Kodak C650 User Manual [en, es, fr]

Kodak
C650 Zoom Camera
ENGLISH/ESPAÑOL/FRANÇAIS
Camera Identification
(16) (15)
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(14)
(13)
(8)
(12)
(11)
(10)
(9)
Camera Identification
(17)
(25)
(18)
(19)
(20)
(24)
(21)
(22)
(23)
LCD Panel
(36) (35)
(26)
+
AUTO
(34)
(33) (32)
(27) (28)
(31)
(29)
(30)
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
NOTE: Your model camera has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits provide reasonable protection against interference in residential use. The camera generates, uses and can radiate radio frequency energy and, if not used in accordance with the instructions, may cause interference to radio communications. There is no guarantee that interference will not occur. If this camera does cause interference to radio or television reception, which can be determined by turning the camera off and on, you may reduce the interference by the following:
— Reorient or relocate the receiving antenna. — Increase the separation between the camera and the receiver. — Consult the dealer or an experienced radio/television technician for help. Changes or modifications not approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations
KODAK ADVANTIX
C650 Zoom Camera
Welcome to the innovative world of the Advanced Photo System! And thank you for buying this KODAK ADVANTIX Camera.
NEED HELP WITH YOUR CAMERA?
Go to our web site at http://www.kodak.com or call: Kodak (USA only) from 9:00 a.m. to 7:00 p.m. (Eastern time)
Monday through Friday at 1 (800) 242-2424. Kodak (Canada only) from 8:00 a.m. to 5:00 p.m. (Eastern time) Monday
through Friday at 1 (800) 465-6325, ext. 36100; for the Toronto area, call (416) 766-8233, ext. 36100.
When you call, please have your camera available.
For warranty purposes, please keep your sales receipt as proof of the date of purchase.
© Eastman Kodak Company, 1998
ENGLISH
ADV ANCED PHOTO SYSTEM FEA TURES AVAILABLE WITH THIS CAMERA
Triple format selection
• You can take three different size pictures: Classic (C), Group/HDTV (H), and Panoramic (P) pictures from the same film cassette. The viewfinder frame changes to match each format selection.
Date and time imprinting
• You can choose to have date and time information printed on the back of your prints. See your photofinisher for a full description of available services.
Double exposure protection (DEP)
• You don’t need to worry about accidentally re-exposing your film. Your camera reads the Film Status Indicator (FSI) on the film cassette to prevent re-exposure.
2
Picture quality information exchange (PQix)
• Your camera features magnetic information exchange that records information about lighting conditions and exposure on the film cassette to assist the photofinishing lab with color correction and exposure adjustments, providing you with the best possible results.
Safety-interlock film door
• The safety interlock on the film door prevents the door from opening before the film is completely rewound.
Look for this logo to be certain that the film you buy is made for this camera.
Look for this logo to select a certified photofinisher for developing your film and to assure that you get all the features of the Advanced Photo System.
Film Status Indicator (FSI)
A highlighted indicator advances from one symbol to another to identify the status of the film inside the cassette.
4
3
PROCESSED NEGATIVES
1
2
UNEXPOSED
PARTIALLY EXPOSED
FULLY EXPOSED
3

CONTENTS

CAMERA IDENTIFICATION............................. 5
ATTACHING THE STRAP................................ 6
LOADING THE BATTERY ................................ 6
Low-battery indicator ................................... 7
Battery tips .................................................. 7
Power shut-off ............................................. 7
LOADING THE FILM ........................................ 8
TAKING PICTURES......................................... 9
Typical print sizes (formats) ....................... 10
Using the focus lock .................................. 10
Using the zoom lens .................................. 11
Tips for better pictures............................... 11
TAKING FLASH PICTURES .......................... 12
Flash-to-subject distance .......................... 12
4
SELECTING THE FLASH AND
INFINITY -FOCUS MODES .......................... 13
Red-eye reduction ..................................... 13
Auto flash without red-eye reduction ......... 14
Fill flash ..................................................... 14
Off flash ..................................................... 15
Infinity focus .............................................. 15
Night-view.................................................. 16
USING THE SELF-TIMER ............................. 16
DATE AND TIME IMPRINTING ...................... 17
Setting the date and time .......................... 17
UNLOADING THE FILM ................................. 17
Automatic rewind ....................................... 17
Manual rewind ........................................... 18
CARING FOR YOUR CAMERA ..................... 18
TROUBLESHOOTING ................................... 19
SPECIFICATIONS.......................................... 20

CAMERA IDENTIFICA TION

(Unfold the front and back cover flaps of manual for camera diagrams.)
1 ZOOM-DIAL LEVER 2 SELECT BUTTON 3 ENTER BUTTON 4 FILM-REWIND BUTTON 5 LCD PANEL 6 SELF-TIMER BUTTON 7 FLASH-MODE BUTTON 8 FORMAT-SELECTOR LEVER
9 FLASH 10 VIEWFINDER 11 LENS 12 METER-CELL WINDOW 13 SELF-TIMER LAMP 14 RED-EYE-REDUCTION LAMP 15 AUTO-FOCUS SENSORS 16 SHUTTER BUTTON 17 BATTERY DOOR 18 FLASH/CAMERA-READY LAMP 19 VIEWFINDER EYEPIECE
20 ON/OFF SWITCH 21 FILM-DOOR LATCH 22 STRAP POST 23 FILM CHAMBER 24 FILM DOOR 25 TRIPOD SOCKET
LCD Panel 26 BATTERY SYMBOL 27 DATE/TIME DISPLAY 28 NIGHT-VIEW INDICATOR 29 RED-EYE-REDUCTION INDICATOR 30 FRAME COUNTER 31 SELF-TIMER INDICATOR 32 FILL-FLASH INDICATOR 33 INFINITY-FOCUS INDICATOR 34 FILM-PRESENCE INDICATOR 35 OFF-FLASH INDICATOR 36 AUTO-FLASH INDICATOR
5

ATT ACHING THE STRAP

1. Insert the shorter looped end of the
strap behind the STRAP POST (22).
Use KODAK
ADVANTIX Film
2. Thread the longer end of the strap
through the shorter loop.
3. Pull the strap tight.
6

LOADING THE BA TTERY

This camera uses one 3-volt lithium KODAK K123LA (or equivalent) Battery that supplies power for all camera operations.
1. Open the
BATTERY
(17).
DOOR
Before you remove the old battery, turn the camera off.
2. Insert the battery into the chamber as shown.
3. Snap the battery door closed.
After you
load a new battery into the camera, you will need to reset the date and time.

Low-battery indicator

It’s time to replace the battery when—
• the BATTERY SYMBOL (26) “blinks” on the LCD PANEL (5)
• none of the indicators appears on the LCD panel and the SHUTTER
(16) cannot be released.
BUTTON
or

Battery tips

• Remember to keep a spare battery with you at all times.
• Read and follow all warnings and instructions supplied by the battery manufacturer.
• Keep batteries away from children.
• Do not try to take apart, recharge or short circuit the battery, or subject it to high temperature or fire.
• Store batteries in their original packaging prior to use.

Power shut-off

To save battery power, the camera will automatically go into a sleep mode (lens will return to the wide-angle position and the LCD panel will display just the date/ time) if it is not operated for more than 3 minutes. You can press any of the control buttons to awaken the camera.
7

LOADING THE FILM

ON
You can load film into the camera with the camera ON or OFF.
1. Move the
FILM-DOOR
(21) to
LATCH
open the
FILM
(24).
DOOR
• The film door will open only when the film chamber is empty or the film in the camera is completely rewound into the film cassette.
8
OFF
OPEN
2. Insert the film cassette completely into the FILM CHAMBER (23).
Make
sure the Film Status
ON
OFF
OPEN
Indicator (FSI) on the film
1
4
2
3
cassette is at (#1 position) for a new cassette.
Do not force the film cassette into
the film chamber.
3. Close the film door to start the auto-
film advance. The FRAME COUNTER (30) on the LCD PANEL (5) will show the number of frames remaining on the film cassette.
• After you close the safety-interlocked
film door, you cannot open the door until the film is completely rewound into the film cassette.

TAKING PICTURES

You can take Classic (C), Group/ and Panoramic (P) pictures on the same film cassette. Y our photo-processing cost may be based on the format size(s) that you use to expose the film.
1. Move the ON/
OFF SWITCH (20)
to the “ON” position to turn the camera on and to raise the
FLASH (9).
2. Move the
FORMAT- SELECTOR LEVER
(8) to select desired format (C, H, or P). The viewfinder will
* High Definition Television (HDTV) prints are
the same aspect ratio as the TV for CD interface capabilities.
HDTV (H)
ON
OFF
OPEN
change to show the selected field of view.
*,
3. Frame your subject within the
VIEWFINDER EYEPIECE (19). For a sharp
picture, stand at least 2 ft (0.6 m) from your subject.
C
P
H
4. Press the SHUTTER BUTTON (16) to take the picture.
SELECT
ENTER
OFFON
OPEN
C P H
9

Typical print sizes (formats)

CHP
Classic Group (HDTV) Panoramic
3.5 x 5 in. or 3.5 x 6 in. or 3.5 x 8.5 in. to 4 x 6 in. 4 x 7 in. 4 x 11.5 in.
(88.9 x 127 mm or (88.9 x 152 mm or (88.9 x 216 mm to
102 x 152 mm) 102 x 178 mm) 102 x 292.7 mm)
NOTE: Y our photofinisher will generally provide 4 x 6, 4 x 7 , and 4 x 11.5 in. (102 x 152, 102 x 178, and 102 x 292.7 mm) sizes. Some local printers may offer
3.5 x 5, 3.5 x 6, and 3.5 x 8.5 in. (88.9 x 127, 88.9 x 152, and 88.9 x 216 mm) sizes.

