accordance with IEC / EN 60950-1 may be connected to the interfaces of the PCI-759 board.
If extensions are made to the PCI-759 board, the legal stipulations and the board specifications must be observed.
5. Scope of Delivery PCI-759 – User’s Guide (V1.02)
www.kontron.com 7
5. Scope of Delivery
Please check that your package is complete, and contains the items below (according to the ordered unit configuration).
If you discover damaged or missing items, please contact your dealer.
1x PCI-759 Board PICMG 1.0 (full-size)
1x Safety Instructions
Fig. 1: PCI-759 board
Optional
PCI-759 board with CompactFlash™ connector (rear side location)
1x Cable Set (Accessories)
HD Audio daughter board
5.1. Labeling Information
Two types of printed labels on the PCI-759 board must show the following information:
1. Board identification label that has implemented: Board Designation/Serial Number/Part Number/Product
Revision/QM-Field/Bar Code/Datamatrix Code
2. 2x MAC-Address Label
6. Features PCI-759 – User’s Guide (V1.02)
8 www.kontron.com
6. Features
The PCI-759 is a full-size PICMG 1.0 form factor single-processor system host board based on the Intel® 945G chipset with
ICH7 I/O Controller Hub. It supports the Intel® Core™2 Duo or Celeron® S Processor on the LGA775 socket. Chipset
features include 1066/800/533MHz Front Side Bus, 2 DIMMs Dual Channel DDR2 667/533/400 MHz up to
4 GB, Intel® Express Graphics Memory Controller Hub with VGA up to 2048x1536x8bit at 75Hz and 24-bit LVDS via DVO up
to 1600x1200.
I/O features of the PCI-759 include onboard Gigabit Ethernet, one channel EIDE Ultra DMA, ATA/133 (optional
CompactFlash™ shared for CompactFlash™ Type-II), 4x SATAII 3Gb/s, MiniPCI slot , 32-bit/33MHz PCI bus, two UART
compatible serial ports, parallel port, floppy drive port, PS/2 Keyboard and Mouse. Only one floppy device can be
connected to the FDD connector.
Only one floppy device can be connected to the FDD connector.
The PCI-759 board supports Intel High Definition Audio via the onboard Audio interface connector and an additional (not
included) HD Audio daughter board).
Form Factor:
• Full size SHB PICMG 1.0 form factor (13.33 x 4.8 inch).
Processor (CPU):
Intel® Core™ 2 Duo
• 533/800/1066 MHz FSB (Front Side BUS)
• FC-LGA6 package
• 4MB, L2 Cache
• Auto-selection of CPU frequency and core voltage
Processor Socket: LGA 775
Memory
• Dual-Channel DDR2 memory architecture, un-buffered, non-ECC
• 2x DDR2 DIMM 240-pin slots for up to 4GB 400/533/667 MHz DDR2 SDRAM
• Memory type: 512Mb, 1GB DDR2, 2GB DDR2-SDRAM technologies
Chipset: Intel® 945G GMCH and Intel® I/O Controller Hub 7 (ICH7)
The Intel® 945G GMCH provides:
• Support for Intel® Core™2 Duo and Intel® Celeron S Processor with Hyper-Threading Technology
• 1066/800/533 MHz system bus
• Support for Dual Channel DDR2 400/533/667 memory, up to 4 GB
• Intel® Graphics Media Accelerator 950 (Intel® GMA 950 graphics) provides stunning media, incredible visuals and
new 3D capabilities
• Direct Media Interface (DMI) between GMCH and ICH7 delivers up to 2.0 GB/s concurrent bandwidth between the
memory and I/O controller
6. Features PCI-759 – User’s Guide (V1.02)
www.kontron.com 9
The Intel® 945G GMCH also features the Graphics Media Accelerator 950 technology with VGA up to 2048x1536x8bit at
75Hz, 24-bit LVDS via DVO up to 1600x1200, and PCI Express.
• 256-bit graphics core, 8/16/32 bpp, up to 8.5 GB/sec memory bandwidth with DDR2 533 MHz, and 1.3 GP/sec and
1.3 GT/sec fill rate
• 128 MB maximum video memory
• 400 MHz DAC frequency for up to 2048x1526 at 75 Hz maximum resolution for both analog and digital displays
• Dynamic Display Modes for flat-panel and wide-screen support
• Two Serial Digital Video Out (SDVO) ports for flat-panel monitors
• Multiple display types for dual monitor capabilities
The Intel® I/O Controller Hub 7 (ICH7) provides:
• PCI Express Base Specification, Rev. 1.0a compliant
• PCI Local Bus Specification, Rev. 2.2 compliant with support for 33MHz PCI operations
• ACPI Revision 1.0 compatible Power Management
• Supports system states: S0, S1D, S4 and S5
• Enhanced DMA controller, Interrupt controller, and timer functions
• Integrated Serial ATA host controller with independent DMA operations on four ports
• Integrated IDE controller supporting Ultra ATA 100/66/33
• USB host interface with support for up to 8 USB ports; two UHCI host controllers; one EHCI high-speed USB 2.0
Host controller
• SMBus Specification, Ver. 2.0 with additional support for I2C devices
• Support for Intel High Definition Audio
• Low Pin Count (LPC) interface
• Firmware Hub (FWH) interface support
BIOS
• AMI Flash BIOS FWH (8Mb ROM)
• SMIBIOS (DMI) compliant
• Boot from LAN [PXE (Pre-Boot Execution Environment) Booting] support
Onboard Gigabit Ethernet Control
The PCI-759 provides two 10/100/1000BASE-T Ethernet interfaces via two Marvell 88E8053 Ethernet Controllers.
• Two Marvell 88E8053 10/100/1000BASE-T Ethernet Controllers (PCIe x1)
• Compliant with 802.3x flow control support
• IEEE 802.1p and 802.1q support
• 10/100/1000 IEEE 802.3 compliance
• Wake on LAN (WOL) power management support
• ACPI 2.0 specification compliance
• Serial Peripheral Interface (SPI) for remote boot (PXE)
• LAN disable implemented under software control
6. Features PCI-759 – User’s Guide (V1.02)
10 www.kontron.com
I/O Control
The Winbond W83627EHF Super I/O provides the following functionality.
• Two UART serial ports, parallel port, floppy drive port, PS/2 keyboard/mouse interface
• Watchdog Timer: 1 to 255 step, (sec/min), software programmable
• Hardware Monitor: The W83627EHF Super I/O provides temperature, fans, and voltage monitor.
7. Functional Diagram PCI-759 – User’s Guide (V1.02)
www.kontron.com 11
7. Functional Diagram
Intel
Core 2 Duo
LGA775 Socket
LPC
Super I/O
1x USB 2.0
DDR2 SDRAM DIMM
DDR2 SDRAM DIMM
BIOS
Flash
AC’97
Connector
LAN
Controller
LAN2
1Gbps
LAN1
1Gbps
LAN
Controller
1x VGA
1x LVDS
AC'97
1x IDE (PATA)
CompactFlash
(option)
PCI
LPC
Memory
Controller
Intel ICH7
Intel 945G
Graphics
Controller
P
I
C
M
G
1.0
FSB
533/800/1066 MHz
6x USB 2.0
Battery
for
RTC
M
i
n
i
P
C
I
CPU Fan
Chassis Fan1
1x PS/2 Keyboard
and Mouse
1x Parallel
1x Serial (RS232)
1x Serial
(RS232/422/485)
1x Floppy
PCI Express 2
PCI Express 1
3. SATA
2. SATA
1. SATA
0. SATA
PCI
to
ISA
ISA
P
C
I
Legend:
On board connectors
External interfaces
Option
Fig. 2: PCI-759 - Functional diagram
8. Memory Installation PCI-759 – User’s Guide (V1.02)
12 www.kontron.com
8. Memory Installation
The PCI-759 board supports two 240 pin DDR2 DIMM sockets for up to a total memory of up to 4GB DDR2 SDRAM. The
single/double sided memory modules can be user-defined combined in sizes of 256MB, 512MB up to maximum 2GB pro
DDR2 DIMM socket.
The majority of systems supporting dual-channel memory can be configured in either single-channel or
dual-channel memory mode.
The speed used in all channels is the speed of the slowest DIMM in the system.
Only around a memory of 3.5 GB is usable for most of 32 bit operating systems.
The DIMM0 (nearest positioned to the CPU) must be fitted first for AMT and QST feature.
For the best dual-channel memory performance on boards with the Intel dual-channel DDR2 chipsets must be used
identically paired memory modules in channel A and B.
We recommend installing into the board DDR2 DIMM sockets a dual channel kit (identically manufacturer, capacity,
speed, number of chips and modules).
Prerequisites for dual-channel memory configuration:
1. Both modules are the same capacity (e.g. both are 256MB or 512MB)
2. Both modules are the same speed (e.g. both are PC2700 or PC3200)
3. Both have the same number of chips and module sides (e.g. both have the same number of chips on the module, and
both are either single-sided or double-sided).
If other memory configuration is used, the system will revert to the single-channel memory mode
(lower-performing mode).
The speed of the bus clock and the timing of the memory access for the main memory (RAM) are given by
the slowest DDR2 DIMM Module built-in the system.
9. Jumpers and Connectors Overview PCI-759 – User’s Guide (V1.02)
www.kontron.com 13
9. Jumpers and Connectors Overview
The jumpers and connectors of the PCI-759 board will be described in detail below.
Signals suffixed by a pound (#) are active-low.
All headers will have a pitch of 0.100" (2.54mm), otherwise noted different.
