KH 2024
21
Operating instructions
Page 5 - 14
1. General description
– Electronic digital radio receiver
– Power supply: 6.0V DC (Direct Current) from batteries
(4 x AA, LR6 1.5V, not supplied) or from an external
adapter 6.0-7.5V AC
– Precision quartz operation
– User-friendly operation using interactive LCD display
– Current time and day of the week display
– 24 hour mode display
– Integrated calendar with automatic year switching from
1950 to 2049
– World time display for 24 cities (see accompanying list
for codes)
– Remaining daylight display for local and world time,
individually programmable.
– Programmable time, date and world time displays.
– Two independent alarm settings, e.g. for weekday
and weekend alarm wake-up times
– Select between radio or tone alarms.
– Sleep Timer for up to 90 minutes.
– Radio with 40 preset memories (10 memory presets
per band)
– Station search buttons, automatic or manual,
forwards or backwards
– Memory search
– Weak battery display
– Button lock feature to prevent unintentional button
actuation.
5
1.1 Features
Telescopic aerial for FM and SW reception
Button lock
Alarm /wake-up setting 1 button
Snooze / radio OFF button
Sleep Timer / radio OFF button
Alarm /wake-up setting 2 button
Station preset save button
Setting buttons »Up« / »Down«
»Mem. Scan«
Mode select button »Mode«
Station presets 1-10
Weak battery display
LCD display
Ext. AC connector
Ext. headphone connector
Carrying strap
Band selector FM/SW/MW/LW
Volume control
Stand
Illumination button
21
Tuning short wave (SW)
Please read before you begin
Batteries:
This device requires 4 UM3/AA/LR6 1.5V batteries (not
supplied). Install the batteries in the battery compart-
ment as shown ("+" and "-"). Incorrect polarisation can
damage the equipment. Never use combinations of new
and used batteries.
If the device is disconnected from the mains, the stored
data can be retained if the connection is restored within
30 seconds. If not, the stored data will be lost, and the
stored information must be input again.
eak battery display :
W
This display lights up if the batteries are discharged.
The old batteries must be replaced with new ones as
soon as possible.
Adapter:
Inserting an adapter into the adapter connector
provides the device with a 6.0V supply. A suitable
universal DC adapter (6.0-7.5V) intended for use on
different equipment can be obtained from most
electrical suppliers.
6
Warning: Even when using an external adapter, you
should always have four UM3 batteries in the battery
compartment as a back-up in case of mains power failure.
Protect the equipment from moisture. Never put it on a
wet surface.
2. Operation
• When the device is switched on for the first time,
the date and time are set as 1 January 2001, 0:00 hours.
• The two alarm presets are both set to 0:00 hours, daily
wake-up, but are switched off.
• The radio is switched off.
• Followed by a change to automatic operation.
2.1 Automatic operation (Brief description)
• By pressing the »MODE« button you can call up the
various operating modes one after the other (with the
radio switched on or off):
Setting the time – date – city for local / world time -
• With the radio switched off you can also select date and
world time clock displays as alternatives to the local
time. For details see Section 2.13 'Alternative Displays'.
• In frequency display operation, the radio shows the
frequency range and band of the station currently being
received.
• Press »AL. 1« to set or check on alarm wake-up time 1.
• Press »AL. 2« to set or check on the alarm wake-up time 2.
• Press »SLEEP/RADIO ON« to activate the Sleep Timer
manually and set the remaining time or just press ON
once to turn on the radio
• Press »SNOOZE/RADIO OFF« to doze for a little while
longer (Snooze alarm function), or press OFF to switch
off the radio (see also Section 2.8).
• With the radio switched on, you can press the buttons
with more than one preset the appropriate number of
times to call up the saved setting (see also Section 2.9).
• With the radio switched on, press »SNOOZE/ RADIO
OFF« to interrupt the set sleep time or alarm wake-up
function.
• To store a station with the radio switched on, press
»MEMORY« and then the desired station preset button
and finally »MEMORY« again in order to store the
currently set station.
• With the radio switched on, press »MEM. SCAN« in
order automatically to call up the stored station preset
7
one after the other.
• At one minute intervals, the actual time is checked with
the alarm setting if this is activated. (for details see
Section 2.8 "Activated alarm setting").
2.2 Setting the clock
• Press »MODE« once if the device is in time display
mode.
• Press »MODE«
• The display shows 'CLOCK'.
• The time display starts to flash and the day of the
week disappears from the LCD.
• The seconds display continues to update every second.
• Press »UP« to increase the time setting by 1 minute.
Keep the »UP« button pressed to change the time quickly
in 10 minute increments.
• Press »DOWN« to decrease the time setting by 1 minute.
Keep the »DOWN« button pressed to change the time
quickly in 10 minute decrements.
• If within 15 seconds there has been no further setting
made, then the current settings are activated/stored
and the device goes once more into automatic operation.
twice if the device is in radio mode.
2.3 Date entry
• Press »MODE« twice if the device is in time display
mode.
• Press »MODE« three times if the device is in radio
mode.
