KC20
Camera
Camera subject to minor appearance and specification changes.
Getting to Know Your Camera
1
7
2
3
4
5
6
8
9
O
es
s
U
19
10
K
!
O
N
M
L
I
F
11
12
13
14
18
16
17
15
Contents
Need Help with Y our Camera?........................................... 2
Camera Identification ......................................................... 3
Specifications..................................................................... 4
Loading the Batteries ......................................................... 5
Loading the Film ................................................................ 6
Taking a Picture ................................................................. 10
Tips for Better Pictures....................................................... 12
Taking Flash Pictures ......................................................... 13
Unloading the Film ............................................................. 15
Troubleshooting.................................................................. 16
ENGLISH
1
Need Help with Your Camera?
Call:
Kodak in your country.
Visit our web site at http://www.kodak.com
For warranty purposes, please keep your sales receipt as proof of the
date of purchase.
2
© Eastman Kodak Company, 1998
Camera Identification (see inside front cover for diagrams)
1 Shutter Button
2 Picture Counter
3 Viewfinder
4 Flash
5 Lens
6 Lens-Cover Switch
7 Camera Strap
8 Film Spindle
9 Viewfinder Eyepiece
10 Flash-/Camera-Ready Light
11 Sprocket T eeth
12 Film Window
13 Film Door
14 Film-Load Mark
15 Battery-Door Latch
16 T ake-Up Spool
17 Film-Rewind Switch
18 Film Chamber
19 Film-Door Latch
3
Specifications
Type: Compact 35 mm fixed-focus camera
Lens: 29 mm, 3-element hybrid
Viewfinder: Reverse-Galilean
Aperture:
Film Speed: DX (ISO) 100–400 for color or black-and-white
Focus Range: Daylight: 4 ft. (1.2 m) to infinity
Flash Unit: Electronic flash with ISO 100/21°, guide
Flash Recycle Time: Approximately 6 sec with fresh batteries
Power Source: 2 AA-size alkaline batteries
Dimensions: 4.7 x 2.6 x 1.7 in. (120.4 x 65.2 x 43.7 mm)
Weight: 5.7 oz. (162 g)
4
f
/5.6
print film
number of 7.5 m; flash every time
Loading the Batteries
This camera uses 2 AA-size
alkaline batteries.
Low-Battery Warning
It’s time to replace the batteries
when—
• the flash- /camera-ready light takes
more than 30 seconds to turn on.
• the camera motor slows down or
will not run.
• the film will not advance.
Auto Power Off
This camera automatically turns
off after approximately 2–3 minutes
to conserve battery power when not
in use.
5
Loading the Film
If in sunlight, turn your back to the
sun and load the film in the shade
of your body.
1. Slide the FILM-DOOR
LATCH(19) down; then open
the FILM
DOOR (13).
6
2. Insert the film into the FILM
CHAMBER (18). Place the flat,
recessed end of the film over
the FILM SPINDLE (8). Push
the other end of the film down
into the film chamber until it
snaps into place.
3. Pull out just enough film to
place the end of the film at the
FILM-LOAD MARK (14).
Be sure the end of the film is
at the film-load mark or you
may not get any pictures.
FILM
LOAD MARK
FILM-GUIDE RAILS
Lay the film flat between the
film-guide rails.
If the end of the film extends past
the film-load mark, gently push
the excess back into the film
cartridge.
7
4. Snap the film door closed.
Y oushould be able to read the
film information in the FILM
WINDOW (12).
CAUTION: Do not open the film
door if you have film loaded in
the camera.
8
5. Slide the LENS-COVER
SWITCH (6) to uncover
the LENS (5) and turn the
camera on.
6. Press the SHUTTER
BUTTON (1) three times
so that the PICTURE
COUNTER (2) moves
to “1.”
NOTE: Because of limited space
on the picture counter, dots stand
for frames 2 and 3. Beginning at
frame 4, only even numbers show.
