KODAK EASYSHARE C142
Digital Camera
Extended user guide
www.kodak.com
For interactive tutorials:
www.kodak.com/go/howto
For help with your camera:
www.kodak.com/go/c142support
Eastman Kodak Company
Rochester, New York 14650
© Eastman Kodak Company, 2009
All screen images are simulated.
Kodak and EasyShare are trademarks of Eastman Kodak Company.
4H6813_en
Front view
Lens
Microphone
Flash
Self-timer/
Video light
A/V
Out
Zoom (Wide
Angle/Telephoto)
lever
Power button
Flash button
Mode button
Shutter button
Product features
IMPORTANT:
Your camera offers a built-in Help system. See page 38.
www.kodak.com/go/support
i
Product features
OK
Battery compartment,
SD/SDHC Card slot
LCD
Share button
USB port
Delete, Menu, Info,
Review buttons
Strap post
Tripod
socket
Back view
IMPORTANT:
Your camera offers a built-in Help system. See page 38.
ii www.kodak.com/go/support
Table of contents 1
1 Setting up your camera .........................................................................1
Attaching the strap .......................................................................................1
Loading the AA batteries...............................................................................1
Turning on the camera ..................................................................................2
Setting the language and date/time...............................................................2
Storing pictures on an optional SD or SDHC Card...........................................3
2 Taking pictures/videos ...........................................................................4
Taking pictures.............................................................................................. 4
Taking a video .............................................................................................. 5
Understanding the picture-taking icons..........................................................6
Know when your batteries need attention......................................................6
Using the optical zoom..................................................................................7
Using the flash..............................................................................................8
Using different modes ...................................................................................9
Using shortcuts ...........................................................................................11
Using the self-timer.....................................................................................12
Using burst .................................................................................................12
3 Sharing and tagging pictures ..............................................................13
Sharing through social networks..................................................................13
Tagging pictures .........................................................................................15
Marking pictures/videos for emailing ...........................................................16
4 Reviewing and editing .........................................................................17
Reviewing pictures/videos ........................................................................... 17
Deleting pictures/videos ..............................................................................18
Viewing pictures/videos in different ways..................................................... 19
A smarter way to find and enjoy your pictures..............................................20
Understanding the review icons................................................................... 21
Creating a slide show..................................................................................22
www.kodak.com/go/support iii
Table of contents
Displaying pictures/videos on a television.....................................................23
Using the menu button in review.................................................................24
Cropping pictures........................................................................................24
Rotating pictures.........................................................................................25
Editing videos .............................................................................................26
Selecting multiple pictures/videos ................................................................ 27
Copying pictures/videos...............................................................................27
5 Doing more with your camera .............................................................28
Using the menu button to change settings...................................................28
Using the Setup menu.................................................................................32
6 Transferring, printing pictures .............................................................34
Download software, transferring pictures.....................................................34
Printing pictures..........................................................................................35
Marking your pictures for printing................................................................37
7 Troubleshooting ..................................................................................38
Getting help from your camera....................................................................38
Troubleshooting.......................................................................................... 39
Getting help on the Web.............................................................................43
8 Appendix .............................................................................................44
Camera specifications ................................................................................. 44
Care and maintenance ................................................................................ 46
Upgrading your software and firmware........................................................46
Storage capacities.......................................................................................47
Important safety instructions .......................................................................47
Battery replacement, battery life..................................................................48
Limited warranty .........................................................................................49
Regulatory compliance ................................................................................50
iv www.kodak.com/go/support
1 Setting up your camera
Attaching the strap
Loading the AA batteries
Purchase extra batteries for your special event www.kodak.com/go/c142accessories
www.kodak.com/go/support 1
Setting up your camera
to change current field.
for previous/next field.
OK
to accept.
At the prompt, press OK.
to change.
OK
to accept.
Language:
Date/Time:
Turning on the camera
Setting the language and date/time
NOTE: To change language in the future, use the Setup Menu (see page 32).
2 www.kodak.com/go/support
Setting up your camera
CAUTION:
1
Turn off the camera.
2
3
Turn on the camera.
Insert the card.
Push it until it clicks.
Storing pictures on an optional SD or SDHC Card
Your camera has internal memory. We recommend purchasing an SD or SDHC Card to
conveniently store more pictures/videos.
A card can only be inserted one way; forcing it may cause
damage. Inserting or removing a card while the camera is on may
damage the pictures, the card, or the camera.
Purchase accessories www.kodak.com/go/c142accessories
www.kodak.com/go/support
3
2 Taking pictures/videos
Framing marks
Taking pictures
To get clear, focused pictures:
1 The camera turns on in Smart Capture mode.
(If it’s in a different mode, press the Mode button,
2 Compose the picture.
3 Press the Shutter button halfway to focus and
Using the framing marks
Framing marks indicate the camera focus area.
1 Press the Shutter button halfway.
2 Press the Shutter button completely down to
then until the LCD displays
mode , then press OK.)
set exposure. When the framing marks turn green,
press the Shutter button completely down.
If the camera is not focusing on the desired subject,
release the Shutter button and recompose the scene.
Smart Capture
IMPORTANT:
4 www.kodak.com/go/support
Your camera offers a built-in Help system. See page 38.
take the picture.
NOTE: Multiple framing marks may appear when faces are detected.
Taking a video
Delete the current picture/video
OK Play/pause a video
While a picture/video is displayed,
you may:
Taking pictures/videos
1 Press the Mode button, then until the LCD
displays
2 Press the Shutter button completely down,
then release it. To stop recording, press and release
the Shutter button again.
To review and work with videos, see page 17.
Video , then press OK.
Reviewing the picture/video just taken
After you take a picture/video, the LCD briefly displays the picture or the first frame of
a video. (To take new pictures/videos sooner, press the Shutter button halfway.)
NOTE: Audio is captured during video recording. Audio can be heard when the video is played on a
computer or when the camera is connected to a TV (see page 23).
To review pictures/videos anytime, see page 17.
www.kodak.com/go/support
5
Taking pictures/videos
Battery level
Capture mode
Pictures/time remaining
Zoom indicator
Keyword tag
Self timer
Flash mode
Focus mode
Exposure compensation
Understanding the picture-taking icons
Know when your batteries need attention
The battery level icon works like the gas gauge in your car, but appears only when the
battery requires your attention. (If you’re viewing shortcuts, the battery level is always
displayed. See page 11.)
Purchase extra batteries for your special event www.kodak.com/go/c142accessories
6 www.kodak.com/go/support
Using the optical zoom
1 Use the LCD to frame your subject.
2 To zoom in, turn the Zoom lever toward Telephoto
(T). To zoom out, press it toward Wide Angle (W).
3 Take the picture.
NOTE: For focus distances, see Specifications starting on page 44.
Taking pictures/videos
Using digital zoom
Use digital zoom to get up to 5X magnification beyond optical zoom. (Digital zoom is
not available in Smart Capture mode.) Press Telephoto (T) until the slider on the LCD
is at the end of the optical zoom range. Release Telephoto (T), then press it again.
NOTE: You may notice decreased image quality when using digital zoom.
www.kodak.com/go/support
7
Taking pictures/videos
Using the flash
Press the Flash button repeatedly until the LCD displays the desired flash mode.
Flash modes Flash fires
Auto When the lighting conditions require it.