Connectors on the I/O Panel
USB USB6 Connector
LAN Ethernet1 Connector
VGA VGA Connector
LAN2 Ethernet2 Connector
PS/2Kb&Ms. PS2 Keyboard/Mouse (CN3)
On-Board Jumpers
JP1 Jumper for LCD (LVDS) power selection (+3.3V or +5.0V)
JP2 RTC Reset (Clear CMOS)
JP3 (Option) CompactFlash Configuration (Master or Slave)
pins 6 and 8 (FP1) The pins 6 and 8 of the FP1 shorted: internal speaker is enabled (default).
On-Board Connectors
FP1 Reset, HDD LED, internal & external speaker (2x4-pin)
FP2 Power Button, Power LED, KB.-Lock, I2CSMBUS (2x5-pin)
CN1 ATX Power Control Connector (2-pin)
CN2 Dual Channel LVDS Connector [JILI New] (40-pin)
CN5 Audio Connector (10-pin) (Line-in, Line-out, Mic.)
CN6 USB header (USB0+USB1) (9-pin+key)
CN7 USB header (USB2+USB3) (9-pin+key)
CN8 USB header (USB4+USB5) (9-pin+key)
CN9 ITP Connector (28-pin) (located on the bottom side)
IDE IDE (40-pin)
CF (IDE Option): CompactFlash Connector (50-pin) (located on the rear side)
SATA1 SATA1 Connector
SATA2 SATA2 Connector
SATA3 SATA3 Connector
SATA4 SATA4 Connector
FDD Floppy Connector (34-pin)
COM1 Serial Connector COM1(10-pin)
COM2 Serial Connector COM2 (10-pin)
LPT Parallel Connector LPT (26-pin)
FAN1 CPU-Fan Connector, 12V (4-pin)
FAN2 Fan Connectors, 12V (4-pin)
9. Jumpers and Connectors Overview PCI-759 – User’s Guide (V1.02)
14 www.kontron.com
Fig. 3: PCI-759 - Jumpers and connectors location
9. Jumpers and Connectors Overview PCI-759 – User’s Guide (V1.02)
www.kontron.com 15
9.1.1. Connectors located on Slot Bracket
Fig. 4: PCI-759 - Slot Interfaces
1 PS/2 keyboard and mouse connector
2 LAN1 connector
3 VGA connector
4 LAN2 connector
5 USB2.0 connector
9.1.1.1. LAN1 and LAN2: Gigabit Ethernet Connectors
The slot bracket of the PCI-759 board is equipped with two LAN connectors. These interface connectors are provided as
RJ45-sockets with integrated LEDs. The data transfer rate for the LAN communication is up to 10/100/1000Mbps.
Pin#
LAN1 and LAN2
Signal Name
RJ45 (female)
1 MDI0+
2 MDI0-
3 MDI1+
4 MDI2+
5 MDI2-
6 MDI1-
7 MDI3+
8 MDI3-
LED left yellow LINK / ACTIVE
orange Link1000
green Link100
LED right
off Link10
18
right LEDleft LED
431 2 5
9. Jumpers and Connectors Overview PCI-759 – User’s Guide (V1.02)
16 www.kontron.com
9.1.1.2. CN3: PS/2 Combined Keyboard and Mouse Connector
To this PS/2 connector you can connect:
a PS/2 keyboard (without using the Y-adapter cable) or
a PS/2 mouse (only by use of the Y adapter cable) or
a PS/2 mouse and a PS/2 keyboard (only by use of the Y adapter cable)
Pin Signal Name 6-pin MiniDIN socket
1 Keyboard data
2 Mouse data
3 GND
4 +5 V
5 Keyboard clock
6 Mouse clock
9.1.1.3. VGA Interface - Connector
Pin Signal Name 15-pin D-SUB socket (female)
1 red
2 green
3 blue
4 pulled to VCC
5, 6, 7,8,10 GND
9 +5 V fused *
11 pulled to VCC
12 DDC-SDA *
13 HSYNC
14 VSYNC
15 DDC-SCL *
* used for DDC
9. Jumpers and Connectors Overview PCI-759 – User’s Guide (V1.02)
www.kontron.com 17
9.1.1.4. USB Interface - Connector
The slot bracket of the PCI-759 board provides an external USB 2.0/1.1 port (USB6 and USB7). This connector allows
connection of USB devices to the board (slot bracket).
Pin Signal Name 4-pin USB Socket
Type A Version 2.0/1.1
1 VCC, fused
2 Data-
3 Data+
4 GND
9. Jumpers and Connectors Overview PCI-759 – User’s Guide (V1.02)
18 www.kontron.com
9.1.2. Jumpers on the PCI-759
The jumpers on the PCI-759 allow you to configure your CPU card according to the needs of your applications.
In order to change a jumper setting, turn off the computer using the ATX-power supply switch.
If your power supply has no On/Off switch, disconnect the main power source. The board otherwise
could be damaged.
The following examples show the conventions used in this section.
21
Jumper Open
21
Jumper Closed
9.1.2.1. JP1: Jumper for the LCD (LVDS) Power Selection (+3.3V or +5.0V)
This jumper allows you to select the required power for the LCD (LVDS) to +3.3V or +5.0V.
JP1: 3-Pin Row
DIP 3-pin
Setting Function
31
Pin 2-3 (Short/Closed)
Power for LCD is +3.3V (Default setting)
31
Pin 1-2 (Short/Closed) Power for LCD is +5.0V
9.1.2.2. JP2: Jumper for RTC Reset (Clear CMOS Content)
This jumper allows you to clear the data (such as system password, date, time, and system setup parameters) in CMOS.
In order to change a jumper setting, please turn off the computer and unplug the power source to the
board. Otherwise, the board could be damaged.
The board might not start with this jumper in “closed” position.
JP2: Pin Row,
DIP 2-pin
Setting Function
21
Pin 1-2 Open (Default) Normal Operation
21
Pin 1-2 Short/Closed Clear CMOS Content
For clearing of content, please wait 10 sec.
9. Jumpers and Connectors Overview PCI-759 – User’s Guide (V1.02)
www.kontron.com 19
9.1.2.3. JP3: CF Card Master/Slave Selecting (Option)
This jumper is used to select if the CompactFlash™ is master or slave device to the primary IDE.
JP3: 2-pin Row Pin Function
Pin 1-2 Open (Default)
The CF Card is Master
1 2
Pin 1-2 Short/Closed
The CF Card is Slave
While using CompactFlash™-cards, only one device can be used on primary IDE.
9. Jumpers and Connectors Overview PCI-759 – User’s Guide (V1.02)
20 www.kontron.com
9.1.3. Connectors On-Board
9.1.3.1. ATX: +12V ATX Power Connector
The ATX connector is used to connect the +12V ATX power supply to the board in order to provide power to the CPU.
J31: 4-pin Connector Pin Signal Name
1 GND
2 GND
3 +12V
4 +12V
9.1.3.2. FP1 (8-Pin) and FP2 (10-Pin) Front Panel 1 and 2 Connector
A system chassis can be equipped with components, that provide acoustical or/and light indication of the computer
activities, and switches to change the computer status. FP1 is an 8-pin box header that provides following connections:
Signal Name Pin FP1: Pin Row,
2x4 (male)
Pin Signal Name
Reset (+) 1 2 External Speaker (+)
Reset (-) 3 4 NC
HDLED (+) 5 6 Internal Speaker
HDLED (-) 7
12
78
FP1
8 External Speaker (-)
The PCI-759 board is delivered with the pins 6-8 of the FP1 shorted: internal speaker is enabled
(default).
In order to connect an external speaker, remove the jumper between pin 6 and 8 and connect the
wires of the ext. speaker to pins 2 and 8.
Signal Name Pin FP2: Pin Row,
2x10 (male)
Pin Signal Name
Power LED (+) 1 2 Power Button (+)
NC 3 4 Power Button (-)
Power LED (-) 5 6 NC
Keyboard Lock (+) 7 8 reserved
GND 9
12
910
FP2
10 reserved
9. Jumpers and Connectors Overview PCI-759 – User’s Guide (V1.02)
www.kontron.com 21
9.1.3.3. CN1: ATX Power Control Connector
CN1: JST Connector
B2B-XH-A
Pin Signal Name
1 PS_ON
12
2 5VSB
9.1.3.4. FAN1: CPU Fan Power Connector
It is a 4-pin header that allows the connection of the CPU fan. The CPU fan must be a 12V fan (max. 750 mA).
J1: 4-pin Molex Connector (friction lock) Pin Signal Name
1 GND
2 +12V
3 Sence
14
4 Control
9.1.3.5. FAN2: Chassis Fan2 Power Connector
It is a 4-pin header that allows the connection of a chassis fan. The chassis fan must be a 12V fan (max. 750 mA).
J4:- 4-pin Molex Connector (friction lock) Pin Signal Name
1 GND
2 +12V
3 Sence
14
4 Control
Also a 3-pin FAN connector cable can be can be connected to each of FAN1 or FAN2. In this case the
corresponding fan is operating with full speed.
9. Jumpers and Connectors Overview PCI-759 – User’s Guide (V1.02)
22 www.kontron.com
9.1.3.6. IDE: Primary IDE Connector
IDE: Boxed Header,
(shrouded), DIP 40-
pin
Signal Name Pin Pin Signal Name
IDE1_RST# 1 2 GND
PDD7 3 4 PDD8
PDD6 5 6 PDD9
PDD5 7 8 PDD10
PDD4 9 10 PDD11
PDD3 11 12 PDD12
PDD2 13 14 PDD13
PDD1 15 16 PDD14
PDD0 17 18 PDD15
GND 19 20 +5V
PDREQ0 21 22 GND
PDIOW# 23 24 GND
PDIOR# 25 26 GND
PIORDY 27 28 GND permanent
PDACK# 29 30 GND
IDE_IRQ14 31 32 IOCS16_IDE#
PDA1 33 34 80 pos. Cable detection
PDA0 35 36 PDA2
PDCS1# 37 38 HPDCS3
IDEACTP 39 40 GND
9. Jumpers and Connectors Overview PCI-759 – User’s Guide (V1.02)
www.kontron.com 23
9.1.3.7. CF: CompactFlash™ Connector (Option)
The optional CompactFlash™ connector is located on the rear side of the PCI-759 board.