Using the focus lock

This camera automatically focuses on whatever is within the auto-focus (AF) circle of the viewfinder eyepiece. To get a sharp picture, make sure the AF circle is on your main subject. If you want to take a picture with the subject positioned outside of the AF circle, use the focus lock as follows:
1. Place the AF circle on the subject that you want focused in the picture.
10
AF CIRCLE
2. Partially depress and hold the
SHUTTER BUTTON (16) to lock the
focus position.
3. While still partially depressing the shutter button, move the camera until your subject is where you want it within the VIEWFINDER EYEPIECE (19).
4. Press the shutter button completely down to take the picture.
VIEWFINDER
VIEWFINDER

Using the zoom lens

This camera has a motorized zoom lens that lets you select the ideal lens-focal length for taking pictures. When you turn the camera on, it is initially set to the wide-angle position.
1. Move the ON/OFF SWITCH (20) to the “ON” position to turn the camera on and to raise the FLASH (9).
2. Move the
ZOOM-DIAL
(1) to
LEVER
the left to the wide-angle position to zoom
away
from the subject. Move the lever to the right to the telephoto position to zoom
3. Frame your subject within the
VIEWFINDER EYEPIECE (19).
4. Press the SHUTTER BUTTON (16) to take the picture.
• The lens barrel will automatically
return to the wide-mode position after approximately 3 minutes.
ON
closer
to the subject.
OPEN

Tips for better pictures

• Move close enough to your subject so it fills the viewfinder but not closer than 2 ft (0.6 m).
• Take pictures at the subject’ s level. Kneel down to take pictures of children and pets.
• Hold your camera vertically to capture tall, narrow subjects, such as a waterfall, skyscraper, or a single person.
• Add interest to your picture by framing it with a tree branch, a window, or even the rails of a fence.
• Keep the sun behind you. This provides the best subject illumination.
11

TAKING FLASH PICTURES

In dim light, such as indoors or outdoors in heavy shade, or on dark overcast days, you need flash. Y our camera features an automatic flash that fires when you need it. The pop-up flash helps to minimize red eyes in flash pictures and to prevent hand obstruction in front of the lens.
1. Move the ON/OFF SWITCH (20) to the “ON” position to turn the camera on and to raise the FLASH (9).
• The FLASH/CAMERA-READY LAMP (18)
“blinks” when the flash is not ready.
2. Frame your subject within the
VIEWFINDER EYEPIECE (19).
3. Partially depress the SHUTTER
12
(16). When the FLASH/CAMERA-
BUTTON READY LAMP (18) glows green, fully
depress the shutter button to take the picture.
4. Keep the subject within the distance range for the speed of film in your camera (see
Flash-to-subject distance). Don’t
take pictures beyond the maximum distance or your pictures will be dark.

Flash-to-subject distance

ISO
film Wide Telephoto
speed (24 mm) (48 mm)
50 2 to 14 ft 2 to 7 ft
(0.6 to 4.3 m) (0.6 to 2.1 m)
100 2 to 19 ft 2 to 10 ft
(0.6 to 5.8 m) (0.6 to 3.1 m)
200 2 to 27 ft 2 to 14 ft
(0.6 to 8.2 m) (0.6 to 4.3 m)
400 2 to 38 ft 2 to 20 ft
(0.6 to 11.6 m) (0.6 to 6.1 m)
800 2 to 53 ft 2 to 28 ft
(0.6 to 16.2 m) (0.6 to 8.5 m)
1600 2 to 74 ft 2 to 40 ft
(0.6 to 22.6 m) (0.6 to 12.2 m)

SELECTING THE FLASH AND INFINITY-FOCUS MODES

Besides the auto-flash mode with red­eye reduction, you can select auto-flash without red-eye reduction, fill flash, off-flash, infinity-focus, and night-view modes.
Press the FLASH-
MODE BUTTON (7)
until the desired indicator appears on the LCD
(5).
PANEL
The flash modes will remain selected after you take the picture. To change the flash-mode selection, press the flash-mode button, or turn the camera off then back on to return to the flash default mode.

Red-eye reduction

Some people’s eyes (and some pets’) can reflect flash with a red glow. This camera features automatic flash with red-eye reduction which is the intitial default setting for this camera. With the help of the pop-up flash and by following the instructions below, you can minimize red eyes in flash or fill-flash pictures.
1. Move the ON/OFF SWITCH (20) to the “ON” position to turn the camera on and to raise the FLASH (9).
2. Press the FLASH-MODE BUTTON (7) repeatedly until the auto flash with RED-
EYE-REDUCTION INDICATOR (29) appears
on the LCD PANEL (5).
• Disregard step 2 if the default setting is
already set for red-eye reduction.
3. Frame your subject within the VIEWFINDER
EYEPIECE
4. Have your subject look directly at the
RED-EYE-REDUCTION LAMP (14).
5. Partially depress the When the FLASH/CAMERA-READY LAMP (18) glows green, fully depress the shutter button to take the picture.
(19).
SHUTTER BUTTON
(16).
13
Auto flash without red-eye reduction
Use this mode for taking pictures without people.
You can change the default setting to auto flash without red-eye reduction by following the steps below:
1. Move the ON/OFF SWITCH (20) to the “ON” position to turn the camera on and to raise the FLASH (9).
2. Press the FLASH-MODE BUTTON (7) repeatedly until the AUTO-FLASH
INDICATOR LCD PANEL (5).
3. Frame your subject within the
VIEWFINDER EYEPIECE (19).
4. Partially depress the SHUTTER
BUTTON READY LAMP (18) glows green, fully
depress the shutter button to take the picture.
• The camera will now default to the
14
(36) appears on the
(16). When the FLASH/CAMERA-
auto-flash mode without red-eye reduction.

Fill flash

When bright light indoors or outdoors comes from behind the subject (backlight­ing), dark shadows (especially on faces) may occur. Use fill flash to lighten these shadows.
1. Move the ON/OFF SWITCH (20) to the “ON” position to turn the camera on and to raise the FLASH (9).
2. Press the FLASH-MODE BUTTON (7) repeatedly until the FILL-FLASH
INDICATOR PANEL
3. Frame your subject within the
VIEWFINDER EYEPIECE (19).
4. Partially depress the SHUTTER
BUTTON READY LAMP (18) glows green, fully
depress the shutter button to take the picture.
(32) appears on the LCD
(5).
(16). When the FLASH/CAMERA-
Off flash
OFF
When you do not want to use the flash, especially indoors where flash is prohibited, such as in theaters and museums, or when you want to take twilight scenes or distant subjects that are beyond the flash range, or capture the ambiance of existing light, use the off­flash feature. Use a tripod or place the camera on another firm support, and use high-speed film because the shutter speed at night will most likely be slow.
1. Move the ON/OFF SWITCH (20) to the “ON” position to turn the camera on and to raise the FLASH (9).
2. Press the FLASH-MODE BUTTON (7) repeatedly until the OFF-FLASH
INDICATOR LCD PANEL (5).
(35) appears on the
3. Frame your subject within the
VIEWFINDER EYEPIECE (19).
4. Partially depress the SHUTTER
(16). When the FLASH/CAMERA-
BUTTON READY LAMP (18) glows green, fully
depress the shutter button to take the picture.

Infinity focus

Capture sharp, distant scenery at any zoom position (for daylight and outdoor use only).
1. Move the ON/OFF SWITCH (20) to the “ON” position to turn the camera on and to raise the FLASH (9).
2. Press the FLASH-MODE BUTTON (7) repeatedly until the INFINITY-FOCUS
INDICATOR PANEL
3. Frame your subject within the
VIEWFINDER EYEPIECE (19).
4. Partially depress the SHUTTER
BUTTON READY LAMP (18) glows green, fully
depress the shutter button to take the picture.
(33) appears on the LCD
(5).
(16). When the FLASH/CAMERA-
15
Night-view
In this mode, the camera balances the flash and existing light exposure so you can take beautiful pictures of people at sunset or at night. Use a tripod or place the camera on another firm support, and use high-speed film because the shutter speed at night will most likely be slow.
1. Move the ON/OFF SWITCH (20) to the “ON” position to turn the camera on and to raise the FLASH (9).
2. Press the FLASH-MODE BUTTON (7) repeatedly until the NIGHT-VIEW
INDICATOR PANEL
3. Frame your subject within the
VIEWFINDER EYEPIECE (19).
4. Partially depress the SHUTTER
BUTTON READY LAMP (18) glows green, fully
depress the shutter button to take the picture.
16
(28) appears on the LCD
(5).
(16). When the FLASH/CAMERA-

USING THE SELF-TIMER

Use this feature to include yourself in pictures.
1. Use the TRIPOD SOCKET (25) to attach the camera to a tripod or place it on another firm support.
2. Move the ON/OFF SWITCH (20) to the “ON” position to turn the camera on and to raise the FLASH (9).
3. Press the SELF-TIMER BUTTON (6).
4. Frame your picture in the VIEWFINDER
EYEPIECE
5. Press the SHUTTER BUTTON (16). The
SELF-TIMER LAMP (13) on the front of
the camera will blink and then glow during the last two seconds of countdown.
• To cancel the self-timer selection
• The self-timer automatically turns off
(19).
before the shutter releases, turn the camera off.
after the shutter releases and returns to the auto-flash start position.
DA TE AND TIME IMPRINTING
Traditional cameras print date and/or time information directly onto the film. Your camera uses the film’s magnetic data-recording capability to record date and time information which your photofinisher can imprint on the back of your photographs. This camera has a quartz clock and automatic calendar through the year 2099. You can record the date in a choice of three date formats (year/month/day, month/day/ year or day/month/year) and one time format (hour/minute).

Setting the date and time

1. Press the SELECT BUTTON (2)
repeatedly to scroll and select desired date format.
ON
2. Press the select button again and hold the button for approximately 2 seconds until the first number(s) of
SELECT
ENTER
OFF
the date/time position “blinks.”
3. Press the ENTER BUTTON (3) to change the “blinking” number(s).
4. Press the select button to store the selected number(s) and to activate the next “blinking” number(s) (follow steps 3 and 4 to complete your selection).

UNLOADING THE FILM

Automatic rewind

The camera automatically rewinds the film into the cassette after the last exposure.
1. Wait for the film to completely rewind into the film cassette.
• When the motor stops running, the
FRAME COUNTER (30) will indicate “0.”
2. Push the FILM-DOOR LATCH (21) up.
• The motor will run for a brief time,
then the film door will open.
3. Remove the film cassette from the camera and reload with new KODAK ADVANTIX Film.
• The FSI on the fully-exposed film
cassette will be at ✖ (#3 position) and the LCD panel will display “E.”
17

Manual rewind

If you don’t want to take pictures on the entire film, you can manually activate the automatic rewind.
1. Gently press the FILM-REWIND
2. Follow steps 1–3 from Automatic
NOTE: Y ou cannot reload partially exposed film into this camera for continuous picture-taking.
18
(4) by using a pointed object to
BUTTON
start the auto-film rewind.
Rewind.
SELECT
ENTER
ON
OFF

CARING FOR YOUR CAMERA

1. Protect the camera from dust,
moisture, sudden impact, and excessive heat.
CAUTION: Do not use solvents or harsh or abrasive cleaners on the camera body.
2. If the lens appears dirty, breathe on it to form a mist and wipe the surface gently with a soft, lintless cloth or camera lens-cleaning tissue. Never wipe a dry lens.
CAUTION: Do not use solvents or solutions not designed for cleaning camera lenses. Do not use chemically treated tissues intended for cleaning eye glasses.
3. Remove the battery when you store the camera for an extended time.
CAUTION: To prevent possible damage and electrical shock, do not attempt to disassemble or repair the camera or flash unit by yourself.