Fill (Flash On) Every time you take a picture, regardless of the lighting
conditions. Use when the subject is in shadow or is “backlit”
(when the light is behind the subject).
NOTE: (Not available in Smart Capture mode.)
Red-eye
Reduction
Choose a setting
in the Setup
menu, page 32.
Preflash The flash fires before the picture is taken to reduce the chance
of red-eye.
Digital
Correction
The camera digitally corrects red-eye after a picture is taken.
(Processing time after taking a picture may increase.)
NOTE: When using digital correction, image processing takes longer
than when using preflash.
Off Never
8 www.kodak.com/go/support
Taking pictures/videos
Using different modes
Press the Mode button, then until the LCD displays the mode that best suits
your subjects and surroundings,
Use this mode For
General picture taking—it offers excellent image quality and ease
of use.
■ Faces get focus and exposure priority.
■ The scene is analyzed for other content and for lighting.
Smart
You can choose the best picture size and aspect ratio for your
Capture
needs—just press the Menu button and choose Picture Size.
then press OK.
■ 3:2 (the best choice when making 4 x 6 prints)
■ 16:9 (wide screen)
■ 4:3 (the default setting)
Program
Scene
Video
Advanced picture taking—allows more access to manual settings
than Smart Capture.
Point-and-shoot simplicity when taking pictures in practically any
situation. (See page 10.)
Capturing video with sound.
played on a computer or when the camera is connected to a TV
page 5.)
www.kodak.com/go/support
Audio can be heard when the video is
(see
9
Taking pictures/videos
Using Scene (SCN) modes
Choose a Scene mode—for great pictures in practically any situation.
1 Press the Mode button, then until the LCD displays SCN,
then press OK.
2 Press to view scene mode descriptions.
If the mode description turns off before you finish reading it, press OK.
3 Press OK to choose a Scene mode.
SCN mode For
Portrait Full-frame portraits of people.
Sport Action pictures.
Blur Reduction Reducing blur caused by camera shake or subject motion.
Landscape Distant scenes.
High ISO People indoors, in low-light scenes.
Close-up Close range. Use available light instead of flash, if possible.
Flower Close-ups of flowers or other small subjects in bright light.
Sunset Subjects at dusk.
Backlight Subjects that are in shadow or “backlit.”
Candle Light Subjects illuminated by candle light.
Children Action pictures of children in bright light.
Manner/
Museum
Text Documents. For best results, place the camera on a steady surface or
Beach Bright beach scenes.
Snow Bright snow scenes.
Fireworks Fireworks. For best results, place the camera on a steady surface or
Quiet occasions, like a wedding or lecture. Flash is off. For best results,
place the camera on a steady surface or tripod.
tripod.
tripod.
10 www.kodak.com/go/support
Taking pictures/videos
Press to
show/hide
shortcuts.
Shortcuts
SCN mode For
Self-Portrait Close-ups of yourself. Assures proper focus and minimizes red eye.
Night Portrait Reduces red eye of people in night scenes or low-light conditions.
Night Landscape Distant scenery at night. Flash does not fire.
Panning Shot Emphasizing horizontal motion, with a sharp subject and blurred
background.
Using shortcuts
Your camera has a clean, uncluttered interface. For quick access to the most popular
capture and review functions:
1 Press the Info button.
The shortcuts appear. To hide the shortcuts again, press .
2 Press to access functions like Exposure Compensation, Self-timer, and Auto
focus. (You’ll see different functions in different modes.)
3 Press to choose a setting.
www.kodak.com/go/support
11
Taking pictures/videos
10
2
2x
Using the self-timer
Use the self-timer when you want to be included in a picture, or to ensure a steady
Shutter button press. For best results, place the camera on a tripod or steady surface.
You can turn on the self-timer using a shortcut (see page 11) or these steps:
1 Press the Menu button. Press to choose Self-timer, then press OK.
2 Press to choose a Self-timer setting:
10 Seconds— A picture is taken after a 10-second delay (so you have time
to get into the scene).
2 Seconds— A picture is taken after a 2-second delay.
2 Picture Timer— The first picture is taken after a 10-second delay. A
second picture is taken 8 seconds later.
3 Compose the scene. Press the Shutter button halfway, then completely down.
The camera takes the picture/pictures after the delay.
To take a video after a 2- or 10-second delay, use the same procedure but press the
Shutter button completely down.
Using burst
Use the burst feature to take up to 3 pictures in rapid succession. You can turn on
burst using a shortcut (see page 11) or these steps:
1 Press the Menu button.
2 Press to choose Self-timer/Burst, then press to choose Burst On.
3 Press the Menu button.
4 Compose the scene. Press the Shutter button halfway, then completely down
and hold it.
The camera stops taking pictures when you release the Shutter button, when pictures
are taken, or when there is no more storage space. Burst is unavailable in some modes.
12 www.kodak.com/go/support
3 Sharing and tagging pictures
Sharing through social networks
It’s never been easier to share pictures on your favorite social networking sites.
IMPORTANT:
1 Press the Review button, then to find a picture.
2 Press the Share button.
If it’s your first time, a Help screen appears.
3 Press to choose a social networking site, then press OK.
A check mark appears. Repeat this step to choose more sites. (Press OK again to clear a
check mark.)
4 Press to choose Done, then press OK.
The picture is displayed with the Share icon. When you transfer the picture to your
computer, it will be sent to the networking site(s) that you chose.
Tip: Do you send pictures to the same sites each time?
Find a picture, then press and hold the Share button for about 1 second.
To use the camera’s social networking features, you need to download
KODAK Software. (See page 34.)
The camera applies the settings that you used previously and adds the Share icon to the
picture.
www.kodak.com/go/support 13
Sharing and tagging pictures
Choose which social networking sites to display on your camera
You can show/hide networking sites on your camera so that only your favorite sites
appear.
1 In Review, press the Menu button.
2 Press to choose the Setup tab, then to choose Share Button Settings,
then press OK.
3 Press to choose a social networking site, then press to choose Show or
Hide. Repeat this step until you have chosen Show/Hide for each social network.
4 When finished, press to choose Done, then press OK.
To return to picture-taking mode, press the Shutter button halfway down. When you
are in Review and press the Share button, only chosen sites are shown.
Manage email addresses and KODAK PULSE Digital Frames
You can add, edit, or delete email addresses and KODAK PULSE Digital Frames on
your camera.
1 In Review, press the Share button. Press to choose Manage Email
Addresses (or Manage Frames), then press OK.
2 To add an email address or frame, press to choose Add Email or Add Frame,
then press OK. Use the on-screen keyboard to make the addition.
(Example: JohnDoe@domain.com)
To edit an email address or a KODAK PULSE Digital Frame, press to choose
the address’s nickname or the frame, then press OK. Use the on-screen keyboard
to make edits.
To delete an email address or frame, choose Delete Email or Delete Frame, then
press OK. Press to choose the address or frames, then press OK so that a
check mark appears. Press to choose Delete, then press OK.
3 When finished, press to choose Done, then press OK.
To return to picture-taking mode, press the Shutter button halfway down.
14 www.kodak.com/go/support
Sharing and tagging pictures
Tagging pictures
You can tag pictures with a keyword to make them easy to find, later.
1 Press the Review button, then to find a picture to tag.
2 Press the Menu button. Press to choose Keyword Tag, then press OK.
3 Press to choose an existing keyword, or New Keyword (See Using the
keyboard) to add a new one.