While using CompactFlash™-cards, only one device can be used on primary IDE. In order to
configure the IDE (PATA) device and CF card, set the JP3 jumper corresponding for your system
configuration (refer to the chapter
9.1.2.3 “JP3: CF Card Master/Slave Selecting (Option)”.
CompactFlash
Signal Name Pin Pin Signal Name
GND 1 26 NC
PDD3 2 27 PDD11
PDD4 3 28 PDD12
PDD5 4 29 PDD13
PDD6 5 30 PDD14
PDD7 6 31 PDD15
PDCS1# 7 32 PDCS3#
GND 8 33 NC
GND 9 34 PDIOR#
GND 10 35 PDIOW#
GND 11 36 WE
GND 12 37 IRQ14
VCC5V+ 13 38 VCC5V+
GND 14 39 CFD_SEL
GND 15 40 NC
GND 16 41 IDE1_RST#
GND 17 42 PIORDY
PDA2 18 43 PDREQ_CF
PDA1 19 44 PDACK_CF#
PDA0 20 45 IDEACTP
PDD0 21 46 P66DET
PDD1 22 47 PDD8
PDD2 23 48 PDD9
IOCS16_IDE# 24 49 PDD10
CF
NC 25 50 GND
9. Jumpers and Connectors Overview PCI-759 – User’s Guide (V1.02)
24 www.kontron.com
9.1.3.8. SATA 1/2/3/4: Serial ATA Connectors
The PCI-759 board supports up to four Serial ATA ports. These connectors allow you to connect Serial-ATA devices. (Each
of the SATA interfaces supports one Serial-ATA device).
SATA1/2/3/4:Serial ATA:
High Speed Headers Molex 67800-8001, Locking Latch)
Pin Signal Name
1 GND
2 TX+
3 TX-
4 GND
5 RX-
6 RX-
SATA1/2/3/4
7 GND
9.1.3.9. FDD: Floppy Drive Connector
FDC: Boxed Header,
(shrouded), DIP 34-
pin
Signal Name Pin Pin Signal Name
GND 1 2 RWC#
GND 3 4 NC
NC 5 6 NC
GND 7 8 INDEX#
GND 9 10 Motor enable 0#
GND 11 12 Drive select 1
GND 13 14 Drive select 0
GND 15 16 Motor enable 1
GND 17 18 Direction
GND 19 20 Step
GND 21 22 Write data
GND 23 24 Write gate
GND 25 26 Track 00
GND 27 28 Write protect
GND 29 30 Read data
GND 31 32 Side 1 select
FDC
GND 33 34 Diskette change
9. Jumpers and Connectors Overview PCI-759 – User’s Guide (V1.02)
www.kontron.com 25
9.1.3.10. LPT: Parallel Port Connector
LPT is an IEEE1284 compatible interface and supports Normal/EPP/ECP mode.
This port is provided as a 26-pin boxed header.
Signal Name Pin LPT: Boxed Header,
DIP 26-pin
Pin Signal Name
Strobe# 1 2 AutoFeed#
PD0, Data 0 3 4 Error#
PD1, Data 1 5 6 Initialize#
PD2, Data 2 7 8 SLIN
PD3, Data 3 9 10 GND
PD4, Data 4 11 12 GND
PD5, Data 5 13 14 GND
PD6, Data 6 15 16 GND
PD7, Data 7 17 18 GND
Acknowledge# 19 20 GND
Busy 21 22 GND
Paper empty 23 24 GND
SLCT 25
25
1
26
2
LPT
26 NC
9. Jumpers and Connectors Overview PCI-759 – User’s Guide (V1.02)
26 www.kontron.com
9.1.3.11. COM1: Serial Port Connector COM1
The 10-pin boxed header is to be used with the supplied serial cable.
COM1 pin assignment RS232:
COM1: Boxed Header,
DIP 10-pin
RS232
(Pinning on the on-board header)
D-SUB
Connector
Pin Signal Name
1 DCD, Data carrier detect
2 DSR, Data set ready
3 RxD, Receive data
4 RTS, Request to send
5 TxD, Transmit data
6 CTS, Clear to send
7 DTR, Data terminal ready
8 RI, Ring indicator
9 GND, ground
1
9
2
10
COM1
10 NC
Pining on the
supplied cable
connector:
9.1.3.12. COM2: Serial Port Connector COM2
The 10-pin box header is to be used with the supplied serial cable. This interface is RS232 (default) and can be configured
as RS422 or RS485 (BIOS Setup).
For RS422 and RS485 mode, please install external termination resistors (120ohm).
COM2-pin assignment as RS232 (default):
COM2: Boxed Header,
DIP 10-pin
RS232
(Pinning on the on-board header)
D-SUB
Connector
Pin Signal Name
1 DCD, Data carrier detect
2 DSR, Data set ready
3 RxD, Receive data
4 RTS, Request to send
5 TxD, Transmit data
6 CTS, Clear to send
7 DTR, Data terminal ready
8 RI, Ring indicator
9 GND, ground
1
9
2
10
COM2
10 NC
Pining on the
supplied cable
connector:
9. Jumpers and Connectors Overview PCI-759 – User’s Guide (V1.02)
www.kontron.com 27
COM2 pin assignment as RS422:
COM2: Boxed Header,
DIP 10-pin
RS422
(Pinning on the on-board header)
D-SUB
Connector
Pin Signal Name
1 TxD–
2 NC
3 RxD+
4 NC
5 TxD+
6 NC
7 RxD–
8 NC
9 GND, ground
1
9
2
10
COM2
10 NC
Pining on the supplied
cable connector:
RxD+
RxD
–TxD
–
TxD+
GN
D
COM2 pin assignment as RS485:
COM2: Boxed Header,
DIP 10-pin
RS485
(Pinning on the on-board header)
D-SUB
Connector
Pin Signal Name
1
TRxD–,
Transmit/Receive data
2 NC
3 NC
4 NC
5
TRxD+,
Transmit/Receive data
6 NC
7 NC
8 NC
9 GND, ground
1
9
2
10
COM2
10 NC
Pining on the supplied
cable connector:
TRxD–
TRxD
+
9. Jumpers and Connectors Overview PCI-759 – User’s Guide (V1.02)
28 www.kontron.com
9.1.3.13. USB Extension (USB0/1, USB2/3, USB4/5)
Each of the onboard boxed 10-pin-header for USB extension (J13, J19 and J10) supports two USB ports (Port 4 and Port
5 / Port 8 and Port 9 / Port 10 and Port 11). Pin 9 is removed for keying purposes. (A slot bracket with 2x USB type A
connectors can be ordered separately.)
The PCI-759 board supports up to seven USB ports :
• USB (USB6) is available on the slot bracket.
• USB0 up to USB5) are available on board.
USB Port 0 USB Port 1
Pin Signal Name
USB0/1: 2x5 Pin Row
Pin Signal Name
1 VCC fused 2 VCC fused
3 D0- 4 D1-
5 D0+ 6 D1+
7 GND 8 GND
9 Key
12
109
10 NC
USB Port 2 USB Port 3
Pin Signal Name
USB2/3: 2x5 Pin Row
Pin Signal Name
1 VCC fused 2 VCC fused
3 D2- 4 D3-
5 D2+ 6 D3+
7 GND 8 GND
9 Key
12
109
10 NC
USB Port 4 USB Port 5
Pin Signal Name
USB4/5: 2x5 Pin Row
Pin Signal Name
1
VCC fused 2 VCC fused
3
D4- 4 D5-
5
D4+ 6 D5+
7
GND 8 GND
9
Key
12
109
10 NC
9. Jumpers and Connectors Overview PCI-759 – User’s Guide (V1.02)
www.kontron.com 29
9.1.3.14. Audio: AC’97 Connector
Pin Signal Name YIMTEX ELECTRONIC
10-pin Boxed Header 2.0 mm
Pin Signal Name
1 AC_RST- 2 AC_SYNC
3 GND 4 AC_DAOUT
5
AC_DAIN2
6 GND
7
GND
8 AC_BCLK
9
+5V
12
910
10 +3.3V
9. Jumpers and Connectors Overview PCI-759 – User’s Guide (V1.02)
30 www.kontron.com
9.1.3.15. MiniPCI Connector
MiniPCI Slot, 124-pin, Pin Assignments
Pin Signal Pin Signal Pin Signal
1 NC 51 AD21 101 GND
2 NC 52 AD22 102 GND
3 NC 53 AD19 103 AC97_SYNC
4 NC 54 AD20 104 GND (M66EN)
5 NC 55 GND 105 AC97_SDATAIN
6 NC 56 PAR 106 AC97_SDATAOUT
7 NC 57 AD17 107 AC97_BITCLK
8 NC 58 AD18 108 GND (ACCID0)
9 NC 59 -CEB2 109 PU (ACCID1)
10 NC 60 AD16 110 AC97_RESET
11 NC 61 -IRDY 111 MPCI_AUDMON
12 NC 62 GND 112 NC
13 NC 63 VCC3 113 GND
14 NC 64 -FRAME 114 GND
15 GND 65 -CLKRUN 115 MPCI_AUDOUT
16 NC 66 -TRDY 116 MPCI_AUDIN
17 -INTB 67 -SERR 117 GND
18 VCC 68 -STOP 118 GND
19 VCC3 69 GND 119 GND
20 -INTA 70 VCC3 120 GND
21 NC 71 -PERR 121 NC
22 NC 72 -DEVSEL 122 -MPCIACT
23 GND 73 -CBE1 123 VCC
24 V3.3Aux 74 GND 124 3.3VAUX
25 CLK 75 AD14
26 -RST 76 AD15
27 GND 77 GND
28 VCC3 78 AD13
29 -REQ 79 AD12
30 -GNT 80 AD11
31 VCC3 81 AD10
32 GND 82 GND
33 AD31 83 GND
34 -PME 84 AD9
35 AD29 85 AD8
36 NC 86 -CBE0
37 GND 87 AD7
38 AD30 88 VCC3
39 AD27 89 VCC3
40 VCC3 90 AD6
41 AD25 91 AD5
42 AD28 92 AD4
43 RESV 93 NC
44 AD26 94 AD2
45 -CBE3 95 AD3
46 AD24 96 AD0
47 AD23 97 VCC
48 IDSEL 98 NC
49 GND 99 AD1
50 GND 100 NC
9. Jumpers and Connectors Overview PCI-759 – User’s Guide (V1.02)
www.kontron.com 31
9.1.3.16. LVDS (JILI) Connector
The LVDS (JILI) complies with the JILI Specification 2.0. This connector allows you to connect LVDS-compatible receivers.