TROUBLESHOOTING

What happened Probable cause Solution
Camera will There are no more Remove the film not operate pictures remaining
Battery weak, dead, Replace or reload the missing, or improperly battery loaded
Film does not Battery weak, dead, Replace or reload advance or rewind missing, or the battery
LCD panel is blank Battery weak, dead, Replace or reload
Film cassette does Loaded partially exposed () Load only new film (●) not fit completely exposed (), or processed into the camera into the film chamber; film() into the camera film door does not close
improperly loaded
missing, or the battery improperly loaded
Camera in sleep mode Press any control button
to awaken camera
Camera turned off Turn on/off switch ON
19

SPECIFICA TIONS

Film type: KODAK ADVANTIX Film for color and black-and-white pictures Lens: 24–48 mm zoom lens, hybrid aspheric Focus system: 70 zones AF Focus range: Wide/Tele: 2 ft (0.6 m) to infinity
(daylight) Viewfinder: Real image with C, H, & P format display Film speed: DXIX (ISO) 50–1600 for color and black-and-white films Flash unit: Built-in/pop-up, KODAK SENSALITE™ Flash Flash range: Wide: 2 to 27 ft (0.6 to 8.2 m)
(ISO 200) Tele: 2 to 14 ft (0.6 to 4.3 m) Apertures: Shutter: Programmed electronic shutter, 1/5 to 1/360 seconds Power source: Main power: one 3 V lithium KODAK K123LA (or equivalent) Battery Dimensions: 4.5 x 2.5 x 1.3 in. (114 x 64 x 34 mm) Weight: 6.9 oz (195 g) without film and battery
Kodak, Sensalite, Advantix, and the Advanced Photo System symbol and logotype are trademarks.
20
f
/4.5–f/8.6
Appareil-photo
KODAK ADVANTIX
C650 Zoom
Bienvenue au monde novateur du système Advanced Photo System! Et merci d’avoir acheté cet Appareil-photo KODAK ADVANTIX.
BESOIN D’AIDE POUR UTILISER VOTRE APP AREIL-PHOTO?
Visitez notre site Web à l’adresse http://www.kodak.com. ou appelez : Kodak (Canada seulement) du lundi au vendredi, de 8 h à 17 h (heure de
l’Est) au numéro 1 800 465-6325, poste 36100. Dans la région de Toronto, composez le (416) 766-8233, poste 36100.
Kodak (É.-U. seulement), sans frais, du lundi au vendredi, de 9 h à 19 h (heure de l’Est) au numéro 1 800 242-2424.
Veuillez avoir en main votre appareil-photo au moment de téléphoner. Pour les besoins de la garantie, veuillez conserver votre facture de vente
à titre de preuve de la date d’achat.
Cet appareil numérique de Classe B répond à toutes les exigences du Règlement sur le matériel brouilleur du Canada.
FRANÇAIS
FONCTIONS ADV ANCED PHOTO SYSTEM OFFERTES A VEC CET APP AREIL-PHOTO
Choix de trois formats
• Vous avez le choix de trois formats différents : classique (C), groupe (H) ou panoramique (P), pour chacune des photos d’une même cassette de film. Le cadre affiché dans le viseur se modifie en fonction du format sélectionné.
Impression de la date et de l’heure
• Vous pouvez choisir de faire imprimer la date et l’heure au dos de vos photos. Consultez votre laboratoire de traitement photo pour connaître les services offerts.
Protection contre la double exposition
• Vous ne courez aucun risque d’exposer accidentellement votre film une seconde fois. Votre appareil vérifie l’indicateur de l’état du film sur la cassette afin de prévenir tout risque de réexposition.
22
Échange d’information pour l’amélioration de la qualité de l’image
• Votre appareil est doté de la fonction d’échange d’information magnétique, qui permet d’enregistrer sur la cassette même des renseignements sur les conditions d’éclairage et sur l’exposition. Le laboratoire de traitement peut ainsi corriger la couleur ou régler l’exposition afin que vos photos soient les plus réussies possible.
Dispositif de verrouillage du compartiment du film
• Le dispositif de verrouillage du compartiment du film empêche l’ouverture du couvercle avant que le film ne soit complètement rembobiné dans la cassette.
Ce symbole sur l’emballage de film vous garantit qu’il est compatible avec cet appareil-photo.
Assurez-vous que le laboratoire de traitement auquel vous confiez vos films affiche ce symbole; vous profiterez ainsi de toutes les caractéristiques du système Advanced Photo System.
Indicateur de l’état du film
Un voyant passe d’un symbole à l’autre pour indiquer l’état du film à l’intérieur de la cassette.
1
4
3
NÉGATIFS DÉVELOPPÉS
NON EXPOSÉ
PARTIELLEMENT
2
EXPOSÉ
TOTALEMENT EXPOSÉ
23