4 Press to add keywords to other pictures. When finished, press to
choose Done, then press OK.
To return to picture-taking mode, press the Shutter button halfway down.
Tip: You can pre-choose a tag so that new pictures are assigned that tag (see
page 29).
Using the keyboard
The keyboard appears when you need to add keywords and email addresses.
1 Press to choose a letter, then press OK.
2 When finished, press to choose OK, then press OK.
www.kodak.com/go/support
15
Sharing and tagging pictures
Marking pictures/videos for emailing
It’s simple to mark pictures so that they’re ready to email when you transfer them to
your computer. First, create a new email address. (See Using the keyboard, page 15.)
1 Press the Review button. Press to find a picture.
2 Press the Share button.
3 Press to choose Email, then press OK.
4 Press to find an email address, then press OK.
To mark other pictures/videos with the same address, press , then press OK.
To send the pictures/videos to more than one address, repeat step 4.
To return to picture-taking mode, press the Shutter button halfway down.
When you transfer the marked pictures/videos to your computer, the software prompts
you to send the pictures/videos.
IMPORTANT:
Your camera offers a built-in Help system. See page 38.
16 www.kodak.com/go/support
4 Reviewing and editing
4X
4X
1X2X 2X
Playback speed
Reviewing pictures/videos
1 Press the Review button.
2 Press for previous/next picture/video.
■ To exit, press the Review button or press the
Shutter button halfway down.
■ To view pictures/videos as thumbnails, press the
Wide Angle (W) button. (For more information,
see page 19.)
Find your pictures like a pro...
See “A smarter way to find and enjoy your pictures” on page 20.
Playing a video
Press OK to play a video. Press OK to pause/resume.
During playback:
■ Press to play at 2X speed; press again for 4X.
■ Press to reverse at 2X speed; press again for 4X.
NOTE: Audio can be heard when the video is played on a computer
or when the camera is connected to a TV (see page 23).
www.kodak.com/go/support 17
Reviewing and editing
CAUTION:
Deleting pictures/videos
1 Press the Review button.
2 Press for previous/next picture/video.
3 Press the Delete button.
4 Follow the screen prompts.
NOTE: To delete protected pictures/videos, remove protection before deleting. (See Protecting
pictures/videos from deletion.)
Using the undo delete picture feature
If you accidentally delete a picture, you may be able to use Undo Delete to retrieve it.
This feature is only available immediately after you delete a picture.
Protecting pictures/videos from deletion
1 Press the Review button.
2 Press the Menu button.
3 Press to choose Protect, then press OK.
4 Press to choose Protect, then press OK.
A check mark indicates that the picture/video is protected. Clicking OK again removes
the check mark. Press to protect other pictures/videos, or press to choose
Done, then press OK.
■ Press the Menu button to exit the menu.
Formatting internal memory or an SD or SDHC Card deletes all (including
protected) pictures/videos. (Formatting internal memory also deletes
email addresses and keyword tags.)
18 www.kodak.com/go/support
Reviewing and editing
Viewing pictures/videos in different ways
Magnifying a picture
1 Press the Zoom lever toward Telephoto (T) to
magnify 1X–8X.
2 Press to view other parts of a picture.
■ Press OK to return to 1X.
Viewing as thumbnails (multi-up)
1 Press the Review button.
The camera shows the last picture that was taken.
2 Press the Zoom lever toward Wide Angle (W)
button to view pictures/videos as thumbnails. (Press
it again to see more, smaller thumbnails.)
To view all pictures/videos, choose the All tab.
To sort by favorites, date, or tagged pictures/videos,
press and choose the appropriate tab.
3 To see a single picture/video, press to
choose it. Then press the Zoom lever toward
Telephoto (T) button.
■ To select multiple pictures/videos, see Selecting
multiple pictures/videos.
www.kodak.com/go/support
■ Press the Review button to exit Review.
19
Reviewing and editing
Keywords
Favorites
Date
All
A smarter way to find and enjoy your pictures
Tag pictures with a keyword to make them easy to find, later. You can also find
pictures by date taken or if it’s marked as a favorite.
1 Press the Review button.
2 Press the Wide Angle (W) button to view pictures by thumbnail (or choose View
Thumbnails shortcut).
3 Press to choose a tab and sort pictures by All, Date, Favorite, or
Keyword.
4 Press to choose a keyword, then press OK.
Press Telephoto (T) see pictures in a stack or to see an individual picture. Press Wide
Angle (W) to see thumbnails or picture stacks.
To return to picture-taking mode, press the Shutter button halfway down.
Tip: For best results, make sure the camera’s date/time is current (see page 32).
20 www.kodak.com/go/support
Understanding the review icons
Email
Favorite
Print/number of prints
Protected
Picture/Video number
Upload
Video duration
Select
picture/video
Battery level
Text tag
Add text tag
View thumbnails
Play video
Shortcuts*
Reviewing and editing
* For more about shortcuts, see page 11.
Know when your batteries need attention
The battery level icon works like the gas gauge in your car, but appears only when the
battery requires your attention. (If you’re viewing shortcuts, the battery level is always
displayed. See page 11.)
Purchase extra batteries for your special event www.kodak.com/go/c142accessories
www.kodak.com/go/support
21
Reviewing and editing
Creating a slide show
Use Slide Show to display your pictures/videos on the LCD. You can play all
pictures/videos, or choose pictures to include in the slide show.
Make a slide show
1 Press the Review button. Select pictures (see page 27). If you don’t select any,
then all pictures will be shown.
2 Press the Menu button.
3 Press to choose Slide Show, then press OK.
Each picture/video is displayed once. To interrupt the slide show, press OK.
IMPORTANT:
Your camera offers a built-in Help system. See page 38.
Play a slide show loop
When you turn on Loop, the slide show is continuously repeated.
1 On the Slide Show menu, press to choose Loop, then press OK.
2 Press to choose On, then press OK.
3 Press to choose Preview Slide Show, then press OK.
The slide show repeats until you press OK or until the batteries are exhausted.
22 www.kodak.com/go/support
Reviewing and editing
Displaying pictures/videos on a television
You can display pictures/videos on a television, computer monitor, or any device
equipped with a video input. To connect the camera directly to a television, use an
A/V cable (may be sold separately).
Purchase accessories www.kodak.com/go/c142accessories
NOTE: To control the audio portion of a video, use the TV (or TV remote control) volume controls. Ensure
that the Video Out setting (NTSC or PAL) is correct (see page 32). The slide show stops if you
connect or disconnect the cable while the slide show is running. (Image quality on a television
screen may not be as good as on a computer monitor or when printed.)
www.kodak.com/go/support
23
Reviewing and editing
Cropped picture
Using the menu button in review
1 Press the Review button, then the Menu button.
2 Press to choose a tab:
■ Review
■ Edit
■ Setup
3 Press to choose a setting, then press OK.
4 Choose an option, then press OK.
IMPORTANT:
Your camera offers a built-in Help system. See page 38.
Cropping pictures
You can crop a picture so that only the desired portion of the picture remains.
1 Press the Review button, then to find a
picture to crop.
2 Press the Menu button, then to choose the
Edit tab. Choose Crop, then press OK.