For the different required cable kits, please contact our GSS support.
LVDS (JILI) Connector Pin Signal Name
1 NC
2 ODD_LVD0-
3 ODD_LVD0+
4 ENAVDD
5 ODD_LVD1-
6 ODD_LVD1+
7 NC
8 ODD_LVD2-
9 ODD_LVD2+
10 GND
11 ODD_LVDC-
12 ODD_LVDC+
13 GND
14 GND (odd LVD3-)
15 GND (odd LVD3+)
16 JILI_DAT
17 EVEN_LVD0-
18 EVEN_LVD0+
19 JILI_CLK
20 EVEN_LVD1-
21 EVEN_LVD1+
22 NC
23 EVEN_LVD2-
24 EVEN_LVD2+
25 GND
26 EVEN_LVDC-
27 EVEN_LVDC+
28 GND
29 GND (even LVD3-)
30 GND (even LVD3+)
31 VCC_5V0
32 VCC_5V0
33 VCC_5V0
34 VCC_5V0
35 ENABKL#
36 BKLGND
37 BKLGND
38 VCC_12V0
39 VCC_12V0
LVDS (JILI)
40 VCC_12V0
9. Jumpers and Connectors Overview PCI-759 – User’s Guide (V1.02)
32 www.kontron.com
9.1.4. Lithium Battery
PCI-759 is provided with a 3.0 V “coin cell” lithium battery for the RTC operation and CMOS Setup RAM.
Fig. 5: Placement of the battery
9.1.5. Replacing the Lithium Battery
To replace the battery please proceed as follows:
1. Turn the power off.
2. If your system is equipped with expansion cards, remove them first, if necessary.
3. Remove the battery by pressing outwards the ejector spring.
4. Insert the new battery into the socket.
5. Make sure that you insert the battery correctly. The minus pole must be as marked (with a white line on the battery) in
the
Fig. 5!
Caution!
Danger of explosion when replaced with wrong type of battery. Replace the battery only with
UL recognized Lithium battery that has the same or equivalent type recommended by Kontron.
Do not dispose of lithium batteries in domestic waste. Dispose of the battery according to the local
regulations dealing with the disposal of these special materials (e.g. to the collecting points for the
disposal of batteries).
Battery socket
Lithium battery
Spring
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
www.kontron.com 33
10. AMI BIOS Configuration
This chapter describes the settings available in the optional AMI-BIOS for the PCI-759 board. The AMI-BIOS (Basic
Input/Output System) pre- installed in your computer system’s ROM supports Intel® Core™2 Duo, Intel® Celeron S
processors in a standard IBM-AT compatible I/O system.
10.1. BIOS Setup
The AMI BIOS provides a Setup utility program for specifying the system configurations and settings. The BIOS ROM of the
system stores the Setup utility. When you turn on the computer, the AMI BIOS is activated.
Pressing the <Del> key immediately allows you to enter the Setup utility. If you are a little bit late pressing the <Del> key,
POST (Power On Self Test) will continue with its test routines, thus preventing you from invoking the Setup. If you still
wish to enter Setup, restart the system by pressing the ”Reset” button or simultaneously pressing the <Ctrl>, <Alt> and
<Delete> keys. You can also restart by turning the system Off and back On again. The following message will appear on the
screen:
Press <DEL> to Enter Setup
In general, you press the arrow keys to highlight items, <Enter> to select, the <PgUp> and <PgDn> keys to change
entries, <F1> for help and <Esc> to quit.
When you enter the Setup utility, the Main Menu screen will appear on the screen. The Main Menu allows you to select
from various Setup functions and exit choices.
The BIOS Setup screen has two main frames. The left frame displays all the options that can be configured. “Grayed-out”
options cannot be configured. Blue options can be select and configured.
The right frame displays the key legend. Above the key legend is an area reserved for a text message. When an option is
selected in the left frame, it is highlighted in white. Often a text message will accompany it.
10.1.1. Navigation
Hot Key Description
→← Left/Right
The Left and Right <Arrow> keys allow you to select a BIOS Setup screen.
For example: Main screen, Advanced screen, Chipset screen, and so on.
↑↓ Up/Down
The Up and Down <Arrow> keys allow you to select a BIOS Setup item or sub-screen.
+ / - Plus/Minus The Plus and Minus <Keys> keys allow you to change the field value of a particular BIOS Setup item.
For example: Date and Time.
Tab The <Tab> key allows you to select BIOS Setup fields.
The <F8> key on your keyboard is the Fail-Safe key. It is not displayed on the key legend by default.
To set the Fail-Safe settings of the BIOS, press the <F8> key on your keyboard. The Fail-Safe settings
allow the motherboard to boot up with the least amount of options enabled. This can lessen the
probability of conflicting settings.
The <F9> key on your keyboard is the Optimal-Default key. To set the Optimal-Default settings of the
BIOS, press the <F9> key on your keyboard.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
34 www.kontron.com
10.2. Main
10.2.1. System Time / System Date
System Time
This field indicates the time of the device. If you change the time setting, enter the time in
the format HH:MM:SS
HH=Hours
MM=Minutes
SS=Seconds
System Date
This field indicates the date of the device. If you change the date setting, enter the date in
the format MM.DD.YYYY.
MM=Month
DD=Day
YYYY=Year
The “System Date” format can be arbitrary configured.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
www.kontron.com 35
¾ Board Information
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
36 www.kontron.com
10.3. Advanced
You can select the sub menus of the Advanced BIOS Setup:
• CPU Configuration
• IDE Configuration
• Floppy Configuration
• SuperIO Configuration
• Hardware Health Configuration
• ACPI Configuration
• MPS Configuration
• PCI Express Configuration
• Smbios Configuration
• USB Configuration
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
www.kontron.com 37
10.3.1. CPU Configuration (Configure advanced CPU settings)
10.3.1.1. Hardware Prefetcher:
This should be enabled in order to enable or disable the Hardware Prefetcher Disable Feature.
Available settings are: Enabled and Disabled.
10.3.1.2. Adjacent Cache Line Prefetch
This should be enabled in order to enable or disable the Hardware Prefetcher Disable Feature.
Available settings are: Enabled and Disabled.
10.3.1.3. Max CPUID Value Limit
Disabled for Windows XP
Available settings are: Disabled and Enabled.
10.3.1.4. Intel® Virtualization Tech
When enabled, a VMM can utilize the additional HW Caps provided by Intel® Virtualization Tech.
Note: A full reset is required to change the setting.
Available settings are: Enabled and Disabled.
10.3.1.5. Execute Disable Bit Capability
A Available settings are: Enabled and Disabled.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
38 www.kontron.com
10.3.1.6. Core Multi-Processing
Available settings are: Enabled and Disabled.
10.3.1.7. PECI
Available settings are: Disabled and Enabled.
10.3.1.8. Intel ® SpeedStep ™ tech
If Disabled: disable GV3
If Enabled: enable GV3
Available settings are: Enabled and Disabled.
10.3.1.9. Intel® C-STATE tech
C-State: CPU idle is set to C2 C3 C4 State.
Available settings are: Enabled and Disabled.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
www.kontron.com 39
10.3.2. IDE Configuration
This field can be use to select options for the IDE Configuration settings.
10.3.2.1. ATA/IDE Configuration
Available settings are: Enhanced, Compatible and Disabled.
If this option is set to Enhanced is available an additional option:
[Configure SATA Channels]
Available settings are: Before PATA and Behind PATA.
10.3.2.2. Legacy IDE Channels
Available settings are: SATA Pri, PATA Sec, PATA Pri, SATA Sec, PATA Only and SATA-Only.
10.3.2.3. Hard Disk Write Protect
This option allows you to enable or disable the device write protection. This will be effective only if the device is accessed
through BIOS.
Available settings: Enabled and Disabled.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
40 www.kontron.com
10.3.2.4. IDE Detect Time Out (Sec)
Set this option to stop the AMI BIOS from searching for IDE devices within the specified number of seconds. Basically, this
allows you to fine-tune the settings to allow for faster boot times.
Low settings can cause unreliable detection!
Possible settings are: 0, 5, 10, 15, 20, 25, 30 and 35.
0 This is the optimal setting for systems whose onboard controllers point to a specific IDE device in the AMI BIOS.
5 Set this option to stop the BIOS from searching the IDE Bus for IDE devices in five seconds.
10 Set this option to stop the BIOS from searching the IDE Bus for IDE devices in ten seconds.
15 Set this option to stop the BIOS from searching the IDE Bus for IDE devices in 15 seconds.
20 Set this option to stop the BIOS from searching the IDE Bus for IDE devices in 20 seconds.
25 Set this option to stop the BIOS from searching the IDE Bus for IDE devices in 25 seconds.
30 Set this option to stop the BIOS from searching the IDE Bus for IDE devices in 30 seconds.
35
This setting is recommended for all IDE devices that are set to AUTO in the BIOS setting (because a Master waits
30 sec. max. for a slave device).