TABLE DES MA TIÈRES

DESCRIPTION DE L’APP AREIL-PHOTO....... 25
FIXATION DE LA DRAGONNE ...................... 26
INSTALLATION DE LA PILE .......................... 26
Indicateur de pile faible.............................. 27
Conseils au sujet des piles ........................ 27
Arrêt automatique ...................................... 27
CHARGEMENT DU FILM .............................. 28
POUR PRENDRE DES PHOTOS .................. 29
Formats des photos................................... 30
Mémorisation de la mise au point.............. 30
Utilisation de l’objectif zoom ...................... 31
Conseils pour prendre de
meilleures photos................................... 31
POUR PRENDRE DES PHOTOS
AU FLASH ................................................... 32
Distances entre le flash et le sujet............. 32
24
SÉLECTION DES MODES FLASH ET
MISE AU POINT À L’INFINI ......................... 33
Réduction des yeux rouges ....................... 33
Flash automatique sans réduction
des yeux rouges .................................... 34
Flash d’appoint .......................................... 35
Flash désactivé ......................................... 35
Mise au point à l’infini ................................ 36
Vue nocturne ............................................. 36
UTILISATION DU RETARDA TEUR ................ 37
IMPRESSION DE LA DATE ET DE L’HEURE ....
Réglage de la date et de l’heure................ 38
RETRAIT DU FILM ........................................ 39
Rembobinage automatique ....................... 39
Rembobinage manuel ............................... 39
ENTRETIEN DE VOTRE APP AREIL-PHOT O.....
DÉP ANNAGE ................................................. 41
CARACTÉRISTIQUES ................................... 42
38
40
DESCRIPTION DE L ’APPAREIL-PHOT O
(Pour consulter les schémas de l’appareil, ouvrez les rabats des couvertures recto et verso de ce manuel)
1 BARILLET DU ZOOM 2 BOUTON DE SÉLECTION 3 BOUTON DE SAISIE 4 BOUTON DE REMBOBINAGE DU
FILM
5 PANNEAU ACL 6 BOUTON DU RETARDATEUR 7 BOUTON DE SÉLECTION DU
MODE FLASH
8 SÉLECTEUR DU FORMAT DE PHOTO
9 FLASH 10 VISEUR 11 OBJECTIF 12 FENÊTRE DU POSEMÈTRE 13 TÉMOIN DU RETARDATEUR 14 TÉMOIN DE RÉDUCTION DES YEUX
ROUGES
15 CAPTEURS DE MISE AU POINT
AUTOMATIQUE
16 DÉCLENCHEUR 17 COUVERCLE DU COMPARTIMENT
LA PILE
DE
18 TÉMOIN DE LAPPAREIL-PHOTO/
FLASH PRÊT
19 OCULAIRE DU VISEUR 20 INTERRUPTEUR MARCHE/ARRÊT 21 LOQUET DU COMPARTIMENT DU
FILM
22 TIGE DE LA DRAGONNE 23 COMPARTIMENT DU FILM 24 COUVERCLE DU COMPARTIMENT
FILM
DU
25 ÉCROU DU TRÉPIED Panneau ACL
26 SYMBOLE DE LA PILE 27 AFFICHAGE DATE/HEURE 28 INDICATEUR DE VUE NOCTURNE 29 INDICATEUR DE RÉDUCTION DES
YEUX ROUGES
30 COMPTEUR DE POSES 31 INDICATEUR DU RETARDATEUR 32 INDICATEUR DU FLASH DAPPOINT 33 INDICATEUR DE MISE AU POINT
À LINFINI
34 INDICATEUR DE LA PRÉSENCE
DUN FILM
35 INDICATEUR DE FLASH DÉSACTIVÉ 36 INDICATEUR DE FLASH
25
FIXA TION DE LA DRAGONNE
1. Enfilez d’abord la petite boucle de la
dragonne sous la TIGE DE LA
DRAGONNE
2. Glissez ensuite la longue boucle dans
la petite.
3. Tirez fermement.
26
Use KODAK
ADVANTIX Film
(22).
INST ALLA TION DE LA PILE
Cet appareil-photo utilise 1 Pile au lithium KODAK K123LA (ou l’équivalent) qui fournit l’alimentation nécessaire à toutes les fonctions de l’appareil.
1. Ouvrez le
COUVERCLE DU COMPARTIMENT
LA PILE (17).
DE
• Avant de retirer la pile, veuillez mettre l’appareil-photo hors tension.
2. Insérez la pile dans le compartiment de la façon illustrée.
3. Refermez bien la porte du compartiment de la pile.
• Après avoir chargé une nouvelle
pile, vous devez régler la date et l’heure de nouveau.
Indicateur de pile faible
Il faut remplacer la pile lorsque
• le SYMBOLE DE LA PILE (26) clignote sur le PANNEAU ACL (5)
• aucun des indicateurs n’apparaît sur le panneau ACL et que le
DÉCLENCHEUR (16) ne peut être
enclenché.
ou
Conseils au sujet des piles
• A yez toujours des piles de rechange avec vous.
• Lisez le mode d’emploi et observez les mises en garde fournies par le fabricant des piles.
• Gardez les piles hors de la portée des enfants.
• N’essayez pas de démonter, de recharger ou de court-circuiter les piles, ou de les exposer à des températures élevées ou aux flammes.
• Conservez les piles dans leur emballage d’origine jusqu’à ce que vous les utilisiez.
Arrêt automatique
Cet appareil-photo se met automatiquement en mode veille (l’objectif revient en position grand­angulaire et le panneau ACL affiche seulement la date et l’heure) après plus de 3 minutes d’inactivité pour préserver l’énergie de la pile. Pour réactiver l’appareil, il suffit d’appuyer sur n’importe quel bouton de contrôle.
27
CHARGEMENT DU FILM
ON
4
3
2
1
ON
OFF
OPEN
Vous pouvez charger le film dans l’appareil-photo, que ce dernier soit SOUS TENSION ou HORS TENSION.
1. Faites glisser le
LOQUET DU COMPARTIMENT
FILM (21)
DU
pour ouvrir le
COUVERCLE DU COMPARTIMENT
DU FILM (24).
• Le couvercle ne s’ouvrira que si le compartiment du film est vide ou si le film qu’il contient est complètement rembobiné dans la cassette.
28
OPEN
2. Insérez complètement la cassette de film dans le COMPAR TIMENT DU
(23).
FILM
• Assurez-
OFF
vous que l’indicateur de l’état du film sur la cassette de film est bien vis-à-vis
(position 1) s’il s’agit d’une nouvelle cassette.
N’exercez pas de pression
excessive pour insérer la cassette dans le compartiment du film
3. Refermez le couvercle du
compartiment du film pour déclencher le mécanisme d’avance automatique du film. Le COMPTEUR DE POSES (30) sur le PANNEAU ACL (5) affichera le nombre de poses restantes.
• Une fois que vous avez refermé le
couvercle du compartiment du film avec verrouillage de sécurité, il ne pourra être rouvert que lorsque le film sera complètement rembobiné dans la cassette de film.
POUR PRENDRE DES PHOTOS
Vous pouvez prendre des photos de formats classique (C), groupe/HDTV (H)* et panoramique (P) sur la même cassette de film. Vos frais de traitement photo peuvent varier en fonction des formats choisis pour le développement.
1. Ouvrez l’INTERRUPTEUR
/
MARCHE ARRÊT (20) pour
mettre l’appareil-photo sous tension et soulever le
FLASH (9).
2. Déplacez le
SÉLECTEUR DU
DE
FORMAT PHOTO
(8) pour choisir le format désiré
* Les photos HDTV (télévision haute définition)
présentent le même rapport hauteur/largeur que la télévision, pour des capacités d’interface CD.
ON
OFF
OPEN
(C, H ou P). Le cadre du viseur s’ajustera pour délimiter la prise de vue sélectionnée.
3. Cadrez votre sujet en regardant dans l’OCULAIRE DU VISEUR (19). Pour une photo nette, placez-vous à au moins 0,6 m (2 pi) de votre sujet.
C
P
H
C P H
4. Appuyez sur le DÉCLENCHEUR (16) pour prendre la photo.
SELECT
ENTER
OFFON
OPEN
29
Formats des photos
CHP
Classique Groupe (HDTV) Panoramique
88,9 mm x 127 mm ou 88,9 mm x 152 mm ou 88,9 mm x 216 mm à
102 mm x 152 mm 102 mm x 178 mm 102 mm x 292,7 mm
(3,5 po x 5 po ou (3,5 po x 6 po ou (3,5 po x 8,5 po à
4 po x 6 po) 4 po x 7 po) 4 po x 11,5 po)
NOTA : Votre laboratoire de traitement photo offre généralement des photos de formats 4 po x 6 po, 4 po x 7 po et 4 po x 11,5 po (102 x 152, 102 x 178 et 102 x 292,7 mm). Certains peuvent aussi proposer les formats 3,5 po x 5 po, 3,5 po x 6 po et 3,5 po x 8,5 po (88,9 x 127, 88,9 x 152 et 88,9 x 216 mm).
Mémorisation de la mise au point
L’appareil-photo effectue automatiquement la mise au point sur tout ce qui se trouve à l’intérieur du cercle de mise au point automatique (AF) de l’oculaire du viseur. Pour obtenir une photo bien nette, assurez-vous d’orienter le cercle de mise au point sur votre sujet principal. Si vous désirez que le sujet principal de la photo soit à l’extérieur du cercle de mise au point, utilisez la fonction de mémorisation comme suit :
1. Centrez votre sujet principal à l’intérieur du cercle de mise au point.
30
CERCLE DE MISE AU POINT
VISEUR
2. Enfoncez partiellement le
DÉCLENCHEUR (16) et maintenez-le
en position pour verrouiller la mise au point.
3. Toujours en maintenant le déclencheur partiellement enfoncé, déplacez l’appareil jusqu’à ce que votre sujet se trouve à l’endroit voulu dans l’OCULAIRE DU
(19).
VISEUR
VISEUR
4. Enfoncez complètement le déclencheur pour prendre la photo.
Utilisation de l’objectif zoom
Doté d’un objectif zoom motorisé, cet appareil-photo vous permet de choisir la longueur focale de l’objectif convenant le mieux à la situation de prise de vue. Lorsque vous mettez l’appareil sous tension, la longueur focale est réglée par défaut en position grand-angulaire.
1. Faites glisser LINTERRUPTEUR MARCHE-
ARRÊT (20) en position «MARCHE» pour
mettre l’appareil-photo sous tension et soulever le FLASH (9).
2. Faites glisser le
BARILLET DU
(1) vers la
ZOOM
gauche en position grand­angulaire pour vous
éloigner
sujet. Ou faites glisser le barillet vers la droite en position téléobjectif pour vous
rapprocher
3. Cadrez ensuite votre sujet dans
LOCULAIRE DU VISEUR (19).
4. Puis, appuyez sur le DÉCLENCHEUR (16) pour prendre la photo.
ON
OPEN
du
du sujet.
• Le barillet reviendra automatiquement à la position «grand-angulaire» après environ 3 minutes
Conseils pour prendre de meilleures photos
• Approchez-vous suffisamment de votre sujet pour qu’il remplisse bien le viseur, sans toutefois vous placer à moins de 0,6 m (2 pi).
• Placez-vous au même niveau que votre sujet. Quand vous photographiez des enfants ou des animaux, agenouillez-vous.