3 Press the Zoom lever toward Telephoto (T) to shrink the crop area or Wide (W) to
stretch it. Press to move the crop box. When satisfied with the crop
box, press OK.
4 Follow the screen prompts.
The picture is cropped. (The original is saved.) Cropped pictures cannot be cropped
again on the camera.
Press the Shutter button halfway down to return to Capture mode.
IMPORTANT:
Your camera offers a built-in Help system. See page 38.
24 www.kodak.com/go/support
Reviewing and editing
Rotating pictures
You can rotate a picture to portrait or landscape orientation.
1 Press the Review button, then to find the previous/next picture.
2 Press the Menu button. Press to highlight the Edit tab.
3 Press to highlight Rotate Picture, then press OK.
4 Press to highlight an option:
■ Rotate Right—rotates the picture 90 degrees clockwise.
■ Rotate Left—rotates the picture 90 degrees counterclockwise.
5 Press OK. Follow the screen prompts to replace the original picture or to save the
rotated picture as a new one.
Press the Shutter button halfway down to return to Capture mode.
IMPORTANT:
Your camera offers a built-in Help system. See page 38.
www.kodak.com/go/support
25
Reviewing and editing
Video
Video
Trimmed vid eo
Editing videos
You can do incredible things with your videos.
Making a picture from a video
You can choose a single frame from a video, then make a picture suitable for a
4 x 6-inch (10 x 15 cm) print.
1 Press the Review button, then to find a
video.
2 Press the Menu button, then to choose the
Edit tab. Choose Make Picture, then press OK.
3 Follow the screen prompts.
A picture is created. (The original video is saved.) Press
the Shutter button halfway down to return to Capture
mode.
IMPORTANT:
Your camera offers a built-in Help system. See page 38.
Trimming a video
You can remove an unwanted start or end from a video, saving only the desired
portion.
1 Press the Review button, then to find a
video.
2 Press the Menu button, then to choose the
Edit tab. Choose Trim, then press OK.
3 Follow the screen prompts.
The video is trimmed. (You can save it as a new video
26 www.kodak.com/go/support
or replace the original.) Press the Shutter button
halfway down to return to Capture mode.
Reviewing and editing
Selected
pictures
Selecting multiple pictures/videos
Use the multi-select feature when you have two or more pictures/videos to print,
transfer, delete, etc. Multi-select is used most effectively in Multi-Up mode, Viewing as
thumbnails (multi-up).
1 Press the Review button, then (and
if you’re in multi-up mode) to find a picture/video.
2 Press OK to select pictures/videos.
A check mark appears on the picture. (Press OK again
to remove a check mark.) You can now print, transfer,
delete, etc. the selected pictures.
Copying pictures/videos
You can copy pictures/videos from a card to internal memory or from internal memory
to a card.
Copy pictures/videos:
1 Press the Review button, then to find a picture. (You can also use
multi-select. See “Selecting multiple pictures/videos” on page 27.)
2 Press the Menu button, then to choose the Edit tab.
3 Press to choose Copy, then press OK. Make a choice, then press OK.
NOTE: Pictures/videos are copied, not moved. To remove pictures/videos from the original location after
copying, delete them (see page 18).
IMPORTANT:
Your camera offers a built-in Help system. See page 38.
www.kodak.com/go/support
27
5 Doing more with your camera
IMPORTANT:
Your camera offers a built-in Help system. To get the most from your
camera, see page 38.
Using the menu button to change settings
You can change settings to get the best results from your camera.
NOTE: Some modes offer limited settings. Some settings remain until you change them; others, until you
change modes or turn off the camera.
1 Press the Menu button.
2 Press to choose a tab:
■ Capture/Video for the most common picture- and video-taking settings
■ Setup for other camera settings
3 Press to choose a setting, then press OK.
4 Choose an option, then press OK.
Using the capture tab
Press Menu, , ,
and OK to access settings
Picture Size
Choose a picture resolution.
28 www.kodak.com/go/support
Picture-taking Options
See Camera specifications, page 44.
Doing more with your camera
Press Menu, , ,
and OK to access settings
Self-timer/Burst
Choose Self-timer or Burst
feature.
Preset Keyword Tag
Create keywords and assign
them to pictures/videos. See
page 37.
Exposure Compensation
Make a picture lighter or
Picture-taking Options
Off
10 Seconds
2 Seconds
2 Picture Timer
Burst On—Press the Shutter button halfway to focus and
set exposure. Press the Shutter button completely down
and hold it to take up to 3 pictures.
New Keyword
Delete Keyword
See Camera specifications, page 44.
darker. (Available in Program
mode.) To access this feature
with a shortcut, see page 11.
ISO Speed
Control the sensitivity of the
camera sensor.
Long Time Exposure
Choose how long the shutter
stays open (normally in
low-light conditions). For best
results, place the camera on a
tripod or steady surface.
Auto—For general picture taking.
For manual settings, see Camera specifications, page 44.
None
0.5, 1.0, 2.0, 4.0, 8.0 seconds
www.kodak.com/go/support
29
Doing more with your camera
Press Menu, , ,
and OK to access settings
Color Mode
Choose color tones.
Unavailable in Video and
Smart Capture modes.
White Balance
Choose your lighting
condition. (Available only in
Program mode.)
Picture-taking Options
High Color
Natural Color
Low Color
Black & White
Sepia—For a reddish-brown, antique look.
Auto—Automatically corrects white balance. Ideal for general
picture taking.
Daylight—For pictures in natural lighting.
Tungsten—Corrects the orange cast of incandescent light
bulbs. Ideal for indoor pictures under tungsten or halogen
lighting without flash.
Fluorescent—Corrects the green cast of fluorescent lighting.
Ideal for indoor pictures under fluorescent lighting without
Focus Mode
Choose a focus distance.
Focus/Exposure Zone
Choose how the camera
assesses the scene for
exposure and focus.
flash.
Open Shade—For pictures in shade in natural lighting.
Auto—For general picture-taking.
Macro—For sharpness and detail in pictures at close range.
Use available light instead of flash, if possible. The camera
automatically sets the focus distance depending on the zoom
position.
Infinity—For distant subjects; auto-focus framing marks are
unavailable.
Face Priority—If faces are detected, they receive
focus/exposure priority. (If faces are not detected, the camera
switches to Multi-Zone.)
Multi-Zone—Evaluates 5 zones to give an even picture
focus. Ideal for general picture taking.
Center-Zone—Evaluates the small area centered in the lens.
Ideal for focusing on a precise area.
30 www.kodak.com/go/support
Doing more with your camera
Press Menu, , ,
and OK to access settings
AF Control (Still)
Choose an auto-focus setting.
Sharpness
Control picture sharpness or
softness.
Video settings
IMPORTANT:
Press Menu, , ,
Your camera offers a built-in Help system. See page 38.
Picture-taking Options
Continuous AF—Because the camera is always focusing,
there is no need to press the Shutter button halfway down to
focus.
Single AF—Focuses when the Shutter button is pressed
halfway down. (This setting uses less battery power.)
High
Normal
Low
Video-taking Options
and OK to access settings
Self-timer
Choose Self-timer feature.
Off
10 Seconds
2 Seconds
www.kodak.com/go/support
31
Doing more with your camera
Using the Setup menu
Use Setup to customize other camera settings.
IMPORTANT:
Press Menu, to choose Setup,
then to access settings
Date & Time Set date and time.