10.3.2.5. ATA(PI) 80Pin Cable Detection
Set this option to define the method used to detect an ATA (PI) 80-pin cable. Possible settings are: Host & Device, Host
and Device.
Host & Device
Set this value to use both the motherboard IDE controller and the IDE device to detect the type of
IDE cable present.
Host
Set this value to use motherboard onboard IDE controller to detect the type of IDE cable present.
Device
Set this value to use IDE disk drive to detect the type of IDE cable present.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
www.kontron.com 41
¾ Primary IDE Master / Primary IDE Slave
These fields call the submenu to make corresponding settings of the IDE devices.
You should change the default settings only if you are connecting an additional IDE drive (e.g. Hard disk
drive).
The description of the setting options for Primary IDE Master also applies to Primary IDE Slave
The default settings strongly depend on the installed drive.
These entries are specific for each installed device as:
• Primary IDE Master/Primary IDE Slave
• Secondary IDE Master/Secondary IDE Slave
• Third IDE Master/Third IDE Slave
• Fourth IDE Master/Fourth IDE Slave
The screens below are only an example for which entries could be available.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
42 www.kontron.com
10.3.2.6. Type
Select the type of device connected to the system.
Not Installed, Auto, CD/DVD and ARMD (ATAPI Removable Media Device).
10.3.2.7. LBA/Large Mode
The LBA (Logical Block Addressing)/Large Mode option allows you to enable or disable support for IDE devices with
capacities greater than 528MB. The maximum drive capacity in the LBA mode is 137GB.
Disabled
Disables the LBA Mode and prevent the BIOS from using LBA mode control on the specified channel.
Auto
This setting allows the BIOS to auto-detect LBA mode control on the specified channel (if the device
supports it and the device is not already formatted with LBA Mode disabled).
10.3.2.8. Block (Multi-Sector Transfer)
If your hard disk supports the block mode, select Auto for the automatic determination of the number of the blocks per
request. Several sectors can be at the same time read/written. The data transfer rate will be increased.
Available settings are: Auto and Disabled.
Auto
The data transfer from and to the device occurs multiple sectors at a time if the device supports it. Block
mode allows transfers of up to 64Kb per interrupt.
Disabled
The data transfer from and to the device occurs one sector at a time. Only 512 byte of data can be
transferred per interrupt if block mode is not used.
This setting should be used only if read and write failures occur with “Auto”.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
www.kontron.com 43
10.3.2.9. PIO Mode
These fields allow your system IDE controller to work faster. Rather than have the BIOS issue a series of commands that
transfer to or from the IDE drive, PIO (Programmed Input/Output) allows the BIOS to communicate with the controller
and CPU directly.
The system supports five modes, numbered from 0 to 4, which primarily differ in timing. Available settings are: 0, 1, 2, 3,
4 and Auto. When Auto is selected, the BIOS will select the best available mode.
Available settings are: Auto, 0, 1, 2, 3 and 4.
Auto
This setting allows the BIOS to auto-detect the PIO mode. This setting is to be used if the IDE disk drive
cannot be determined.
0
This setting allows the BIOS to use the PIO mode 0. It has a data transfer rate of 3.3MBs.
1
This setting allows the BIOS to use the PIO mode 1. It has a data transfer rate of 5.2MBs.
2
This setting allows the BIOS to use the PIO mode 2. It has a data transfer rate of 8.3MBs.
3
This setting allows the BIOS to use the PIO mode 3. It has a data transfer rate of 11.1MBs.
4
This setting allows the BIOS to use the PIO mode 4. It has a data transfer rate of 16.6MBs. This setting
generally works with all hard disk drives manufactured after 1999. For other disk drive, such as IDE CD-
ROM drives, check the specifications of the drive.
Do not change the default setting “Auto”.
If some read and write failures occur, check the length and quality of the integrated device cable first or
set this option to a setting with a lower data transfer rate as specified for your device.
10.3.2.10. DMA Mode
This option allows you to select the DMA mode option (depending on the integrated device). Available settings are:
Auto, SWDMA0, SWDMA1, SWDMA2, MWDMA0, MWDMA1, MWDMA2, UDMA0, UDMA1, UDMA2, UDMA3, UDMA4, UDMA5 and
UDMA6.
Auto
If “Auto” is set, the BIOS auto-detects the DMA mode. This is the default setting.
SWDMA0
If “SWDMA0” is set the BIOS uses the Single Word DMA mode 0. It has a data transfer rate of 2.1MBs.
SWDMA1
If “SWDMA1” is set the BIOS uses the Single Word DMA mode 1. It has a data transfer rate of 4.2MBs.
SWDMA2
If “SWDMA2” is set the BIOS uses the Single Word DMA mode 2. It has a data transfer rate of 8.3MBs.
MWDMA0
If “MWDMA0” is set the BIOS uses the Multi Word DMA mode 0. It has a data transfer rate of 4.2MBs.
MWDMA1
If “MWDMA1” is set the BIOS uses the Multi Word DMA mode 1. It has a data transfer rate of 13.3MBs.
MWDMA2
If “MWDMA2” is set the BIOS uses the Multi Word DMA mode 2. It has a data transfer rate of 16.6MBs.
UDMA0
If “UDMA0” is set the BIOS uses the Ultra DMA mode 0. It has a data transfer rate of 16.6MBs (the same
data transfer rate as PIO mode 4, and Multi Word DMA mode 2).
UDMA1
If “UDMA1” is set the BIOS uses the Ultra DMA mode 1. It has a data transfer rate of 25MBs.
UDMA2
If “UDMA2” is set the BIOS uses the Ultra DMA mode 2. It has a data transfer rate of 33.3MBs.
UDMA3
If “UDMA3” is set the BIOS uses the Ultra DMA mode 3. It has a data transfer rate of 44.4MBs. It is
required to be used the 80-conductor ATA cable for this data transfer rate.
UDMA4
If “UDMA4” is set the BIOS uses the Ultra DMA mode 4. It has a data transfer rate of 66.6MBs. It is
required to be used the 80-conductor ATA cable for this data transfer rate.
UDMA5
If “UDMA5” is set the BIOS uses the Ultra DMA mode 5. It has a data transfer rate of 99.9MBs. It is
required to be used the 80-conductor ATA cable for this data transfer rate.
UDMA6
If “UDMA6” is set the BIOS uses the Ultra DMA mode 6. It has a data transfer rate of 133.2MBs. It is
required to be used an 80-conductor ATA cable for this data transfer rate.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
44 www.kontron.com
10.3.2.11. S.M.A.R.T.
S. M. A. R. T. (Self-Monitoring, Analysis and Reporting Technology) is used to predict drive failures. (The integrated drive
has to support this feature).
Available Settings are: Auto, Disabled and Enabled.
10.3.2.12. 32Bit Data Transfer
This option allows you to enable or disable the 32bit data transfer rate for the IDE devices. If this option is “Enabled” the
date transfer is accelerated and the CPU (PCI Bus) is relieved.
Available settings are: Enabled and Disabled.
10.3.3. Floppy Configuration
10.3.3.1. Floppy A
This option selects the type of the floppy drive. Only one floppy device can be connected to the FDD connector.
Possible settings are: Disabled, 360KB 5¼", 1.2MB 5¼", 720 KB 3½", 1.44 MB 3½" and 2.88 MB 3½".
Disabled
Set this value to prevent the use of the selected floppy disk drive channel. This option should be set if no
floppy disk drive is installed on the specified channel.
360KB 5¼"
Set this value if the floppy disk drive attached to the corresponding channel is a 360 KB 5¼" floppy disk
drive.
1.2MB 5¼"
Set this value if the floppy disk drive attached to the corresponding channel is a 1.2 MB 5¼" floppy disk
drive.
720KB 3½"
Set this value if the floppy disk drive attached to the corresponding channel is a 720 KB 3½" floppy disk
drive.
1.44MB 3½"
Set this value if the floppy disk drive attached to the corresponding channel is a 1.44 MB 3½" floppy disk
drive.
2.88 MB 3½"
Set this value if the floppy disk drive attached to the corresponding channel is a 2.88 MB 3½" floppy disk
drive.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
www.kontron.com 45
10.3.4. Super IO Configuration
This field can be used to select the Super I/O settings.
10.3.4.1. Onboard Floppy Controller
This function enables or disables the floppy drive controller.
Possible settings are: Enabled and Disabled.
Enabled
The floppy disk controller of the board is used.
Disabled
If a supplementary floppy disk controller is used or the system is not equipped with a floppy disk drive.
10.3.4.2. Serial Port 1 & 2 Address
These fields allow you to select the onboard serial ports and their addresses.
Available settings are:
Default
Available settings (without default setting)
Serial Port 1 Address
3F8/IRQ4
3E8/IRQ4 / 2E8/IRQ3 / Disabled
Serial Port 2 Address
2F8/IRQ3
3E8/IRQ4 / 2E8/IRQ3 / Disabled
10.3.4.3. Serial Port2 Mode
This field allows you to select the line mode for serial communication.
Available settings are: Normal (RS232), RS422 and RS485.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
46 www.kontron.com
10.3.4.4. Parallel Port Address
This field selects the I/O address used to access the parallel interface.
The possible values are: Disabled, 378, 278, 3BC.
The use of address space 3BC may be restricted for some modes because it doesn’t allow for
eight consecutive addresses.
10.3.4.5. Parallel Port Mode
This field is used to specify whether the parallel port is to be used as a bi-directional input/output port or just as an
output port. ECP and EPP transfer modes allow faster transfer rates of 2 and 2.4 Mbytes/s. These modes will only work with
peripheral devices which support them. In addition, the field Parallel Port Address must be set to 378 or 278 when using
one of these two modes.