• Tenez votre appareil à la verticale pour mettre en valeur les sujets de forme allongée, par exemple les chutes d’eau, les gratte-ciel ou une personne seule.
• Donnez de la dimension à vos photos en les encadrant avec une branche d’arbre, une fenêtre ou encore, avec les traverses d’une clôture.
• Placez-vous dos au soleil afin d’offrir le meilleur éclairage possible à votre sujet.
31
POUR PRENDRE DES PHOTOS AU FLASH
Dans des conditions de lumière faible, à l’intérieur, ou à l’extérieur dans des lieux ombragés ou par temps couvert, il vous faut utiliser un flash. Votre appareil-photo est doté d’un flash automatique qui s’actionne au besoin. En outre, le flash escamotable aide à minimiser l’effet des yeux rouges sur les photos prises avec le flash, et les risques d’obstruer l’objectif.
1. Placez l’INTERRUPTEUR MARCHE/
ARRÊT (20) en position «MARCHE» pour
mettre l’appareil-photo sous tension et soulever le FLASH (9).
• Le TÉMOIN DE LAPPAREIL-PHOTO/
FLASH PRÊT (18) «clignote» si le flash
n’est pas prêt.
2. Cadrez votre sujet en regardant dans
LOCULAIRE DU VISEUR (19).
3. Enfoncez partiellement le
DÉCLENCHEUR (16). Lorsque le TÉMOIN
LAPPAREIL-PHOTO/FLASH PRÊT (18)
DE
passe au vert, enfoncez complètement le déclencheur pour prendre la photo.
32
4. Assurez-vous que votre sujet se trouve à une distance qui soit appropriée pour la sensibilité du film chargé dans votre appareil (voir Distances entre le flash et le sujet). Ne vous éloignez pas au-delà de la distance maximum recommandée, sinon vos photos seront sombres.
Distances entre le flash et le sujet
Sensibilité Grand-angulaire Téléobjectif ISO du film (24 mm) (48 mm)
50 0,6 m à 4,3 m 0,6 m à 2,1 m
(2 pi à 14 pi) (2 pi à 7 pi)
10 0 0,6 m à 5,8 m 0,6 m à 3,1 m
(2 pi à 19 pi) (2 pi à 10 pi)
20 0 0,6 m à 8,2 m 0,6 m à 4,3 m
(2 pi à 27 pi) (2 pi à 14 pi)
40 0 0,6 m à 11,6 m 0,6 m à 6,1 m
(2 pi à 38 pi) (2 pi à 20 pi)
80 0 0,6 m à 16,2 m 0,6 m à 8,5 m
(2 pi à 53 pi) (2 pi à 28 pi)
1 600 0,6 m à 22,6 m 0,6 m à 12,2 m
(2 pi à 74 pi) (2 pi à 40 pi)
SÉLECTION DES MODES FLASH ET MISE AU POINT À L ’INFINI
Outre le mode flash automatique avec réduction des yeux rouges, vous pouvez choisir les modes flash automatique sans réduction des yeux rouges, flash d’appoint, flash désactivé, mise au point à l’infini et vue nocturne.
Appuyez sur le bOUTON DE
SÉLECTION MODE
jusqu’à ce que
DU
FLASH (7)
Réduction des yeux rouges
Les yeux de certaines personnes (et de certains animaux) peuvent réfléchir le flash et ainsi produire un éclat rouge sur les photos. Cet appareil-photo est doté d’un flash automatique avec option de réduction des yeux rouges par défaut. Grâce au flash escamotable et en suivant les directives ci­dessous, vous pouvez minimiser le phénomène des yeux rouges dans les photos prises avec flash ou flash d’appoint.
1. Glissez l’INTERRUPTEUR MARCHE/
l’indicateur du mode recherché apparaisse sur le PANNEAU ACL (5).
2. Appuyez sur le BOUTON DE SÉLECTION DU Une fois la photo prise, les modes flash demeureront actifs. Pour modifier le mode flash, il suffit d’appuyer sur le bouton de sélection du mode, ou de fermer puis rouvrir l’appareil-photo pour réinitialiser le flash au mode par défaut.
3. Cadrez bien votre sujet dans LOCULAIRE
ARRÊT (20) en position «MARCHE» pour
mettre l’appareil-photo sous tension et soulever le FLASH (9).
FLASH (7) successivement jusqu’à
MODE
ce que le flash automatique avec
INDICATEUR DE RÉDUCTION DES YEUX
(29) s’affiche sur le PANNEAU
ROUGES
(5).
ACL
• Passez l’étape 2 si l’appareil-photo est déjà réglé par défaut à réduction des yeux rouges.
VISEUR (19).
DU
33
4. Demandez ensuite à votre sujet de regarder bien en face le TÉMOIN DE
RÉDUCTION
DES YEUX ROUGES (14).
5. Enfoncez alors partiellement le
DÉCLENCHEUR (16). Lorsque le TÉMOIN
LAPPAREIL-PHOTO/FLASH PRÊT (18)
DE
passe au vert, appuyez complètement sur le déclencheur pour prendre la photo.
34
Flash automatique sans réduction des yeux rouges
Utilisez ce mode pour prendre des photos sans personnages.
Vous pouvez changer le réglage par défaut à flash automatique sans réduction des yeux rouges de la façon suivante :
1. Glissez l’INTERRUPTEUR MARCHE/
ARRÊT (20) en position «MARCHE» pour
mettre l’appareil-photo sous tension et soulever le FLASH (9).
2. Appuyez sur le BOUTON DE SÉLECTION DU FLASH (7) successivement jusqu’à
MODE
ce que l’INDICATEUR DE FLASH
AUTOMATIQUE PANNEAU ACL (5).
3. Cadrez bien votre sujet dans LOCULAIRE
VISEUR (19).
DU
4. Enfoncez ensuite partiellement le
DÉCLENCHEUR (16). Lorsque le TÉMOIN DE
APPAREIL-PHOTO/FLASH PRÊT (18) passe
L
au vert, appuyez complètement sur le déclencheur pour prendre la photo.
• L ’appareil-photo est maintenant réglé par défaut au mode flash automatique sans réduction des yeux rouges.
(36) s’affiche sur le
Flash d’appoint
OFF
À l’intérieur ou à l’extérieur, la lumière vive projetée sur des sujets éclairés à contre­jour peut créer des ombres marquées (en particulier sur les visages). Pour adoucir ces ombres, il suffit d’utiliser le flash d’appoint.
1. Placez l’INTERRUPTEUR MARCHE/
ARRÊT (20) en position «MARCHE» pour
mettre l’appareil-photo sous tension et soulever le FLASH (9).
2. Appuyez à plusieurs reprises sur le
BOUTON DE SÉLECTION DU MODE
(7) jusqu’à ce que l’INDICATEUR
FLASH
FLASH DAPPOINT (32) soit affiché sur
DU
le PANNEAU ACL (5).
3. Cadrez bien votre sujet dans l’OCULAIRE VISEUR (19).
DU
4. Enfoncez partiellement le
DÉCLENCHEUR (16). Lorsque le TÉMOIN
LAPPAREIL-PHOTO/FLASH PRÊT (18)
DE
passe au vert, enfoncez complètement le déclencheur pour prendre la photo.
Flash désactivé
Lorsque vous ne voulez pas utiliser le flash, notamment à l’intérieur dans les endroits où on l’interdit (comme les musées et les théâtres), pour photographier des scènes au crépuscule ou des sujets éloignés situés au-delà de la portée du flash, ou encore pour saisir l’atmosphère créée par la l lumière ambiante, utilisez la fonction de flash désactivé. Servez-vous d’un trépied ou placez l’appareil sur une surface stable, et utilisez un film de sensibilité élevée parce que la vitesse d’obturation sera vraisemblablement plus lente la nuit.
1. Placez l’INTERRUPTEUR MARCHE/
ARRÊT (20) en position «MARCHE» pour
mettre l’appareil-photo sous tension et soulever le FLASH (9).
2. Appuyez sur le BOUTON DE SÉLECTION MODE FLASH (7) à plusieurs reprises
DU
jusqu’à ce que l’INDICATEUR DU FLASH
DÉSACTIVÉ PANNEAU ACL (5).
3. Cadrez bien votre sujet dans
l’OCULAIRE DU VISEUR (19).
(35) soit affiché sur le
35
4. Enfoncez partiellement le
DÉCLENCHEUR (16). Lorsque le TÉMOIN
LAPPAREIL-PHOTO/FLASH PRÊT (18)
DE
passe au vert, enfoncez complètement le déclencheur pour prendre la photo.
Mise au point à l’infini
Saisissez nettement des scènes éloignées, et ce, à n’importe quelle position zoom (seulement en lumière du jour et à l’extérieur).
1. Placez l’INTERRUPTEUR MARCHE/
ARRÊT (20) en position «MARCHE» pour
mettre l’appareil-photo sous tension et soulever le FLASH (9).
2. Appuyez sur le BOUTON DE SÉLECTION MODE FLASH (7) à plusieurs reprises
DU
jusqu’à ce que l’INDICATEUR DE MISE AU
À LINFINI (33) soit affiché sur le
POINT PANNEAU ACL (5).
3. Cadrez bien votre sujet dans
l’OCULAIRE DU VISEUR (19).
4. Enfoncez partiellement le
DÉCLENCHEUR (16). Lorsque le TÉMOIN
LAPPAREIL-PHOTO/FLASH PRÊT (18)
DE
36
passe au vert, enfoncez complètement le déclencheur pour prendre la photo.
Vue nocturne
Avec ce mode, l’appareil-photo est en mesure d’équilibrer l’intensité du flash en fonction de l’éclairage existant pour vous permettre de prendre de superbes photos de gens au coucher du soleil ou en soirée. Servez-vous d’un trépied ou placez l’appareil sur une surface stable, et utilisez un film de sensibilité élevée parce que la vitesse d’obturation sera vraisemblablement plus lente la nuit.
1. Placez l’INTERRUPTEUR MARCHE/
ARRÊT (20) en position «MARCHE» pour
mettre l’appareil-photo sous tension et soulever le FLASH (9).
2. Appuyez sur le BOUTON DE SÉLECTION MODE FLASH (7) à plusieurs reprises
DU
jusqu’à ce que l’INDICATEUR DE VUE
NOCTURNE PANNEAU ACL (5).
3. Cadrez bien votre sujet dans
l’OCULAIRE DU VISEUR (19).
(28) soit affiché sur le
4. Enfoncez partiellement le
DÉCLENCHEUR (16). Lorsque le TÉMOIN
LAPPAREIL-PHOTO/FLASH PRÊT (18)
DE
passe au vert, enfoncez complètement le déclencheur pour prendre la photo.
UTILISA TION DU RET ARDA TEUR
Utilisez ce mode si vous souhaitez vous inclure dans la photo.
1. Utilisez l’ECROU DU TRÉPIED (25) pour fixer l’appareil-photo sur un trépied ou placez-le sur une surface stable.
2. Placez l’INTERRUPTEUR MARCHE/
ARRÊT (20) en position «MARCHE» pour
mettre l’appareil-photo sous tension et soulever le FLASH (9).
3. Appuyez sur le BOUTON DU
RETARDATEUR
4. Cadrez bien votre sujet dans l’OCULAIRE DU VISEUR (19).
(6).
5. Enfoncez le DÉCLENCHEUR (16). Le
TÉMOIN DU RETARDATEUR (13) situé sur
le devant de l’appareil s’allumera, puis clignotera pendant les deux dernières secondes du compte à rebours.
• Pour annuler le mode retardateur avant que la photo ne soit prise, il suffit de mettre l’appareil-photo hors tension.
• Le retardateur se désactive automatiquement une fois le déclencheur relâché et revient à sa position de départ.
37
IMPRESSION DE LA DA TE ET DE L’HEURE