Auto Time Setting Date and time are set when camera is connected
LCD Brightness
Choose LCD brightness during
picture/video capture.
Share Button Settings
Choose what is displayed when the Share
button is pressed in Review.
Your camera offers a built-in Help system. See page 38.
Setup Options
to a computer.
High Power—Brighter LCD; uses more battery
power.
Power Save—Dimmer LCD; uses less power.
Show or hide:
■ Individual social networking sites
■ E-mail addresses (all or none)
■ KODAK Digital Frames (all or none)
Red-eye Reduction
The Red-eye flash fires automatically
before a picture is taken.
Video Out
Choose the regional setting that lets you
connect the camera to a television or other
external device.
Image Storage
Choose a storage location for
pictures/videos.
Preflash—The flash fires before the picture is
taken to reduce the chance of red-eye.
Digital correction—The camera digitally
corrects red-eye after a picture is taken.
(Processing time after taking a picture may
increase.)
NTSC—Used in North America and Japan; most
common format.
PAL—Used in Europe and China.
Auto—The camera uses the card if one is in the
camera. If not, the camera uses internal memory.
Internal Memory—The camera always uses
internal memory, even if a card is installed.
32 www.kodak.com/go/support
Doing more with your camera
CAUTION:
Press Menu, to choose Setup,
then to access settings
Language Choose your language.
Reset Camera
Reset settings to their default.
Format
Formatting deletes all
pictures/videos, including those
that are protected. Removing a
Setup Options
Reset All Camera Settings—Settings revert to
their factory defaults.
Reset Startup Application—Resets camera to
startup mode to allow KODAK Software download.
Memory Card—Deletes everything on the card;
formats the card.
Cancel—Exits without making a change.
Internal Memory—Deletes everything in
internal memory including email addresses and
keyword tags; formats the internal memory.
card during formatting may
damage the card.
KODAK Camera Software
View URL to download KODAK Software.
About
View camera information.
www.kodak.com/go/support
33
6 Transferring, printing pictures
Turn on the camera.
3
Use the KODAK Camera USB
Cable, Micro B / 5-Pin to
connect camera to computer.
1
Turn off the camera.
After the software
is installed, follow the
prompts to transfer
pictures and videos to
your computer.
2
* If the downloader does not run, find and launch it:
• WINDOWS OS: in My Computer
• MAC OS: on your Desktop
Download software, transferring pictures
Download KODAK Software—so it’s easy to transfer and share pictures and videos.
Make sure the computer is connected to the Internet. When you connect the camera
to the computer, the KODAK Software Downloader automatically runs. Follow the
prompts to download and install KODAK Software.*
NOTE: You can also use a card reader to transfer your pictures/videos.
Download KODAK Software later www.kodak.com/go/camerasw
Get Software help www.kodak.com/go/support
To use this camera on more than one computer, use
the camera’s Reset Startup Application feature
34 www.kodak.com/go/support
see page 33
Transferring, printing pictures
Printing pictures
Direct printing with a KODAK All-in-One Printer
Your camera is compatible with PICTBRIDGE Technology, so you can print directly to
PICTBRIDGE enabled Printers. You need a camera, a PICTBRIDGE enabled Printer, and
a USB cable.
Connecting the camera to a KODAK All-in-One Printer
1 Turn off the camera and printer.
2 Connect the USB cable from the camera to the printer.
Printing from a KODAK All-in-One Printer
1 Turn on the printer. Turn on the camera.
The PictBridge logo is displayed, followed by the current picture and menu. (If no
pictures are found, a message is displayed.) If the menu turns off, press any button to
redisplay it. If the printer sees the camera as a mass storage device, turn the camera off
and then back on.
2 Choose a printing option, then press OK.
Current Picture—Press to choose a picture.
Tagged Pictures—If your printer is capable, print pictures that you marked for
printing.
Index Print—Print thumbnails of all pictures. (This option requires one or more
sheets of paper.)
All Pictures—Print all pictures in internal memory or on a card.
Image Storage—Access Auto or Internal Memory.
NOTE: During direct printing, pictures are not permanently transferred or saved to the printer. To transfer
pictures to your computer, see page 34.
Purchase cables, accessories www.kodak.com/go/c142accessories
www.kodak.com/go/support
35
Transferring, printing pictures
Disconnecting the camera from a KODAK All-in-One Printer
1 Turn off the camera and printer.
2 Disconnect the USB cable from the camera and the printer.
Ordering prints online
KODAK Gallery (www.kodakgallery.com) makes it easy to:
■ Upload your pictures.
■ Edit, enhance, and add borders to your pictures.
■ Store pictures, and share them with family and friends.
■ Have prints, photo greeting cards, frames, and albums delivered to your door.
Printing from an optional SD or SDHC Card
■ Automatically print tagged pictures when you insert your card into a printer with
an SD/SDHC Card slot. See your printer user’s guide for details.
■ Make prints at an SD/SDHC Card-capable KODAK Picture Kiosk. Go to
www.kodak.com/go/picturemaker.
■ Take the card to your local photo retailer for professional printing.
36 www.kodak.com/go/support
Transferring, printing pictures
Marking your pictures for printing
1 Press the Review button. Press to find a picture.
2 Press the Menu button.
3 Press to choose Print, then press OK.
4 Press to choose the number of copies.
Optional: You can apply a print quantity to other pictures. Press for
previous/next. Repeat this step until the desired print quantity is applied to each
picture.
5 Press OK.
Press the Shutter button halfway down to return to Capture mode.
IMPORTANT:
Your camera offers a built-in Help system. See page 38.
www.kodak.com/go/support
37
7 Troubleshooting
Scroll through a Help topic.
Press the Menu
choose a menu choice.
Press the Info
1
button.
2
button,
Getting help from your camera
You want the most from your camera. You want to understand:
■ What it can do for you
■ And how to take the best possible pictures and videos
Great news!
Your camera offers a built-in Help system. It describes every setting for every menu
choice. If you learn nothing else about your camera, learn how to use on-camera Help.
Turning on camera Help
38 www.kodak.com/go/support
Troubleshooting
Camera problems
Status Solution
Troubleshooting
Camera does not
turn on
Camera does not turn
off
Camera buttons and
controls do not
function
In Review, a blue or
black screen is
displayed instead of
a picture
Pictures remaining
number does not
decrease after taking a
■ Make sure the batteries are installed correctly (see page 1).
■ Make sure batteries are new. If batteries are rechargeable, make
sure they are fully charged (see charger documentation).
■ Transfer
■ Take another picture.
■ Continue taking pictures. The camera is operating normally.
all
pictures to the computer (see page 34).
(The camera estimates the number of pictures remaining after each
picture is taken, based on picture size and content.)
Flash does not fire ■ Check the flash setting, and change as needed (see page 8).
NOTE: The flash does not fire in all modes.
Memory card is almost
or entirely full
Battery life is short ■ Make sure the correct battery type is installed (see page 48).
■ Transfer the pictures to the computer (see page 34).
■ Delete pictures from the card (see page 18) or insert a new card.
■ Wipe the contacts with a clean, dry cloth before inserting
batteries in the camera.
■ Insert new/charged batteries (see page 1).
www.kodak.com/go/support
39
Troubleshooting
Status Solution
You cannot take a
■ Turn the camera off, then on again.
■ Depress the Shutter button all the way (see page 4).