Normal
The port functions as an output port only.
Bi-Directional Data can be transferred in both directions across the port.
EPP
Fast transfer mode (up to 2 Mbytes/s), can output and receive data. The mode requires a peripheral
device which supports the EPP (Enhanced Parallel Port) transfer mode.
ECP
Fast transfer mode (up to 2.4 Mbytes/s), can output and receive data. The mode requires a
peripheral device which supports the ECP (Enhanced Capability Port) transfer mode.
ECP & EPP
Fast transfer mode (up to 2.4 Mbytes/s), can output and receive data. The mode requires a
peripheral device which supports both EPP (Enhanced Parallel Port) and ECP (Enhanced Capability
Port) transfer mode.
10.3.4.6. Parallel Port IRQ
This field selects the interrupt used for the parallel interface.
It is possible to choose between: IRQ7 and IRQ5.
IRQ7
This setting allows the parallel port to use the interrupt IRQ7.
IRQ5
This setting allows the parallel port to use the interrupt IRQ5.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
www.kontron.com 47
10.3.5. Hardware Health Configuration
These fields allow you to observe the parameters of the hardware monitoring function feature of the system. These values
are read-only values for the monitoring of the system and show the PC health status.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
48 www.kontron.com
10.3.6. ACPI Configuration
ACPI Configuration settings allow you to select the Advanced Power Management (APM) options.
¾ Advanced ACPI Configuration
10.3.6.1. ACPI Versions Features
This option allows you to set the corresponding ACPI version.
It is possible to choose between: ACPI v1.0, ACPI v2.0 and ACPI v3.0.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
www.kontron.com 49
10.3.6.2. ACPI APIC support
This option determines whether or not to include the ACPI APIC table pointer to the RSDT pointer list.
It is possible to choose between: Enabled and Disabled.
Enabled
This setting will initiate ACPI APIC support.
Disabled
This setting disables ACPI APIC support.
10.3.6.3. AMI OEMB table
This option allows you to include the OEMB table pointer to R(X)SDT pointer list.
It is possible to choose between: Enabled and Disabled.
Enabled
This setting enables adding an OEMB table.
Disabled
This setting disables adding an OEMB table.
OEMB table is used to pass POST data to the AML code during ACPI O/S operation. It is required for
proper functionality.
10.3.6.4. Headless mode
This option is used to update the ACPI FACP table to indicate headless operations.
It is possible to choose between: Enabled and Disabled.
Enabled
This option enables updating the ACPI FACP table to indicate headless operation.
Disabled
This option disables updating the ACPI FACP table to indicate headless operation.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
50 www.kontron.com
¾ Chipset ACPI Configuration
10.3.6.5. APIC ACPI SCI IRQ
This option allows you to enable or disable the APIC ACPI IRQ function.
Available settings: Enabled and Disabled.
10.3.6.6. High Performance Event Timer
This option allows you to enable or disable the HPET (High Performance Event Timer).
Available settings: Enabled and Disabled.
10.3.7. MPS Configuration
This field allows you to select which MPS (Multi-Processor Specification) version is used. You have to select the MPS
version supported by your operating system.
Available settings are: 1.4 and 1.1.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
www.kontron.com 51
10.3.8. PCI Express Configuration
10.3.8.1. Active State Power Management
This option allows you to enable or disable the L0s and L1 link power states.
Available settings are: Enabled and Disabled.
10.3.9. Smbios Configuration
10.3.9.1. Smbios Smi Support
SMBIOS SMI Wrapper support for PnP Func 50h-54h
Available settings are: Enabled and Disabled.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
52 www.kontron.com
10.3.10. USB Configuration
This field allows you to select options for USB configuration.
10.3.10.1. Legacy USB Support
This function enables or disables support for legacy USB. Enabling legacy USB support allows using USB devices under
DOS and other non-Plug & Play operating systems.
Possible settings are: Enabled, Disabled and Auto.
If “Auto” is set, the system searches for USB devices. Whether no device is detected, the BIOS disable this option in
background.
10.3.10.2. USB 2.0 Controller Mode
The [USB 2.0 Controller Mode] option is available only if the option [Legacy USB Support] is set to
Enabled or Auto.
This option allows you to set the data signaling rate for the USB 2.0 controller.
Possible settings are: FullSpeed and HiSpeed.
HiSpeed
This setting allows data signaling rate of 480 Mbps.
FullSpeed
This setting allows data signaling rate of 12 Mbps.
10.3.10.3. BIOS EHCI Hand-Off
The [BIOS EHCI Hand-Off)] option is available only if the option [Legacy USB Support] is set to Enabled
or Auto.
This option allows you to enable support for operating systems without “EHCI Hand-Off” features.
Possible settings are: Enabled and Disabled.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
www.kontron.com 53
¾ USB Mass Storage Device Configuration
This option is only available if USB storage devices are connected to the board.
10.3.10.4. USB Mass Storage Reset Delay
This option specifies amount of time the BIOS USB code should wait after issuing a reset to the USB mass storage devices
(only needed for slow starting devices).
It is possible to choose between: 10 Sec, 20 Sec, 30 Sec, and 40 Sec.
10.3.10.5. Emulation Type
This option specifies the type of emulation provided by the BIOS for the device.
It is possible to choose between: Auto, Hard Disk, CD-ROM, Floppy and Forced FDD.
Auto
When this option is selected the BIOS detects the current formatted media.
Hard Disk
This option allows the device to be emulated as hard disk.
CD-ROM
This option allows the device to be emulated as a CD-ROM (if the block size of the media is greater than
512 bytes).
Floppy
This option allows the device to be emulated as floppy drive.
Forced FDD
This option allows a hard disk image to be connected as a floppy image.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
54 www.kontron.com
10.4. PCIPnP
The “PCI PnP Configuration” section of the BIOS controls the settings for the onboard PCI slots.
10.4.1.1. Clear NVRAM
This option allows you to clear the NVRAM during the system boot.
The available settings are: No and Yes.
10.4.1.2. Plug & Play O/S
This field determines the Plug&Play function. Plug&Play means that added components are automatically recognized and
installed if they support automatic recognition.
The available settings are: No and Yes.
No
The system BIOS assumes the recognition of the components and assigns the resources (e.g. DOS, WIN3.1).
Yes
The operating system assumes part of the Plug&Play functions.
This setting should only be selected if the operating system supports Plug&Play (e. g. Windows 95 or
higher) (e.g. Windows 2000, XP, Modem, LINUX).
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
www.kontron.com 55
10.4.1.3. PCI Latency Timer
This choice specifies, how long (PCI clock) a PCI card can still use the PCI Bus as master, if another PCI card requests the
access to the PCI Bus.
The available settings are: 32, 64, 96, 128, 160, 192, 224 and 248.
10.4.1.4. Allocate IRQ to PCI VGA
This option allows or restricts the system to allocate an IRQ to a VGA adapter card that uses the PCI Bus.
The available settings are: Yes and No.
Yes
Assigns an IRQ to PCI VGA card if the card requests an IRQ.
No
Does not assign an IRQ to a PCI VGA card even if the card requests an IRQ.
10.4.1.5. Palette Snooping
This option allows the compliance of older higher resolution video cards to the VGA standard. As presently all video
boards are compliant to this standard, this option must stay Disabled.
This default setting should not be changed unless the VGA card manufacturer requires Palette Snooping to be “Enabled”.
The available settings are: Enabled and Disabled.
10.4.1.6. PCI IDE BusMaster
If this option is „Enabled“, the BIOS uses busmastering for reading/writing to IDE drives.
The available settings are: Enabled and Disabled.
10.4.1.7. OffBoard PCI/ISA IDE Card
This option is to be used if an offboard PCI/ISA IDE controller adapter card is installed in the system.
The settings of this option allow you to specify the PCI expansion slot on the motherboard where the offboard PCI/ISA
controller is installed.
The available settings are: PCI Slot1, PCI Slot2, PCI Slot3, PCI Slot4, PCI Slot5, PCI Slot6, and Auto.
10.4.1.8. IRQ3, IRQ4, IRQ5, IRQ7, IRQ9, IRQ10, IRQ11, IRQ14, IRQ15
These options allow you to configure the IRQ Resources.
Available settings are: Available and Reserved.
Available
This setting allows the specified IRQ to be used by PCI/PnP device.
Reserved
This setting allows the specified IRQ to be used by a legacy ISA device.
10.4.1.9. Reserved Memory Size
This option allows you to specify the memory size for the ISA extension cards (only to be used if the ISA-Bridge is
equipped on the backplane).
Available settings are: 16k, 32k, 64k and Disabled.
If this option is enabled to 16k, 32k or 64k a supplementary option is available: “Reserved Memory Address”.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
56 www.kontron.com
10.4.1.10. Reserved Memory Address
This option allows you to specify the memory size for the ISA extension cards in the reserved memory address.
Available settings are: C0000, C4000, C8000, CC000, D0000, D4000, D8000 and DC000.
For a proper ISA card installation, set the same values of the BIOS options “Reserved Memory Size”
and “Reserved Memory Address” like on the OS level and/or driver level (depending on the installed
ISA card).
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
www.kontron.com 57
10.5. Boot
In the Boot menu you define the sequence in which the system BIOS searches the drives for system files to start the
operating system.
¾ Boot Settings Configuration
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
58 www.kontron.com
10.5.1.1. Quick Boot
This option allows or restricts the BIOS to perform all POST tests.
It is possible to choose between: Enabled and Disabled.
Enabled
This setting allows the BIOS to skip certain POST tests to boot faster.
Disabled
This setting allows the BIOS to perform all POST tests.