Les appareils-photo traditionnels impriment la date et l’heure de la photo directement sur le film. Votre appareil utilise plutôt la bande magnétique du film pour y enregistrer les données de date et heure, que votre laboratoire pourra imprimer plus tard au dos de vos photos. Cet appareil possède une horloge à quartz et un calendrier automatique allant jusqu’en l’an 2099. Vous pouvez inscrire la date, sous trois formats différents (année/mois/ jour, jour/mois/année ou mois/jour/ année), et l’heure (heure/minutes).
38
Réglage de la date et de l’heure
1. Appuyez sur le BOUTON DE
SÉLECTION
pour choisir le format de date souhaité.
2. Appuyez de nouveau sur le bouton de sélection et
maintenez-le
pendant environ 2 secondes, jusqu’à ce que les premiers chiffres de la date ou de l’heure clignotent.
3. Appuyez sur le BOUTON DE SAISIE (3) pour changer les chiffres qui «clignotent».
4. Puis, appuyez sur le bouton de sélection pour enregistrer votre choix et activer la prochaine partie de la date ou de l’heure (clignotante); répétez les étapes 3 et 4 pour achever votre sélection.
(2) de façon successive
SELECT
ENTER
ON
OFF
RETRAIT DU FILM
Rembobinage automatique
L’appareil-photo rembobinera automatiquement le film dans la cassette une fois la dernière photo prise.
1. Attendez que le film soit complètement rembobiné dans la cassette.
• Lorsque le moteur s’arrête, le
COMPTEUR DE POSES (30)
indique «0».
2. Soulevez le LOQUET DU COMPARTIMENT
FILM (21).
DU
• Le moteur tournera quelques
instants, puis le couvercle s’ouvrira.
3. Retirez la cassette de film de l’appareil-photo, puis rechargez-le avec une nouvelle cassette de Film KODAK ADVANTIX.
• L’indicateur de l’état du film d’une
cassette de film entièrement exposé sera vis-à-vis ✖ (position 3); un
«E» s’affichera en outre sur le
panneau ACL.
Rembobinage manuel
Si vous ne souhaitez pas prendre toutes les photos du rouleau de film, vous pouvez activer de façon manuelle le dispositif de rembobinage automatique.
1. Appuyez délicatement sur le BOUTON REMBOBINAGE DU FILM (4) au moyen
DE
d’un objet pointu pour activer le dispositif de rembobinage automatique.
2. Poursuivez avec les étapes 1 à 3 de la
section
Rembobinage automatique
NOTA : Vous ne pouvez recharger cet appareil avec un film partiellement exposé pour poursuivre la prise de photos.
SELECT
ENTER
ON
OFF
.
39
ENTRETIEN DE VOTRE APP AREIL-PHOTO
1. Préservez votre appareil-photo de la
poussière, de l’humidité, des chocs et de la chaleur excessive.
ATTENTION : N’utilisez pas de solvants ou de produits rugueux ou abrasifs pour nettoyer le boîtier de l’appareil-photo.
2. Si l’objectif est sale, placez-le devant votre bouche, puis expirez légèrement pour former un léger brouillard; nettoyez ensuite à l’aide d’un linge doux, sans charpie, ou d’un tissu nettoyant pour objectif. N’essuyez jamais un objectif à sec.
ATTENTION : N’utilisez pas de solvants ou de produits qui ne sont pas spécialement conçus pour nettoyer les objectifs d’appareil-photo. N’utilisez pas non plus de tissus traités chimiquement et destinés au nettoyage des verres.
40
3. Retirez les piles lorsque vous entreposez l’appareil-photo pour une longue période.
ATTENTION : Pour prévenir tout dommage ou choc électrique, n’essayez pas de désassembler ou de réparer vous-même l’appareil-photo ou le flash.
DÉP ANNAGE
Problème Cause probable Solution
L’appareil-photo ne Il ne reste plus de photos Retirez le film. fonctionne pas. à prendre.
La pile est faible, épuisée, Remplacez ou réinstallez manquante ou mal installée. la pile.
Le film n’avance pas ou La pile est faible, épuisée, Remplacez ou réinstallez ne se rembobine pas. manquante ou mal installée. la pile.
Le panneau ACL La pile est faible, épuisée, Remplacez ou réinstallez est vierge. manquante ou mal installée. la pile.
L’appareil-photo est en Appuyez sur n’importe mode veille. quel bouton de contrôle.
La cassette de film ne Le film que vous tentez de Chargez uniquement de s’insère pas dans le charger dans l’appareil- nouveaux films () dans compartiment du film; le photo est déjà exposé (✖), l’appareil-photo. couvercle du compartiment. partiellement expose (◗)
L’appareil-photo est Mettez l’appareil-photo hors tension. sous tension.
ou traité (■).
41
CARACTÉRISTIQUES
Type de film : Film KODAK ADVANTIX pour photos couleur ou noir et blanc Objectif : Objectif zoom asphérique hybride, 24 mm à 48 mm Système de mise
au point : Mise au point automatique à 70 zones Portée de la mise
au point Viseur : Image réelle avec affichage des formats C, H et P Sensibilités de film : Films pour photos couleur ou noir et blanc DXIX 50 à
Flash : Flash intégré escamotable KODAK SENSALITE Portée du flash
Ouvertures : Obturateur : Électronique préprogrammé, 1/5 à 1/360 seconde Alimentation : Principale : 1 Pile au lithium 3V KODAK K123LA
Dimensions : 114 mm x 64 mm x 34 mm (4,5 po x 2,5 po x 1,3 po) Poids : 195 g (6,9 oz) sans pile ni film
42
(lumière du jour)
: Grand-angulaire/Téléobjectif : 0,6 m (2 pi) à l’infini
(200 ISO)
Kodak, Sensalite, Advantix et les symbole et logo
Advanced Photo System sont des marques de commerce.
1600 ISO
:Grand-angulaire : 0,6 m à 8,2 m (2 pi à 27 pi)
Téléobjectif : 0,6 m à 4,3 m (2 pi à 14 pi)
f
/4,5 à f/8,6
(ou l’équivalent)
MC
KODAK ADV ANTIX
Cámara Zoom C650
¡Bienvenidos al mundo innovador del Advanced Photo System! Y gracias por comprar esta cámara KODAK ADVANTIX.
¿NECESIT A A YUDA CON SU CÁMARA?
Visite nuestro sitio en la red mundial electrónica (worldwide web) a la dirección http://www.kodak.com o llame a:
Kodak (en los Estados Unidos solamente), llamada sin cargo al número 1 (800) 242-2424, de lunes a viernes de 9:00 a.m. a 7:00 p.m. (hora del este).
Kodak (solamente en el Canadá) , llamada sin cargo al número 1 (800) 465-6325, extensión 36100, de lunes a viernes de 8:00 a.m. a 5:00 p.m. (hora del este); para el área de Toronto, llame al (416) 766-8233 extensión 36100.
Cuando llame, por favor asegúrese de tener la cámara disponible. Para hacer válida la garantía, sírvase guardar el recibo de venta como
prueba de la fecha de compra.
ESPAÑOL
Este dispositivo cumple con la parte 15 de las reglamentaciones de la FCC. El manejo está supeditado a las siguientes dos condiciones: (1) Este dispositivo puede no causar interferencia dañina, y (2) este dispositivo debe aceptar cualquier interferencia recibida, incluyendo interferencia la cual pudiese causar un funcionamiento indeseable.
NOTA: El modelo de su cámara ha sido aprobado y cumple con las limitaciones
establecidas para un dispositivo digital Clase B, de acuerdo con la Parte 15 de las reglamentaciones de la FCC. Estas limitaciones proveen una protección razonable en contra de la interferencia que se encuentra en uso residencial. La cámara genera, usa, y puede emitir energía de frecuencia radial y si no es usada de acuerdo con las instrucciones, puede causar interferencia a comunicaciones de radio. No se puede garantizar que esta interferencia no ocurra. En caso de que esta cámara cause interferencia a la recepción de radio o televisión, lo cual puede ser determinado encendiendo y apagando la cámara, puede reducir la interferencia haciendo lo siguiente:
– Vuelva a orientar o situar la antena de recepción – Aumente la distancia entre la cámara y el receptor – Para recibir ayuda consulte con el distribuidor o un técnico especializado en
radio/televisión
Cambios o modificaciones no aprobadas por el contratante responsable de acatar estas regulaciones podría anular la autoridad del consumidor para operar éste equipo.
44
Busque este logo para asegurarse que la película que usted compre esté hecha para esta cámara.
Busque este logo para seleccionar un servicio de fotoacabado certificado para revelar su rollo y para asegurarse de aprovechar todos los beneficios del Advanced Photo System.
Indicador del estado de la película (FSI)
El indicador realzado avanzará de una posición a otra para identificar el estado de la película dentro del cartucho.
1
4
3
NEGATIVOS PROCESADOS
NO EXPUESTA
PARCIALMENTE
2
EXPUESTA
COMPLETAMENTE EXPUESTA
45
CARACTERÍSTICAS DEL ADV ANCED PHOTO SYSTEM DISPONIBLES CON EST A CÁMARA
Selección triple de formato
• Usted puede tomar, en el mismo rollo, fotografías en tres tamaños diferentes: Clásico (C), Grupo/HDTV (H), y Panorámico (P). El marco del ocular del visor cambia según el formato seleccionado.
Impresión de fecha y hora
• Usted puede escoger si quiere que la información de la fecha y hora sea impresa en el la parte de atrás de sus fotografías. Vea a su servicio de fotoacabado para una descripción total de los servicios disponibles.
Protección en contra de doble exposición (DEP)
• No debe preocuparse de accidentalmente volver a exponer su película ya usada. Su cámara lee el Indicador del estado de película (FSI) en el cartucho de la película y de esta forma previene la doble exposición.
46
Intercambio de información sobre la calidad de la fotografía (PQix)
• Su cámara tiene la característica de intercambio de información magnética la cual registra información, en el cartucho de la película, acerca de la condición de iluminación y exposición. Esta característica asiste al laboratorio de fotoacabado en la rectificación del color y los ajustes de exposición y de esta forma se provee el mejor resultado posible.
Traba de seguridad en la puerta del compartimiento de película
• La traba de seguridad en la puerta del compartimiento de película previene que la puerta se pueda abrir antes de que la película esté completamente rebobinada.