■ Insert new/charged batteries in the correct orientation (see
page 1).
■ When inserting a memory card, push it in until it clicks (see
page 3).
■ Memory is full. Transfer pictures to the computer (see page 34),
delete pictures (see page 18), or insert another card.
Memory card not
recognized or camera
freezes with card
Cannot find the
■ Use a card reader to check the card on a computer. If it’s
corrupted, format the card in the camera (see page 33).
■ Try another SD or SDHC Card.
■ To view pictures on a card or in internal memory, see page 17.
desired picture/video
Computer/connectivity problems
Status Solution
Slide Show does not
run on an external
video device
Computer does not
communicate with
the camera
■ Adjust the camera Video Out setting to NTSC or PAL (see
page 32).
■ Make sure the external device settings are correct. (See the
device’s user guide).
■ Turn off the camera, then turn it back on.
■ Make sure the battery is charged and installed correctly (see
page 1).
■ Make sure the KODAK Camera USB Cable, Micro B / 5-Pin is
connected to the camera and the computer (see page 34). Then
turn on the camera.
■ See KODAK Software Help at www.kodak.com/go/camerasw.
40 www.kodak.com/go/support
Troubleshooting
Picture quality problems
Status Solution
Picture is not clear ■ To automatically set exposure and focus, press the Shutter button
halfway. When the framing marks turn green, press the Shutter
button completely down to take the picture.
■ Clean the lens (see page 46).
■ Make sure the camera is not in Macro mode if you are more than
27.6 in. (70 cm) from your subject (see page 30).
■ Place the camera on a flat, steady surface or use a tripod (especially
in high-zoom settings or in low light).
■ Use a larger picture size (see page 28).
■ If you’re manually adjusting the ISO speed, realize that high ISO
setting may cause grainy pictures (see page 29).
Picture is too dark ■ Reposition the camera for more available light.
■ Use Fill flash (see page 8) or change your position so light is not
behind the subject.
■ Move so that the distance between you and the subject is within the
effective flash range. (See Camera Specifications starting on
page 44.)
■ To automatically set exposure and focus, press the Shutter button
halfway. When the framing marks turn green, press the Shutter
button completely down to take the picture.
■ In Program mode, adjust the Exposure Compensation (see page 29).
Picture is too light ■ Reposition the camera to reduce the amount of available light.
■ Turn the flash off (see page 8).
■ Move so that the distance between you and the subject is within the
effective flash range. (See Camera Specifications starting on
page 44.)
■ To automatically set exposure and focus, press the Shutter button
halfway. When the framing marks turn green, press the Shutter
button completely down to take the picture.
■ In Program mode, adjust the Exposure Compensation (see page 29).
www.kodak.com/go/support
41
Troubleshooting
Direct printing (PICTBRIDGE enabled printer) problems
Status Solution
Cannot find the
■ Use the Direct printing menu to change the image storage location.
desired picture
The Direct printing
■ Press any camera button to redisplay the menu.
menu interface turns
off
Cannot print pictures ■ Make sure there is a connection between the camera and the
printer (see page 35).
■ Make sure the printer and the camera have power.
Camera or printer
■ Follow the prompts to resolve the issue.
displays an error
message
42 www.kodak.com/go/support
Getting help on the Web
Camera
Troubleshooting
Get support for your product (FAQs, troubleshooting
information, arrange for repairs, etc.)
See step-by-step solutions and repair information www.kodak.com/go/itg
Purchase camera accessories www.kodak.com/go/c142accessories
Download the latest camera firmware and software www.kodak.com/go/c142downloads
See online demonstrations of your camera www.kodak.com/go/howto
Register your camera www.kodak.com/go/register
Chat, email, write, or phone Kodak
(Chat not available in all languages)
www.kodak.com/go/c142support
www.kodak.com/go/contact
Software
Download and get Help with other KODAK Software www.kodak.com/go/camerasw
Download KODAK EASYSHARE Software www.kodak.com/go/easysharesw
(or see Help in EASYSHARE Software)
Get help with the WINDOWS OS and working with
digital pictures
wcww.kodak.com/go/pcbasics
Other
Get support for cameras, software, accessories, more www.kodak.com/go/support
Get information on KODAK All-in-One Printers www.kodak.com/go/inkjet
www.kodak.com/go/support
43
8 Appendix
Camera specifications
CCD—1/2.5-type
Effective pixels—10 MP (3672 x 2760)
LCD—2.5 in. (6.35 cm) LCD; 230K pixels; 4:3 aspect ratio
Image storage—Optional SD/SDHC Card (The SD logo is a trademark of the
SD Card Association.) Maximum supported card size: 32 GB
Internal storage capacity—32 MB internal memory (15 MB available for image
storage. 1 MB equals one million bytes.)
Taking lens—3X optical zoom; f/2.9–f/5.2; 35 mm equivalent: 34–102 mm
Lens protection—Built-in
Digital zoom—5X continuous
Focus system—TTL-AF (through-the-lens auto focus); Multi-Zone, Center-Zone,
Face Priority. Working range:
0.6 m (2 ft)–infinity @ wide, normal
0.6 m (2 ft)–infinity @ telephoto, normal
13–70 cm (5.1–27.6 in.) @ wide, Macro mode
35–70 cm (13.8–27.6 in.) @ telephoto, Macro mode
Auto focus control—Continuous and Single AF
Face detection—Yes
Shutter speed—8–1/1600 seconds
Long time exposure—0.5–8 seconds
ISO speed—Smart Capture mode: Auto 80–400
Program mode: Auto 80-400; manual 80, 100, 200, 400, 800, 1600
44 www.kodak.com/go/support
Appendix
Exposure metering—TTL-AE; Face Priority, Multi-Zone, Center-Zone
Exposure compensation—+/-2.0 EV with 1/3 EV step
White Balance—Auto, Daylight, Tungsten, Fluorescent, Open Shade
Electronic Flash—Auto flash; Auto, Fill, Red Eye, Off; Guide No. 6.3 (m); working
range @ ISO 250: 0.6–3.4 m (2–11.2 ft) @ wide; 0.6–1.9 m (2–6.2 ft) @ telephoto
Self-timer mode—10–second, 2–second, 2–shot
Burst mode—Maximum 3 pictures @ 1.1 fps
Capture modes—Smart Capture, Program, Scene modes, Video
Image file format—
Still: EXIF 2.21 (JPEG compression); file organization DCF
Video: QUICKTIME (CODEC Motion JPEG; audio: -Law)
Picture size—10.0 MP (4:3): 3648 x 2736 pixels
8.9 MP (3:2): 3648 x 2432 pixels
7.5 MP (16:9): 3648 x 2048 pixels
5.0 MP (4:3): 2592 x 1936 pixels
3.1 MP (4:3): 2048 x 1536 pixels
2.1 MP (16:9): 1920 x 1080 pixels
1.2 MP (4:3): 1280 x 960 pixels
Color modes—High Color, Natural Color, Low Color, Black & White, Sepia
Sharpness modes—High, Normal, Low
Video capture—4 GB maximum; VGA (640 x 480 @ 30 fps)
Communication with computer—USB 2.0 full speed (PIMA 15740 protocol); via
KODAK Camera USB Cable, Micro B / 5-Pin
Video output—NTSC or PAL
Microphone—Yes
Beeper—Yes
PICTBRIDGE support—Yes
www.kodak.com/go/support
45
Appendix
Power—KODAK MAX Alkaline Batteries AA; KODAK Ni-MH Rechargeable Digital
Camera Batteries AA (Pre-Charged); KODAK Ni-MH Rechargeable Digital Camera
Batteries AA; AA lithium batteries
Tripod mount—1/4 inch
Size—92.9 x 62 x 29.6 mm (3.7 x 2.4 x 1.2 in.) @ power off
Weight—170 g (6 oz) with card and batteries
Operating temperature—0–40
° C (32–104° F)
Care and maintenance
■ If you suspect water has gotten inside the camera, remove the batteries and card.