10.5.1.2. Quiet Boot
This option allows you to modify the boot up screen settings between POST messages or OEM logo.
It is possible to choose between: Enabled and Disabled.
Enabled
This setting allows the computer system to display the OEM logo instead of POST messages.
Disabled
This setting allows the computer system to display the POST messages.
If this option is Enabled the installed AMI-Logo (or a customized Company-Logo, if ordered) will be
displayed during POST.
10.5.1.3. AddOn ROM Display Mode
This option can be used to display add-on ROM (read-only memory) messages (e.g. the SCSI BIOS or VGA BIOS).
It is possible to choose between: Force BIOS and Keep Current.
Keep Current
A third party BIOS messages are not displayed during system boot.
Force BIOS
This setting allows the computer system to force a third party BIOS to display its messages during
system boot.
10.5.1.4. Bootup Num-Lock
Set this value to allow the Number Lock setting to be modified during boot up.
It is possible to choose between: On and Off.
On
Set this value to allow the Number Lock on the keyboard to be enabled automatically when the
computer system is boot up. This allows the immediate use of 10-keys numeric keypad located on the
right side of the keyboard. To confirm this, the Number Lock LED light on the keyboard will be lit. This
is the default setting.
Off
This option does not enable the keyboard Number Lock automatically. To use the 10-keys on the
keyboard, press the Number Lock key located on the upper left-hand corner of the 10-key pad. The
Number Lock LED on the keyboard will light up when the Number Lock is engaged.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
www.kontron.com 59
10.5.1.5. PS/2 Mouse Support
This option allows you to activate or to restrict the PS/2 mouse support.
It is possible to choose between: Auto, Enabled and Disabled.
Enabled
Set this value to force the system to reserve an IRQ for PS/2 devices.
Disabled
This option will prevent the PS/2 mouse port from using system resources and will prevent the port
from being active. Use this setting if you want to install an external serial mouse.
Auto
Set this value to allow the BIOS to auto-detect a PS/2 mouse and to reserve the resources for it.
10.5.1.6. Wait For ‘F1’ If Error
This option specifies if errors detected during the boot time, determine the interruption of the boot procedure.
It is possible to choose between: Enabled and Disabled.
Enabled
The boot procedure is stopped, whenever the BIOS detect an error. The system waits for a user input.
Disabled
The boot procedure will be not halted for any error that may be detected.
10.5.1.7. Hit ‘DEL’ Message Display
This option allows you to modify the setting for “Hit ‘DEL’ Message Display”.
It is possible to choose between: Enabled and Disabled.
Enabled
This setting allows the system to display:
Hit Del to enter Setup
during memory initialization.
If “Quiet Boot” option is enabled, the Hit ‘DEL’ message will not display.
Disabled
This setting prevents the system to display:
Hit Del to enter Setup
during memory initialization.
If “Quiet Boot” option is enabled, the Hit ‘DEL’ message will not display.
10.5.1.8. Interrupt 19 Capture
Set this value to allow option ROMs such as network controllers to trap BIOS interrupt 19.
It is possible to choose between: Enabled and Disabled.
Enabled
The BIOS allows option ROMs to trap interrupt 19.
Disabled
The BIOS prevents option ROMs from trapping interrupt 19.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
60 www.kontron.com
¾ Boot Device Priority
In the Boot Device Priority menu you define the sequence in which the system BIOS searches the drives for system files to
start the operating system.
List of devices available for use as boot devices: (the possible selection is depending on the system configuration).
10.5.1.9. 1
st
/ 2nd, / 3rd, .... / nth Boot Device
Available settings: [SATA: PS-WDC WD800AAJS-00PSA0]; [CD/DVD: PM-HL-DT-STDVD-ROM GDRH2];
[CD/DVD: PM-HL-DT-STDVD-ROM GDRH2]; [USB: Kingston DataTraveler]; [Network: B04 D00 Yukon PXE]; [Network: B03 D00
Yukon PXE] and Disabled.
Boot Devices (examples) Description
1st Boot Device SATA: PS-WDC WD800AAJS-00PSA0
Primary Slave (not included)
2nd Boot Device CD/DVD: PM-HL-DT-STDVD-ROM GDRH2
Primary Master (not included)
3rd Boot Device CD/DVD: PM-HL-DT-STDVD-ROM GDRH2
Secondary Master (not included)
4th Boot Device USB: Kingston DataTraveler
(not included)
5th Boot Device Network: B04 D00 Yukon PXE
(not included)
6th Boot Device Network: B03 D00 Yukon PXE
(not included)
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
www.kontron.com 61
10.6. Security
PCI-759 supports Supervisor and User password.
Valid password (Supervisor and User) can be a 1 to 6 alphanumeric characters combination.
If you are using both passwords the Supervisor password must be set first.
Keep a record of the new password when the password is changed. If you forget the password, you must
erase the system configuration information in NVRAM.
The system can be configured so that all users must enter a password every time the system boots or when BIOS Setup is
executed, using either or either the Supervisor password or User password.
The Supervisor and User passwords activate two different levels of password security.
If you select password support, you are prompted for a one to six character password. Type the password on the keyboard.
The password does not appear on the screen when typed. Make sure you write it down. If you forget it, you must drain
NVRAM and reconfigure.
10.6.1. Supervisor Password
This field indicates whether a supervisor password has been set.
If the password has been installed, Installed displays. If not, Not Installed displays.
10.6.2. User Password
This field indicates whether a user password has been set. If the password has been installed, Installed displays. If not,
Not Installed displays.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
62 www.kontron.com
10.6.2.1. Change Supervisor Password
Select this option and press <Enter> to access the sub menu.
You can use the sub menu to change the supervisor password. Select the “Change Supervisor Password” option from the
Security Setup menu and press <Enter>.
“Enter New Password:” input field appears. Valid password can be a 1 to 6 alphanumeric characters combination. Type the
password and press <Enter>. The screen does not display the characters entered. “Confirm New Password:” input field
appears. Retype the password as prompted and press <Enter>. If the password confirmation is incorrect, an error message
appears. The password is stored in NVRAM.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
www.kontron.com 63
If a Supervisor Password is installed two options are available:
“User Access Level” with following settings: Full Access, Limited, View Only, and No Access.
“Password Check” with following settings: Setup and Always.
10.6.2.2. Change User Password
Select this option and press <Enter> to access the sub menu.
You can use the sub menu to change the user password. Select Change User Password from the Security Setup menu and
press <Enter>.
“Enter New Password:” input field appears. Valid password can be a 1 to 6 alphanumeric characters combination. Type the
password and press <Enter>. The screen does not display the characters entered. “Confirm New Password:” input field
appears. Retype the password as prompted and press <Enter>. If the password confirmation is incorrect, an error message
appears. The password is stored in NVRAM.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
64 www.kontron.com
If a User Password is installed are available the “Clear User Password” option:
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
www.kontron.com 65
10.6.3. Boot Sector Virus Protection
With this field you can protect the boot sector against virus.
It is possible to choose between: Enabled and Disabled.
Enabled
The boot sector cannot be changed. A virus that attacks the boot sector cannot infect the system.
Select “Enabled” to enable boot sector protection. The system displays a warning when any program (or
virus) issues a Disk Format command or attempts to write to the boot sector of the hard disk drive.
If “Enabled”, the following appears when a write is attempted to the boot sector. You may have to type N
several times to prevent the boot sector write.
Boot Sector Write!
Possible VIRUS: Continue (Y/N)? _
The following appears after any attempt to format any cylinder, head, or sector of any hard disk drive via
the BIOS INT 13 Hard disk drive Service:
Format!!!
Possible VIRUS: Continue (Y/N)? _
Disabled
The boot sector could be changed. The protection is disabled.
Before installing an operating system you have to change this selection to “Disabled”. During
installation the first sector is written by the operating system. After the installation you can enable the
boot virus protection by set “Enabled”.
Boot Sector Virus is not very common today. Set this do not replace the anti-virus software.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
66 www.kontron.com
10.7. Chipset
All “Chipset” BIOS Setup options are described in this section. The “Chipset” BIOS Setup screen is shown below.
10.7.1. North Bridge Chipset Configuration
You can use this field to select options for the NorthBridge chipset configuration.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
www.kontron.com 67
10.7.1.1. DRAM Frequency
The available settings are: Auto, 400 MHz, 533MHz and 667 MHz.
10.7.1.2. Configure DRAM Timing by SPD
The available settings are: Enabled and Disabled.
10.7.1.3. Memory Hole
In order to improve performance, certain space in memory can be reserved for ISA cards. This memory must be mapped
into the memory space 15MB-16MB.
The available settings are: 15MB-16MB and Disabled.
10.7.1.4. Initiate Graphic Adapter
These settings allow you to select the graphics controller used as primary boot device.
The available settings are: IGD, PCI/IGD.
PEG: PCI Express Graphics
PCI: PCI Device
10.7.1.5. Internal Graphics Mode Select
This option allows you to select the amount of system memory used by the internal graphics device.
Available settings are: Enabled, 1MB, / Enabled, 8MB, / Disabled.
If the [Internal Graphics Mode Select] option is set to “disabled” the submenu [Video Function
Configuration] is not available (refer to the picture below).
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
68 www.kontron.com
¾ Video Function Configuration
10.7.1.6. DVMT Mode Select
This option allows you to select the DVMT operating mode.
Available settings are: Fixed Mode, DVMT Mode and Combo Mode.
10.7.1.7. DVMT/Fixed Memory
Available settings are: Maximum DVTM, 64MB and 128MB.
The option [DVMT/Fixed Memory] is not accessible when the option [DVMT Mode Select] is set
to Combo Mode.
10.7.1.8. Boot Display Device
This option allows you to select the boot display device.
Available settings are: Auto, CRT, LFP and CRT & LFP
10.7.1.9. Flat Panel Type
This option allows you to select the flat panel type.