CONTENIDO

IDENTIFICACIÓN DE LA CÁMARA............... 48
COMO AJUST AR LA CORREA
DE LA CÁMARA .......................................... 49
COMO CARGAR LA BATERÍA ...................... 49
Indicador de batería débil .......................... 50
Consejos para usar la batería ................... 50
Apagado automático ................................. 50
COMO CARGAR LA PELÍCULA .................... 51
COMO TOMAR FOTOGRAFÍAS .................... 52
Tamaños típicos de impresión
de fotografías (formatos)........................ 53
Como usar el cerrojo de enfoque .............. 53
Como usar el lente de zoom...................... 54
Consejos útiles para obtener mejores
fotografías .............................................. 54
COMO TOMAR FOTOGRAFÍAS
CON FLASH ................................................ 55
Distancia del sujeto al flash ....................... 55
COMO SELECCIONAR LOS MODOS DE FLASH
Y ENFOQUE INFINITO ................................ 56
Reducción de ojos rojos ........................... 56
Flash automático sin reducción de
ojos rojos ............................................... 57
Flash de relleno ......................................... 57
Flash apagado........................................... 58
Enfoque infinito.......................................... 58
Vista de noche........................................... 59
COMO USAR EL
DISPARADOR AUTOMÁTICO..................... 59
COMO IMPRIMIR LA FECHA Y HORA ......... 60
Como fijar la fecha y hora.......................... 60
COMO DESCARGAR LA PELÍCULA ............ 61
Rebobinado automático ............................ 61
Rebobinado manual .................................. 61
CUIDADO DE LA CÁMARA ........................... 62
PROBLEMAS Y SOLUCIONES ..................... 63
ESPECIFICACIONES .................................... 64
47
IDENTIFICACIÓN DE LA CÁMARA
(Abra la cubierta del frente y la de atrás de este manual para ver los diagramas de la cámara)
20
1
PALANCA DEL DISCO SELECTOR DEL ZOOM
2
BOTÓN DE SELECCIÓN
3
BOTÓN DE ENTRADA
4
BOTÓN DE REBOBINADO DE PELÍCULA
5
PANEL LCD
6
BOTÓN DE DISPARADOR AUTOMÁTICO
7
BOTÓN DE MODO DE FLASH
8
PALANCA DE SELECCIÓN DE FORMATO
9
FLASH
10
VISOR
11
LENTE
12
VENTANA DE MEDIDOR DE CÉLULA FOTOELÉCTRICA
13
LÁMPARA DE DISPARADOR AUTOMÁTICO
14
LÁMPARA DE REDUCCIÓN DE OJOS ROJOS
15
SENSORES DE ENFOQUE AUTOMÁTICO
16
BOTÓN DEL DISPARADOR
17
PUERTA DEL COMPARTIMIENTO
BATERÍA
DE
18
LÁMPARA DE FLASH/CÁMARA LISTA
19
OCULAR DEL VISOR
48
INTERRUPTOR DE ENCENDER/APAGAR
21
SEGURO DE LA PUERTA DEL COMPARTIMIENTO
22
PRESILLA DE LA CORREA
23
COMPARTIMIENTO DE PELÍCULA
24
PUERTA DEL COMPARTIMIENTO DE PELÍCULA
25
MONTAJE PARA TRÍPODE
DE
PELÍCULA
Panel LCD 26
SÍMBOLO DE BATERÍA
27
EXHIBICIÓN DE FECHA/HORA
28
INDICADOR DE VIST A DE NOCHE
29
INDICADOR DE REDUCCIÓN DE
ROJOS
OJOS
30
CONTADOR DE CUADROS
31
INDICADOR DE DISPARADOR AUTOMÁTICO
32
INDICADOR DE FLASH DE RELLENO
33
INDICADOR DE ENFOQUE INFINITO
34
INDICADOR DE LA PRESENCIA
PELÍCULA
DE
35
INDICADOR DE FLASH APAGADO
36
INDICADOR DE FLASH AUTOMÁTICO
COMO AJUST AR LA CORREA DE LA CÁMARA
1. Pase el extremo corto de la correa por
detrás de la PRESILLA DE LA
(22).
CORREA
Use KODAK
ADVANTIX Film
2. Ponga el extremo largo de la correa a través del corto.
3. Tire de la correa hasta que quede ajustada.
COMO CARGAR LA BA TERÍA
Esta cámara utiliza una batería de litio de 3 voltios KODAK K123LA (o su equivalente) que proporcionan la energía necesaria para todas las funciones de la cámara.
1. Abra la PUERTA
DEL COMPARTIMIENT O
BATERÍA (17).
DE
• Antes de retirar la batería usada, apague la cámara.
2. Coloque la batería en su compartimiento como aquí se indica.
3. Cierre a presión la puerta del compartimiento de batería.
• Después que cargue la batería
nueva en la cámara, necesitará volver a poner la fecha y hora.
49
Indicador de batería débil
Debe cambiar la batería cuando —
• el SÍMBOLO DE LA BATERÍA (26) “parpadea” en el PANEL LCD (5) o
• ninguno de los indicadores aparece en el panel LCD y el BOTÓN DEL
DISPARADOR
(16) no funciona.
Consejos para usar la batería
• Acuérdese de llevar una batería de repuesto con usted en todo momento.
• Lea y siga todas las advertencias e instrucciones del fabricante de la batería.
• Mantenga las baterías fuera del alcance de los niños.
• No intente desarmar, recargar o causar un cortocircuito en las baterías o exponerlas a altas temperaturas o fuego.
• Antes de usarlas, guarde las baterías en su empaque original.
50
Apagado automático
Cuando la cámara no se usa por aproximadamente 3 minutos, ésta se apagará automáticamente para conservar la energía de la batería (el lente regresará a la posición de gran angular y el panel LCD demostrará solamente la fecha y hora). Para activar la cámara, puede oprimir cualquiera de los botones de control.
COMO CARGAR LA PELÍCULA
ON
Puede cargar película en la cámara cuando la cámara esté ENCENDIDA o APAGADA.
1. Deslice el
SEGURO DEL COMPARTIMIENT O
PELÍCULA (21)
DE
para abrir la
PUERTA DEL COMPARTIMIENT O
PELÍCULA (24).
DE
• La puerta del compartimiento de película se abrirá solamente cuando el compartimiento de película esté vacío o la película en la cámara esté completamente rebobinada dentro del cartucho de la película.
OFF
OPEN
2. Ponga el cartucho de película completamente en el COMPARTIMIENTO
PELÍCULA (23).
DE
• Asegúrese
que el Indicador del estado de película (FSI) en el cartucho de
ON
OFF
OPEN
1
4
2
3
la película está en (posición #1) para un cartucho nuevo.
No fuerce el cartucho de película
en el compartimiento de película.
3. Cierre la puerta del compartimiento de
película para comenzar el avance automático de la misma. El contador
DE CUADROS (30) en el PANEL LCD (5)
mostrará el número de exposiciones restantes.
• Después que cierre la traba del
seguro de la puerta del compartimiento de película, no podrá abrirla hasta que toda la película haya sido rebobinada en el artucho.
51
COMO TOMAR FOTOGRAFÍAS
Puede tomar fotografías Clásicas (C), Grupo/HDTV (H)*, y Panorámicas (P) usando el mismo cartucho de película. El costo del revelado de sus fotografías puede estar basado en el/los tamaño(s) del formato que usó cuando expuso la película.
1. Para encender la cámara y levantar el FLASH (9), deslice el INTERRUPTOR DE
ENCENDER APAGAR (20) a
/
la posición ENCENDER
2. Mueva la PALANCA
SELECCIÓN DE
DE FORMATO
(8) al formato deseado (C, H, o P). El visor cambiará y demostrará el campo de vista seleccionado.
* Impresiones de Televisión de Alta Definición
(HDTV) son del mismo aspecto proporcional como las capacidades interfaciales de la TV para CD.
52
ON
OFF
OPEN
3. Encuadre a su sujeto dentro del
OCULAR DEL VISOR (19). Para una
fotografía nítida, manténgase a una distancia mínima de 2 pies (0,6 m) de su sujeto.
C
P
H
C P H
4. Oprima el botón DEL DISPARADOR (16) para tomar la fotografía
SELECT
ENTER
OFFON
OPEN
Tamaños típicos de impresión de fotografías (formatos)
CHP
Clásica Grupo (HDTV) Panorámico
3.5 x 5” ó 3.5 x 6” ó 3.5 x 8.5” a 4 x 6 “ 4 x 7” 4 x 11.5”
(88,9 x 127 mm ó (88,9 x 152 mm ó (88,9 x 216 mm a
102 x 152 mm) 102 x 178 mm) 102 x 292,7 mm)
NOTA: Su laboratorio de fotoacabado usualmente provee impresiones en los tamaños de 4 x 6, 4 x 7, y 4 x 11.5 pulgadas (102 x 152, 102 x 178, y 102 x 292,7 mm). Algunos laboratorios locales de fotoacabado pueden ofrecer impresiones en los tamaños 3.5 x 5,
3.5 x 6, y 3.5 x 8.5 pulgadas (88,9 x 127, 88,9 x 152, y 88,9 x 216 mm).
Como usar el cerrojo de enfoque
Esta cámara se enfoca automáticamente en cualquier objeto que aparezca en el círculo de enfoque automático (AF) del ocular del visor. Para obtener una fotografía nítida, asegúrese que el sujeto a fotografiar esté dentro del círculo de enfoque automático (AF). Si desea tomar una fotografía con el sujeto fuera del círculo de enfoque automático (AF), use el cerrojo de enfoque de la siguiente manera:
1. Coloque el círculo de enfoque automático (AF) sobre el sujeto que quiera enfocar en la fotografía.
CÍRCULO AF
VISOR
2. Oprima parcialmente y mantenga oprimido el BOTÓN DEL
DISPARADOR
(16) para asegurar la
posición enfocada.
3. Con el disparador parcialmente oprimido, mueva la cámara hasta que el sujeto se encuentre en la posición que usted desee dentro del ocular deL
(19).
VISOR
VISOR
4. Oprima completamente el disparador para tomar la fotografía.
53
Como usar el lente de zoom
Esta cámara tiene un lente motorizado de zoom que le permite seleccionar la distancia ideal de enfoque del lente al tomar fotografías. Cuando encienda la cámara, automáticamente el lente se encuentra en la posición de gran angular.
1. Para encender la cámara y levantar el
FLASH (9), deslice el INTERRUPTOR DE ENCENDER APAGAR (20)
a la posición ENCENDER.
2. Deslice hacia la izquierda la
PALANCA DEL DISCO SELECTOR ZOOM
angular, para alejarse del sujeto. Deslice la palanca hacia la derecha, a la posición de telefotográfico, para acercarse al sujeto.
3. Encuadre al sujeto dentro del OCULAR
DEL
54
/
ON
OPEN
DEL
(1), a la posición de gran
VISOR (19).
4. Oprima el BOTÓN DEL DISPARADOR (16) para tomar la fotografía.
• El cilindro del lente automáticamente
regresará a la posición de modo de gran angular, después de aproximadamente 3 minutos.
Consejos útiles para obtener mejores fotografías
• Acérquese lo suficiente al sujeto a
fotografiar de modo que éste ocupe todo el visor, pero no más cerca de 2 pies (0,6 m).
• Tome fotografías al nivel del sujeto.
Arrodíllese para fotografiar niños y animales.
• Haga tomas verticales de sujetos altos
y angostos, como cascadas, rascacielos o una persona sola.
• Agregue interés a sus fotografías
incluyendo una rama, una ventana o una cerca.
• Manténgase de espalda al sol. Así se
logra mejor iluminación.
COMO TOMAR FOTOGRAFÍAS CON FLASH
A poca luz, ya sea en interiores, en exteriores donde hay mucha sombra o en días oscuros o nublados, necesitará usar el flash. Su cámara incluye un flash automático el cual se dispara cuando es necesario. El flash que se levanta automáticamente también ayuda a reducir al mínimo los ojos rojos en fotografías con flash y prevenir que el lente sea obstruido por su mano.
1. Para encender la cámara y levantar el
FLASH (9), deslice el INTERRUPTOR DE ENCENDER
ENCENDER.
• La LÁMPARA DE FLASH/CÁMARA
2. Encuadre su sujeto dentro del OCULAR
DEL
3. Oprima parcialmente el BOTÓN DEL
DISPARADOR DE
verde, oprima completamente el disparador para tomar la fotografía.
/APAGAR (20) a la posición
(18) “parpadeará” cuando el
LISTA
flash no esté listo.
VISOR (19).
(16). Cuando la LÁMPARA
FLASH/CÁMARA LISTA (18) brille
4. Mantenga el sujeto a fotografiar dentro del alcance indicado para la sensibilidad de la película en su cámara (vea
Distancia del sujeto al flash). No tome fotografías a
más distancia de la indicada o sus fotografías saldrán oscuras.
Distancia del sujeto al flash
Sensibilidad
ISO de la Gran angular Telefotográfico
película (24 mm) (48 mm)
50 2 a 14 pies 2 a 7 pies
(0,6 a 4,3 m) (0,6 a 2,1 m)
100 2 a 19 pies 2 a 10 pies
(0,6 a 5,8 m) (0,6 a 3,1 m)
200 2 a 27 pies 2 a 14 pies
(0,6 a 8,2 m) (0,6 a 4,3 m)
400 2 a 38 pies 2 a 20 pies
(0,6 a 11,6 m) (0,6 a 6,1 m)
800 2 a 53 pies 2 a 28 pies
(0,6 a 16,2 m) (0,6 a 8,5 m)
1600 2 a 74 pies 2 a 40 pies
(0,6 a 22,6 m) (0,6 a 12,2 m)
55
COMO SELECCIONAR LOS MODOS DE FLASH Y ENFOQUE INFINITO
Además del modo de flash automático con reducción de ojos rojos, puede seleccionar los modos de flash automático sin reducción de ojos rojos, flash de relleno, flash apagado, enfoque infinito y vista de noche.
Oprima el BOTÓN DE
DE FLASH (7)
MODO