Allow all components to air-dry for at least 24 hours before using the camera.
■ Blow gently on the lens or LCD to remove dust and dirt. Wipe gently with a soft,
lint-free cloth or an untreated lens-cleaning tissue. Do not use cleaning solutions
unless designed specifically for camera lenses. Do not allow chemicals, such as
suntan lotion, to contact painted surfaces.
■ Service agreements may be available in your country. Contact a dealer of KODAK
Products for more information.
■ For digital camera disposal or recycling information, contact your local authorities.
In the US, go to the Electronics Industry Alliance site at www.eiae.org or
www.kodak.com/go/c142support.
Upgrading your software and firmware
Download the latest versions of KODAK Software and the camera firmware (the
software that runs on the camera). Go to www.kodak.com/go/c142downloads.
46 www.kodak.com/go/support
Appendix
CAUTION:
Storage capacities
The LCD displays the approximate number of pictures (or minutes/seconds of video)
remaining. Actual storage capacity varies depending on subject composition, card
size, and other factors. You may be able to store more or fewer pictures and videos.
Important safety instructions
Do not disassemble this product; there are no user-serviceable parts
inside. Refer servicing to qualified service personnel. KODAK AC Adapters
and Battery Chargers are intended for indoor use only. The use of
controls, adjustments, or procedures other than those specified herein
may result in exposure to shock and/or electrical or mechanical hazards. If
the LCD breaks, do not touch the glass or liquid. Contact Kodak customer
support.
■ The use of an accessory that is not recommended by Kodak may cause fire, electric
shock, or injury. For approved accessories, go to www.kodak/go/accessories.
■ Use only a USB-certified computer equipped with a current-limiting motherboard.
Contact your computer manufacturer if you have questions.
■ If using this product in an airplane, observe all instructions of the airline.
■ When removing the batteries, allow them to cool; they may be hot.
■ Follow all warnings and instructions supplied by the battery manufacturer.
■ Use only batteries approved for this product to avoid risk of explosion.
■ Keep batteries out of the reach of children.
■ Do not allow batteries to touch metal objects, including coins. Otherwise, a battery
may short circuit, discharge energy, become hot, or leak.
■ Do not disassemble, install backward, or expose batteries to liquid, moisture, fire,
or extreme temperature.
www.kodak.com/go/support
47
Appendix
■ Remove the batteries when the product is stored for an extended period of time. In
the unlikely event that battery fluid leaks inside the product, contact Kodak
customer support.
■ In the unlikely event that battery fluid leaks onto your skin, wash immediately with
water and contact your local health provider. For additional health-related
information, contact your local Kodak customer support.
■ Go to www.kodak.com/go/reach for information about the presence of substances
included on the candidate list according to article 59(1) of Regulation (EC) No.
1907/2006 (REACH).
■ Dispose of batteries according to local and national regulations. Go to
www.kodak.com/go/kes.
■ Do not charge non-rechargeable batteries.
For more information on batteries, go to www.kodak.com/go/batterychart.
Battery replacement, battery life
KODAK MAX Alkaline Batteries AA: 200 pictures per charge. Battery life per CIPA
testing method. (Approx. number of pictures in Smart Capture mode, using an SD
Card.) Actual life may vary based on usage. For other compatible batteries, see the
Power section in Camera specifications, page 44.
Extending battery life
■ Use power-saving features (see Using the Setup menu, page 32).
■ Charge Ni-MH batteries when they are nearly depleted.
■ Dirt on the battery contacts can affect battery life. Wipe the contacts with a clean,
dry cloth before loading batteries in the camera.
■ Battery performance is reduced at temperatures below 41° F (5° C). When using
your camera in cold weather, carry spare batteries and keep them warm. Do not
discard cold batteries that do not work; when they return to room temperature,
they may be usable.
48 www.kodak.com/go/support
Appendix
Limited warranty
Kodak warrants its digital cameras and accessories (excluding batteries) to be free
from malfunctions and defects in both materials and workmanship for the warranty
period specified on your KODAK Product packaging. Retain the original dated sales
receipt. Proof of purchase date is required with any request for warranty repair.
Limited warranty coverage
Warranty service is only available from within the country where the Products were
originally purchased. You may be required to ship Products, at your expense, to the
authorized service facility for the country where the Products were purchased. Kodak
will repair or replace Products if they fail to function properly during the warranty
period, subject to any conditions and/or limitations stated herein. Warranty service
will include all labor as well as any necessary adjustments and/or replacement parts. If
Kodak is unable to repair or replace a Product, Kodak will, at its option, refund the
purchase price paid for the Product provided the Product has been returned to Kodak
along with proof of the purchase price paid. Repair, replacement, or refund of the
purchase price are the sole remedies under the warranty. If replacement parts are
used in making repairs, those parts may be remanufactured, or may contain
remanufactured materials. If it is necessary to replace the entire Product, it may be
replaced with a remanufactured Product. Remanufactured Products, parts and
materials are warranted for the remaining warranty term of the original Product, or 90
days after the date of repair or replacement, whichever is longer.
Limitations
This warranty does not cover circumstances beyond Kodak's control. This warranty
does not apply when failure is due to shipping damage, accident, alteration,
modification, unauthorized service, misuse, abuse, use with incompatible accessories
or attachments (such as third party ink or ink tanks), failure to follow Kodak's
operation, maintenance or repacking instructions, failure to use items supplied by
Kodak (such as adapters and cables), or claims made after the duration of this
warranty. Kodak makes no other express or implied warranty for this product. In the
event that the exclusion of any implied warranty is ineffective under the law, the
duration of the implied warranty will be the length of the express warranty period
www.kodak.com/go/support
49
Appendix
specified on your Kodak product packaging. The option of repair, replacement, or
refund is Kodak's only obligation. Kodak will not be responsible for any special,
consequential or incidental damages resulting from the sale, purchase, or use of this
product regardless of the cause. Liability for any special, consequential or incidental
damages (including but not limited to loss of revenue or profit, downtime costs, loss
of the use of the equipment, cost of substitute equipment, facilities or services, or
claims of your customers for such damages resulting from the purchase, use, or failure
of the Product), regardless of cause or for breach of any written or implied warranty is
expressly disclaimed.
Your righ ts
Some states or jurisdictions do not allow exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion may not apply to you.
Some states or jurisdictions do not allow limitations on how long an implied warranty
lasts, so the above limitation may not apply to you. This warranty gives you specific
rights, and you may have other rights which vary from state to state or by jurisdiction.
Outside the United States and Canada
In countries other than the United States and Canada, the terms and conditions of
this warranty may be different. Unless a specific Kodak warranty is communicated to
the purchaser in writing by a Kodak company, no warranty or liability exists beyond
any minimum requirements imposed by law, even though defect, damage, or loss may
be by negligence or other act.