Available settings are: 1024 x 756, 1280 x 1024, 1400 x 1050 and 1600 x 1200.
10.7.1.10. Local Flat Panel Scaling
This option allows you select the setting for flat panel scaling.
Available settings are: Auto, Force Scaling and Disabled.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
www.kontron.com 69
10.7.2. South Bridge Chipset Configuration
You can use this field to select options for the SouthBridge chipset configuration.
10.7.2.1. USB Function
This option allows you to enable or disable the host controllers.
Possible settings are: Disabled, 2 USB Ports, 4 USB Ports, 6 USB Ports and 8 USB Ports.
10.7.2.2. USB 2.0 Controller
This option allows you to enable or disable the EHCI USB controller function.
Possible settings are: Enabled and Disabled.
If this option “USB 2.0 Controller” is set to “Disabled”, the option “USB 2.0 Controller Mode”
(Advanced/USB Configuration) is not available.
10.7.2.3. Audio Controller
This option allows you to enable or disable the onboard audio.
The available settings are: Auto, AC’97 Audio and Modem, Azalia and All Disabled.
10.7.2.4. SMBUS Controller
This option allows you to enable or to disable the SMBUS controller.
Possible settings are: Enabled and Disabled.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
70 www.kontron.com
10.7.2.5. SLP_S4# Min Assertion Width
The available settings are: 1 to 2 seconds, 2 to 3 seconds, 3 to 4 seconds and 4 to 5 seconds.
10.7.2.6. Restore on AC Power Loss
This option allows you to specify the state the system should return to when power is restored after AC power loss.
The available settings are: Power Off and Power On.
10. AMI BIOS Configuration PCI-759 – User’s Guide (V1.02)
www.kontron.com 71
10.8. Exit
10.8.1. Save Changes and Exit
This field saves the settings you have made and exits BIOS Setup.
10.8.2. Discard Changes and Exit
This field exits BIOS Setup without saving the new settings.
10.8.3. Discard Changes
This field resets all values to those that were active when the computer was turned on without exiting BIOS Setup.
10.8.4. Load Optimal Defaults
This option allows you to load the default values of your system configuration. These default settings (manufacturing
settings) are optimal and enable all high performance features.
10.8.5. Load Failsafe Defaults
By this option the system can reload all default settings, which are permanently stored in the BIOS-ROM.
These settings are not the optimized default settings (manufacturing defaults) for your system, but can be used, if after
changes, the system does not run reliably. The Fail-Safe settings are designed for maximum stability, but not maximum
performance.
11. Technical Data PCI-759 – User’s Guide (V1.02)
72 www.kontron.com
11. Technical Data
PCI-759 Board Main Specification
Processor
Intel® Core™ 2 Duo or Celeron® S (45nm process technology)
Socket 775
For CPU frequency, please refer to the actually data sheet on the web page:
www.kontron.com
Board Type
PICMG 1.0 standard, full size
Memory Socket
2x 240-pin DDR2 DIMMs
Memory
Up to maximum 4GB of 400/533/667 MHz DDR2 SDRAM (dual channel), unbuffered, non-ECC;
DIMM Memory Type: (256 MB, 512MB), 1GB, 2GB.
Cache
Up to 4 MB Level 2 depending on the installed processor
Chipset
Intel® 945G Express Chipset Graphics and Memory Controller Hub (GMCH) with integrated
Graphics Media Accelerator 950 and Intel® ICH7
Gigabit Ethernet
Controllers
2x onboard Marvell LAN Controller
ISA Interface
PCI to ISA Bridge ITE8888G
LPC Super I/O
Winbond W83627EHF
BIOS
AMI BIOS PnP; ACPI 3.0; 4MB (32Mbits) Flash BIOS ROM
Watchdog
Time-out occurs after 255 seconds/minutes
Operating Systems
Information about the applicable operating systems refer to the web page:
www.kontron.com
or:
support@kontron.com
External Connectors
(on the slot bracket)
2x Ethernet (LAN1, LAN2) (10/100/1000 Mbps,
1x USB (2.0)
1x VGA
1x combined PS/2 keyboard and Mouse
Onboard Connectors
1x EIDE Ultra DMA, ATA/133 (CompactFlash shared for CompactFlash Type-II)
1x Floppy (FDD)
4x SATA II, 3Gbps
1x Mini PCI slot, 32-bit/33MHz PCI bus
2x Serial Port
1x COM1 (RS232)
1x COM2 (RS232) configurable RS422, RS485
1x Parallel Port
6x USB (2.0)
1x Audio interface connector (optional Audio daughter board)
1x Connector with support for:
1x Reset Button
1x HDD LED
1x External or internal Speaker
1x Connector with support for:
1x Power LED
1x Keyboard Lock
1x Power Button
1x I2C Bus SMB Data and Clock
1x Connector for ATX Power Control
2x 12V Fan Power Connector (4-pin)
1x 12V ATX Power Connector
1x LVDS
1x Lithium Battery Socket
The table is continued on the next page.
11. Technical Data PCI-759 – User’s Guide (V1.02)
www.kontron.com 73
Onboard Jumpers
1x Jumper for LCD (LVDS) power selection (+3.3V or +5.0V)
1x [CompactFlash Configuration (Master or Slave) as option]
1x RTC Reset (Clear CMOS)
Power Supply
Lithium battery 3.0 V for RTC, Type: CR2032
External ATX PSU and additional 12V ATX
Power via backplane and PICMG 1.0 edge connector: +12.0 V, +5.0 V
11.1. Electrical Specifications
Board
Version
Type of the external PSU Inputs via
Backplane +5.0 V, +12.0 V PCI-759 ATX PSU
On-board 12 V ATX power connector:
Power ATX
+12V
11.2. Mechanical Specifications
Dimensions
338.3 mm x 122 mm x 22.7 mm (13.33" x 4.8" x 0.89")
(height without CPU heatsink)
Weight
0.450 kg (0.992 lbs.) (without CPU fan)
11.3. Environmental Specifications
Operating Temperature
0 °C to 60 °C (32 °F to 140 °F)
Storage/Transport
Temperature
-40 °C to +70 °C (-40 °F to 158 °F)
Relative Humidity
5 % to 95 % (non-condensing)
Vibration
Frequency: 10 - 300 Hz Acceleration: 2 g
Cycle Count: 10/axis, 3 axis
Bump
Peak Acceleration: 15 g
Duration: 11 ms half sine
Shock Counts: 500 /direction
Shock
Peak Acceleration: 30 g
Shock Duration: 9 ms half sine
Shock Count: 3/direction, 6 directions
11. Technical Data PCI-759 – User’s Guide (V1.02)
74 www.kontron.com
11.4. CE Directives, Standards
CE Directives
Electrical Safety
General Product Safety Directive (GPSD) 2001/95/EC
Low Voltage Directive (LVD) 2006/95/EC
ElectroMagnetic
Compatibility (EMC)
EMC Directive 2004/108/EC
CE Marking Council Directive 93/68/EEC
Electrical Safety Harmonized Standards
EUROPE
Information technology equipment - Safety - Part 1: General requirements
EN 60950-1: 2006
U.S.A. / CANADA
UL Listing/Classification Mark File E147705
EMC Harmonized Standards
EUROPE
Generic emission standard for industrial environments (Emission):
EN 61000-6-4:2006
Generic standards - Immunity for industrial environments (Immunity):
EN 61000-6-2:2005
U.S.A. FCC 47 CFR Part 15, Class A
CANADA ICES-003, Class A
12. Declaration of Conformity PCI-759 – User’s Guide (V1.02)
www.kontron.com 75
12. Declaration of Conformity
13. Technical Support PCI-759 – User’s Guide (V1.02)
76 www.kontron.com
13. Technical Support
For technical support, please contact our Technical Support department.
German headquarter Hotline:
TEL: (+49) 8165-77 112
FAX: (+49) 8165-77 110
E-mail:
support-keu@kontron.com
Make sure you have the following on hand when you call:
• the unit part id number (P/No #),
• and the serial number (S/No #) of the unit (provide the serial number found on the label, placed on the rear side of
the board).
Be ready to explain the nature of your problem to the service technician.
If you have any questions about Kontron Europe or our products and services, you may reach us at the aforementioned
numbers, or at:
www.kontron.com or by writing to:
Kontron Europe GmbH
Oskar von Miller-Str. 1
85386 Eching
Germany
13.1. Returning Defective Merchandise
Before returning any merchandise please:
1. Download the form for returning a device with an RMA No. [RMA (Return of Material Authorization)] from our website
www.kontron.com / Support /RMA Information; contact our Customer Service department to obtain an RMA No.:
Fax: (+49) 8165-77 412
e-Mail:
service@kontron.com
2. Ensure that you have received an RMA No. from Kontron Customer Services before returning any device. Write this
number clearly on the outside of the package that you are sending to us.
3. Describe the fault that has occurred.
4. Please provide the name and telephone number of a person we can contact to obtain more information, where
necessary. Where possible, please enclose all the necessary customs documents and invoices.
5. When returning a device:
• Pack it securely in its original box.
• Enclose a copy of the RMA form with the consignment.
Corporate Offices
Europe, Middle East & Africa
Oskar-von-Miller-Str. 1
85386 Eching/Munich
Germany
Tel.: +49 (0)8165/ 77 777
Fax: +49 (0)8165/ 77 219
info@kontron.com
North America
14118 Stowe Drive
Poway, CA 92064-7147
USA
Tel.: +1 888 294 4558
Fax: +1 858 677 0898
info@us.kontron.com
Asia Pacific
17 Building,Block #1,ABP.
188 Southern West 4th Ring
Beijing 100070, P.R.China
Tel.: + 86 10 63751188
Fax: + 86 10 83682438
info@kontron.cn
Loading...