hasta que el indicador que usted desee aparezca en el PANEL
(5).
LCD
Los modos de flash se mantendrán
inicialmente fijada la característica de un flash automático con reducción de ojos rojos. Con la ayuda del flash que se levanta automáticamente y siguiendo las instrucciones que aquí se indican, usted puede reducir al mínimo los ojos rojos en fotografías con flash o con flash de relleno.
1. Para encender la cámara y levantar el
FLASH (9), deslice el INTERRUPTOR DE ENCENDER
ENCENDER.
2. Oprima repetidamente el BOTÓN DE
MODO INDICADOR DE REDUCCIÓN DE OJOS ROJOS
• Omita este paso si al encender la
encendidos después que se tome la fotografía. Para cambiar la selección de modos de flash, oprima el botón de modo de flash o apague la cámara y vuelva a encenderla para regresar a los modos de flash.
Reducción de ojos rojos
Los ojos de algunas personas (y algunos animales) se pueden reflejar en la fotografía, cuando se usa el flash, como un brillo rojo. Esta cámara tiene
56
3. Encuadre su sujeto dentro del OCULAR
DEL
4. Haga que sujeto mire directamente a la
LÁMPARA DE REDUCCIÓN DE OJOS ROJOS
5. Oprima parcialmente el BOTÓN DEL
DISPARADOR FLASH
oprima completamente el disparador para tomar la fotografía.
/APAGAR (20) a la posición
DE FLASH (7) hasta que el
(29) aparezca en el PANEL LCD (5).
cámara el modo de reducción de ojos rojos ya está seleccionado.
VISOR (19).
(14).
(16). Cuando la lÁMPARA DE
/CÁMARA LISTA (18) brille verde,
Flash automático sin reducción de ojos rojos
Use este modo para tomar fotografías que no incluyan a personas.
Usted puede cambiar el modo a flash automático sin reducción de ojos rojos siguiendo las instrucciones que aquí se indican:
1. Para encender la cámara y levantar el
FLASH (9), deslice el INTERRUPTOR DE ENCENDER
ENCENDER.
2. Oprima repetidamente el BOTÓN DE
MODO INDICADOR DE FLASH AUTOMÁTICO (36)
aparezca en el PANEL LCD (5).
3. Encuadre su sujeto dentro del OCULAR
DEL
4. Oprima parcialmente el BOTÓN DEL
DISPARADOR DE
verde, oprima completamente el disparador para tomar la fotografía.
• La cámara cambiará al modo de
/APAGAR (20) a la posición
DE FLASH (7) hasta que el
VISOR (19).
(16). Cuando la LÁMPARA
FLASH/CÁMARA LISTA (18) brille
flash automático sin reducción de ojos rojos.
Flash de relleno
En escenas interiores o exteriores de mucho contraste, sombras (especialmente en las caras) pueden ser causadas cuando los sujetos tienen como iluminación de fondo una luz brillante (contraluz). Use el flash de relleno para aclarar estas sombras.
1. Para encender la cámara y levantar el
FLASH (9), deslice el INTERRUPTOR DE ENCENDER
ENCENDER.
2. Oprima repetidamente el BOTÓN DE
MODO INDICADOR DE FLASH DE RELLENO (32)
aparezca en el PANEL LCD (5).
3. Encuadre su sujeto dentro del OCULAR
DEL
4. Oprima parcialmente el BOTÓN DEL
DISPARADOR DE
verde, oprima completamente el disparador para tomar la fotografía.
/APAGAR (20) a la posición
DE FLASH (7) hasta que el
VISOR (19).
(16). Cuando la LÁMPARA
FLASH/CÁMARA LISTA (18) brille
57
Flash apagado
OFF
Cuando no quiera usar el flash, especialmente en interiores donde el uso del flash está prohibido, come en teatros y museos, o cuando quiera fotografiar escenas en penumbras, o sujetos que se encuentran fuera del alcance del flash, o capturar el ambiente con la luz existente, use la función de flash apagado. Use un tripié o coloque la cámara sobre otra base firme, y use película de alta sensibilidad de ISO porque la mayor probabilidad es que, por la noche, la abertura del diafragma será lenta.
1. Para encender la cámara y levantar el
FLASH (9), deslice el INTERRUPTOR DE ENCENDER
/APAGAR (20) a la posición
ENCENDER.
2. Oprima repetidamente el BOTÓN DE
SELECCIÓN INDICADOR DE FLASH APAGADO (35)
/FLASH (7) hasta que el
aparezca en el PANEL LCD (5).
3. Encuadre su sujeto dentro del OCULAR VISOR (19).
DEL
58
4. Oprima parcialmente el BOTÓN DEL
DISPARADOR
FLASH/CÁMARA LISTA (18) brille
DE
(16). Cuando la LÁMPARA
verde, oprima completamente el disparador para tomar la fotografía.
Enfoque infinito
CAPTURE FOTOGrafías nítidas de escenas a mucha distancia en cualquiera posición del zoom (para uso en exteriores a la luz del día).
1. Para encender la cámara y levantar el
FLASH (9), deslice el INTERRUPTOR DE ENCENDER
ENCENDER.
2. Oprima repetidamente el BOTÓN DE
MODO INDICADOR DE ENFOQUE INFINITO (33)
aparezca en el PANEL LCD (5).
3. Encuadre su sujeto dentro del OCULAR
DEL
4. Oprima parcialmente el BOTÓN DEL
DISPARADOR DE
verde, oprima completamente el disparador para tomar la fotografía.
/APAGAR (20) a la posición
DE FLASH (7) hasta que el
VISOR (19).
(16). Cuando la LÁMPARA
FLASH/CÁMARA LISTA (18) brille
Vista de noche
Para que usted pueda tomar fotografías bellas de personas a la puesta del sol o por la noche, en este modo la cámara crea un balance entre el flash y la luz presente. Use un tripié o coloque la cámara sobre otra base firme y use película de alta sensibilidad de ISO porque la mayor probabilidad es que, por la noche, la abertura del diafragma será lenta.
1. Para encender la cámara y levantar el
FLASH (9), deslice el INTERRUPTOR DE ENCENDER
ENCENDER.
2. Oprima repetidamente el BOTÓN DE
MODO INDICADOR DE VISTA DE NOCHE (28)
aparezca en el PANEL LCD (5).
3. Encuadre su sujeto dentro del OCULAR
DEL
4. Oprima parcialmente el BOTÓN DEL
DISPARADOR DE
verde, oprima completamente el disparador para tomar la fotografía.
/APAGAR (20) a la posición
DE FLASH (7) hasta que el
VISOR (19).
(16). Cuando la LÁMPARA
FLASH/CÁMARA LISTA (18) brille
COMO USAR EL DISP ARADOR AUTOMÁTICO
Use esta característica para incluirse en las fotografías.
1. Use el MONTAJE PARA TRÍPODE (25) para montar la cámara en el tripié o coloque la cámara sobre otra base firme
2. Para encender la cámara y levantar el
FLASH (9), deslice el INTERRUPTOR DE ENCENDER
ENCENDER.
3. Oprima el BOTÓN DE DISPARADOR
AUTOMÁTICO
4. Encuadre su sujeto dentro del OCULAR
DEL
5. Oprima el BOTÓN DEL DISPARADOR (16). La LÁMPARA DE DISPARADOR
AUTOMÁTICO
cámara parpadeará y entonces brillará durante los dos últimos segundos de la cuenta regresiva.
• Para cancelar el modo de disparador
/APAGAR (20) a la posición
(6).
VISOR (19).
(13) en el frente de la
automático antes de tomar la fotografía, apague la cámara.
59
• Después que tome la fotografía, el disparador automático se cancela automáticamente y regresa al modo inicial de flash automático.
COMO IMPRIMIR LA FECHA Y HORA
Las cámaras tradicionales imprimen la información de la fecha y/u hora directamente en la película. Su cámara usa la característica de la franja magnética en la película para registrar la información de fecha y hora, la cual su fotoprocesador puede imprimir en la parte de atrás de sus fotografías. Esta cámara tiene un reloj de cuarzo y un calendario automático hasta el año 2099. Usted puede registrar la fecha en tres formatos distintos: (año/mes/día, mes/día/año, o día/mes/año) y un formato para la hora (hora/minuto).
60
Como fijar la fecha y hora
1. Oprima repetidamente el BOTÓN DE
SELECCIÓN
seleccionar el formato deseado para la impresión de la fecha.
2. Oprima nuevamente y mantenga oprimido el botón de selección por
aproximadamente 2 segundos hasta que el/los primer(os) número(s) en la posición de fecha/hora “parpadeen”.
3. Oprima el
BOTÓN DE ENTRADA (3) para cambiar
el/los número(s) “parpadeante(s)”.
4. Oprima el botón de selección para guardar el/los número(s) seleccionado(s) y para activar el/los próximo(s) número(s) “parpadeante(s)” (vuelva a usar los pasos 3 y 4 hasta completar su selección).
(2) para ver la lista y
SELECT
ENTER
ON
OFF
COMO DESCARGAR LA PELÍCULA
Rebobinado automático
Esta cámara automáticamente rebobina la película una vez que se haya tomado la última fotografía.
Rebobinado manual
Si no desea tomar el rollo completo de fotografías, usted puede manualmente activar el proceso de rebobinado automático.
1. Para comenzar el rebobinado
1. Espere a que la película se rebobine completamente dentro del cartucho.
Cuando el motor se detenga, el
CONTADOR DE CUADROS (30)
indicará “0”.
2. Siga los pasos 1–3 del Rebobinado
2. Deslice hacia arriba el INTERRUPTOR
COMPARTIMIENTO DE PELÍCULA (21).
DEL
• El motor trabajará por unos breves
momentos y entonces la puerta del compartimiento de película se abrirá.
NOTA: Para la toma continua de fotografías, no puede volver a cargar película parcialmente expuesta en esta cámara.
3. Retire el cartucho de película de la
cámara y vuelva a cargarla con un rollo nuevo de película KODAK ADVANTIX.
• El FSI en el cartucho de película
completamente expuesto estará en 6 (posición #3) y el panel LCD demostrará “E”.
automático de la película oprima cuidadosamente el BOTÓN DE
REBOBINADO
DE PELÍCULA (4) usando un
objeto puntiagudo.
automático.
SELECT
ENTER
ON
OFF
61
CUIDADO DE LA CÁMARA
1. Proteja la cámara del polvo, humedad,
golpe repentino, y calor excesivo. PRECAUCIÓN: No use solventes o
soluciones ásperas o abrasivas en el cuerpo de la cámara.
2. Si el lente se ve sucio, cúbralo con su aliento para empañarlo y limpie la superficie cuidadosamente con un paño suave que no tenga pelusas o con un pañuelo especialmente diseñado para la limpieza de lentes. Nunca limpie el lente en seco.
PRECAUCIÓN: No use solventes o soluciones que no hayan sido diseñadas para la limpieza de lentes de cámaras. No use pañuelos con químicos diseñados para la limpieza de gafas.
62
3. Remueva la batería cuando vaya a guardar la cámara por un largo período.
PRECAUCIÓN: Para prevenir la posibilidad de daño y choque eléctrico, no trate, usted mismo, de desarmar o reparar la cámara o la unidad del flash.
PROBLEMAS Y SOLUCIONES
Problema Causa probable Solución
La cámara no funciona No quedan más fotografías Retire la película
La batería está débil, Reemplace o vuelva a descargada, mal colocada, cargar la batería o falta colocarla
La película no avanza La batería está débil, Reemplace o vuelva a o se rebobina descargada, mal colocada, cargar la batería
o falta colocarla
El panel LCD está La batería está débil, Reemplace o vuelva a en blanco descargada, mal colocada, cargar la batería
o falta colocarla La cámara está en el modo Oprima cualquier botón
de apagado automático de control para activar
la cámara
La cámara está apagada Ponga el interruptor
encender/apagar en ENCENDER
El cartucho de la película no Carada con película Solamente ponga cabe completamente dentro expuesta (), parcialmente película nueva (●) del compartimiento de expuesta (), o en la cámara película; la puerta del com- película procesada (■) partimiento de película no cierra
63
ESPECIFICACIONES
Tipo de película: Película KODAK ADVANTIX para fotografías a color y
Lente: 24– 48 mm, lente zoom híbrico esférico Sistema de enfoque: 70 zonas AF Enfoque Visor: Imagen real con formato C, H, & P Sensibilidad de película: DXIX (ISO) 50– 1600 para fotografías a color y blanco
Unidad del flash: Integrado/se levanta automáticamente, flash
Alcance del flash
Abertura de diafragma: ƒ/4.5–f/8.6 Obturador: Obturador electrónico programado, 1/5 a 1/360 segundos Fuente de energía: Primaria: una batería de litio de 3 voltios KODAK K123LA
Dimensiones: 4.5 x 2.5 x 1.3” (114 x 64 x 34 mm) Peso: 6.9 onzas (195 g) sin película ni batería
64
(luz del día
(ISO 200)
blanco y negro
): Gran angular/telefotográfico: 2 pies (0,6 m) a infinito
y negro
KODAK SENSALITE™
: Gran angular: 2 a 27 pies (0,6 a 8,2 m)
Telefotográfico 2 a 14 pies (0,6 a 4,3 m)
(o su equivalente)
El símbolo y logotipo de Kodak, Sensalite, Advantix,
y el Advanced Photo System son marcas registradas
Loading...
