Page 1
Features
•
Pressure-balancing diaphragm technology maintains outlet
temperature within +/-3°F during water pressure fluctuations.
•
Antiscald protection.
•
A single handle controls both on/off activation and
temperature setting.
•
MasterClean™ sprayface features an easy-to-clean surface
that withstands mineral buildup.
•
Coordinates with other products in the Tone collection.
Material
•
Premium material construction with metal handle ensures
reliability and durability.
•
KOHLER finishes resist corrosion and tarnishing.
Installation
•
Requires Rite-Temp® pressure-balancing valve (sold
separately).
Water Conservation & Rebates
•
This product can help a building earn Water Efficiency points
in LEED® Green Building Rating System.
Required Products/Accessories
K-8304 Series Rite-Temp® Valve & Cartridge Kits
or
K-8300 Series Rite-Temp® Valve Body Rough-ins
K-8305 Series Rite-Temp® Cartridges
Adapters, Rough-in and Extension Kits
10350 Range: 3-1/2" (89 mm) -
4-1/4" (108 mm)
Recommended Products/Accessories
K-23723 Faucet cleaner
Optional Products/Accessories
K-10350 Deep rough-in kit
K-10351 Test cap for K-8300 Series valve bodies
1307346 Retro mixer cap for K-304 Rite-Temp valve
1362395 Retro mixer cap for K-2971 HiFlow Rite-Temp valve
Codes/Standards
ASME A112.18.1/CSA B125.1
DOE - Energy Policy Act 1992
EPA WaterSense
®
California Energy Commission (CEC)
KOHLER® Faucet Lifetime Limited
Warranty
See website for detailed warranty information.
Available Colors/Finishes
Color tiles intended for reference only.
Color Code Description
CP Polished Chrome
BN Vibrant® Brushed Nickel
BL Matte Black
2MB
Vibrant® Brushed Moderne
Brass
CBL
Matte Black with Polished
Chrome
BMB
Matte Black with Moderne
Brass
Tone™ Rite-Temp
Pressure-balancing shower faucet trim set
K-TS27420-4G
®
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-10-2022 14:13 - US/CA/LM/MX
Page 2
Tone™ Rite-Temp
*If 3-1/2" (89 mm) to
4-1/4" (108 mm) use
deep roughing-in kit.
K-8300 Valve
Series
Finished Wall
1/2 NPT
4-1/2"
(114 mm)
3-11/16"
(94 mm)
4-11/16"
(119 mm)
Ø 2-13/16"
(71 mm)
Ø 6-5/16"
(160 mm)
7-3/4"
(197 mm)
Typical
Technical Information
All product dimensions are nominal.
Drain included: No
Showerhead/Body Spray:
Rated maximum
flow:
1.75 gal/min (6.6 l/min)
Pressure: 45 psi (3.1 bar)
Notes
Install this product according to the installation
instructions.
®
Pressure-balancing shower faucet trim set
K-TS27420-4G
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-10-2022 14:13 - US/CA/LM/MX