• If the device is already in "Setting the clock" mode as
described in Section 2.2, you can enter "Date entry"
mode by pressing the »MODE«
• The existing set date DD.MM.YY (Day.Month.Year)
flashes, then the LCD shows a steady display of 'DATE'
as well as the day of the week.
• Press »UP« or »DOWN« in order to change the existing
setting (by a day at a time). Keep the »UP« or »DOWN«
button pressed to activate fast forward or fast backward
adjustment (by 10 days at a time). The day of the week
display is automatically activated as soon as the date
display is steadily illuminated again.
• If within 15 seconds there has been no further setting
made, then the current settings are activated and the
device goes back into automatic operation.
8
button once.
2.4 Setting the local time
• Press »MODE« three times if the device is in time
display mode.
• Press »MODE«
mode.
• If the device is already in "Date entry" mode as
described in Section 2.3, you can enter "Setting the local
time" mode by pressing the »MODE«
• The preset local time starts to flash. 'LOCAL CITY'
is displayed steadily.
• The hours, minutes and the day of the week displays
are not displayed here and the display is empty.
• By pressing »UP« or »DOWN« you can select the time
zone you require from the different codes. :
Code Time difference to CET City
LON 0:00 London
MUN + 1:00 München
CAI + 2:00 Kairo
MOW + 3:00 Moskau
DXB + 4:00 Dubai
KHI + 5:00 Karachi
four times if the device is in radio
button once.
DAC + 6:00 Dhaka
BKK + 7:00 Bangkok
HKG + 8:00 Hong Kong
TYO + 9:00 Tokyo
SYD +10:00 Sydney
NOU +11:00 Nouméa
WLG +12:00 Wellington
--- –11:00 --HNL –10:00 Honolulu
ANC – 9:00 Anchorage
LAX – 8:00 Los Angeles
DEN – 7:00 Denver
CHI – 6:00 Chicago
NYC – 5:00 New York City
CCS – 4:00 Caracas
RIO – 3:00 Rio de Janeiro
-1H – 2:00 ---
-2H – 1:00 ---
• The 'SUN' (sun symbol) display shows the remaining
daylight. Press the SNOOZE/RADIO OFF button
to activate the display.
• If within 15 seconds there has been no further setting
9
made, then the current settings are activated and the
device goes back into automatic operation.
is made within 15 seconds, the device shows the
frequency if the radio is on, or if not, the time again.
2.5 Checking the world time
• Press »MODE« four times if the device is in time
display mode.
• Press »MODE« five times if the device is in radio
mode.
• If the device is already in "Setting the local time" mode
as described in Section 2.4, you can enter "Checking the
world time" mode by pressing the »MODE«
once.
• The last time zone is displayed steadily in the hours and
minutes part of the display, while on the right the code
for the appropriate city starts to flash. The display
shows "CITY" above steadily.
• You can select the required time zone by pressing the
»UP« or »DOWN« buttons in accordance with the table
in Section 2.4.
• Press »SNOOZE« to change the display. The display
'SUN' shows the remaining daylight.
• If »MODE«
is pressed once, or if no further setting
button
2.6 Sleep Timer
• Press »SLEEP/RADIO ON« once to check the sleep
timer current setting. If the Sleep Timer is not activated,
then the display briefly shows "ON" (radio switched on).
• Press »SLEEP/RADIO ON« once again to change the
current setting. (in decrements of 10 minutes, from 9010 minutes). The radio remains switched on and the
selected band appears in the lower area of the LCD.
• Press »SLEEP/RADIO ON«
when the display reaches
desired number of minutes/duration for the Sleep Timer
(e.g. "10" for 10 minutes). "OFF" switches off the radio.
• If within 15 seconds there has been no further setting
made, then the current settings for the Sleep Timer are
activated and the device goes back into automatic
operation.
2.7 Setting ALARM 1 and ALARM 2
• Press the »AL. 1« or »AL. 2« button once. 'AL 1'
or 'AL 2' is displayed steadily in the alphanumeric
10
LCD display.
• The current setting HH.MM (hours:minutes) and the
day of the week display start to flash.
• Use »UP« to adjust the setting in increments of 1 minute.
• Use »DOWN« to adjust the setting in decrements of
1 minute.
• Keep the »UP« or »DOWN« button pressed to change
the time quickly in 10 minute increments or decrements.
• Press »SNOOZE« to change the alarm operation cycle
between daily (all seven days of the week) and
weekdays (Monday to Friday).
• Press the »AL. 1«
or »AL. 2« button again to select
either a music or tone wake-up alarm.
Wake-up type LCD display (on right in display)
Wake-up tone Symbol 'BELL 1'
Radio Symbol 'MUSIC 1'
Off Nothing displayed
Note: The alarm wake-up function is only activated if
one of the two wake-up types (music or tone) is set.
• If within 15 seconds, there has been no further setting
made then the current settings are activated and the
device goes back into automatic operation.
2.8 Alarm wake-up function
• When the actual time (clock) and the set alarm wake-up
time are identical, the alarm wake-up function is
switched on.