9
Taking a Picture
This camera features a flash that,
when the flash-ready light glows,
will fire every time you take a
picture. The all-the-time flash
feature acts as fill flash in hazy
outdoor pictures or in bright-light
conditions where shadows
may exist.
10
1.Slide the LENS-COVER
SWITCH (6) open until it locks
into place. The camera will not
work if the lens cover is not
completely open.
2. For a sharp picture, be at least
4 ft (1.2 m) from your subject.
4 ft.
(1.2 m)
3. Look through the
VIEWFINDER
EYEPIECE
see your subject.
(9) to
VIEWFINDER
4. Hold the camera steady and
gently press the SHUTTER
BUTTON (1) to take a picture.
Wait for the FLASH-/CAMERAREADY LIGHT (10) to turn “on”
before you take the picture.
11
The flash automatically fires
when you take a picture (see
Taking Flash Pictures). Do
not block the lens or flash
with your fingers, strap, or
any other object.
5. The film automatically
advances so you can take your
next picture.
12
Tips for
Better Pictures
• Keep your pictures simple.
Move close enough to your
subject, so the subject fills the
viewfinder but not closer than
4 ft (1.2 m).
• Take pictures at the subject’s
level. Kneel down when taking
pictures of children, pets, etc.
• Hold your camera vertically to
capture tall, narrow subjects,
such as a waterfall, skyscraper,
or single person.
• Add interest to your picture by
framing your subject with a tree
branch, window, or even the
rails of a fence.
• Keep the sun behind you. This
provides the best subject
illumination.
Taking Flash Pictures
In dim light, such as indoors or
outdoors in heavy shade, or on
dark overcast days, you need
flash. Y our camera features an
automatic flash that, when the
flash-ready light glows, will fire
every time you take a picture.
1. Slide the LENS-COVER
SWITCH (6) open to turn the
camera on.
13
2. When the FLASH- /CAMERA-
READY LIGHT (10) turns “on”,
you are ready to take the
picture.
ISO Film Speed Flash-to-Subject Distance
100 4 to 9 ft (1.2 to 2.8 m)
200 4 to 13 ft (1.2 to 4.0 m)
400 4 to 18 ft (1.2 to 5.5 m)
14
3. Keep the subject within the
distance range for the speed of
the film in your camera. Do not
block the flash or lens with
your fingers, strap, or any
other object.
Unloading the Film
After you take the last picture on
the roll of film, slide the FILMREWIND SWITCH (17) into
position to start the film rewind. You
may get a few extra pictures on a
roll (26 instead of 24, etc.). Wait for
the camera motor to stop before
you open the FILM DOOR (13) and
remove the film cartridge.
Using Mid-Roll Rewind
If you don’t want to take pictures on
the entire roll of film, you can
rewind the film manually. Slide the
FILM-REWIND SWITCH (17) in
until it latches
and remains in
the on position.
Wait for the
camera motor to
stop before you
remove the film cartridge.
NOTE: You cannot reload the film
into the camera for continuous
picture-taking.
15
Troubleshooting
What happened Probable cause Solution
Camera will Lens cover closed Slide the lens-cover
not operate switch to uncover lens
Batteries weak, Replace or reload the
dead, missing, or batteries; see Loading
improperly inserted the Batteries
16
and turn on camera
What happened Probable cause Solution
Picture counter Film door opened Close film door and
returns to “0” rewind film to avoid
losing additional
pictures
Film does not Batteries weak, Replace or reload the
advance dead, missing, or batteries; see Loading
improperly inserted the Batteries
Film not loaded See Loading the Film
properly
17
What happened Probable cause Solution
Film does Film did not See Loading the Film
not rewind load properly
Batteries weak, Replace or reload the
dead, missing, or batteries; see Loading
improperly inserted the Batteries
Flash- /camera- Batteries weak Replace with fresh AAready light fails size alkaline batteries
to turn on within
30 seconds
18
Kodak is a trademark.
Consumer Imaging
EASTMAN KODAK COMPANY
Rochester, NY 14650
Pt. No. 7C4218 1-98
Printed in USA