Regulatory compliance
FCC compliance and advisory
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed or used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
50 www.kodak.com/go/support
Appendix
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures: 1) reorient or relocate the
receiving antenna; 2) increase the separation between the equipment and the
receiver; 3) connect the equipment to an outlet on a circuit different from that to
which the receiver is connected; 4) consult the dealer or an experienced radio/TV
technician for additional suggestions. Any changes or modifications not expressly
approved by the party responsible for compliance could void the user’s authority to
operate the equipment. Where shielded interface cables have been provided with the
product or specified additional components or accessories elsewhere defined to be
used with the installation of the product, they must be used in order to ensure
compliance with FCC regulation. The KODAK High Performance USB AC Adapter
K20-AM complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause
undesired operation.
Waste Electrical and Electronic Equipment/Battery disposal
In Europe: For human/environmental protection, it is your responsibility to
dispose of this equipment and batteries at a collection facility established for
this purpose (separate from municipal waste.) For more information, contact
your retailer, collection facility, or appropriate local authorities; or go to
www.kodak.com/go/recycle. Product weight: 170 g (6 oz) with card and
batteries.
Canadian DOC statement
DOC Class B Compliance—This Class B digital apparatus complies with Canadian
ICES-003.
Observation des normes-Classe B—Cet appareil numérique de la classe B est
conforme à la norme NMB-003 du Canada.
www.kodak.com/go/support
51
Appendix
N137
Eastman Kodak Company
Rochester, NY 14650
CE
Hereby, Eastman Kodak Company declares that this KODAK Product is in compliance
with the essential requirements and other relevant provisions of Directive 1999/5/EC.
Australian C-Tick
VCCI Class B ITE
Russian GOST-R
China RoHS
52 www.kodak.com/go/support
Korean Class B ITE
Appendix
www.kodak.com/go/support
53
Index 1
A
A/V out, 23
about this camera, 33
accessories
battery, 48
buying, 43
SD/SDHC Card, 3
add keywords, 15
AF control (Still), 31
AF control (video), 31
AF zone, 30
auto, 9
focus control, 31
focus framing marks, 4
auto focus (AF)
zone, 30
B
backlight, 10
C
cable
audio/video, 23
Canadian compliance, 51
care and maintenance, 46
children, 10
clock, setting, 2
color mode, 30
computer
connect camera, 34
transfer to, 34
connector, USB / A/V, 23
copy pictures
card to memory, 27
memory to card, 27
to computer, 34
cropping pictures, 24
customize camera, 32
battery
expected life, 48
loading, 1
purchase, 6, 21
status,6,21
types, 48
beach, 10
burst, 12
button
delete, 5
telephoto/zoom, 7
54 www.kodak.com/go/support
D
date setting, 2
deleting
during quickview, 5
from internal memory, 18
from SD/SDHC Card, 18
protecting pictures, videos, 18
digital zoom, 7
displaying slide show, 22
disposal, recycling, 46
download
KODAK Software, 34
download pictures, 34
Index
E
edit videos, 26
emailing pictures, videos, 16
expected battery life, 48
exposure
long time, 29, 32
exposure compensation, 29
external video device
viewing pictures, videos, 23
F
FCC compliance, 50
find pictures, 20
fireworks, 10
firmware, upgrading, 46
flash, using, 8
flower, 10
focus framing marks, 4
focus mode, 30
format, 33
framing marks, 4
battery, 1
SD/SDHC Card, 3
ISO speed, 29
K
keyboard, 15
KODAK Software
upgrading, 46
KODAK Software, download, 34
Kodak Web sites, 38
L
language, 33
LCD
brightness, 32
reviewing pictures, 17
reviewing videos, 17
LCD brightness, 32
lens
cleaning lens, 46
loading
battery, 1
G
guidelines, battery, 48
SD/SDHC Card, 3
locate pictures, 20
long time exposure, 29, 32
H
help
camera help, 38
Web links, 38
high ISO, 10
M
magnify a picture, 19
maintenance, camera, 46
make picture from video, 26
manner/museum, 10
I
icons, modes, 9
image storage, 32
installing
www.kodak.com/go/support 55
marking
for email, 16
memory
inserting card, 3
Index
menu settings, 28
modes, 9
auto, 9
backlight, 10
beach, 10
children, 10
fireworks, 10
flower, 10
high ISO, 10
manner/museum, 10
night landscape, 11
night portrait, 11
scene (SCN), 10
self-portrait, 11
snow, 10
text, 10
modes, capture
emailing marked, 16
marking, 37
protecting, 18
review icons, 21
reviewing, 17
taking, modes, 9
transfer to computer, 34
pictures/video
deleting, 18
playing a video, 17
power
camera, 2
printing
from a card, 36
optimizing printer, 38
order online, 36
PICTBRIDGE, 35
smart capture, 9
multiple selections, 27
multi-up, 19
N
night landscape, 11
night portrait, 11
O
online prints, ordering, 36
optical zoom, 7
P
PICTBRIDGE enabled printer, 35
picture size, 28, 29
pictures
copying, 27
cropping, 24
tagged pictures, 36
protecting pictures, videos, 18
Q
quickview, using, 5
R
recycling, disposal, 46
regulatory information, 50
repair, 43
reset camera, 33
reviewing pictures/video
as you take them, 5
deleting, 18
LCD, 17
protecting, 18
slide show, 22
56 www.kodak.com/go/support
Index
running slide show, 22
S
safety, 47
scene modes (SCN), 10
SD/SDHC Card
inserting, 3
printing from, 36
search pictures, 20
select multiple pictures/videos, 27
self-portrait, 11
self-timer, 12
set tag, 29
setting
AF zone, 30
auto-focus, 31
color mode, 30
problems, 40
self-timer delay, 12
slide show
continuous loop, 22
running, 22
smart capture, 9
smart display, 32
smart find, 20
snow, 10
software
upgrading, 46
software downloader, 34
specifications, camera, 44
strap, 1
T
taking pictures, videos, 4
date and time, 2
image storage, 32
ISO, 29
language, 33
LCD brightness, 32
long time exposure, 29, 32
picture size, 28, 29
picture-taking mode, 9
self-timer, 12
sharpness, 31
video out, 32
white balance, 30
setting up the camera, 1
setup menu, 32
Share button, 32
sharpness, 31
shutter
television, slide show, 23
text, 10
text, entering, 15
time, setting, 2
timer, shutter delay, 12
tips
battery guidelines, 48
care & maintenance, 46
transfer pictures, 34
trash can, deleting, 5
trimming a video, 26
troubleshooting, 38
turning camera on and off, 2
typing, 15
U
undelete, undo, 18
www.kodak.com/go/support 57
Index
upgrading software, firmware, 46
URLs, Kodak Web sites, 38
USB
transfer pictures, 34
V
VCCI compliance, 52
video
copying, 27
edit, 26
emailing marked, 16
out, 32
playback, 17
protecting, 18
review icons, 21
transfer to computer, 34
viewing, 17
video out, 32
viewing
by multi-up, 19
picture, after taking, 5, 17
W
warranty, 49
white balance, 30
Z
zoom
digital, 7
optical, 7
58 www.kodak.com/go/support
Loading...