• When the alarm switches on, then the Sleep Timer,
if in operation, is immediately ended.
• Alarm with wake-up tone,
a) 4.5 kHz wake-up tone sounds
b) Radio is silenced, even if it is switched on.
c) The wake-up tone sounds for 10 minutes.
• Alarm with radio,
a) The radio switches itself on (the last selected station)
b) The radio plays for a maximum of 60 minutes
• By pressing the »SNOOZE/RADIO OFF«
put off the alarm wake-up by 9 minutes (Snooze alarm
function). The wake-up function is interrupted and
resumed after 9 minutes.
• To stop the alarm wake-up, press the appropriate »AL.1«
or »AL. 2« button.
11
button you can
2.9 Selecting radio presets
• There are 10 presets for each radio band.
• Each button can have two presets. In order to call up
the other preset, just press the button a second time.
• If the radio is switched on, press the station presets 1/6.
The display shows 'MEM' steadily, the frequency of
preset 1 appears steadily on the LCD and '1' appears
steadily on the 'MEM display.
• To select the required preset station, press the
appropriate button 1/6, 2/7, 3/8, 4/9 or 5/10.
• The radio is silenced (MUTE) during the preset setting
process. If the input of new preset data is interrupted
for 1 second, then the preset selection is accepted, the
radio changes to the corresponding frequency and
the muted mode ends.
2.10 Storing radio stations
• Press »MEMORY« once to save the frequency of the
radio station currently being received. The 'MEM'
display starts to flash.
• The particular preset is determined by pressing once
or twice on the appropriate preset station button.
The number of the selected preset is shown on the
'MEM display.
• Press »MEMORY« again to initiate the preset process.
The 'MEM' display shows steadily.
• When the 'MEMORY' display is flashing you can use
»UP«, »DOWN« or »MEM. SCAN« to search up and
down through the presets. The 'MEMORY' display is no
longer shown.
2.11 Station search manual /search process
• If the radio is on, press »UP« to increase the reception
frequency manually (for step sizes, see frequency steps
column in the table).
• Press »DOWN« in order to change the reception
frequency downwards (by a step at a time).
• Keep pressing on to »UP« or »DOWN« button for an
automatic search (search process) for the nearest
receivable radio station.
12
• Table of frequency bands and steps for each band. :
Band Frequency range Frequency steps
FM 87.5 - 108.5 MHz 50 kHz
SW 5.85 -15.6 MHz 5 kHz
MW 530 -1656 kHz 9 kHz
LW 144 - 281 kHz 1 kHz
2.12 Tuning short wave (SW)
Set the slide switch to LX if the reception of the station
is strong enough. Set the slide switch to RX to improve
the reception of weak short wave stations.
2.13 Preset search (MEMORY SCAN)
• If the radio is on, press »MEM. SCAN« once to go
through the 10 preset stations.
• The search process starts at the next preset or MEM-1
if no particular preset has been selected.
• The search process is stopped after 5 seconds for each
station.
• Press »SNOOZE /RADIO OFF« to terminate the preset
search.
2.14 Display mode
• In time display mode (with the radio switched off),
press »ALT. DISP.« once. The Time and day of the week
displays are not shown, the current displays are made
using 'CLOCK', 'DATE' and 'CITY'.
By the appropriate number of presses you can select
which display appears in addition to the time display.
If the radio is switched off, the selected displays appear
one after the other.
Display LCD display (right top in display)
Time display only Steady 'CLOCK' display only
Time + date Steady 'CLOCK' + 'DATE'
display only
Local time Steady 'CLOCK' + 'CITY'
and world time display only
Local time Steady 'CLOCK' + 'DATE' + 'CITY'
+date +world time display only
13
• Press »ALT. DISP.« to show all the selection options.
If no further button is pressed for 3 seconds, the normal
display is automatically activated.
• If the radio is switched on and in frequency display
mode, only the frequency of the station being received
is displayed irrespective of the display type selected
in the display mode.
2.15 Button lock
• Move the switch for the button cut lock into
the desired position:
UNLOCK = button lock OFF
LOCK = button lock activated
With the button lock on, the buttons have no effect.
2.16 Aerial
For improved reception in FM and SW bands,
pull out and extend the telescopic aerial fully,
turning it to get the best reception.
ML and LW use an internal ferrite antenna, so
you only need to rotate the device to get the best
reception.
2.17 Stand
The stand on the back of the device can be
folded out to provide the radio with a reliable stand.
14
3. Statement of conformity
We, Kompernaß Handelsgesellschaft mbH, Burgstr. 21,
D-44867 Bochum, Germany, hereby declare that this
product conforms with the following EC regulations:
EC low voltage regulations, Electromagnetic
compatibility, Applicable harmonised standards.
Type/Description: Digital world radio receiver KH 2024
Bochum, 31.01.2003
Hans Kompernaß
- Managing Director -
15
www.kompernass.com
© graphic design, photos and translations by ORFGEN · Essen / Germany
Loading...
